USER MANUAL PPKSA 40-Li B2 PARKSIDE

Translation of the original instructions

NL BE

Accu-kettingzaag

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Recyclingsymbol: Wellpappe

Scope of delivery/accessories. 37

Overview. 37

Description of functions. 38

Technical data. 38

Safety information. 39

Meaning of the safety information. 39

Pictograms and symbols. 40

General Power Tool Safety
Warnings. 41

General Chain Saw Safety
Warnings. 44

Additional safety instructions.....45

Causes and Operator Prevention of Kickback. 45

Residual risks. 46

Preparation. 46

Safety devices. 46

Checking the battery charge level. 47

Charging. 47

Charging the battery. 47

Operation. 48

Before operation. 48

Inserting and removing the battery. 49

Switching on and off. 49

Overload indication. 50

Checking the charge status of the battery in the tool. 50

Changing the chain speed. 50

Mounting the saw chain and blade bar. 50

Changing the saw chain and blade bar. 50

Installing the saw chain and blade bar. 50

Tensioning the saw chain. 51

Sawing techniques. 52

Parkside app. 55

Removed the device from the app. 55

Privacy policy. 55

Cleaning, maintenance and storage. 56

Cleaning. 56

Maintenance. 56

Storage. 59

Transport 59

Troubleshooting. 59

Disposal/environmental protection. 60

Disposal instructions for rechargeable batteries. 61

Service. 61

Guarantee. 61

Repair service. 62

Service Centre. 63

Importer. 63

Spare parts and accessories......63

Translation of the original EU declaration of conformity. 64

Exploded view. 349

Introduction

Congratulations on purchasing your new cordless chainsaw (hereafter referred to as device or power tool). You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device. In some cases, residual amounts of lubricants may be present on or in the device. This is not a flaw or a defect and is no cause for concern.

The instruction manual forms part of this device. It contains important

information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following use:

• Sawing wood

The device is not intended for any other types of application. This typically includes cutting masonry, plastic, stone, metal, food or wood containing foreign objects (e.g. nails or screws). The device is intended for use by adults. Children under the age of 16 may not use the device, except under supervision.

The chainsaw may only be used by one person. The user must wear appropriate personal protective equipment (PPE). The chainsaw must be held with the right hand on the rear handgrip and the left hand on the front handgrip.

Before using the device, the user must read and understand all information and instructions in the instruction manual.

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial

use. The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

The device is part of the

X 20 V TEAM series and can be operated with batteries of the X 20 V TEAM series. Batteries of the X 20 V TEAM series may only be charged using chargers of the X 20 V TEAM series.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

• Cordless Chainsaw
• Blade bar (pre-assembled)
• Saw chain (pre-assembled)
• Chain guard
• Oil bottle (180 ml Organic saw chain oil)
• Original instructions

Batteries and charger are not included in delivery.

Overview

The illustrations for the device can be found on the front and back fold-out page.

Fig. A

1 Rear handle
2 On/Off switch
3 Switch lock
4 Front handle
5 Chain brake lever/Front hand protection
6 Saw chain
7 Blade bar
8 Chain catch

9 Tank cover (Chain oil)
10 Sight line/Felling direction indicator
11 Oil level indicator
12 Wing nut (Sprocket cover)
13 Chain tensioner screw
14 Sprocket cover
15 Rear hand protection
16 Chain guard
17 Battery
18 Battery release
19 Button (Charge level indicator Battery)
20 Charge level indicator (Battery)
21 Charger
22 Oil bottle

Fig. B

23 Sprocket
24 Lug
25 Blade bar bolt
26 Chain tensioner pin
27 Receptacle (Chain tensioner pin)

Fig. E

28 Battery holder
29 Charge level indicator (Device)
30 Chain speed indicator
31 On/off button
32 Button (Chain speed)
33 "Connected" display

Fig. G

34 Indicator

Fig. H

35 Oil passage

Description of functions

The circulating saw chain is guided over a blade bar (guide rail). The chainsaw is equipped with a quick

stop chain brake. An automatic oil system ensures continuous chain lubrication. The chainsaw is also equipped with a chain quick-tensioning system. The device is provided with various protective devices to protect the user.

The device can be coupled with the Parkside App.

Please refer to the descriptions below for information on how the operating elements work.

Technical data

Cordless Chainsaw PPKSA 40-Li B2

Engine voltage U .... 40 V = ; (2x 20 V)
Engine current I 16 A
Chain speed v_0 ... 15 m/s bzw. 20 m/s
Chain speed v_ ... 25 m/s
Weight (without blade bar, chain, encasing, oil and batteries) 3.17 kg Tank capacity 180 cm
Blade bar ..M1431656-1041TL (Trilink)
- Blade bar type 16"
- Blade bar length . 45.5 cm (455 mm)
- Cutting length 38 cm (380 mm) Saw chain CL14356TL (Trilink)
-Chain pitch .9.525 mm (3/8")
-Chain spacing 10 mm
- Number of driving elements 56
- Drive link thickness 1.1 mm (0,043")
Chain sprocket pitch .9.525 mm (3/8")
-Number of teeth (chain sprocket) ... 6
Temperature max. 50^
-Operation . -20-50°C
- Storage 0 - 45 °C
Sound pressure level (L_pA) 90.5 dB; K_pA = 3 dB
Sound power level (L_WA)
Guaranteed 103 dB
- Measured ....99.8 dB; K_WA = 3.29 dB
Vibration (a_h) ....1.76 m/s2; K = 1.5m / s^2

Type of battery ...... Li-Ion PARKSIDE Performance Smart battery Smart PAPS 204 A1/ Smart PAPS 208 A1

• Operating frequency/Frequency band 2400 - 2483.5 MHz
• transmitted power ≤ 20 dBm

Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity.

The specified total vibration value and the stated noise emission value have been measured according to a standardised test method and can be used to compare one power tool with another. The specified total vibration value and the stated specified noise emission value can also be used for a provisional assessment of the load.

