USER MANUAL Bolero DressCode Top 750 Inverter CECOTEC

White washing machine with control panel and digital display (no visible text or symbols)

EN · The coding in this manual is generic and applies to all code variants of the appliance.

Read the following instructions carefully before using the product and follow the safety instructions to minimise the risk of fire or explosion, electric shock and to avoid property damage, personal injury or death. Keep this instruction manual for future reference or new users. Non-compliance with these instructions will void any guarantee. It is your responsibility to make sure every user is informed about the warnings and precautions stated in this instruction manual.

• WARNING: This symbol and word indicate a potentially hazardous situation that may cause serious injuries or death.
• Warning: This pictogram combination indicates a potentially hazardous situation that may result in minor injuries or property and environmental damage.
• Fire: This pictogram combination indicates a potentially hazardous situation that may result in a fire hazard due to flammable materials.
• Important/Note: This pictogram combination indicates a potentially hazardous situation that may result in slight or minor injuries.

Warning: risk of electric shock

• If the cable is damaged, it must be replaced by the manufacturer, the supplier, or qualified personnel to avoid hazards.
• If the appliance is damaged, it can only be handled by the manufacturer, technical service or qualified personnel. Risk of electric shock
• This appliance can be used by children aged 8 and above and people with reduced physical, sensory, or mental

ENGLISHENGLISH

capabilities or lack of experience and knowledge, as long as they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Do not allow children to play with the appliance. Cleaning and maintenance should not be carried out by children without supervision.

• Keep children under 3 years old away from the appliance or under continuous supervision.
• Animals and children could climb on the machine. Check it before every washing.
• Do not climb or sit on the device.

Installation location and surrounding

• Do not install the washing machine on a surface in which the base cannot air properly, like a carpet. Blockage of the openings can damage the machine.
• Keep the appliance away from heat sources and direct sunlight to prevent the plastic and rubber parts from getting damaged.
• Do not use the appliance on wet areas or rooms containing explosive or corrosive gases. In case of water leakage or splashes, let the appliance dry on its own.
• Do not install the device in dusty areas. Do not install or store outdoors or in any environment exposed to direct sunlight, wind, rain or freezing temperatures.
• Do not use the machine in rooms with a temperature below 5 °C. This can damage its parts. If needed, make sure to completely drain the water in the appliance after every use (check the "Maintenance - Drain pump filter cleaning" section) to prevent frost damage.
• The appliance must not be installed behind a lockable door, a sliding door, or a door with a hinge on the opposite side to

that of the washing machine.

- ⚠️ Never use sprays or flammable substances near the appliance.

Installation

• Remove the transport bolts before using the appliance. Otherwise, it could cause serious damage.
• Packaging material may be dangerous to children. Remove it and place it out of their reach.
• Check the appliance and its packaging for damage. Never use the appliance if it is damaged, contact Cecotec's Technical Support Service immediately.
• IMPORTANT: Do not connect the washing machine to a hot water supply.
• The plug must be accessible after the installation.
• The washing machine must be levelled before operation.
• Do not place heavy objects on the appliance, such as water containers or other devices.
• You must use the new hose set provided with the appliance, do not reuse old hoses.
• The maximum inlet water pressure is 1 MPa. The minimum inlet water pressure is 0.1 MPa.

Electrical connections

• Make sure that the mains voltage matches the voltage stated on the rating label of the appliance and that the wall outlet is grounded. If you are in doubt as to whether the equipment is properly grounded, consult a qualified electrician.
• Do not modify the plug provided with the appliance if it does not match the power socket.
• The washer must be grounded in accordance with local Standards and Regulations. If an electric shock occurs,

ENGLISHENGLISH

grounding can provide a path of minimum current resistance, thus reducing the risk of electric shock.

• Check the power cord regularly for visible damage. If the cable is damaged, it must be replaced by the official Technical Support Service of Cecotec in order to avoid any type of danger.
• Do not use the product if the cable, plug or structure is damaged or not working properly.
• In case of anomalies (abnormal noises, burning smell, smoke, etc.), immediately disconnect the power plug to stop the machine and contact the Cecotec Customer Service.
• Make sure the power cord is not trapped under the machine, as it could be damaged.
• The installation of an earthed socket must be carried out by a qualified electrician.
• Make sure the machine is installed according to local regulations.
• It is recommend for water and electrical appliances to be connected by qualified personnel in accordance with the manufacturer instructions and local safety regulations.

