USER MANUAL EasyShear BOSCH

Warning: Keep a safe distance to the

product when operating. Do not use the product in the rain or leave it outdoors when it is raining.

Warning: The blade continues to move

after the product is switched off. Keep hands away from blade. General Power Tool Safety Warnings WARNING Read all safety warnings, instruc- tions, illustrations and specifica- tions provided with this power tool. Failure to follow all in- structions listed below may result in electric shock, fire and/ or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains- operated (corded) power tool or battery-operated (cord- less) power tool. Work area safety u Keep work area clean and well lit. Cluttered or dark areas invite accidents. u Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. u Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. Electrical safety u Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. u Avoid body contact with earthed or grounded sur- faces, such as pipes, radiators, ranges and refrigerat- ors. There is an increased risk of electric shock if your body is earthed or grounded. u Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of elec- tric shock. u Do not abuse the cord. Never use the cord for carry- ing, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. u When operating a power tool outdoors, use an exten- sion cord suitable for outdoor use. Use of a cord suit- able for outdoor use reduces the risk of electric shock. u If operating a power tool in a damp location is un- avoidable, use a residual current device (RCD) protec- ted supply. Use of an RCD reduces the risk of electric shock. Personal safety u Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inatten- tion while operating power tools may result in serious per- sonal injury. u Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection F 016 L81 893 | (09.12.2019) Bosch Power ToolsEnglish | 11 used for appropriate conditions will reduce personal in- juries. u Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or en- ergising power tools that have the switch on invites acci- dents. u Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal in- jury. u Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. u Dress properly. Do not wear loose clothing or jew- ellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. u If devices are provided for the connection of dust ex- traction and collection facilities, ensure these are con- nected and properly used. Use of dust collection can re- duce dust-related hazards. u Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe in- jury within a fraction of a second. Power tool use and care u Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was de- signed. u Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. u Disconnect the plug from the power source and/or re- move the battery pack, if detachable, from the power tool before making any adjustments, changing ac- cessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. u Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. u Maintain power tools and accessories. Check for mis- alignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. u Keep cutting tools sharp and clean. Properly main- tained cutting tools with sharp cutting edges are less likely to bind and are easier to control. u Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into ac- count the working conditions and the work to be per- formed. Use of the power tool for operations different from those intended could result in a hazardous situation. u Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations. Battery tool use and care u Recharge only with the charger specified by the manu- facturer. A charger that is suitable for one type of bat- tery pack may create a risk of fire when used with another battery pack. u Use power tools only with specifically designated bat- tery packs. Use of any other battery packs may create a risk of injury and fire. u When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. u Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally oc- curs, flush with water. If liquid contacts eyes, addi- tionally seek medical help. Liquid ejected from the bat- tery may cause irritation or burns. u Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. u Do not expose a battery pack or tool to fire or excess- ive temperature. Exposure to fire or temperature above 130°C may cause explosion. u Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire. Service u Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. u Never service damaged battery packs. Service of bat- tery packs should only be performed by the manufacturer or authorized service providers. Hedge trimmer safety warnings u Keep all parts of the body away from the blade. Do not remove cut material or hold material to be cut when blades are moving. Blades continue to move after the switch is turned off. A moment of inattention while oper- ating the hedge trimmer may result in serious personal in- jury. u Carry the hedge trimmer by the handle with the blade stopped and taking care not to operate any power Bosch Power Tools F 016 L81 893 | (09.12.2019)12 | English switch. Proper carrying of the hedge trimmer will de- crease the risk of inadvertent starting and resultant per- sonal injury from the blades. u When transporting or storing the hedge trimmer, al- ways fit the blade cover. Proper handling of the hedge trimmer will decrease the risk of personal injury from the blades. u When clearing jammed material or servicing the unit, make sure all power switches are off and the power cord is disconnected. Unexpected actuation of the hedge trimmer while clearing jammed material or servi- cing may result in serious personal injury. u Hold the hedge trimmer by insulated gripping sur- faces only, because the blade may contact hidden wir- ing. Blades contacting a "live" wire may make exposed metal parts of the hedge trimmer "live" and could give the operator an electric shock. u Keep all power cords and cables away from cutting area. Power cords or cables may be hidden in hedges or bushes and can be accidentally cut by the blade. u Do not use the hedge trimmer in bad weather condi- tions, especially when there is a risk of lightning. This decreases the risk of being struck by lightning. Shrub/Grass Shears safety warnings u This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to en- sure that they do not play with the product. u Never allow children or people unfa- miliar with these instructions to use the product. Local regulations may restrict the age of the operator. When not in use store the product out of reach of children. u The user is responsible for accidents or hazards occurring to other people or their property. u Never operate the product while people, especially children or pets, are nearby. u Avoid trimming in bad weather con- ditions especially when there is a risk of lightning. u Use the product only in daylight or good artificial light. u Check that covers and guards are un- damaged and correctly fitted. Carry out necessary maintenance or re- pairs before using. u Only switch on the motor when your hands and feet are away from the blade. u Take care against injury to feet and hands from the cutting means. u Do not touch or insert conductive objects (such as screwdrivers or sim- ilar) into the micro USB port. u The product contains a battery that is non-replaceable. Safety Warnings for Battery Chargers u Never allow children, persons with physical, sensory or mental limita- tions or a lack of experience and/or knowledge and/or people unfamiliar with these instructions to use the battery charger. Local regulations may restrict the age of the operator. u Supervise children at all times. This will ensure that children do not play with the battery charger. u Keep the battery charger away from rain or moisture. Penetration of water in the battery charger increases the risk of an electric shock. u Keep the charger clean. Contamination can lead to danger of an electric shock. F 016 L81 893 | (09.12.2019) Bosch Power ToolsEnglish | 13 u Before each use check the battery charger and USB cable. If damage is detected, do not use the battery charger. Never open the battery charger yourself. All repairs must be performed by a Bosch Service Centre. Damaged battery chargers and USB cables increase the risk of an electric shock. u Do not operate the battery charger on flammable sur- faces (e.g., paper, textiles, etc.) or surroundings. The heating of the battery charger during the charging pro- cess can pose a fire hazard. u Damage to the machine may cause vapours to be emit- ted. Ventilate the area and seek medical attention in case of discomfort. The vapours can irritate the respirat- ory system. Symbols The following symbols are important for reading and under- standing the original instructions. Please take note of the symbols and their meaning. The correct interpretation of the symbols will help you to use the product in a better and safer manner. Symbol Meaning Wear eye protection and stout shoes at all times while operating the product. Only use the battery charger indoors, in dry conditions. Movement direction Reaction direction Wear protective gloves Weight Switching on Switching off Symbol Meaning Permitted action Prohibited action CLICK! Audible noise Accessories/Spare parts Product description and specifications Read all safety warnings and all instruc- tions. Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury. Please observe the illustrations at the ending of this operat- ing manual. Intended use The garden product is intended for light trimming of shrubs and lawn edges. Product Features (see figureA) (1) Battery Charge Indicator (2) Cover, micro USB port (3) On/Off switch (4) Lock-off button for On/Off switch (5) Pivot cover (6) Grass shear blade (7) Shrub shear blade (8) Handle (insulated gripping surface) (9) USB cable

