Product type	Corded electric lawn mower
Brand	Bosch
Model	Rotak 180043 R
Rated input power	1800 W
Cutting width	43 cm
Adjustable cutting height	20 – 70 mm
Grass catcher volume	50 L
Weight (according to EPTA 01/2003)	13.2 kg
Protection class	II (double insulation)
Rated voltage	230 V ~ 50 Hz
Sound pressure level	80 dB(A)
Guaranteed sound intensity level	95 dB(A)
Vibration emission value	< 2.5 m/s² (uncertainty K = 1.5 m/s²)
Blade type	Steel rotary blade
Leaf collection function	Yes, cutting adjustment at 70 mm recommended
Handlebar	Folding for compact storage
Power supply	Mains via extension cable (H05VV-F, H05RN-F or IEC)
Recommended extension cable cross-section	1.0 mm² (max 40 m), 1.5 mm² (max 60 m), 2.5 mm² (max 100 m)
Safety device	Residual current circuit breaker 30 mA recommended
Blade maintenance	Replacement with original Bosch blades, tightening to 17 Nm
