USER MANUAL PPMAS 20-Li A2 PARKSIDE

Operation and safety notes

Translation of the original instructions

FR BE

20 V POLISSEUSE SANS FIL

GB/IE Operation and safety notes Page 24

Warnings and symbols used. 25

Introduction 26

Intended use. 26
Scope of delivery . 26
Parts description. 26
Technical data. 27

Safety instructions 28

General power tool safety warnings. Page 28
Polisher safety warnings. Page 30
Vibration and noise reduction. 31
Behaviour in emergency situations. 31
Residual risks. 31
Battery charger safety warnings.. 32

Before first use. 33

Unpacking the product. 33
Accessories 33

Operation. 33

33
Checking the battery pack charging level . 33
Charging the battery pack 33
Installing/removing the polishing disc and polishing sponge. Page 34
Notes on the use of other accessory tools. Page 34
Switching on and off. 35
Adjusting the speed 35
Trial run. 35

Working instructions. 35

Cleaning and care. 36

Cleaning 36
Maintenance. 36
Repair. 36
Storage. 36
Transportation. 37

Disposal 37

Warranty. 38

Warranty claim procedure. Page 38

Service 39

EU Declaration of conformity. 40

Warnings and symbols used The following warnings are used in this instruction manual, on the packaging and on the rating label:
	Read the instruction manual.		Switch the product off and remove the battery pack before replacing attachments, cleaning and when not in use.
	DANGER! This symbol in combination with the signal word "Danger" marks a high-risk hazard that if not prevented could result in death or serious injury.		WARNING! This symbol in combination with the signal word "Warning" marks a medium-risk hazard that if not prevented could result in death or serious injury.
	CAUTION! This symbol in combination with the signal word "Caution" marks a low-risk hazard that if not prevented could result in minor or moderate injury.		ATTENTION! This symbol with the signal word "Attention" indicates a possible property damage.
max. 45°C	Protect the battery pack against heat and continuous intense sunlight.		Protect the battery pack against water and moisture.
	Use in dry indoor rooms only. Protect the battery pack from fire.
	Wear safety gloves.		Protection class II (double insulation)
	Wear hearing protection! Alternating current/voltage
	Wear eye protection! Direct current/voltage
	Unplug	T3.15A	Fuse
	Wear a safety helmet! Do not use if damaged.

Use a dust mask!	CE	CE mark indicates conformity with relevant EU directives applicable for this product.
Not for cutting	☐	Safety information
	☐	Instructions for use

20V CORDLESS POLISHER STARTER SET

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This cordless polisher (hereinafter "product" or "power tool") is intended for polishing.
Any other usage of or modification to the product is deemed to be improper and carries a significant risk of accidents. The manufacturer accepts no responsibility for damage(s) resulting from improper usage. The product is not intended for commercial use.
The product is designed for use by adults.
Adolescents over the age of 16 may use the product only under supervision. The operator or user is responsible for accidents or damage to other people or their property.

The product is part of the Parkside X 20 V Team series. The product must be used with batteries from the Parkside X 20 V Team series.

Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 20V Cordless polisher starter set PPMAS 20-Li A2
1 Polishing disc (M8) with pre-assembled washer and O-ring
2 Polishing sponges (0 150 mm) (black = soft, red = hard)
1 Wrench
1 Carrying case
1 Battery pack
1 Battery charger
1 Instruction manual

- Parts description

Figure A:

1 On/off switch
Speed adjustment wheel
3 Grip handle
4 Battery pack
Polishing sponge
6 Polishing disc
Guard
8 Spindle
9 Thread cap
10 Wrench

Figure B:

11 Release button for battery pack
12 button (charging level)
13 Charging level LEDs (red/orange/green)

Figure C:

14 Battery charger (rapid battery charger)
15 Mains cord with mains plug
16 Charging control LED - Green
17 Charging control LED - Red

Figure E:

6a Washer
6b O-ring

Technical data

20V Cordless Polisher Starter Set PPMAS 20-Li A2
Rated voltage: 20 V	---
Motor speed: 500-3,000 min	-1
Plate size: 150 mm
Working capacity per 4 Ah battery charge: approx. 50 min

Battery pack PAP 204 A1
Model: HG13859
Type: Lithium-Ion
Rated voltage:	20 V--- max.
Capacity:	4.0 Ah
Energy value:	80 Wh
Number of cells:	10

