Product type	Cordless hand vacuum cleaner
Brand	Scheppach
Model	BC-VC250-X
Rated voltage	20 V
Suction power	16 kPa
Airflow	11 l/s
Dust container capacity	0.6 L
Weight (without battery)	1.2 kg
Protection class	IPX0
Suction levels	2 levels (Normal and Intensive)
Motorized roller brush	Yes, integrated in floor nozzle
Battery type	Lithium-ion, 20V IXES series (not included)
Filtration system	Filter cartridge with paper filter and foam filter
Included accessories	Floor nozzle, crevice tool, upholstery nozzle, extension hose, wall mount
Intended use	Dry surfaces only
Recommended maintenance	Regular filter cleaning and dust container emptying
Warranty	5 years (extendable to 10 years upon registration)
Compliance standards	CE, EU directives 2014/30/EU, 2014/35/EU, 2011/65/EU

Frequently Asked Questions - BC-VC250-X SCHEPPACH

How to empty the dust container?

Stop the vacuum and remove the battery. Press the release button (5a) to remove the container. Open the lid (5b) by operating the release (5c) and empty the container. Close the lid until it clicks. Put the container back in place, making sure it locks properly.

How to clean the filter?

Remove the container and take out the filter cartridge (5d). Unscrew the paper filter (5e) and tap it on a hard surface. Remove the foam filter (5f) and wash it in lukewarm water. Clean the cartridge with a brush. Let all parts dry completely before reassembling.

Which accessories are included with the vacuum?

The vacuum is supplied with: a floor nozzle (7) with motorized roller brush, a crevice tool (8), an upholstery nozzle (8a), an extension hose (6), a wall mount (9) with screws and wall plugs, and the instruction manual.

Can I vacuum liquids?

No, the vacuum is designed only for dry surfaces. It is forbidden to vacuum wet, flammable, explosive or harmful substances. This could damage the appliance and pose a fire risk.

How to change the suction level?

The vacuum has two suction levels. Use the suction level switch (1a) to switch between levels. Level 1 is for hard floors and low-pile carpets, level 2 for thick carpets or intensive cleaning. The display (1b) shows the active level.

How to clean the roller brush?

To clean the roller brush (7b), fold down the locking tab (7c) and remove the brush from the guide. Clean it to remove dirt and wound fibers. Put it back in the floor nozzle until it clicks.

Can I use the vacuum without a filter?

No, never use the vacuum without a filter. Operating without a filter can damage the motor and reduce performance. Make sure the filter is properly installed before each use.

How to install the wall mount?

Choose a suitable location without hidden pipes. Drill holes for the wall plugs (9b) and fix the wall mount (9) horizontally with the screws (9a). Hang the vacuum. Make sure the installation is secure to prevent falls.

What to do if the vacuum does not start?

First check that the battery is charged and correctly inserted (a click should be heard). If the problem persists, check the On/Off switch. If the vacuum still does not work, contact after-sales service. Also consult the troubleshooting table in the manual.

What is the warranty period of the vacuum?

The warranty is 5 years from the date of purchase. For batteries, the warranty is 12 months. You can extend the warranty to 10 years by registering your product on the Scheppach website within 30 days of purchase. The warranty does not cover normal wear and tear or damage due to improper use.

USER MANUAL BC-VC250-X SCHEPPACH

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

Revision date 25.04.2024

https://shop.scheppach.com/contact

1 Introduction 15 2 Proper use. 15 3 Product description (Fig. 1-11) 15 4 Scope of delivery (Fig. 2) 16 5 Unpacking 16 6 Technical data. 16 7 Safety instructions. 16 8 Assembly. 17 9 Before commissioning. 18 10 Operation 18 11 Cleaning and maintenance 19 12 Storage and transport 20 13 Repair and ordering spare parts 20 14 Disposal and recycling 20 15 Troubleshooting 21 16 EU Declaration of Conformity 22 17 Warranty conditions - Scheppach 20V IXES series 22 18 Exploded view. 243

Explanation of the symbols on the product

Symbols are used in this manual to draw your attention to potential hazards. The safety symbols and the accompanying explanations must be fully understood. The warnings themselves will not rectify a hazard and cannot replace proper accident prevention measures.

	Before commissioning, read and observe the operating manual and safety instruc-tions!
Lithium	Lithium-ion battery
CE	The product complies with the applicable European directives.
A	The product complies with the applicable Serbian directives.

1 Introduction

Manufacturer:

Scheppach GmbH

Günzburgrueger Straße 69

D-89335 Ichenhausen

Note:

In accordance with the applicable product liability laws, the manufacturer of this product assumes no liability for damage to the product or caused by the product arising from:

• Improper handling, non-compliance with the operating manual
• Repairs carried out by third parties, unauthorized specialists
• Installing and replacing non-original spare parts
• Improper use

Note:

The operating manual is part of the product and contains important information for safe, proper, and economical operation. Please also observe the applicable national regulations. Read all operating and safety instructions carefully before use and only use the product as described. Keep the manual and pass it on when you give the product to someone else.

2 Proper use

The product is suitable for vacuuming dry surfaces. It can only suck up dry suction material. The vacuuming of wet, flammable, explosive, or hazardous substances is forbidden.

The product may only be used in the intended manner. Any use beyond this is improper. The user, not the manufacturer, is responsible for damages or injuries of any type resulting from this.

An element of the intended use is also the observance of the safety instructions, as well as the assembly instructions and operating information in the operating manual.

Persons who operate and maintain the product must be familiar with the manual and must be informed about potential dangers.

The liability of the manufacturer and resulting damages are excluded in the event of modifications of the product.

The product may only be operated with original parts and original accessories from the manufacturer.

The safety, operating and maintenance specifications of the manufacturer, as well as the dimensions specified in the technical data, must be observed.

Please note that our products were not designed with the intention of use for commercial or industrial purposes. We assume no guarantee if the product is used in commercial or industrial applications, or for equivalent work.

