| Brand | Livarno Lux |
| Model | 10643A |
| Category | Decorative outdoor light |
| Product type | Solar ground light garland |
| Use | Outdoor (garden, terrace, balcony) |
| Bulb | White and RGB LEDs |
| Rated power | max. 0.2 W |
| Protection type | IP44 (protected against water splashes) |
| Power supply | Integrated solar panel + rechargeable Li-ion battery |
| Lighting duration | Up to 8 hours (depending on sunlight) |
| Lighting modes | White, color change, single color (3 modes) |
| Control | Switch (ON/OFF) and MODE button |
| Automatic on/off | Yes, at dusk/dawn off |
| Package contents | Solar panel with stake, 8 lanterns with stakes, connection cable, mounting screws |
| Maintenance | Clean the solar panel regularly; remove the battery during prolonged non-use (winter) |
| Safety | Do not leave children unsupervised; do not short-circuit batteries; risk of explosion if batteries used incorrectly |
| Spare parts / Reparability | LEDs cannot be replaced individually; replace the entire fixture at end of life |
| Disposal | Product and batteries recyclable according to local regulations (do not dispose of with household waste) |
| Standards | Directive 2006/66/EC (batteries) |
Frequently Asked Questions - 10643A Livarno Lux
User questions about 10643A Livarno Lux
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Lighting in PDF format for free! Find your manual 10643A - Livarno Lux and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 10643A by Livarno Lux.
USER MANUAL 10643A Livarno Lux
SOLAR-BODENLICHTERKETTE/SOLAR GROUND LIGHTCHAIN/BALISES SOLAIRES
DE AT CH
SOLAR-BODENLIGHTERKETTE
Kurzanleitung
FR BE
BALISESSOLAIREs
GB/IE Short manual Page 13
| List of pictograms used | |||
| i | Please read the operating instructions! | Wear safety gloves! | |
| =DC | Direct current/voltage | 3 light modes: white/colour change/single colour | |
| V | Volt | Lighting duration of up to 8 hours | |
| A | Observe the warning and safety instructions! | Lock/Release | |
| B | Never leave children unsupervised with packaging materials and the product. | Improper disposal of rechargeable batteries may result in environmental damage! | |
| A WARNING! | Potential of serious to fatal injuries. | Dispose of packaging and device in an environmentally-friendly way! | |
| X | For outdoor use Splash-proof | IP44 | |
| A | Caution! Danger of explosion! | Incl. Li-ion rechargeable battery | |
| A | Caution! Fire hazard! | ||
| Dimensions | |||
Solar Ground Light Chain
Introduction
This document is a shorter printed version of the complete instruction manual. By scanning the QR code, you will be taken
straight to the Lidl service website (www.lidl-service.com) where you can view and download the complete instruction manual by entering the article number (IAN) 380670_2107.
WARNING! Observe the complete instruction manual and safety notes to prevent personal injury and property damage. The short guide forms an integral part of this product. Prior to using the product, familiarize yourself with all operation and safety notes. Keep the short manual well preserved and if you hand the product on to third parties, all documentation should be passed on as well.
Intendeduse
The solar fairy lights garden set is an ambient light or a decorative light for outdoor use. The integrated solar cell and the rechargeable battery allow usage independent from the electricity grid. Any modification to the product are considered improper use and
may result in considerable hazards. The manufacturer will not accept liability for loss or damage arising from improper use. This device is not intended for commercial use.
- Parts description
| 1 Solar panel |
| 2 Solar cell housing |
| 3 Groundstake (solar panel) |
| 4 Light cover |
| 5 Base plate |
| 6 Lantern |
| 7 Groundstake (lantern) |
| 8 | Fairy lights |
| 9 | MODE button |
| 10 | Switch |
| 11 | Power cable |
| 12 | Fixing screws |
| 13 | Recess |
Technical data
Model-no.: 10643A/10643B/10643C
Rechargeable
battery: 1 × 18650 Li-ion rechargeable battery, 1500mAh , 3.2V = =
Illuminant: white and RGB LEDs
Rated power: max 0.2 W
Degree of protection: IP44 (splash-proof)
Safety instructions
PLEASE READ THE OPERATING INSTRUCTIONS PRIOR TO USE! PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE! IF PASSING THIS PRODUCT ON TO A THIRD PARTY, INCLUDE ALL DOCUMENTS!
This device may be used by children aged 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or lacking experience and/or knowledge, so long as they are supervised or instructed in the safe use of the device and understand the associated risks. Do not allow children to play with the appliance. Cleaning and user maintenance should not be performed by children without supervision.
Do not use the product if you detect any type of damage.
Switch the product off whilst storing in a dark environment to prevent draining the battery.
This product is only suitable for the specified use.
Product-specific safety instructions
CAUTION! RISK OF INJURY! Make sure that when the light is removed, the ground stakes are also removed, so that they cannot pose any risk (e.g. stumbling over them).