Rapid battery charger PLG 20 C3
Model
- VDE version:	HG13195
- BS version:	HG13195-BS
Input:
Rated voltage:	230-240 V~
Rated frequency:	50 Hz

Rated power:	120 W
Fuse (internal):	3.15 A/ T3.15A
Output:
Rated voltage:	21.5 V---
Charging current:	4.5 A
Protection class:	II/□

Charging time:

		2 PAP 202 A1 2 Ah	2 PAP 204 A1 4 Ah
1	PLG 20 A4/C1 (max. 2.4 A)	60 min	120 min
1	PLG 20 A3/C3 (max. 4.5 A)	35 min	60 min
1	Battery charger
2	Battery pack

Recommended ambient temperature:

While charging:	+4 °C to +40 °C
During operation:	+4 °C to +40 °C
During storage:	+20 °C to +26 °C

Noise emission value

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the power tool is typically as follows:

Sound pressure level LpA:	74.0 dB
Uncertainty KpA:	3 dB
Sound power level LWA:	82.0 dB
Uncertainty KWA:	3 dB

Vibration emission value

Vibration total values (triaxial vector sum) determined according to EN 62841:

Hand/arm vibration ah,AG:	6.774 m/s2
Uncertainty K: 1.5 m/s	2

WARNING!

Wear ear protection!

WARNING!

The vibration and noise emissions during actual use of the power tool can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed.

Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the power tool is switched off and when it is running idle in addition to the trigger time).

NOTE

The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

Safety instructions

• General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

1) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
3) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

1) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
2) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased

risk of electric shock if your body is earthed or grounded.

3) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
4) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
5) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
6) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

1) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
2) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
3) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.

4) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
5) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
6) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
8) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

1) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
2) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
3) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

4) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
5) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
7) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
8) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Battery tool use and care

1) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
2) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
3) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails,

screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

4) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
5) Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
6) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130^ may cause explosion.
7) Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.

Service

1) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
2) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.

• Polisher safety warnings

WARNING!

Dust from materials such as lead paint, some types of wood, and metal can be harmful to your health.

WARNING!

Contact with or inhaling this type of dust can present a danger to the user or persons nearby.

WARNING!

Wear safety glasses and a dust mask!

Vibration and noise reduction

To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment.

Take the following points into account to minimise the vibration and noise exposure risks:

Only use the product as intended by its design and these instructions.

Ensure that the product is in good condition and well maintained.

Use correct accessory tools for the product and ensure they are in good condition.

• Keep tight grip on the handles/grip surface.

• Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate).

Plan your work schedule to spread any high vibration tool use across a longer period of time.

Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.

• Switch the product off and disconnect it from the mains if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
Danger of injury and property damage caused by flying objects.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

- Battery charger safety warnings

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

• Do not charge nonrechargeable batteries. Disregarding this instruction is hazardous.

• Protect the electrical pa
  against moisture. Do not
  immerse such parts in
  water or other liquids to
  avoid electrical shock.
  Never hold the appliance
  under running water. Pay
  attention to the instructions

provided for cleaning, maintenance and repair.

The appliance is suitable for indoor use only.

Suitable battery packs and chargers

ATTENTION! This charger is only designed for charging the battery pack types:

Parkside 20 V battery pack
PAP 202 A1	2 Ah	5 cells
PAP 204 A1	4 Ah	10 cells

Battery pack:	Parkside X 20 V Team
Charger: Parkside X 20 V Team

Customers can order compatible replacement batteries and chargers from Lidl online shops for the following countries:

Germany (lidl.de), France (lidl.fr), Belgium (lidl.be), Czech Republic (lidl.cz), Netherlands (lidl.nl), Poland (lidl.pl), Slovakia (lidl.sk), Spain (lidl.es)

Customers from all other countries can order from www.optimex-shop.com.

Before first use

Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

- Accessories

WARNING!

Do not use accessories not recommended by Parkside. This may result in electric shock or fire.

NOTE

This instruction manual contains information and suggestions for several accessory tools and their uses. The accessory tools depicted are not included in the shipment (see "Scope of delivery"), but are meant to indicate additional possibilities for using this product.

To operate this product safely and correctly, the following accessories, i.e. tools and accessory tools, are necessary:

Polishing disc
Polishing sponge

Accessories and accessory tools are available through your authorised dealer. When buying always consider the technical requirements of this product (see "Technical data").

If you are not certain, ask a qualified specialist and get advice from your trusted dealer.

