USER MANUAL S7P DOMETIC

WINDOWS & DOORS WINDOWS DometicS7P_IOM_4445101861_EMEA16_202x-xx-xx.book Page 1 Saturday, July 31, 2021 1:38 PM© 2021 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or be patent pending. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights are reserved. DometicS7P_IOM_4445101861_EMEA16_202x-xx-xx.book Page 2 Saturday, July 31, 2021 1:38 PMEN S7P Explanation of symbols

WARNING! Safety instruction: Indicates a hazardous situation that, if not avoided, could result in death or serious injury. NOTICE! Indicates a situation that, if not avoided, can result in property damage. NOTE Supplementary information for operating the product. DometicS7P_IOM_4445101861_EMEA16_202x-xx-xx.book Page 3 Saturday, July 31, 2021 1:38 PMEN Safety and installation instructions S7P

2 Safety and installation instructions Please observe the prescribed safety instructions and stipulations from the vehicle manufacturer and service workshops.

Please note the following:

• If faults or disturbances occur, consult a specialist workshop immediately.

• Before starting your journey, check that the wall window is locked properly.

• Before starting your journey, check the wall window for damage (such as tension cracks in the acrylic glass).

• Do not open the wall window in strong wind or rain.

• Close the wall window if it rains or snows.

• Do not leave the vehicle with the wall window open.

3Scope of delivery 4Accessories Available as accessories (not included in the scope of delivery): NOTE If you do not have sufficient technical knowledge for installing the components in vehicles, you should have a specialist install the wall win- dow in your vehicle. WARNING! Always keep the vent window closed while driving and while on public roads. No. infig. 1Description1 WindowDescriptionPleated blindInstallation kit (Fastening bolts 3.5 x 12 mm, securing clips) DometicS7P_IOM_4445101861_EMEA16_202x-xx-xx.book Page 4 Saturday, July 31, 2021 1:38 PMEN S7P Intended use

5 Intended use The S7P wall window is suitable for installing in delivery vans with curved exterior surfaces (radius of 5000 mm). The wall windows are designed as vent windows. The S7P window is designed for a wall thickness of 22 – 43 mm. This product is only suitable for the intended purpose and application in accordance with these instructions. This manual provides information that is necessary for proper installation and/or operation of the product. Poor installation and/or improper operating or mainte- nance will result in unsatisfactory performance and a possible failure. The manufacturer accepts no liability for any injury or damage to the product resulting from:

• Incorrect assembly or connection, including excess voltage

• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer

• Alterations to the product without express permission from the manufacturer

• Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. 6 Instructions before installation

1. Before installation, check the wall thickness of your vehicle. Consult the vehicle

manufacturer if you have any questions. You need securing clips (not supplied) to suit the thickness of the wall (see chapter “Preparing the installation” on page 6).

2. With sheet metal coverings, the wall thickness must be increased to at least

22 mm by adding a suitable mounting frame (e.g. wooden frame).

3. When choosing the installation location, observe the following:

– Adjoining components (attachment and reinforcing parts), cables and cabinets in the vehicle interior must not get damaged when sawing the hole. – Sufficient space needs to be available for installing the inner and outer frames. – Only install the wall window on curved wall surfaces with a radius of 5000 mm. DometicS7P_IOM_4445101861_EMEA16_202x-xx-xx.book Page 5 Saturday, July 31, 2021 1:38 PMEN Installing windows S7P

6.1 Pressing out the hole

6.2 Preparing the installation

Supplementary to fig. 3

1. Measure wall thickness W (A)

If the wall thickness is less than 22 mm, then you must add to the wall section with a suitable mounting frame (B)

2. Determine the type of clip by referring to the following table:

7 Installing windows See fig. 4

1. Check that the window has sufficient space around it (approx.1 to 2.5 mm) in the

2. Clean the wall section externally in the mounting area.

3. Seal the window frame with a flexible non-hardening sealing compound (e.g.

4. Determine the number of clips by referring to the following table:

5. Glue the mounting frame to the vehicle wall, e.g. with double-sided adhesive

6. Insert the window from the outside in the centre of the wall section.

7. Press the window slightly so that the packing compound spreads out.

8. Fasten the window using the fastening bolts and the appropriate securing clips.

9. Assemble the top mounting brackets first.

Always attach the mounting brackets from the center of the frame to the outside.

10. Remove the protective film from both sides of the window glass.

11. After installing, check the wall window works properly.

1. Proceed as follows for each rotary bolt:

Turn the rotary bolt by 90°.

2. Tilt the window pane outwards to the desired opening angle.

Closing the window (fig. 7)

1. Close the window slowly.

2. Proceed as follows for each rotary bolt:

Turn the rotary bolt by 90°. 9 Cleaning and maintenance

➤ Put talcum powder on the rubber seal. NOTE If a window frame guide rail does not fit evenly against the vehicle wall, then you must use more clips, where required, than are specified in the table. NOTICE! Damage hazard Do not use any sharp or hard objects for cleaning since they may damage the acrylic glass. Only use cleaning agents that are approved by the manufacturer. Acrylic glass polish (ref. no. 9600000128), special polishing cloth (ref. no. 9600000130) and acrylic glass cleaning agent (ref. no. 9600000129). DometicS7P_IOM_4445101861_EMEA16_202x-xx-xx.book Page 8 Saturday, July 31, 2021 1:38 PMEN S7P Warranty
