Product Type	Snow Thrower
Brand	NAC
Model	MM741450E
Engine	4-stroke gasoline, with ignition key and electric start
Clearing Width	Approximately 71 cm (28 inches)
Clearing Height	Approximately 53 cm (21 inches)
Fuel Tank Capacity	Approximately 3.5 liters
Transmission Types	Hydrostatic, 5 forward speeds and 2 reverse
Chute Orientation	Manual or electric, 180° rotation
Deflector	Adjustable manually or electrically
Controls	Free Hand, Easy Turn, heated handles
Safety System	Automatic auger and drive stop in 5 seconds
Lighting	Not specified, but may be present on some models
Weight	Approximately 110 kg (242 lb)
Adjustable Skid Shoes	Yes, to adjust cutting height
Cleaning Tool	Provided to unclog the chute
Maintenance	Oil change, spark plug check, air filter cleaning, chain lubrication
Warranty	2 years (parts and labor)

Frequently Asked Questions - MM741450E NAC

How to start the MM741450E snow thrower?

Make sure the tank contains gasoline and that the oil level is correct. Turn the key to ON. If the engine is cold, pull the choke. Press the primer button twice, then pull the starting rope or use the electric start by plugging in an extension cord.

What to do if the discharge chute is clogged?

Immediately stop the engine and wait 10 seconds for the blades to stop. Always use the provided cleaning tool to clear the chute, never your hands. This prevents any risk of amputation.

How to adjust the skid shoe height?

Loosen the mounting nuts of the skid shoes under the auger housing. Place a desired clearance block under the scraper bar, then push the skid shoes down until they touch the ground. Tighten the nuts. Repeat on the other side.

Why doesn't the auger stop when I release the lever?

This may be due to a poorly adjusted control cable or a worn belt. Refer to the Maintenance section of the manual to adjust the cable or have it checked by an authorized repair person.

What type of oil to use for the engine?

Use a 4-stroke motor oil of grade SAE 5W-30, preferably synthetic. Check the level before each use and change according to the manufacturer's recommendations (every 50 hours or once per season).

How to replace a shear pin?

Stop the engine and remove the key. Remove the broken pin, lubricate the auger shaft, align the holes, and insert a new original shear pin. Secure it with a cotter pin or lock nut depending on the model.

Does the snow thrower move on its own?

Yes, thanks to the hydrostatic transmission. To move forward, lower the traction control lever. You can select one of the 5 forward speeds using the selection lever. Release the lever to stop the machine.

How to store the machine at the end of the season?

Empty the fuel tank or treat it with a stabilizer. Change the oil, clean the machine, lubricate all grease points. Remove the spark plug and inject a little oil into the cylinder. Cover the machine and store it in a dry place.

Are the heated handles optional?

Some models of the MM741450E are equipped with heated handles controlled by a switch. Check for the switch on your machine. If absent, it can be added as an accessory.

What to do if the machine doesn't start at all?

Check that the key is on ON, that the tank has fuel, that the choke is in the correct position (closed if engine cold). Check the spark plug spark and the condition of the air filter. If the problem persists, consult an authorized repair person.

USER MANUAL MM741450E NAC

Products Covered by This

Manual

CAUTION indicates a hazard which, if not avoided, could result in minor or moderate

The following products are covered by this manual:

1695856, 1695994, 1695995, 1695996, 1695997, 1696009, 1696010, 1696011, M2E2, addresses practices not related to personal injury.
1696053, 1696054,1696055, 1696056, 1696061, 1696062, 1696063, 1696065, 1696066
1696067, 1696301, 1695996-00, 1695997-00, 1696011-00, 1696012-00, 1696055-00
1696062-00, 1696199-00, 1696200-00, 1696201-00, 1696202-00, 1696203-00, 169620 Hazard Symbol Charts
1696207-00.1696212-00.1696220-00
1696226-00. 1696227-00. 1696228-00. 1696229-00. 1696230-00. 1696253-00.
1696255-00. 1696256-00. 1696257-00. 1696277-00. 1696278-00. 1696300-00.
1696302-00. 1696381-00. 1696382-00. 1696390-00. 1696391-00. 1696392-00.
1695997-01.1696011-01.1696012-01.1696055-01.1696062-01.1696199-01
1696202-01、1696203-01、1696207-01、1696212-01、1696221-01、1696222-01
1696224-01.1696227-01.1696253-01.1696254-01.1696255-01.1696256-01
1695996-02, 1695997-02, 1696011-02, 1696012-02

Manual Contents:

Operator Safety

Safety System Tests

Features and Controls

Operation

Maintenance 1

Troubleshooting

© 2013 Briggs & Stratton Corporation, Milwaukee, WI, USA. All rights re

The images in this document are representative, and are meant to compare the instructional copy they accompany. Your unit may vary from the images used and RIGHT are as seen from the operator's position.

Operator Safety

Discharge Chute Warning

DANGER

Amputation hazard

The discharge chute contains a rotating impeller to throw snow. I quickly become caught in the impeller. Never clear or unclog the with your hands. Always use a clean-out tool.

Failure to observe these safety instructions will result in traumatic or severe laceration.

Hand contact with the rotating impeller inside the discharge chute is the cause of injury associated with snowthrowers. Never use your hands to discharge chute.

To safely clear a clogged discharge chute, follow these instructions: 1. Shut OFF the engine.
2. Wait 10 seconds to be sure the impeller blades have stopped rotating
3. Always use a clean-out tool, not your hands.

Symbol	Meaning	Symbol	Meaning
96201-01	Safety information about hazards that can result personal injury.		Read and understand the operator's manual before operating or servicing the
96223-01	Amputation hazard - rotating impeller.		Read the operator's manual before performing service.
96257-01	Amputation hazard - rotating impeller.		Amputation hazard - rotating auger
96283	Amputation hazard - touch moving parts.	do	Thrown objects hazard.
96	Fire hazard.		Explosion hazard.
96	Shock hazard.		Toxic fume hazard.
96	Hot surface hazard.		Ear protection recommended for extended use.
96	Keep a safe distance.		Remove the key before performing service.
96	Keep children away.		Kickback hazard.

General SafetyWarnings

Read the Manual

discharge chute DANGER
amputation This snowthrower is capable of amputating hands and feet and throwing Read and observe all the safety instructions in this manual. Failure to e mresultcomdeath or serious injury.

clean out the

Read the operator's manuals before operating the machine. This machine is dangerous if used carelessly.

• Save these original instructions for future reference.
• Never operate the snowthrower without all guards, covers, shields, and other protection devices in place and working.

Stop the engine whenever leaving the operating position.

Safety Alert Symbol and Signal We

The safety alert symbol indicates a potential personal injury hazard. A signal stop the engine and remove the key before unclogging the impeller hous (DANGER,WARNING,orCAUTION)is used with the alert symbol to designate a degree or level of hazard seriousness. Asafety symbol maybe used to represent the type wheofhazirng the machine,remove the key.

The signal word NOTICE is used to address practices not related to personal injury reduce the risk of fire, keep the machine clean and free from spilled debris.

injury.

WARNING indicates a hazard which, if not avoided, could result in death or serious

injury.

WARNING

Read, understand, and follow all the instructions on the snowthrower and operator's manual before operating this unit. Failure to observe the safety instructions in this manual could result in death or serious injury.

• Be thoroughly familiar with the controls and the proper use of the snowthrows. Always place containers on the ground, away from your vehicle, before fil
• Make sure you are properly trained before operating the snowthrower.
• Know how to stop the unit and disengage the controls quickly.
• Never allow anyone to operate the snowthrower without proper instruction.
• Always follow the instructions in the operator's manual, if the snowthrower stored for an extended period. Maintain or replace safety and instruction necessary.
• Never attempt to make major repairs on the snowthrower unless you have properly trained. Improper servicing of the snowthrower can result in hazard operation, equipment damage, and voiding of the product warranty.

Operation and Equipment Safety

WARNING

This snowthrower is only as safe as the operator. If it is misused, maintained, it can be dangerous. Remember: you are responsible for and that of those around you.

notfuproperspilled on clothing, change clothing immediately.

our safety

When starting the engine:

• Keepfuel away from sparks, open flames, pilot lights, heat, and other igni
• Check fuel lines, cap, and fittings frequently for cracks or leaks. Replace
• Use an approved fuel container.

• If fuel spills, wait until it evaporates before starting engine.

• If fuel is spilled, do not attempt to start the engine, but move the sno
  from the area of the spill, and avoid creating any source of ignition, un

• Do not over-prime the engine. Follow the engine starting instructions in th
• If the engine floods, set choke (if equipped) to OPEN/RUN position, move equipped) to FAST position and crank until engine starts.

Ensure that spark plug, muffler, fuel cap, and air cleaner (if equipped) are secure.
remove all do not crank the engine with the spark plug removed.
Wehe Walpering We equipment:
- Keep the area of operation clear of all persons, particularly small children and pets and secured.
- Thoroughly inspect the area where the snowthrower will be used and remove all doormats, sleds, boards, wires, and other foreign objects.
- Do not operate the snowthrower without wearing adequate winter clothing.
- Wear footwear that will improve footing on slippery surfaces. Use caution to avoid dissipated. Slipping or falling especially when operating the snowthrower in reverse. - Do not over-prime the engine. Follow the engine starting instructions in the
- Never operate the snowthrower without good visibility or light.
- Disengage the auger while transporting.
Always be sure of your footing, and keep a firm hold on the handlightheWalloperating the equipment:
- Do not clear snow across the face of slopes. Use extreme caution when changing direction on slopes. Do not attempt to clear steep slopes.
- Do not overload the machine capacity by attempting to clear snow too. Do not choke the carburetor to stop the engine.
- Never operate the snowthrower at high transport speeds on slippery surfaces (look equipped) removed.
- Do not use the snowthrower on surfaces above ground level such as roofs of and result in a fire or explosion.
- Operators should evaluate their ability to operate the snowthrower safely. When outtransporting equipment:
protect themselves and others from injury. Transport with fuel tank EMPTY. or with fuel shut-off valve OFF.
The snowthrower is intended to remove snow only. Do not use the snowthrower for any other purpose. When storing gasoline or equipment with fuel in the tank:
- Do not carry passengers.
- After striking a foreign object, shut OFF the engine, disconnect the cord motors, thoroughly inspect the snowthrower for any damage, and repair the before restarting and operating the snowthrower.
- If the snowthrower vibrates abnormally, shut OFF the engine. Vibration is a warning of trouble. See an authorized dealer if necessary for repairs.
- For models equipped with electric starting motors, disconnect the power the engine starts.
- Exercise extreme caution when operating on or crossing gravel drives, Stay alert for hidden hazards or traffic.
- Run the machine a few minutes after throwing snow to prevent freeze collector/impeller.

Fuel Handling

WARNING

Fuel and its vapors are extremely flammable and explosive. Always with extreme care.

Failure to observe these safety instructions can cause a fire or could result in severe burns or death.

When adding fuel:

• Never add fuel to a running engine or to a hot engine.
• Turn off engine and let cool at least 2 minutes before removing the fuel.
• Fill fuel tank outdoors or in a well ventilated area.

Moving Parts

Keep hands, feet, and clothing away from rotating parts. Rotating parts can be entangle hands, feet, hair, clothing, or accessories.

Failure to observe these safety instructions will result in traumatic amput or severe laceration.

• Whenever cleaning, repairing, or inspecting the snowthrower, make sure the handle is full of the engine key is removed, and all moving parts have stopped.
• Do not put hands or feet near or under rotating parts. Keep clear of the torsionoporth at all times.
• Never operate the snowthrower without proper guards, and other safety de place and working.
• Never leave the snowthrower unattended while engine is running. Always on the auger and traction controls, stop engine, and remove keys.

fuel Kaa and loaing clothing away from the front of the snowthrower and augmittens, dangling drawstrings, loose clothes, and pants can quickly become in the rotating device and amputation will occur. Tie up long hair and n

• Run the machine a few minutes after discharging snow to prevent freeze-up of the collector/impeller.
• Disengage power to the collector/impeller when snowthrower is transported by Carbon Monoxide use.

Thrown Objects

WARNING

Objects can be picked up by the auger and thrown from the chute. snow toward bystanders or allow anyone in front of the snowthrower. observe these safety instructions could result in death or serious [in]

WARNING

Englines give off carbon monoxide, an odorless, colorless, polson gas. Breathing carbon monoxide can cause nausea, fainting, or death.

Nevetadischargeun the engine outdoors.

Failure to Do not run the engine in an enclosed area, even if doors and windows are

• Always wear safety glasses or eye shields during operation, and while adjusting or repair to protect eyes from foreign objects that may be machine.
• Always be aware of the direction the snow is being thrown. Nearby or property may be harmed by objects being thrown.
• Be aware of your environment while operating the snowthrower. Runnin such as, gravel, doormats, newspapers, toys, and rocks hidden under be thrown from the chute or jam in the auger.
• Use extreme caution when operating on or crossing gravel drives, wa
• Adjust the collector housing height to clear gravel or crushed rock surface. Do not use pressurize starting fluids because their vapors are flammable.
• Never operate the snowthrower near glass enclosures, automobiles, window wells, drop-offs, and the like without proper adjustment of the discharge chute angle.
• Familiarize yourself with the area in which you plan to operate the off boundaries of walkways and driveways.

