USER MANUAL HG07875A Livarno Lux

100% FSC www.fsc.org RECYCLED Packaging made from recycled material FSC® C153805

IAN 498846_2204

LED CEILING LIGHT

LED плафон

Assembly, operating and safety instructions

LED STROPNÉ SVIETIDLO

Before reading, unfold the two pages with the illustrations and then familiarise yourself with all the functions of the unit.

GR

Blank grid paper with uniform black lines on white background, no text or symbols present

12 BG

Blank grid paper with no text, numbers, or symbols

EDI Light Service Center

Kleinbahnstraße 35

E: [e-mail]

Österreich

EDI Light Service Center

Heiligkreuz 22

6136 Pill, ÖSTERREICH

T: [phone]

E: [e-mail]

Schweiz

EGLO Schweiz AG

Seetalstraße 142

6032 Emmen, SCHWEIZ

T: [phone]

E: [e-mail]

De anvendte piktogrammers legende.... Side 30

Indledning ...... Side 30

Blank grid paper with uniform black lines on white background, no text or symbols present

36 DK

Diagram illustrating LED and 250V light interaction with a lamp, showing light source, lens, and output light.

EE-10143 TALLINN, ESTONIA

T: [phone]

E: [e-mail]

44 EE

250V LED LED

Installation Page 65

List of pictograms used ...... Page 70

Introduction Page 70

Intended use Page 71

Scope of delivery ...... Page 71

Parts description ...... Page 71

Technical data Page 71

Safety Page 71

Preparation Page 73

Starting up Page 73

You will need the following tools and materials ...... Page 73

Installing the lamp Page 73

Inserting / replacing batteries (remote control) Page 74

Maintenance and cleaning Page 74

Disposal Page 74

Declaration of conformity ...... Page 75

Service address Page 75

List of pictograms used*
	Read the instructions!		Observe the warnings and safety information!
	Safety notesInstructions for use		Caution! Danger of explosion!
	This light is only suitable for indoor use in dry and enclosed spaces.		Danger to life and risk of accidents for infants and children!
	Volts (AC voltage)		Warning! Danger of electric shock!
	Hertz (frequency)
	Watts (effective power)		Caution: hot surfaces
	Colour rendering index of LED lighting		Lumen
	Cannot be dimmed using an external controller.		Protection class I
	How to behave correctly!		Protection class II (Driver)
tc	Housing temperature at stated point		Dispose of the packaging and de-vice in an environmentally friendly manner!
	Product complies with the product-specific applicable European directives.
	LED control gear can only be specialist to replace		Packaging from responsible Sources
			TÜV SÜD / GS certified
	LED light source can only be replaced by the specialist		Wear protective gloves
	Polarity output	* Further details, e.g. additional symbol explanations or related information samples for device components, etc.

* Further details, e.g. additional symbol explanations or technical information, can be found at www.edi-light.com

LED ceiling light

Introduction

Congratulations on your purchase of an LED panel with flowing colour effects! (Sometimes referred to below as "the

product"). You have chosen a high-quality product. Please read this user manual right through carefully. Start by unfolding the pullout sheet with the diagrams. This manual constitutes part of the product and

includes important information for getting the product ready to use and operating it. Read all the safety information carefully. Before you use the product for the first time, make sure that the voltage is correct and all parts are correctly installed. If you have any questions or are unsure about using the product, please get in touch with your retailer or service centre. Store this manual carefully and pass it on to third parties if necessary.

PDF ONLINE www.1idi-service.com

Scan the QR code or download the complete operating instructions at www.lidl-service.com.

Intended use

This product is only suitable for use in indoor, dry and enclosed areas. This product is only intended for private household use.

Scope of delivery

When you unpack the product, check straight away that no parts are missing or defective.

