USER MANUAL PGG 15 G6 PARKSIDE

Operation and safety notes

Translation of the original instructions

FR BE

GRAVEUR

Authorised Signatory

DE

CE

26 DE/AT/CH

Warnings and symbols used .... Page 28

Introduction Page 29

Intended use.... Page 30

Scope of delivery.... Page 30

Description of parts ...... Page 31

Technical data Page 31

Safety instructions.... Page 33

General power tool safety warnings .... Page 33

Safety warnings specific for carving operations ..... Page 39

Operation...... Page 41

Switching on and off Page 41

Setting the stroke depth ...... Page 41

Changing the engraving tips ...... Page 42

Working procedures ...... Page 42

Cleaning and maintenance ...... Page 43

Cleaning. Page 43

Maintenance Page 43

Storage Page 44

Disposal Page 44

Warranty Page 45

Warranty claim procedure.... Page 46

Service.... Page 46

EC declaration of conformity.... Page 47

Warnings and symbols usedThe following warnings are used in this user manual and on the packaging:
	Read the instruction manual.
	WARNING! This symbol in combination with the signal word “Warning” marks a medium-risk hazard that if not prevented could result in death or serious injury.
	CAUTION! This symbol in combination with the signal word “Caution” marks a low-risk hazard that if not prevented could result in minor or moderate injury.
	ATTENTION! This symbol with the signal word “Attention” indicates a possible property damage.
	NOTE: This symbol in combination with “Note” provides additional useful information.
	Alternating current/voltage
	Symbol for a Protection Class II product (double insulation)
	Danger - risk of electric shock!
	Wear ear protection!
	Wear eye protection!
	Wear dust protection!
	Use the product in dry indoor spaces only.
	CE mark indicates conformity with relevant EU directives applicable for this product.
	Safety informationInstructions for use

ENGRAVING TOOL

● Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This engraving tool (hereinafter "product" or "electric tool") is designed for engraving or decorating materials such as metal, plastic, glass, leather and stone.

Always use the correct accessory tools according to the intended use! Observe the technical requirements of this product (see "Technical data") when purchasing and using accessory tools!

Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage. The manufacturer is not liable for any damages caused by improper use. The product is not intended for commercial or similar uses.

- Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 Engraving tool PGG 15 G6
4 Engraving templates
1 Instruction manual

• Description of parts

(Fig. A)

1 On/off switch
2 Carrying lug
3 Power cord and power plug
4 Engraving tip
5 Engraving tip lock
6 Stroke rate control

(Fig. B)

7 Engraving templates

- Technical data

Rated voltage: 230 V\~, 50 Hz

(Alternating current/voltage)

Rated current: 0.16 A

Stroke rate: 6000 min -1

Weight: approx. 380 g

Protection class: II / ☐

NOTE

Do not use the product for more than 30 minutes. An appropriate power off time (up to a few hours) is necessary before the next usage.

Noise emission value

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the product is typically as follows:

Sound pressure level: L _pA = 67.4 dB(A)

Uncertainty: K _pA = 3 dB

Sound power level: L _WA = 78.4 dB(A)

Uncertainty: K WA = 3 dB

Total vibration value

Vibration emission value a_h : 0.4 m/s 2

Uncertainty K: 1.5 m/s ^2

WARNING!

Wear hearing protection!

NOTE

The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

WARNING!

The vibration and noise emissions during actual use of the product can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed. Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the product is switched off and when it is running idle in addition to the trigger time).

Safety instructions

- General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "electric tool" in the warnings refers to your mains-operated (corded) electric tool or battery-operated (cordless) electric tool.

Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

● Safety warnings specific for carving operations

a) Do not use the product for more than 30 minutes.

b) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

c) This power tool is intended to function as a carving tool. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

d) Wear personal protective equipment. Depending on application, use face shield, safety goggles or safety glasses. As appropriate, wear dust mask, hearing protectors, gloves and workshop apron capable of stopping small abrasive or workpiece fragments. The eye protection must be capable of stopping flying debris generated by various operations. The dust mask or respirator must be capable of filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss.

e) Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation.
f) Position the cord clear of the spinning accessory. If you lose control, the cord may be cut or snagged and your hand or arm may be pulled into the spinning accessory.
g) Never lay the power tool down until the accessory has come to a complete stop. The spinning accessory may grab the surface and pull the power tool out of your control.
h) Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electrocution or shock.

