USER MANUAL Thermometers 4 in 1 LA090103 LANAFORM

Version 01 dated 01/09/2010EN InstructIons INTRODUCTION Thank you for purchasing a LANAFORM® «4 IN 1 THERMOMETER».This ear and forehead thermometer from LANAFORM gives you an accurate temperature reading thanks to the infrared technology with which it is equipped. TITLE AND DESCRIPTION OF THE SYMBOLS IN THE LEAFLET DESCRIBINg THE PRODUCT: Symbol definition Identification Manufacturer’s informationManufacturer’s detailsLANAFORM SAB-4141 SPRIMONTBatch number LOTA BF type devicePlease note, please see the instructions.Please note, consult the attached documents. Please read these instructions before using the device. Please also follow these instructions carefully while using the device.Organisation notified Waste electrical and electronic equipment (WEEE) PLEASE READ ALL THE INSTRUCTIONS PRIOR TO USING YOUR «THERMOMETER», IN PARTICULAR THESE FEW BASIC SAFETY INSTRUCTIONS:

• Check that your mains voltage is compatible with that of the appliance. • Always keep your «4 IN 1 Thermometer» away from sources of heat such as stoves and radiators, etc. • Never use this appliance in a room where aerosol products (sprays) are used or in a room where oxygen is administered.

• Do not submerge the device in water.

• Do not drop the device and do not use it if it is damaged.

• This thermometer must be used when the ambient temperature is between 16 and 40°C.

• Do not expose the thermometer to electric shocks.

• Do not expose this thermometer to extreme temperature conditions, that is temperatures higher than 50°C or lower than -20°C.

• Do not use this device if the relative humidity is greater than 95%.

• Do not use this device close to strong magnetic fields, like for example those produced by cordless telephones or mobile phones.

• Accuracy of the temperature measurement can be affected if the forehead is covered by hair, sweat, a hat or a scarf.

• We recommend keeping the thermometer in the room for 10 minutes before using it.

• The use of this thermometer does not replace a consultation with your doctor.

• In case of problems with your thermometer, please contact the outlet you purchased it from.

• Do not try to repair the thermometer yourself.

• This device was not designed for use by people, including children, with reduced physical, sensory or mental capabilities, or people lacking experience or knowledge, unless they have had the benefit of prior supervision, advice and instruction in using the device from a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

• Only use the «4 in 1 Thermometer» for the use for which it is intended as described in this manual.

• The «4 in 1 Thermometer» is pre-configured before leaving the factory. There is no need to calibrate it therefore before first using it.

• Replace the cover over the sensor carefully after use.

• Replace the thermometer on its base and out of the reach of children.

• The ear and forehead infrared thermometer can be used for taking the temperature of the ear canal as well as that of the forehead. Do not use it for taking the temperature via the rectum, orally or the temperature under the arm. CHARACTERISTICS INSTANTANEOUS - Temperature in degrees Celsius taken in less than 1 second. - No need to wait. COMFORTABLE The ergonomic shape ensures comfort in use.

Version 01 dated 01/09/2010EN ECONOMICAL The function that switches the thermometer off automatically after a minute ensures a battery life of at least 5000 readings. DURABLE The infrared detection technology ensures the system has a long life. ACCURATE The frequency of the reader ensures precision of +/- 0.2°C. COMPACT The thermometer’s compact and light design make it an ideal instrument both at home and while travelling.

- The data displayed on the liquid-crystal screen is easy to understand. - The thermometer tells you the time, as well as the ambient temperature of the room. INSTRUCTIONS

Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 REPLACINg THE BATTERY

1. Using a tool, press the tab on the battery cover (figure 2).

2. Get ready a new lithium battery (3V) of the CR2032 type.

3. Using the tool, remove the battery and replace it with the new one. (figure 3).

4. Replace the battery cover.

In order to avoid all accidents or improper use, make sure you keep batteries out of the reach of children. Please recycle used batteries in the appropriate containers. In order to avoid any environmental pollution, do not simply throw the batteries away.

1. Using a tool, press the tab on the battery cover and remove the cover (figure 2).

2. Push button B (figure 4), in order to start setting the clock.

3. The hours flash. Set the hours using button A (figure 4).

4. In order to set the minutes, press button B once again and the minutes flash. Set the minutes

5. Once you have finished setting the time, press button B and replace the cover.

OPERATION OF THE THERMOMETER

The LANAFORM ear and forehead thermometer is a delicate, high-technology electronic instrument designed for taking the temperature of the body. By way of an indication, here are two tables giving the average temperature of a human being according to the place where the measurement is taken and according to age. Normal temperatures according to the method of measurement Method of measurement Temperature °C Rectum 36,6 to 38 Mouth 35,5 to 37,5 Armpit 34,7 to 37,3 Ear 35,8 to 38 Normal temperatures according to age Age Temp. °C 0 to 2 years36.4 to 38.0 3 to 10 years36.1 to 37.8 11 to 65 years35.9 to 37.6 >65 years.35.8 to 37.5 Comment:

1. The temperature of a body in good health varies according to a number of factors: age, time

of the day, physical activity, outdoor temperature,… and more particularly in the case of a forehead reading (influence of the type of skin (greasy or dry, creased or not), ambient temperature (air conditioning)…). It is therefore important to determine the normal temperature range for each member of your family, to use it as a guide to help you detect any subsequent fever.

2. In the case of children, ear temperature is close to the temperature in the rectum.

3. When you visit your doctor you need to tell him/her whether the temperature has been taken via

the ear or the forehead.