1 LED ceiling light

1 set of mounting material

(4 dowels, 4 Phillips screws)

1 installation and user manual

Teilebeschreibung

1 Lamp base

2 Screws for attaching lamp (4 pcs.)

3 Wall plugs (4 pcs.)

4 Lustre terminal for installation box

5 LED ceiling light

Technical details

Item number: 56233

Operating voltage: 220-240V\~, 50/60Hz

Appliance class: 1 /

Total power: 60W

Total power: IP20

LED light source: 53W, 6200 Lumen (360°), 2700-6500K;

Dimensions: ∅ 760mm,

battery type

(Remote control): 2 x AAA; 1,5V; LR03

Diagram illustrating LED lighting process with labeled components and directional arrows

LED control gear can only be specialist to replace

LED light source can only be replaced by the specialist

Marketed by:

EDI Light GmbH,

Heiligkreuz 22,

6136 Pill,

AUSTRIA

www.edi-light.com

Safety

WARNING! DANGER TO LIFE AND RISK OF ACCIDENT FOR INFANTS AND CHILDREN!

Never leave children unattended with the packaging material - they can suffocate themselves. Children often underestimate the risks. The packaging material is not a toy.

This product is not a toy; please keep out of reach of children. Children are unaware of the dangers involved in handling the product.
The product is not a toy and should not be given to children. Children are not capable of recognising the dangers associated with the product.
This product can be used by children aged 8 years and over and by people with limited mental, sensory or intellectual capacities, or by people without relevant experience and knowledge, provided they understand or have been briefed about safe use of the product and the associated risks. Children may not play with the product. Children may not carry out cleaning and maintenance activities without supervision.

Avoid the risk of fatal injury from electric shock

Safety

We assume no liability for property damage or personal injury due to improper handling or failure to observe the safety information!
- Have electrical installation performed by a trained electrician or a person trained to perform electrical installations.
Please do not use the lamp if it is damaged in any way.
■ Remove the fuse or switch off the circuit breaker (0 setting) in the fuse box prior to installation.
■ Never let the lamp come into contact with water or other liquids.
Before installing, ensure that the available mains voltage matches the operating voltage required by the light.
Be sure not to damage any wires during installation.
■ Never open the lamp casing or insert objects into it. Actions of this kind may cause a fatal electric shock.
If the lamp glass is broken, replace it immediately with a new one. The service centre will be happy to help you.
Please use only the parts provided by the manufacturer.
Do not install the lamp on a damp or conductive surface!

The LED lamp cannot be dimmed with an external controller.

Prevent fire and injury hazards

CAUTION: HOT SURFACES – RISK OF BURNING To avoid burns, make sure that the light is switched off and has cooled

down before you touch it. Lamps can get very hot.

Do not look directly into the light source (light bulb, LED, etc.). Do not look at the light source (light bulb, LED, etc.) through an optical instrument such as a magnifying glass.

Dos and don'ts:

Please install the lamp in such a way that it is protected from moisture and dirt.
Pay close attention at all times! Always be mindful of what you are doing and act sensibly at all times.

Do not mount the lamp if you are unable to concentrate or feel unwell.

Safety instructions for batteries / rechargeable batteries

	Do not recharge battery
	Do not deform or damage batteries
	Do not throw battery into fire
	Do not insert battery incorrectly
	Keep battery away from small children
	Do not mix batteries of different brands or types
	Mix unused and new batteries
	Do not open battery
	Do not bring the battery into contact with metallic objects; Danger of short circuit
	Insert batteries correctly +/-
	Do not dispose of in water

DANGER TO LIFE! Keep batteries / rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.

Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.

DANGER OF EXPLOSION! Never recharge non-rechargeable batteries. Do not short-circuit batteries /

rechargeable batteries and / or open them. Overheating, fire or bursting can be the result.

• Never throw batteries / rechargeable batteries into fire or water.
• Do not exert mechanical loads to batteries / rechargeable batteries.

Risk of leakage of batteries / rechargeable batteries

• Avoid extreme environmental conditions and temperatures, which could affect batteries / rechargeable batteries, e.g. radiators / direct sunlight.
  If batteries / rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES!

Leaked or damaged batteries / rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

In the event of a leakage of batteries / rechargeable batteries, immediately remove them from the product to prevent damage.

Only use the same type of batteries / rechargeable batteries. Do not mix used and new batteries / rechargeable batteries.