WARNING! The vibration and noise emissions may deviate from the specified values during actual use of the power tool, depending on how the power tool is being used. Try to keep the exposure to vibrations as low as possible. An example of a measure to reduce vibration exposure is limiting the working hours. All parts of the operating cycle have to be considered while doing so (for example, times when the power tool is switched off and times when it is switched on but running without any load).

X 20 V TEAM

The device is part of the X 20 V TEAM series and can be operated with batteries of the X 20 V TEAM series. Batteries of the X 20 V TEAM series may only be charged using chargers of the X 20 V TEAM series.

We recommend that you operate this appliance with the fol

lowing batteries only: PAP 20 A1,
PAP 20 A2, PAP 20 A3, PAP 20 B1,
PAP 20 B3, Smart PAPS 204 A1,
Smart PAPS 208 A1

Use of the device with the following batteries is prohibited: Smart PAPS 2012 A1

We recommend charging these batteries with the following chargers: PLG 20 A1, PLG 20 A2, PLG 20 A3, PLG 20 A4, PLG 20 C1, PLG 20 C3, PDSLG 20 A1, PDSLG 20 B1, PLG 201 A1, Smart PLGS 2012 A1 Rechargeable battery and charger technical data: See separate manual.

Safety information

This section deals with the basic safety instructions for using the device.

WARNING! Injury and property damage due to improper handling of battery. Observe the safety information and notes on charging and proper use as shown in the instruction manual for your battery and charger from the series X 20 V TEAM. A detailed description of the charging process and further information can be found in these separate operating instructions.

WARNING! A chainsaw is a dangerous piece of equipment that can cause serious or even fatal injuries if used incorrectly or carelessly. Therefore, for your safety and the safety of others, always observe the following safety instructions and ask an expert for advice if you are unsure.

Meaning of the safety information

DANGER! If you do not observe this safety instruction, an accident will

GB MT

occur. The result of which is severe bodily injury or death.

WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.

CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury. NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols

Symbols on the device

NOTICE! Familiarise yourself with all operating elements before starting work. Practise using the chainsaw and have an expert explain the function, mode of operation and sawing techniques to you.

Attention!

Read the instruction manual

Use eye protection

Use hearing protection

Use head protection

Wear protective clothing

Use protective gloves

Wear safety shoes with firm soles!

Always work with both hands!

Attention! Kickback - be aware that you may experience kickback while working with the machine.

Use of the device in the rain or a damp environment is prohibited.

Guaranteed sound power level L_WA in dB(A)

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

Saw chain oil

Remove the batteries before maintenance work!

Blade bar type

Chain brake

Note: Release chain brake before starting

Chain speed indicator

Setting the chain speed levels

Smart LED display

On/off button

Charge level indicator

Graphical symbol beneath sprocket cover

Observe direction of travel of the saw chain. Attention! Read the instruction manual.

Graphical symbol on blade bar

Blade bar type

Groove width

Chain pitch

Number of driving elements

Graphical symbol on mounting screw of sprocket cover

OPEN

CLOSE

Graphical symbol on chain brake lever

Chain brake: OFF

Chain brake: ON

Chain brake (activated/deactivated)

Symbol on screw for chain quick-tensioning system

loosen

tighten

Graphic symbol on packaging

Dispose of the packaging material properly.

Recycling symbol: Corrugated cardboard

General Power Tool SafetyWarnings

WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious in

jury. Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

1. WORK AREA SAFETY

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

2. ELECTRICAL SAFETY

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. PERSONAL SAFETY

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the

power tool in unexpected situations.

4. POWER TOOL USE AND CARE

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power

tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal

objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130^ may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.
6. SERVICE
a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.

General Chain Saw SafetyWarnings

• Keep all parts of the body away from the saw chain when the chain saw is operating. Before you start the chain saw, make sure the saw chain is not contacting anything. A moment of inattention while operating chain saws may cause entanglement of your clothing or body with the saw chain.
• Always hold the chain saw with your right hand on the rear handle and your left hand on the front handle. Holding the chain saw with a reversed hand configuration increases the risk of personal injury and should never be done.
• Hold the chain saw by insulated gripping surfaces only, because the saw chain may contact hidden wiring. Saw chains contacting a "live" wire may make exposed metal parts of the chain saw "live" and could give the operator an electric shock.
• Wear eye protection. Further protective equipment for hearing, head, hands, legs and feet is recommended. Adequate protective equipment will reduce personal injury from flying debris or accidental contact with the saw chain.
• Do not operate a chain saw in a tree, on a ladder, from a rooftop, or any unstable support. Operation of a chain saw in this manner could result in serious personal injury.

• Always keep proper footing and operate the chain saw only when standing on fixed, secure and level surface. Slippery or unstable surfaces may cause a loss of balance or control of the chain saw.

• When cutting a limb that is under tension be alert for spring back. When the tension in the wood fibres is released the spring loaded limb may strike the operator and/or throw the chain saw out of control.

• Use extreme caution when cutting brush and saplings. The slender material may catch the saw chain and be whipped toward you or pull you off balance.
• Carry the chain saw by the front handle with the chain saw switched off and away from your body. When transporting or storing the chain saw, always fit the guide bar cover. Proper handling of the chain saw will reduce the likelihood of accidental contact with the moving saw chain.
• Follow instructions for lubricating, chain tensioning and changing the bar and chain. Improperly tensioned or lubricated chain may either break or increase the chance for kickback.
• Cut wood only. Do not use chain saw for purposes not intended. For example: do not use chain saw for cutting metal, plastic, masonry or non-wood building materials. Use of the chain saw for operations different than intended could result in a hazardous situation.
• Do not attempt to fell a tree until you have an understanding of the risks and how to avoid them. Serious injury could occur to the operator or bystanders while felling a tree.
• Follow all instructions when clearing jammed material, storing or servicing the chain saw. Make sure the switch is off and

the battery pack is removed. Unexpected actuation of the chain saw while clearing jammed material or servicing may result in serious personal injury.

