Download the instructions for your Milk frother in PDF format for free! Find your manual 68471 - Lund and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 68471 by Lund.
USER MANUAL 68471 Lund
Read the operating instruction
Safe contact with food
This symbol indicates that waste electrical and electronic equipment (including batteries and storage cells) cannot be disposed of with other types of waste. Waste equipment should be collected and handed over separately to a collection point for recycling and recovery, in order to reduce the amount of waste and the use of natural resources. Uncontrolled release of hazardous components contained in electrical and electronic equipment may pose a risk to human health and have adverse effects for the environment. The household plays an important role in contributing to reuse and recovery, including recycling of waste equipment. For more information about the appropriate recycling methods, contact your local authority or retailer.
PRODUCT CHARACTERISTICS
The milk frother is used to heat and froth milk. Milk can be frothed cold or warm. The detachable base ensures convenient and safe use of the device. The product is intended for home use only. The correct, reliable and safe operation of the device depends on proper use, therefore:
Before using the appliance, read the entire manual and keep it.
The supplier is not liable for any damage resulting from failure to comply with the safety regulations and recommendations of this manual.
SAFETY INSTRUCTIONS
Warning! The device can heat up to high temperatures during operation, be careful when handling it. Only hold the device by the handle.
Recommendations for transporting and installing the device
The device may only be placed on a hard, flat, even and non-flammable surface resistant to high temperatures. The surface must be able to support the weight of the device itself and the milk placed in it.
It is necessary to provide a gap of at least 10 cm around the side walls of the device, do not place materials that are not resistant to high temperatures above the device. This will allow the device to be properly ventilated. Do not place it near the edge, e.g. a table. Do not place anything on the device. This disrupts air circulation and may cause damage to the device, as well as fire.
Do not place the appliance near flammable materials, such as curtains or drapes.
Do not place any electrical devices above the device. During operation, water vapor is released, which can short circuit the electrical installation and cause electric shock.
It is prohibited to drill any holes in the device or make any other modifications to the product not described in the instructions.
Only carry the appliance with hot milk by grasping the handle and
EN
lifting it from the base. Do not carry the hot appliance together with the base. Do not move the appliance by pulling on the power cable. The temperature at the place of installation and use of the device must be between +10 °C ÷ +38 °C, and the relative humidity must be below 90% without condensation.
Recommendations for connecting the device to the power supply Before connecting the product to the power supply, make sure that the voltage, frequency and capacity of the power supply correspond to the values indicated on the device's nameplate. The plug must fit the socket. It is forbidden to modify the plug or socket in any way to fit one another.
The device must be connected directly to a single mains socket. Extension cords, multi-sockets and double sockets are not allowed. The mains circuit must be equipped with a protective conductor and a fuse of at least 16 A.
Avoid contact of the power cable with sharp edges and hot objects and surfaces. The power cable must always be fully unwound during operation and must be positioned so that it does not obstruct operation of the device. The power cable must not be positioned to pose a tripping hazard. The power socket should be located in such a way that it is always possible to quickly disconnect the power cable plug from the device. When disconnecting the power cable plug, always pull on the plug housing, never on the cable.
If the power cable or plug is damaged, immediately disconnect it from the mains and contact an authorised service centre for replacement. Do not use the device with a damaged power cable or plug. The power cable or plug cannot be repaired, in the event of damage to these elements they must be replaced with new ones free from defects.
EN
Recommendations for using the device
Note! The product is intended only for heating and frothing milk. It is prohibited to use any other liquid or substance than milk for heating or cooking.
The appliance must only be used with the supplied base. The power cord must be fully unrolled when using the appliance. A coiled cord can overheat and create a risk of fire and electric shock.
Make sure that the floor near the place where the appliance is used is not slippery. This will prevent slipping, which could cause serious injuries.
The device may be connected to the power supply only during operation. After use, disconnect the device from the power supply by removing the plug from the mains socket. Do not leave the connected device unattended.
Fill the product with milk by pouring it into the frother. Never immerse the frother in milk or any other liquid. If, while filling the frother with milk, it is splashed on the outside of the frother or on the base, dry it thoroughly before connecting the frother to the power supply.
Do not start the product without milk. The minimum milk level is approx. 1 cm from the bottom of the frother. The milk must completely cover the heater. There are also two maximum surface indicators inside the frother. A lower one for frothed milk and a higher one for only heated milk. The maximum level should not be exceeded depending on how the frother is used.
