| Product Type | Cordless Glue Gun |
| Brand | Parkside |
| Model | PHPA 4 B3 |
| Rated Voltage | 4 V (DC) |
| Battery Type | Integrated Lithium-ion |
| Battery Capacity | 1500 mAh |
| Heating Time | Approximately 60 seconds |
| Operating Temperature | Approximately 170 °C |
| Glue Stick Diameter | 7 mm |
| Glue Stick Length | 140 mm |
| Runtime (fully charged battery) | Approximately 30 minutes |
| Charger - Input Voltage | 100 - 240 V, 50/60 Hz (AC) |
| Charger - Output Voltage | 5 V (DC) |
| Charger - Output Current | 1.7 A |
| Charging Time | Approximately 1 hour |
| Protection Class | II (double insulation) |
| Automatic Shut-off | After 10 minutes of inactivity |
| Items Included | Glue gun, charger with stand, base, USB cable, power adapter, 6 glue sticks, instruction manual |
| Intended Use | For bonding wood, cardboard, PVC, fabric, ceramic, etc. |
| Maintenance | Clean with a dry cloth; do not use solvents |
| Safety | Do not touch the hot nozzle; risk of burns |
Frequently Asked Questions - PHPA 4 B3 PARKSIDE
User questions about PHPA 4 B3 PARKSIDE
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Hot glue gun in PDF format for free! Find your manual PHPA 4 B3 - PARKSIDE and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PHPA 4 B3 by PARKSIDE.
USER MANUAL PHPA 4 B3 PARKSIDE
Translation of the original instructions
NL BE
ACCU-LIJMPISTOOL
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.
FR BE
GB/IE Translation of the original instructions Page 21
Temperatur ca. 170^
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
DEUTSCHLAND
www.kompernass.com
General safety warnings for electric heating tools . .25
Use and handling of the cordless electrical power tool 27
Safety guidelines for battery chargers 28
Before use 29
Charging the appliance battery 29
Battery level display 30
Preparing the surfaces to be glued 30
Use 31
Maintenance and cleaning 33
Disposal 33
Kompernass Handels GmbH warranty 35
Service 38
Impor ter 38
Translation of the original Conformity Declaration . .39
CORDLESS HOT GLUE GUN PHPA 4 B3
Introduction
Congratulations on the purchase of your new appliance. You have chosen a high-quality product. The operating instructions are part of this product. They contain important
information about safety, usage and disposal. Before using the product, please familiarise yourself with all operating and safety instructions. Use the product only as described and for the range of applications specified. Please also pass these operating instructions on to any future owner.
Intended use
This appliance is intended for gluing wood, cardboard, packaging, PVC, carpet, seals, plastics, leather, ceramics, glass and fabric with hot-melt adhesive. The material to be glued must be clean, dry and free of grease. You can also use the appliance for sealing, grouting, handicrafts and decorating. Any other usage of or modification to the appliance is deemed to be improper and carries a significant risk of accidents. The manufacturer accepts no responsibility for damage(s) attributable to misuse. The appliance is not intended for commercial use.
Notes on trademarks
USB® is a registered trademark of USB Implementers Forum, Inc. All other names and products may be trademarks or registered trademarks of their respective owner.
Features
1 Temperature indicator
ON/OFF button
3 Battery capacity/charge level indicator
Glue stick
5 Feeder shaft
Trigger
USB-C connection
USB-C plug of the charger cable
USB plug of the charger cable
10 Mains adapter
Charging contacts
12 Stand
Charger with appliance cradle
14 Nozzle
Thermal protection for nozzle
Package contents
1 cordless hot glue gun
1 charger with appliance cradle
1 stand
1 charging cable
1 mains adapter
6 glue sticks
1 set of operating instructions
Technical data
Cordless hot glue gun PHPA 4 B3
Nominal battery voltage 4 V (DC)
Cells
Battery (integrated)
Battery capacity 1500 mAh
Heat-up time approx. 60 sec.
Temperature
Glue stick diameter 7mm
一
1
Lithium Lithium ion
approx.
NOTE
We recommend to use commercially available glue sticks with 7mm
Glue stick length 140 mm
Working time with one battery charge approx. 30 min.
Charger PHPA 4 B3-1
INPUT
Nominal voltage 100-240 V ~,
50/60 Hz (AC)
Nominal current
300 mA
Safety transformer
Switched-mode power supply
OUTPUT
Nominal voltage 5 V (DC)
Nominal current
Charging time
Protection class
一
1,7A
approx. 1 hr
II/（double insulation)
General safety warnings for electric heating tools
WARNING!
- Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "electric heating tool" in the warnings refers to your mains-operated (corded) electric heating tool or battery-operated (cordless) electric heating tool.
Children should be supervised to ensure that they do not play with the appliance.
NOTE! This appliance must be placed on its stand 12 or the charger 13 when not in use.