3 Product description (Fig. 1-11)

1. On/off switch 1a. Suction level switch 1b. Suction level indicator
2. Handle
3. Battery mount 3a. Battery* 3b. Release button
4. Product body 4a. Suction connection 4b. Motor air filter 4c. Foam filter
5. Collection bucket 5a. Release button 5b. Dust canister lid 5c. Lid release 5d. Filter cartridge 5e. Paper filter 5f. Foam filter
6. Extension pipe 6a. Release button
7. Floor nozzle

7a. Release button

7b. Brush roller

7c. Release slide

1. Joint nozzle

8a. Upholstery nozzle

8b. Release button

8c. Brush latch

1. Wall bracket

9a. Screw

9b. Plastic wall plugs

^* = may not be included in the scope of delivery!

4 Scope of delivery (Fig. 2)

Item Quantity Designation

6.1 x Extension pipe

1. 1 x Floor nozzle

8.1 x Joint nozzle

8a. 1 x Upholstery nozzle

9.1 x Wall bracket

9a. 2 x Screw

9b.2 x Plastic wall plugs

1 x Cordless hand-held vacuum cleaner

1 x Operating manual

5 Unpacking

WARNING

The product and the packaging material are not children's toys!

Do not let children play with plastic bags, films or small parts! There is a danger of choking or suffocating!

• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport damage. Immediately report any damage to the transport company that delivered the product. Later claims will not be recognised.
• If possible, keep the packaging until the expiry of the warranty period. Familiarise yourself with the product by means of the operating manual before using for the first time.
• With accessories as well as wearing parts and replacement parts use only original parts. Spare parts can be obtained from your specialist dealer.
• When ordering please provide our article number as well as type and year of manufacture for the product.

6 Technical data

Rated voltage 20V	---
Suction power 16 kPa
Suction capacity	11 l/s
Protection category	IPX0
Capacity (collection bucket)	0.6 l
Weight (without battery)	1.2 kg

Subject to technical changes!

Explanation of the signal words in the operating manual

DANGER

Signal word to indicate an imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Signal word to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

Signal word to indicate a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.

ATTENTION

Signal word to indicate a potentially hazardous situation which, if not avoided, could result in product or property damage.

7 Safety instructions

WARNING

Read all safety warnings, instructions, illustrations and specifications provided with this power tool.

Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

General safety instructions

• This product can be used by children from 8 years of age as well as by persons with reduced physical, sensory or mental capabilities or with a lack of experience or knowledge, if they are supervised or if they have been trained in the safe use of the product and understand the resultant hazards. Children may not play with the product. Cleaning and user maintenance must not be carried out by children unsupervised.

ATTENTION

The following safety measures for protection against electric shock, and the risk of injury and fire must be observed when using electric tools:

It will help you avoid accidents and injuries

• Never leave a product ready for operation unattended at the workplace.

People and animals must not be suctioned with the product. - Never point the product or nozzles at yourself or others, especially your eyes and ears, during operation. There is a danger of injury. - Do not suck up any hot, glowing, flammable, explosive or hazardous substances. These include hot ash, petrol, solvents, acids or alkalis. There is a risk of fire and injury. - Check the product and accessories regularly for damage. Do not use a damaged product or accessories.

To avoid accidents and injuries due to electric shock

• Switch off the product:
• when the product is not in use, is being transported or is unattended.
• when checking the device, it is raining or when removing blockages.
• when cleaning or performing maintenance or changing accessories.
• after contact with foreign objects or in the event of abnormal vibrations.
• Do not immerse the product in water and do not operate it in a damp environment.
• Never immerse the product in water or other liquids for cleaning.
• Do not touch the product with damp or wet hands!

This way, product damage and any resulting personal injury can be avoided.

• Ensure that the product is correctly assembled and that the filters are in the correct position.
• Do not work without a filter. The product may become damaged.
• Only use original spare parts and accessories (see "Spare parts/accessories") supplied and recommended by our Service Centre. Using third-party parts leads to a loss of guarantee claims.
• Only have repairs carried out by authorised service centres.
• Follow the instructions for cleaning and maintaining the product.
• Store the product in a dry place and out of reach of children.

Residual risks

The product has been built according to state-of-the-art and the recognised technical safety rules. However, individual residual risks can arise during operation.

• Damage to hearing if the stipulated hearing protection is not worn.
• Residual risks can be minimised if the "Safety Instructions" and the "Intended Use" together with the operating manual as a whole are observed.
• Use the product in the way that is recommended in this operating manual. This is how to ensure that your product provides optimum performance.
• Furthermore, despite all precautions having been met, some non-obvious residual risks may still remain.

WARNING

This power tool generates an electromagnetic field during operation. This field can impair active or passive medical implants under certain circumstances. In order to prevent the risk of serious or deadly injuries, we recommend that persons with medical implants consult with their physician and the manufacturer of the medical implant prior to operating the power tool.

WARNING

In case of extended working periods, the operating personnel may suffer circulatory disturbances in their hands (vibration white finger) due to vibrations.

Raynaud's syndrome is a vascular disease that causes the small blood vessels on the fingers and toes to cramp in spasms. The affected areas are no longer supplied with sufficient blood and therefore appear extremely pale. The frequent use of vibrating products can cause nerve damage in people whose circulation is impaired (e.g. smokers, diabetics).

If you notice unusual adverse effects, stop working immediately and seek medical advice.

ATTENTION

The product is part of the 20V IXES series and may only be operated with batteries of this series. Batteries may only be charged with battery chargers of this series. Observe the manufacturer's instructions.

WARNING

Follow the safety and charging instructions and correct usage given in the instruction manual of your 20V IXES Series battery and charger. A detailed description of the charging process and further information are provided in this separate manual.

8 Assembly

8.1 Fitting the wall bracket (9) (Fig 3)

WARNING

• Before wall mounting, make sure that there are no lines in the wall in the area of the drill holes that could be damaged.
• Children must not play with the product, even if it is hanging on the wall.
• Mounting behind doors and their swinging range is not recommended, as there is a risk of tearing off or otherwise damaging the product.