Do not use an extension cord or multiple sockets.

• This appliance must not be controlled by external switching devices such as timers, or connected to electrical circuits that are continuously switched on and off.
• Do not disconnect the plug from the socket if there is flammable gas near them.
• Pull from the plug, not the cable, to unplug it. Do not touch the cable or appliance with wet hands.

Water connection

- Check the water supply hose, the tap and the drain hose to

detect any possible problem due to water pressure changes. If the connections are loose or leaking, close the tap and seek technical assistance. Do not use the appliance before the hoses are installed by qualified personnel.

• The door may reach high temperatures during operation. Keep children and pets away from the machine while in use.
• The water inlet and outlet hoses must be installed securely and undamaged. Otherwise, there may be water leakage.
• Do not remove the drain pump filter while there is water in the appliance. Large quantities of water may be released, which may cause a risk of burns due to the hot water.

Operation and maintenance

- Never use flammable, explosive or toxic solvents. Petrol, alcohol, etc. should not be used as detergents. Use only detergents for washing machines.

• Make sure that all pockets are empty. Sharp and rigid items such as coins, brooches, nails, screws or stones may cause serious damage to this appliance.
• Thoroughly rinse items that have been washed by hand.
• Some detergents are highly alkaline. They may be extremely dangerous if you ingest them. Avoid contact with the skin and eyes. In case of contact with eyes, rinse immediately with clean water.
• Items with stains from substances such as oils, acetone, alcohol, petroleum, paraffin, stain removers, turpentine, wax and wax cleaners should be washed hot with an extra amount of detergent before drying with the appliance.
• Never try to force the door open. The door will unlock shortly after the end of a cycle.
• Keep children away from the washing machine when the

ENGLISHENGLISH

door is open.

• Do not close the door with excessive force. If it is found difficult to close the door, please check if the clothes are put in or distributed well.
• Always unplug the appliance from the mains and close the water tap before carrying out any cleaning or maintenance tasks and after every use.
• Do not pour water on the appliance to clean it. Risk of electric shock
• Repairs must only be carried out by Cecotec, its authorised Technical Service, or similarly qualified personnel to avoid potential risks. Cecotec shall not be liable for damage caused by unauthorised persons.

Transport

• Before transporting the product, you must place the transport bolts again in the machine and drain the water out of the machine.
• The washing machine is very heavy. Transport it with care. Do not hold the appliance by its protruding parts to lift it. Do not use the machine door as a handle.
• Before disposing of the old washer, unplug it. Cut the power cord directly behind the appliance to prevent misuse.

Recommended use

- The product is exclusive for household use and moderate loads, and is designed for machine washable laundry only. Install the machine in the interior of a well-ventilated room. This product is not designed for installation as a built-in

appliance.

• Do not install the washing machine on humid areas.
• Any other use shall be considered improper use
• resulting from failure to follow the installation and/or operation instructions contained in this instruction manual.
• Cecotec shall not be held liable for any damage, accident, or incident resulting from the misuse of this appliance. It is the responsibility of the user to operate and maintain the appliance according to the instructions and recommendations detailed in this manual. Failure to follow instructions may result in personal injury, property damage, or loss of product warranty.

FRANÇAISFRANÇAIS

INSTRUCTIONS DE SÉCURITÉ

1. Power cord
2. Control panel
3. Drain hose
4. Door
5. Detergent/softener drawer
6. Drum
7. Drain pump filter

Accessories\*

Fig. 2

1. Plastic cups for the transport bolt holes
2. Cold water supply hose
3. Instruction manual
4. Acoustic foam

^a NOTE: Accessories may vary depending on the washing machine model.

NOTE:

• The graphics in this manual are schematic representations and may not exactly match the product.
• To improve quality, our products are constantly updated and their appearance and specifications may change.
• Each appliance has undergone a thorough quality control before leaving the factory to ensure its reliability. You may find water droplets generated by our quality control in your new washing machine. This will not affect its performance.

2. BEFORE USE

This appliance includes a safety package to protect it during transport. Remove the washing machine from its box, and store the original box and other packaging in a safe place. It will help prevent any damage if the appliance needs to be transported in the future. If you wish to dispose of the original packaging, make sure all items are recycled properly.
- Make sure all parts and components are included and in good conditions. If any of them are missing or damaged, please contact Cecotec's Official Technical Support Service immediately.