(10) Battery charger

(country-specific) (11) Micro USB socket (12) Release button for cover

Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Technical Data EasyShear Grass shear Shrub shear Article number 3 600 H33 3.. 3 600 H33 3.. Rated voltage V 3.6 3.6 Blade length mm − 120 Blade width mm 80 − Weight according to EPTA‑Procedure 01:2014 kg 0.46 0.53 Recommended ambient temperature during charging °C +10... +35 +10... +35 Bosch Power Tools F 016 L81 893 | (09.12.2019)14 | English EasyShear Grass shear Shrub shear Permitted ambient temperature during opera- tion

and storage °C -10... +50 -10... +50 Battery Li-Ion Li-Ion Rated voltage V 3.6 3.6 Capacity Ah 1.5 1.5 Number of battery cells 1 1 A) Limited performance at temperatures <0°C Charger Article number EU 2 609 120 713 UK 2 609 120 718 Charging current A 1.0 Charging period (battery discharged) h 3.5 Weight according to EPTA‑Procedure 01:2014 kg 0.03

country specific The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models. Noise/Vibration Information Grass shear Measured sound values determined according to EN50636-2-94. Typically the A-weighted sound pressure level of the product is less than 70dB(A). Vibration total values a

(triax vector sum) and uncertainty K determined according to EN50636-2-94:

Shrub shear Noise emission values determined according to EN 62841-4-2. Typically the A-weighted noise levels of the product are: Sound pressure level XXdB(A); sound power level XXdB(A). Uncertainty K== XXdB. Vibration total values a

(triax vector sum) and uncertainty K determined according to EN 62841-4-2:

