MZP03 - Iron MPM - Free user manual and instructions

Product Type	Garment Steamer
Brand	MPM
Model	MZP03
Water tank capacity	260 ml
Power cord length	2.5 m
Power voltage	220-240 V ~ 50/60 Hz
Rated power	1500 W
Heat-up time	Approx. 30 seconds
Main functions	Vertical and horizontal steam, auto-off, steam lock
Included accessories	Brush for thick fabrics, fabric brush
Usage	Household use only
Care and cleaning	Wipe the body and soleplate with a damp cloth; rinse the tank regularly
Safety	Auto-off, do not immerse, do not direct steam at people or animals
Storage	In vertical position, empty tank, cord wrapped
Weight	Approx. 1.2 kg

Frequently Asked Questions - MZP03 MPM

How to fill the water tank of the MPM MZP03 steamer?

Unplug the device. Remove the filling cap (6a) and pour demineralized or distilled water up to the MAX level. Do not exceed the MAX line to avoid leaks. Close the cap.

Why is my steamer not producing steam?

Check the water level in the tank and make sure the cap is properly closed. Press the steam button (5) harder. Hold the device vertically during use.

What to do if water leaks from the tank?

Check that the water level is not too high (should not exceed the MAX mark). Make sure the filling cap is properly closed.

How to use the brush for thick fabrics?

For thick fabrics (coats, velvet), attach the brush (cushion) to the soleplate when the device is unplugged and cooled. The brush improves steam penetration and removes pet hair.

How to clean the MPM MZP03 steamer?

Unplug the device and let it cool. Wipe the body and soleplate with a non-abrasive damp cloth. Rinse the water tank with clean water and empty it. Never immerse the device in water.

Why does the steamer make a loud pump noise?

A louder than usual pump noise usually indicates a lack of water in the tank. Fill the tank with demineralized or distilled water.

How to avoid burns when using the steamer?

Never direct steam at people or animals. Do not touch the hot soleplate. Use the brush to maintain a safe distance. The device emits very high temperature steam.

Can I use the steamer horizontally?

Yes, the device is designed for vertical and horizontal use. However, do not turn the device completely upside down. For horizontal steaming, keep the soleplate about 5 cm from the fabric.

How to store the steamer after use?

Turn off the device, unplug it, and empty the water tank. Let it cool completely. Wrap the cord around the device and store it in vertical position on a stable surface, away from heat and sunlight.

What to do if the steamer does not heat up?

Check that the plug is properly inserted into a grounded outlet and that the power supply is active. Make sure the switch (3) is in the on position. If the problem persists, contact an authorized service center.

USER MANUAL MZP03 MPM

EN We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances

Black and gold steam shaver with a glossy black body and a light blue handle (no visible text or symbols)

MZP-03

NAPAROVAC ON T.V.

DAMPTG-ATTR

ROMASTE ALRUT

HAPP-1 POJXON

(1) 2023年1月1日

DÉFROISSEUR A UNGE

PULIAGOZOLO

VAPORE | O PER VESTITI

KABUZU GARNTUVAS

ARCEBO VALETAOS

15/30/2014A 3C 18H24

APARAT DE AEUR PENTRU HANE

Automatic, continuous stream of steam (up to 30 yr./min.), activated by an button

AUTO SHUT-OFF - Automatic shutdown

For all types of fabrics, including delicates

Removable cover with a velour brush and bristles

Removable water tank 260 ml

Stainless steel steam plate

BEZPEČNOSTNÍ POKYNY PŘI POUŽÍVÁNÍ

-Read the instructions carefully before use.
-Insert the device's power plug to an earthed power socket.
- Take special care when children are near the device. Do not let anyone touch the device during steam ironing.
- Do not immerse the device, cable or plug in water or other liquids!
-Do not leave the device unattended if connected to the mains.
- Do not hang the cable on sharp edges or allow it to come into contact with hot surfaces.

- Regularly check the power cord and the connecting hose for any damage.

- Never use a damaged device, including one with a damaged cord or plug, in which case have it repaired at an authorised service centre.

-Always unplug the device when not in use.

- Before cleaning, assembling or disassembling the device, unplug it from the mains socket and wait until it has cooled down completely.

- Disconnect the device from the mains before filling in or emptying the tank.

-Never touch the device's soleplate when it is on!

- Fill the tank with water only. It is recommended to use distilled water to avoid limescale buildup on the device's internal parts.

- Do not add any chemical agents to the water in the tank - they may damage the device.