WARNING

Risk of damage to supply lines

Contact with electric lines may cause electric shock and fire, contact with a gas line may cause explosion. Damage to a water pipe can cause damage to property and electric shock.

• When drilling for wall mounting, make sure that there are no supply lines in the wall in the area of the drill holes that could be damaged.
• Find a suitable place for the wall bracket (9).
• Mount the wall bracket (9) using the screws (9a) and plastic wall plugs (9b) included in the scope of delivery.
• Ensure that the wall bracket (9) is fixed horizontally.

9 Before commissioning

CAUTION

Danger of injury!

Do not insert the battery until the battery-powered tool is ready for use.

9.1 Selecting the tool attachment (Fig. 4 5)

Floor nozzle (7)

Vacuuming floor areas, carpets or floor mats. - Drives the brush roller via a motor.

Joint nozzle (8)

• Vacuuming joints, corners, radiators and hard-to-reach areas.

Upholstery nozzle (8a)

• Vacuuming seating furniture, sofa sets and upholstered surfaces.

9.1.1 Inserting/removing the tool attachment

1. Choose the right tool attachment for your project: Floor nozzle (7), joint nozzle (8) or upholstery nozzle (8a). You can combine any tool attachment with the extension tube (6) as required. Consider in advance whether the extension tube (6) is required for your application.
2. Place the selected tool attachment (7, 8, 8a), optionally with the extension tube (6), on the suction connection (4a). Ensure that the connection latches into place audibly.
3. To remove the tool attachment (7, 8, 8a) or the extension tube (6), press and hold the respective release button (6a, 7a, 8b).
4. Carefully pull the tool attachment (7, 8, 8a) or the extension tube (6) off the suction connection (4a).

9.2 Inserting/removing the battery (3a) (Fig. 6)

Inserting the battery

1. Push the battery (3a) into the battery mount (3). The battery (3a) clicks into place audibly.

Removing the battery

1. Press the unlocking button (3b) of the battery (3a) and remove the battery (3a) from the battery mount (3).

10 Operation

The product is equipped with a sturdy, transparent plastic bucket for collecting dirt.

Please refer to the following descriptions for the function of the controls.

ATTENTION

Make sure that the ambient temperature does not exceed 50°C and does not fall below -20°C during work.

ATTENTION

The product is part of the 20V IXES series and may only be operated with batteries of this series. Batteries may only be charged with battery chargers of this series. Observe the manufacturer's instructions.

10.1 Switching the product on/off (Fig. 7)

ATTENTION

Do not use without a filter!

Switching on

1. Switch the product on by pressing the on/off switch (1).

Switching off

1. Switch off the product by pressing the on/off switch (1) again.

10.2 Suction levels

The product has two suction levels. The suction level switch (1a) can be used to change the suction level by pressing it once. The current suction level is indicated by the suction level indicator (1b).

Level 1:

• Provides normal suction power and brush roller speed (7b).
• Ideal for cleaning hard floors and short-pile carpets.
• Recommended if a longer running time is required.

Level 2:

• Enables a higher suction power and a higher brush roller speed (7b).
• Ideal for cleaning plush carpets or when a stronger cleaning performance is required.
• Shortens the battery runtime.

10.3 Overload switch-off

ATTENTION

Important information

In the event of overloading, the motor will switch itself off. After a cool-down period (time varies) the motor can be switched back on again.

1. Switch the product off.
2. Remove the battery.
3. Check whether there is a blockage or obstruction.

10.4 Emptying the dust canister (5) (Fig. 8)

WARNING

Empty and clean the product before and after use to avoid the accumulation of materials that could pose a fire risk in the product.

WARNING

Switch off the product and remove the battery!

The product can be damaged if the dust canister (5) is too full of dust.

1. Remove the dust canister (5) by pressing and holding the release button (5a).
2. Tilt the dust canister (5) slightly forwards and remove the dust canister (5) upwards.
3. Position the dust canister (5) over a waste container.
4. Press the lid release (5c) so that the dust canister lid (5b) opens downwards.
5. Empty the collection bucket (5).
6. Close the dust canister lid (5b) until you hear it click into place.
7. If necessary, clean the dust canister (5) with a damp cloth. If necessary, clean the filter cartridge (5d) as described at 11.1.1.
8. Reattach the dust canister (5) to the product. Fit the dust canister (5) to the underside. Ensure that the nose on the dust canister (5) is positioned in the recess on the body of the product (4) and snap it into the release on the top side.

11 Cleaning and maintenance

WARNING

Have maintenance and repair tasks that are not described in this operating manual, carried out by a specialist workshop. Use only original spare parts.

WARNING

Improper maintenance or cleaning work can cause injuries!

WARNING

The product may start unexpectedly and cause injuries and burns during cleaning, repair and maintenance work.

• Switch the product off.
• Remove the battery.
• Allow the product to cool.

11.1 Cleaning

1. Never immerse the product in water or other liquids for cleaning.
2. Do not splash the product with water.
3. Keep protective devices, air vents and the motor housing as free of dust and dirt as possible. Rub the product clean with a clean cloth or blow it off with compressed air at low pressure. We recommend that you clean the product directly after every use.
4. Ventilation openings must always be free.
5. Do not use any cleaning products or solvents; they could attack the plastic parts of the product. Make sure that no water can penetrate the product interior.

11.1.1 Cleaning the filter cartridge (5d) (Fig. 9)

Clean the filter cartridge (5d) if the suction capacity decreases.