Box content\*

• Top loading washing machine
• Drain hose
• Water supply hose
• Plastic cups for the transport bolt holes
• Acoustic foam
• Instruction manual

^a NOTE: The contents of the box may vary depending on the model of washing machine.

3. INSTALLATION

Installation area

Fig. 3

Leave a space of at least 20 mm between the washer and the wall.

Previous steps

• Place the washing machine on a stable, flat, and dry surface. Make sure the product does not stand on the power cord.
• Avoid direct sunlight and ensure sufficient ventilation.
• The room temperature must be above 0°C (not less than 5°C is recommended).
• Choose a location away from heat sources, like gas or coal.
• Remove the cardboard box and every packaging protecting the washing machine. Make sure to remove the small foam at the bottom. If you are unable to do so, place the washing machine on its side and remove it manually.
• Remove the tape securing the power supply cord and drain hose.
• Remove the water inlet hose, Instruction manual and all accessories that may be inside the drum.

Packaging materials can be dangerous for children due to risk of suffocation. Keep them away from children.

Step 1. Acoustic sponge\*

Fig. 4

Note:

Make sure to install the acoustic foam before using the washing machine for the first time. The foam is designed to effectively reduce noise during washing, which will help provide you with a quieter and more peaceful living environment.

1. Place the washing machine on the floor, using soft material such as foam, blankets or towels

ENGLISHENGLISH

between the machine and floor to ensure protection.

1. Attach the longer foam to the longer bottom edges of the washing machine and the shorter foam to the shorter bottom edges.

*Available depending on washing machine model

Step 2. Removing the transport bolts

Warning:

• All 4 transport bolts on the back of the washing machine must be removed before using the appliance. The warranty does not cover faults that occur due to operating the washing machine without removing the transport bolts.
• If you do not remove the bolts there may be strong vibrations, noise and defective operation.
• Keep the transport bolts for future transport.

Fig. 5-6

1. Loosen the transit bolts by turning them anticlockwise with a suitable spanner.
2. Remove the transport bolts by pulling them
3. Insert the plastic caps provided in the holes where the transport bolts were located.

Step 3. Levelling the washing machine

Warning: The lock nuts on all four feet must be screwed tightly against the housing.

Fig. 7

1. Loosen the locking nut on the foot.
2. Turn the foot until it touches the ground.
3. Adjust the feet height and tighten the locking nuts with a spanner. Make sure that the washing machine is level and does not move.

Step 4. Water supply hose connection

Warning: Do not twist, crush or modify the water supply hose.

Connect the water supply hose to the water inlet valve (Fig. 8) and to a cold water tap (Fig. 9) as shown in the figures.

Note: Do not use tools for connection, do it manually. Check the connection is firm.

Step 5. Drain hose connection

Warning:

• Do not kink or protract the drain hose.
• Place the drain hose correctly; otherwise, there could be leaks.

You can connect the end of the drain hose in 2 ways:

1. To a drain. Fig. 10
2. In a drain pipe located in a sink. The pipe height must be between 60 and 100 cm. Fig. 11

Note: If the machine is equipped with a drain hose bracket, install it as shown in figure 12.

Fig. 12 key:

• When installing the drain hose, fix it properly.
• If drain hose is too long, do not force it into washing machine as it will cause abnormal noises.

4. OPERATION

Quick Start

Warning:

• Before using the washing machine for the first time, make sure it is correctly installed.
• Your device was thoroughly checked before leaving the factory. To remove any water residue and to neutralise possible odours, it is recommended to clean the appliance before using it for the first time. To do this, start the "Drum Clean" program without laundry and detergent/softener.

Before washing

Fig. 13

1. Plug in the washing machine.
2. Open the tap.
3. Load the washer with laundry.
4. Add detergent/fabric softener.
5. Close the drum door.
6. Close the washing machine door.

ENGLISHENGLISH

Please note

• Make sure the drum flaps are correctly locked. Fig. 14
• All metal hooks must be securely hooked inside the flap of the rear door. Fig. 15
• Check the drum before each wash, it should roll smoothly.
• If the washing machine has a 'Pre-wash' function, detergent must be added in tank I of the drawer.

