USER MANUAL EK5 AENO

ENG The AEK0005 Electric Kettle is designed for heating and boiling drinking water.

Technical Specifications

Power supply (input): 220–240 V, 9.2 A (max.) (AC), 50–60 Hz, 1,850.0–2,200.0 W. Capacity: 1.7 L. Boiling time: up to 6 min. Control: manual. Modes: Boil, Heat (+40 °C, +50 °C, +60 °C, +70 °C, +80 °C, +90 °C, +100 °C) *, Keep Warm (+40 °C, +50 °C, +60 °C, +70 °C, +80 °C, +90 °C, +100 °C) for up to 30 minutes. Automatic shut-off. Color: White. Material: plastic, glass. Power cord length: 0.7 m. Plug type: E/F. Device size (L×W×H): 217×138×255 mm. Net weight: 1.1 kg. Operating conditions: temperature +5...+40 °C, relative humidity ≤ 85 % (non-condensing). Storage conditions: temperature +5...+45 °C, relative humidity ≤ 93 % (non-condensing).

Package Contents

AEK0005 Electric Kettle, base, Quick Start Guide.

Device Elements (see figure)

1 – lid release button, 2 – lid, 3 – spout, 4 – casing, 5 – water level marks, 6 – backlight, 7 – base, 8 – power cord, 9 – plug, 10 – handle, 11 – control panel, 12 – temperature scale selection button, 13 – “KEEP WARM” button, 14 – (“Start/Stop”) button, 15 – “+/-” (temperature adjustment) button, 16 – display.

Limitations and Warnings

ATTENTION! Electric shock hazard. Avoid contact of the electrically conductive parts of the device with water.

ATTENTION! Do not turn on an empty kettle.

ATTENTION! Fill the kettle at least to the "MIN" mark on the device casing, but not above the "MAX" mark.

ATTENTION! Only lift the kettle by the handle.

Before using the device, read this document thoroughly and save it for future reference. Use the device only for its intended purpose. The kettle is designed only for heating and boiling water. The device is not intended for use by children under 14 or persons with physical, mental or intellectual disabilities unless they have sufficient experience or knowledge of how to use the device and are supervised by a person responsible for their safety. Do not use the device outdoors. The device is for household use only (in a home; in temporary accommodation, such as hotels, etc.; in staff meal rooms in offices and other similar enclosures). Handle the device with dry hands only. Before using the device, make sure that the rated voltage and frequency provided in the technical specifications are the same as your mains parameters. Always make sure that the power cord is not twisted, kinked, pinched, or in contact with hot, sharp objects or heat sources. Do not drop or throw the device. Do not immerse the plug, power cord, kettle and/or base in water or other liquids. Do not use a damaged device. Do not disassemble or repair the device yourself. Repairs must be performed by a qualified technician at an authorized service center. Do not leave the device running unattended. Place the device away from external heat sources or other electrical appliances. Do not open the kettle's lid while the water is boiling as well as for two minutes after boiling. Be careful when pouring in hot water; do not tilt the kettle too sharply when filled with water. Before lifting the kettle, make sure the lid is closed tightly. Use the device only with the included base. To reduce limescale build-up, use purified water. Unplug the device from the mains when idle as well as before cleaning. Do not use chemical or aggressive detergents, abrasive pastes, products containing acids and solvents, or metal scourers to clean the device. For a detailed description of the device, its modes and features, see the full User Manual available for download at aeno.com/documents.

Backlight States

State	Description
Solid blue	The boiling or heating process has been started
Solid green	Keep Warm mode has been started
Off Th	e boiling or heating process has finished or been stopped, or the Keep Warm time has elapsed; the device is in standby mode or off

If you experienced any issues or difficulties while using your AENO™ device, please contact support by e-mail at [e-mail] or via online chat at aeno.com/service-and-warranty. Our specialists will help you solve the problem, and you will not have to spend time and effort visiting the store.

* You can change the unit of temperature from °C to °F and vice versa in the device settings.

