Product type	Vacuum sealer
Brand	Laica
Model	VT3217
Power supply	AC 220-240 V, 50/60 Hz
Power consumption	120 W
Max bag width	300 mm
Functions	Automatic vacuum and sealing, manual sealing, pulse vacuum, vacuum sealing of containers (with tube), sealing type adjustment (single, double, double extended)
Drip tray	Removable and washable
Sealing bar	Double
Gaskets	Sealing gaskets and sealing bar gasket
Built-in cutter	Yes, for cutting rolls
Locking handle	Yes
Indicator lights	Indicate ongoing operations
Operating temperature	+10°C to +40°C
Max relative humidity	85%
Usage	Household
Maintenance and cleaning	Clean the exterior with a dry or slightly damp cloth; drip tray washable under running water; do not use abrasive products; do not immerse the appliance
Safety	Thermal protection; do not use outdoors; do not immerse in water; unplug after use
Available spare parts	Gaskets (code AH1046); drip tray (code A-1044)
Warranty	2 years from date of purchase

Frequently Asked Questions - VT3217 LAICA

How to use the Laica VT3217 vacuum sealer with bags?

Place the open end of the bag into the vacuum chamber, lower the lid and lock the handle. Press the Automatic/STOP button to start the automatic vacuum and sealing cycle. Wait until the lights turn off, then open the lid.

How to select the sealing type?

Use the Sealing setting button to choose between single (dry foods), double (moist foods), and double extended (very moist foods or meats). The selection is stored as long as the appliance is plugged in.

Can I use containers with this appliance?

Yes, use the supplied tube to connect the appliance to Laica containers. Fill the container to within 2 cm of the rim, close the lid, plug the tube into the Canister port and press the Canister button to start vacuuming.

How to vacuum seal liquids?

First freeze the liquid for 12 to 19 hours in a suitable container, then place it in a bag and proceed with normal vacuum sealing. Then keep in the freezer.

What to do if vacuuming is not complete?

Check that the bag is not punctured or incorrectly positioned. Make sure the inside of the bag is clean and wrinkle-free. You can also use the Pulse vacuum mode to manually control the vacuum.

How to clean the vacuum sealer?

Clean the exterior with a dry or slightly damp cloth. Remove the drip tray and wash it under running water. Clean the sealing bar once cool with a soft cloth. Never use abrasive products.

The appliance does not start, what to do?

Check that the plug is properly inserted into an electrical outlet. If the thermal protection has been triggered, let the appliance cool down for at least 30 minutes before trying again.

The bag does not seal properly, why?

Make sure the bag edge is clean, dry and wrinkle-free. Check that the bag is correctly positioned in the vacuum chamber. If the problem persists, reduce the sealing time by selecting a shorter mode.

Where can I find spare parts?

Sealing gaskets and the sealing bar gasket are available under code AH1046 and the drip tray under code A-1044. Contact your dealer or Laica customer service.

The appliance gets very hot, is this normal?

Yes, after several sealing cycles, the sealing bar may become hot. Let the appliance cool down for a few minutes between uses. It is recommended to wait at least 15 seconds between two sealings.

USER MANUAL VT3217 LAICA

The image is too blurry to recognize any text content.

m = 311

m = 311

INDUSTRAL FED NOTE

1. 2017年1月1日

1463 062020

LAICA®

LAICA S.p.A.

Vale del Lavoro, 10

36048 Barbarano Mossano (VI) - Italy

Tel. +39 0444,795314

Made in China

www.laica.it

LAICA®

Exterior view of a modern electric device with black casing and control panel (no visible text or symbols)

ISTRUZIONI E GARANZIA

VT3217

MACCHINA PER SOTTOVUOTO

pagina 4

Instructions and warranty page 10
VACUUM SEALER
Instrucciones y garantía página 15
MÁQUINA PARA CONSERVAR AL VACÍO
Instruções e garantia página 22
MÁQUINA DE EMBALAR POR VÁCUO
Anleihungen und Garante Seite 28
VAKUUMIERBERÄT
Instructions at garantie page 34
MACHINE SOUS-VIDE
Οδηνίες και εγγύηση ακλάδα 40
MHXANHMA KENOY AEPOΣ
Instructiuni și garanția pagina 46
MAŞINĂ DE VIDAT
Navod a zámka shana 52
VAKUOVÁ BALIČKA POTRAVIN
Navod a záruka strana 58
STROJ NA VÁKUOVÉ BALENIE
Használet utesítások és garancia oidal 64
VÁKUUMFÓLIÁZÓ GÉP
21 Navodila in garancija stran 70
APARAT ZA VAKUUMSKO PAKIRANJE
Uputo I Jarnstvo stranica 78