Suitable battery packs and chargers

Parkside X 20 V Team battery pack and charger

Operation

• Attaching/removing the battery pack

(Fig. D)

• Removing the battery pack: Press the battery pack release button [1]. Remove the battery pack [4].

• Attaching the battery pack: Align the battery pack 4 to the grip handle 3 and slide the battery pack in. Ensure the battery pack clicks noticeably in place. The battery pack can only be inserted into the product in one direction.

• Checking the battery pack charging level

(Fig. B)

Check battery pack charge level: Press the 12 button. The charging level LEDs 13 light up:

LED 13	Charging level
Green Maximum
Orange Medium
Red Low

Charging the battery pack (Fig. C)

NOTE

The battery pa4 may be charged at any time without reducing the life.
Interrupting the charging process does not damage the battery pack [4].

• Charge the battery pack 4 before operation when it is at medium or low charging level.

The charging control LEDs (green 16 and red 17) indicate the status of the charger 14 and the battery pack 4:

LED Status
Red LED lights up	Battery pack charges
Green LED lights up	Battery pack fully charged
Green and red LED flashing	Battery pack defective
Red LED flashing	Battery pack too cold or too warm
Green LED lights up (without battery pack) Charger ready

1. Insert the battery pack 4 into the charger 14.
2. Connect the mains cord with mains plug 15 of the charger 14 to the socket.

3. When the battery pack 4 is fully charged: Remove the battery pack from the charger 14. Then disconnect the mains cord with mains plug 15 of the charger from the socket.

4. Installing/removing the polishing disc and polishing sponge

WARNING!

Before installing/removing the polishing disc 6: Switch the product off. Remove the battery pack 4 from the product to prevent the product from starting unintentionally. Let the product cool down.

CAUTION! Risk of injury!

Wear protective gloves.

CAUTION! Risk of injury!

• Keep your hands away from the polishing disc when the product is in operation.
  After the product has been switched off, the polishing disc 6 continues moving for some time. Do not touch the polishing disc and do not attempt to brake it.

NOTE

The product must only be operated with the polishing disc 6 and polishing sponge 5 mounted.

1. Switch the product off.
2. Remove the battery pack 4.
3. Remove the thread cap 9 from the polishing disc 6. Make sure that the washer 6a and the O-ring 6b are securely mounted (Fig. E).
4. Fix the spindle 8 using the wrench 10 (Fig.F).

5. Installing:

6. Screw the polishing disc into the spindle in clockwise direction.

7. Attach the polishing spong 5 on the polishing disc 6 (Fig. G).

8. Removing:

9. Rotate the polishing disc in counter-clockwise direction.

10. Remove the polishing sponge from the polishing disc.

Notes on the use of other accessory tools

CAUTION! Risk of injury!

Only use accessory tools recommended by the manufacturer. Using other accessory tools and other accessories can represent a risk of injury for you.

CAUTION! Risk of injury!

Only use accessory tools, which bear information about the manufacturer, type of binding, dimension and permitted number of revolutions.
Only use accessory tools where the printed rotational speed is at least as high as what has been specified on the product marking.
Do not use any broken, cracked, or otherwise damaged accessories.
Only use flawless accessory tools.
Ensure that the accessory tool dimensions match those of the product.
Never re-drill a locating hole which is too small to make it larger.
Never use separate bushings or adaptors in order to make wheels with a hole that is too large fit the product.

Switching on and off

(Fig. H)

CAUTION! Risk of injury!

Always wear protective gloves when handling or working with the product.

CAUTION! Risk of injury!

Always hold the product with both hands while working (Fig. 1).
- Keep your hands away from the polishing disc when the product is in operation.
After the product has been switched off, the polishing disc 6 continues moving for some time. Do not touch the polishing disc and do not attempt to brake it.

CAUTION! Health risk!

Never work on materials containing asbestos. Asbestos is considered carcinogenic.

• Switching on: Slide the on/off switch 1 to position ON.
• Switching off: Slide the on/off switch 1 to position OFF.

(Fig. J)

Adjusting the speed

• Roll the speed adjustment wheel 2 up or down to adjust the speed.

The product features 6 speed levels.

Level Speed
1 500 min	-1
2 1,000 min	-1
3 1,500 min	-1
4 2,000 min	-1
5 2,500 min	-1
6 3,000 min	-1

Trial run

Always carry out a no-load trial run before starting work and after every accessory tool replacement. Switch the product off immediately if the accessory tool is not running smoothly, if considerable vibration occurs or if you hear abnormal noises.

