User's Instructions Installation

All operations relative to installation (electric connection) should be carried out by skilled personnel in conformity with the rules in force.

As for the specific instructions see part pertaining to installer.

Use TOUCH CONTROL HEATING ELEMENTS

Touch sensitive keys All operations can be performed using touch sensitive keys (capacitive sensors) located on the front of the control board; each key has a corresponding display. All actions are confirmed by an audible signal.

TOUCH CONTROL B (Fig. 2)

1 Power ON / Power OFF
2 Cooking zone +
3 Cooking zone -
4 Double circuit
5 Timer
6 Setting display
7 Timer display
8 Zone selection lights
9 Timer indicator light

Switching the Touch Control ON/OFF

After mains voltage is applied the control initializes for approx. 1 second before it is ready for operation. After a reset all displays and LEDs glow for approx. 1 second. When this time is over all displays and LEDs extinguish and the control is in the stand-by mode.

By operating the ON/OFF key the control can be turned into the ON-mode. The cooking zone displays show a static "0". If a cooking zone is in the "hot" status, the display shows a static "H" instead of "0". The bottom right dot is blinking in 1 second intervals on all cooking zone displays to indicate that no cooking zone is selected at the moment.

After switching-ON the electronic control remains activated for 20 seconds. If no cooking zone or timer selection follows within this period of time, the electronic control automatically switches back into the stand-by-mode.

The control can only be switched-ON if it identifies the ON/OFF key alone being operated. Should it recognize key

activation other than that, the control remains in the standby- mode.

If the child safety feature is active when switching on, all cooking zones show "L", (LOCKED). (also refer to 1.11). If the cooking zones are in a "hot" status, the display shows "L" and "H" in alternation. When the Touch Control is ON it can be switched-

OFF at any time by operating the ON/OFF key. This is also valid if the control has been locked (activated child safety feature).

The ON/OFF key has always priority in the switch-OFF function.

Automatic switch-OFF

When the control is ON it automatically switches-OFF after 20 seconds if no cooking zone or select key has been operated within this period of time. If case of a cooking zone selection, the automatic switch- OFF time is composed of 10 seconds deselection time for a cooking zone at setting"0" and 10 seconds switch-OFF time.

Switching a cooking zone ON and OFF

If the control is ON the respective cooking zone can be selected by operating a cooking-zone-select-key (= PLUS-key of the respective cooking zone). There is a static dot indication in the respective display. If the cooking zone is "hot "0" is displayed instead of "H". On all other cooking zone displays the blinking dot extinguishes. Then a setting will be chosen by a renewed operation of the cooking-zone select- key or the MINUS-key and the cooking zone begins to heat up. In order to use the cooking-zone-select-key as a PLUS-key the control has to recognize that after the selection the cooking zone has been released for 0,3 seconds.

After selection of a cooking zone the setting can be increased by continuously pressing the PLUS-key, starting at step "1" it is increased by 1 step every 0,4 seconds. When setting "9" is reached the setting will not be changed further (end stop).

If the selected cooking zone will be switched ON by means of the MINUS key, the cooking zone starts at the maximum setting "9" ("reverse switching-ON").

When the key is continuously operated, it decreases by 1 step every 0,4 seconds. When setting "0" is reached, there will be no further setting changed (end stop). Only a renewed operation of the MINUS (or PLUS) key changes the setting.

Switching OFF an individual cooking zone

To switch off an individual cooking zone, the respective cooking zone has to be selected with the cooking-zone-select key (= PLUS) . The selection is indicated with the static dot in the respective cooking zone display. If the control recognizes that the PLUS- (cooking-zone-select-key is the PLUS-key) and the MINUS key have been activated simultaneously the setting of the selected cooking zone will be put back to "0". Alternatively, the MINUS-key can be used to count down the setting to "0". If all cooking zones are at "0", all decimal points in the cooking zone displays are blinking. If a cooking zone is "hot", "H" will be displayed instead of "0".

Switching-OFF all cooking zones

Immediate switching-OFF of all cooking zones can be achieved anytime by means of the ON/OFF key. In the standby- mode an "H" appears on all cooking zones which are "hot". All other cooking zone displays are not illuminated.

Wattage settings

The output of the cooking zones can be set in 9 steps which are indicated by the figures "1" thru "9" by means of sevensegment-displays.

Automatic heat-up function (selectable)

When the automatic heat-up function is activated the wattage of the cooking zone is at 100% ED for a certain heat-up time which is dependent on the selected (continuous) setting. At the end of the heat-up time the electronic control switches back to the preselected simmering setting.

Starting process of the automatic heat-up:

• Control is ON and a cooking zone will be selected
• The automatic heat-up will be activated by operating the PLUS-key for a second time.
• The requested continuous setting will be selected with the PLUS- and MINUS-key, the chosen setting appears in the display.
• 3 seconds after the last key operation (selection of the setting) and within 16 seconds after activation of the heat-up function, the symbol "A" (which stands for the heat-up boost) appears on the display, in alternation with the chosen setting.
• If a lower setting will be selected with the MINUS-key after the "A" has appeared in the display, the automatic heat-up function will be interrupted.
• By means of the PLUS-key a higher continuous setting can be chosen, here the duration of the heat-up boost will be automatically adapted to the actual selected setting.
• When the heat-up time is over, the selected (continuous) setting will be indicated on the display.