The vibration level and noise emission value given in these instructions have been measured in accordance with a standardised measuring procedure and may be used to com- pare power tools. They may also be used for a preliminary estimation of vibration and noise emissions. The stated vibration level and noise emission value repres- ent the main applications of the power tool. However, if the power tool is used for other applications, with different ap- plication tools or is poorly maintained, the vibration level and noise emission value may differ. This may significantly increase the vibration and noise emissions over the total working period. To estimate vibration and noise emissions accurately, the times when the tool is switched off or when it is running but not actually being used should also be taken into account. This may significantly reduce vibration and noise emissions over the total working period. Implement additional safety measures to protect the oper- ator from the effects of vibration, such as servicing the power tool and application tools, keeping their hands warm, and organising workflows correctly. Starting Operation u Use only the chargers listed in the technical data. Only these battery chargers are matched to the lithium-ion bat- tery of your product. Battery Charging (see figure B) Note: The battery is supplied partially charged. To ensure full battery capacity, completely charge the battery in the battery charger before using for the first time. The lithium-ion battery can be charged at any time without reducing its service life. Interrupting the charging procedure does not damage the battery. The “Electronic Cell Protection (ECP)” protects the lithium- ion battery against deep discharging. When the battery is discharged, the machine is switched off by means of a pro- tective circuit: The garden product no longer operates. Note: The micro-USB port (11) for connection of the micro- USB cable (9) is in the handle. When the charger level indicator (1) lights up red, the bat- tery must be charged. Switch the machine off and charge the battery. Connect the machine to the charger (10) using the micro- USB cable (9). Plug the charger (10) into the socket. The charging process begins. F 016 L81 893 | (09.12.2019) Bosch Power ToolsEnglish | 15 During the charging procedure, the handle of the machine warms up. This is normal. The charger level indicator (1) continuously lights up red during the charging procedure. When the battery is com- pletely charged, the charger level indicator (1) goes out. Disconnect the battery charger from the mains supply when charging process ends. Observe the notes for disposal. Mounting/Removing the Blade (see figures C) Press the release button (12) and slide the cover (5) toward the rear. Remove the cover (5) from the housing. Tilt the blade (6)/(7) upward and then remove the blade (6)/(7). Align the recesses on the blade (6)/(7) against the holding pins and then tilt the blade (6)/(7) downward. Mount the cover (5) again and then slide it toward the front until it engages. Operation u Make sure that the cover of the USB port (2) is shut dur- ing operation. This prevents the penetration of dust. u Do not use a damaged blade (e.g. cracks, etc.). Replace a damaged blade immediately. Switching On and Off (see figure D) Press and hold the lock-off button (4) and actuate the On/ Off switch (3). Release the lock-off button (4). When actuating the On/Off switch (3), the LED continuously lights up green. Battery Charge Indicator LED Capacity LED continuously lights up green 33−100% LED continuously lights up red while On/Off switch is halfway pressed. 0−33% Cutting Shrubs (only Shrub Shear) u Make sure that the product is switched off when removing cut-off material or during maintenance. Unintentional switching on may cause serious injury. Before cutting check the hedge/shrub for foreign objects e.g. wire fences. Cut stems up to 8 mm in thickness. When cutting, move the product steadily along the line of cut, so that stems are fed directly into the cutter blades. The double edge of the cut- ting blade enables cutting to either direction, or with a side to side motion. After use, mount the blade guard. Recommended times Cut hedges with deciduous leaves in June and October. Cut evergreen hedges in April and August. Cut conifer and other fast growing shrubs approx. every six weeks from May onwards. Cutting Edges (only Grass Shear) Guide the product along the edge of the lawn. Prevent the blade from coming into contact with paved paths, stones or garden walls because this significantly reduces the lifetime of the blade. After use, mount the blade guard. Troubleshooting Problem Possible Cause Corrective Measure Cutting time per bat- tery charge too low Battery close to end of service life. Contact Service Agent. Charger level indicator lights up red and the product cannot be switched on. Battery temperature too high Ambient temperature too high Do not expose the