| Product type | Domestic high-pressure cleaner |
| Brand | Husqvarna |
| Model | PW 345C |
| Intended use | Domestic exterior cleaning in vertical position |
| Power supply | Mains connection via power cable |
| Operating pressure | Variable depending on setting |
| Water source | Connection to drinking water network or suction (tank, river, lake) |
| Detergent | Husqvarna detergents only |
| Safety devices | Automatic trigger stop, handle lock, thermal protection, hydraulic safety valve |
| Electrical protection | Residual current device (30 mA) recommended |
| Operating temperature | Above 0°C (do not use when frozen) |
| Maximum garden hose length | 10 to 25 meters, ½ inch diameter |
| User maintenance | Drain after use, inspection before start, regular cleaning |
| Storage | Frost-proof, horizontal on back, cable and hose coiled |
| Repairability | Use original Husqvarna parts, repair by authorized workshop |
| Compatible accessories | Hoses, fittings, and high-pressure couplings recommended by Husqvarna |
| Noise level | Hearing protection recommended |
| Personal protective equipment | Safety shoes, respirator mask, goggles, protective clothing |
| Countries of compliance | CENELEC and non-CENELEC (depending on version) |
| Disposal | Do not dispose of with household waste, recycle via collection points |
Frequently Asked Questions - PW 345C HUSQVARNA
User questions about PW 345C HUSQVARNA
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Washing machine in PDF format for free! Find your manual PW 345C - HUSQVARNA and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PW 345C by HUSQVARNA.
USER MANUAL PW 345C HUSQVARNA
Before first use of the machine, read the instructions carefully. Save instructions for later use.
Safety instructions marked with this symbol must be observed to prevent personal injury or serious damage to property.
The instruction consists of 3 parts. Part 1:3 Safety Instructions. Part 2:3 Serial specific User Guide. Part 3:3 Serial specific Technical Data and Declaration.
Warnings
This machine should only use Husqvarna branded detergents. The use of other cleaning agents or chemicals may adversely affect the safety of the machine.
High pressure jets can be dangerous if subject to misuse. The jet must not be directed at persons, live electrical equipment or the machine itself.
Do not use the machine within range of persons unless they wear protective clothes.
Do not direct the jet against yourself or others in order to clean footwear.
Risk of explosion – Do not spray flammable liquids.
High pressure washers shall not be used by children or untrained personnel.
High pressure hoses, fittings and couplings are important for the safety of the machine. Use only hoses, fittings and couplings recommended by Husqvarna.
To ensure machine safety, use only original spare parts recommended by Husqvarna.
Water that has flown through back-flow preventers is considered to be non-potable.
Don't use the machine if a supply cord or important parts of the machine are damaged, e.g. safety devices, high pressure hoses, trigger gun.
Inadequate extension cords can be dange rous. If an extension cord is used, it shall be suitable for outdoor use, and the connection has to be kept dry and off the ground. It is recommended that this is accomplished by a cord reel which keeps the socket at least 60 mm above the ground.
Switch off and unplug the machine when leaving it unattended, when finished using it or when converting it to another function, when doing repair and maintenance.
During use of high pressure washers, aerosols may be formed. Inhalation of aerosols can be hazardous to health, for the protection against aerosols a respiratory mask of class FFP 2 or equivalent may be needed, depending on the cleaning environment.
Intended use and terms of liability
The 100, 200, 300 and 400 series have been developed for domestic cleaning pur poses only and for use in an upright position. Any other use is considered as improper use.
A high pressure washer operates with different levels of pressure and cleaning detergents for various cleaning tasks and results. Always follow instructions on detergents for use, emergency and disposal.
Do not operate the machine at temperatures below 0^ C. Never start a frozen machine, never use it indoor and never cover it during use. This is considered improper and wrongful use. Use of wrongful pressure, detergent and/or applications may cause damage to machine, surfaces, material and devices. All of the above is considered improper and wrongful use. Husqvarna accepts no liability for any damage
resulting from any improper or wrongful use. Please refer to our website at www.husqvarna.com for further instructions and information on use, emergency and disposal.
Safety devices and their functioning
The machine automa tically stops when releasing the trigger. The machine will start again when reactivating the trigger. The spray handle features a locking device. When activated, the spray handle cannot be operated. The machine has an automatic self-resetting thermal protector. If the machine is overheated, the thermal protector will cut the power supply. In this case, wait for the machine to cool down. An integrated hydraulic safety valve protects the system from excessive pressure.
Precautions
The electric supply connection shall be made by a qualified electrician and comply with IEC 60364-1. It is recommended that the electric supply to this machine should include either a residual current device that will interrupt the supply if the leakage current to earth exceeds 30 mA for 30 ms or a device that will prove earth circuit.
Use motor start/delayed fuses with characteristic C, or D according to IEC 898-1, or IEC947-2, or corresponding standards outside IEC.