Children

Tragic accidents can occur if the operator is not alert to the pr Children are often attracted to the unit and the operating activity. that children will remain where you last saw them.

bce of children.

Hot Surfaces

WARNING

Running the engine produces heat. Engine parts, especially the muffler, are extremely hot.

Failure to observe these safety instructions could result in severe thermal contact.

Never assume Never touch a hot engine or muffler. Allow muffler, before touching.
attracted Remove debris from muffler area and cylinder area.

• Install and maintain in working order a spark arrester before using equipment, forest-covered, grass-covered, or brush-covered unimproved land.
  U.S.A. Models: It is a violation of California Public Resource Code Section 4442 to use or operate the engine on or near any forest-covered, brush-covered, or grass-covered land unless the exhaust system is equipped with a spark and meeting any applicable local or state laws. Other states or federal areas are similar laws.

Engine Safety

Safe operation of the snowthrower requires the proper care and maintenance of the engine. Failure to observe the safety instructions in this manual may lead to death or serious injury.

Maintenance and Storage

This result thrower must be properly maintained to ensure safe operation performance. Failure to observe the safety instructions in this manual cou In death or serious Injury.

• Disengage all clutches and shift into neutral before starting the engine
• Let the engine adjust to outdoor temperature before starting to clear
• Use extension cords and receptacles as specified by the manufacturer with electric drive motors or electric starting motors.
• Use a grounded three-wire plug-in for all snowthrowers equipped with motors or electric starting motors.

Kickback hazard

Rapid retraction of the starter cord (kickback) will pull your hands to the engine faster than you can let go. Broken bones, fractures, and could result.

When starting engine, pull the starter cord slowly until resistance pull rapidly to avoid kickback.

car snow. When performing any maintenance or repairs on the snowthrower, shut OFF the engine wait for all moving parts to stop, and remove the engine key to cover for someone from accidentally starting the engine.

• Check shear bolts and other hardware at frequent intervals for proper tightth electric drive. The snowthrower is in safe working condition.

• Keep nuts and bolts tight and keep snowthrower in good condition.

• Never tamper with safety devices. Check their proper operation regularly a necessary repairs if they are not functioning properly.

• Components are subject to wear, damage, and deterioration. Frequently check components and replace with recommended parts, when necessary.

rises, cheopraiarol operation frequently. Adjust and service as required.

• Use only factory authorized replacement parts, or equivalent, when making is felt and then Always comply with factory specifications on all settings and adjustments.

• Only authorized service locations should be utilized for major service and requirements.

• Use only attachments and accessories approved by the factory, or equivale as wheel weights, counterweights, or cabs).
• Never attempt to make any adjustments while the engine is running (except specifically recommended by the factory).

Safety Decals

Before operating your unit, read the safety decals. The cautions and warnings are safe. To avoid a personal injury or damage to the unit, understand and follow decals.

WARNING

If any safety decals become worn or damaged, and cannot be read, decals from your local dealer.

Chute Danger DecalA	172707 ×3
Auger Danger DecalB

Safety System Test (units with Free control)

all the sa

NING

Amputation hazard

This snowthrower is equipped with several mechanical safety systems designed to provide safe while using the unit. Check the operation of these systems using the safety system tests listed. If the unit fails to operate as described, operate it. See your authorized dealer for service immediately.

Test 1 - Auger/Impeller Control

With the engine running:

• Press down on the auger control lever. (The auger/impeller should rotate)
• Release the auger control lever. (The auger/impeller should stop within 5

Test 2 - Traction Drive Control

With the engine running and speed control in 1st gear:

Press down on the traction control lever. (The unit should move forward
- Release the traction control lever. (The unit should stop)

Test 3 - Free Hand Control

With the engine running:

• Engage the auger and traction control levers, then release the auger controls (Both controls should remain engaged)
• Next, release the traction control lever. (Both controls should release)

Safety System Tests

Determining Which Test to Use

Models with Free Hand™ Control: After engaging the traction control auger control (right hand), Free Hand allows the operator to release for the auger control to remain engaged until the traction control is models have the icon set shown in Figure 2 on the dashboard.

Models without Free Hand Control: On units without Free Hand, the a controls operate independently, and the Free Hand icon set is not found. Please select the appropriate Safety System Test for your unit.

Safety System Test (units without Hand control)

WARNING

Amputation hazard

This snowthrower is equipped with several mechanical safety systems the operator safe while using the unit. Check the operation of these using the safety system tests listed. If the unit fails to operate as operate it. See your authorized dealer for service immediately.

Test 1 - Auger/Impeller Control

With the engine running:

• Press down on the auger control lever. (The auger/impeller should
• Release the auger control lever. (The auger/impeller should stop w

Test 2 - Traction Drive Control

With the engine running and speed control in 1st gear:

• Press down on the traction control lever. (The unit should move
• Release the traction control lever. (The unit should stop)

Features and Controls

Engine Features and Controls

auger control and engine features and controls, please refer to the engine operator's manual.

Snowthrower Features and Controls

on the dashboard.		Locatisdictional
A Free		Auger Control Lever - Used to engage and disengage the auger and impeller. To engage, push down. To disengage, release.
B signed to keep systems regularly described, DO NOT	↑3-1-1-	Speed Select Lever - Allows the operator to select forward and reverse speeds. To shift, move speed select lever to desired position. NOTE: Do not move speed select lever while Traction Control is engaged. This may result in severe damage to the drive system.
		Chute Rotation Crank - In-Dash (if equipped) Used to rotate the discharge chute to the left or right.
D rotate) E min 5 seconds)		Chute Rotation Crank - Lefthand Crank (if equipped)- Used to rotate the discharge chute to the left or right.
		Chute Rotation Switch - Electric (if equipped) Used to rotate the discharge chute to the left or right.
F forward)		Free HandTM Control (if equipped)- After engaging the traction control (left hand) and au control (right hand), allows the operator to release the auger control lever to use other controls.
G		Traction Control Lever - Used to propel snowthrower forward or reverse. Push down to disengage, release to disengage. See also, "Free-Hand Control".

		DescriptionIconLocation
H		Deflector Control - In-Dash (if equipped) to control the angle of the deflector (up
I		Deflector Control - Manual (if equipped) to control the angle of the deflector (up
J		Deflector Control - Electric (if equipped) to control the angle of the deflector (up
K		Easy TurnTM Traction Control (if equipped) When engaged, allows the operator to release one drive wheel, but allows the other wheel driving for easy turning.
L		Grip Warmer Switch (if equipped) - Used warm the hand grips (high, off, low).
	-M	Clean-Out Tool - Used to remove snow debris from the discharge chute and the auger housing.
	-N	Skid Shoes - Used to adjust the ground of the auger housing.

Operation

Before Operating the Snowthrower

WARNING

Read the operator's manual before operating the machine. This may be dangerous if used carelessly.

• Never operate the snowthrower without all guards, covers, and ship
• Stop the engine whenever leaving the operating position.
• Remove the key before unclogging the impeller housing or discharge before making repairs or adjustments.
• When leaving the machine, remove the key.

• To reduce the risk of fire, keep the machine clean and free from and debris.

• On electric start models, disconnect the extension cord before operating.

• Be sure to check the engine oil level before starting the engine. operator's manual for oil recommendations.

Operating the Snowthrower

DANGER

Amputation hazard

The discharge chute contains a rotating impeller to throw snow. It quickly become caught in the impeller. Never clear or unclog the with your hands. Always use a clean-out tool.

Failure to observe these safety instructions will result in traumatic or severe laceration.

Hand contact with the rotating impeller inside the discharge chute is the cause of injury associated with snowthrowers. Never use your hands to discharge chute.

To safely clear a clogged discharge chute, follow these instructions:
1.Shut OFF the engine.
2. Wait 10 seconds to be sure the impeller blades have stopped rotating
3. Always use a clean-out tool, not your hands.

f. clearance the engine. Please refer to the engine operator's manual for engine i
2. Rotate the chute rotation crank (C or D, Figure 3) or use the chute rotor to set the direction of the discharge chute.
3. Models with manual defector adjustment: Loosen the wingnut securing the deflector (l). Raise the deflector to throw snow further. Set the defector 1 position and tighten the wingnut.

Models with in-dash deflector control lever: Use the deflector control le move the deflector up or down. Raise the deflector to throw snow further

Models with electric deflector control: Use the deflector control switch (the deflector up or down. Raise the deflector to throw snow further.

line can be speed select lever (B) to select the forward or reverse drive speed speeds when clearing wet, heavy snow. Use higher speeds for light snow in transporting.

NOTE: Always set engine speed to FAST (full throttle).

chute... and
5. Fully press the auger control lever (A) to engage the auger. Release the the auger.
6. Fully press and hold the traction control lever / Free Hand control (F/G) spilled straight above and begin moving the snowthrower. To stop, release the lever NOTE: Always release the traction control lever before changing speeds.

When both the auger (A) and traction control levers (F) are pressed, the control lever is activated. This allows you to release the auger control lever (A) controls. The auger will continue to rotate until the traction control lever/F1 control lever is released.
8. If desired, if equipped, use the grip warmer switch (L) to turn on the he

Stopping the Snowthrower

1. Release the auger control lever (A, Figure 1).

2. Release the traction control lever (F).

ischarge chate engine. Please refer to the engine operator's manual for engine in

Easy Turn™ Traction Control (if equipped)

For easy turning when using the snowthrower, squeeze the Easy Turn traction (Figure common

plan out the Note The Easy Turn will be more difficult to activate under a heavy load. lever before beginning a turn.

Engaging the Easy Turn traction control lever releases one of the traction wheels on the other wheel to continue driving. Releasing the Easy Turn traction control law automatically engages both drive wheels for full traction (Figure 5).

Wheel Release - Lock Knob (if equip

Some models are equipped with a drive wheel release that allows you to dis the drive wheels, for easier transporting of the unit with the engine off.

Models with Traction Lock Knob: Wheels equipped with a traction lock (6) can be completely released by pulling the knob out away from the wheel pin is disengaged from the wheel. Then rotate the knob so the pin does wheel. Reverse this process to engage the drive wheel.

Wheel Release - Lock Pins (if equ

Wheels equipped with a traction lock pin (A, Figure 7) can be completely removing the pin and installing it in the outer axle hole. Reverse this proof drive wheel.

Deflector Adjustment

A. Manual Deflector Control (if equipped)

Loosen the deflector knob (A, Figure 8), adjust the deflector to the desired then tighten the knob to secure. Raise the deflector to throw snow further

B. Electric Deflector Control (if equipped)

While the engine is running, press either side of the deflector control switch to move the deflector up and down. Raise the deflector to throw snow further

C. In-Dash Deflector Control (if equipped)

Move the deflector control lever (C, Figure 8) forward or backward to rais deflector. Raise the deflector to throw snow further.

Chute Rotation Adjustment

A. Electric Chute Rotation Control (if equipped)

While the engine is running, press either side of the chute rotation switch.
rotate the chute left or right.

B. In-Dash Chute Rotation Control (if equipped)

Locate the in-dash chute rotation crank (B, Figure 9). Rotate the crank

C. Lefthand Crank Chute Rotation Control (if equipped)

Locate the lefthand chute rotation crank (C, Figure 9) Rotate the crank

skid A Fig the Shoe Height Adjustment

Amputation hazard

pped)

Discharge chute contains a rotating impeller to throw snow. Fingers can be released caught and traumatic amputation or severe laceration will result. Hand cast the energizing tiimpeller inside the discharge chute is the most common cat associated with snowthrowers.

Turn the engine OFF, wait for all moving parts to stop, and remove the er performing any maintenance or repairs.

Thrown objects hazard

Objects such as gravel, rocks, or other debris, if struck by the impeller, may be with sufficient force to cause personal injury, property damage, or damage to the ctsnod (the figure 8) to

'Be sure to set the skid shoes at the proper height to maintain ground clear type of surface being cleared.

Thiandowthere is equipped with two height adjust skids, secured to the out auger housing. These elevate the front of the snowthrower.
When removing snow from a hard surface area such as a paved driveway or the skids up to bring the front of the snowthrower down.
When removing snow from rock or uneven construction, raise the front of the by moving the skids down. This will help to prevent rocks and other debris
upA,anFigurnow) by the augers.
1. Determine how much clearance you want between the scraper bar at the the auger housing and the ground. If clearing a gravel surface, enough g clearance is needed to prevent the unit from picking up rocks.
2. Place the block equal to the desired ground clearance under the scraper base
3. Loosen the skid shoe mounting nuts (A, Figure 11) and push the skid sh until it touches the ground. Re-tighten mounting nuts.
4.rod the skidte sho on the other side at the same height.

Filling the Fuel Tank

Please refer to the engine operator's manual for information about filling for fuel recommendations.