VT3217 VT3217

Fig. 1 ⑦ ② ③ ④ ⑤ ⑥ ⑧

Labeled diagram of a portable electronic device with numbered parts for identification

1. 13
2. AutomaticSTOP key
3. 594 Kf
4. "Fus vacuum key
5. Vancier Key
   b. 'Setting setting' key (single=
   dourie - dour
6. Indicator rights
   e. SOCKS TO CANSER TUBE
7. Locking heads
8. Locating half-tre
9. Double swirl
10. Common stock
11. Vacuum touch lens, perovole grip 1mm
12. Air
13. Ginko
14. 09102
15. Seating
16. Cable
17. Dper
18. 陈小玲

Fig. 2

LAICA® 2

LAICA S.p.A.

Dear customer. Laica would like to thank you for choosing one of our products, designed according to strict performance and quality criteria in order to ensure total satisfaction.

IMPORTANT

READ CAREFULLY BEFORE USE KEEP IN A SAFE PLACE FOR FUTURE REFERENCE

The instruction manual must be considered an integral part of the product, and must be kept for its entire life. If the appliance is transferred to another owner, its documentation must also be transferred in its entirety. To ensure the cars and correct use of the product, the user must carefully read the instructions and warnings contained in the manual instead as they provide important information regarding safety, user and maintenance instructions. If the instruction manual is lost on in the event, you require additional information or clarifications, please contact the company at the address shown below: Labia S.p.A. Viale del Navaro, 10 - 36048 Barbaro Mussano (N) - Italy - Tel.: [phone] - [e-mail] www.labia.it

CONTENTS

SYMBOL LEGEND	page 10
SAFETY INSTRUCTIONS	page 10
PRODUCT DESCRIPTION	page 11
INSTRUCTIONS FOR USE	page 12
MAINTENANCE	page 13
TROUBLESHOOTING	page 14
DISPOSAL PROCEDURE	page 14
WARRANTY	page 15

Warning

YMBOL LEGEND

Prohibition

Food grade

SAFETY INSTRUCTIONS

• Prior to use, ensure the product is intact and that there is no visible damage. If in doubt, refrain from using the device and contact the retailer that sold you the product.
• Keep the plastic bag away from children: danger of suffocation.
• Before connecting the appliance, make sure the mains voltage corresponds with the voltage on the plate located up the loop of the appliance.
• This device must only be used for its intended purpose and in the manner indicated in the instructions. All other types of use shall be considered inappropriate and therefore hazardous. The manufacturer shall not be deemed liable for any damage caused by inappropriate or incorrect use.
• This device may be used by children aged 14 years and over.
• This appliance may only be used or maintained by individuals with reduced physical, sensory, or mental capacities or unskilled individuals under adequate adult supervision. Children must not play with the device.
  ☑ NEVER leaves the appliance operating unsupervised. Once finished using it, turn it off and unplug it from the mains.
• In the event of a failure and/or malfunction, turn off the appliance without tampering with it. Always contact the retailer for repairs.
  Do NOT connect or disconnect the appliance and do NOT use it with wet or damp hands.
  Do NOT pull on the power cord or the device itself to unplug.
• Handle the product with care, protect it against impacts, extreme temperature fluctuations, humidity, dust, direct sunlight and sources of heat.
• Unplug immediately after use and always before cleaning.
• If an electrical appliance falls into water, do not attempt to extract it, but immediately remove the plug from the power socket.
  Warning! Do NOT tamper with the power cord for any reason. It damaged, contact your retailer.
• Unwind the cable for its entire length and keep it away from heat sources. ⊗ Never use power adapters other than those reported on the data label located on the bottom of the appliance.