Too low a milk level may damage the device or prevent it from starting.
Too high a level may cause milk to overflow from the frother while heating or frothing, which could cause serious burns.
Warning! Do not remove the cover while the device is operating.
Always close the lid when using the frother. After use, high-temperature condensed steam may accumulate under the lid.
EN
Contact with it may cause burns.
Note! The lid must be positioned so that steam escapes away from the handle.
The device has been designed for home use and is not to be used in commercial applications, e.g. catering establishments.
It is forbidden to repair, disassemble or modify the device yourself. All repairs to the product must be carried out by an authorized repair center.
The device is not intended for use by children under 8 years of age or by persons with reduced physical or mental capabilities or persons lacking experience and knowledge of the device. Unless they are supervised or instructed on how to use the device in a safe manner so that the associated risks are understood. Children should not play with the device. Children should not clean or maintain the device without supervision.
Do not use aggressive substances, solvents, caustic agents, alcohol, gasoline or abrasive agents to clean the device.
Unpack the product, removing all packaging elements. Unwind the cable. Place the base according to the instructions.
Before first use, wash the frother according to the instructions in the product maintenance section.
Frothing and heating milk
The milk can be frothed at the temperature at which it was poured into the frother or it can be additionally heated while frothing.
Remove the frother cover and pour in the milk. The milk level must not exceed the lower mark on the inner wall. Install the cover and place the frother on the base. Connect the power cable plug to the socket and use the switch on the control panel to select the appropriate frothing method. To start the device, press the switch, and subsequent presses of the switch allow you to choose between different frother modes using the appropriate stirrers:
- mode 1 - warm milk froth with a stable consistency (frothing stirrer);
- mode 2 - hot chocolate (frothing stirrer + hot chocolate stirrer);
- mode 3 - warm milk with delicate froth (frothing stirrer) or warm milk without froth (standard stirrer);
- mode 4 - cold thick foam (foaming mixer).
The selection of a given mode will be confirmed by the lighting up of the indicator light with the symbol of the given operating mode.
Capacity Markers
Capacity marks are located inside the frother and indicate the required capacity level when using the selected
EN
mixer:
MIN - means minimum capacity;
lower MAX - indicates the maximum capacity when using the frothing mixer;
upper MAX - indicates the maximum capacity when using the regular mixer.
After finishing work in any mode, the frother will turn off automatically. Lift the frother from the base by grasping only the handle.
Remove the cover and pour the milk out of the frother. Disconnect the power cord plug from the wall outlet.
After use, allow the product to cool down.
Note! Manually pressing the switch used to start the device will end its operation at any time.
MAINTENANCE, TRANSPORT AND STORAGE
Product maintenance
Since the appliance is used to prepare milk for consumption purposes, it is necessary to keep it clean and perform regular maintenance.
NOTE! All maintenance operations must be carried out with the device powered off. To do this, remove the power cable plug from the mains socket.
WARNING! The device or its base must not be immersed in water or any other liquid. The device or its base must not be washed under running water, in dishwashers or with high-pressure water.
NOTE! Before starting maintenance, wait until all components of the appliance have cooled down completely. Do not speed up the cooling process by filling the frother with cold water.
For cleaning, use a mild dishwashing detergent. Remove any remaining solution with a cloth soaked in water (base and outside of the frother) or by filling it with water several times (interior of the frother). After cleaning, wipe the product dry or leave to dry.
The stirrers and the lid, after being removed from the frother, can be washed under a stream of lukewarm running water using dishwashing liquid.
The frother should be cleaned after each use and it is recommended to do this immediately after cooling or after use if the heater has not been used. Milk residue is easier to remove before it has time to dry.
Storage and transportation of the device
During storage, store the device in closed rooms, protect it from dust, dirt and moisture. It is recommended to store the device in the factory packaging.
Store the device in its working position. Do not stack devices in layers. Do not place anything on the device during storage.
Transport the device in its original packaging. Protect it from excessive shock during transport. Do not place anything on the device during transport.
TECHNICAL DATA
| Parameter Unit of measurement Value | ||
| Catalogue number 68471 | ||
| Nominal voltage [V~] 220 - 240 | ||
| Nominal frequency [Hz] 50 - 60 | ||
| Rated power [W] 500 | ||
| Capacity for frothing milk [ml] 150 | ||
| Capacity for heating milk [ml] 300 | ||
| Net weight [kg] | 0,8 |
