USER MANUAL PLKA 4 C3 PARKSIDE

Black and white photo of a parkside electric soldering tool (no visible text or symbols on body)

4 V AKKU-LÖTKOLBEN/4V CORDLESS SOLDERING IRON/4 V FER À SOUDER SANS FIL PLKA 4 C3

DE AT CH

4 V AKKU- LÖTKOLBEN

User manual Translation of the original instructions

ES

4 V SOLDADOR RECARGABLE

4V ACCU- SOLDEERBOUT

Close-up of a hand holding a black handheld electronic device with a screwdriver (no visible text or symbols)

Scanned image showing two identical icons with Chinese characters and symbols, likely representing a product or service.

Scope of delivery ..... 35

Parts description..... 35

Technical data. 35

Safety instructions ..... 37

General safety instructions. 37

Special safety instructions. 39

Safety instructions for

batteries/rechargeable

batteries 40

Battery charger safety

instructions 42

First set-up of the product 43

Unpacking the product.... 43

Charging the battery..... 44

Fitting/changing the

soldering tip 45

Switching on/off 45

Use 46

Cleaning/maintenance.... 47

Cleaning 47

Maintenance 48

Storage 49

Transportation. 49

Troubleshooting.... 50

Disposal.... 50

Warranty 52

Warranty claim procedure. . 53

Service 54

List of pictograms used
	Read the user manual.
	DANGER! – Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)
	WARNING! – Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)
	CAUTION! – Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)
	NOTICE! – Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)
	INFO: This symbol with the “Info” signal word offers additional useful information.
	Only use the chargers recommended by the manufacturer.
	Protection class III
	Protection class II
	Direct current/voltage
	Alternating current/voltage
	Use the product in dry indoor spaces only.
	Attention, hot parts.Maintain a safe distance!
	Vapours can lead to headaches and fatigue if inhaled.
[44S2]	Safety information Instructions for use
	CE mark indicates conformity with relevant EU directives applicable for this product.

4V CORDLESS SOLDERING IRON

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is designed for soldering electronic components.
- Do not use this product for any other purpose.
■ This product is only intended for indoor use.
This product is only intended for private household use, not for commercial purposes.
■ The manufacturer accepts no liability for damages caused by improper use.

- Scope of delivery

1 4V Cordless soldering iron
1 Soldering tip
1 Solder, ∅ 1.0 mm
1 Charging cable (USB-A to USB-C)
1 Station
1 Sponge
1 User manual

Parts description

1 Soldering tip
2 Soldering tip holder
3 Work light
4 On/off button
5 Indicator light
6 Sponge
7 Station
8 Charging cable (USB-A to USB-C)
9 Charging plug (USB-C)
10 Solder ∅ 1.0 mm
11 Charging socket (USB-C)

- Technical data

4V Cordlesssoldering iron PLKA	4 C3
Protection class:
Temperature of the soldering tip:	max. 470 °C
Weight: 111 g
Rechargeable battery (Li-Ion)
Rated voltage: 4 V
Capacity C: 1.5 Ah
Power P: 8 W
Number of cells: 1
Charging time: approx. 1 h
Charger*HG06825, HG06825-BS
Input voltage: 100–240 V~
Input alternating current frequency: 50/60 Hz
Power consumption: 8,5 W
Output voltage: 5,0 V
Input current: 0.3 A
Output power: 8.5 W
Average efficiency in operation: 78.8 %
Efficiency at low load (10 %): 79.5 %
Power consumption at no load:	0.07 W
Protection class:	II
Socket: USB-A

Use only the following charger adapter to charge the cordless product\*:

Information

Manufacturer's name or trade mark, commercial registration number and address:

OWIM GmbH & Co. KG

HRA 721742

Stiftsbergstraße 1

74167 Neckarsulm

GERMANY

Model identifier:

HG06825, HG06825-BS

Safety instructions

● General safety instructions

This appliance can be used by children aged from 8 years and above and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they are supervised or have been instructed on how to use the appliance safely and understand the hazards involved. Children must not play with the appliance. Cleaning and user maintenance must not be carried out by children unless they are aged 8 years or older and are supervised.

BEFORE USING THE PRODUCT, FAMILIARISE YOURSELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, ALSO INCLUDE ALL THE DOCUMENTS!

In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

Children and persons with disabilities

⚠ WARNING! RISK OF LOSS OF LIFE OR ACCIDENT TO INFANTS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation.

Children frequently underestimate the dangers. Always keep children away from the packaging material.

The product may only be used by adults. Children under the age of 16 may only use the product under supervision.
- Keep children away from the product.

General information

- Observe the information in these operating instructions regarding operation, cleaning, storage and disposal.

• Check the product before each use. Have a damaged product repaired. Do not use a damaged product.
  ■ Switch off the product when not in use.
  ■ Never leave the product switched on unattended.

● Special safety instructions

WARNING! Fire risk!

▶ Only place the product on a non-flammable surface.
Place the product in such a way that the soldering tip does not come into contact with flammable materials.
Do not leave the product unattended when hot.
Allow the product to cool down before putting it away.