Always protect the appliance from rain and moisture. Water entering a power tool will increase the risk of electric shock.
Only for indoor use.
During breaks in work, rest the appliance on the stand 12.
■Allow the appliance to cool completely after use and before storage.
- Do not work on any material containing asbestos.
Avoid the risk of injury or fire as well as health risks: Risk of burns! The nozzle reaches a temperature of over 170^ C . The glue reaches a temperature of over 170^ C . Do not touch the nozzle or the hot glue. Do not allow hot glue to come into contact with people or animals. In case of contact with skin, rinse the affected part in cold running water for a few minutes. Do not attempt to remove the adhesive from the skin.
not pull out the glue stick!
Use and handling of the cordless electrical power tool
a) Charge the appliance using only the charger recommended by the manufacturer. Chargers are often designed for a particular type of rechargeable battery unit. There is the danger of fire if other types of rechargeable battery units are used.
c) When not in use, store the appliance away from paper clips, coins, keys, nails, screws or other small metal objects that could bridge the contacts. Short-circuiting the contacts of a rechargeable battery unit may result in heat damage or fire.
c) Fluids may leak out of rechargeable battery units if they are misused. If this happens, avoid contact with the fluid. If contact occurs, flush the affected area with water. Seek additional medical help if any of the fluid gets into your eyes. Escaping battery fluid may cause skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries.
Protect the appliance from heat, e.g. also from continuous sunlight, fire, water and humidity. There is a risk of explosion.
Safety guidelines for battery chargers
This appliance may be used by children aged 8 years and above and by persons with limited physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the appliance safely and are aware of the potential risks. Do not allow children to use the appliance as a toy. Cleaning and user maintenance tasks may not be carried out by children unless they are supervised.
The charger is suitable for indoor use only.
If you are using a USB power supply, the mains socket used must always be easily accessible so that the USB power supply can be quickly disconnected from the socket in a hazardous situation. Please also observe the operating instructions for the USB power supply.
WARNING! Use only the power cable supplied with the supplied charger!.
The nozzle . reaches a temperature of over 170^
WARNING!
- Never operate the charger if the power plug is damaged. Damaged plugs are hazardous to life due to the increased risk of electric shock.
Before use
Charging the appliance battery
Only for indoor use!
NOTE
The battery is supplied partially charged. Before first use, charge the battery for at least 1 hours. Li-ion batteries can be charged at any time without adversely affecting their service life. Interrupting the charging process does not damage the battery.
Never charge the appliance when the ambient temperature is below 10^ or above 40^ .
Starting charging
Connect the USB-C plug of the charger cable 8 to the USB-C charging port 7 on the charger 13.
Connect the USB plug of the charger cable to the mains adapter 10.
Connect the mains adapter to a 100 - 240V ,50 / 60Hz power source.
Place the cordless glue gun onto the charging cradle 13. The battery charge level indicator lights up red.
Stopping charging
The green battery charge level indicator ③ indicates that the charging process is complete and the cordless glue gun is ready for use.
Remove the cordless glue gun from the charging cradle 13.
Disconnect the mains adapter 10 from the power supply.
Battery level display
The battery level display 3 indicates the charge level using 2 coloured LEDs.
Green LED
The battery is fully charged.
Red LED
The battery is flat. Recharge it.
Preparing the surfaces to be glued
- Do not use flammable solvents to clean the surfaces to be glued.
The ambient temperature and the materials to be bonded may not be colder than 5^ and not warmer than 50^ .
The area to be glued must be clean, dry and free of grease.
Smooth surfaces should be roughened before gluing.
Quick-cooling materials such as steel should be warmed a little to facilitate adhesion.
Use
Inserting a glue stick
Push the glue stick into the feeder shaft.
Switching on
To turn on the cordless glue gun, press the ON/OFF button until the temperature indicator lights up red and the battery capacity/charge level indicator lights up green/red. The glue is heated up.
Allow the appliance to heat up for about 60 seconds. The appliance is now ready for use.
The temperature indicator lights up green as soon as the appliance has reached working temperature.
Switching off
To turn off the cordless hot glue gun, press the ON/OFF button. The temperature indicator goes out.
During breaks in work, put the glue gun down on the stand 3. Allow the appliance to cool down fully before storing it. The hot nozzle . can cause damage and/or burns.
Automatic switch off
NOTE
The cordless glue gun switches itself off after 10 minutes to save energy.
- Switch the cordless glue gun back on. Check the temperature indicator ① and the battery capacity indicator ③ to see whether the appliance needs to be recharged or heated further.
To save energy, do not switch the cordless glue gun on unless you plan to use it.
During breaks in work, put the glue gun down on the stand.
Gluing
Pull the trigger to regulate the flow of glue in accordance with your requirements.
Apply the glue in spots. For flexible materials, such as textiles, apply the glue in zigzag lines.