Clearing a Clogged Discharge Chute

DANGER

Amputation hazard

The discharge chute contains a rotating impeller to throw snow. It quickly becomes caught in the impeller. Never clear or unclog the with your hands. Always use a clean-out tool.

Failure to observe these safety instructions will result in traumatic or severe laceration.

Hand contact with the rotating impeller inside the discharge chute is the cause of injury associated with snowthrowers. Never use your hands to discharge chute.

To safely clear a clogged discharge chute, follow these instructions: 1. Shut OFF the engine.
2. Wait 10 seconds to be sure the impeller blades have stopped rotating.
3. Always use a clean-out tool, not your hands.

A clean-out tool (A, Figure 10) is provided with the unit.

Off-Season Storage

If fuel tank would be stored for 30 days or more at the end of the season, are recommended to prepare it for storage. Always refer to the operator's mar important details if the unit is to be stored for an extended period.

Please refer to the engine operator's manual for engine storage information.

NOTE: Fuel must be removed or treated to prevent gum deposits from forming filter, hose, and carburetor during storage.

dlaiaargeandhuplesion ha

Gasoline is highly flammable and its vapors are explosive. Fumes may travel ampritation source and an explosion and/or fire may result.

Handle gasoline carefully. Never store the unit, with fuel in the tank, indoors creastilatemnclosure where fuel fumes could reach an open flame, spark, pilot ceas auftfuthace, water heater, or clothes dryer.

Thoroughly clean the unit.
- Lubricate all lubrication points (see Maintenance section).
- Make sure all nuts, bolts, and screws are securely fastened. Inspect all parts for damage, breakage, and wear. Replace if necessary.
- Touch up all rusted or chipped paint surfaces; sand lightly before painting
- Cover the bare metal parts of the snowthrower housing auger, and the i rust preventative.
If possible, store your unit indoors and cover it to give protection from
If the machine must be stored outdoors, cover with a heavy tarpaulin.

To Return to Service:

• Fill the fuel tank with a fresh fuel.
  Make sure all fasteners are tight.
• Make sure all guards, shields, and covers are in place.

Maintenance

Maintenance Schedule

Before Each Use

Check engine oil levelPerform Safety System Test

Every 8 Hours or Daily

Check engine oil level

Every 25 Hours or Annually

Lubricate control lever linkageLubricate the auger assemblyLubricate the discharge chute rotation gear and deflectorLubricate the drive system hex shaft with 5w-30 synthetic motor oil greaseLubricate the disc drive system (if equipped)

Every 50 Hours or Annually

Check muffler and spark arrester (if equipped)Check tire pressure

Engine Maintenance

For engine maintenance schedules and procedures, please refer to the engine manual.

Control Lever Linkage Lubrication

Check the function of the Free Hand control (A, Figure 12). The controls described in the Operation section.

WARNING
Amputation hazard

It is critical for safe operation of the unit that the controls disengage no circumstances should the unit be used if the controls do not function safely. Systems Tests to confirm correct operation.

Lubricate the linkage for the Free Hand control, speed select control, and Steer control every ten operating hours, or as necessary to ensure safe

Auger Assembly Lubrication

Lubricate Auger Gear Box

The auger gear box is lubricated at the factory and should not require If for some reason the lubricant should leak out, or if the auger gear add Lubriplate GR132 Grease or equivalent. Maximum 3-1/4 ounces, (92 be used.

Remove filler plug (A, Figure 13), once a year to check grease level. If not add. If grease is not visible, use a piece of fine wire, like a dipstick grease in the gear box.

Lubricate Auger Shaft Fittings

Using a grease gun, lubricate the auger shaft fittings (B, Figure 13) every or once per season. Each time a shear bolt or pin (C) is replaced, the greased.

For storage or when replacing shear bolts or pins, remove the shear bolts to lubricate the shaft fittings (B), and rotate the augers several times to distal Reinstall the shear bolts or pins when complete.

Discharge Chute and Deflector

Lubricate the chute rotation gear (Figure 14) with grease, and automotive type oil every twenty five operating hours.

Lubric

the deflector

Hex Shaft and Chain Lubrication

The hex shaft and drive chains must be lubricated at the interval specified in Chart. Please have your authorized dealer perform this maintenance.

Traction Cable Inspection

The cables are adjusted at the factory and no adjustment should be necessary if the cables have become stretched or are sagging, adjustment will be nees see your dealer for this adjustment.

Traction Drive Belt Adjustment

The traction drive belt is under constant spring tension and doesnotrequire any If the traction drive belt is slipping, see your authorized dealer.

Speed Control Rod Adjustment

find the chasped with control rod requires adjustment, see an authorized dealer.

Easy Turn™ Cable Adjustment

If the Easy Turn cable has stretched, the gears will not disengage when the activated. Adjust the cable using the following procedure. 1. Turn the engine off and remove the key.
2. Loosen the jam nut (A, Figure 34).
3. Turn the adjustment nut (B) to lengthen or shorten the cable. The cable tightened until all slack is removed from the lever. However, it must not Easy Turn without depressing the control lever.
4. Tighten the jam nut (A).

Auger Cable Adjustment

Amputation hazard

Over-tightening the auger cable may cause the auger drive to engage without the auger drive control.

Indopoeled treatment procedure to ensure the cable is not over-tightened. n properly. See

1. With the auger control lever released, the hook (A, Figure 16) should bare lever (B) without raising it. There can be a maximum of 1/32'' (0.8 mm) Easy to loosen the nut (C) by holding the adjusting flats (D) and turn operation Then, turn the adjusting flats and hold the adjustment screw (E). The adj is a Phillips screw and the head can be held or turned by inserting a through the spring (F).

2. Hold the adjusting flats and tighten the nut.

3. To ensure that the auger does not engage unless the controlfullydepressed, perform the Safety System Tests. The auger must stop within 5 seconds of the additional control being released.
   box has been serviced,

rams) should Determine Which Shear Bolt/Pin System

You

Please refer to the Illustrated Parts List to determine if your unit requires a shear bolt and spacer combination.

The discharge chute contains a rotating impeller to throw snow. Fingers can become caught and traumatic amputation or severe laceration will result. Hand with the rotating impeller inside the discharge chute is the most common car associated with snowthrowers.

Turn the engine OFF, wait for all moving parts to stop, and remove the er pening any maintenance or repairs.

r mechanism with

Where an oil can is pictured, lubricate with engine oil. Where a grease lubricate with lithium grease.

Shearred Pin Replacement

Augers are secured to the auger shaft with special pins that are designed to object becomes lodged in the auger housing. Use only factory spec, or equiv pins.

1. Turn off the engine and wait for all moving parts to stop.
2. Remove the existing shear pin.
3. Lubricate the auger grease fittings and rotate the auger to lubricate

4. Align the shear pin holes. Install the new shear pin (A, Figure 17) shaft (C). Secure with a cotter pin (B).

5. Turn off the engine and wait for all moving parts to stop.

6. Remove the existing shear bolt.

the3 . auguricahafthhe auger grease fittings . Spin the auger to lubricate the auger s

through the auger shaft (C). Secure with the locknut (D).

Shear Bolt Replacement

1. Turn off the engine and wait for all moving parts to stop.
2. Remove the existing shear bolt.
3. Lubricate the auger grease fittings. Spin the auger to lubricate the auger shaft.
4. Align the bolt holes. Install the new shear bolt (A, Figure 18) through the auger (B). Secure with the locknut (C).

Checking Tire Pressure

Tire pressure should be checked periodically. Recommended tire pressure varies manufacturer. A good rule of thumb is to inflate the tire up to, but not exc Inflation" stamped on the side-wall of the tire.

Gear Drive System (if equipped)

The gear drive system requires no maintenance or adjustment. Should you have with the gear drive system, contact your authorized service dealer.

Shear Bolt and Spacer Replacement

Augers are secured to the auger shaft with special bolts that are designed to break if an object becomes lodged in the auger housing. Use only factory spec, or equivalent, shear bolts.

Troubleshooting

Troubleshooting Chart

Perform the inspection or repair as indicated in the Troubleshooting Chart.

		RemedyLook for Problem
is released.	Free Hand control (if equipped) is ACTIVE.Auger	Releasenobottopausgathincofrotecmks Frater Height controll (leve equipped) to stop auger.
		See authorized dealer.Auger drive belt out of adjustment
		See authorized dealer.Auger belt guide out of adjustment
		See authorized dealer.Electrical failure.Discharge chute or
Discharge chute or deflector does not work (remote MANUAL).lubrication.		Adjust and/or lubricate control linkage.Discharge chute or
Drive fails to move snowthrower at slow speeds.	Traction control out of adjustment.	See authorized dealer.
Engine fails to start.	Key is in OFF position.	Set key to ON position.
	Failure to prime a cold engine.	Press primer button twice and restart.
	Fuel shut-off valve, if equipped, is in CLOC	STOn positionto OPEN position.
	Out of fuel.	Fill fuel tank.
	Choke OFF - cold engine.	Turn choke ON, set throttle to FAST.
	Engine flooded.	Move the choke to OPEN/RUN position, move throttle 1 FAST position, and crank until the engine starts.
		See authorized dealer.No spark.
Engine starts hard or runs poorly.	Water in fuel, or old fuel.	Drain tank. (Dispose of fuel at an authorized hazard facility.) Fill with fresh fuel.
		See authorized dealer.Spark plug faulty, fouled, or gapped
	Fuel cap vent is blocked.	Clear vent.
Excessive vibration.	Loose parts or damaged impeller.	Stop engine immediately. Tighten all hardware. If continues, have the unit serviced by an authorized dea
Snowthrower does not stop when traction control lever is released.	Traction control out of adjustment.	See authorized dealer.
Scaper bar does not clean hard surface.	Skid shoes and scraper bar improperly adjusted.	Raise or lower skid shoes and scraper bar.
Unit fails to propel itself.	Drive belt loose or damaged.	Replace drive belt. See authorized dealer.
		See authorized dealer.Incorrect adjustment of traction
	Worn or damaged friction disc.	Replace friction disc. See authorized dealer.
		RemedyLook for Problem damage section
		See authorized dealer.Auger drive belt loose or Adjust auger control cable. Refer to Maintenance this manual.
	Auger control cable not adjusted correctly.
	Broken shear pin or shear bolt.	Replace shear pin or bolt. Refer to Maintenance this manual, or see an authorized dealer.
	Discharge chute clogged.	Stop engine immediately. Always use the clean-out tool Clear discharge chute and inside of auger housing. Refer to Discharge chute Warning in the Operator Safety
	Foreign object lodged in auger.	Stop engine immediately. Always use the clean-out tool clear a clogged chute, not your hands. Remove auger. Refer to WARNING in the Operator Safety sec

Uprofikern protismykovych boticek

kata tento postup

NEBEZPECI

Riziko amputace

isou

Ouzyz-ziab zannitj routjno shka k gonazovani shnve ycme mudk zachyceni prstau a jejich amputacm ic vazmyn poranemir Nejcastesi poraner pouziti snhehove frezy vznikaji pri kontaktu rukou s pohanecem odpadoveno nos

uynenena

Nez zacneta provadet jakoukoli udrzbu ci opravy, VYPNETE motor, vyckje, az pohyblive casti zastavi, a pak vyndeje klic motoru.

VAROVÁNÍ

Nebezpeci odhazc

predmetu

Fikimj kameny, sterk nebo jiny odpad mohou po odhozeni snekem letu siou, ze zpusobi poraneni, skody na majetku nebo poskozeni snehove frezy.

Rensselaer University

FIGURE 10.3.2. (a) The crystal structure of the CuO -based ZnO nanocrystals. (b) The crystal structure of the CuO -based ZnO nanocrystals. (c) The crystal structure of the CuO -based ZnO nanocrystals. (d) The crystal structure of the CuO -based ZnO nanocrystals.

© 2013 Briggs & Stratton Corporation, Milwaukee, WI, USA. Minden jog

J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J. J.

© 2013 Briggs & Stratton Corporation, Milwaukee, WI, USA. Tutti i diritti

© 2013 Briggs & Stratton Corporation, Milwaukee, WI, USA (JAV). Visos

© 2013 Briggs & Stratton Corporation, Milwaukee, WI, USA. Alle rettigheter

Be3oNaChocn onepaTopa

PpOBepKa CnCTeMbI 6e3oNaChOcTH

OncaHne xapaKTepeNcTHn H pbIarOB ynpaBHeH

Onepaun

06cIyKHHaHHe

Ponck yctpaHHe HEnCpBaBHOcTei

© Kopnpaunig Briggs & Stratton Corporation, Milwaukee, WI, USA. 2013 zauuuehbl.

H3o6paHexHH, coepkaueeB DAHHOM DOKyMeHTe, npBODrTcB KaeeCTBe

HIOCTpaun K HNCTpyKUaM. BaaMa MoeJb MoHcT OTnHaTbcr OT npedctab

H306paKHeN.CJIEBA H CIPABA OTHOCHTcK TOTKe 3peHnO npaTopa,3aHBWero

CBOE MECTO.