Additional safety instructions

• Follow the maintenance, control and service instructions in this instruction manual carefully. Damaged safety equipment and parts must be repaired or replaced professionally by our service centre, unless otherwise indicated in the instruction manual.
  It is recommended that a first-time user at least practice the cutting of logs on a saw log or frame.
• Lay the power cord so that it is not caught by branches or similar during sawing.
• For sawing work on slopes, always stand in the area above the log. To keep total control while "sawing through", reduce the pressure at the end of the cut without loosening your grip on the handles of the chainsaw. Make sure the saw chain does not touch the ground. After completing the cut, wait until the chainsaw has come to a stand-still before removing the chainsaw. Always shut off the motor of the chainsaw before switching between trees.
• Dirt, stones, loose bark, nails, clips and wires must be removed from the tree.
• Do not use any accessories that are not recommended by PARKSIDE. This can result in electric shock or fire.

Causes and Operator Prevention of Kickback

• Kickback may occur when the nose or tip of the guide bar touches an object, or when the wood closes in and pinches the saw chain in the cut (Fig. b).
• Tip contact in some cases may cause a sudden reverse reaction, kicking the guide bar up and back towards the operator (Fig. a).
• Pinching the saw chain along the top of the guide bar may push the guide bar rapidly back towards the operator.
  Either of these reactions may cause you to lose control of the saw which could result in serious personal injury. Do not rely exclusively upon the safety devices built into your saw. As a chain saw user, you should take several steps to keep your cutting jobs free from accident or injury.

Kickback is the result of chain saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below:

• Maintain a firm grip, with thumbs and fingers encircling the chain saw handles, with both hands on the saw and position your body and arm to allow you to resist kickback forces. Kickback forces can be controlled by the operator, if proper precautions are taken. Do not let go of the chain saw.

• Do not overreach and do not cut above shoulder height. This helps prevent unintended tip contact and enables better control of the chain saw in unexpected situations.

• Only use replacement guide bars and saw chains specified by the manufacturer. Incorrect replacement guide bars and saw chains may cause chain breakage and/or kickback.
• Follow the manufacturer's sharpening and maintenance instructions for the saw chain. Decreasing the depth gauge height can lead to increased kickback.

Residual risks

There will always be residual risks even if you operate this device according to the instructions. The following hazards may occur in connection with the type and design of this device:

• Hearing damage if suitable ear protection is not worn.
• Health injuries resulting from the effect of hand/arm vibration in the event that the tool is used over a longer period of time or is not used and maintained properly.
  Cutting injuries

WARNING! Danger due to electromagnetic field generated while the tool is in operation. Under certain circumstances, this field may negatively affect active or passive medical implants. In order to reduce the danger of serious or fatal injuries, we recommend that individuals who wear medical implants should consult their doctor and the manufacturer of the implant before operating the tool.

Preparation

WARNING! Risk of injury due to unintentional start-up. Only insert the battery into the device once the device is fully prepared for use.

Safety devices

The following safety devices are provided to protect the user and the device:

Rear handle (1) with rear hand guard (15)

• Protects the hand from branches, twigs and if the saw chain jumps off.

On/Off switch (2) with immediate chain stop

• The device switches off immediately once the on/off switch is released.

Switch lock (3)

• The switch lock must be unlocked in order to switch on the device.

Chain brake lever/front hand protection (5)

• The saw chain does not run when the chain brake is locked into place.
• Stops the saw chain immediately in the event of a kickback.
• Lever can also be operated manually.
• Protects the operator's left hand if it slips off the front handle.

Saw chain (6) with low kickback

• Helps to absorb kickbacks thanks to specially developed safety devices.

Chain catch (8)

Increases stability when making vertical cuts.
- Makes sawing easier.

Checking the battery charge level

LEDs Meaning

red, orange, green Battery charged

red, orange Battery partially charged

red Battery needs to be charged

1. Press the button (19) next to the charge level indicator button (20) on the battery (17).
   The LEDs of the charge level indicator show how much charge remains in the battery.
2. Charge the battery (17) when only the red LED on the charge level indicator (20) is illuminated.

Charging

WARNING! Injury and property damage due to improper handling of battery. Observe the safety information and notes on charging and proper use as shown in the instruction manual for your battery and charger from the series X 20 V TEAM. A detailed description of the charging process and further information can be found in these separate operating instructions. Warning! Risk of injury caused by leaking electrolyte solution! Do not expose the battery to extreme conditions such as heat and shocks. In case of contact with eyes or skin, rinse the affected sites with water or a neutralising agent and seek medical attention.

WARNING! Risk of injury from electric shock! Only charge batteries in dry rooms. The external surface of the battery must be clean and dry before being connected to the charger.

• Charge the batteries before using them for the first time.

Always comply with the latest safety information, as well as the regulations and information relating to environmental protection.

Charging the battery

See also the charger instruction manual.

Notes

If warm, allow the battery to cool before charging.
- Do not expose the battery to direct sunlight for long periods and do not place it on a radiator (max. 50^ ).

Charging the battery

1. Remove the battery (17) from the device.
2. Push the battery (17) into the charging slot of the battery charger (21).
3. Connect the battery charger (21) to a power outlet.
4. After charging, disconnect the battery charger (21) from the mains.
5. Pull the battery (17) out of the battery charger (21).

Control LEDs on the charger (21):

green red	Meaning
lights up	- • Battery	y is fully charged • stand-by (No battery inserted)
- lights up	Battery	is charging
- flashes	Battery is	over-heated
flashes	flashes	Battery is defective

Operation

Before operation

WARNING! Risk of injury! Always wear protective gloves while working with the saw chain and use only original parts.

You need to do the following before using the tool for the first time:

Tensioning the saw chain, p. 51
- Pouring in chain oil, p. 48
- Charge and insert both batteries
- Checking the chain brake, p. 48
- Checking the oil automation, p. 48

Checking the chain brake

NOTICE! The saw chain does not rotate when the chain brake is locked into place.