Press the two workpieces to be bonded together immediately after applying the glue and hold for about 30 seconds. The glued bond is ready after about 5 minutes.
During breaks in work, put the glue gun down on the stand 12.
Remove any glue residue after it has cooled down with a sharp knife. Bonded joints can be released by heating.
Maintenance and cleaning
The cordless glue gun is maintenance free.
WARNING! Always remove the mains adapter ⑩ from the power socket before cleaning the appliance. Keep the appliance clean and dry at all times.
The appliance must always be kept clean, dry and free from oil or grease.
Do not allow any liquids to get into the appliance.
Use a cloth to clean the housing. Never use petrol, solvents or cleansers which can damage plastic.
Disposal
The packaging is made from environmentally friendly material and can be disposed of at your local recycling plant.
Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material components for disposal if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1-7: plastics, 20-22: paper and cardboard, 80-98: composites.
Your local community or municipal authorities can provide information on how to dispose of the worn-out product.
Do not dispose of electrical appliances in the household waste!
As required by European Guideline 2012/19/EU, worn-out electrical appliances must be collected sepa
rately and fed into an environmentally compatible recycling process.
The appliance and the batteries must be disposed of separately.
ATTENTION!
The battery must be removed/disposed of by a specialist technician.
Dispose of the appliance via an approved disposal company or your municipal waste facility. Please comply with all applicable regulations. Please contact your waste disposal facility if you are in any doubt.
Do not dispose of batteries in your normal householdwaste! Disposal of (rechargeable) batteries
Used batteries may not be disposed of in the household waste. Consumers are legally obliged to dispose of batteries at a collection point in their community/city district or at a retail store. The purpose of this obligation is to ensure that batteries are disposed of in an environmentally friendly manner. Only dispose of batteries when they are fully discharged.
The product is recyclable, subject to extended producer responsibility and is collected separately.
This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.
This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.
The warranty period does not apply to
Normal reduction of the battery capacity over time
Commercial use of the product
Damage to or alteration of the product by the customer
Non-compliance with safety and maintenance instructions, operatingerrors
Damage caused by natural hazards
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
Please have the till receipt and the item number (e.g. IAN 12345) available as proof of purchase.
- You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com.
This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 123456.
WARNING!
Have your appliance repaired by qualified specialists only. Always use original spare parts. This will ensure that the safety of the appliance is maintained.
- Plugs and power cords should only be replaced by the manufacturer of the power tool or the manufacturer's authorised customer service agent. This will ensure that the safety of the appliance is maintained.
Service
Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN 338353_2001
Importer
Please note that the following address is not the service address. Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Translation of the original Conformity Declaration
We, KOMPERNASS HANDELS GMBH, documents officer: Mr. Semi Uguzlu, BURGSTR. 21, 44867 BOCHUM, Germany, hereby declare that this product complies with the following standards, normative documents and EC directives:
EC Low Voltage Directive (2014/35/EU)
EMC (Electromagnetic Compatibility) (2014/30/EU)
RoHS Directive (2011/65/EU)*
- The manufacturer bears the full responsibility for compliance with this conformity declaration. The object of the declaration described above complies with the requirements of the Directive 2011/65/EU of the European Parliament and Council of 8 June 2011 on the limitations of use of certain dangerous substances in electrical and electronic appliances.
Applied harmonised standards
EN 60335-1:2012/A2:2019
EN 60335-2-45:2002/A2:2012
EN 60335-2-29:2004/A11:2018
EN 62233:2008
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN IEC 61000-3-2:2019
EN 61000-3-3:2013
EN 61000-3-3:2013/A1:2019
EN 50581:2012
Type/appliance designation: Cordless hot glue gun PHPA 4 B3
Year of manufacture: 05-2020
Serial number: IAN 338353_2001
Bochum, 04/06/2020
Semi Uguzlu
- Quality Manager -
The right to effect technical changes in the context of further development is reserved.
Table des matieres
Introduction 42
Chere cliente, cher client,
Chere cliente, cher client,
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
ALLEMAGNE
www.kompernass.com
Directive RoHS (2011/65/EU)*
Nominate stroom 300 mA
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
DUITSLAND
www.kompernass.com
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NIEMCY
www.kompernass.com
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NÉMECKO
www.kompernass.com
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NEMECKO
www.kompernass.com
Preklad originalneho vyhlasyenia o zhode
My, spolocnost' KOMPERNASS HANDELS GMBH, zodpovedny za dokumentaciu: pán Semi Uguzlu, BURGSTR. 21, 44867 BOCHUM, Deutschland/Nemecko vyhlasujeme, ze tento vyrobok je v sulade s nasledovnymi normami, normativnymi dokumentmi a smernicami ES:
Smernica ES o nízkom napāti (2014/35/EU)
Elettromagneticka kompatibilita (2014/30/EU)
Smernica RoHS (2011/65/EU)*
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