Button Functions

Button	Action	Description
°C/°FTEMP	Press once	Changes the temperature scale from °C to °F and vice versa
KEEP WARM		Selects Keep Warm mode
(1)		Starts/stops the boiling or heating process, or enables Keep Warm mode
+/-		Adjusts the heating temperature

Preparing for First Use

Clean the device before first use; to do that, follow the instructions below:

1. Carefully open the packaging and remove the device. Remove all packing materials.
2. Put the base on a flat, stable surface.
   3.Open the kettle's lid and fill it with water up to the "MAX" mark.
3. Close the lid tightly and put the kettle on the base.
4. Insert the plug (9) of the power cord (8) into an electrical socket.
5. Press the button ⏻: the backlight will light up blue and the water will start to heat.
6. Wait until the water boils and the backlight goes out.
7. Remove the plug of the power cord from the socket.
   9.Remove the kettle from the base and carefully drain the water.

ATTENTION! Do not drink the water from the first two boils.

1. Let the device to cool down and repeat Steps 3–9.

2. After the device has cooled down completely, wipe its exterior and interior surfaces with a dry cloth.

Using the Device

1. Open the lid and pour the required amount of water into the kettle.

Note. Fill the kettle at least to to the "MIN" mark on the device casing, but not above the "MAX" mark.

1. Close the lid tightly and put the kettle on the base.

- Boil. Complete Steps 5–7 of the "Preparing for First Use" section.

ATTENTION! Pour water for subsequent boils or heat-ups only into a cooled kettle.

- Heat. Use the “+/-” button to set the required temperature and press the button ⏻. the water will heat up to the selected temperature.

- Keep Warm. Press the “KEEP WARM” button. Use the “+/-” button to set the required temperature and press the button ⏻the water will heat up to the selected temperature, which will then be maintained for 30 minutes.

Note. You cannot boil water in this mode.

1. Remove the kettle from the base and carefully pour water from it.

Note. You can stop the boiling or heating process or disable Keep Warm mode by pressing the button (again) or by removing the kettle from the base.

Cleaning and Maintenance

ATTENTION! Before cleaning, unplug the kettle from the mains and let it cool down.

Wipe the outside of the kettle with a soft cloth dampened with warm water or a mild soap solution. Then wipe with a soft cloth dampened with clean water and wipe dry.

Descaling

If using the kettle 3–5 times a day, descale it: once a month (hard and very hard water); once every 2–3 months (moderately hard or soft water).

Descalers and cleaning methods

Table vinegar	Citric acid	Commercial descaler
Pour 0.5 L of vinegar (6 % or 9 %) into the kettle and leave for 1 hour without boiling. Discard the contents of the kettle and wash it by pouring in water and draining it 5–6 times	Boil 0.5 L of water. Add 25 g of citric acid and leave for 15 minutes. Discard the contents of the kettle and wash it by pouring in water and draining it 5–6 times	Follow the manufacturer's instructions on the product packaging

Troubleshooting

• The device does not turn on. Possible causes: faulty electrical socket; the kettle is not on the base. Solution: check if the socket is working properly by plugging a different device into it; if necessary, connect the device to a properly working socket; put the kettle on the base.
• The kettle switches off a few seconds after it is switched on. Possible cause: no or too little water. Solution: unplug the kettle from the mains. Wait for it to cool down and repeat the steps in the “Using the Device” section.
• The kettle does not turn off automatically after the water boils. Possible cause: the device's lid is not closed. Solution: remove the plug of the power cord from the electrical socket. Let the device cool down for a few minutes, then make sure the lid is tightly closed.

ATTENTION! If none of the suggested solutions helped you eliminate the problem, contact the supplier or an authorized service center. Do not disassemble the device or attempt to repair it yourself.

ASBISC reserves the right to modify the device and to revise and change this document without prior notice to users. This device complies with applicable safety requirements. The warranty period and service life is 2 years from the date of retail sale of the product.

Manufacturer: ASBISC Enterprises PLC, lapetou, 1, Agios Athanasios, 4101, Limassol, Cyprus. Tel.: [phone], e-mail: [e-mail], asbis.com. Made in China. The date of manufacture is indicated on the package. All trademarks and trade names used herein are the property of their respective owners. Up-to-date information and a detailed description of the device, as well as connection instructions, certificates, information about companies that accept quality claims and warranties, are available for download at aeno.com/documents.

