USER MANUAL PNKP 105 B1 PARKSIDE

Translation of the original instructions

Introduction Congratulations on the purchase of your new appliance. You have selected a high-quality product. The operating instructions are part of this product. They contain important information about safety, usage and disposal. Before using the product, please familiarise yourself with all operating and safety instructions. Use the product only as described and for the range of applications specified. Please also pass these operating instructions on to any future owner. Intended use This appliance is specifically intended for a variety of creative hobby applications involving the gluing of heat-sensitive materials such as paper, flowers, cardboard, packaging, plastics, leather, ceramics, glass and fabric. The material to be glued must be clean, dry and free of grease. Any other usage of or modification to the appliance is deemed to be improper and carries a significant risk of accidents. The manufacturer accepts no responsibility for damage(s) attribut- able to misuse. The appliance is not intended for commercial use.PNKP 105 B1

 3 ■ Features 1 Feeder shaft 2 Power cable 3 Trigger 4 Stand 5 Nozzle 6 Thermal protection for nozzle 7 Glue sticks Package contents 1 hot glue gun PNKP 105 B1 1 stand (pre-mounted) 6 glue sticks 1 set of operating instructions Technical details Rated voltage 230V ∼, 50Hz (AC) Rated power consumption 5 W (20 W in operation) Operating temperature 105–140°C Heating-up time approx. 5 min. Protection class II / (double insulation) For glue sticks Ø 7 mm e.g. PARKSIDE PNKPZ 3 B2PNKP 105 B1 ■ 4 

General safety warnings for power tools in household use ATTENTION! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.

This appliance may be used by children aged 8years and above and by persons with limited physical, sensory or mental capa- bilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the appliance safely and are aware of the potential risks. Do not allow children to use the appliance as a plaything. Cleaning and user maintenance tasks may not be carried out by children unless they are supervised. ■ To avoid potential risks, damaged mains cables should be replaced by the manufac- turer, their customer service department or asimilarly qualified person.PNKP 105 B1

 5 ■ Additional safety instructions for glue guns ■ Children should be supervised to ensure that they do not play with the appliance. ■ ATTENTION! This appliance must be placed on its stand 4 when not in use. ■ Always protect the appliance from rain and moisture. Water entering a power tool will increase the risk of electric shock. ■ Do not misuse the power cord, e.g. to carry or hang up the appliance, or to pull the plug from the socket. Keep cord away from heat, oil, sharp edges or moving parts. If the power cord is damaged or severed during work, do not touch the cord but rather pull out the plug. Damaged or entan- gled cords increase the risk of electric shock. ■ Only for indoor use. ■ If you take a break of longer than 30 minutes, pull out the power plug. ■ Allow the appliance to cool completely after use and before storage. ■ Do not work on any material containing asbestos. ■ Avoid the risk of injury or fire as well as health risks: RISK OF BURNS! The adhesive and the nozzle reach a temperature of around 105°C. Do not touch the nozzle or the glue. Do not allow hot glue to come into contact with people or animals. In case of contact with skin, rinse the affected part in cold running water for a few minutes. Do not attempt to remove the adhesive from the skin. ■ Always route the power cable towards the rear, away from the appliance.PNKP 105 B1 ■ 6 

Original accessories/auxiliary equipment ♦ Only use the accessories and additional equipment that are specified in the operating instructions and compatible with the appliance. Operation Preparing the surfaces to be glued ■ Do not use flammable solvents to clean the surfaces to be glued. ■ The ambient temperature and the materials to be bonded may not be colder than 5°C and not warmer than 50°C. ■ The area to be glued must be clean, dry and free of grease. ♦ Smooth surfaces should be roughened before gluing. ♦ Quick-cooling materials such as steel should be warmed a little tofacilitate adhesion.

