USER MANUAL DR200BT HAMA

Telescopic aerial B: Radio control panel

[BACK] button C: Rear

• This quick-reference guide contains the most important basic information, such as safety instructions and the steps necessary to operate the product.

• To help protect the environmental and conserve valuable rawmaterials, Hama does not issue aprinted manual and instead makes this available exclusively as aPDF download.

• The full text of the manual is available at the following internet address: www.hama.com -> 00173191 -> Downloads

• Save the manual on your computer for reference and print them out if possible.3

1. Explanation of warning symbols and notes

Risk of electric shock This symbol indicates arisk of electric shock from touching product parts carrying hazardous voltage. Warning This symbol is used to indicate safety instructions or to draw your attention to specichazards and risks. Note This symbol is used to indicate additional information or important notes.

• USB-C charging cable

• The product is intended for private, non-commercial use only.

• Do not use the product in areas in which electronic products arenot permitted.

• Protect the product from dirt, moistureand overheating and use it in dry rooms only.

• As with all electrical products, this device should be kept out of the reach of children.

• Do not drop the product and do not expose it to any major shocks.

• Do not operate the product outside the power limits specied in the technical data.

• Keep the packaging material out of the reach of children due to the risk of suffocation.

• Dispose of packaging material immediately in accordance with the locally applicable regulations.

• Do not modify the device in any way.Doing so voids the warranty.

• Use the product only for the intended purpose.

• Do not use the product in the immediate vicinity of heaters, other heat sources or in direct sunlight.

• Do not use the product in adamp environment and avoid splashing water.

• Only use the article under moderate climatic conditions.

• The battery is integrated and cannot be removed.

• Do not incinerate the battery or the product.

• Do not tamper with or damage/heat/disassemble the batteries/rechargeable batteries.

• Route all cables so that thereisnorisk of tripping.

• Do not bend or crush the cable. Risk of electric shock

• Do not open the device or continue to operate it if it becomes damaged.

• Do not use the product if the AC adapter,the adapter cable or the mains cable are damaged.

• Do not attempt to service or repair the product yourself.Leave any and all service work to qualied experts.

4. Charging the battery

Warning –rechargeable battery

• Only use suitable charging devices or USB connections to charge the product.

• Do not use defective chargers or USB ports and do not attempt to repair them.

• Do not overcharge the product or allow the battery to completely discharge.

• Avoid storing, charging and using in extreme temperatures and at extremely low atmospheric pressures (such as at high altitudes).

• Charge regularly (at least quarterly) during periods of prolonged storage.

• The product contains arechargeable battery.

• Fully charge the product once beforeusing it for the rst time.

• Connect the supplied USB-C charging cable to the USB-C connection (15) on the product.

• Connect the free plug on the USB-C charging cable to a suitable USB charger.Todothis, consult the operating instructions for the USB charger you areusing.

• The actual battery life willvary depending on how you use the device, the settings and the environmental conditions (batteries have alimited life). Note –charging process

• Acomplete charging cycle takes about 3hours.

• The product's battery can be charged both when it is switched on and off.4

5. Start-up and operation

Note -optimising reception

• At the initial start-up, the system interface will ask about the preferred language. Select your preferred language.

• Astation search in DABoperating mode is automatically started when you switch the radio on for the rst time. Please note:

• Always pull the antenna out completely.

• We recommend you adjust the antenna vertically to ensureoptimal reception.

5.1 General notes on use

5.1.1 Switch On /Off /Standby

• Press [ ](7) to switch the radio on.

• Press [ ](7) for approx. 1second to switch the radio off. (Standby)

• Press and hold [ ](7) for approx. 3seconds to switch the radio off completely. Note

• If the radio is switched off completely when in battery power mode, timers and alarms that have been set will no longer be valid. Conrm the prompt that appears on the display with (OK).

5.1.2 Navigation and control

• See the table attached for this.

• Restarting or resetting to the factory default settings can remedy some problems and malfunctions. To restart the radio, proceed as follows:

• Use aneedle or similar object. Press and hold the Reset button (13) for approx. 3seconds.

• To reset the radio to the factory settings, navigate in the menu to the System settings -> System and select the "Factory settings" option. Note

• Note that when you reset to the factory settings, all default settings such as language and favourites will be permanently deleted. Note

• Czech, English, Danish, Dutch, German, Finnish, French, Italian, Norwegian, Polish, Portuguese, Slovak, Spanish, Swedish, Turkish

6. Care and maintenance

Note Disconnect the device from the mains beforecleaning and during prolonged periods of non-use.

• Only clean this product with aslightly damp, lint-free cloth and do not use aggressive cleaning agents.

• If you do not plan to use the product for aprolonged period, turn off the device and disconnect it from the power supply.Storeitinaclean, dry place away from direct sunlight.

7. Warranty Disclaimer

Hama GmbH &CoKGassumes no liability and provides no warranty for damage resulting from improper installation/ mounting, improper use of the product or from failureto observe the operating instructions and/or safety notes.

8. Service and Support

Please contact Hama Product Consulting if you have any questions about this product. Hotline: +49 9091 502-115 (German/English) Further support information can be found here: www.hama.com The full text of the manual is available at the following internet address: www.hama.com -> 00173191 -> Downloads5

9. Recycling information

Note on environmental protection: After the implementation of the European Directives 2012/19/EU and 2006/66/EU in the national legal system, the following applies: electrical and electronic devices as well as batteries must not be disposed of with household waste. Consumers areobliged by law to return electrical and electronic devices as well as batteries to the designated public collection points or to the point of sale at the end of their service lives. Detailed information on this topic is dened in the national laws of the respective country.This presence of the above symbol on the product, operating instructions or package indicates that the product is subject to these regulations. By recycling, reusing the materials or other forms of utilising old devices/batteries, you aremaking an important contribution to protecting our environment.

10. Declaration of Conformity

Hama GmbH &CoKGhereby declares that the radio equipment type [00173191] is in compliance with Directive 2014/53/EU.The full text of the EU declaration of conformity is available at the following internet address: www.hama.com -> 00173191 -> Downloads Frequency band(s) Maximum radio-frequency power transmitted Bluetooth: 2,402 –2,480 GHz

Menu Note: If the description of any of the key functions listed above does not distinguish between along and short key press, the key press is short. Along key press requires the key to be pressed for approx. 3seconds.7 Key function Short key press: Call up favourite memory slot 1for current playback mode Long key press: Save the current station to favourite memory slot 1 Short key press: Call up favourite memory slot 2for current playback mode Long key press: Save the current station to favourite memory slot 2 Call up the favourites memory list (1-30) to call up stations Long key press: Call up the favourites memory list (1-30) to save the station currently active as afavourite Short key press: Open the menu of the currently active mode Long key press: Open the device's system settings Back to the playback screen active in the background Short key press: Wake the radio from standby mode or place it in standby mode Long key press: Switch the radio on or off Toggle between the operating modes available Short key press: Volume reduction in playback mode Long key press: Previous track Menu: Navigation to the previous menu item Change the display of the playback screen with abrief key press