product to direct sunlight. Wait 10–15 minutes to let battery cool down. Maintenance and Service Maintenance, Cleaning and Storage u To ensure safe and efficient operation, always keep the power tool and the ventilation slots clean. u For safe and proper working, always keep the product clean. Do not place other objects on the garden product. To ensure safe and efficient operation, always keep the product and the ventilation slots clean. Never spray the product with water. Never immerse the product in water. Store the product in a secure, dry place, out of the reach of children. Do not place other objects on the product. Keep all nuts, bolts and screws tight to ensure safe working with the product. Inspect the product and replace worn or damaged parts for safety. Ensure replacement parts fitted are Bosch-approved. Bosch Power Tools F 016 L81 893 | (09.12.2019)16 | English After-sales Service and Application Service www.bosch-garden.com In all correspondence and spare parts orders, please always include the 10‑digit article number given on the nameplate of the product. Great Britain Robert Bosch Ltd. (B.S.C.) P.O. Box 98 Broadwater Park North Orbital Road Denham Uxbridge UB 9 5HJ At www.bosch-pt.co.uk you can order spare parts or arrange the collection of a product in need of servicing or repair. Tel. Service: (0344) 7360109 E-Mail: boschservicecentre@bosch.com Ireland Origo Ltd. Unit 23 Magna Drive Magna Business Park City West Dublin 24 Tel. Service: (01) 4666700 Fax: (01) 4666888 Australia, New Zealand and Pacific Islands Robert Bosch Australia Pty. Ltd. Power Tools Locked Bag 66 Clayton South VIC 3169 Customer Contact Center Inside Australia: Phone: (01300) 307044 Fax: (01300) 307045 Inside New Zealand: Phone: (0800) 543353 Fax: (0800) 428570 Outside AU and NZ: Phone: +61 3 95415555 www.bosch-pt.com.au www.bosch-pt.co.nz Republic of South Africa Customer service Hotline: (011) 6519600 Gauteng – BSC Service Centre 35 Roper Street, New Centre Johannesburg Tel.: (011) 4939375 Fax: (011) 4930126 E-Mail: bsctools@icon.co.za KZN – BSC Service Centre Unit E, Almar Centre 143 Crompton Street Pinetown Tel.: (031) 7012120 Fax: (031) 7012446 E-Mail: bsc.dur@za.bosch.com Western Cape – BSC Service Centre Democracy Way, Prosperity Park Milnerton Tel.: (021) 5512577 Fax: (021) 5513223 E-Mail: bsc@zsd.co.za Bosch Headquarters Midrand, Gauteng Tel.: (011) 6519600 Fax: (011) 6519880 E-Mail: rbsa-hq.pts@za.bosch.com Armenia, Azerbaijan, Georgia Robert Bosch Ltd. David Agmashenebeli ave. 61 0102 Tbilisi, Georgia Tel. +995322510073 www.bosch.com Kyrgyzstan, Mongolia, Tajikistan, Turkmenistan, Uzbekistan TOO “Robert Bosch” Power Tools, After Sales Service Muratbaev Ave., 180 050012, Almaty, Kazakhstan Service Email: service.pt.ka@bosch.com Official Website: www.bosch.com, www.bosch-pt.com Transport The contained lithium-ion batteries are subject to the Dan- gerous Goods Legislation requirements. The batteries are suitable for road-transport by the user without further re- strictions. When shipping by third parties (e.g.: by air transport or for- warding agency), special requirements on packaging and la- belling must be observed. For preparation of the item being shipped, consulting an expert for hazardous material is re- quired. Disposal The product, batteries, accessories and pack- aging should be sorted for environmental- friendly recycling. Do not dispose of the product and batteries/re- chargeable batteries into household waste! Only for EU countries: According to the European Guideline 2012/19/EU, products that are no longer usable, and according to the European Guideline 2006/66/EC, defective or used battery packs/ batteries, must be collected separately and disposed of in an environmentally correct manner. Battery packs/batteries: Li-ion: Please observe the notes in the section on transport (see "Transport", page16). F 016 L81 893 | (09.12.2019) Bosch Power ToolsFrançais | 17 u Integrated batteries may only be removed for disposal by a qualified repair person. Opening the housing shell can damage or destroy the product. Before you can remove the battery from the product, you will need to run the product until the battery is completely dis- charged. Unscrew the screws on the housing and remove the housing shell in order to remove the battery. To prevent a short circuit, disconnect the connectors on the battery one at a time and then isolate the poles. Even when fully dis- charged, the battery still contains a residual capacity which can be released in case of a short circuit. Français Consignes de sécurité Explication des symboles Lire soigneusement ces instructions d’utilisation. Prendre les précautions nécessaires pour que les personnes se trouvant à proximité ne risquent pas d’être bles- sées par des projections provenant de l’outil.

EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regu- lations listed below and are in conformity with the following stan- dards. Grass Shear Shrub Shear Article number