Бezonauchoctn onepatopa

"OcToPoXHoCTb npn nCNoJIb30BaHnn pa3rpy3oUHoro HeIo6a"

ONACHO

Onachoctb amnytaunn

Bpa3rpy3oHOM Hxlo6e HaxoHTC BpaaOuNecn Koneco,OT6pa3b Cher. PAnb cy Moryt nonactb B KpbIbTaTHy. 3anpeuaetc pyhann pa3rpy3oHyb Hxlo6.DIy OHCTHN Bcerda HcnoJb3ayTe ppoHCTHO Hnctpymet.

HecobIIOeHHe DaHHbIX npabIN 6e3oNaChocTH npHBedet K OTpbIBy nTpaBMAM HOHeuHocTei.

Camao paacnpoctpaehnHO TpaBMO, KOtopyno nolyaHT Ha cherooHCTmTeJAX
AIBJIaETCR NOBPEXDEHNE PYN PNI KOHTaKTE C BPAUaOeJeC KpbIbHaTHO
pa3pry3OHoro JHeNo6a. 3AnpeEHO OcUeCTBnTb OHCTHy pa3pry3OHoro JKe
pykamn.

YTo6bl 6e3oNaCHO npOuHcHTb 3a6HBuHcNc pa3rpy3oHbI HeNo6, cne 3TMM HnCTpyHcHm:

1. 3aIywnTe DnBraTeIb.
2. Iopokndte 10 ceHyd, YTO6bI Jnonactn KpbInbYaTkn ycneNIOCTaHOBHTbcA.
   3.ДЯ OYHCTKN BCERda HcNoIb3yITe CNEUaJIbHbI INHCTpyMeHT, a He pyHN.

IpeynpeintelhbIe 3HaHn onaCHOCTN cnHaIbHbIe cNoBa

1696012,
1696012,
1696012,
1696012,
1696012,

PepdynpeDntbHb3HaK MOKeT yKa3bBaTb Ha BnO NaCHOCTN. CnHaJI

00, "IPIMMEYAHIE" yka3bBAeTHa CHTyaun, He CBraHHbE C ONACHOCTbIO NOIy

996-01,

20A-01

2010NACHOVAaHbAeTHaOnachVIOCHTVaUMIOKOTOPAecn ee He 36

25738et K CMEPTENbOMy HXcOyH NHN NONYeHHIO Cep63BHX TpAM.

I PEPDYNPPEKHEHNE yka3bIBaHa ONaCHyIO CHTyaHIO, KOTopA, ECIN ee 136eHtB, MOJET PNIEBcTNI K CMePTeJIbHOMY HxOyI INI NIOUyEHNIO cepE3HbIX TpABM.

BHHIMAHNE yka3bIbaet Ha onachyio CHTyaunio, KOtopa, ecln ee He n36 MoJcT npHBeCTn K noJIyuEnIO TpABM HN3KOi IIN cpeJeH TAnKectn.
101 PIPMEHAHNE yHa3bIbAeT Ha CHTyauuHHe CBraaHHbIe C ONaCHOCTbIO NOJUeyHnA T

101

IpeDyPepHdaIOUne 3HaHn Ha

CHeroOoUcHTnTeJIe

TOnJIbBO Iero HcnapenH JIeHNO BocJIaMeHJOTc N B3pbIbOonacHb. Bcer, OobpaauTeCb C TOnJIbBOM C Oco6oN OCTOpOHIOCTbO.

Hue Hne Hn Hbix npaBn 6eOnacHO MoKet cTb npuHoo
BocnHHe Hn B3b1Ba, Yo MOKet NOBLeCb 3a cO60 TJeBle Tpa

TONNBA:

3anpeaetcdoJINBAbTToNIMBO npn pa6oTaIOeM mI rOpyem Dniratene.

3arnyuHTe DniratJIb, daTe emy octIbT KaH MNHHMm 2 MmHyTbi, n TOnI 3TOrO CHMNTE KpbIshky TOINIBHoro 6aKa H DoJeITe TOnJIMBO.
3aIbAeTe TOnnBBO B ToNnBHyBbI 6aK ToJIbKO Ha yInue HIN B Xopoio BOHTNIHPyEMOM NOMeUeHIN.
3anpeiaeTcraapabIbToTOnIIBHbIEemHOCTMaunHbI，aTaKeHe nIIOIeMOpme Hcy3OBA Imnpuena CnlaTHKOBoOmbHbO.Bcerda CTBaTe bHa 3eMIO，BDAJIOT MaunHbI，NEpeTEM.KAK HaNATbe nepeINbAt.

3nBHO EcHn BO3MOxHO, CHMaiTe yCtpoCTBa, paOtaKUme Ha 6eH3nHe, C rpy3OB1 Hnn npiueena H 3aJIbAte B HIX TOnIINBO Ha 3emJe. EcHn 3TO HeBO3MO) 3anpaBIA Te TOnIMBO C NOMOJBIO KaHNCTp BmecTo TORo, YTO6bl 3aJIbBA Tb 6 H3 3aJIpABQHORFO NHCToLETa.

JINI, CoxpaHnTe KOHTAHT 3anpaboHOrO NtCToJIeTa C 06oDM TOnIINBHOrO 6aKa I EMKOCnHa npTOAeHHN Bcero npocceca 3anpabKn. He cNoIb3yIte ΦHKCa OTHpBtORo NOIOJKeHHa ZAnOPHOg YCTPOJCTBa 3anpaboHOrO NtCToJIeTa.
Dpyrpepe3anycOK DnBraTeTuaTeIbHo 3aKpyTHTe KpbHky TOnNHBoro 6aka DaTe Bpem Hcnapntbcn PpOINbWEmyCnTOINBy.
He npenolHnTe TOnnBb6aK. PpHHMa B pacHTe TEnIOBoe paunpeH 6eHNHa, He 3aONHLrte 6aK Bblue Hn3a rOpbluHa.

• DepHnTe TOnJIbNO Ha paacctoHHN OT NCKp, OTKpbIToro OTHN, 3anaJIbHbIX yCTPdHTe CBO6OHeIe HIN CBNAcOuNe 3JEMeHTbl OJeKDbI BdaII OT nepeHne I npyTnx NcTOHKnOB BO3rOpAHn. CHEEROHCTInTeIa N uHEKOHoromexHaHIm3Ma. JApfbI, BaepKKn, CBNAcoUne shyp
  Peynphno npoeepnte tonbnbnpobod, kpbkny na pby6n ha hannne CBOOHN OdeHna BpOKN MOrT bBtB JIRO 3axBaueHb BpaauoMMnC n npotekanin. B clyae heo6xOdMOnctn npoeDnTe 3amEny. DetaJAMN, YTO MOHT npBeCTn K TaBPMaTHNeckoanmTyauHnAcTe Ke KOHeuHO 3atraHnTe dHHbIE BONcL N CHMNITe YKPAUENHn.
• NcnoIb3yTe TOnbKO odObeHnble K npImeHHeHIO KaHNCTpbl IaT OToNlBa. - Pocne OkOHuaHH v6OpKn Chera daTte MaunHe Nopa60TaB eue HeckOJIbHO
  B cnyae npolna TOnnBa noDoknte, noka oHO He HcnapntcH, H TonbHcyTOpneDPaHTb 3aMeep3aHHe KOnJIeHTopn H KpbIbHaTHN. 3TOrO 3anychAte DBrTaTeIb.
  EcnTOnnHb nponnoocb Ha oJey, HEmdienHNo nepeoedhTecb.

Pn 3anyche ABnraTeJIr:

• Y6eIntecb, yTO npOBOD CBEH N3aKnRAHnR, rIyWHTeB, KpbIHa TOIINHBnN BO3dyuHbI pNtBp (ecn TaKoBbIe HMeIOTCa) HaxOJrTcH Ha CBOUX Me
  He 3abOndTe dBnraTbe pykoarbno npni OTHKIOHcHOM npoBOe cBeHn 3
• Ecln TOnJIHb npOJIHNoB, He NbIaTneCb 3aNyCTNt b DnIaTeJIb, a OTHaTIc HceroOCHNTeJIb OT MeCTa npOIHbA H e NcOJIb3yIte HcTOcHHHN 3aHXrT tex nop, nOHA he pa3Be0TCr Napbl ToNJIbA.
  He nepe3aHbAte DBrataTeB. CneyTe yka3AHm no 3anycky DbraratE daHHOM pyKOBoDCTBe.
• Ecln npon3oewen nepelNB tonlNb B Kap6opatop, n DbrarateB 3axne6bl yctahOBHTe npabLeHHe 3acNoHKnOe (ecn TaKOBa HmeETc) B noLoKeHne OPEN/Run (OTkpbIb/3aynck), peryTATOP noDaun TonlNb (ecn HMeETc) noLoKeHne FAST (Bictpo) n npobOpauHBAte pyKoTHy, noka DBrAteB 3aBoTeCra.

Pn3HcNpyaTaauo6OpydoBaHHa

He hAnIOHnTe cHeroOoHcTneIbNoI yrIOM, T.K. 3TO npBBeTe K npOIMBy
He nepeKpbIbaiTe 3acNoHky Kap6OpaTopa, TTo6bl 3aIywnTb DnIraTeIb.
3anpeaetc3aynckatb DnHraTeIb,ecn ydaJeHb CHTMa OCHCTKBO3D BO3dyhbln HbTp (ecn TaKOBbie HMeIOTC).
EcIn Bbl CnIBaTe MacNo Yepe3 BePbXHO Tpy6Hy, TOnINBbI bak DoJIH NycTbIMnHaue ToNlINO BO MoKeT IpoteYb n PnBeCTn K BOCIIaMeHEHIO I

Ptp TpaHcnpTHpOBHe 6OpdyoBaHHa:

• TpahcnoptnoBky cIeNyet OcyueCTbIbTc IYCTbIM TOINBBHbIM 6aKOM INTOINBBHbIM NEPEKpbBaOuM KlaanAHOM B NOLOXHeHH OFF (NEPEK(PbITO).

Ppi xpaHeHH 6eH3nHa HnObOpydoBaHH C ToIINBOM B 6aHe:

BENH NERNO BOCNAMEHREM, a ero npbl B3pbIOOaHbI. Napbl 6eHNHa pacnpoCTpaHbCBA DO ydaenHHbIX HCTOCHNKOB 3aHHaHn, 4TO MOHT npMB B3pyBn nnoNHOAPy.
- BydTe octopoHbI npn obpaueHHN C 6eH3HHOM. KaTeOpHueChN 3anpeuB xpaHTb CHerooOCHTteB C 3aJIbTBIM B 6aK TOIINBOM B NOMEeHHN BYENTHINpyEMOM nocCTpaHCTBE, rge napbl TOIINBa MOrYT DoCTNH bOTKpbIO HcKpbI IIN 3anaIbHorO yctpoCTBa, HanpIMep, B Neu, BODOHarpeBaTeJe cyuHInke DnA OdeKDbI.
XpaHInTe TOIINBO BDAH NOT Neey, PnHT, HArpeBaTeNEI BOBIMN DpyrHc 3aapanbHbIMn npCnOcO6LnEHNMn IyDPMN HCTOnHHKaMn BO3rOpAHI NOCKJbHy OHN MOrT NBOcPiMaEHHb NapBi TOIINBA.

DnKyuuee Ta

ONACHO

Depnnty Hn Hn OeJHy Ha paCtOHHN OT BpaAouoHxcn TaBpaAouoHecn detanMoryT 3axBaHTb n 3aTReHytb pyHn, Horn, BonoCbI,nnn anCeccya.

Heco6JIIOeHHe DaHHbIX npABIN 6e3OnaCHocTH npBBeTe K OTPbIBy nITpABMaM KOHeuHOCTei.

Bbl6pacbibaemble 06beKTbl

OCTOPOHHO

HHeHObBm MExAHn3M MoHcT BtRnBaTb NpeMeTb H Bbl6paCbIBaTb Hx H3
HnOo 3AnpeuEHO HnapBaTb Pa3rpy3OCHN HHeoB B CTOpOH HaxOaIu
NoBn3OCTn IIOe, a TanKe No3BOJrB HOMy-JIb6 HaxOaNTbCn nepeD
CheroooHTneJeH. HeocBIOJedHe N daBH X npabn 6eOnacHO TMOH cTa1
PpHnHO TReHeBIX TpABM, B T.4.C CmePTbHbIM CXODOM.

BbBaTeBgda HadeBaTte 3aunTHHe 0nKn nn 3aunTHbN 3kpaH BO BpeM pa6oTbB 3eCHOOHCTHeMe, a TaKeero perylnpOBKn Hm peMOHa,TOb6laaunTTbB 1B OT NOctOPoHHN XnpDoMEToH, HOTOpB MOrY Bb6PacBbATbCn 34 MaUMHbI.

Bcergda CneDnTe, B KaKOM HApPabLeHHN Ot6paCbBaETCr ChER. HaxoJaHneCe HEnOdaJIeKy NWeEXOdbI, DomaHmHe JxIBOThBHe IIN MHyUeCTBO MOrYT 6bTb p HIN NOpeKxDoHb Bi6paCbBaEaMbIMn PnpdMeTAMn.