■ Remove batteries / rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

■ Only use the specified type of battery / recharge-able batteryl
Insert batteries / rechargeable batteries according to polarity marks (+) and (-) on the battery / rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery / rechargeable battery and in the battery compartment before inserting!

■ Remove exhausted batteries / rechargeable batteries from the product immediately.

● Preparation

Starting up

Remove all parts of the lamp from the box and discard the packaging material. Check all parts for any visible damage. Do not install the lamp if you detect any visible damage. Contact our service department instead.

You will need the following tools and materials

The specified tools and materials are not included. The information and values specified are non-binding and are only provided as a reference. The nature of the material is determined by the specific local conditions.

• pencil/marking tool
• two-pole voltage tester
• Phillips screwdriver
• electric drill
• drill bit (diameter approx. 6 mm)
• wire cutters
• ladder

Installing the lamp

DANGER OF ELECTRIC SHOCK!

Note: Remove all packaging material from the product.

☐ Detach the base of the lamp from the cover by opening the catches on either side. (see fig. A and B).
☐ Use the holes provided in the base of the lamp for the screws to mark where you need to drill the holes. (see fig. C)
Now drill holes for attaching the lamp to a depth of approx. 30mm. Make sure that you do not damage the power supply cable. (see fig. D)
☐ Insert the wall plugs into the drilled holes and attach the base of the lamp with the screws provided (see fig. E).
☐ Connect the mains cable (external) to the LED ceiling light using the lustre terminal (see fig. F).

☐ Make sure that you connect each individual wire of the mains cable (external) correctly: live wire, black or brown = symbol L; neutral wire, blue = symbol N; earth wire, green and yellow = symbol 12 (see fig. F) Place the cover on the lamp base and secure it with the catches. (see fig. G)
☐ Replace the fuse or switch on the circuit breaker in the fuse box (I position) (see fig. H).
☐ Your LED ceiling light is now ready for use.

- Inserting / replacing batteries (remote control)

Note: The batteries are included in the scope of delivery and must be inserted prior to the first use.

☐ If the range of the remote control reduces, the batteries need to be replaced. To do this, remove the battery compartment cover from the remote control in the direction of the arrow.
☐ Remove the batteries and insert the new batteries The battery type is specified in the chapter "Technical data".

Note: The correct polarity is indicated in the battery compartment.

☐ Replace the battery cover on the battery compartment.

The remote control is now ready to use.

● Maintenance and cleaning

Disconnect the light from the power supply before cleaning. To do so, remove the fuse or switch off the circuit breaker in the fuse box (0 setting)

Disposal

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and

numbers (b) with following meaning: 1–7: plastics / 20–22: paper and fibre-board / 80–98: composite materials.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is

valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

When your product reaches the end of its life, please consider the environment and do not throw it into your general waste: instead,

dispose of it properly. You can find out about disposal facilities and their opening times from your local council or administration. Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries / geable batteries!

Batteries / rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries / rechargeable batteries at a local collection point.

The adjacent symbol of a crossed-out wheeled garbage can indicate that this device is subject to Directive 2012/19/EU.

This directive states that you must not dispose of this device with normal household waste at the end of its service life, but must take it to specially set up collection points, recycling centers or disposal companies. This disposal is free of charge for you. Protect the environment and dispose of it properly.

Declaration of conformity

CE

This product complies with the requirements of the applicable national and European directives. Declarations and

documentation to this effect are available with the manufacturer. The product complies with the requirements of German safety legislation for equipment and products.

We reserve the right to make technical changes and modifications to the appearance of the item in the course of our product improvement process. Typing errors and misprints reserved.

This product contains a light source of energy class F.

Service addresses

Great Britain & Ireland

EGLO UK LTD.

Unit 12 Cirrus Park, Lower Farm Road, Moulton Park Industrial Estate, NORTHAMPTON NN3 6UR

T: [phone]

E: [e-mail]

Hungary - Production & Logistics

EGLO MAGYARORSZAG KFT.

Fő út. 155

H-3060 PASZTO

T: [phone]

E: [e-mail]

100 HU