• The appliance cover is not protected against liquid penetration.
Do NOT touch the sealing bar when the appliance is on. Danger of burns.
☑ NEVER submerge the device into water or any other liquids.
DO NOT use the appliance outdoors.
- During extreme conditions (voltage 10% above the nominal voltage and temperature around 40°C), intensive use of the appliance could trigger the automatic thermal protection device. In this case, wait for the appliance to cool before using.
Do not perform more than 100 vacuum packing operations in a row. Beyond this limit, the appliance's automatic thermal protection systems could be triggered (we recommend waiting at least 15 seconds between sealing operations.
- We recommend using LAICA embossed vacuum bags or of equivalent quality. Caution: the use of unsuitable bags does not guarantee an optimal vacuum sealing.
Do NOT store the vacuum sealer with the locking handle lowered. - It is recommended to leave approximately 8/10 cm between the bottom of the vacuum sealed product and the bag opening.
- This device is not intended for professional use, but rather only for domestic use.

WARNING! BEFORE USING THIS APPLIANCE

PRODUCT DESCRIPTION (see Fig. 1)

1. Lid
2. "Automatic/STOP" kay
3. "Sea" key
4. 'Fuse vacuum' key
5. "Canister Key"
6. "Sealing setting" key (single - double - double extend)
7. Indicator lights
8. Socket for carrier tube

9. Canister tube

10. Locking handle

11. Double sealing bar
12. Vacuum chamber / removable drip tray
13. Air extraction hole
14. Gaskets
15. Sealing gasket
16. Cutter
17. Cutter slot

COMPONENT AND FUNCTION DESCRIPTION

1. Lid: creates the airtight seal required to generate the vacuum in the bag

2. "Automatic / STOP" key:

• starts the automatic air extraction and sealing cycle

- blocks the previously selected function.

1. "Seal" key:

• the appliance seals only:

• during the automatic cycle, air extraction is blocked and the bag is

automatically sealed.

1. "Pulse vacuum" key: starts the pulse vacuum process; air extraction

starts when the key is pressed, and stops when it is released.

1. "Canister" key: starts the vacuum sealing cycle for the canisters (not supplied).

2. Coping

3. "Sealing setting" key: allows the type of seal to be selected based on the load being sealed.

the look being packed:

- "single": the machine makes a single seal, ideal for dry foods such as

bread, pasta, biscuits and similar, which require a short sealing time;

• "double": the machine makes a double seal, ideal for wet foods
containing liquids and moisture, such as fruit, vegetables and cold

reats, which require double sealing:

- "double extended": the machine makes a double seal, extending the sealing time. Ideal for wet or very moist foods such as meats and cooked vegetables.

1. Indicator lights: indicate the operations under way and the functions selected.

EN English

English EN

8.9. Socket for canisler tube: to connect the machine to the canisters using the supplied tube.

1. Locking handle: to book and release the lid onto/from the base of the machine

2. Double scaling bar; makes the seal.

12.13. Vacuum chamber / removable and washable drip tray: area where the far open end of the bag is positioned to allow air extraction and the elimination of any excess fluids.

1. Gaskets: creates an optimal airtight seal in the vacuum chamber to generate a vacuum in the bags.

2. Sealing gasket: ensures the bag adheres to the sealing bar.

3. Cutter: cuts the bag roll to the desired size.

TECHNICAL SPECIFICATIONS

Voltage: AC 220-240V 50Hz

- Power absorption: 120W

- Environmental operating conditions: +10°C +40°C; relative humidity ≤ 85%

Environmental storage conditions: +10°C +50°C; relative humidity ≤ 85%

- MAX bag width: 300 mm

The roll supplied is foodgrade

INSTRUCTIONS FOR USE

PREPARATION

- Before each use, thoroughly clean the appliance as described in the section "maintenance".

- Place the appliance on a flat, rigid surface, leaving a sufficient clear space in front of the device in which to place the bags containing the food to be packed.

- Check that the drip tray is inserted in its slot.

- Connect the appliance to a power socket

- Insert the food to be packed evenly in the bag. Check that the bag is 8 cm longer than the food to be preserved.

- Lift the lid.

It is possible to select the sealing time of the appliance and the number of

seas to be made based on the food being packed (see section "Description of functions"). The machine is automatically set to the "Scaling selling single" function by default. To change the settings, over the handle. Once the selection has been changed, it is saved until the appliance is disconnected from the power socket.

USE WITH BAGS

1. Position the open end of the bag inside the vacuum chamber as shown in figure 2. With bags that have only one embossed side, position the smooth side facing upwards.

Make sure the inside of the bag, in the point where it will be sealed, is clean and free at any food residue. The bag must be perfectly stretched and unwrinkled.