PaoTae co cheroOCHHTeIeM, cIeHTe 3a OkpyKaIOeJ 06ctAHOBHO. By TcHHeHHe HceroOCHHTeJIa NOBpX HcOTOpbIX PpeMeTOB, TaHx KaK rPc KOBpHN, Ra3eTbI, HpyuHn I KamHn, ChpytBIX NOD CHEROM, MOKeT pINBeCT BByopCbIBAHIO 3THN PpeMeTOB Chee3 JeNo6 NII K IN X 6IoHnPOBe 5HEK MEXAHN3Ma.

PpOABJIeT Oco6yO OCTOpOHHocb npn pa6oTe Ha Dopore nHn neWexOHOJ HIOKKe, NOhpyToI rpaBnem, a TAnKe nepceKaar nx.
Otperynpyte BbICOTy KopnycakOnkeToppa,ec/Heo6xOIMo Ipon3BecTN OCHTK NOBepxHOCTN, NOKpIToR rpaBnEM nIN ue6HEM.

HJIANPEUHO HONJL3OBaHT CHEROQHCTNTbPRAOM CO CTKJIHHBMN ORpAHNDEHNIABTOMO6JIIMM, CTEKHINHbIMN CTEHAMN, O6pbIbAMN I.T.D., He yCTaHOBNBHAJIENKAIUYOL PA3rpy3KN JHeNo6A.
O3HaKOMbTecb c TeppHTOpneH, Ha KOTOpOH PpECDToT OcYuEcTBtB

aMonoybopohhblepaobTb.IPomTe rpanuI neeXoHbIX dopOHeK n oBbe3 IBeCTmyn.

Wn
TTOFOACH8

OCTOPOHHO

Ecnn onepatop He6peHHO OTHeceTc H npHcyTcTBIO Detet, MoHET npOn3 TpaHpTaHn HeecAchThb CnyaH. Detet qacto npBHeAhoT pa3JnHHe yctpoCTBa H TO, KaH OHn pa6OtaHOt. He cIeYet DymaTb, YTO DetE moc 6ydet octabTaCba Ha Tom He MeCeTe, rge Bbl BnDenn Hx BnocdHm

He donyuchaiTe Detey Ha Teppntopno paobtI cherooohnTEnla. Detey hac npBlekaot pa3nuHbte yctpoCTBa. NomHTE O HaxOrauxxBokpyr IIOJx.
Bydte 6dtelbbl, n ecn dTe 3aIyT Ha Teppntopno y6opn chera, MaunHy.

Jne.3anpeueho donyckaTb deTei K ynpabHeHMo MaHHoH.

OeHbByDTEOC06eHHO BHNMaTeIbHbI, np6nHaKcBHyrIaM, KcTAm, DepeBbR MOrpaHnHbAioUmm 063Op 6bektam. TaM mOyT haoOntcbcA detn.

TaeJbIM

Be30nacchoctb pa60tbl BnraTeHa

OCTOPOHHO

YcNoBm 630nacHOn 3nCnJyatauMn CHeroOChTHeJI RnJIteCn npaBnblbHbI yXoH N TexNHueChOE 06ClyNHBaHne DBrHateJe. Heco6LIOHeH npaBn 630nacHocTH, ONcaHHbIX B DaHOM pyKOBoCDtBe, MOKeT cTaTb npHnHO TcOeEbeX TpABM, B T.4.CO CmepeTbeHbIM HxOdoM.

• OTHJIOHTe BCE CHOPOCTn I NOCTaBbTe KOpOBky nepeaday B HeITpaJIbHOe no peed TEM, KAK BKHIOUaTb DBHrTaTeIb.

• PnnpoBedeHm qHCTHn, peMOHTa nnn oCmOTpa cheroOOnCTHnTnra y6bDnBdrarateIb BblJIIOHEH, KInouy 3aKHeRnna BblHyt, a BCE DnBnHyUneecq QOctAHOBHeH.

3aepoHNO npKacatbca pykamn Hn HOramn K BpaauoMCA DeTajm. depHNTecb B CTOPOHE OT CNTeMbblb6poca.
3aepueho pa6oTaHa HceroOohCTHTeNe 6e3 yctAHOBJIeHHbIX n pa6oTaHADnHOaunm 6o3aumTHbIX npncnOCoJIeHHn Ipyrnx yctPOIcTB, 06ecneYBaUaUMx 6e3onacCHobT.
3anpeuO octab/ta 6e3 npcMToPa cheooCHTHe b pa6oTaIOHM DInaratelem. Bcerda OTHIOyauTe WHeHOBbie MExAHN3Mb i CpeCTBa ynpCenJeHnEM, rnyUunDeIbrataeJIb N BuHIMMaTe KIOUHO 3aKHHaHaR.

aBHeHeped HauJOM y6OpHN CHera DaIte DBrHrAeTIO BPeM aADANTnPoBaTbCg K TemnepaType OKpyKaIoUe Cpebl.

• Ppi n3HcnpnyatauMH moDJIeC 3JeKtpoDBnraTeJHM NIN DnBnraTeJHM C TexHnueckoe o6ClyKbHaHe H xpaHeHne

3eKTPnECHM CTAPTEOP M CNOJIb3yIte ydINHITEN I N 03ETKN CORLACHO Tpe6oBAAHAM PPON3BOITEN.

IcnoN3yIte 3a3eMlneHHb TpExnpoBnHb IITENCEJIbIg BCEX CHEROCHNTI O6OpyDobAHbIX 3JIeKTHPOBnRAtenJIM ININ DBrHrATeJAMN C 3JIeKTPnueCCHM CTapTePOM

OCTOPOKHO

OnachocTb o6paTHoro xOja

BbICTPOBTHBAHNEIyCKBOIOTpOCA（6oPbTHbI XOa）PiPHTHEBAtyKCHb HpyK JdNBIeTIOHOToKAKBlyCynEeTeOTYcNCTbIg.30MOKET pNBEChT K nepeiOMa,IIyHbAMn bILbHXAM.

• Ecn no6bn3ocn npno3oJna yTeJka npnpOHorO nI IN cKHeHHoro ra3a 3anyckai Te DBnrataJIb.
  He HcnoIb3yIte HaxoIaIueeCnOd DaIbeHnEMpyCKOBle HnDHOCTN, HcnpaeHnJIerKo BocIaMeHrOToC.

Topruehe nobepxnoctu

OCTOPOKHO

PabotaoHnBnraTeBbpaabTaBaeTentno.DeraHnBnraTea,ocobeho nyHntel,HarpebaOcTdoueHbBbCOKoTEMnepeAtpyb.

Hec6noeHHHe daHHbIX npABnB 63oNaCHCTH MOKET pNHBcTH K TAKeJIbM OKOrAM PnPnPHKOCHOBHH.

3anpeheo npnhaTcK roPHeMy dBHrTeNo nnn rnuuTeNo. PpeJe,em pnpnaCAtbck R rnuuHTeNo, uHHpam dBHrTaN epepa padnatopa.NoBolte Nm OCTbTb.
- N3BNEkaiTe Mycop H3 TnyuHTeJI I 06LnACTH qINIHpOB.
- PpEKeJc, cHcNoIb3ObaTb 06OpyDobAHnHe HcOeOpBa6oTaHHoI TeppHTopHn, NOKpbITbNLeCOM, TpaBOH nHn KcTpAHIOM, ycTaHOBnTe NcKporacCTeBn NODaePbHXBAIte ERO bPA6OcH coCTOBHH.
MOnIIN CIIIA:HCnOJIb3OBaHHe HIN 3KcNpyataJH DnRrTeJHa TePPHTOpH NIM PdOM C TePPHTOPHNOKpBTIO JECOM, KcTApNHkAMn HIN TPABO,6e3 OCHaENH CNCTEM BbIXLOIHbIX RA3OB NCKPOYOBNTeJEM, KOtOpB NTBeyeaCTaHdaptam MeCTbX 3aHOHOBNI 3aHOHOBUTATA, ABINETC HapUWeHHe HOpMATBa Public Resource Code pa442 B WATE KaHOFOPHN. B dpynx Wtatax FeepalbHbIX TePPHTOPHX MOrTy DeIcTBoBA TbIObHbe 3aHOHbI.

OCTOPOKHO

DaHHbCHerooHCTHeBdoJKeHOBcLyKHBaTcBcOJHKbHMObpa3OMdIa
DIOeHApKaHH6E01aNACHOCTKcIIyTAauTHn. HecoBIOHeHne IpABnI
6E01NaCHOCTh, OINCAHHbB DaHHOMpyKOBOCTBE, MOKET cTaB pIHHHo
TBkHEbX TpABM,B T.H.CO CMEptEBHbMHXCDOHm

• Pnp npoBeHnTexHHueckoro 06cnyHbAHn Hnn peMOHTa CHeroOCHNTeJI BblKIOUHTE DnIgATEB, noDOKJNTe, noHa He octahOBRTc BCE dNHyuMeCt DeTALIN, N BblHe TE KHOU 3aHNaHn, YTObI KTO-HbEyb CNYaHNO He sanyCT DBIgATEB.
  Peynno npoepeTne, kak 3aHnytbl cpe3hble 60Ib n Dpyrme deTAM, o6ecneuHt b 6e3oNaChOCTb pa60Tb CHeroOocNCTteTIA.
  CneTe, T06blraHn 60Tb1 6bln 3aTHyTb1, n noDepKmbTe cherooB XopoWEM COCTOHN.
  He cneyuET npene6peKHTeIbHO OTHoCtBcra K yctpoCTBaM 06ceNeyHn 6e3onachOCTn. PeryIaHPO npoeBpTe Ix coCToRHe N peMOHTpyTe, ecln He FyHNuONHyrOT HndJeKaUIM 06ba3OM.
• DeTALMOTN3HaWbTaBcNOBPeHdaTbCnINLOMaTbCn.PeyIaPHO npoBCO MCMOT DEtaJIeN I NO MEpe He6OxDMOCNTn 3aMeHnTe IN DeTaJIaMI,PEKOMEHODABAHbIMN NfROTOBITEJIEM.
  PeryIpaHno npOBepRte yHKnIOHaJIbHOCTb cpeCDTB ynpaBHeHH. Pn Heo6xOdmocTN npOBOnTe peryIpaOBky n 06cIyKmbAHne.
  IPOBDAPEMOHT,ДЯЗAMEHNCHOJIb3yTeTOJIbKOABTOpHINPOBaHhIE DeTaJIK 3KKBNAJIeHTHbE HMI.

OcyueCTbIaHanaHy nperynpOBky, Bcerda co6nOaTe COOTBETCTBNE TBI 3AeKMM xapaHTepnCTnKAM.

-Дя npOBeDEHЯ KaHNTaJIbHOrO peMOHTa I NOJIHOrO 6cLyHnBaHnCneJyET ObaPauTaBcra TOLbKO Ha aBTOpIN3HPOBaHHBe CTAHmTexHnueCHOrO 6cLyHnBaH
YCTAHABINBAIte ToJIbHO Te pInIOJHEnHn I akCEcyapbl, KOtOpBIE yTBepDnI INrTOBHTeCBHEROCHNTeJI, Nl60 3KBNBaJIeHTHbIe IM (HanPIMep, KOnEChblnpOTIBOBcBc, KaHmbl, n T.D.)
3anpeeHNO npoBnTb kakne-ny60 perynipn pa6oTaOuem Dbratene NCKIOUCHENEM CNTyaun,OTdJIbHO OROBOpHHx n3rOBoHTeMe).
- Ecnn CheroooHCTnTeIb 6ydt XpaHnTcB npoJIoHNtEJIbHOe Bpem, 063aTeIb npOHTne COOTBETCTByIOUpi pa3dEn n3 pyKOBODCTBA no 3KcNpyaTuIN.

HaKleiKN C nppeynpexKeHnMaO 6e30IaCHOCTN

Bblyk Nepe 3cknnyatauuecheeroohcTneI npoHTte hakleyn c npdeynpejdeHmM.3TN npdyneJpeHn H npdoctepeKHeHn CdeIaHb I nla Bawey 3auHtB. BHMaTeBHO npOHTte N cJeDyTe BCem npdoctepeKeHnM Ha hakleynhax, YTo6blN36eHaTb N nobpeHdH CheroOHCTHNE.

OCTOPOKHO

Ecnn HauJeKn C npDpyPnHexHnAAMn O 6e3OnaCHOCT N3HOWeHbI nn POBpeHdo 3akaJHTe HOBBe HauJeKn y CBOero MeCTHOrO dInepa.