Residual heat indicator

It is meant to indicate to the user that the glass ceramic has a dangerous touch temperature in the circumference of a cooking zone. The temperature will be determined following a mathematical model and the remaining residual heat will be indicated by means of "H" on the corresponding 7-segmentdisplay. Heating-up and cooling down will be calculated dependent on

• the selected setting (.,0^u to ,9^u)
• the ON/OFF time.

After switching-OFF the cooking zone the respective display shows "H" until the assigned cooking zone temperature is mathematically in a uncritical level. (≤ 60^)

Automatic power OFF function (operating time limitation)

Dependent on the selected setting, every cooking zone will be switched-OFF after a defined maximum operation time if no operation of the assigned cooking zone follows within this time period. Every change of the cooking zone condition (by means of the PLUS-, MINUS- or BOOSTER key) puts back the maximum operation time of this cooking zone to the initial value of the operating time limitation.

Protection against unintended switching-ON

• If the electronic control realizes a continuous operation of keys for approx. 10 seconds, it switches OFF automatically. The control sends out an audible failure signal for 10 seconds, so that the user can remove the object which has been mistakenly placed onto the operation surface. The displays show the failure code "E R 0 3". If the failure carries on for more than 10 seconds, only the code "E R 0 3
  will be displayed as long as the failure will be recognized Dby the electronic control. If the cooking zone is in the "hot" status, "H" will appear on the display in alteration with the failure notice.
• If no cooking zone will be activated within 20 seconds after switching-ON by means of the Power-key, the control switches back from the ON-condition into the stand-by-mode.
• When the control is switched- ON the ON/OFF-key has priority over all other keys, so that the control can be switched-OFF anytime, even in case of multiple or continuous operation of keys.
  In the stand-by mode a continuous operation will not be signalized. However, before the electronic control can be switched-ON again, it has to recognize that all keys are not operated.

Key lock (child safety feature)

Child safety feature:

Key lock:

After switching-ON the control the child safety feature can be activated. To achieve this it is necessary to simultaneously operate the front right cooking zone- select-key and the MINUS-key and then press the front right cooking-zone-select key again. There will be an "L", meaning LOCKED (child safety feature against unintended switching-ON). If a cooking zone is in the "hot" condition, "L" and "H" will be displayed in alternation.

This course of operation has to take place within a period of 10 seconds, no other key than described above may be operated. Otherwise the input will be interrupted because of incompleteness, the cook top will not be locked then. The electronic control remains in a locked condition until it gets unlocked, even if the control has been switched-OFF and -ON in the meantime. Also a reset of the control (after a voltage drop) does not cancel the key lock.

Unlocking for cooking purposes:

To unlock and operate the control it is required to operate the front right cooking-zone select-key and the MINUS-key simultaneously. "L" (LOCKED) in the display extinguishes and all cooking zones show "0" with a blinking dot. Should a cooking zone be "hot", "H" is displayed instead of the static "0". After switching- OFF the control, the child safety feature is active again.

Cancelling the key lock:

After switching-ON the control the child safety feature can be deactivated. Here it is necessary to simultaneously operate the front right cooking-zone-select key and the MINUS-key and then operate the MINUS-key alone. If all steps have been carried out in the right order within 10 seconds the key lock gets cancelled and the control is OFF. Otherwise the input will be considered incomplete, the control remains locked and switches-OFF after 20 seconds. After a renewed

switching-ON by means of the ON/OFF key all displays show 0^ , the display dots are blinking and the control is ready for cooking. If a cooking zone is "hot", "H" will be displayed instead of the static 0^ .

Multi-circuit cut-off

Depending on the design it is possible to operate dual- or triple-circuit radiant heating elements with the LITE-Touch Control.

When a multi-circuit heating element is put into operation, all heating circuits are switched-ON at the same time. If only the inner heating circuits should be used, the outer heating circuit can be switched-OFF by means of the multi-circuit key or in individual steps.

By operating the multi-circuit key the respective outer circuit of the assigned active cooking zone (setting ,0^ can be cutoff anytime. An activated outer circuit will be indicated by an additional LED. A renewed operation of the multi-circuit key will add the outer circuit(s) at any time, the assigned LED's glow again (toggle-function)

If a cooking zone other than the one with multi-circuit function will be selected, the multicircuit status will be changed and all cooking zones will be deselected (the decimal point extinguishes).

Behaviour of dual-circuit cut-OFF:

If the heating element to be controlled is a triple-circuit heating element, the course of action is as follows:
- The first activation of the multi-circuit key cuts-off the outer heating circuit and the top LED extinguishes.
- A second activation of the multi-circuit-key cuts-off the middle heating circuit. (also the bottom LED extinguishes.)
- A third activation adds the middle heating circuit again. A further activation adds the third heating circuit as well and the assigned LEDs glow again.