Working instructions

ATTENTION! Risk of property damage!

Do not use a damaged polishing sponge. Using a damaged polishing sponge increases the risk of scratches on the surface to be polished.

• Select a low speed for polishing (level 1-2) to prevent the surface from overheating.
• When using a polishing agent, refer to the instructions for use from the polishing agent manufacturer.
• Apply the polishing agent to an area slightly smaller than the area which you intend to polish. Using the appropriate polishing accessory, work in the polishing agent using side-to-side or circular motions. Apply moderate pressure only.
• Apply the polishing agent in 4 to 6 even spots on the polishing accessories. Then distribute it selectively over the surface to be polished.
  Do not allow the polishing agent to dry out on the surface, as this may damage the surface.
  Do not expose the surface which you intend to polish to direct sunlight.
  Clean the polishing accessories regularly to ensure good polishing results.

Wash the polishing accessories with mild detergent and warm water. Do not use thinning agents.

- Cleaning and care

WARNING!

Always switch the product off, remove the battery pack 4 and let the product cool down before performing inspection, maintenance and cleaning work!

WARNING! Risk of electric shock!

Do not spray the product with water. Do not immerse the product in water.

- Cleaning

NOTE

Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.

• Never allow fluids to get into the product.
  The product must always be kept clean, dry and free from oil or grease. Remove debris from it after each use and before storage.
  Regular and proper cleaning will help ensure safe use and prolong the life of the product.
  Clean the product with a dry cloth. Use a soft brush for areas that are hard to reach.
  In particular clean the air vents after every use with a cloth and soft brush.

The vents must always be clear.

Maintenance

Before and after each use, check the product and accessories (e.g. accessory tools) for wear and damage. If required, exchange them for new ones as described in this instruction manual. Observe the technical requirements (see "Technical data").

Repair

This product does not contain any parts that can be repaired by the user. Contact an authorised service centre or a similarly qualified person to have it checked and repaired.

Storage

Switch the product off.
Clean the product (see "Cleaning").

Store the product and its accessories in a dark, dry, frost-free, well-ventilated place.

Always store the product in a place that is inaccessible to children. The ideal long term storage (longer than 3 months) temperature is between +20 and +26^ .
Store the product in its case 18.

Battery pack advice

• Only store the battery pack 4 partially charged. The battery pack should be charged to 40 to 60% (orange charging level LED 13 lights up) before storing for extended periods.
  Check the battery pack 4 charge about every 3 months when storing for extended periods. Recharge as necessary.

- Transportation

Switch the product off.

Transport the product in its carrying case 18.
- Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles.
- Secure the product to prevent it from slipping or falling over.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the

packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Remove the batteries/battery pack from the product before disposal.

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used

batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 495861_2504) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 495861_2504 takes you to the operating instructions for your item.

Service

GB

Service Great Britain

Tel.:[phone]

Contact form on parkside-diy.com

IAN 495861_2504

E

Service Ireland

Tel.:[phone]

Contact form on parkside-diy.com

IAN 495861_2504

EU Declaration of conformity

EU DECLARATION OF CONFORMITY (No.495861_2504)

IAN: 495861_2504

Product identification:

"PARKSIDE" Cordless Polisher 20V

Model Number: HG13739

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN ISO 12100:2010

EN 62841-1:2015/A11:2022

EN 62841-2-4:2014/AC:2015

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021

EN 61000-3-3:2013/A2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018 (4.3.3.c)

IEC 62321-3-1:2013

IEC 62321-4:2013+A1:2017

IEC 62321-5:2013

IEC 62321-6:2015

IEC 62321-7-1:2015

IEC 62321-7-2:2017

IEC 62321-8:2017

Additional information:

N° / Parts

EN 60335-2-29:2021/A1:2021

EN 60335-1:2012/A16:2023

EN 62233:2008

IEC 62133-2:2017

IEC 62133-2:2017/AMD1:2021

EN 62841-1:2015/A11:2022 Annex K

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 30.09.2025

Place

Date

Productidentification:

EU VYHLASENIE O ZHODE (c. 495861_2504)

IAN: 495861_2504

Identifikación Produktu:

"PARKSIDE" Aku uhlova lesticka 20V

Cislo modelu: HG13739

Kunderiandre landekan bestille disse pa www.optimex-shop.com.

• Inden den første化进程

6a Rondella
6b O-ring

Dati tecnici
