Product type Cordless multi-tool
Brand Metabo
Model MA 3618 LTX BL Q
Power supply Li-Ion battery (CAS system)
Rated voltage 18 V
Recommended battery capacity 4.0 Ah to 8.0 Ah (LiHD or Li-Power)
Rotational speed Selectable 2 speeds
Start-up Activation button + lock + switch
Included accessories Shoulder strap (depending on model)
Compatible accessories Hedge trimmer MA-HS 50, Pruner MA-MS 25, Brush cutter MA-FS 40, Shaft extension (ref. 628498000)
Safety Switch lock, automatic stop, mandatory battery removal before maintenance
Maintenance Clean with a dry cloth; do not use water; lubrication not required
Storage In a dry place, out of reach of children
Operating temperature -20 °C to 50 °C (limited performance below 0 °C)
Charging temperature 0 °C to 40 °C

Frequently Asked Questions - MA 3618 LTX BL Q METABO

How to assemble the accessory bar with the multi-tool?
Loosen the wing screw (17), position the bar ends facing each other, interlock them until the release button (16) clicks, then tighten the wing screw. Regularly check that the screw is tight during use.
What types of batteries can I use with the MA 3618 LTX BL Q?
Use exclusively Metabo or Cordless Alliance System (CAS) batteries with a voltage of 18 V. Recommended capacities range from 4.0 Ah to 8.0 Ah (LiHD or Li-Power models).
How to start the tool?
First press the activation button (6) to select the speed. Then keep the switch lock (7) pressed and press the switch (8) to start. If the activation step is not followed within 5 seconds, repeat it.
What to do if the bar ends do not interlock during assembly?
If the parts are difficult to interlock, slightly rotate the accessory bar or briefly start the motor so that the coupling element changes position. Make sure the release button (16) clicks correctly.
Can I use the tool without an accessory?
No, the multi-tool must always be used with an accessory installed. Never use without an accessory, as this poses a risk of injury.
How to clean the tool after use?
Clean the tool with a dry cloth to remove dirt and deposits. Never use water as this could damage electrical components.
What to do if the tool vibrates unusually?
Stop the tool immediately, remove the battery and check for damage. Replace or repair damaged parts before using the tool again. Unusual vibrations may indicate a safety issue.
Is it necessary to lubricate the tool?
No, no lubrication is necessary for this tool. Regular maintenance consists of checking the tightness of screws and the general condition of the machine.
How to store the tool safely?
Remove the battery, clean the tool, and store it in a dry place out of reach of children. Use the suspension eyelet (11) to hang the tool if necessary.
Where can I find spare parts or have the tool repaired?
For repairs, contact an authorized Metabo representative. Spare parts lists are available at www.metabo.com. Use only original spare parts.