Washing

1. Turn on the washing machine.
2. Select a programme.
3. Select an additional function or do not modify the default settings.
4. Press the Start/Pause button to start the programme.

Note: If any of the default options is selected, step 3 can be skipped.

After washing

All the lights on the control panel will turn off.

Before each washing

• The washing machine must be used in a place where the temperature is between 5 °C and 40 °C. If used under 0 °C, the inlet valve and draining system may get damaged. If the machine is installed at low temperatures, it should be moved to a normal room temperature to ensure that the water supply hose and drain hose can be defrosted before use.
• Check the care labels and detergent instructions before washing. Use non-foaming or less-foaming detergent suitable for machine washing.

Fig. 16

1. Check the care label
2. Sort laundry by colour and type of fabric.
3. Remove all the objects from the pockets.
4. Knot long textile straps and belts, and fasten zips and buttons.
5. Put small textiles in a laundry bag
6. Turn over garments that are easily shredded and have long hair.

Warning:

• Do not wash items that have been cleaned, soaked or dampened with combustible or explosive substances such as wax, oil, paint, petrol, alcohol, paraffin and other flammable materials.
• Washing too few items can easily create a large eccentricity and cause an imbalance

alarm. Therefore, it is recommended that you add more items to the laundry so that the spin cycle runs smoothly.

- Do not wash or spin-dry waterproof garments.

Detergent drawer

Fig. 17

1. Pre-wash detergent compartment
2. Softener compartment
3. Main detergent compartment.

Note: Do not exceed the MAX mark when pouring detergents, softener or other additives.

Programme Pre-wash detergent Main wash detergent Fabric softerer
Cotton Optional Necessary Optional
Synthetics Optional Necessary Optional
Mix Optional Necessary Optional
Jeans Optional Necessary Optional
Sportswear Optional Necessary Optional
Drum Clean	-	-	-
20 °C	-	Necessary Optional
Steam	Optional Necessary Optional
Spin Only	-	-	-
Rinse&Spin	-	- Optional
Wool	-	Necessary Optional
Baby Care	Optional Necessary Optional
Quick 15' (Quick)	-	Necessary Optional
ECO 40-50	-	Necessary Optional
Rapid 45' (Rapid)	-	Necessary Optional

ENGLISHENGLISH

Detergent recommendations

Recommended detergent	Wash cycles	Washing temperature	Type of garment and textile
Strong detergent with bleaching agent and optical brighteners	Cotton, Mix	20/40/60	White cotton or boil-resistant linen clothes
Colour detergent without bleaching agent nor optical brighteners	Cotton, Mix	Cold/20/40	Coloured laundry made of cotton or linen
Colour or mild detergent without optical brighteners	Synthetics	Cold/20/40	Colour clothes made from easy-care fibers or synthetic materials
Mild washing detergent	Synthetics	20/40	Delicate fabrics, silk, viscose
Special wool detergent	Wool	20/40	Wool

Note:

• You can dilute concentrated detergents or additives in a little water before pouring them into the detergent drawer, to avoid clogging the detergent drawer inlet and causing water overflow.
• Choose the adequate detergent to get the maximum washing performance and the minimum water and energy consumption.
• To obtain the best washing results it is important to use a correct detergent dose.
• Use a reduced amount of detergent if the drum is not fully loaded.
• Always adjust the detergent amount to the water hardness, if tap water is soft, use less detergent.
• Dose according to the soiling level of the laundry. The less soiled laundry requires less detergent.
• The highly concentrated compact detergent requires particularly precise dosing.

The following anomalies occur due to the use of a high detergent dose:

• Abundant foaming.
• Poor washing and rinsing results.

The following anomalies occur due to the use of a low detergent dose:
- Laundry turns grey.
- Build-up of limescale deposits on the drum, heating element and/or laundry.

5. CONTROL PANEL

Fig. 1B

1. Power (ON/OFF). It turns on or off the washing machine.
2. Start/Pause. Press the button to start or pause the washing cycle.
3. Additional functions. This button allows you to select an additional function which will light up when selected.
4. Programmes. It is used to select a programme according to the type of laundry and its soiling.
5. Display. The display shows the settings, estimated time remaining, options, and status messages of the washing machine. The display will remain on through the cycle.