WARNING!

Only use the specified detachable charger (HG06825 or HG06825-BS) to charge the battery.

⚠️ CAUTION! Risk of injury!

The soldering tip reaches temperatures of over 400 °C. Touching the metal parts can lead to severe burns.
▶ Allow the product to cool down before carrying out inspection, maintenance or cleaning work!

NOTICE!

The product must be plugged into the station when it is not in use.

- Only switch on the product shortly before it comes into contact with the working material. - Harmful vapours are produced during soldering and when working with plastics. Ensure good ventilation or a suitable fume cupboard.

- Avoid eating, drinking and smoking in rooms where soldering work is taking place. Otherwise, lead residues on your hands might contaminate the food, drink or cigarettes and be absorbed into your body.

■ Always wash your hands thoroughly after soldering.

■ Wear protective goggles and suitable work clothing to protect yourself from solder splashes and corrosive vapours.

■ The product must never be used to heat liquids or plastics.

This product contains batteries that can only be replaced by trained personnel.

- Do not dispose of solder waste in normal household waste! Solder waste should be disposed of with hazardous waste.

● Safety instructions for batteries/rechargeable batteries

⚠️ DANGER TO LIFE! Keep batteries/rechargeable batteries out of reach of children. If

accidentally swallowed seek immediate medical attention.

RISK OF EXPLOSION!

Never recharge non- rechargeable batteries. Do not short-circuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.
- Do not exert mechanical loads to batteries/rechargeable batteries.

CAUTION! RISK OF EXPLOSION!

Never charge non-rechargeable batteries!

Protect the rechargeable battery from heat,

for example from continuous exposure to sunlight, fire, water

and moisture. There is a risk of explosion.

Risk of leakage of batteries/rechargeable batteries

• Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.
  If batteries/rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE

GLOVES! Leaked or damaged batteries/rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

This product has a built-in rechargeable battery which cannot be replaced by the user. The removal or replacement of the rechargeable battery may only be carried out by the manufacturer or his customer service or by a similarly qualified person in order to avoid hazards. When disposing of the product, it should be noted that this product contains a rechargeable battery.

Before cleaning: In order to minimise the risk of electric shock, remove charging cable from the product.

■ Before charging: Allow the battery to cool down completely.

Do not open the battery and avoid mechanical damage to the battery. There is a risk of a short circuit and vapours may leak out, causing irritation to the respiratory tract. Seek fresh air and medical assistance.

● Battery charger safety instructions

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or

instruction concerning use of the product in a safe way and understand the hazards involved.

Children shall not play with the product.

Cleaning and user maintenance shall not be made by children without supervision.

• Keep the charger clean and away from moisture and rain. Never use the charger outdoors. Dirt and water ingress increase the risk of electric shock.
  The charger may only be used to charge the designated products.

Charging other products can lead to injuries and fire risks.

The charger must not be operated on a flammable surface (e.g. paper, textiles).

There is a risk of fire due to the heat generated during charging.

■ Never attempt to charge non-rechargeable batteries.

- First set-up of the product

● Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described (see "Warranty").

● Charging the battery

NOTE

The battery is not replaceable. If you have problems with the battery, contact the service centre (see "Service").
Only use the HG06825 or HG06825BS charger to charge the battery safely (see "Maintenance" and "Service").
The product cannot be used while it is being charged.
Charge the battery fully before using it for the first time.
▶ Recharge the battery when the heating power decreases.

1. Connect the charging cable 8 to the charger.
2. Connect the charging plug 9 to the charging socket 11 (Fig. B).
3. Connect the charger to a power socket.

The indicator light 5 shows the status:

Colour	Status
Red The	battery is charging.
Green The	battery is charged.

After charging

1. Disconnect the charger from the power socket.
2. Remove the charging plug 9 from the charging socket 11 (Fig. B).

● Fitting/changing the soldering tip

(Fig. C)

CAUTION! Risk of injury!

▶ Allow the product to cool down before carrying out inspection, maintenance or cleaning work!

1. Remove the charging plug 9 from the charging socket 11.
2. Turn the soldering tip 1 anti-clockwise out of the soldering tip holder 2.
3. Turn the new soldering tip 1 clockwise into the soldering tip holder 2 (hand-tight).

Switching on/off

i INFO:

• When the product is switched on, the work light 3 illuminates.
  The soldering tip 1 requires approx. 30 seconds to reach operating temperature (300 °C).
  ■ The indicator light 5 shows the status:

Colour Status
Red The solderingtip 1 heats up.
Green The operating temperature (300 °C) has been reached.
Red (flashing)	The battery is low.Charge the battery.

■ The product switches off automatically after 10 minutes. Switch the product on again if required.

Switching on

☐ Press and hold the on/off button 4 for 4 seconds.

Switching off

□ Briefly press the on/off button 4.

Use

CAUTION! Toxicity risk!

Vapours can lead to headaches and fatigue if inhaled.