Procedure (Fig. G)

1. Place the chainsaw on a firm, level surface. It must not touch any objects.
2. Operate the chain brake lever (5).
3. Hold the tool firmly with both hands, with your right hand on the rear grip (1) and your left hand on the front grip (4). Your thumb and fingers must tightly clasp the grips.
4. Switch on the tool. A warning tone sounds. The indicator (34) for the inserted chain brake flashes.

The chain brake functions.

1. Release the on/off switch (2).

WARNING! Risk of injury from the trailing saw chain. Do not use the chainsaw if the chain brake does not work properly. Contact the service centre.

Checking the oil automation

Before starting work, check the oil level in the oil automation system.

Procedure

1. Hold the chainsaw over a lightcoloured surface. The chainsaw should not touch the ground.
2. Switch on the chainsaw. If a trace of oil appears, the chainsaw is working flawlessly. If there is no trace of oil, clean the oil passage or contact the service centre.

Cleaning the oil passage

Clean the oil passage (35) to ensure fault-free, automatic oiling of the saw chain during operation.

Tools and aids required

• Cloth
  Brush

Procedure (Fig. H)

1. Wipe out any residue from the oil passage (35). Use a cloth or brush for this.

Chain lubrication

NOTICE! If the chainsaw is used with too little oil, the cutting performance and lifespan of the saw chain will decrease as the saw chain will become blunt more quickly. You can recognise insufficient oil by the smoke development or discolouration of the blade bar. Make sure that there is always oil flowing onto the chain.

The tool is equipped with an automatic oil system. The oil flows to the blade bar (7) as soon as the motor starts operating.

CAUTION! Switch off the tool and remove the batteries before carrying out any maintenance work.

Pouring in chain oil

WARNING! Risk of fire! Always turn off the device and let the engine cool down before filling with chain oil.

• Check the oil level indicator (11) regularly and top up with oil once the "minimum mark" is reached.

The "minimum mark" is the lower line of the oil level indicator (11). The oil tank holds 180~cm^3

• Use bio chain oil containing additives to reduce friction and wear. Alternatively, use chain lubricating oil with a low proportion of adhesion additives.
• Empty the oil tank if it will not be used for a prolonged period of time (6-8 weeks).

Procedure (Fig. D)

1. Place the tool on its side with the fuel cap (9) facing upwards.
2. Unscrew the fuel cap (9).
3. Pour the bio chain oil into the tank.
4. Wipe away any spilt oil.
5. Screw the fuel cap (9) on.

Inserting and removing the battery

WARNING! Risk of injury due to unintentional start-up. Only insert the battery into the device once the device is fully prepared for use. NOTICE! Risk of damage! An incorrect battery can damage the device and battery.

Inserting the batteries (Fig. E)

1. Push the two batteries (17) along the guide into the battery holder (28).

You will hear the batteries click into place.

Removing the batteries (Fig. E)

1. Press and hold the battery release (18) on the battery (17).
2. Pull the batteries out of the battery holder (28).

Switching on and off

Requirements

• The blade bar (7), saw chain (6) and sprocket cover (14) are correctly fitted.
• Sufficient chain oil in the tank. Top up with chain oil if necessary (Pouring in chain oil, p. 48).
• Batteries are fully charged.
• The device may only be used with two batteries of the X 20 V Team series from Parkside.

Procedure (Fig. F)

1. If necessary, insert the batteries (17) into the device.
2. Release the chain brake by pushing the chain brake lever (5) against the front handle (4).
3. Hold the chainsaw firmly with both hands, with your right hand on the rear handle (1) and your left hand on the front handle (4). Your thumb and fingers must tightly clasp the handles.
4. Before starting, make sure that the chainsaw is not touching any objects.
5. To activate the device, first press the on/off button (31).

NOTICE! The device is in standby mode for approx. 5 minutes and must then be reactivated.

1. To switch on, press the switch lock (3) with your right thumb and then press the on/off switch (2). The chainsaw runs at maximum speed. Release the switch lock (3) again.
2. Release the on/off switch (2) to switch off the chainsaw. Continuous switching is not possible.
3. To deactivate the device, press the on/off button (31).

Overload indication

In case of overload, the red and yellow LEDs of the charge level indicator (29) flash.

Checking the charge status of the battery in the tool

Procedure

1. The charge level indicator (29) lights up during operation.

The charge level of the battery is indicated by illumination of the corresponding LEDs on the charge level indicator (29).

Red, orange and green Batteries charged

Red and orange Batteries partially charged

Red Batteries need to be charged

1. Charge the batteries (17) when only the red LED on the charge level indicator on the tool (29) is illuminated.

Changing the chain speed (Fig. E)

Pressing the button for chain speed selection (32) lets you switch between chain speeds 15 and 20m / s .

The chain speed indicator (30) shows you the chain speed at which the tool is currently operating by illuminating levels 1 or 2.

Level 1: 15m / s Level 2: 20m / s NOTICE! At Level 2, the chain speed is 25m / s if you use the tool with two 8 Ah performance batteries "Smart PAPS 208 A1".

Mounting the saw chain and blade bar

CAUTION! Cutting injuries! Wear cut-resistant gloves when working

with the saw chain or with the blade bar.

Procedure (Fig. B)

1. Switch off the tool and remove the batteries (17) from the tool.
2. Place the tool on a level surface.
3. Turn the wing nut (12) and chain tensioner screw (13) to loosen the chain tension and remove the sprocket cover (14).
4. Remove the blade bar (7) and saw chain (6): To remove the blade bar (7), hold it at an angle of approx. 45 degrees and swivel it upwards to make it easier to remove the saw chain (6) from the chain sprocket (23).

Changing the saw chain and blade bar

Prior to changing the saw chain, the groove of the guide rail must be cleaned of dirt because dirt deposits available can cause the saw chain to break out of the rail. The deposits can also absorb the chain oil. So the consequence would be that the chain oil would not or only a small part of it would reach the underside of the rail and the lubrication would be reduced.

Requirements

• Mounting the saw chain and blade bar, p. 50

Procedure

1. Replace the blade bar (7) and the saw chain (6).
2. Fit the blade bar (7) and saw chain (6) as described under Installing the saw chain and blade bar, p. 50.