1. Remove and empty the dust canister (5) as described in 10.4.
2. Carefully pull the filter cartridge (5d) upwards out of the dust canister (5).
3. Unscrew the paper filter (5e) from the filter cartridge (5d) by turning it anti-clockwise.
4. Tap the paper filter (5e) on a hard surface. Make sure that you do not damage the paper filter (5e) in the process.
5. Remove the foam filter (5f) from the filter cartridge (5d).
6. Clean the foam filter (5f) carefully under lukewarm running water.
7. Remove the dust from the filter cartridge (5d) with a brush* and wash out the filter cartridge (5d) if necessary.
8. Allow all wet or damp elements to dry completely before reassembling the filter cartridge (5d).
9. Check all elements for cracks or other damage. Replace any damaged components immediately.
10. Place the dried foam filter (5f) back into the filter cartridge (5d). Screw the paper filter (5e) back on by turning it clockwise.
11. Re-insert the filter cartridge (5d) into the dust canister (5).
12. Reattach the dust canister (5) to the product.

^* = may not be included in the scope of delivery!

11.1.2 Cleaning the brush roller (7b) (Fig.10)

The brush roller (7b) is located in the floor nozzle (7). The brush roller (7b) should be cleaned regularly to ensure optimum cleaning performance.

1. Pull the release slide (7c) backwards.
2. Pull the brush roller (7b) out of the guide.
3. Clean the brush roller (7b) of dirt and anything that has become wrapped around the brush roller (7b).
4. Re-insert the brush roller (7d) into the floor nozzle (7). The brush roller (7b) clicks into place audibly.

11.1.3 Cleaning the motor air filter (4b) (Fig. 11)

There are ventilation inlets on the body of the product (4) to cool the motor. A motor air filter (4b) is installed to protect the motor from dust and dirt. Clean it regularly to increase the service life of your product.

1. Pull the motor air filter (4b) out of the body of the product (4).
2. Remove the foam filter (4c) and clean it carefully under lukewarm running water.
3. Allow the foam filter (4c) to dry completely before reinserting it.
4. Slide the motor air filter (4b) back into the body of the product (4).

11.2 Maintenance

The product is maintenance-free.

1. Check the product for obvious defects such as loose, worn or damaged parts before each use.

12 Storage and transport

WARNING

Danger of injury and burning!

The product can start unexpectedly and cause injuries.

• Switch off the engine before carrying out any cleaning or maintenance work.
• Allow the engine to cool down.
• Remove the battery.

12.1 Storage

Preparation for storage

1. Remove the battery from the product before prolonged storage (e.g., winter storage).
2. Clean and check the product for damage.
3. Store the battery in a partially charged state.
4. When stored, check the battery charge level every three months.

Store the product and its accessories in a dark, dry, and frost-free place that is inaccessible to children. The optimum storage temperature is between 5°C and 30°C.

Store the product in its original packaging.

Cover the product to protect it from dust or moisture. Store the operating manual with the product.

13 Repair and ordering spare parts

With this product, it is necessary to note that the following parts are subject to natural or usage-related wear, or that the following parts are required as consumables.

ATTENTION

According to the German Product Liability Act, no liability is accepted for damage caused by improper repairs or by not using original spare parts.

Such work should be performed by a customer service centre or an authorised specialist. The same applies to accessory parts.

Spare parts and accessories can be obtained from our Service Centre. To do this, scan the QR code on the front page.

13.1 Ordering spare parts

Please provide the following information when ordering spare parts:

• Model designation
• Item number
• Type plate data

Spare parts / accessories

Battery pack SBP2.0 - Article no.: 7909201708

Battery pack SBP4.0 - Article no.: 7909201709

Battery charger SBC2.4A - Article no.: 7909201710

Battery charger SBC4.5A - Article no.: 7909201711

Battery charger SDBC2.4A - Article no.: 7909201712

Battery charger SDBC4.5A - Article no.: 7909201713

StarterKit SBSK2.0 - Article no.: 7909201720

StarterKit SBSK4.0 - Article no.: 7909201721

14 Disposal and recycling

Notes for packaging

The packaging materials are recyclable. Please dispose of packaging in an environmentally friendly manner.

Notes on the disposal of electrical and electronic equipment

Waste electrical and electronic equipment does not belong in household waste, but must be collected and disposed of separately!

• Used batteries that are not installed permanently in the old device must be removed non-destructively before disposal! Their disposal is regulated by the battery act.
• Owners or users of electrical and electronic devices are legally obliged to return them after use.
• The end user is responsible for deleting their personal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that waste electrical and electronic equipment must not be disposed of with household waste.
• Waste electrical and electronic equipment can be handed in free of charge at the following places:

Public disposal or collection points (e.g. municipal works yards) - Points of sale of electrical appliances (stationary and online), provided that dealers are obliged to take them back or offer to do so voluntarily. - Up to three waste electrical devices per type of device, with an edge length of no more than 25 centimetres, can be returned free of charge to the manufacturer without prior purchase of a new device from the manufacturer or taken to another authorised collection point in your vicinity.

Further supplementary take-back conditions of the manufacturers and distributors can be obtained from the respective customer service.

• If the manufacturer delivers a new electrical appliance to a private household, the manufacturer can arrange for the free collection of the old electrical appliance upon request from the end user. Please contact the manufacturer's customer service for this. These statements only apply to devices installed and sold in the countries of the European Union and which are subject to the European Directive 2012/19/EU. In countries outside the European Union, different regulations may apply to the disposal of waste electrical and electronic equipment.

Notes on lithium-ion batteries

Remove the battery before disposing of the device!

• Do not dispose of batteries in household waste, in a fire (risk of explosion) or in water. Damaged batteries can harm the environment and your health if toxic vapours or liquids escape. Defective or used batteries must be recycled in accordance with Regulation (EU) 2023/1542.
• Hand in the battery and the battery charger at a recycling centre. The plastic and metal parts used can be separated by type and thus recycled.
• Dispose of batteries when discharged. We recommend covering the poles with an adhesive strip to protect against a short circuit. Do not open the battery.
• Dispose of batteries in accordance with local regulations. Return batteries to a used battery collection point where they can be recycled in an environmentally friendly manner. Ask your local waste disposal company about this.