RoHS Directive. The device complies with the requirements of the Directive 2011/65/EU on the Restriction of Hazardous Substances (RoHS), including the requirements of the RoHS Directive 2015/863/EU.

Sthuhlywui puniawqntpp

Uünigniup (ünlnp) 220–240 Q, 9,2 U (wnwultq.) (AC), 50–60 <g, 1850,0–2200,0 Un: Dwnlwp 1,7 l: Dnduu duwulwlp uhpul 6 pnwt: Uwnwulwniup dtnpnul: Ntchhutp twngnul, wnpwgnul (+40 °C, +50 °C, +60 °C, +70 °C, +80 °C, +90 °C, +100 °C) *, wnpwgnul gtpdwnunhawuh upwhuwulwup (+40 °C, +50 °C, +60 °C, +70 °C, +80 °C, +90 °C) uhpul 30 pnwt: Ujnnfuun wugwnnl: Qnijn' uwhnuul: Ujnlən' uwwunhl, wuwulh: <nuwufph wuptnh tplwnljaŋnlp 0,7 u: fmpgh untwulp E/F: Uwnph zwhutnp (B×L×F) 217×138×255 u: Qnlun pu2n 1,1 hq: Guhwqnpduuu wuydwutpp 'gtpdwnunhawuh +5...+40 °C, hwuptpnwlu hndwnljaŋnlp ≤ 85% (wnwug hnuugduu): Tuhwuiduu uuydwutpp 'gtpdwnunhawuh +5...+45 °C, hwuptpnwlu hndwnljaŋnlp ≤ 93 % (wnwug hnuugduu):

Unipudi whetip

Eltlyunpwlyu pətʃuhl AEK0005, unulŋhp, oqunwqnđuful huulwnnn nntgnjg:

Uwnph unwnptpn (nt'u ülwupp)

1 – lquhwphgh puwduu lynawu, 2 – lquhwphs, 3 – ptpwu, 4 – lnpwniu, 5 – qnh uwlqwnwuh dqnufutn, 6 – nluwwlnpnjajniu, 7 – unwlnhp, 8 – hnuwuph iwn, 9 – hupnguw, 10 – pnfuw, 11 – lwnwwlpndwu qwhuwuw, 12 – gtpnuwwunhawuh uwwnnwuh pwnpnjajwu lynawu, 13 – «KEEP WARM» («Qtpnuwwunhawuh wwhuwunl») lynawu, 14 – «Uthfuwrph/Quub») lynawu, 15 – «+/-» lynawu (gtpnuwwunhawuh pwnpnjajniu), 16 – nhuhhtj:

Uwhāwāwghwlqnlùtpr lī whuwqqn12wgnlùtpr

ФГУЧРНФЗНГУ: Етлунpwuwú gǔgnlǚutph nhul: Ω-нүл úh unltp, np uwnph hnuwúpuwhwnnpnhs unwnptpn 2yultú qnh htun:

NF G U P N H O 30F U: Twnwnh p tj h ln u h u hw g n tp:

ФГУПРНФЗНГУ: Умпр 2nnul uħ 1gntp «MIN» ½nlühg guðn lquw «MAX» ½nlühg ultn:

ФГУТРОНФЗОНГ: О-тбјühlnp ршпăpwugntap ığhwjü pnßwulnyı:

ENG Recycling information. This symbol indicates that you must follow the Waste Electrical and Electronic Equipment (WEEE) and Waste Battery and Battery Regulations when disposing of the device, its batteries and accumulators, and its electrical and electronic accessories. According to the rules, this equipment must be disposed of separately at the end of its service life. Do not dispose of the device, its batteries and accumulators, or its electrical and electronic accessories together with unsorted municipal waste, as this will harm the environment. To dispose of this equipment, it must be returned to the point of sale or turned in to a local recycling facility. You should contact your local household waste disposal service for details.