Installing the saw chain and blade bar

CAUTION! Risk of injury due to unintentional start-up. Switch off the

machine. Remove the batteries from the tool.

Procedure (Fig. B)

1. Place the tool on a level surface.
2. Turn the wing nut (12) to remove the sprocket cover (14).
3. Spread out the saw chain (6) in a loop so that the cutting edges are aligned in a clockwise direction. Use the symbol below the sprocket (23) as a guide for aligning the saw chain (6).

Direction of travel by saw chain

1. Place the saw chain (6) in the blade bar groove. To assemble, hold the blade bar (7) tilted upwards at an angle of approx. 45 degrees in order to be able to guide the saw chain (6) more easily onto the sprocket (23).
2. Place the blade bar (7) and saw chain (6) on the blade bar bolt (25). If the lug ([24) is positioned to the right of the blade bar bolt (25) in the slotted recess on the blade bar, the blade bar is positioned correctly. It is normal for the saw chain (6) to sag.
3. Put the sprocket cover (14) back in position. The chain tensioner pin (26) on the inside of the sprocket cover (14) must be guided into the holder for the chain tensioner pin (27).
4. Tighten the wing nut (12) O slightly.
5. Pretension the saw chain (6) by turning the chain tensioner screw (13) U.
6. Tighten the wing nut (12) of the sprocket cover .

CAUTION! The chainsaw can be re-oiled. Please be aware that the chainsaw will regrease after use and

may leak oil if it is stored on its side or upside down. This is a normal occurrence and is caused by the ventilation opening on the top edge of the tank which is a necessary component; this is not grounds for complaint. Since every chainsaw is inspected and tested using oil during manufacture, a small amount of oil may remain in the tank after emptying, which may slightly dirty the housing during transport. Please clean the housing with a cloth.

Prior to changing the saw chain, the groove of the guide rail must be cleaned of dirt because dirt deposits available can cause the saw chain to break out of the rail. The deposits can also absorb the chain oil. The result would be that the chain oil does not reach the underside of the rail - or only does so to a limited extent - thereby reducing lubrication.

Tensioning the saw chain

NOTICE! Do not re-tension or change the saw chain when it is hot because it shrinks slightly once it has cooled down. If this is not observed it can lead to damage on the guide rail or the engine because the saw chain is now too taut on the blade bar.

Regularly tightening the saw chain provides safety for the user and reduces and/or prevents wear and chain damage. We recommend that the user check the chain tension before starting work and at intervals of approx. 10 minutes and correct it if necessary. The saw chain warms up when working with the saw and thus expands slightly. These "expansions" can be expected especially from newer saw chains.

Chain tension and chain lubrication have a significant impact on the service life of the saw chain. The chain

tension of a new saw chain must be readjusted after a maximum of 5 cuts. The saw chain is properly tensioned when it does not hang from the underside of the blade bar and cannot be moved around by a gloved hand. When pulling on the saw chain with 9N (approx. 1kg ) of force, the saw chain and blade bar should not be separated by a distance of more than 2mm .

CAUTION! Risk of injury due to unintentional start-up. Switch off the machine. Remove the batteries from the tool.

Procedure (Fig. C)

1. Make sure that the chain brake is released, i.e. the chain brake lever (5) is pressed against the front handle (4).
2. Undo the wing nut (12)
3. To tension the saw chain, turn the chain tensioner screw (13) . To loosen the tension, turn the chain tensioner screw (13) .
4. Retighten the wing nut (12) . The chain tension of a new saw chain must be readjusted after a maximum of 5 steps.

Sawing techniques

WARNING! Risk of injury! If the saw chain is jammed, do not try to pull the chainsaw out by force. Switch off the engine and use a lever arm or wedge to release the chainsaw.

• Always stand above the tree trunk when sawing on slopes.

• Remove dirt, stones, loose bark, nails, clips and wires from the tree.

• The saw chain must not touch the ground or any object while sawing through the material or thereafter.
• You will have better control over the device if you saw using the lower edge of the blade bar (saw chain in pulling direction) and not using the upper edge of the blade bar (saw chain in pushing direction).
• Ensure that the saw chain does not get stuck while sawing. The log must not break or splinter.
• Please observe the precautionary measures to protect against kickback (Causes and Operator Prevention of Kickback, p. 45)
• Reduce the contact pressure towards the end of the cut without loosening the firm grip on the chainsaw handles in order to maintain full control at the moment of "sawing through".
  After completing the cut, wait until the chainsaw has come to a standstill before removing it.
  Always switch off the chainsaw engine before moving from tree to tree.

Felling trees

WARNING! A lot of experience is needed to fell trees. Only fell trees if you know how to use the chainsaw safely. Never use the chainsaw if you feel unsafe.

CAUTION! Do not cut down a tree if there is a strong or changing wind, if there is a risk of damage to property or if the tree could hit power lines. When felling trees, ensure that no other persons are subject to hazards and that no material damage is caused. If a tree should come into

contact with a power line, the supply company must be informed immediately.

CAUTION! For safety reasons, we advise inexperienced users against felling a tree trunk with a blade bar length that is smaller than the trunk diameter.

• Please make sure that no other persons or animals are present in your work area. The safety distance between the tree to be felled and the nearest workplace must be 212 tree lengths.
• Pay attention to the felling direction. The user must be able to move around safely near the felled tree so that he can cut the tree to size and cut off all branches easily. The falling tree must be prevented from becoming entangled in another tree.
• Please note that the natural falling direction depends on the pitch and crookedness of the tree trunk, the wind direction, position of larger branches and the number of branches.
• Stay above the tree to be felled when sawing on a slope. The tree will probably roll or slide downhill after felling.
• Small trees with a diameter of 15-18 cm can usually be sawn off with one cut.
• For trees with a larger diameter, notch cuts and a felling cut must be applied (Fig. O).
• If cutting and felling is being carried out by two or more persons simultaneously, the distance between the felling and cutting persons must be at least twice the height of the tree to be felled.