15 Troubleshooting

Fault Possible cause Remedy
The product cannot be started. The battery power is too weak. Charge the battery.
The battery is not properly inserted.	Push the battery into the battery mount. The battery clicks into place audibly.
On/off switch defective Please contact our service department.
Motor defective.
Product works with interruptions.	Internal loose contact. Please contact our service department.
On/off switch defective.
The suction capacity is reduced and the product does not suck up dirt.	The collection bucket is full. Empty the collection bucket.
	The airway is blocked.	Check the following parts for blockages and remove the blockages: •Drip tray •Extension pipe •Joint/floor/upholstery nozzle
	The filter cartridge is blocked.	Clean the filter cartridge.
The suction capacity is also reduced after cleaning the filter insert.	The filter insert is damaged.	Please contact our service department.
The product is overheated.	The filter element is blocked.	Clean the filter insert.
Dust escapes from the product.	The collection bucket has not been installed correctly.	Attach the collection bucket correctly.

16 EU Declaration of Conformity

Translation of the original Declaration of Conformity

Manufacturer:

Scheppach GmbH

Günzburgerstraße 69

D-89335 Ichenhausen

We declare under our sole responsibility that the product described here complies with the applicable directives and standards.

Brand: SCHEPPACH

Art. designation: Cordless hand-held vacuum cleaner - BC-VC250-X

Art.no.5909277900

EU directives:

2014/30/EU, 2011/65/EU*, 2014/35/EU,

• The object of the declaration described above fulfils the regulations of the directive 2011/65/EU of the European Parliament and Council from 8th June 2011, on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

Applied standards:

EN IEC 60335-2-2:2023/A11:2023;

EN 60335-1:2012/A16:2023;

EN 62233:2008, EN IEC 55014-1:2021;

EN IEC 55014-2:2021;

Documentation authorised representative:

Georg Kohler

Günzburger Str. 69

D-89335 Ichenhausen

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

Revision date 25/04/2024

Dear customer,

Our products are subject to strict quality checks. However, if a product does not function perfectly, we deeply regret this and ask that you contact our customer service at the address specified below. We will also be glad to assist you by telephone via the service number. The following information is intended to help you to process and settle your claim without any problems.

For the assertion of warranty claims, the following applies:

1. The warranty conditions govern our additional manufacturer warranty services for purchasers (private end consumers) of new products. The statutory warranty claims are not affected by this warranty. This is the responsibility of the dealer who you purchased the product from.
2. The manufacturer's warranty only covers defects in a new product purchased by you that are due to a material or manufacturing defect. If material or manufacturing defects occur during the warranty period, the manufacturer as guarantor shall provide one of the following services of its choice under this warranty:

Free repair of the goods

Free replacement of the goods with an item of equal value (if necessary also replacement with a successor model if the original goods are no longer available).

Replaced products or parts shall become our property. Please note that our products were not designed for commercial, trade or professional use. A warranty claim is therefore not valid if the product has been used in commercial, trade or industrial operations within the warranty period or has been subjected to equivalent stress.

3. The following are excluded from our warranty services:

• Damage to the product which was caused by non-observance of the assembly instructions, improper installation, non-observance of the operating instructions (e.g. connection to an incorrect mains voltage or type of current) or the maintenance and safety regulations or use of the product in unsuitable environmental conditions as well as by insufficient care and maintenance.
• Damage to the product caused by misuse or improper application (such as overloading the product or using non-approved tools and accessories), penetration of foreign bodies into the product (such as sand, stones or dust), transport damage, use of force or external influences (such as damage caused if dropped).
• Damage to the product or parts of the product which is due to intentional, normal (operational) or other natural wear as well as damage and/or wearing of wear parts.

Defects in the product which have been caused by the use of accessories, expansions or spare parts that are not original parts or are not used as intended.

• Products on which changes or modifications have been made.
• Minor deviations from the target characteristics which are irrelevant for the value and usability of the product.
• Products on which unauthorised repairs have been carried out, in particular by an unauthorised third party.
• If the marking on the product or the identification information of the product (machine label) is missing or illegible.
• Products that are very dirty and are therefore refused by the service personnel.
• Claims for damages and consequential damages are generally excluded from this warranty.
• The warranty period is usually 5 years (12 months for batteries/rechargeable batteries) and starts from the date of purchase of the product. The date on the original purchase receipt is decisive. Warranty claims must be made immediately after becoming aware of them. The assertion of warranty claims after expiry of the warranty period is excluded. The repair or replacement of the product does not result in an extension of the warranty period, nor does this service initiate a new warranty period for the product or for any installed spare parts. This also applies when using an on-site service. A prerequisite for a claim under the warranty is that the manufacturer, as the guarantor, is enabled to examine the warranty claim by sending in the goods at the manufacturer's request. Care must be taken to avoid damage during transport by using appropriate packaging. The product concerned is to be cleaned and returned to the service centre together with a copy of the purchase receipt, which must include the date of purchase and the product designation. If a product is sent in incomplete without the complete scope of delivery, the missing accessories will be charged / deducted in value if the product is exchanged or in the event of a refund. Partially or completely dismantled products cannot be accepted as a warranty claim. In the event of an unjustified complaint or if outside the warranty period, the purchaser shall generally bear the transport costs and the transport risk. Please report a warranty claim in advance to the service centre (see below). It is generally agreed upon that the defective product will be returned to the service address given below with a brief description of the fault by organised return or, in the case of repair outside the warranty period, with sufficient postage, taking the appropriate packaging and shipping guidelines into account. Please note that your product (depending on the model) will be free of all operating materials when returned for safety reasons. The product sent to our service centre must be packaged in such a way that damage to the product under complaint is avoided during transport. After successful repair / replacement, we will send the product back to you free of charge. If products cannot be repaired or replaced, a sum up to the purchase price of the defective product may be refunded at our own discretion, taking into account any deduction for wear and tear. These warranties are only for the benefit of the original private purchaser and cannot be assigned or transferred.
• Extension of the warranty period to 10 years: Scheppach offers an additional warranty extension of 5 years on products of the Scheppach 20V series. Thus, the warranty period for these products totals 10 years. Batteries / rechargeable batteries, battery chargers and accessories are excluded from this. You can claim this warranty extension by registering your Scheppach product from this range at https://garantie.scheppach.com no later than 30 days from the date of purchase. After registering online successfully, you will receive confirmation for the item-related warranty extension.
• In order to submit your warranty claim, please contact our service centre.