Operation

- Never use the product for other purposes and only original parts/accessories. Using attachments or accessory tools other than those recommended in the operating instructions can lead to a risk of injury.

- Switching on and off

■ Connect the power plug 3 with a power outlet.

• Hold the product firmly with one hand, in the same way you would hold a pen.
  ■ Switching on: Set the on/off swi1 to position I with your other hand.
  ■ Switching off: Set the on/off swi1 to position ●.

WARNING!

▶ Never run the product unattended.
Always switch off the product and disconnect the power plug 3 from the power outlet while the product is not in use.

- Setting the stroke depth

- You can use the stroke rate control 6 to adjust the depth of the engraving. A low setting is usually sufficient for the most common applications.

■ Increasing the stroke depth: Turn the stroke rate con 6 towards +.

■ Decreasing the stroke depth: Turn the stroke rate con6 towards -.

● Changing the engraving tips

CAUTION! RISK OF INJURY!

Switch the product off and remove the power p3 before commencing any work to the product.

- Change the engraving 4 as soon as it becomes worn and no longer delivers the desired engraving results. Turn the engraving tip lock 5 anticlockwise until the engraving tip 4 can be removed.

■ Remove the spring and washer.

■ Slide the washer and spring onto a new engraving ^4 . Then insert it into the product and turn the engraving tip lock ^5 clockwise to lock the tip.

■ Ensure that the engraving 4 is fixed correctly in place.

- Working procedures

You can use the product to create imaginative and unique engravings. For example, you can permanently mark valuable items. You can engrave numbers and letters onto metal, glass, wood, plastic, ceramics, stone and leather. To do this, use the supplied engraving templates 7.

- Hold the product at an angle, in the same way you would hold a pen.

- Your arm should be resting on the table.

■ Move the engraving 4 over the workpiece while applying gentle pressure. To find out the ideal engraving speed, practice on a spare piece of material.

NOTE

The supplied engraving 4 is made of tungsten steel. It is therefore not suitable for engraving electronic media such as CDs, DVDs, etc. These materials and their readability could be damaged.

● Cleaning and maintenance

Cleaning

WARNING! RISK OF INJURY!

Always remove the power p3 from the power outlet before all maintenance and cleaning work on the product.

■ Remove all dirt from the product. Use a dry cloth to do this.

Maintenance

WARNING!

Have the product repaired by the service centre or a qualified electrician and only using genuine replacement parts. This will ensure that the safety of the product is maintained.

Always ensure that the power p3 or the power cord 3 is replaced only by the manufacturer of the product or by an approved customer service provider. This will ensure that the safety of the product is maintained.

Storage

■ Store the product in a dry indoor location protected from direct sunlight, preferably in its original packaging.

● Disposal

The packaging is made of environmentally friendly materials, which may be disposed of through your local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

FR + 1 + 1

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your wornout product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.

● Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase.

Should this product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

● Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 418494_2210) available as proof of purchase.

You will find the item number on the rating plate, an engraving, on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB

Service Great Britain

Tel.:[phone]

E-Mail:[e-mail]

IE

Service Ireland

Tel.:[phone]

E-Mail:[e-mail]

EC declaration of conformity

EC DECLARATION OF CONFORMITY

IANI

418494_3210

Product Identification

"Parkside" Engraving Unit

Model Number:

19019375

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation.