Fold up the hearing protection immediately after finishing the sawing pro

cess so that you can hear sounds and warning signals.

Procedure

1. Limbing (Fig. T)

Remove branches hanging downwards by sawing from the top of the branch. Never saw off branches higher than shoulder height.

2. Escape area (Fig. N)

Remove the undergrowth around the tree to ensure an easy retreat. The escape area (1) should be offset by about 45^ behind the planned felling direction (2).

3. Cut drop notch (A) (Fig. O)

Place a drop notch in the direction in which you want the tree to fall. Start with the lower, horizontal cut. The cutting depth should be about 1/3 of the trunk diameter. Now make an oblique saw cut with a cutting angle of approximately 45^ from above, which meets the lower saw cut exactly. This prevents the saw chain or guide rail from jamming when the second notch cut is made.

WARNING! Never step in front of a tree that is notched.

4. Felling cut (B) (Fig. O)

Make the felling cut from the other side of the trunk. Stand to the left of the tree trunk and saw with the saw chain pulling (with the underside of the blade bar). The felling cut must be at least 5cm above the horizontal notch section. It should be deep enough so that the distance to the notch cutting line is at least 1/10 of the trunk diameter. The part of the log that has not been sawn through is called the hinge (felling bar). The hinge prevents the tree from turning and

falling in the wrong direction. Do not cut through this hinge. When the felling cut nears the hinge, the tree should begin to fall if it becomes apparent that the tree will not fall in the desired direction or if it bends back, and if the saw chain is stuck, discontinue the felling cut. Use wooden, plastic or aluminium wedges to open the cut and fell the tree to f into the desired fall line.

1. Slide a cutting wedge into the felling cut as soon as the cutting depth so permits, in order to prevent the blade bar from getting jammed (Fig. P).
2. If the trunk diameter is greater than the length of the blade bar, make two cuts (Fig. R).
3. Once the felling cut has been made, the tree falls by itself or with the help of the felling wedge.

WARNING! As soon as the tree starts to fall, pull the chainsaw out of the cut, stop the engine, put the chainsaw down and leave the workplace via the retreat path. Pay attention to falling branches and do not stumble.

Limbing

Limbing is the term for removing branches and twigs from a felled tree.

CAUTION! Risk of injury! Never saw off branches when you are standing on the tree trunk. Keep an eye on the kickback area when branches are under tension.

(Fig. M)

• Only remove support branches after cutting to length.

• Saw branches under tension from the bottom upwards to prevent the chainsaw from jamming.

• Use the same technique as for Cutting to length, p. 54 when sawing off thicker branches.

• Work to the left of the trunk and as close as possible to the chainsaw. If possible, the weight of the chainsaw should rest on the trunk.
• Change location to saw off branches beyond the trunk.
• Cut branched branches to length individually. Leave larger branches pointing downwards and supporting the tree for the time being.
• Separate smaller branches with one cut.

Cutting to length

Cutting to length means sawing felled tree trunks into small sections.

• Ensure that you have a secure footing and balance your body weight evenly on both feet.
• Support the trunk if possible. The trunk should be underpinned and supported by branches, beams or wedges.
• Make sure that the saw chain does not touch the ground when sawing.
• Stand above the trunk on sloping terrain.

Techniques for cutting to length

Trunk lying on the ground (Fig. I)

Saw all the way through the trunk from above, taking care not to touch the ground at the end of the cut. If it is possible to turn the trunk, saw through 2/3 of it. Then turn the trunk over and saw through the rest of the trunk from above.

Trunk is supported at one end (Fig. J)

First saw through 1/3 of the trunk diameter from bottom to top (with the top of the blade bar) to avoid splintering. Then saw from top to bottom

(with the underside of the blade bar) towards the first cut to avoid jamming.

Trunk is supported at both ends (Fig. K)

First saw through 1/3 of the trunk diameter from top to bottom (with the underside of the blade bar). Then saw from bottom to top (with the top of the blade bar) until the cuts meet.

Sawing on a sawhorse (Fig. L)

Hold the chainsaw firmly with both hands and guide the machine in front of your body while sawing. When the log is cut, guide the machine past the body on the right (1). Keep your left arm as straight as possible (2). Watch out for the falling trunk. Position yourself so that the severed trunk does not pose a hazard. Pay attention to your feet. The severed trunk could cause injuries if it falls. Keep your balance (3).

PARKSIDE app

The PARKSIDE app lets you monitor the device and control certain functions. The functions may change with updates to the app and firmware. For more information on the PARKSIDE app, see the instructions for the smart battery.

Requirements

To find the device in the PARKSIDE app, the following requirements must be met:

• The PARKSIDE app is installed on your smartphone and Bluetooth® is activated.
• The following battery is inside the device: PARKSIDE Performance Smart battery PAPS 204 A1 or PAPS 208 A1. This battery is already connected to the PARKSIDE app.

The device communicates with the app via the battery.

Connecting the device to the PARKSIDE app

1. Insert the smart batteries (17).
2. Press the on/off button (31).

The "Connected" display (33) flashes three times. When the device is connected, the "Connected" indicator lights up continuously.

1. Open the PARKSIDE app.
2. Your tools.

The device is displayed in the list. If the device does not appear in the list, add the device manually.

Monitoring and controlling the device

1. Your tools.
2. Select the device from the list. The device overview page is displayed.
3. Select the desired setting on the overview page.

Select help if you are unsure. A dialogue box with a description for the relevant setting is displayed.

Removed the device from the app

When a device is removed from the app, the associated data is also deleted.

1. Your tools.
2. Swipe the device's card from right to left.

1. Confirm the dialog box.

Privacy policy

see Page More; Section Legal, Privacy policy

Cleaning, maintenance and storage

Cleaning

WARNING! Electric shock! Never spray down the device with water.
WARNING! Risk of injury! Always switch off the motor and let it cool down, then remove the batteries before any cleaning work.
CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

NOTICE! Risk of damage. Chemical substances may attack the plastic parts of the machine. Do not use any cleaning agents or solvents.

Clean the machine thoroughly. This will extend the life of the machine and prevent accidents.