Make sure the solar cell is free of dirt and free of snow and ice in winter. Otherwise the performance of the solar panel will be diminished.
Cold temperatures negatively impact the battery operating time. If the solar fairy lights garden set will not be used for extended periods, e.g. in winter, it should be cleaned and stored in a dry, warm location. If this happens, switch off the product and remove the rechargeable battery.
The solar fairy lights garden set must not be connected with the power supply while it is still in its packaging, provided that the packaging has not been adjusted for exhibition purposes.
The LEDs are non-replaceable.
If the light source has reached the end of its service life, the entire light must be replaced.
The product is not suitable for use as room lighting.
Safety instructions for rechargeable batteries
RISK OF WARNING! ACCIDENT AND DANGER TO LIFE FOR INFANTS AND CHIL
DREN! Rechargeable batteries are not intended to be in the hands of children. Do not leave the batteries lying around. There is a danger that these will be swallowed by children or pets. If they are accidentally swallowed seek immediate medical attention.
CAUTION!
EXPLOSION HAZARD! Use only rechargeable batteries of the recom-. pte. Other rechargeable or single-use could explode during charging.
FIRE HAZARD! Never short-circuit
rechargeable batteries. Otherwise the rechargeable batteries may overheat,
become a fire hazard or explode.
CAUTION!
EXPLOSION HAZARD! Never
throw rechargeable batteries into
fire or water.
Expired or drained rechargeable batteries may leak chemicals which will damage the product. Therefore remove the rechargeable battery if the fairy lights will not be used for extended periods.
WEAR PROTECTIVE GLOVES!
Leaked or damaged rechargeable batteries could cause chemical burns
on contact with the skin; you should therefore wear suitable protective gloves at all times if such an event occurs.
Only use rechargeable batteries of the correct size and and the recommended type (see section "Technical data").
Make sure you fit the battery with the right polarity. This is displayed on the solar cell housing.
Functionality
The solar cell built into the product converts sunlight into electricity and stores it in a Li-lon rechargeable battery. The light switches on at dusk. The built-in LED is an energy-saving illuminant with a very long life. The light duration depends on the amount of sunlight, the angle at which light hits the solar panel, and the temperature (the battery capacity varies by temperature). A vertical angle of light at temperatures above the freezing point is ideal. The rechargeable battery will only achieve its maximum capacity after several charging and discharging cycles.
- Initial use
Before first use, remove the protective film from the solar panel 1.
- Assembling the fairy lights (10643A/10643B/10643C)
Insert the ground stake 3 into the solar cell housing 2 (see Fig. A).
Place the light cover 4 onto the base plate 5 with some force (see Fig. B).
Model 10643A only: Then tighten the light cover by turning it anticlockwise. In doing so, pay attention to the recesses
Model 10643A only: To loosen the connection, turn the light cover 4 clockwise from the base plate 5.
- Attach the ground stakes 7 to the base plates 5 by inserting the ground stakes 7 into the prefabricated notches on the underside of the base plates 5 and tighten them by turning them counterclockwise.
- Installing the fairy lights
Wear protective gloves when assembling and setting up the fairy lights.
Ensure when setting them up that they are securely positioned.
Push the ground stake 3 for the solar cell housing 2 far enough into the ground (lawn, flower bed) so it is firmly positioned upright in the ground.
Make sure it is firmly positioned. Do not use any force when assembling or setting up the product, e.g. hammer blows. This will damage the product. In order to achieve the best result, set the solar fairy lights garden set up in a place where the solar cell will get direct sunlight for as long as possible.
Make sure the solar cell is not impacted by other light sources, e.g. yard- or street lighting, or the light will not switch on at twilight. In low light the
light will automatically switch on, and automatically switch off in normal ambient light.
Insert the lanterns 6 with the ground stakes 7 so far into the ground (lawn, flower bed) that they are positioned securely and upright in the ground (see Fig. C).
- Switching the fairy lights on/off (see Fig. D)
Slide the switch 10 to position "W" or "C" to switch the fairy lights 8 on. The fairy lights 8 will automatically switch on or off at twilight.
Slide the switch 10 to the "OFF" position to switch the fairy lights 8 off.
- Charging
The battery charging period using the solar cell depends on the intensity of the sunlight and the angle incidence of the light on the solar cell. Place the solar cell as perpendicular as possible to the angle of light incidence. In this way you will receive the highest light levels. The rechargeable battery only charges when the product is switched on. For this purpose, slide the switch 10 to position "W" or "C".
Disposal
The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.
The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.
Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.
Faulty or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries/rechargeable batteries and/or the product to the available collection points.
Environmental damage through incorrect disposal of the batteries/rechargeable batteries!
Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.
Pile: 1 pile 18650 Li-ions
$$ 1 5 0 0 \mathrm {m A h}, 3, 2 \mathrm {V} = = = $$