Directive 2006/42/91C

Directive 2004/30/91U

Directive 2011/95/91U

References, to the relevant harmonised standards used or references to the other testisical specifications in relation to which conformity is declared:

INa / Parts

Directive 3004/42/1C

Directive 2004/30/1U

EN 55014-2: 2017/04/11:2010

EN 55014-2: 2015

EN 61000-3-2: 2019

EN RC 61000-3-2: 2019

EN 61000-3-3: 2013/9.2:2019

The object of the declaration described above is in conformity with Directive 2011/05/EU of the European Parliament and of the Council of N June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

HP / Parts

Direction: 2015/NEV/VU

EN EC 63000: 2018

Additional information - Further related standards

N° / Porto

PPF 13013A: 2019

EN ISO 12100-2018

Keeper of the technical documentation: OWild GmbH & Co.KQ

Signed for and on behalf;

This declaration of conformity is bound and/or the role responsibility of the manufacturers.

Translation of the original declaration of a conformation

Hackwahme

Place

21.12.3822

Duke

Berkswagen Streets

Managing Director

88a. Fudan 89a. Jahn Bauschheim

Authorized Signatory

GB

CE

DÉCLARATION DE CONFORMITÉ CE

SAN:

418994_2210

Directive 2008/42/16

Directive 2014/10/10

Directive 2013/5/10

⚠ WAARSCHUWING! RISICO OP LETSEL!

"Turkside" GRAVEERAPPARAAT

Modellnummer:

NO0379

Directive 2006/4/21/EC

Directive 2014/7/30/EU

Directive 2015/9/31/EU

Author/stand Signatory

CE

Flattel plausinthe protellizen's insult

Rockaryalini

Mistur

21.12.2022

Datum

Berjamin Street

Managing Director

88a. Fudha 88a. Fudha

Authorised Signatory

a

CE

134 CZ

Directive 2006/N1/EIC

Directive 2004/30/EU

Directive 2001/N5/EU

Bargarnie Smith Managing Director

gga. Budra

Authorised Signatory

No. / date

Directive 2011/05/1U

EN EC 63000-2018

Väterligere oplyninger - Väterligere relatarede standarder:

N° / Parts

PPP 1301.8A: 2019

EN ISO 12100-2010

Overactions of original maintenance and testing

Metrarsden

Shed

21.37.2022

Date

Bajekarnish Steels

Managing Director

88a. Fudra Jouw Jieh Buchheim

Authorised Signatory

DE

CE

Directive 2026/42/TC

Directive 2014/30/EU

Directive 2011/51/EU

Bemoglobin Steels Managing Director

88a. Fudha 89a. Jap. Buchhausen

Authorised Signatory

Negotovost: K _pA = 3 dB

Nivo zvočne moči: L _WA = 78,4 dB(A)

Negotovost: K WA = 3 dB

Pooblaščeni serviser:

OWIM GmbH & Co. KG

Stiftsbergstraße 1

74167 Neckarsulm

NEMČIJA

Directive 2006/42/81C

Directive 2014/90/81J

Directive 2011/95/81J

Mitaravija na opazibjere harmonistruo standante di Mitaravija na druga taborišne specifikacije e svizi s skladnostja. Vi je navedena e izjani.

Sr. / Data

Directive 2006/42/EC

Directive 2014/30/EU

EN 15014-1: 2017/A11:2020

EN 15018-2: 2015

EN 61000-3-2: 2019

EN IIC 61000-3-2: 2019

EN 61000-3-3: 2015/A1:2019

Da Institute for the purpose of which is a subject to the information obtained.

Normal setting space is broadband

Nordansulme

King

五日2023

Status

Bunjamid Steeri

Managing Director

88a. Budra Bou J. Buchheim

Authorised Signatory

CE

Korištene upozoravajuće napomene i simboli.... Stranica 263

Uvod. Stranica 264

Uvjeti korištenja .... Stranica 265

Directive 2006/4Q/1C

Directive 2014/3Q/1U

Directive 2015/4V/1U

Berifarpin Street Managing Director

88a. Fudra

Authorised Signature

NO

CE

Directive 2016/12/14

Directive 2014/10/14

Directive 2013/15/14

April/September

October 2011/05/18

17th 9C £3000: 2018

Authorized Signatory

GR

CE