Cleaning after every use

• Keep the handles free of petrol, oil or grease. If necessary, clean the

handles with a damp cloth washed in soapy water.

• Clean the saw chain. Do not use any liquids to clean the saw chain. Lightly oil the saw chain with chain oil after cleaning.
• For cleaning, also remove the sprocket cover (14) so that this area can also be cleaned.
  Clean the blade bar (7)
• Clean the ventilation slits and the surface of the machine with a paintbrush or dry cloth.
• Clean the oil passage (35) to ensure fault-free, automatic oiling of the saw chain during operation. Use a brush or a cloth to help remove residues from the oil passage.

Maintenance

Service intervals

Carefully perform the maintenance tasks listed in the following table on a regular basis. Regular servicing of your device will extend its life. Additionally, you will achieve optimum cutting performance and prevent accidents.

Machine part Action Before		each use	After 10 hours of use	After each use
Chain brake components	Visual inspection, replace as needed	✓
Sprocket (23) Visual inspection, replace as needed		✓
Saw chain (6) Check saw chain, oil, reg-rind or replace if necessary		✓
Saw chain (6) Clean and oil the saw chain ✓
Blade bar (7) Servicing the blade bar, p. 58		✓		✓
Blade bar (7) Turning the blade bar, p. 58			✓
Automatic oil system	Check, clean oil passage if necessary	✓

Oiling the saw chain

CAUTION! Clean and oil the chain regularly. This keeps the chain sharp and achieves optimum machine performance. Damage due to insufficient maintenance of the saw chain will invalidate the warranty. Remove the batteries and use cut-resistant gloves when handling the chain or blade bar.

• Oil the chain after cleaning, after 10 hours of use or at least once a week, whichever comes first.
• Before oiling, the blade bar, especially the teeth of the blade bar, must be thoroughly cleaned. Use a hand brush and a dry cloth for this purpose.
• Oil the individual chain links using an oil syringe with a needle tip (available from specialist dealers). Apply individual drops of oil on the joints and on the tooth tips of the individual chain links.

Sharpening the cutting teeth

CAUTION! Risk of injury! An incorrectly sharpened saw chain increases the danger of kickback! Use cut-resistant gloves when working with the saw chain or with the blade bar. A sharp saw chain ensures optimum cutting performance. It effortlessly eats through the wood and leaves behind large, long wood chips. A saw chain is dull when you have to push the cutting equipment through the

wood and the wood chips are very small. With a very blunt saw chain, no chips are produced, only wood dust. Special tools are required for sharpening the saw chain to ensure that the chain is sharpened at the correct angle and to the correct depth. For inexperienced chainsaw users, we recommend having the saw chain sharpened by an expert or a specialist workshop. If you are confident that you can sharpen the chain, proceed according to the instructions for your saw chain sharpener (e.g. Parkside PSG 85 B2).

• The sawing parts of the saw chain are the cutting links, which consist of a cutting tooth and a depth gauge lug. The height distance between these two determines the sharpening depth.
• The saw chain is worn and must be replaced with a new saw chain when only approx. 4mm of the cutting tooth is left.

• The following values must be taken into account when sharpening the cutting teeth (Fig. Q):

• Sharpening angle (30^)

• Front angle (85^)
• Sharpening depth (0.65 mm)
• Round file diameter (4.0 mm)

WARNING! Risk of accident! Deviations from the dimensions of the cutting edge geometry can lead to an in

creased tendency of kickback by the machine.

Tools and aids required

• Round file
• Flat file

Procedure (Fig. S)

1. Switch off the device and remove the batteries.
2. Ensure that the saw chain is tightly tensioned to enable correct sharpening.
3. Only sharpen from the inside out. Guide the round file from the inside of the cutting tooth to the outside. Lift off the file when you pull it back.
4. Sharpen the teeth on one side first. Then turn the saw chain over and sharpen the teeth on the other side.
5. Check the length of the cutting links. After sharpening, all the cutting links must have the same length and width.
6. After every third sharpening, check the sharpening depth (depth gauge) and re-file the height using a flat file. The depth gauge should be set back by approx. 0.65mm from the cutting tooth.
7. After resetting, round off the depth gauge slightly towards the front.

Adjusting the chain tension

Adjusting the chain tension is described in section Tensioning the saw chain, p. 51.

Running in a new saw chain

The tensioning force of a new saw chain decreases after some time. You must therefore retighten the saw chain after the first 5 cuts or after 10 minutes of sawing at the latest (Tensioning the saw chain, p. 51).

WARNING! Risk of injury! Never attach a new saw chain to a worn chain sprocket or to a damaged or worn blade bar. The saw chain could jump off or break.

Servicing the blade bar

CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

Tools and aids required

• Flat file

Procedure (Fig. B)

1. Switch off the device and remove the batteries from the device.
2. Remove the sprocket cover (14), saw chain (6) and blade bar (7).
3. Check the blade bar (7) for wear.
4. Remove burrs and straighten the guide surfaces with a flat file.
5. Clean the oil passage (35) to ensure fault-free, automatic oiling of the saw chain during operation.
6. Mount the blade bar (7), saw chain (6) and sprocket cover (14) and tighten the chainsaw.

When in an optimal condition, the oil passages will automatically spray the saw chain with a little oil a few seconds after starting the chainsaw.

Turning the blade bar

CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

The blade bar (7) needs to be reversed regularly after a working time of about 10 hours in order to ensure even wear.

Procedure (Fig. B)

1. Switch off the device and remove the batteries from the device.

2. Remove the sprocket cover (14), saw chain (6) and blade bar (7).

3. Turn the blade bar around its horizontal axis and install the blade bar and saw chain as described under Installing the saw chain and blade bar, p. 50. Pay attention to the correct rotation direction of the saw chain while doing so!

Direction of travel of saw chain

1. To align the saw chain (6), use the symbol below the sprocket cover (14) as a guide when turning the blade bar.

Storage

• Clean the device prior to storage.
• Attach the encasing (16).
• Empty the oil tank prior to longer periods of non-use. Dispose of waste oil environmentally correctly (Disposal/environmental protection, p. 60).