Fig. 19

A: Display
B: Door lock
C: Delay Start
D: Pre-wash
E: Extra rinse

Programme Max. recommended load (kg) Display time
Cotton 7.5 2:40
Synthetics 3.5 2:20
Mix 7.5 1:20
Jeans 7.5 1:40
Sportswear 3.5 0:47
20 °C	3.5 1:01
Baby Care	7.5 2:01
Drum Clean -	1:18
Spin Only	7.5 0:12
Rinsc&Spin	7.5 0:20
Wool	2.0	1:07
Steam	3.5 1:47
ECO 40-60	7.5 3:33
Quick 45' (Quick)	2.0	0:45

ENGLISHENGLISH

Rapid 15' (Rapid)

2.0

0:15

Note: The values in this table are approximate and for the user's reference. In actual use, may be differences due to the environment, the characteristics of the water used, the and quantity of casting, the method of placement, etc.

Cycle	Normal capacity (kg)	Set temperature (°C)	Cycle running time (h:min)	Energy consumption (kWh/cycle)	Water consumption (l/cycle)	Maximum temperature (°C)(1)	Residual moisture/spin speed (%/rpm)(2)
Quick '15'	2.0	Cooling	0:15	0,026	33	Cooling	70%/800
20 °C	3.5	20	1:01	0.18	45	20	70%/800
Cotton	7.5	60	2:45	1,342	68	60	53%/1200
Synthetics	3.5	40	2:20	0,596	41	40	70%/800
Mix	7.5	40	1:20	0,755	68	40	70%/800
ECO 40-60(3)	7.5	--	3:33	0,701	55	35	53.9%/1200
	3.5	--	2:45	0,436	45	32	53.9%/1200
	2.0	--	2:45	0,186	35	23	53.9%/1200

The highest temperature reached by the laundry in a washing cycle for at least 5 minutes.

(a) Residual moisture after the wash cycle in percentage of water content and the spin speed at which it was reached.

The ECO 40-60 programme is able to clean normally soiled cotton laundry declared as washable at 40 °C or 60 °C, together in the same cycle. This programme is used to assess compliance with EU eco-design legislation

- The length, and energy and water consumption of each programme may vary according to the weight and type of laundry, the additional functions active, water and room temperature.

- It is recommended the use of liquid detergent for washing programmes at low temperature. You can vary the quantity of detergent according to the quantity of laundry and its soiling level. Follow the detergent manufacturer recommendations for the quantity of detergent you must use.

- The information above are just references and can change according to the different use conditions.

- The information given for the different programmes of the ECO 40-60 programme are just indicative.

- The most efficient programmes in terms of energy consumption are generally those that

are carried out at lower temperatures and longer duration

• Loading the washing machine up to the recommended capacity for the respective programmes will contribute to saving energy and water.
• Noise and residual moisture content are influenced by the spin speed: the higher the spin speed, the higher the noise and the lower the residual moisture content.
• Data according to EN 60456:2016/prA2019 with (EU)2019/2014, (EU)2019/2023.
• Energy efficiency class: A
• Half load for washing machines of 7.5 kg capacity: 3.5 kg
• Quarter load settings (for 7.5 Kg capacity washing machines): 2 kg

Warning: If there is power failure while the appliance is in operation, the washing he will continue the programme when the power supply is restored.

Programmes
Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen.
Synthetics Wash synthetic articles, for example shirts, coats, mix.While washing the knitting textiles, detergent quantity shall be reduced asthe soft fabric is more prone to bubbles.
Baby Care It ensures cleaner baby clothes, the rinse cycle is more intense so the babyskin is protected.
Quick 45' It can be used to wash a few items of laundry or clothes that are not toodirty.
Mix Mixed loads with cotton and synthetic clothes.
Sportswear For washing sports clothes.
Jeans Specialty designed for denim clothing.
Quick 15' Extra-short programme, suitable for washing lightly soiled clothes or smallloads of laundry.
Wool Hand or machine-washable wool or rich-wool textiles. Gentie washingprogramme to prevent shrinkage, with longer programme pauses (withtextiles soaking).
Spin Only	Extra spin with selectable spin speed.
Rinse&Spin	Extra rinse with spin.