Preferably, please use our form on our homepage:

https://shop.scheppach.com/contact

Please do not send us any products without first contacting and registering with our service centre.

Contacting our service centre first is mandatory to claim these warranty promises. Warranty claims must be made before expiry of the warranty period within 14 days of discovery of the defect. For this purpose, the original purchase receipt and, if necessary, confirmation of the item-related warranty extension are required.

1. Processing time - We normally process complaint consignments within 14 days of receipt at our service centre. If, in exceptional cases, the processing time mentioned is exceeded, you will be informed in good time.
2. Wear parts are generally excluded from the warranty! - Wear parts are: a) supplied, attached and/or installed batteries / rechargeable batteries as well as b) all model-dependent wear parts (i.e. belts, saw blades, tool attachments, grinding discs, filters, carbon brushes etc., see operating manual). The warranty does not cover batteries or rechargeable batteries that are deeply discharged or those with damaged housing or battery terminals.
3. Cost estimate - Products that are not covered or no longer covered by the warranty will be repaired at extra cost. Upon request to our service centre, you can send in the defective products for a cost estimate and, if necessary, give the service centre approval for the repair in writing (by post, e-mail). No further processing will take place without approval for the repair.

The warranty conditions only apply in the current version at the time of the complaint and, if necessary, can be found on our homepage (www.scheppach.com).

In case of translations, the German version is decisive.

Scheppach GmbH · Günzburger Str. 69

89335 Ichenhausen (Germany)

Tel: [phone]

E-Mail: [e-mail]

Internet: https://www.scheppach.com

We reserve the right to make changes to the warranty conditions at any time without prior notice.

Division Manager Product Center

Andreas Pecher

Head of Project Management

Dear customer,

https://shop.scheppach.com/contact

Telephone: [phone]

E-mail: [e-mail]

Website: https://www.scheppach.com

Division Manager Product Center

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

[e-mail]

Internet: https://www.scheppach.com

Division Manager Product Center

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

Review date: 2024.04.25.

Dear Customer,

https://www.scheppach.com/de/service

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20 V IXES series

Revision date 25.4.2024.

Dear customers,

Our products are subject to strict quality control. If, despite this, a product does not function correctly, we are very sorry about that and ask you to contact our service department at the address below. We will be happy to help you by phone at the service department's phone number. The following notes serve you for simple processing and regulation in the event of damage.

https://shop.scheppach.com/contact

Do not send us products without prior contact and registration with our service center.

12 Storage and transport

WARNING

Danger of injury and burns!

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

Revision date 25.04.2024

Dear customer,

https://shop.scheppach.com/contact

Please do not send us any products without first contacting us and registering with our service center.

General safety instructions

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty Terms - Scheppach 20V IXES series

https://shop.scheppach.com/contact

E-mail: [e-mail]

Internet: https://www.scheppach.com

We reserve the right to change these warranty terms at any time without prior notice.

Contents

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty Terms – Scheppach 20V IXES series

Review date 2024-04-25

Dear customers.

https://shop.scheppach.com/contact

Do not send us any products without first contacting our technical support center and registering with them.

Günzburger Straße 69

D-89335 Ichenhausen

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

Do not send us any products without first contacting our service center and registering with them.

Email: [e-mail]

Internet: https://www.scheppach.com

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty Terms - Scheppach 20V IXES Series

Revision date 2024-04-25

Aradekund.

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

https://shop.scheppach.com/contact

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

Revision date 25-04-2024

Dear customer,

https://shop.scheppach.com/contact

Please do not send us products without first contacting us and registering with our service center.

Preparation for storage

1. Remove the battery from the product before storing for longer periods (e.g., over winter).
2. Clean and inspect the product for damage.
3. Store the battery in a partially charged state.
4. Check the battery charge level every three months during storage.

Spare parts / accessories

Batteri SBP2.0 artikkel-nr.: 7909201708
Batteri SBP4.0 artikkel-nr.: 7909201709
Lader SBC2.4A artikkel-nr.: 7909201710
Lader SBC4.5A artikkel-nr.: 7909201711
Lader SDBC2.4A artikkel-nr.: 7909201712
Lader SDBC4.5A artikkel-nr.: 7909201713
Startersett SBSK2.0 artikkel-nr.: 7909201720
Startersett SBSK4.0 artikkel-nr.: 7909201721

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

https://shop.scheppach.com/contact

Please do not send us any products without first contacting us and registering with our service center.

To make a claim under this warranty, first contact with our service center is a mandatory requirement. Warranty claims must be submitted within 14 days after the defect is discovered, before the warranty period expires. This requires the original purchase receipt and, if applicable, confirmation of the article-related warranty extension.

E-mail: [e-mail]

Internet: https://www.scheppach.com

Battery-powered tool for working with rechargeable batteries. Operating instructions.

9.1 Selecting the working tool (Fig. 4, 5)

Working tool (7)

• For sanding floors, walls, or ceilings. For filling and polishing.

Cutting tool (8)

• For cutting drywall, wood, panels, and hard-to-reach places.

Taper tool (8a)

• For sanding furniture, painted and varnished surfaces.

9.1.1 Installing/removing the working tool

1. Select the appropriate working tool for your project: working tool (7), cutting tool (8), or taper tool (8a). You can combine any working tool with the extension tube (6) as needed. Check in advance whether the extension tube (6) is necessary for your application. 2. Place the selected working tool (7, 8, 8a), optionally with the extension tube (6), onto the sanding pad (4a). Make sure the connection is secure. 3. To remove the working tool (7, 8, 8a) or the extension tube (6), press and hold the corresponding release button (6a, 7a, 8b).

