USER MANUAL EWSTrio HAMA

1. Transmissionindicatorlight
2. TXbutton manualconnectiontothebase station
3. Recessforwallmounting
   20.Slideswitch=selectschannel1,2or3
   21.Batterycompartment

ThankyouforchoosingaHamaproduct.

Takeyourtimeandreadthefollowinginstructionsand informationcompletely.Pleasekeeptheseinstructionsinasafeplaceforfuturereference.Ifyouellthedevicepleasepasstheseseoperatinginstructionsontothewowner.

1.ExplanationofWarningSymbolsandNotes

Warning

Thissymbolisusedtoindicatesafetyinstructionsorto drawyourattentionospecifichazardsandrisks.

Note

Thissymbolisusedtoindicateadditionalinformationor importantnotes.

2.PackageContents

-Triweatherstation(basestationforindoors)
- 3measuringstationsforoutdoors
-3AAAbatteries
-6AAbatteries
Theseoperatingsinstructions

3.SafetyNotes

The productis intended for private, non-commercial use only.
- Donotoperatetheproductoutsidethepowerlimitsgiven inthespecifications.
- Donotusetheproductinmoistenvironmentsandavoid splashes.
- Donotusetheproductintheimmediatevicinityofheaters orotherheatsourcesorindirectsunlight.
- Donotusetheproductinareaswheretheuseofelectronic devicesisnot permitted.
- Donotplaceheproductnearinterferencefields, metal frames, computers, TVs, etc. Electronic devices and window framescan negativelyaffect the product's functionality.
- Donotdroptheproductanddonotexposeittoanymajor shocks.
- Donotopenthedevicorcontinuetooperateititif becomesdamaged.
- Donotattempttoserviceorrepairtheproductyourself.

Leaveanyandallsserviceworktoqualifiedexperts.

• Keepthepackagingmaterialoutofthereachofchildren duetotheriskofsuffocation.
• Disposefpackagingmaterialimmediatelyaccordingto locallyapplicableregulations.
• Donotmodifytheproductinyway.Doingsovoidsthe warranty.
• Use the product for its intended purpose only.
• Protectttheproductfromdirt, moisture andoverheating, andonlyuseitinadryenvironment
• Keepthisproduct,asallelectricalproducts,outofthereachofchildren!
• Usetheitemonlyinmoderateclimaticconditions.

Warning-Batteries

• When inserting batteries, notethe correct polarity (+and-markings) and insert the batteries accordingly. Failure to do so could result in the batteries leaking or exploding.
• Onlyusebatteries(ORRECHARGEablebatteries)that match thespecifiedtype.
• Beforeyouinsertthebatteries, clean the battery contacts and the polar contacts.
• Donotallowchildrentochangebatterieswithout supervision.
• Donotmixoldandnewbatteriesorbatteriesofadifferenttypeormake.
• Removethebatteriesfromproductsthatarenotbeing usedforanextendedperiod(unlessthesarebeingkept readyforanemergency).
• Donotshort-circuitbatteries.
• Donotchargebatteries.
• Donotthrowbatteriesinafire.
• Keepbatteriesoutofthereachofchildren.
• Neveropen, damageorswallowbatteriesorallow themtoentertheenvironment. Theycancontaintoxic, environmentallyharmfulheavymetals.
• Immediatelyremoveanddisposefdeadbatteriesfrom theproduct.
• Avoidstoring, charging or using the device in extreme temperatures and extremely low atmospheric pressure (foreexample, athighaltitudes).

4. Gettingstarted

Note

Beforeuse, makesurethatyouinsertthebatteriesinthe measuringstationfirstandtheninthebasestation.

4.1 Measuringstation

• Open the battery compartment (21) and insert two AAbatterieswiththecorrectpolarityintothebattery compartment.
• Use the slide switch (20) to select the channel that the respective measuringstationistousefortransmission. Eachofthreemeasuringstationsmustuseadifferent channel!
• Closethebatterycompartment.

4.2Basestation

• Open the battery compartment (15) and insert three AAAbatteries with the correct polarity into the battery compartment.
• Thenclosethebatterycompartmentcover.

4.3Replacingthebatteries

Note-Replacingthebatteries

• Notethathestationsshavetoberesynchronisedeach timeafteryouchangethebatteriesinthemeasuringor basestation.
• Todothis,removethebatteriesfromtheotherstation andthenreinsertthem,orchangethemasrequired.

Measuringstation

• If the symbolis displayed onthebasisstation in the measurement values areaofoneofthreemeasuring stations(5/6/7), replacethetwoAAbatteries of the affected measuring station with twonewones.
• Openthebatterycompartment(21),removeandproperly disposeofthedepletedbatteries,andinserttwonewAA batterieswiththecorrectpolarity.Thenclosethebattery compartmentcover.