ENGLISHENGLISH

Drum Clean	Programme to clean the drum and hoses. Sterilisation temperature of 90°C to make the wash more environmentally friendly. When running this programme, you should not introduce laundry or clothes in general.If you use the appropriate amount of chlorine bleach product, the cleaning will be much more effective. The user can use this programme as many times as necessary.
ECO 60-40 40	°C by default, not selectable, suitable for washing clothes at about 40°C-60 °C.
Steam This programme penetrates deep into the fibre, which effectively eliminates bacteria and worms, preventing odours and protecting health.
20 °C	For washing brightly coloured clothes, as it protects the colours better.
Cycle	Default temp. (°C)	Default spin speed in rpm	Additional functions
Cotton	40 800
Synthetics	40 800
Mix	40 800
Ieans	40	800
Sportswear	20 800
20 °C	20 800
Baby Care	60	800
Drum Clean	90 --
Spin Only -- 800
Rinse&Spin	-- 800

Wool 40 600			ⓧ ,⓸
Steam 40 800			⓹ ,⓺ , 亅
ECO 40-50 ---			⓺
Quick 45' 20 800			⓺ ,⓺
Quick 15' Cooling 800			⓺

The table shows the setting options for each cycle. Not all settings are possible for every cycle.

Note:

• To know the maximum spin speed, the programme time and other ECO 40 60 programme details, refer to the contents of the Product Sheet page.
• You can find more information on this model by scanning the QR code of the reference of your product (you will also find the energy label).

Reference	EU01_T18909
Model	Bolero DressCode Top 750 Inverter
QR code

Pre-Wash

The pre-wash function is used to perform an extra wash before the main wash, it is suitable for washing the dust on the surface of the laundry; you should pour detergent into compartment. I when you select it.

Extra Rinse

The laundry will undergo extra rinse once after you select it.

Delay start

To set the Delay Start function:

1. Select a programme. Press the Delay Start button to choose the time (delay time: 0-24 hours).

ENGLISHENGLISH

1. Press the Start/Pause button to activate the Delay Start.

To cancel the delay start function:

Press the Delay Start button until the display shows OH. You must do it before starting the programme. If the programme has already started, switch off programme to reset a new one.

Temperature (Temp)

Press this button to select the desired temperature (Cold, 20 °C, 40 °C, 60 °C, 90 °C).

Speed (Spin)

Press this button to change the spin speed: 0, 600, 800, 1000 and 1300 rpm.

Child Lock

It is used to prevent children from operating the device.

1. Select a programme.
2. Press the Start/Pause button.
3. Press and hold the Spin and Delay buttons for 2 seconds until you hear a beep.

Warning:

• When the child lock function is activated, the appliance will beep when the buttons are pressed
• Hold down both buttons for 3 seconds to deactivate the child lock.
• The child lock disables all the buttons except for the power button.
• If the power supply is cut off, the child lock will be deactivated.

Mute

1. Choose a programme.
2. To mute the washing machine, press and hold the Spin button for 3 seconds.
   To activate the sound, press and hold the Spin button again for 3 seconds.

Warning:

• The setting will stay activated until you restart the device.
• If you mute the washing machine, sounds will be deactivated.

Favourite programme function (Favourites/My Cycle)

• This function is used to save a frequently used programme.
• After selecting a programme and adjusting the desired additional options, press and hold the Temperature (Temp) button for 3 seconds before starting the wash. By default, this setting is the Cotton programme.

Note:

• Usage counter: Disconnect the appliance for 10 seconds and reconnect it.
• Switch on the appliance and within 10 seconds, press the Temperature (Temp) and Function buttons simultaneously for approximately 5 seconds until the display shows digits indicating the appliance's usage time.
• Repeat step 1 to resume normal operation.

6. CLEANING AND MAINTENANCE

Warning: Before starting any maintenance task, unplug the washing machine and close up.

Cleaning the exterior

• Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted neutral (non-abrasive) detergent if necessary. If there is any water overflow, use a cloth to wipe it off immediately.
• Do not use sharp objects.

Note: Formic acid and its solvents or any equivalent material such as alcohol, solvents.

chemicals, etc. should not be used to clean the exterior of the product.

Drum cleaning

• The rusts left inside the drum by the metal articles shall be removed immediately with chlorine-free detergents.
• Do not use steel wool pads.

Note: Do not put laundry in the washing machine during the drum cleaning.

Cleaning the inlet filter

Note: Decreasing water flow is a signal to clean the filter.