1. Lower the lid and hook it to the base of the machine, pressing the handle downward: the "Sealing setting" key light turns on indicating the previously made selection ("single - double - double extended").

2. Press the "Automatic/STOP" key to start the automatic air extraction and sealing procedure: the "Automatic/STOP" key light turns on. During the sealing phase, the light on the "Seal" key will come on.

3. Wall until the indicator lights turn off. Open the lid by lifting the handle.

4. Check that the bag is properly sealed and place it in the refrigerator, freezer or storeroom.

USE WITH ROLLS

Using the roll, it is possible to prepare bags of the desired length specific to the type of food being stored.

1. Lift the lid.

2. Determine the length of the bag by considering the length of the food being preserved and adding at least 8 cm.

3. Cut the roll to the desired length using the supplied cutter.

4. Position one of the two open ends of the bag on the sealing bar. With rolls that have only one embossed side, position the smooth side facing upwards.

5. The bag must not protrude from the vacuum chamber / drip tray or on the gasket seal.

6. Make sure that the bag is fully stretched out, clean and unwrinkled.

7. Lower the lid and hook it to the base of the machina, pressing the handle downward; the "Sealing setting" key light turns on indicating the previously made selection ("single - double - double extended").

8. Press the "Seal" key to start sealing. When the indicator light turns off, sealing is complete. Open the lid by lifting the handle.

9. Check that the bag is properly sealed

10. Continue as described in the section "USE WITH BAGS".

PARTIAL VACUUM

Total air extraction using the automatic method tends to crush more delicate and fragile foods (such as strawberries, berries, breadsticks, vegetables, etc.) in these cases, it is therefore possible to use the manual vacuum, interrupting air extraction when necessary.

1. Position the bag and secure the lid of the machine as described in points 1 and 2 of the section "Use with bags".

A vacuum can be manually generated in two ways:

a. Press the "Automatic/STOP" key to start extracting the air. Keep a close eye on the air being extracted from the bag, and when necessary stop the vacuum process by pressing the "Seal" key.

b. Press the "Pulse vacuum" key to extract the air, and when necessary stop the vacuum process by pressing the "Sea" key.

1. Lift the lid and check that the bag is properly sealed.

USE WITH CONTAINERS (not supplied)

Using Laica canisters.

Before each use, make sure that the lid, canister and canister seal are completely clean and dry.

1. Fill the canister up to a maximum of 2 cm below the top edge.

2. Put the lid on and, for the VT3304 model only, turn the air valve on the lid to the "SEAL" position.

3. Connect the canister tube by inserting one of the two ends into the socket located on the machine lid, and the other end into the socket located on the canister lid.

4. Hook the Id onto the base of the machine by lowering the locking handle.

5. Press the "Canistar" key to start the automatic air extraction procedure:

the indicator light on the key will come on. Wait until the indicator light goes out.

1. Extract the tube from the canister, place the canister back in the fridge, freezer or storeroom.

To place liquids under vacuum, they need to be frozen first.

Place the liquid food in a suitable canister, place it in the freezer for approximately 12-18 hours, then take it out of the canister and place it in a vacuum bag. Extract the air and seal the bag as described in the section "user instructions - use with bags"; then place the bag back in the freezer.

MAINTENANCE

- Wash your hands thoroughly before cleaning the appliance.

- Before and after use, clean the appliance with a dry or slightly damp cloth, taking care not to allow liquids to enter the appliance.

- After each use, remove any residual nylon (bag) from the sealing bar using a soft cloth being careful not to damage it. Clean the sealing bar only once it is cooled.

- After every use, remove the drip tray and wash it thoroughly under running water to remove any liquid residue. Make sure it is perfectly dry before putting it back in its slot.

- Never use chemicals or abrasive products.

- Store the appliance in a cool, dry place.

Do not store the device with the locking handle lowered in order to prevent the deformation of the sealing gasket and gaskets.