Audible signal (buzzer)

While the control is in operation the following activities will be signaled by means of a buzzer:

• normal key activation with a short sound signal.
• continuous operation of keys over a longer period of time (_10 seconds) with a longer, intermittent sound signal.

Timer function (optional)

The timer function is realized in two versions:
- Stand-alone timer 1..99 min: sound signal when the time is over (= minute minder). This function is only available when the cooktop is not in operation, i.e. when there is no cooking.
- Cooking zone timer 1..99 min: sound signal when the time is over, four cooking zones can be programmed independently.

Timer as minute minder (stand-alone):

• If the control is OFF the standalone-timer can be operated by activating the timer key. The timer display shows "00". Operation of the Power-key puts the control back into the stand-by mode and the stand-alone-timer will be cut-off.
• Adjustment range (0-99min), it can be set in 1-minute steps with any key, starting at 1 up to 99 (end stop) with the minus-key starting at 99 down to 0 (end stop)
  Continuous activation of the plusor minus-key results in a

dynamic increase of the adjustment speed up to maximum Precautions (Fig. 3)

value without sound signal.

• when the plus- or minus key is released in the meantime, the adjustment speed starts again from a (low) initial value.
• adjustment can be made with a continuously activated plus-or minus-key or by tip-operation (with sound signal). After the timer is set the time runs down according to the adjustment. When the time is over there is a sound signal and the timer display blinks.

The sound signal will be stopped

• automatically after 2 minutes and/or
• by operating any key. Then the blinking of the timer display stops and the display extinguishes.

Switching-OFF/changing the timer

• The timer can be changed or switched-off anytime by operating the TIMER- or MINUS key (with sound signal). The timer will be switched off by counting down to "0" with the minus-key or by operating the TIMER- and MINUS-key together, which sets the timer directly to "0". For 6 seconds the timer display remains at "0" before it will be switched-off.

• If the control will be switched-ON by means of the Powerkey, the stand-alone timer will be switched-off also.

Timer programming on cooking zones

When the control is switched- ON an independent timer can be programmed for every cooking zone.

• By selecting a cooking zone with the cooking-zone-selectkey, then selecting the setting and finally activating the timerselect-key, the timer can be programmed as a switch-off function for a cooking zone. Around the timer four LEDs are arranged. These indicate for which cooking zone the timer has been activated.
• As soon as the timer has been selected, the assigned timer-LED blinks and the dot in the timer display glows. If a cooking-zone-select-key will be operated, the dot in the timer displays extinguishes and the LED does not blink any longer.
• When switching-over from one cooking zone to another, the timer display always shows the present timer value of the respective cooking zone. However, the programmed timers of other cooking zones remain active.
• The further setting behaviour corresponds to the STANDALONE-TIMER. For increasing the adjusted time, the PLUS-key of the respective cooking zone has to be used. (setting "0")
• When the timer has run down, there is a sound signal and the timer display shows "00" statically, the assigned cooking zone timer LED blinks. The programmed cooking zone will be cut off and H^ will be displayed if the coking zone is hot, otherwise a stroke will show in the cooking zone display.

The sound signal and the blinking of the timer LED will be stopped

automatically after 2 minutes
- by operating any key.
The timer display extinguishes.
The basic behavior follows the description of the "minute minder" (stand-alone-timer).

Precautions (Fig. 3)

• When one makes use of heating elements, we advise receptacles with flat bottom having same diameter or lightly higher than that of the hot area.
• Avoid overflows of liquid, therefore when boiling has happened, or in any case when liquid is heated, reduce the heat supply.
• Don't leave the heating elements on without receptacles on the top or with void pots and pans.
• If the surface of the hob is damaged, immediately disconnect the appliance from the mains to prevent the possibility of electric shock.
• Never use a steam cleaner to clean the hob.
• This appliance hood is not designed to be used by people (including children) with reduced physical, sensorial or mental capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use the appliance by someone who is responsible for their safety.
• Children must be supervised to ensure that they do not play with the appliance.

Should there be no cable and/or plug on the equipment, use suitable absorption material for the working temperature as well, as indicated on the matrix plate. Under no circumstance must the cable reach a temperature above 50^ of the ambient temperature.

Should a direct connection to the network be required, it will be necessary to interpose an omnipolar switch with min. aperture between the 3mm contacts, dimensioned to bear the plate load and it must follow the standards in force (the yellow/green earth cable must not be interrupted by the switch). The plug or omnipolar switch must be easily reached on the installed equipment.

The manufacturers decline any responsibility in the event of non-compliance with what is described above and the accident prevention norms not being respected and followed.

To avoid all risk, if the power cable becomes damaged, it must only be replaced by the manufacturer, by an authorised service centre, or by a qualified electrician.

Maintenance (Fig. 4)

By means of a scraper immediately remove any alluminium foil bits, food spills, grease splashes, sugar marks and other high sugarcontent food from the surface in order to avoid damaging the hob.

Subsequently clean the surface with some towel and appropriate product, rinse with water and dry by means of a clean cloth. Under no circumstance should sponges or abrasive cloths be used; also avoid using aggressive chemical detergents such as oven sprays and spot removers.