4. Also note, in comparison with a forehead reading, there is a margin of difference of

approximately 0.5°C when the temperature is taken via the ear. Important: Taking the temperature via the ear is not recommended for infants under 3 months, the shape of the ear canal not permitting a reliable reading.

HOW TO USE THE THERMOMETER

MEANINg OF THE THERMOMETER’S SYMBOLS AND SIgNALS Degrees of temperature: Celsius: Taking the ear temperature: Taking the forehead temperature: Reading the current temperature: Symbol that the last result recorded has been memorised: Low battery warning: SELECTINg THE TEMPERATURE READINg MODE: - Press the «On» button (A) in order to select one of the 2 temperature selection modes. An initial screen appears with all the symbols. - After a few seconds, a second screen appears with the symbol indicating ear or forehead temperature measurement flashing. Press the «On» button (A) once more to select the desired mode. TAKINg THE EAR TEMPERATURE:

1. Remove the sensor cover (figure 1).

2. Press the «On» button (A) and select ear temperature mode as explained above.

3. Wait until you hear two audible signals indicating that the temperature can be taken. The last

measurement taken then appears on the screen. If it is the first time the thermometer has been used after installing a battery, it will indicate a default value of 36.8°C.

4. Insert the tip of the thermometer into the ear canal and keep the «On» button (A) pressed. An

arrow appears at the top of the LCD screen indicating that the temperature is being taken.

5. Wait for the audible signal indicating that detection has finished. The temperature read is then

will give a correct measurement if the temperature detected is greater than 32°C.

7. In order to obtain a more accurate temperature reading, wait for five seconds between readings.

TAKING THE FOREHEAD TEMPERATURE:

1. When taking the forehead temperature you must not remove the cover from the sensor.

2. Press the «On» button an initial time in order to activate the thermometer and select forehead

temperature mode as explained above.

3. Wait until you hear 2 audible «beeps» indicating that the temperature can be taken. The last

measurement taken then appears on the screen.

4. Apply the tip of the thermometer to the forehead and keep the «On» button (A) pressed.

An arrow appears on the screen. Then slide the thermometer across the whole length of the forehead and release the «On» button. A new audible signal sounds indicating that detection has finished. The temperature read is then displayed on the screen. TECHNICAL CHARACTERISTICS Normal conditions of use Display resolution0.1°C Operating temperature 16 to 40°C Storage temperature -20 to 50°C Humidity rate <95% Power supply 3V DC (1 «CR2032» battery) Measuring range 32.0 to 43 °C Accuracy ± 0.3°C (32.0-35.9°C) ± 0.2°C (36.0-39.0°C) ± 0.3°C (39.1-42.5°C)

MAINTENANCE AND CLEANING

- When you need to take a new reading and in order to ensure accuracy and hygiene, always clean the tip of the sensor with a cotton bud moistened with alcohol (figure 5).

Version 01 dated 01/09/2010EN - Use a soft dry cloth to clean the body of the thermometer. Never use an abrasive material and never submerge the thermometer in water or other liquids. - Never expose the thermometer to extreme temperatures, damp, direct sunlight or impact. - Do not touch the lens with your fingers. - Do not dismantle the thermometer. SOLVINg PROBLEMS

1. The screen constantly displays the too low temperature indicator:

• Make sure the end of the sensor is clean.

• You have not inserted the sensor into the ear correctly. The sensor lens must be adjusted against the opening of the ear canal.

2. The screen constantly displays the too high temperature indicator:

• Make sure that the sensor lens is not damaged. If it has been, contact the outlet from which you purchased the thermometer.

3. The temperature shown is outside the thermometer’s detection limit:

• Take the temperature again.

• All the packaging is composed of materials that pose no hazard for the environment and which can be disposed of at your local sorting centre to be used as secondary raw materials. The cardboard may be disposed of in a paper recycling bin. The packaging film must be taken to your local sorting and recycling centre.

• When you have finished using the device, please dispose of it in an environmentally friendly way and in accordance with the law. Prior to disposal, please remove the battery and dispose of it at a collection point so that it can be recycled. Please note: under no circumstances should spent batteries be disposed of with household waste!!! LIMITED WARRANTY LANAFORM® guarantees this product against any material or manufacturing defect for a period of two years from the date of purchase, except in the circumstances described below. The LANAFORM® guarantee does not cover damage caused as a result of normal wear to this product. In addition, the guarantee covering this LANAFORM® product does not cover damage caused by abusive or inappropriate or incorrect use, accidents, the use of unauthorized accessories,

Version 01 dated 01/09/2010EN changes made to the product or any other circumstance, of whatever sort, that is outside LANAFORM®’s control. LANAFORM® may not be held liable for any type of circumstantial, indirect or specific damage. All implicit guarantees relating to the suitability of the product are limited to a period of two years from the initial date of purchase as long as a copy of the proof of purchase can be supplied. On receipt, LANAFORM® will repair or replace your appliance at its discretion and will return it to you. The guarantee is only valid through LANAFORM®’s Service Centre®. Any attempt to maintain this product by a person other than LANAFORM®’s Service Centre will render this guarantee void.

DECLARATION OF EC 0029 CONFORMITY

Medical Device Class IIa. We, LANAFORM, Declare that the «4 in 1 thermometer» medical device complies with European Directive 93/42/EC concerning medical devices and its latest amendment 2007/47/EC. APRAGAZ 156 chaussée de Vilvoorde 1120 Brussels (Belgium), notified organization No. 0029, has verified the product (according to Appendix IV).

Figure 1 Figure 2 Figure 3 Figure 4 Figure 5
