USER MANUAL skimmarine 600 EHEIM

for purchasing your new skimmarine600 sea water skimmer.

The innovative EHEIM SKIMmarine600 skimmer in combination with the EHEIM compactON marine2500 skimmer pump offers ideal performance coupled with the highest standards of reliability and the greatest possible effectiveness. The EHEIM skimmarine600 protein skimmer quickly and reliably rids your sea water aquarium from organic and inorganic protein compounds. The protein compounds, which originate from feed residues, dead microorganisms and excretions from fish and invertebrates, form deposits on the air bubbles, created by the EHEIM compactON marine2500 skimmer pump, by means of static attraction and / or adsorption and are removed from the aquarium water together with dirt particles, dead cells of bacteria, algae, etc. as dirt foam (suspended material). This prevents bacteria degrading the protein compounds in the aquarium and hence polluting the aquarium water with contaminants.

Translation of the original operating manual compactON marine2500

General user instructions

Information on using the operating manual

Before using the appliance for the first time, the operating manual must be read fully and understood.
- Consider the operating manual as part of the product and keep in a safe and accessible location.
Enclose this operating manual if passing the appliance on to a third party.

Symbol explanation

The following symbols are used on the appliance.

The appliance must only be used indoors, and exclusively for aquariums.

The device has an immersion depth of max. 1.0m

The pump is of protection class II.

IP68The symbol indicates that the appliance is protected against permanent submerging.

The product has been approved of in accordance with the relevant nationals regulations and directives and complies with the EU standards.

The following symbols and signal words are used in this operating manual.

DANGER!

The symbol indicates imminent danger from electric shock that can result in death or serious injury.

DANGER!

The symbol indicates imminent danger that can result in death or serious injury.

WARNING!

The symbol indicates imminent danger that can result in moderate to minor injury or a health risk.

CAUTION!

The symbol indicates the danger of material damage.

Note with useful information and tips.

Typographical conventions:

AReference to a figure; in this case, reference to figure A.

You are prompted for an action.

Application

The appliance and all parts included in the scope of delivery are intended for private use and must only be used:

• for the removal of metabolic products in saltwater aquariums up to approx. 600 l
• indoors
• in compliance with the technical data

The following limitations apply to the appliance:

• do not use for commercial or industrial purposes
• the water temperature may not exceed 35^

VERY IMPORTANT SAFETY INSTRUCTIONS

WARNING- To guard against injury, basic safety precautions should be observed, including the following.

FOR HOUSEHOLD USE ONLY · WARNING! RISK OF ELECTRIC SHOCK!
- This pump has not been investigated for use in swimming pools areas!
DO NOT RUN DRY!

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

DANGER. To avoid possible electric shock, special care should be taken since water is employed in the use of a aquarium equipment. For each of the following situations, do not attempt repairs by yourself; return the appliance to an authorized service facility for service or discard the appliance.
- If the appliance shows any sign of abnormal water leakage, immediately unplug it from the power source.
- Carefully examine the appliance after installation. It should not be plugged in if there is water on parts not intended to be wet.
- Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning or if it is dropped or damaged in any manner.

• Always unplug an appliance from an outlet when taking off parts, and before cleaning. Never yank cord to pull plug from outlet. Grasp the plug and pull to disconnect.
• Do not use an appliance for other than intend not recommended or sold by the appliance manufacturer may cause an unsafe condition.
• Do not install or store the appliance where it to temperatures below freezing.
• Make sure an appliance mounted on a tank is ting it.
  • Read and observe all the important notices on
• If an extension cord is necessary, a cord with A cord rated for less amperes or watts than the appliance rating may overheat. Care should be taken to arrange the cord so that it will not be tripped over or pulled.
• Check that the voltage shown on the label of the ge of the mains supply.
• Disconnect all electrical appliances from the water.
• The line cord of this unit cannot be replaced become damaged the appliance must be discarded.

KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Safety instructions

Risks for persons and property can arise from this appliance if the appliance is improperly used or not used as intended or if the safety instructions are not heeded.

For your safety

• This appliance can be used by children from the age of 8 and by persons with reduced physical, sensory or mental capabilities or lack of experience and/or knowledge if they are supervised and have been instructed in the safe use of the appliance and have understood the resulting dangers. Children must not play with the appliance. Cleaning and user maintenance must not be carried out by children unless they are supervised.
• Before use, carry out a visual inspection to ensure that the appliance, especially the mains cable and plug, are undamaged.
• Repairs must only be carried out by an EHEIM service centre.
• Do not carry the appliance by the mains cable, and to disconnect from the mains, always pull on the plug and not on the cable or appliance.
• Only carry out the work described in these instructions.
• Only use original spare parts and accessories for the appliance.
• To protect against contact voltage being too high, the fixture must have a residual current device with a rated release fault current not exceeding 30mA . Ask your electrician.
• In the event of water leakage or when the residual current protection device is triggered, immediately disconnect all devices in the aquarium from the power supply.
• If they are not being used, always disconnect all devices in the aquarium from the power supply before you install/remove any parts and before all cleaning and maintenance work.
• Protect the mains socket and mains plug against moisture. It is recommended to form a drip loop with the mains cable to prevent any water running along the cable to the mains socket.

• The electrical data of the pump must match the data of the power mains. This data is found on the type plate, the packaging and in these instructions.