1. Fold out the stand 4. Put down the appliance.

2. Push a glue stick 7 into the feeder shaft 1.

3. Allow the appliance heat up for about 5 minutes.

The appliance is now ready for use. Preparing the surfaces to be glued ♦ Pull the trigger 3 to regulate the flow of glue in accordance with your requirements.

1. Apply the glue in spots. For flexible materials, such as textiles,

apply the glue in zigzag lines.

2. Press the two workpieces to be bonded together immediately

after applying the glue and hold for about 30 seconds. The glued bond is ready after about 5 minutes.

3. During breaks in work, put the glue gun down on the stand4.PNKP 105 B1

 7 ■ Switching the appliance off ♦ Unplug the appliance from the mains socket.

The nozzle 5 reaches a temperature of over 140°C. Maintenance and cleaning WARNING! Always remove the power plug from the power socket before cleaning the appliance! ■ The low-temperature glue gun is maintenance-free. ■ Keep the appliance clean and dry at all times. ■ Never permit liquids to enter inside the appliance. Use a cloth to clean the housing. Never use petrol, solvents or cleansers which can damage plastic. Disposal The product and its packaging are recyclable. They are subject to an extended manufacturer responsibility and will be collected separately. Do not dispose of power tools in your normal domestic waste! The adjacent symbol of a crossed-out dustbin means that this appliance is subject to Directive 2012/19/EU. This directive states that this appliance may not be disposed of in the normal household waste at the end of its useful life, but must be taken to specially set-up collection locations, recycling depots or disposal companies.PNKP 105 B1 ■ 8 

The disposal is free of charge for the user. Protect the environment and dispose of this appliance properly. Your local community or municipal authorities can pro- vide information on how to dispose of the worn-out product. The packaging is made from environmentally friendly material and can be disposed of at your local recycling plant. Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and sepa- rate the packaging material components for disposal if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1–7: plastics, 20–22: paper and cardboard, 80–98: composites.PNKP 105 B1

 9 ■ Kompernass Handels GmbH warranty Dear Customer, This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below. Warranty conditions The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase. If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred. If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period. Warranty period and statutory claims for defects The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.PNKP 105 B1 ■ 10 

Scope of the warranty This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery. The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches or parts made of glass. The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the oper- ating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided. This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres. The warranty period does not apply to ■ Normal reduction of the battery capacity over time ■ Commercial use of the product ■ Damage to or alteration of the product by the customer ■ Non-compliance with safety and maintenance instructions, operating errors ■ Damage caused by natural hazardsPNKP 105 B1

 11 ■ Warranty claim procedure To ensure quick processing of your case, please observe the following instructions: ■ Please have the till receipt and the item number (IAN) 397421_2204 available as proof of purchase. ■ You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product. ■ If functional or other defects occur, please contact the service department listed either by telephone or by e-mail. ■ You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred. You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com. This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 397421_2204.PNKP 105 B1 ■ 12 

 13 ■ Translation of the original Conformity Declaration We, KOMPERNASS HANDELS GMBH, documents officer: Mr. Semi Uguzlu, BURGSTR. 21, 44867 BOCHUM, Germany, hereby declare that this product complies with the following standards, normative documents and EC directives: EC Low Voltage Directive (2014/35/EU) EMC (Electromagnetic Compatibility) (2014/30/EU) RoHS Directive (2011/65/EU)*

The manufacturer bears the full responsibility for compliance with this conformity declaration. The object of the declaration described above complies with the requirements of the Directive 2011/65/EU of the Euro- pean Parliament and Council of 8 June 2011 on the limitations of use of certain dangerous substances in electrical and electronic appliances. Applied harmonised standards EN 60335-2-45:2002/A2:2012 EN 60335-1:2012/A15:2021 EN 62233:2008

Type designation of machine: Hot glue gun PNKP 105 B1 Year of manufacture: 08–2022 Serial number: IAN 397421_2204 Bochum, 21/07/2022 Semi Uguzlu - Quality Manager - The right to effect technical changes in the context of further development is reserved.PNKP 105 B1