NOTE

The soldering tip 1 requires approx. 30 seconds to reach operating temperature.
To obtain a proper solder joint, the solder joint must be clean and free of grease.
The flux is either included in the solder or is applied separately. Find out about the type of application and the suitable solder when purchasing.
In the case of electronic components, the parts to be soldered must not be heated too much to avoid damage.
Before starting work, the soldering tip 1 must be tinned (coated with solder 10). Only good tinning guarantees perfect soldering and heat transfer.
▶ Recharge the battery when the heating power decreases.
□ Moisten the sponge 6 before starting work so that

you can dab the soldering tip 1 during and after use.

☐ Hold the product like a pen (Fig. D).
☐ Ensure that the soldering tip 1 is always clean and free of scaling and excess solder 10. Clean the soldering tip regularly with a wet sponge. Never use a file for cleaning.

☐ If possible, create a mechanical connection between the metals to be joined before soldering. For example, twist the wires together to prevent them from slipping. This will give you stable solder joints and avoid heat damage caused by soldering for too long.

☐ To solder two metals, hold the soldering tip 1 on the joint and briefly add solder 10. The solder melts and flows into the solder joint. Once the solder has spread, remove the soldering tip. Allow the solder joint to cool down without vibration.

☐ Never heat solder 10 directly and do not use too much solder.

☐ Allow the product to cool down in the station 7.

● Cleaning/maintenance

⚠️ CAUTION! Risk of injury!

Allow the product to cool down before carrying out inspection, maintenance or cleaning work!

- Cleaning

⚠ NOTICE! Risk of short circuit!

▶ Never submerge the product in water or other liquids.

⚠ NOTICE! Risk of short circuit!

Do not allow water to enter into the product.

⚠ NOTICE! Risk of product damage!

- Do not use abrasive, aggressive cleaning agents or hard brushes for cleaning. - Never scrape or file off solder residue from the soldering tip 1 with hard objects, as this will damage the soldering tip!

NOTE

Keep the product clean to ensure secure work.

☐ Before cleaning: Switch off the product and allow it to cool down.

☐ Wipe the warm soldering tip 1 on the moistened sponge 6 during and after use.

□ Clean the product with a soft, dry cloth.

Maintenance

NOTE

The integrated Li-ion battery may only be removed by trained or qualified personnel.

☐ Check the product for obvious defects such as loose, worn or damaged parts before each use. Replace these parts if necessary.

Replacement parts/Accessories

Customers can obtain compatible replacement parts and accessories via www.optimex-shop.com.

□ Have the order number ready for your order.
☐ Orders can only be placed and processed online.
□ Contact the Lidl service hotline (see „Service“) for further information.

Part Order number
10 Solder∅ 1.0 mm	99947191501

Storage

□ Clean the product.
☐ Allow the product to cool down completely before storing it.
□ Store the product in a frost-free, dry and dust-protected place, out of the reach of children.

- Transportation

This product contains a Li-Ion rechargeable battery and is therefore subject to hazardous materials regulation. Users may transport the product with built-in rechargeable battery on roads or by sea without special requirements.

The packaging and marking is subject to special requirements when it is transported by third parties (e.g. airline, courier, carrier). A hazardous materials expert must be consulted when transported by third parties.

● Troubleshooting

Possible problems

The soldering tip 1 does not heat up.

The battery is empty. Charge the battery.

The battery is not charging.

The charging cable 8 or the charger is defective.

Contact the service centre (see "Maintenance" and "Service").

The indicator light 5 flashes red.

The temperature of the soldering tip 1 is too low.

The soldering tip 1 is loose.

1. Allow the product to cool down.
2. Tighten the soldering tip 1 (hand-tight).

Problem

Cause

Solution

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

serve the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

Scanned image showing two labeled icons with Chinese characters, likely representing product or service categories.

The product and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/ rechargeable batteries must be recycled. Return the batteries/ rechargeable batteries and/ or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge

to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 471915_2407) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the

service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

PDF ONLINE parkside-diy.com

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 471915_2407 takes you to the operating instructions for your item.

Service

Service Great Britain

Tel.:[phone]

E-Mail: [e-mail]

Service Ireland

Tel.:[phone]

E-Mail: [e-mail]

Scanned image showing two labeled icons with symbols, likely representing product or service categories.

WAARSCHUWING! Brandgevaar!

Scanned image showing two labeled icons with Chinese characters and symbols, likely representing product or service categories.

QR code image with a central logo, likely linking to a digital resource or website.

PDF ONLINE
parkside-diy.com

Scanned image showing two labeled icons with Chinese characters, likely representing concepts or functions.

Scanned image showing two labeled icons with symbols and text, possibly representing product or service categories.

Scanned image showing two identical icons with Chinese characters and symbols, likely representing concepts or functions.

Scanned image showing two identical icons with Chinese characters and symbols, likely representing concepts or functions.

ADVARSEL! Brandfare!

⚠️ FORSIGTIG! Fare for forgiftning!

Scanned image showing two identical icons with Chinese characters and symbols, likely representing concepts or functions.

Scanned image showing two identical icons with Chinese characters and symbols, likely representing concepts or functions.

Scanned image showing two identical icons with Chinese characters and symbols, likely representing a product or service category.