-To avoid burns, do not touch the device's hot metal parts, hot water or steam.

- Do not use the device for purposes other than those for which it was intended.

-The device is intended for domestic use only.

-Do not use the device outdoors.

-Do not open the water tank's cover when using the device.

-Place the device on a stable surface when not in use

- Do not use the device if it fell down, shows signs of damage or leaks.

- This equipment may be used by children of at least 8 years of age and by persons of diminished physical, mental capacity and lack of experience and knowledge of the equipment if supervision or

instruction is provided regarding the safe use of the equipment so that the hazards involved are understood. Unsupervised children should not perform cleaning and maintenance on the equipment.

-Keep the device and its cord out of reach of children under 8 years of age.
-Children are not allowed to play with the device.
- Pour out the water remaining in the tank after the ironing is finished.

• Never iron clothes or fabric that are worn or placed on people or pets.
• Never direct the steam at people or pets.
• Do not pull the plug out of the power socket by pulling the cord.
  -Do not connect the plug to the power socket with wet hands.
• Do not wind the power cable around the device until it cools down.
• Do not place the device near electric or gas cookers, burners, ovens, etc.
• The equipment is not designed to operate using external timers or a separate remote control.
• When putting the iron away on the stand, make sure the surface on which the stand is placed is stable.
• Before switching the device on, make sure the mains parameters match the values on the device's identification plate.
• For the safety of children, please do not leave freely accessible parts of the packaging (plastic bags, cardboard boxes, polystyrene, etc.).
• WARNING! Do not allow children to play with the film. Danger of suffocation!
• Place the device no closer than 20 cm from walls, curtains or other materials sensitive to heat or steam. Make sure there is ample empty space on all sides of the device for air circulation.
• Do not fill the water tank beyond the MAX capacity line as this may cause water leakage.
  -Exercise caution when using the device as it generates steam.
  -Do not let the power cord touch any hot surfaces.
• Do not use the device without water. This can damage the device.
• Do not use the device for cleaning electrical equipment and installations.
• Do not touch any hot surfaces. Before installing or removing accessories, turn the device off and wait for cooling down.

WARNING! Exercise caution. The icon on the appliance indicates that hot steam is being released during operation. Care should be taken when operating the device to expose yourself to the risk of suffering burns.

DEVICE DESCRIPTION

1. Housing
2. Steam plate
3. On / off switch
4. Operating status indicator light

5. Steam ejection on/off button with lock

6. Water tank with a capacity of 260 mL 6a. Water filler cap

7. 2.5 m rotating mains cable
8. Pad for thicker fabrics and pet hair removal

Fabric brush (8) - allows better steam penetration, ideal for thick fabrics such as coats; allows to pick up threads, hair, lint or hair from delicate materials such as velour, velvet or wool quickly.

BEFORE FIRST USE

1. Take the device out of the box and remove all protecting cardboard and foil.
2. Unwind and straighten the cord before use.

CAUTION! A smoke may come out of the device during the first use. This phenomenon stops after a short while.

PREPARATION FOR USE

FILLING THE WATER TANK

1. Make sure the device is not connected to the mains.
2. Remove the water tank (6).
3. Remove the water filler cap (6a).
4. Fill the tank with water to the maximum level.

ATTENTION! To prevent scale formation, always use fresh demineralized or distilled water. Do not use chemically descaled water or any other liquids.

1. Close the water filler hole (6a).
2. Put the water tank back into the device.

INSTALLATION OF ACCESSORIES

1. In order to put on the overlay, disconnect the device from the power source and wait until it cools down completely.
2. Then, holding the device firmly with one hand, put on the brush with the other so that the protrusions in the attachment fit into the recesses in the working part of the device; a "click" will be heard if lock will be placed correctly. To remove the cap, hold the device firmly and pull the handle at the bottom of the cap.

CAUTION! Always unplug the steamer from the power supply before attaching or removing the brush attachment. Warning! The steam soleplate may still be hot.

The brushes improve the penetration of steam into thick and heavy fabrics, allowing faster results. Brush attachments are intended for use with steam.

USING THE FOOD PROCESSOR

1. Connect the power cord plug (7) to a grounded power socket. The indicator light (4) will start flashing.
2. The steamer heats up and is ready for use after about 30 seconds. This is signalled by the constant lighting of the control lamp (4).
3. When the device is ready to use, press the steam activation button (5). Before starting ironing, direct the steam stream away from the clothing for a few seconds, as the initial steam stream may contain drops of water.
4. Press the on/off button to stop steaming.
5. If the brush attachment is not in use during steam ironing, keep the steam foot 5 cm away from the fabric.
6. During steam ironing, bring the steam soleplate closer to the garment. At the same time, use your other hand to pull the sides of the garment to straighten it.

