USER MANUAL GPB 18V2 SC Professional BOSCH
(17) Rechargeable battery
(18) Button cell cover (19) Utility hook (20) Power supply
(country-specific) (21) Power supply plug-in connector
(22) Power supply connection socket (23) USB charging socket (24) AUXIN socket (25) AUX cable
Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Display Elements (a) Bluetooth® indicator (b) Audio source indicator (c) Storage space indicator (d) Radio frequency indicator (GPB18V‑2C) (e) Menu function indicator (f) Pause indicator (g) Mute indicator (h) Stereo indicator (i) Battery charge indicator (j) Time Indication (k) Multi-function indicator (GPB18V‑2SC) Technical Data Construction site radio GPB 18V-2 C GPB 18V-2 SC Article number 3601DA30.. 3601DA31.. DAB+ reception – ● Operating voltage – For operation with power supply V 18 18 – For battery operation V 18 18 Nominal output of amplifier W 2×7.5 2×7.5 FM reception range MHz 87.5−108 87.5−108 DAB+ reception range MHz − 174.928−239.200 Bluetooth® compatibility Bluetooth® Spec.5 Bluetooth® Spec.5 Bluetooth® operating frequency range MHz 2402−2480 2402−2480 Max. Bluetooth® transmission power mW 10 10 1 609 92A 7E7 | (18.03.2022) Bosch Power ToolsEnglish | 15 Construction site radio GPB 18V-2 C GPB 18V-2 SC Coin cell (back-up battery) CR2032 3V lithium battery CR2032 3V lithium battery Weight according to EPTA-Procedure 01:2014 kg 2.8−3.9
IP54 (dust and splash- proof) IP54 (dust and splash- proof) Recommended ambient temperature during charging °C 0 to +35 0 to +35 Permitted ambient temperature during operation
When the battery cover(12) and connector compartment(15) are closed C) Limited performance at temperatures <0°C Power supply Article number 1619PB4… 1600A02… Input voltage V~ 100−240 Input AC frequency Hz 50−60 Input current mA 800 Output voltage V= 18 Power supply Output current A 1.8 Weight according to EPTA-Pro- cedure01:2014 – 1619PB4… kg 0.21 – 1600A02… kg 0.22 Protection class
