| Brand | Metabo |
| Model | T 13125 Set Tuck |
| Product Type | Angle grinder |
| Max. disc diameter | 125 mm |
| No-load speed (max.) | 11000 rpm (estimated) |
| Variable speed | Yes, adjustment wheel |
| Power supply | Corded, 230 V ~ 50 Hz |
| Power consumption | 1400 W (estimated) |
| Weight (without cable) | 2.5 kg (estimated) |
| Spindle thread | M14 (standard) |
| Quick locking system | Quick (M-Quick) |
| Main functions | Grinding, cutting, sanding, brushing |
| Protective guard | Type A/B/C depending on use, tool-free adjustable |
| Auxiliary handle | Removable, left or right mounting |
| Safety devices | S-automatic safety clutch, spindle lock, restart protection |
| Maintenance and cleaning | Regular cleaning of ventilation slots |
| Spare parts | Original Metabo accessories |
| Repairability | By authorized Metabo repair service |
| Protection class | II (double insulation) |
| Dimensions (L×W×H) | 280 × 125 × 100 mm (estimated) |
Frequently Asked Questions - T 13125 Set Tuck METABO
What types of discs can I use with the Metabo T 13125?
You can use grinding wheels, cutting wheels (metal, masonry), diamond discs, wire brushes, sanding pads, and polishing accessories (depending on model). Make sure to respect the max. diameter of 125 mm and the maximum speed.
How do I change the disc on the Metabo T 13125 grinder?
Unplug the device. Lock the spindle with the red button (M-Quick). Use the Quick clamping nut: turn by hand counterclockwise to tighten. To loosen, press the M-Quick button shortly before complete stop. If the disc is thick (>7.1 mm), use the two-hole nut with the pin wrench.
How do I adjust the rotation speed?
Use the speed adjustment wheel (mark 8). Turn it to a high number for fast speed, low for slow speed. Adapt the speed to the accessory: high speed for cutting wheels, medium for brushes, low for sanding.
What is the function of the S-automatic safety clutch?
The S-automatic safety clutch stops the machine immediately in case of sudden disc blockage, reducing the risk of kickback and injury. If the system triggers, release the switch and eliminate the cause of blockage before restarting.
Can I use this grinder for polishing?
Polishing is only possible on the mentioned models WEV 15-125 Quick HT, WEV 17-125 Quick Inox, WEV 17-125 Quick Inox RT. For the T 13125 model, polishing is not recommended. Use a Metabo angle polisher for optimal results.
How do I maintain my Metabo T 13125 grinder?
Regularly clean the ventilation slots with a vacuum cleaner or dry air (wear a mask and goggles). Check the condition of the cable and accessories. Immediately replace any damaged guard or handle.
What should I do if the electronic indicator lights up during work?
The electronic indicator indicates an overload. Let the machine run at idle until it turns off. If the indicator flashes and the machine does not start, the restart protection is active: turn off then turn on the device.
Which protective guards should be used for each type of work?
Use type A guard for cutting, type B for sanding, type C for both (combined), type D for cup wheels, type E/F for dust extraction. Do not mix guards: an incorrect guard may cause loss of control.
Can I use non-Metabo accessories?
It is strongly recommended to use only original Metabo accessories that comply with specifications (diameter, speed, thread). Using unsuitable accessories may lead to risks of breakage, kickback, or injury.
Where can I find spare parts and get my grinder repaired?
Spare parts are available on the Metabo website (www.metabo.com). Repairs must be carried out by an authorized Metabo repair center. Do not attempt to repair the machine yourself, except for changing accessories.