CAUTION! Do not aim the steam directly at metal accessories. Be careful around metal accessories.

1. After steam ironing, press the on/off switch.

To make it easier to iron items of clothing, hang them on a hanger.

For shirts with buttons, fasten the first button at the collar to make it easier to straighten the fabric.

CAUTION! Do not support the fabric with your unprotected hand during steam ironing. Do not place the steam foot on the power cord after use.

Steam ironing may cause small wet spots on the garment. Clothing may also be slightly damp due to steam.

At the end of your session, let your garment dry before putting it on or putting it back on.

ATTENTION! The steamer is designed to be used vertically and horizontally. The device should not be turned upside down.

CAUTION! The work of the water pump can be heard as a soft hum initiating by press - ing the steam button. If there is no water in the tank, the operation of the pump will be louder. If such situation occurs, the water tank should be refilled.

The device is equipped with an automatic shut-off function. This function is launched when the device is not used for a long time. This function is signalled by the blinking of the control lamp (4).

CAUTION! The device produces steam at a very high temperature! Risk of scalding! Do not direct the vapor stream at people or animals!

AFTER FINISHING IRONING

1. Turn off the device using the switch (5).
2. Unplug the power cord (7) from the electrical socket.
3. Empty the water tank (6).
4. Put the device in a safe place in an upright position and wait for it to cool down.

CLEANING AND MAINTENANCE

CAUTION! Never submerge the device in water or rinse it under running water

1. Wipe off any deposits from the steam soleplate (2) using a damp cloth and a non-abrasive liquid cleaner.

CAUTION! To keep the surface of the foot unscratched, the device should not be placed near any metal objects. Do not use scourers, vinegar or other chemicals to clean the foot.

1. Wipe the housing of the device with a damp cloth.
2. Regularly rinse the tank with water (6) and empty it after rinsing.

STORAGE

1. Turn off the device using the switch (3) and remove the plug from the mains socket.
2. Empty the water tank (6).
3. Wait for the device to cool down. Securely wrap the power cord around the device.
4. Always store the empty device in an upright position on a stable surface.
5. Do not place the device near heat sources or in direct sunlight.
6. Always make sure that the steam outlets are clean and free of debris.

TROUBLESHOOTING

Problem Possible solution
The steamer will not heat up Check if the power cord plug is properly connected.Check if power is available.Check the switch.
The steamer will not generate steam Check the water level and the correct closure of the water filler cap.Press the steam trigger harder.Hold the steamer upright.
Water is leaking from the tank Check that the water level is not too high - just under the cap.Check that the water filler cap is closed properly.
There is a loud buzzing or pumping noise coming from the steamer	Check the water level, if it is low or if there is no water at all, fill the tank.
Wrinkles cannot be easily removed with a steamer	For best ironing results, hold the steamer upright and straighten the fabric by pulling downwards.
When to use a brush for thicker fabrics	A brush for thicker fabrics should be used if the steam comes into direct contact with the fabric being ironed.For ironing delicate fabrics, e.g. silk, to reduce the risk of water dripping onto the garment during ironing.
How to avoid discoloration of metal decorative elements on clothing	Do not stop the steamer directly over metal parts on the garment.Be cautious around such items.

TECHNICAL DATA

Technical specifications are given on the product nameplate. Length of mains cable: 2.5 m

CAUTION! MPM agd S.A. reserves the right to technical changes!

Proper disposal of the product (waste electrical and electronic equipment)

Marking on the product indicates that after the service-life of the product expires, it should not be disposed with other type of municipal waste. Used equipment may have a negative impact on the environment and health of people due to potentially containing hazardous substances, mixtures and components. Mixing electric waste with other types of waste or disassembling those in an unprofessional manner may cause a release of substances that are hazardous to the environment and health.

Used equipment should be handed-over to a point for collection of electric waste. In order to obtain detailed information regarding the electric waste collection points, the user should contact the municipal point of electric waste collection or used equipment processing department.

WARNING! Exercise caution. The icon on the appliance indicates that hot steam is being released during operation. Care should be taken when operating the device so as not to expose yourself to the risk of suffering burns.