Fig. 20

1. Remove the water supply hose from the tap.
2. Clean the filter in the hose with a brush.
3. Loosen the water supply hose from the rear part of the washing machine. Remove the filter with a long nose pliers.
4. Use a brush to clean the filter.
5. Install the filter again in the water supply and connect the water supply hose again.
6. Clean the inlet filter at least every 3 months to ensure normal operation of the appliance.

ENGLISHENGLISH

Cleaning the detergent drawer

Fig. 21

1. Press the softener cover in the direction of the arrow as shown in figure 21.
2. Lift the tab, remove the softener compartment cover and wash all the slots with water.
3. Place the softener cover again and gently push the drawer into position.

Note:

• Do not use abrasive or corrosive detergents to clean the detergent drawer.
• Clean the detergent drawer every 3 months to guarantee the normal operation of the device.

Cleaning the drain pump filter

Warning:

• Make sure the appliance has finished the washing cycle and is empty. Switch it off and unplug it from the mains supply before cleaning the drain pump filter.
• Be careful with hot water as when cleaning the drain pump filter it is common for water to be released. Wait for the water to cool down before cleaning this filter. Risk of burns
• You can use a container to collect the residual water from the filter
• Clean the filter regularly every 3 months to ensure normal operation of the washing machine.

Fig. 22

1. Remove the cover in the lower part of the washing machine.
2. Remove the filter by turning it counterclockwise.
3. Remove any strange object.
4. Refit the cover.

7. TROUBLESHOOTING

- Follow the indications on this table to try and solve the problem on your own before contacting Cecotec's Technical Support Service.

Problem description	Possible causes	Possible solutions
The washing machine does not start	The door is not closed properly	Restart after the door is closedCheck if there are clothes stuck

You cannot open the door	The protection system of the washing machine is active	Unplug and restart the washing machine
Water leakage Poor	connection between the inlet pipe and the drain hose	Check the hoses and connect them properlyClean up outlet hose
Detergent residues in the drawer	Detergent is dampened or agglomerated	Clean and wipe the detergent drawer
Indicator or display does not light	The printed circuit board is disconnected or there is a connection problem in the wiring	Check if the power is shut down and the power plug is connected correctly
Abnormal noise Check you have removed the		transport boltsCheck it is installed in a level and solid surfaceCheck the washing machine is level

Note:

• Do not attempt to carry out these instructions if you do not have the necessary skills and knowledge, as any damage caused by an improper repair will void the warranty.
• If none of these situations match your problem, do not attempt to disassemble or repair the device yourself. Repairs carried out by unqualified people may result in injury or serious malfunctions. Contact Cecotec's Official Technical Support Service. Repairs must be carried out by an authorised technician using only original spare parts.
• Self maintenance or unauthorised maintenance will affect product use safety and warranty policy application.

WARNING:

Any electrical repair of this appliance must comply with local and/or state Laws. Please contact the official Cecotec Technical Support Service in case of doubt and before carrying out any of the above operations. Always disconnect the appliance from the power supply.

Display warnings

Error on the display	Cause Solution
E30 The door is not closed properly		Restart after the door is closed
		Check if there are clothes stuck

ENGLISHENGLISH

E10 Water injecting problem while washing	Check if the water pressure is too low
	Check the water supply hose is not twisted, rolled or crushed
	Check if the inlet valve filter is blocked
E21 Overtime water draining Check if the drain hose is blocked
E12 Water overflow Restart the washing machine
EXX Additional notes Try again and contact Cecotec's	Technical Support Service if the warning does not disappear

Note: After performing the necessary checks, restart the washing machine. If the problem persists or the display shows another error code, switch off the washing machine and contact Cecotec's Official Technical Support Service.

Transport

Important steps you must follow to transport the device:

• Unplug the device and close the water inlet tap.
• Check if the door and the detergent drawer are properly closed.
• Remove the water supply hose and drain hose from your home installation.
• Let the water drain completely out of the appliance (check the 'Drain pump filter cleaning' section).

Important:

• Place the 4 transport bolts again in the rear part of the washing machine.
• The washing machine is very heavy. Transport it with care. Do not hold the appliance by its protruding parts to lift it. Do not use the washing machine door as a handle.

8. RECYCLING OF ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol indicates that, according to the applicable regulations, the product and/or battery must be disposed of separately from household waste. When this product reaches the end of its useful life, you should remove the batteries/accumulators and take them to a collection point designated by local authorities.