There may still be oil residues within hoses and in the device that could leak out during storage. Place the device on a suitable base/oil pan for storage.

• Store the device in a dry and dust-proof location and out of reach of children.

Transport

• Cover the blade bar and saw chain with the chain guard (16) when you transport the tool.
• Short distances at the place of work: Carry the tool by the front handle (4) with the blade bar pointing backwards.
• Switch off the tool each time before transport. Secure the tool against tipping over during transport (including in vehicles) to prevent injury, damage or loss of fuel.

Troubleshooting

The following table will assist you in fixing faults:

Problem Possible cause	Error correction
Device does not start	Batteries (17) empty or not inserted	Check battery charge level, repair by a qualified electrician if necessary
	On/Off switch (2) is broken	contact the service centre.
	Defective motor
Saw chain not running and warning tone sounds	Chain brake blocks saw chain (6)	Checking the chain brake, p. 48
Poor cutting performance	Saw chain (6) incorrectly fitted	Installing the saw chain and blade bar, p. 50
	Saw chain (6) blunt • Sharpening the cutting teeth, p. 57 • Running in a new saw chain, p. 58
	Insufficient chain tension Tensioning the saw chain, p. 51
Device has difficulties running, saw chain jumps off	Insufficient chain tension Tensioning the saw chain, p. 51
Saw chain gets hot, smoke development when sawing, discolouration of the rail	Not enough chain oil • Checking the oil level and oil automation • contact the service centre.

Disposal/ environmental protection

Empty the oil tank carefully.
Do not dispose of used oil residues in the sewage system or down the drain.
Dispose of waste oil in an environmentally friendly way – take them to your local recycling centre.
Remove the battery from the device and recycle the device, battery, accessories and packaging in an environmentally-friendly manner.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be disposed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured. Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.

This does not affect accessories enclosed with the old devices or tools without any electrical components.

Disposal instructions for rechargeable batteries

Do not throw batteries into domestic waste, fire (risk of explosion) or water. Damaged batteries can harm the environment and your health if poisonous fumes or liquids escape.

Dispose of the batteries according to local standards. Defective or used batteries must be recycled. Hand in the batteries at a used battery collection point where they are recycled in an environmentally friendly manner. For more information, please contact your local waste management provider or our service centre. Dispose of batteries in a discharged state. We recommend covering the contacts with an adhesive strip to protect against short circuits. Do not open the battery.

Service

Guarantee

Dear Customer,

This product is provided with a 5 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within five years of the date of purchase of this product, we will repair or replace - at our choice - the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented

within the five-year period with a brief written description of what constitutes the defect and when it occurred. If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. Saw chain) or to cover damage to breakable parts.

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling,

use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

• Please have the receipt and product number (IAN 465830_2404) ready as proof of purchase for all enquiries.
• Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.
• Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.
• After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

You can view and download these and many other manuals on parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 465830_2404.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

• We can only work on devices which are sent in properly packed and with postage paid.
  Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.
• The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.
  We will dispose of defective devices you ship to us free of charge.

Service Centre

GB Service Great Britain Tel.:[phone] Contact form on parkside-diy.com IAN 465830_2404

MT Service Malta Tel.: [phone] Contact form on parkside-diy.com IAN 465830_2404

Importer

Please note that the address below is not a service address. Contact the service centre named above first. Grizzly Tools GmbH & Co. KG Stockstädter Str. 20 63762 Großostheim GERMANY www.grizzlytools.de

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 63

Pos. nr.	Name Order No.
6	Saw chain 30091626
7	Blade bar 30091627
14	Sprocket cover 91120139
16	Chain guard 91110676
23	Sprocket 91110674

WARNING! Safe use of the chainsaw is only possible with approved saw chains and guide rails. The use of unapproved combinations can cause serious or even fatal injuries.

- Blade bar:

164MLEA041(112329) (Oregon)
M1431656-1041TL (Trilink)

- Saw chain:

90PX056X (Oregon)
- CL14356TL (Trilink)

Translation of the original EU declaration of conformity

Product: Cordless Chainsaw

Model: PPKSA 40-Li B2

Serial number: 000001-047000

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2006/42/EC • 2014/30/EU • 2000/14/EC & 2005/88/EC

2011/65/EU & (EU) 2015/863

Product with battery Smart PAPS 204 A1/Smart PAPS 208 A1: 2014/53/EU

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 62841-1:2015/A11:2022 • EN 62841-4-1:2020

EN ISO 12100:2010 • EN IEC 55014-1:2021

EN IEC 55014-2:2021 • EN IEC 63000:2018

Product with battery Smart PAPS 204 A1/Smart PAPS 208 A1:

EN 301 489-1 V2.2.3:2019 • Draft EN 301 489-17 V3.2.6:2023

EN 300 328 V2.2.2:2019 • EN 50663:2017

In accordance with the Directive 2000/14/EC relating to noise emission, the following is confirmed: Sound power level (L_WA)

Measured: 99.8 dB;

Guaranteed: 103 dB

Followed conformity assessment procedure according to 2000/14/EC, Annex VI.

EC type-examination certificate

Number: M6A 036607 1856 Rev. 01
- Notified body: TÜV SÜD· Ridlerstraße 65 • 80339 München • Deutschland, NB: 0123

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction. 65

Pas des pignons 9,525 mm (3/8")

-Nombre de dents (pignon) 6

Temperature max. 50^

Indicator overbelasting. 117

Reparatie-service. 131

Service-Center. 131

Imporateur. 131

Kettingwielindeling ....9,525 mm (3/8")

Indicator overbelasting

Bij overbelasting knipperen de rode en gele leds van de laadtoestandindicator (29).

-Roztec retezu .9,525 mm (3/8")

-Vzdalenost retezu 10 mm

Lancosztas 9,525 mm (3/8")

1. BEZPIECZENSTWO W MIEJSCU PRACY

Reparationservice. 344

Service-Center 344

Importor. 344