EN english

Spare parts available

o gaskets and sealing gasket: code AI-1046,

o drip tray: code AHI044,

o carister tube: code AH039

TROUBLESHOOTING

Problem Possible cause Solution
The appliance is not working.	The appliance is not plugged it.	Plug the product into the electrical socket.
	The thermoproctor was triggered.	Let the appliance cool for at least 30 minutes and turn it back on.
The device does not create the complete vacuum in the bag.	The bag may be purchased.	Make sure the bag is intact or replace it.
	The bag is not positioned correctly in the suction and liquid collection chamber.	Position the bag as described in section "machings - low with bags".
The device does not create the complete vacuum in the bag.	The sealing bar could be overloaded. This happens when several suits are made comparatively and very quickly.	Wait a few minutes to allow the sealing bar to cool. Wait at least 15 seconds between seats.
The bag doesn't maintain its vacuum after sealing.	The bag may be purchased.	Make sure the bag is intact or replace it.
	The edge of the bag is not perfectly clean.	Make sure there are no impurities using the seat such as crumbs, grease, etc. Open the bag and try again.

Problem Possible cause Solution
The bag melts are doesn't seal property.	The bag sealing area is dirty and not flat.	Make sure the inside of the bag is clean and the bag lies flat.
	The selected "double extunded" sealing time is too long.	Reduce the sealing time by pressing the "Seal Setting double" key.

DISPOSAL PROCEDURE

The symbol on the bottom of the device indicates the separated collection of electric and electronic equipment (Dir. 2012/19/Eu-WEEE).

At the end of life of the device, do not dispose it as mixed solid municipal waste, but dispose it referring to a specific collection centre located in your area or returning it to the distributor. When buying a new device of the same type to be used with the same functions. If the appliance to be disposed of is less than 25 cm, it can be returned to a retail location that is over 400 m² without having to purchase a new, similar device.

This procedure of separated collection of electric and electronic devices is carried out forecasting a European environmental policy aiming at safeguarding, proceeding and improving environment quality, as well as avoiding potential effects on human health due to the presence of hazardous substances in such equipment or to an improper use of the same or of parts of the same. Cautitani: The wrong disposal of electric and electronic equipment may involve sanctions.

CE This product is meant for domestic use. The conformity, certified by the CE-marking on the device, refers to the Directive 2014/30/Eu on electromagnetic compatibility and to the Directive 2014/35/Eu on electric material destined to be used within given voltage limits.

This product is an electronic device that was tested to assure, according to

English

the current technical knowledge, that it does not interfere with other nearby located equipment (electromagnetic compatibility) and that it is safe if used according to the advices given in the instructions for use.

In case of operation anomalies, do not keep using the device and, if necessary, refer to the manufacturer directly.

WARRANTY

This equipment is covered by a 2-year warranty starting from the purchase date, which has to be proven by means of the stamp or signature of the dealer and by the fiscal payment receipt that shall be kept enclosed to this document.

This warranty period complies with the laws in force and applies only in case the consumer is an individual. Laica products are designed for domestic use only; therefore, their use for commercial purposes is forbidden.

The warranty covers only production defects and does not apply. If the damage is caused by accidental events, misuse, negligence or improper use of the product.

Use the supplied accessories only; the use of other accessories invalidate the warranty cover.

Do not open the equipment for any reason whatsoever, the opening or the tampering of the equipment, definitely invalidate the warranty.

Warranty does not apply to parts subject to tear and wear along the use, as well as to batteries, when they are included.

Warranty decays after 2 years from the purchase date.

In this case, technical service interventions will be carried out against payment. Information on technical service interventions, under warranty terms or against payment, may be requested by writing at [e-mail]. Repair or replacement of products covered by the warranty terms are free of charge. In case of faults, refer to the dealer; DO NOT send anything directly to LAICA.

All interventions covered by warranty including product replacement or the replacement of any of its parts shall not be meant to extend the duration of the original warranty period at the replaced product.

The manufacturer cannot be made liable for any damages that may be caused, directly or indirectly, to people, things and pets requiring from the inobservance of the provisions contained in the suitable user manual, especially with reference to the instructions related to installation, use and maintenance of the equipment.

Being constantly involved in improving its own products, Laica reserves the right to modify its product, totally or partially, with reference to any production need, without that this involves any responsibility whatsoever by Laica or its dealers.

ES Español

Español ES

i MÁQUINA PARA CONSERVAR AL VACÍO - INSTRUCCIONES Y GARANTÍA

Utilize as recipientes laica.

PROBLEMAS E SOLUÇÕES

DESCRIPTION DU PRODUIT (Part 1)

A UTILISER AVEC LES BOÎTES (non incluses)

e tube your recipients. ed. AHI

PROBLEME \$I SOLUTII

HASZNÁL AT TEKFBCCSEI