4. Carefully remove the working tool (7, 8, 8a) or the extension tube (6) from the sanding pad (4a).

9.2 Installing/removing the battery (3a) (Fig. 6)

Use the battery pack

1. Insert the battery (3a) into the battery slot (3). The battery (3a) clicks into place.

Removing the battery pack

1. Remove the battery (3a) from the battery compartment (3) and remove the battery (3a) from the receiving slot for the battery (3).

10 Control

The products are equipped with a charger, a plastic container for collecting debris. The operation of the control unit may be impaired in the described manner.

WARNING

Make sure that the ambient temperature during operation does not exceed 50 °C and does not fall below -20 °C.

WARNING

The product is part of the 20V IXES series and can only operate with batteries from this series. The battery packs may only be charged with the charging devices from this series. When doing so, follow the manufacturer's instructions.

10.1 Switching the product on/off (Fig. 7)

WARNING

Do not use without the filter!

Switching on

1. Switch on the product by pressing the on/off switch (1).

Switching off

1. Switch off the product by pressing the on/off switch (1) again.

10.2 Locking the trigger

The degree of tightening can be changed. The degree of tightening can be changed by pressing the switch for the degree of tightening (1a). The current degree of tightening is shown by the indicator for the degree of tightening (1b).

Level 1:

• Normal tightening power and roller speed (7b). -Ideal for cleaning soft surfaces and low-friction materials. -Recommended when a longer working time is needed.

Level 2:

-Allows higher tightening power and higher roller speed (7b). -Ideal for cleaning stubborn dirt or when a stronger cleaning power is needed. Shortened working time of the product's battery.

10.3 Switching off during operation

WARNING

Important notes

When operating the motor, it switches off automatically. After a cooling period (varying in time), the motor can be switched on again.

Division Manager Product Center

Andreas Pecher

Head of Project Management

Date of change 25.04.2024

Dear customers,

If this product is the object of a quality control check and it happens that this product does not function flawlessly, we apologize for this and you can contact our service department at the address given below. We are pleased to be at your disposal for service and telephone support. The following information will help you process your claims without problems.

For warranty claims, please note the following:

1. These warranty conditions regulate our supplementary warranty services for the purchase (by private end consumers) of new products. Statutory warranty rights are not affected by this warranty. This is the responsibility of the dealer from whom you purchased the product.
2. The manufacturer's warranty covers defects in material or workmanship of the new product purchased by you. If defects in material or workmanship arise during the warranty period, the manufacturer will, at its discretion, provide the following services within the scope of this warranty:

- free repair of the product

- free replacement of the product with an article of equal value (if necessary, also replacement with a subsequent model if the original product is no longer available).

Replaced products or parts become our property. Please note that our products are not designed for commercial, industrial, or professional use. Consequently, the warranty claim is void if the product has been used for commercial, industrial, or industrial purposes during the warranty period or has been subjected to abnormal stress.

3. Our warranty conditions do not include the following:

• Damage to the product caused by failure to follow the installation instructions, incorrect installation, failure to follow the operating instructions (e.g., connection to incorrect mains voltage or current type), or the rules for maintenance and safety, or from use of the product under unsuitable environmental conditions, as well as from improper care and maintenance.

Damage to the product caused by improper use or improper handling (for example, overloading the product or using unsuitable tools or accessories), penetration of foreign bodies into the product (for example, sand, stones, or dust), damage during transport, use of force or impact (for example, damage caused by dropping).

- Damage to the product or parts of it, caused by normal, usual (operational) or other natural wear and tear, such as damage or depreciation of the wearing parts. - Damage to the product caused by the use of non-original accessories, spare parts or reserve parts that are not original or were not used for their intended purpose. - Products that have been modified or altered. - Insignificant deviations from the normal state, if they are not of significance for the value or usability of the product. - Products that have been subjected to unauthorized repair or adjustment, especially by an unauthorized third party. - If the marking on the product or the identification information for the product (sticker or machine plate) is missing or illegible. - Products that have been frozen and the damage is discovered by service personnel. - The claims for disinfection and disinsection are excluded from this warranty.

1. The warranty period is usually 5 years (12 months for batteries/accumulator batteries) and starts from the date of purchase of the product. The date of the original cash receipt for the purchase is decisive. Warranty claims must be submitted immediately after discovery. Warranty claims after the expiry of the warranty period are excluded. Repair or replacement of the product does not extend the warranty period, nor does it start a new warranty period for the product or for any installed spare parts. This also applies to on-site service. The submission of a warranty claim gives the manufacturer, as a guarantor, the opportunity to examine the warranty case upon receipt of the goods. It is important to ensure that the goods are protected from damage during transport by using suitable packaging. The defective product must be returned to the service center together with a copy of the cash receipt for the purchase, which must contain the date of purchase and the name of the product. If the product is sent without proper packaging, the accessories will be credited/deducted in value. If the product is replaced or the amount is refunded, partially or fully disassembled products cannot be accepted as warranty claims. If the complaint is unfounded or the warranty period has expired, the buyer bears the transport costs and transport risk. Please contact the service center in advance for warranty claims (see below). As a rule, it is agreed that the defective product, with a brief description of the damage, is sent through an organized carrier - in case of repair beyond the warranty period.

To obtain a replacement sum for warranty claims, you must follow the corresponding instructions for packaging and shipping to the service address, as described below. Please note that for safety reasons, your product (depending on the model) will be returned without any operating materials. Products sent to our service center must be packaged in such a way as to avoid damage to the product during transport. Once the repair/maintenance is completed, we will send the product back to you free of charge. If the product cannot be repaired or replaced, we may reimburse the purchase price of the defective product, taking into account any wear and tear. These warranty conditions apply only to the original purchaser and cannot be transferred or resold.