Basestation

Ifthe symbolisdisplayedonthebasestationinthe indoorvaluesarea(2),replacethreeAAAbatteriesin thebasestationwiththreenewones.
- Openthebatterycompartment(15),removeandproperly disposeofthedeadbatteriesandinsertthreenewAAA batterieswiththecorrectpolarity. Thenclosethebattery compantmentcover.

5.Installation

Note-Installation

• Werecommendinitiallyplacingthebasestation and measuringstation(s)intheintendedlocationswithout installingthemandmakingallthesettingsdescribed in 6. Operation.
• Onlyinstallthestationsoncetheappropriatesettings havebeenmadeandastablewirelessconnectionis established.

Note

• Thewirelesstransmissionrangebetweenthemeasuring andbasestationsisupto50minopenspaces.
• Beforeinstallation, ensure that wireless transmission will not be disrupted by interference or obstacles like buildings, trees, vehicles, high-voltages, etc.
• Beforethefinalinstallation,ensurethatthereis sufficientreceptionbetweentheintendedinstallation locations.
• Wheninstallingthemeasuringstation,ensurethatitis protectedfromdirectsunlightandrain.
• The international standard height formesuring air temperature is 1.25 m (4 ft) above ground.

Warning

• Buyspecialorsuitableinstallationmaterialfrom specialiseddealerforwall-mounting.
• Ensurethatnofaultyordamagedpartsareinstalled.
• Neverapplyforceduringinstallation. This could damage the product.

• Beforeinstallation, ensure that the chosen wallis suitablefortheweighttobemounted, and makesure that there are no electrical wires, water, gas or other lines at the installationsite onthewall.
• Donotmounttheproductabovelocationswhere personsmightlinger.

5.1 Basestation

• Use the basetopositionthebasestationonalevel surface.

5.2 Measuringstation

• You canalsoposition themeasuringstationonalevel outdoorsurface.
• Werecommendinstallingthemeasuringstationsecurely onanoutdoorwallusingtheopening(19).

6. Operation

6.1 Connectionto themeasuringstation

After you have inserted the batteries, the basestation automatically searches for a connection to the three measuring stations and performs initial setup.

Note

• Rememberthateachofthreemeasuringstations mustuseadifferentchannel.
• Initialsetupapproximatesapproximately3minutes.
• During the connection attempt, themeasuring station radiosymbol will flash.
• Donotpressanybuttonsduringsetup. Otherwise, valuesmaynotbetransmittedcorrectlyandthereisa riskofvalueerrorsandinaccuracy.
  The processiscompletedwhentheindoor(2/4)and outdoor(5/6/7)measurementdataisdisplayed.

• Ifasignalfromthemeasuringstationiststillnotreceived, selectoneofthethreechannelsbypressingtheCHbutton (9). ThenholdtheCHbutton(9)forapproximately3 secondstostartthemanualsearchforthesignal.
• PresstheTXbutton(18)onthedesiredmeasuringstation toinitiatabetransmissionofasignalthatcanbereceived bythebasestation.

6.2Basicandmanualsettings

AutomaticsettingusingtheDCFsignal(radio-controlledclock)

• Whenthebasestationhasbeenswitchedonforthefirst timeandsuccessfultransmissionhasbeenestablished betweenthebasestationandthemeasuringstation, the clockwillautomaticallysearchfortheDCFsignal. During thesearch,theradiusymbol forDCFreceptionflashes.

Display(8)SearchingfortheDCFsignal

Displayflashing

Displayedcontinuously

Active

Successful—signalisbeingreceived

NotdisplayedDeactivated

• If thestation still does not receive a signal, press and hold the DOWN button (13) until the radiosymbol begin to flash, to start the manual search for the DCF signal.

Note-Timesettings

• Thesearchprocessstakesabout3minutes.lfthesearch fails, itendsandisrepeatedatthenextclockhour. The radiosymbol( )goesout.
  -Itisnotpossibletomanusallysettettimeanddate duringthesearchfortheDCFsignal.
  The clockautomaticallycontinuestosearchfortheDCF signalonadailybasis(between 1 amand5am)to correctanydeviations.

• If the signal is received successfully, the manually set time and date are overwritten.

• PressandholdtheDOWNbutton(13)againfor approximately3secondstostopthemanualsearch.

Note-Summertime

The clock automatically switchestosummertime.

Manualsettings

Note

• Hold the UP button (12) or the DOWN button (13) to selectthevaluesfaster.