Hand pWar HANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHANHAN

Tect 1 - YnpaBHeHne WHeKOM/KpbIbHaTHoH

Pn 3anyeHHOM BnRatene:

OCTOPOXHNO Onachocb amnytaun

AHHbI CHER0OCHNTeJIb OCHAueH HeCKoJIbKIMM MEXaHnuecHmM CHTeMaM

6e03oNaOCTOn 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 6006eBcHnHb 60

HHe TcTob. Ecln CheeroOunCTHeIb pa6oTaet He TaK, KaH onncaHo, HE HaKMnte H ydePknBaTe pblar cuenlneHn. (CheroooNCTHeIb doJIKeH nay 3KnlyaTpyIte erO. HemeJeHNO o6paTHTeB K CBOeMy ABTopn3OBAHOMy DnIepey DnIKHeHne BnpePe).

Tect 1 - YnpaBHeHne UHeHOM/HpbIbUbaTHoH

Pn 3anyeHHOM DBIRatene:

Tect 3 - YnpaBneHne Free Hand

Pn 3anyeHHOM DnHrataTe:

HaKMnTe n yedepKmbaTe pbyar uHeKa. (UHeK/KeIbuaTaKa DoJIHeN BpaaTaC)HaKMnTe pbyarnu HeKa n CuenneHn. 3aTEM OTyVCTe PbHar uHeKa.
OTnyCTHe pbHr uHeHa. (UHeK/kpblbuaTha DOnJIeH OCTaHOHTbcB TeueHne(CcIeJIeHHe N UHeK DoJIHHbOCTaTbC BJIIOUeHHbIMN) 5 cekyHd).

3aTeM otnyctnte pbuHc cuenenHeN. (CuenenHe Hn HeK DoJHKb BblIOUy

Tect 2 - YnpabLeHHem cenJIeHHem

KoradBnataIb 3anyuH, npyhar nepehNIOUeHn CHOPoTei CTouT Ha 1-oi nepepaue:

• HauHmIte u ydepXnBaTe pbyar cuenHeN. (CheroOuHCTnteB doJKeH DBNHeHne BnpeD).
• OTnyctHte pbHar cUeJIeHn. (CheroOoHcHTeIb DoJIkeH OCTaHOBtbcra).

Qnncahne xapaKTepeHcTnK npbIyarOB ynpaBJeHna

XapakTepnCTnHn DBratela npbUarnynpaBHeHn

IIOJyHnHIO HOpMaunO xapaKTepeCTnax DnRaTeJI N pbiarax ynpabJIeH 06paauTecb K pykoBODCTBy no 3KnnyatauIN DnRaTeJIa.

XapakTepnCTnHn n opraHbI ynpaBleHn CHeroOouchTHTeJI

OncaHne3HaOKPpOHH

A

PbYar WHeKa - HcNoJb3yeTcR dIaKTHBaUHn DeakTHBaUzMn WHeKOBOFo MEXAHNMa I KpbIbUaTHN. TTo6b1 BHKIOHTb, HAXMMTE BH3. TTo6b1 BbIKIOHTb, OTYNCTHe.

B

3 2 1

PbIar nepeKIOUeHHn CHOpocTe - NO3BOJAEt ONEpatopy NcNOJIb3OBaBbOHy H3 PAnTH NepeDnHx n DByX 3aDNHx NEpEDA. JnnepeKIOUeHHN CHOpOCTH npBBeDHTe PbIar B JeHaEMoe noJONHeHne.

c

IPIMUEAHNE:He dBnraTe pbUar nepeHIOUeHcy CHOPoTei, KOrDa BHIOUeHO cuenHeN.3To MoHcT NOBLeYb 3a co6oB cepE3HbIe NOBpeKdHcy CHTeMbI npBODa.

D

PyhoTHa NOBOPOA HeNo6a -Ha NaHeJI (ecHn HmEeTc) -NcNoIb3yTeCn dN NOBOPa TaP3py3OHOro HeNo6a BBeO Nn BNpABo.

PyOHRTKa NOBOPota JHeLO6a -JIeBOCTOpOHnra (ecnnmEeTcra) NcNOJb3yeTcra nDa NOBOPota pa3rpy3OHOFO JHeLO6a BNeEO HIN BnPABo.

		Опесане3нachуонРаюн Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья Спл�аТацья
E		П配电лочателоворота Нелоба -... Зелочателоворота Нелоба -... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H... Зелочателоворота H...	Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho Опacho
F		Уралене Free HandTM - NOCEннхдг ычаг сцелени (пебо рухи) и рычагш.... (правим рухи) постом OTератуOTуNTг ычагш�ка,Чтошы И.... Ороганы урален. Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б ... ... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... Б... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... В... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... ... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... B... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H .... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... H ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M ... M

Операцья

Ipeed 3Kcnnyataune CHeroOoHCTHTeJ

OCTOPOHHC

Ipeed NaHApOEM 3cHcNlyatauHH CHeoOCHTHTeJI Heo6XoHMo 03HaKOMITbC pYHOBOCTBOM No 3cHcNlyatauHH.HeocToOpHnOe 6paueHne c daHbIM N3dienem MOHe TpeDCTABJIb Cepe3HyO onaCHOCTb.

3aPpeaaetcpa0taTbcoCHEROOHTeIeM6e3yCTAHOBJIeHHbIX 3aPnncnocoblenk, KpbIeK n HNTKOB.
- Pookdpa6ooye MeTo, Bcerda rnyuHTe DnraTeIb.
Ipeep npochtno KOHyyxa KpbIbUaHTKn HIN pa3rpyoHoro JKeIo6a, neepnpoBedeHNem perylnpOBHNn peMOHTa arperata HeooxOIMKIOH 3aIKHraHH.
- yxodr ot cheroouhctnte, BbiHbTe KIOU 3aKnraHna.
- ⅡIa ChnKeHnO nacHOCTn BO3ropaHnepKHTe H3dJIHe B YICTOM 6e3 Haeta rpaHn npoINBweroCOTJINBa Hm MacJa.

EeTeCb, TcHa TeppntOpnn pa60tbl CheroOCHNTeHnKOro HET. 3appeaae HanpaBnTb pa3rpy30Hyh JKeIb B CTOPOHy IIOJe, 3dAnHn N ABTomObnei.

1. 3aynCTHe DnBraTeJIb. 3a HnHΦopMaunHe O DBnRaTeIe 06paauTecb K pyKOBoJ no 3KcNlYatauH DnBraTeJIa.

P NoBepHnTe pyKoTHy BpaueHn HEno6a Cnn D, pnc.3) nIn nCnoB3yT nepeHnIOuATEb (E), T06bl yTaHOBNb HAnpaBHeHne Bbi6poca Chera.

3.ДЯ moJen c pyHoi perynhoBHOI dePnEHTopa: Oclab6Te 6apauKOByH TThbIX rayHy,ydepHbBaOuSyIO nePnEHTOp HJeO6a (I).YTo6bI CHER ot6paCbBaCra daN pOnHHMNTe peNtOp YctahOBHt e PnEHTOp BKeJaMOe NNoHOHe H 3akpyTne 6apauKOBHy raiHy.

a TaHIOI MODEJI c pblarom YnpablenHa naneiC noBbHyTObHara ynpablenHa dePnEHTOPOM (H) nepeBmHbTe DePnEHTOP BBepx HIN BTO6bCHER OTbpcBaBcN DaIbue, NOHNIMTE peDpNETOP.

MoeJeIe 3neKTPnueChm YnpaBHeHMe DEeNtOpOc NOMOuBo TpeHnIOATE AeDeNtOpa (J) nepeBDnBHe Te DeNeKToP BBepx HIN BHIN. CHER OTo6pacbIbAon DaIbue, POnHMInTe DeNkTOp.
4. HcnoJb3yIte pIbIar nepeHJIIOUeHHa CHOpOCTe (B), YTO6bl BbIbpaTb nepeDHIIO 3aDHIOO CHOPOCTb. Pn OHCTKe OT BnAHOHRo TnHENoR O ChEBA BnIOuHaTe Hn3He CHOPOCTn.PnIOHnCTKeOT JERKHO O CHERi NIN TpAHcNOPTnPobKE McN0JIb3 60Je e BbICOKHe CHOPOCTn.

PnmeHne: Bcerda yctaHaBbBaIe peryIaTOp ckopoctn dbratEn B noJIOHeH N FAST ("nonhny ra3").

1. NIOHOCbIO HAKMITE pyhar uHEKa (A), 4TO6bl BKNIOHTB BpaueHHe uHEKa. OCTAHOBITb BpaueHHe uHEKa, OTNCTTE 3OT pbiar.
2. NoHocbHn HauMnte n dApKInTepeBc qcnIeHn/FreeHand (F/G), TTOsbI BkIOUcH cenIeHne H NauBt BdnHHe CHEROooCTHEn. TTOsbI ocTahOBnTB CHEROOCHNTEN, OTNCTHn 30T pbHaR.

PnmeaHne: Ipeed nepeKIOUeHHem CkOPOTe Bcerda OTyckaIte pbHar cen

1. Korda hatab pyhar uheka (A) n pbhar cuenlennna (F), aKTHBpyeTcB bhyne noBopom Hjno6a pbyarom c nahen (ec Hand. 3to no3oBnHem BAM OTNCTMb pbhar uheka (A), qTO6bI nCIOB3OaB TnOyHe pbharynpaBnHema. UHE 6ydt BPAuATbCS Do tex nop, noka He 6yDnOHTbHnB HauHTe Ha naHEn pykoAthy nobopoTa Hjno6a (B, pnc. 9). DnBaPaeHnX pbhar cuenlennHa-Free-Hand.
2. Pn HJHANMOHO BHKIOHTb NOORpeB pyKoTcN C NOMOuBNO nepeKnOyateJIa (L) (ecmHMeetc).

OctahOBHa CHEEROOCHNTeJIa

1. Otnyctntpe pbHar uHeKa (A, pnc. 3).
2. OTnyctnte pbHar cquenHeNn (F).
3. 3aIywnb DnRatEnb. 3a HNCTpyKunmM O DnRatEne obaaJTecb K no 3Knnyatau nn DnRatEna.

C. YnpabLeHne NOBOpOTom HeNo6a c NOMOuBIO pyHOaTHN leBoi CTopoHbI (ecn HmeeTc)

Haundte c leBOn CTOpOnbI pyKoTHy nobopoTa JHeNo6a (C, pnc. 9). IInn noBoB bpaauite 3Ty pyKoTHy.

PbUar cUeIeHnE Easy-TurnTM (ecnN nMeetc)

Iy 60eHn noBopoTa pa6oTioe O CHEROoHCTHTe 3aHmTe pbHar (pnc.4).

PpHMeaHHe: Pn 60nbwo Harpy3Ke TpydHee BkIOHTb FyHNIOEasy-Tum. pHyar neped Hauanom nobopoTa.

Pn HauHATMa HbYBaH Easy Turn OTHIOHaTeC npINbO Ha OJHO n3 KOJI pnpOJHaet Bpaaatbc. Pn OTNcyKaHH NpUarA Easy-Turn ABToMaTHeeCKB pInbOHa 0ba HoLecA (PMC.5).

Ocbo6oHdEHe KOleca - cTOnOpHa pyka (ecn nMeetc)

HeKOTOpBie MOdeJIIN OChaIeHb CnCTeMoI OCB6OJHDeHn KOneCa OT pInBOda 0BeJeHHn nepeMeIeHHn CHeroOCHNTeJI npN BbIKIOeHHOM DBrarateJIe.

I Mdoen co ctonopnoh yho: Koneca, ochaehnble ctonopnoh py. (PNC.6) MOHNO NIOHcTbO OCBoDHTb OT CuenHeN, BByTHyB pyHu DO I KOrda ctonOpNo h TnΦT OCBoOHaet KOleco. 3aTeM NOBepHnte pyKHy, YTO CHOBA He BKNIOHvPiNbOBD Ha 3TO KOleco. 4To6bl BKnIOuHTb PnBOD KOleco. npoeeC B O6pTHOM nopAKe

Ocbo6oHdene Holeca - cTOnOpHbIe wTnΦTbI (ecnn HmEIoTc)

HoeneaOchaueHHbte CTOnOpHbIMUHTnΦTAMN (A, pnc. 7), MOJHO NOIHOCCTbO CHAB WHTΦT H BCTABHB ERO B HApYHKHO OTBepCTHE OCN. TTO6bl BHJIOCHITb NOBOTOPTE npocce B o6pATHom NOPdKe.

PerylnpOBka deΦJIeKTopa

A. PyuHoe ynpablenHe DeΦIeHTopom (ecn HmeeTc)

Ocna6bTe raiHy deΦIeKToPA (A, pnc. 8), yctanohnite deΦIeHToP B JeknaEMa3aTet 3aTnHte raiHy, YTOsbI zakpenNTb deΦIeKToP. HTOsbI cher ot6pa DaJIbe, noDHHMITE deΦIeKToP.

B. 3LeHTpuechoe ynpabIeHne deΦlehtopom (ecn HmE

Pn 3aŋyueHHOM DABrAteIe NaHMMTe Ha Ondy H3 CTopoH nepeKlHouTaTeIa (B, pnc. 8) T06bI nepemecntb DepeNtOp BBepx nIN BHN. T06bI cher dAbJIe, noDnHMITE dePeHTOp.