1. Extension of warranty period to 10 years: Scheppach offers an additional warranty extension of 5 years for products from the Scheppach 20V series. Consequently, the warranty period for these products is a total of 10 years. Excluded are batteries/accumulators, charging devices, and accessories. You can take advantage of this warranty extension by registering your Scheppach product from this series online at the address https://Garantie.scheppach.com no later than 30 days from the date of purchase. After successful online registration, you will receive confirmation of the warranty extension associated with the article.
2. To submit a warranty claim, please contact our service center.

We recommend using our contact form on our website:

https://shop.scheppach.com/contact

Please do not send any products without first contacting us and registering with our service center.

To submit a warranty claim, prior contact with our service center is required. Warranty claims must be submitted within 14 days of the defect being discovered before the warranty period expires. For this, the original purchase receipt is required, and if applicable, the warranty extension confirmation associated with the product.

1. Processing time - We process warranty claims within 14 days of their receipt at our service center. If, in exceptional cases, the processing time is extended, we will inform you in a timely manner.

8. Wearing parts are excluded from warranty by regulation! - Wearing parts are: a) supplied, attached, and/or mounted battery packs/accumulators, as well as b) all model-dependent wearing parts (including belts, saw blades, cutting tools, grinding discs, filters, carbon brushes, etc., according to the operating instructions). The warranty covers batteries or accumulators that are deeply discharged or have damaged housings or terminals.

9. Return of products - Products that are not covered by the warranty or are no longer covered by the warranty, which have been repaired for a fee. If you contact our service center, you can send the defective products for evaluation of the costs and, if necessary, give written permission to the service center for repair (by mail, email). There will be a more detailed processing without obligation for repair.

The warranty conditions apply to the current version at the time of the advertisement and can be found on our website (www.scheppach.com). In case of translation, the German version is authoritative.

Scheppach GmbH · Günzburger Str. 69

89335 Ichenhausen (Germany)

Phone: [phone]

Email: [e-mail]

Internet: https://www.scheppach.com

We reserve the right to change these warranty conditions at any time without prior notice.

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty terms - Scheppach 20V IXES series

https://shop.scheppach.com/contact

Our service center will contact you without prior communication and in writing at our service center.

The prerequisite for the acceptance of these obligations is that the first delivery is made to the company's service center. It will be understood that the delivery must be made before the start of the warranty period and within 14 days from the date of purchase. For this, it is necessary to provide proof of purchase and any extended warranty for the specific product.

89335 Ichenhausen (Germany)

Tel: [phone]

E-mail: [e-mail]

Internet: https://www.scheppach.com

We reserve the right to make changes to the warranty terms at any time without prior notice.

Table of contents

1 Introduction 216 2 Intended use 216 3 Product description (fig. 1-11) 216 4 Delivery package (fig. 2) 217 5 Unpacking 217 6 Technical data 217 7 Safety instructions 217 8 Assembly 219 9 Before commissioning 219 10 Operation 219 11 Cleaning and routine maintenance 220 12 Storage and transport 221 13 Repair and spare parts ordering 221 14 Disposal and recycling 222 15 Troubleshooting 223 16 EU Declaration of Conformity 223 17 Commercial warranty conditions - Scheppach 20V IXES series 224 18 Exploded assembly drawing 243

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Commercial warranty conditions - Scheppach 20V IXES series

Revision date 25.04.2024

Dear customer,

https://shop.scheppach.com/contact

Please do not send us any product without contacting us and registering in advance with our service center.

89335 Ichenhausen (Germany)

Phone: [phone]

E-Mail: [e-mail]

Internet: https://www.scheppach.com

We reserve the right to make changes to these warranty conditions at any time without prior notice.

Contents

1 Introduction. 226 2 Intended use 226 3 Product description (fig. 1-11) 226 4 Scope of delivery (fig. 2). 227 5 Unpacking 227 6 Technical data 227 7 Safety notes 227 8 Assembly 229 9 Before commissioning. 229 10 Operation 229 11 Cleaning and maintenance 230 12 Storage and transport. 231 13 Repair and ordering spare parts 231 14 Disposal and recycling. 231 15 Troubleshooting 232 16 EU declaration of conformity. 233 17 Warranty conditions - Scheppach 20V IXES series .. 233 18 Exploded view 243

Explanation of symbols on the product

Division Manager Product Center

Andreas Pecher

Head of Project Management

17 Warranty conditions - Scheppach 20V IXES series

Revision date 25.04.2024.

Dear customers,

Our products are subject to strict quality controls. If this device nevertheless does not work flawlessly, we apologize and ask you to contact our service department at the address given below. We are happy to assist you by phone via the service number. The notes below should help you with processing and adjustment without problems and in case of damage.

https://shop.scheppach.com/contact

Do not send us products without first contacting us and registering with our service center.

To obtain these services under warranty, you must first contact our service center. Warranty claims must be submitted before the warranty period expires within 14 days after the defect is identified. This requires the original receipt and, if necessary, proof of warranty extension for the specific product.

1. Processing time - in regular cases, we process complaint shipments within 14 days after delivery to our service center. If the stated processing time is exceeded in exceptional cases, we will inform you in a timely manner.
2. Consumable parts - consumable parts are: a) delivered, connected and/or installed batteries/rechargeable batteries as well as b) all model-dependent consumable parts (including belts, saw blades, intervention tools, grinding discs, filters, carbon brushes, etc., see the instruction manual). Completely discharged or pole-damaged batteries or rechargeable batteries are excluded from the warranty.
3. Cost calculation - products that are not or no longer covered by warranty are repaired for a fee. Upon inquiry to our service center, you can send defective devices to prepare a cost estimate and, if necessary, send written approval (by mail, e-mail) for repair to the service center. Without repair approval, further processing will not be carried out.

SCHEPPACH GMBH

Günzburger Str. 69

D-89335 Ichenhausen