• PresstheSETbutton(11)tomakethefollowingsettings inorder:

• Timezone

Year

Calendarmonth

-Date

• Hour

·Minute

12/24-hourformat

• Toselectindividualvalues, presstheUPbutton(12) or the DOWNbutton(13) and confirmeachselectionbypressing the SETbutton(11).
• PresstheSETbutton(11)toadoptthesetvaluedisplayed andtoskip.
• If you don't make an entry for 20 seconds, you automatically exit the setting mode.

Note-Timezone

The DCF signal can berveived over long distances, but always transmits the current Central European Time in Germany. Please notethat for countries with different timezone, you must set the time difference manually.
- IfyouareinMoscow,forexample,thetimeis3hours laterthaninGermany.Thismeansthayoushould set+3forthETIMEzone.Theclockthensetsthetime automaticallyto3hoursaheadafterreceivingtheDCF signaloraccordinqtothemeanuallysettime.

Celsius/Fahrenheit

• PresstheDOWNbutton(13)toswitchbetween°Cand°F forthetemperaturedisplay.

6.3Alarm

AlarmmodeALisdisplayedbetweenthehoursandminutes ofthetimedisplay.

• PresstheALARMbutton(8)oncotocallupalarmmode.
• PressandholdtheALARMbutton(8)forapproximately 3secondstosetthealarmtime.Thehoursdisplaybegins toflash.
• Press the UP button (12) or the DOWN button (13) toselectthehourforthealarmtimeandconfirmyour selectionbypressingtheALARMbutton(8).Theminutes displaybeginstoflash.
• Repeattheprocesstosettheminutesforthealarmtime.
• If youdonotmakeanentryforapproximately5seconds, youautomaticallyexitthesettingmode.
  PresstheALARMbutton(8)twicetoactivateor deactivatethealarm.Theactivealarmisindicatedbythe alarmsymbol( ).Whenanactivealarmisd deactivated, thealarmsymbolgoesout.
• Ifthealarmistrigered, thealarmsymbol( )willbegin toflashhandanalarmwillsound.
• Pressanybutton(excepttheSNZ/LIGHTbutton(10))to stophealarm. Otherwise, it will stop automatically after 2 minutes.

Note-Snoozefunction

• While the alarmsignalissounding, presstheSNZ/ LIGHTbutton(10)toactivatethesnoozefunction. The alarmsymbol() will start to flash on the display. The alarmsignalwillstopfor5 minutes, after which it will sound again.
• Pressanybutton(excepttheSNZ/LIGHTbutton)tostop thesnoozefunctionandthealarm.

6.4Maximumandminimumtemperature and humidityvalues

Thebasestationautomaticallystoresthemaximumand minimumoutdoor/indoortemperatureandhumidityvalues.

• RepeatedlypresstheUPbutton(12)toswitchthedisplaybetweenthecurrenttemperatureandhumidity, maximumtemperatureandhumidity(MAX)andminimumtemperatureandhumidity(MIN).

6.5Backlight

PresstheSNZ/LIGHTbutton(10)tolightupthedisplay forapproximately5seconds.

7.CareandMaintenance

• Onlycleanthisproductwithaslightlydamp, lint-freecloth anddonotuseaggressivecleaningagents.
• Makesurethatwaterdoesnotgetintotheproduct.

8.WarrantyDisclaimer

HamaGmbH&CoKGassumesnoliabilityandprovidesn warrantyfordamageresultingfromimproperinstallation/ mounting,improperuseoftheproductormfromfailureo observetheoperatinginstructionsand/orsafetynotes.

1. Technical Data

1	BasestationMeasuringstation
Powersupply	4.5V3xAAAbatteries	3.0V2xAbatteriesWerecommendusingAAlithiumbatteriesfortheoutdoorsensorswhenoutdoortemperaturesarebelow0°C/32°F.
Measuringrange:TemperatureHumidity	0°C-+50°C/32°F-+122°F10-99%	-40°C-+70°C/-40°F-+158°F20%-95%
Measurement increments:TemperatureHumidity	0.1°C/0.2°F1%	0.1°C/0.2°F1%
Radio-controlledDCFclockYesNo
ThermometerYesYes
HygrometerYesYes
AlarmfunctionYesNo
Max.numberofmeasuringstations3
Range≤30m

10.DeclarationofConformity

Hereby, HamaGmbH&CoKGdeclaresthatthe radioequipmenttype[00186311]isincompliance withDirective2014/53/EU. The fulltextofthe EU declaration of conformity is available at the following internet address: www.hama.com->00186311->Downloads.

Frequencyband(s)433MHz
Maximumradio-frequencypower transmitted	9,419mW