C. YnpabJIeHHe DeΦJIeHTOpOM pbIarOM c nAHeJI (ecnI

IpeepBnHbte pHyar dephiKeToppa (C, pnc. 8) Bnepei nn Ha3ad, TTo6bl nOnyCTNTb DephiKeTopp. YTo6bl Cher ot6paBbAcn daJIbwe, noHNMTe dephi

PerynpoBHa nobopoTa Jel06a

A. ΘeHTpuechoe ynpaBHeHne IOBopoTOM HeIo6a (ecn HmeeTc)

Pn 3anyeHHOM DnIgATEne HAnMITE HaOHy n3 CTOpOH nepeKIOHateJI pnc.9)YTO6bI NOBepHyTb pa3rpy30HbI JKeIb6(B) BJIeBO nnBnPaBO.

HanoJHeHn ToNnBHoro 6aHa
No Bonpocam HanoJIHeHn ToNnBHoro 6aHa n 3a peKOMeHaIaIcIyMa m no TOnl
ObpaauTeCb k rykoBoDCTBy no 3KnIyatauMn DBrHrataJe.

OuNCTHa 3a6NBweroocpa3rpy30HOro

ONACHO

Onachoctb amnytaunu HTOBTOPOE

HcyAepy30OHm HneObe HxodnTcB BpaauoHneC HoNEco, O6pacsAouee Cher. Pablbmyonactb HpbIbYaTHy. 3anpeaaetc pyaAMN HCTNTb pa3py30HbHneO6. dIn OCHTHBcerda nCnOnb3yTe npOCHTHOHHTPYMENT.

Heco6nOHeHne DaHHbIX npabN 6e3oNaChocTH npHBedet H OTPbBy nTAAK TpaBMAM KOHeuHOCTei.

Camo paccnoctpaheneHHo TpaBMOH, HOTOPYO NOyauoHT Ha CHEROOHCTHTEAX.
BBAHIOIO NOBpeKDeHne pyu npn KOHTaKe C BpaAhoeCn KpbIbuaTHo BHyTt
pa3pry3oHoro JHeNo6a. 3AnpeuHO OcyueCTBbOcHry pa3rp3oHoro HeNo6a
pykAMN.

Bb6pacbIBaEMbIe npedMeTbI

Tahhe npedmetb, kah rpaBn, kAMHN nI npOyM yCop, B cnyae noHaHnF KpbIbHATy MOrY Bb6pabibBaTcB C cnIO, DoCTaTOHOH dIra pNmHHeH TpaB! HaeceHH NOpeXeHdN MUYECTBy IIN CAMOMY CHEFOOCHTEnIO.

YctaHOBNTe cana3Kn Ha D0JHKHyO BbICOTy, B COOTBeTcBn C TINOM OHTIaEMOI NOBEXHCTN, YTO6bI ObecneuTH Heo6XoDMoe pacCToRHeNo 3emNI.

DAnHbI CHEROOCHNTeB Cha5BeHc IyBMy Cai3AkhMn DJIpeRyIpOBHm BbcOTbl, paCNOLOKeHHbIMn H BHeUHc TcPOHO KcHyXa UHeKa.C IN NOMoUbIO MOJOHO npINOHNMaTb CHEROOCHNTeB Hau yPOBHeM 3eJIn.

Pn y60pe chera c Tbepoi noBepxHocTn, TaOH KaK MoeHbIe dopor n TpoTyapbl, noHMmaTe caa3Kn, YTO6bl Oyctntb CheroOuHcTntenb 6lnke K

Pn y6bOpHe cHera C KAMeHNCTbIX HIN HePOBbIX NOBepXHOCTe NODHMaIte CHEROONCTTEnb HAD YPOBHEM 3emN, ONyCNaJcA1zKn. 3To 6yDet CNOC6C TOMy, TTObIK KAMHN IN PpOHy MycOp He 3axBaTbIbALncb N He BbI6paCbIbAN MEXAH3MOM.

1. OnpeJInTe, KaHOn 3a3Op BbXoHTeHMtB MeHyDIOHeO6pa3BaTeIeMHa nCTOPOHE KOHXyXu IHeKAn 3eMaNl. PnI OUnCTHe NOBePxHOCTn, NOKpbTOHeO6xoIMD IOCTaTOHNO 60JIbIoH 3a3Op, YTObI KaMeUKN He 3aXBaTbIAhCHeroOooTHTJeTM.
   2.ПлонITE noД loHeo6pa3OBaTeIb KOLOdHy, BbICota KOTOpO paBHa JHeJa 3a3opy.
   3.Ocna6bTe raKn KpeJIeHncaIa30K(A，pnc.11）n CdbNbTe caJa3Kn copnKoCHOBeHHn c 3emJei.3aKpyTne raKn KpeJIeHHn
   4.YctaHOBHTe Ha TY JKe BbICOTy caIa3Hn Ha DpyroIN CTopoHE cHEROONCTN

MeHHce3OHHoe xpaHeHne

Ecn cherooohctntelb6ydt xpaHnTbC B TeueHne Tpndatn (30) nnn 6oee HnFOPMAuO pacncaHn npoeDpyax Texnuecce30Ha pa6ot, pehOMeHyTeC npdeLaTb Cnedyouane wan, TTo6bl noTROBnBCnyHBaHn OpaauaTEcb K pyHOBOCTBy no 3KcnNyatau nn DBnratae. CHERooHCTNTelk XpaHOnHIO. Bcerda o6paauTecb K COOTBeTCTByoUeMy paDeIy I3
pykoBoDtBA no 3Kcnnyatauun, ecn cherooOHCTntelb 6ydt xpaHnTbC Cma3Ha cnCTembl ynpabLeHHN

3a HOpMauee O XpaHEnn DBratela 6paauTecb K pyKOBoCTBy no DBrataJIa.

PImHMOaHHe: TonIbO DoIHHo 6bTb N3pAocObaHO nIh O6pa6OTAHOCOTBcTe60pa3OM, TOb6bl npEoTBpaHTb O6pa3OBaHHe cMOHCTbIX OTIOHEHn Ha 6aKeJUaHHe nn Hap6iOpatope BO BPEM xPAHEHN.

OCTOPOXHO

Onachoctb BO3ropaHn B3pbBa

BbHn HrHo BocnAmehReM, aero Napb B3pbBoOnaHb. Napb 6eH3nHa paacnpocTpaHbTaCdo ydaenHHbIX hToCHHHOB 3aHHraHn, qTO MoHET npBeB3bpHy nnoKapy.

Bydte octopohhbnpno 6bpaehn C 6eH3nHOM. Hateropueckn 3anpeaaetcr CherooohCTHeB C 3aJIbTBIM B 6ak TOIINBOM B NOMOEHHN HIN B PINOxO poctpaHCTBe, rge npbl ToIINBa MOryT OocTHb OTHpblTOrO ORH, hCKpb 3anaIbHorO yctpoCTBA, HanpImep, B neH, BOHOarpeBaTeNe IIN cyuNNKe oJekdb.

OCTOPOHHO

OnachocTb amnyTaun

Длбьб�ансй 3кглуарази снгоочптел OчEH BaKHO，YTOБbl npOcBO60HdENH bIharOB ynpaBLeNHa OTKIOHauNcB Te 3JEMeHTbI，KOTOpbIMn OHynpaBIAHOT. Hb KoeM clyuye He 3KcHnyATpyte ChERooCHNTeJI，ecm pHyyPnaBLaHHe he pa6OtaTod JOnkHbIM o6p3OM. YTObI y6eDITbC B nPaBnIbHOCTNp60Tb CM.pa4en IpoBOPka CnCTeMb 630anacHocTH.

H K CmabaiTemexAH3MbI pyharaFree Hand, pchara nepeknquhenckopctey pbHa EasyTurn/Easy Steer noocle kakdbx 10 cacob pa60tbl, m6o no mepe Heo6xo xpahtb06ecneHTb 630nachyo pa60ty.

Cma3ka uHeKa

Cma3ka peyuHTopa wHeKa

PeyHTOP 1WHeKA CMA3bIAEaTc H A 3aObeA He Tpe6yEoDonOHJIeBHO mC3aHI KAO KaKTHIb6 PnPHUHE CMA3Ka BByTeHNa IIN peyHTOpUIHEKA O6cLyHKBaJcN, HAI

343yge GR132 HnKbBnAeHTHy eH. Cneyet nCnoIb3oBabHe 60nee 92 rp HNHN B CmaHH.

P3B. RQD BbHIMMATE np66ky 3anpaBHN (A, pnc.13), TTO6bl npOBepnTb ypoBe Cm3aHa HE NduH, McnoJIb3yTE OTpeoH TOHOKOINPOBOLOKHANpHMep, cYTN, TnpOBepHTb HMEETCJ LIM CMA3aB PedyKTOpe.

Cmha TaBOTHc BaIa WHeHa

C NOMOboCMa3OHOHOMDcMCA3bBAIe TABOTHNbI BANOB LHeHa (B, pnc. Hauhdo 25 haoB 3Kcnpyataunn 1060 odn pa3 3e0on. BCaHn pa3 noceJ EpeEo 60jTn uHTnTc (C) HEOEXOdIMO cMA3bIBaB bai HHeHa.

TuaTeNbHO npOuHCTnTE CHERooHCTnTeIb.

CmaKbTe BCE TOHKn Cma3Kn (cm. pa3deTexHHuechoe 06cJyHNBAHne)
Y6dntBc8bTO BCE rAkh, 60NTI H BNHTBI NIOJTHO 3aTnHytBI. OCMOT BINMbIe DInKUyIeCACTH Na PpeDMET NOLOMKH, NOBpeKHeHNI CJIyue Heo6XdoNIMoCTN npOBdTe 3aMeHY.
- OTeJaTeBce 3apKabeBwne NOBepxHocTn HIN NOBepxHocTn CO CHOJIoTOI cnErKa noTpHTe neckOM nepeD noKpaCHOI.
HaHeCHTe aHTNkoppo3nHoe NOKpbITne Ha BCE roJIbe MetaJIInueckne Yactn Ha KOKkyXe JeIoo6a H KpbIbUbaTke.
Ecln 3TO BO3MOXHO, xpaHInTe CHEROOnCTInTeIb B NOMEeHNN H aKp8 3aUHTbl OT TbJIIN I pR3N.
- Ecln cherooohcntteIb doJIkeH xaHHTbcHa yIuIe, HauKpoTe erO sp

B0306HOBHeHH 3KcNlyatauHn:

3aeneTe CBexn 6eH3nB TOJINHBb6ak.
- Y6eIntecb, 4TO BCE BnHTbl TyTo 3aTMyTbI.
- Y6eHntecb, YTO BCE 3aunTHbIe npncnocO6JIeHn, KpbIuKn I uHTKn HaxoJrTcHa MeCTe.

06cnyHbAHne

PacnicaHne TexHnueChoro 06cIyKmbaHn

Ipeed haidoJ 3Hcnyataunei

• PpOBepbTe ypoBeHb MOTOpHOro Macla
• PpOBepeTe CnCTeMy 6e30NaCHOCTN

HaKdble 8 Yacob nn pa3 B DeHb

B zelax xpaHHe Hn np 3aMeHe cpe3bIX 60IToB Hn WTHΦTOB BblbTe Cpe Hn WTHΦTb(C), CmaKbTe TABOTHnbl Bana (B) n NOBePHITE uHE HeCKOJIbKO paBHNOHPO pacipedeHNb CMA3Hy. No 3abepweHIO yCTaHOBITE Ha MeCTO Cpe3H 60IITb Hn WTHΦTb.

Cma3ka pa3rpy30uHoro HeIoo6a n deΦJIeKTopa

Mca3bIaIe MEXAHmB BpaueHnPa3pRpy3OuHoro JHeJIOBa (pnc. 14) rCyTOI CMA3K MEXAHmM dePfkeToppa - ABTOMO6bIbHbIM CMA3OuHbIM MacLOM nocne KaJbIX Dba PANTY cAcOB pa60Tb.

Ecnn n3o6paXeHa MaCnEnHka, CMAKbTe 3TO MeCTO MOTOPbIM MacJOM. Ecnn n300 Cma304HbI uPiu, CMAKbTe 3TO MeCTO KOHCNCteHTHO (JIHTHeBO) CMA3KO.

Cma3Ha WeecTnRpaHHoro Bala n ZenOppeJeIte, KaHoi Cpe3HOJ 6oIT/HTNΦ (ecIn HmeeTc) yCTaHOBJIeH Ha BaWeM CheroOuHCTNTeJI

IeCTHrpAHHbB BAI N cENH Hoo6XdMMo CMA3bIBaTb C nepHOINHNOCTbIO, yip aaeane TeHNueKeOe o6cNynBuHne. MoKHO 6opATnBcRA OfMuaJIbHOMy DNlney DIA npOBeHEn TeHNueCeCHO O6cNynBuHnA.