For detailed information on how to properly dispose of electrical and electronic equipment

and/or the corresponding batteries, consumers should contact their local authorities. Compliance with the above guidelines will help protecting the environment.

9. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The content of this publication may not either in part or in its entirety, be reproduced, stored in a retrieval system, transmitted or distributed by any means (electronic, mechanical, photocopying, recording or similar) without prior authorisation from CECOTEC INNOVACIONES, S.L.

10. SIMPLIFIED DECLARATION OF CONFORMITY

Cecotec Innovaciones hereby declares that this appliance complies with the essential requirements and other relevant provisions of the regulations applicable in the European Union. This appliance has been designed, manufactured and tested in compliance with required safety and quality standards. The full text of the EU Declaration of Conformity can be found on

the following website: https://cecotec.es/es/information/declaration-of-conformity

FRANÇAISFRANÇAIS

1. PIÈCES ET COMPOSANTS

Img. 1

Fonction programme favorl (Favourites/My Cycle)

Função programa favorito (Favourites/My Cycle)

7. PROBLEEMOPLOSSING

information/declaration-of-conformity

1. MEPH KAI E3APTHMATA

Σχήμα 1

Four-panel image showing icons: three apples, a magnifying glass, an open book, and vertical bars (no text or symbols)

2134
Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/U2

W≥20mm w w

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/Uşkın3

Diagram showing a device with 2x speed indicators and an open panel, illustrating a mechanical or electrical process.

Fig./img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/U44U4

Diagram showing a hand holding a tool interacting with a device, with arrows indicating motion or sequence.

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/Şkışın

Three-step diagram showing a mechanical component with blue arrows indicating direction, no text or symbols present.

Fig./img./Abb./Afb./Rys./Obr./Sekil/Eik./ábra/u###/6

Close-up of a mechanical component with a blue circular arrow indicating rotation (no text or symbols)

Fig./Img./Abb./Afb./Rys./Obr./Sekil/Eik./ábra/Uksh/7

Close-up of a white object with blue arrows indicating direction, no visible text or symbols

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./abra/Üçüli8

Close-up of a faucet with a blue arrow indicating clockwise motion (no text or symbols)

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/UJ4U9

Pure diagram of a vertical device with pipes and valves, no text or symbols present

Fig./img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/Uk10

Max.100cm Min.60cm

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/۱۱۲۹۰۱۱

Line drawing of a kitchen sink with faucet and faucet (no text or symbols)

3 1 2 Max.100cm Min.60cm Max.100cm Min.60cm

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/12

Hand holding a tool interacting with an open electrical outlet (no text or symbols visible)

Illustration of a car backseat with a hand holding a bag and a folded garment (no text or symbols)

Technical diagram of a mechanical component with no visible text or symbols

Simple line drawing of a box with an arrow indicating direction (no text or symbols)

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./âbra/###13

Pure diagram of a mechanical or electrical component with no text, numbers, or symbols

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/14

Pure diagram of a mechanical component with no text, numbers, or symbols

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/15

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./śbra/16

I 1 2 3 II

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./âbra/۱۲۴۱۷

Cotton Synthetic Mix Jeans Sportswear 20°C Baby Care My Max CD Express 15° Express 42° ECO 60-60 Stearl Wool Rimsa & Spin Spool Drum Clean

4

cecoctec 5 7,5 kg INVENTER PLUS 90 1000 60 1000 40 800 20 600

3
Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./âbra/Ükül 18

90 1200 60 1000 40 800 20 600 C A D B E

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./âbra/###19

Diagram of a mechanical assembly with rotating components (no text or symbols)

Line drawing of a hand holding a microphone with a tool, no text or symbols present

Hand holding a small object with a circular inset showing a mechanical component (no text or symbols visible)

Simple line drawing of a mechanical device with a circular component and a handle (no text or symbols)

Fig./Img./Abb./Afo./Rys./Obr./Şekil/Eik./åbra/J20

Simple line drawing of a mechanical component with a circular hole and an arrow indicating rotation (no text or symbols)

Hand holding a circular button with an arrow, pressing down on a rectangular device (no text or symbols visible)

3

Technical line drawing of a mechanical component with rotational arrows indicating motion (no text or symbols)

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./ábra/Ükül 22

Fig./Img./Abb./Afb./Rys./Obr./Şekil/Eik./śbra/21

www.cecotec.es