If the supply cord is damaged, it must be replaced by an authorized Husqvarna distributor or similar qualified person in order to avoid a hazard.
No actions needed for adjusting machines marked with dual voltage and frequency.
Supervise children not to play with the machine.
The operator and any one in the immediate vicinity of the site for cleaning should take action to protect oneself from being struck by debris dislodged during operation.
Always wear safety boots, respiratory mask, ear protection, goggles and protective clothing during operation.
The high pressure generated by the machine is a particular source of danger. Hold the spray lance firmly with both hands. The spray lance is affected by a kickback force and a sudden torque during operation.
See PART 3:3 for the actual size of the kickback force.
During transportation: Position the machine horizontally on the backside and secure with straps.
Valid for model PW 235R
Batteries may not be discarded together with household waste, but must be collected separately in accordance with local laws and regulations.
CENELEC countries
(AT, BE, BG, HR, CY, CZ, DK, EE, FI, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, ML, MT, NL, NO, PL, PT, RO, ES, SK, SI, SE, CH, TR, GB)
This machine can be used by people with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the machine in a safe way and understand the hazards involved.
Children shall be supervised to make sure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Outside CENELEC countries
- This machine is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge.
- Children should be supervised to ensure that they do not play with the appliance.
Part 2:3
Part 2:3 provides a general overview of the machine and operation elements along with illustrated sections on preparation, operation, water connection, storage, and user maintenance.
A Unpacking and preparing for use
Follow illustrations in A.
B Connection to potable water mains
High pressure washers are not suitable for connection to potable water mains. Always check national regula-before connecting the machine to potable water mains use a back-flow preventer if required.
Use 12 " garden hose, 10-25 m.
Follow illustrations in B.
C Connection to other water sources
You can connect the machine to e.g. rain water vessels, rivers, lakes and cisterns etc. and operate it in suction mode. Follow illustrations in C.
D Pairing of spray handle and machine
R-models only. After battery insert, D1, you have 2 min. to pair spray handle and machine. The light will flash orange when searching for the machine. When paired, the light will turn off. Follow illustrations D2. If pairing aborts, do pairing according to illustrations D3. Power regulation is indicated by green light, see illustration D5.
E Leaving the machine unattended > 5 min.
See listed warnings. Follow the illustrations in E.
F After use and storage
After use always:
- Turn off the machine.
- Empty machine and accessories of water to avoid frost damage.
- Remove the plug from socket.
- Disconnect water inlet hose.
- Wind up electrical cable and high pressure hose to avoid damage of cable, high pressure hose and fittings.
Storage of machine shall be frost free. Follow illustrations in F.
G Maintenance, inspection and repair
Maintenance of the machine should always be done when starting up after long time of storage.
Before use, always inspect the machine and equipment for damages. In case of damages, act according to listed warnings.
Do not attempt any maintenance not described in the instructions. If the machine refuses to start, stops, pulsates, pressure fluctuates, motor buzzes, fuse blows or no water comes out, check the trouble shooting diagram at our website www.husqvarna.com.
Any repair should always be made in Husqvarna authorized workshop with original Husqvarna spare parts.
User maintenance according to illustrations in G.
DA - SIKKERHEDSINSTRUKTIONER
HR - SIGURNOSNE UPUTE
Prije prve uporabe stroja pažljivo pročitajte upute. Sačuvajte upute za kasniju uporabu.
The image contains no discernible text or characters. The horizontal lines are stylistic or background elements and must be ignored according to the rules. Therefore, the correct OCR output is an empty string.
□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
[Non-Text]
The image contains no text. The horizontal lines are stylistic or background elements and must be ignored according to the rules.
The image contains only a stylistic horizontal line, which must be ignored according to the rules. According to Rule 2, such lines must be ignored and not represented by underscores or any other character in the OCR output.
Therefore, the corrected OCR text is:
[empty string]
The image contains only a stylistic horizontal line, which must be ignored according to the rules. According to Rule 2, such lines must be ignored and not represented by underscores or any other character in the OCR output.
Therefore, the corrected OCR text is:
[Empty String]
The image contains no text. The horizontal lines are stylistic or background elements and must be ignored according to the rules.
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
الاحتياطات
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
30
30
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
.
The image contains no text. The horizontal line is a stylistic or background element and must be ignored according to the rules.
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
3:3
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
PW 235R صالح للطراز
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□□
EN - Equipment marked with the crossed-out wheeled bin symbol indicates that used electrical and electronic equipment should not be discarded together with unseparated household waste. To avoid negative effects on human health and the environment the equipment must be collected separately at the designated collection points. Users of electrical and electronic household equipment must use the municipal collection schemes. Please note that commercially used electrical and electronic equipment, shall not be disposed of via municipal collection schemes. We will be pleased to inform you about suitable disposal options.