HIOHOHOCTpOBOAHbI CNICOK DTeJAE, YTO6bl ONpeDeJNTb, Tpe6yETcN IIN CHEROOHCTHTeJI TOBko Cpe3HO 60JTN HnCpe3HO 60JTN B KOMHNaUNC pa

Ocmotp Tpocnka czeJIeHna

TpoCHN yCTAHOBJeHb NaΦa6nKe, nIyI Hx He DOnJIHa Tpe6oBaTcBpe OJdako, ecln TPOCHN BBytHyIChb IIN npOBAcIOT, Heo6XoIMma Ix peryInp 3ToI peryIPOBHN 06paTHTeCb K CBOemy DInIepy.

ONACHO

PbBcRt b amnytaunn

Bka.

Bpa3py30HOM JHeJIO6 HAXODTcR BpaauoUmeC Koneco,OTpaCbBaOuCE CHeI TaIbIy MoYr 6bITb 3axBaueHbMexAHN3MOM IOTOpBaHb NIN TKeLo TpaBMp Camo paacnoctpahenHO TpaMOH, KOtopy NOlyaOt HA CheroOCHTHeJx,
BpeTcNOBpeKdE HpyKn PnP KOtAHTe C BpaauoUeC KpbIbHaTHOBHYTg
Dpy3OHOrO XeNo6a.

Tpe6yeT

Hpy npoBeDnHem TexHnEeCKOrO 6cIyHNBaHnna NIN pMoHTa BbHNIOT E bBrrteJIb, IIOJOnKdIte, NOKa HE OCTaHOBraTc Bce DbHNHyUneCer dTeaJI, M BbHt KNoH 3aKHeRHa.

PerylnpobknapboHoro pemn H

PnBbDhoH peMEnh HaxoDHTCn NOI NOCTOHNbHM HATJKeHNEM npyKHHbN He NIKAKHO perylnoPBKn. Ecln PnBbDHOH peMeHb NpOcKaJIb3bIbAeT, O6paTINTeCbKABTPOTHOBAHMOH MyInepy.

PerylnpOBka pbIyara nepeKIOUeHnA cnOpocTei

Ecn Tpe6yETcpeynnpOBKa pbHara nepeKIOOeHNr CKOpocTei, obaTnTecb ABTopn3OBaHHOMy DnIepy.

Perylnpobka ha6eJ Easy-TurnTM nMeetc)

Ecnn TPOCHN Easy-TurnTM pactrHnC, cquenHe He pa3bEHNRETC, KORda pbhar npaBnHEno. Otperynpyte TpoCn cornaCHO cJeDIOeI npOeDype. 1. 3aRnuNTe DnBaTae N BbHbTe KJIou 3AKnraHAnu.

1. Ocna6bTe KOHTprAHy (A, pnc. 34).
2. NoBepHnTe peryIINPOBOHyraKy (B),YTObI yDInHHb HInyKOpOTnTb TpOCH CneIeYer HATRnBaTb Do Tex nop, NOHa HE HCpe3He cIaNoHa. He DOnIKH BHNIOuHaTcNCTEmy Easy Turn 6e3 HAnHima Ha bHar yn
3. 3akpyTHe KOHTprAHy (A).

PerynpoBka TpocnKa ynpaBleHna UHeKOM

OCTOPOXHO

Onachoctb amnytaun

Ye3meHoe HataKeHHe TPOcHa 1nHeKa MoKet npBODnTb K BkHOeHHo HaKaTHa Ha pbUar ynpabLeHn HAHEOM.

YTo6bI He DoynCTnTb Qpe3MepHOro HataJKeHnHa TpocnKa, CJeDyTe npOeDypepeRyIpOBKn.

3aMeHa cpe3Horo 7tNΦTa

K CBOemy Bany C NOMOJIbCneIaJIbHbIX WTHOTB, PACCnHa cpe3aHHe B CyaJee, ecNI NOCTOPOHHH NpeDMET 3AKNIHITc B KOHXYE uHE IcnoJIb3yTE TOJIbKO AP6HNHIE Cp3eHbUe TNIKHTbI INIK KBNBAELHTHBI HmE
1. 3aIyUHTe DnBraTeIbI NoDOKnte, NOHa He OCTaHOBTcA BCE DInHyUneCg De HNIMITE NOLOMAHHbI Cpe3HOI WITHT.

3.CmaKbTe TaBOTHnUb WHeKa N NOBepHnTe WHeK, YTO6bI CMA3aTb BAI WHeKa.
HaGOBMeCTe OTBepCTNa Cpe3HO TnΦTa.BCTaBtE HOBBi Cpe3HO WTHoT ( pnc.17)Yepe3 BAN WHeKa (C).3aФнСнpyTe c nOMOuBIO WnINHTA (B).

3aMeHa cpe3Horo 6oIta

TROC#IeYUHHTe DBrAteIbH NIOOJHNTe, NOKa HE OCTaHOBRTc BCE DBNKHyIeCEr De Ondako TPOCKN
2017017017017017017017017017017017017017017017017017017017017017017017017017017017017017017017017017017

1. BBeHnTe CMa3ky B TaBOTnCbI WHeKa. NObepHnTe WHeK, YTO6bl CMa3aTb BaI
2. CoBmctnTe OTBepCTnIa 6oJIa. BCTabBe HObBi Cpe3HOI 6oIT (A, pnc. cepe3 BaI uHEka (B). 3aΦHcnpyTe KOHTprAIKOI (C).

3aMeHa cpe3Horo 6oJtA n pacnopkn

HHeHH npKpeIeHb K CBOeMy Bany c NOMOuBc NeueHaNbHbIX 60LTOB, paccHTHa cpe3aHne B Cyaue, ecn NOCTOpOHHN NpeDMt 3akJINHTC K bOKHYe IHENcNoJIb3yIte ToIbKO foabPnHBe cpe3bE BoNTbI nIKBnBAnETHbIE Hm.
1. 3aIyWHTe DnBraTeIbH nOoHdITe, noka He octaHOBATc Bce DnHyUHeCae

2 CHMMTe NOLOMAHHbI Cpe3HO 60NT.
3. BBeHrTe Cm3ky B TaBOTHNuB WHeKa. NObepHrTe WHeK, YTo6bI Cm3aTb BaJ

1. CoBmectnte 60nT n OTBepCTn paCnpKn. BCTaBte HObbl cpe3Hoi 60nT (A 19) n pacnopky (B) yepe3 BaI uHeKa (C). 3aΦHKcnpyTe KOHTprAHOI (D

2. Pn OTnyueHHOM pbHare uHEKa KpIOOH (A. pnc.16) DOJIKeH eBa HacaTepbHa

(B) He noDnMa er. MeXdy HmM MoHET 6bITb 3a3Op He 60nee dIOIMa).

2.ДуpeRyIbOuRnOcAobTe rayH cy, UdEpyRbAperyIbOoBHyIe faChn maTefurher. Ha npaktnke yeo6ho npndepKbHbTaC cJeDyUoTo pnpBaNHaNyBa NOBOPaYbRnKny.3aTeM noBpRhyE perVyIbOoBHyIe faChn yeoDyBa HTOBo Oto mETOnn "Max Inflation" (MaKc NaHdyB) ha 60koBoi TopoPe L

perylnpOboHb BNHT (E). PerylnpOboHb BNHT HMeet kpeTOBn 3a

KOTOpB Iero MOHHO ydepeKHBaTb HIN NOBOPaHBaTb C NOMOUBHO OTBepT

BCTaBHeHHo Yepe3 npyHHHy (F).

1. yedepkmba perynpobouhhe fachni, 3atraHnTe raKy.
2. TTo6bI y6eHITbC, yTO uHEK He BnIOyaeTcdo NOJHOrO HauaTHa Ha pbUar uHeKa, npoBeDHTe IpoBepHy ChCTeMbI be3oNaChOCTH. uHeOBbIM MExaHNsM dOJIkeH OCTAHOBNTbCBA TeEHne 5 cekHyd nocJe TORO, KaK OTnyuien PbUar ynpaBHeHH uHeHom.

TIOBepka DaBLeHnB B UHHax

Tire pressure should be checked periodically. Recommended tire pressure varies manufacturer. Ha npaktke yobno npndepknaBbctc cnekyoJero npabla ha dyba TONBko do OTMeTH "Max Inflation" (MaKc hndyB) ha 60koB ToPone L

3y6aTbI npNBOd (ecnn nMeetc)

3y6aTbI npBOD He Tpe6yeH N H 06cnyhBaHnH, H n perynnpOBKn. B cnyae nc np6bIe C 3y6aTbIM npBODOM 6paNTecb K CBOemy OphiunaihHomO cepBHCOMy

Ponck yctpaHene HencnpaBHOCTeI

m = 311 ;

m - 1 0 ;

12x - 1 > 0 ②

m - 1 0 ;

12x - 1 > 0 ②

12x - 1 > 0 ②

m - 1 0 ;

1 + u7 = 7 + 1 > ( 1 + u) u7 = u

1

图1

m - 1 0 ;

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

1

m - 1 0 ;

m - 1 0 ;

m = 311 ;

1

m - 1 0 ;

1

m - 1 0 ;

1

12x - 1 > 0 ②

1 + u7 = 70

12x - 1 > 0

m - 1 0 ;

1

m : x = 1 或 3x + 4y + 1 = 0

1

12x - 1 > 0 ②

m - 1 0 ;

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

1

m - 1 0 ;

.

m - 1 0 ;

1

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

1 + u7 = 4.8

m - 1 0 ;

12x - 1 > 0 ②

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

m = 311 ;

m - 1 0 ;

12x - 1 > 0 ②

m - 1 0 ;

12x - 1 > 0 ②

1

1

12x - 1 > 0 ②

m - 1 0 ;

m - 1 0 ;

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

1

m - 1 0 ;

12x - 1 > 0 ②

m - 1 0 ;

1

1

1

m = 311

1

m - 1 0 ;

1 + u7 = 70%

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

12x - 1 > 0

m - 1 0 ;

m - 1 0 ;

1

m - 1 0 ;

1

m - 1 0 ;

1 + u7 = 70%

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

1

m - 1 0 ;

m - 1 0 ;

NITE MOTOR

m - 1 0 ;

12x - 1 > 0 ②

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

图

12x - 1 > 0 ②

12x - 1 > 0 ②

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

1 + u7 = 70

m - 1 0 ;

1

m - 1 0 ;

1

m - 1 0 ;

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

1

m - 1 0 ;

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

m - 1 0 ;

m - 1 0 ;

1

m - 1 0 ;

m - 1 0 ;

( x - 2x) t - xy^2 = ( x - 2x) f^ t

1

1

12x - 1 > 0 ②

12x - 1 > 0

m - 1 0 ;

1

m - 1 0 ;

impatiab

1

1

m - 1 0 ;

1 + u7 = 7 + 1 > ( 1 + u) u7 = u

12x - 1 > 0 ②

m - 1 0 ;

m - 1 0 ;

NITE MOTOR

12x - 1 = 12x( 1 - x)

m = 311 ;

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

12x - 1 > 0 ②

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

m = 311 ;

m - 1 0 ;

12x - 1 > 0 ②

12x - 1 > 0 ②

1 + u7 = 70

1

1

12x - 1 > 0 ②

1

1

12x - 1 > 0 ②

m - 1 0 ;

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

1

m - 1 0 ;

12x - 1 > 0 ②

1

m - 1 0 ;

1

m - 1 0 ;

1

m - 1 0 ;

m - 1 0 ;

1 + u7 = 70%

12x - 1 > 0

m - 1 0 ;

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

m - 1 0 ;

1

m - 1 0 ;

m - 1 0 ;

m - 1 0 ;

m - 1 0 ;

m - 1 0 ;

m - 1 0 ;

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

12x - 1 > 0 ②

12x - 1 > 0 ②

m - 1 0 ;

m = 311 ;

1 + u1 - 1 = ( 1 + u) u1 < 1 = u

12x - 1 > 0 ②

1 + u7 = 7019

m = 311 ;

m - 1 0 ;

12x - 1 > 0 ②

12x - 1 > 0 ②

1 + u7 = 70

1

m : x = 1 或 3x + 4y + 1 = 0

m - 1 0 ;

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

m - 1 0 ;

12x - 1 > 0 ②

m : x = 1 或 3x + 4y + 1 = 0

A

2 : x^ ( x) = 10 , 2 : x^ ( x) 0. .

B

m = 311 ;

1. Mody's manualynym nestavenim ychylovača: Uvolinite maticus kridelkami, ktorá zaisfuje vchylovač Žfabu (I). Zdvihnutm vchylovača budete dalej. Vchylovač nastavte do požadovanej polohy a utiahnite ma

Modely s'pakou ovladania vychylova na pristrojovej doske: Pomocou paky ovladania vychylova (H) posunite vychylova nahr alebo nadol. vychylova budete odhadzovat sneh dalej.

Modelys elektrickym ovladacov vychlova; Pomocou prepina c ovladania vychlova (J) posunite vychlovac nahor alebo nadol. Zdvihutim budete odhadzovat sneh dalej.

2.102.103.104.105.106.107.108.109.110.111.112.113.114.115.116.117.118.119.120.121.

3.Vzdy pouzivaje naradie na cistenie a nie ruky.