Pinwheel Pump EHEIMcompactON marine2500

Design: see nameplate of the motor body

A Function

skimmarine600 Protein Skimmer

① Foam cup lid ② Foam cup ③ Bayonet fitting ④ Sealing ring ⑤ Skimmer housing
⑥ 4x fixing screws ⑦ Knurled screw ⑧ Reaction chamber lid ⑨ Reaction chamber
⑩ Precision control valve ⑪ Small gear wheel with screw ⑫ Screw for the large gear wheel ⑬ Water level regulation plate ⑭ Distance sleeve ⑮ Large gear wheel ⑯ Nut
⑦ Phillips screws ⑧ Skimmer plate ⑨ Base plate ⑩ Pump holder ② Connecting piece
② Diffusor nozzle ③ Air hose ④ Plastic screw M6 x 20 mm ⑤ Plastic screw M4 x 8 mm
② 6 Silencer base plate ⑦ Silencer ⑧ Air metering screw ⑨ Suspended material connection sockets.

Pinwheel Pump compactON marine2500

1 Pump motor body 2 Pressure side connection 3 Pinwheel 4 Ceramic axle 5 Axle bushes 6 Pump cover with locking ring.

B Assembly

(a) Loosen the four knurled screws ⑥ and lift off the skimmer housing ⑤.
(b)Loosen the Phillips screws ⑰ of the pump holder ②
Insert the skimmer pump, fit the pump holder on the left and right in the side groove of the pump and secure it to the base plate using the Phillips screws.
d Place the reaction chamber 19 on the pump discharge and secure it to the pump connection with the connecting piece 2. Then secure the reaction chamber lid 8 using the knurled screw 7.
Before the assembly of the reaction chamber observe the following: It is imperative that the lid of the reaction chamber is fitted in such a way that the section of the reaction chamber cover that has no apertures is located directly over the pump outlet.

Fit the skimmer housing to the skimmer plate again and tighten the four securing screws.
Fit the silencer using the plastic screw on the edge of the housing and connect it to the diffusor nozzle via the air hose.
h With slight pressure, insert the diffusor nozzle into the pump inlet of the skimmer pump.
① Guide the precision control valve ⑩ through the eyelet on the skimmer housing. Fit the small gear wheel with screw ⑪ meshing with the large gear wheel ⑮ under the skimmer plate ⑱ of the skimmer. Fit the sealing ring ④ to the bottom of the foam cup ②. Fit the foam cup and secure it by turning the bayonet fixing ③ anticlockwise.

TIP: The foam cup has a connecting piece for a suspended material drain.

C Positioning of the Skimmer

Place the skimmer in the filter tank.

In order to ensure optimum operation, the water level in the filter tank should be 180 to 240~mm . Given that changes in the water level directly affect skimming, the use of an automatic level control, EHEIM water refill Type 3548, is recommended.

Tip: Changes in the water level directly affect the operation of the protein skimmer. Therefore, we recommend the use of the EHEIM water refill Type 3548 automatic level control.

D Setting the skimmer

④First, fully open the precision control valve and then stat the pump. Slowly close the precision control valve until the water in the skimmer levels out between the bayonet fixing and the foam cup. Half open the air intake valve (turn the air metering screw ②8 anticlockwise 1 - 2 mm upwards) and leave it in this position for 1-2 days (start-up phase).

Once foam begins to form after the start-up phase, the fine adjustment for the optimum skimming can be made by adjusting the air supply valve and the precision control valve.

For dry skimming, turn the precision control valve clockwise and open the water outlet. For moist skimming, turn the precision control valve anticlockwise and close the water outlet. The EHEIM skimmarine600 can be operated with ozone up to a maximum of 50mg/hour using a suitable silicon hose.

Tip: Ozone volumes of 5-10mg/hour per 100 litres of seawater. Fit the T-piece to the air intake on the pump. Connect one end of the T-piece to the silencer, the other end to the ozone device. The ozone extraction is significantly improved by reducing the air intake (closing the air intake valve).

E Care Instructions

Remove calcification on components of the skimmer caused by coralline red algae and such like by submerging the parts in question in a 10% citric acid solution. Then rinse thoroughly with water. On no accounts use washing up liquid or other detergents to clean the skimmer or its components; only use tap water.

None of the parts of the protein skimmer are suitable for dishwashers.

Decommissioning

Storage

1. Take the appliance out of the aquarium.
2. Clean the appliance
3. Store the appliance in a frost-proof place.

Disposal

When disposing of the appliance, heed the respective statutory regulations. Information on the disposal of electrical and electronic appliances in the European Union: Within the European Union, disposal of electrically operated appliances is governed by national regulations that are based on the EU Directive 2012/19/EU on waste electrical and electronic equipment (WEEE). The appliance may no longer be disposed of with the municipal or household waste. The appliance will be accepted free of charge at municipal collection points or recycling centres. The product packaging is made up of recyclable materials. Dispose of them in an environmentally responsible manner and take them for recycling.

Technical Data

EHEIMskimmarine600 220-240 V / 50 Hz
Type 3552
Type 200 - 600 I	44 - 132 Imp. Gal. 53 - 158 US Gal.
Air intake 300 - 540 l/h
Body Ø 16 cm
Floor space mm 190 x 160
Water level mm 180 - 240
Dimensions I x w x h cm 19 x 19 x 52,5
