USER MANUAL 4Maxi 52 SH MARINA

Translation of the original instructions

INDEX

1 SAFETY INSTRUCTIONS
2 EXPLANATION OF THE SYMBOLS ON THE UNIT
3 DESCRIPTION
4 INTENDED USE
5 ASSEMBLY
6 SWITCHING ON THE UNIT
7 MAINTENANCE AND CARE
8 TROUBLESHOOTING

1 SAFETY INSTRUCTIONS

When using lawn mowers, comply with the following basic safety instructions to protect against risk of injury:

• Read and then comply with the operating manual.
• Keep the operating manual for subsequent use or for the next owner.
• Follow the safety instructions and warnings on the unit.

Users

• Children and young people under 16 years old and who are not familiar with the operating instructions must not use the unit. Local regulations may specify the minimum age.
• Wear long, tight-fitting trousers and non-slip footwear.

Working area

• Carefully check the whole working area. Remove all foreign objects such as stones, sticks, wire, bones, etc.
• Do not use the lawn mower if there are any persons (caution: children) or animals (including wildlife) in the working area.

Operating times

• Observe national operating times for lawn mowers (noise prevention).
• Use the lawn mower only in daylight or if the working area is well illuminated.

Operation

• Always visually inspect the lawn mower before use.
• Before the use visually inspect the good condition of the blades, the adapter and the fixing screws. Damaged or worn parts must be replaced only in set to keep correct and balanced work conditions
• Do not use the lawn mower in case of defective or damaged protection devices, never when

the safety devices, as the deflectors or the grass catcher, shouldn't be in place or in correct positions

• Switch off the engine and pull off the spark plug connector:

• Before to remove any obstruction or clean the discharge chute

• After the mower strikes an object

• If the mower suddenly start to vibrate

• Keep nuts, bolts and screws tight, to guarantee a safety use of the lawn mower

• Frequently check the grass catcher shouldn't worn or damaged

Before performing any work on the unit:

• Switch off the engine, wait until the blade has come to a standstill and pull off the spark-plug connector.
• Damaged or worn parts must be replaced immediately.
• Use the unit only in a technical condition stated by the manufacturer.
• The user of the unit is responsible for any accidents involving other persons or their property.
• Switch off the engine before crossing surfaces other than the surface which is being mown.
• Do not start the motor if you are standing in front of the discharge channel (side discharge mower).
• Use the lawn mower on lawns only.
  -Do not disable the safety equipment or protective equipment on the lawn mower.
• The cutter must be freely rotatable before the lawn mower is started. Disengage any drives.
• If the lawn mower has to be lifted before it can be started, the cutter must be facing away from the user.

• Keep hands and feet away from rotating parts.

• The lawn mower may only be used in compliance with the safety distance provided by the guide handle.

• Ensure that you have a secure footing.
• Never lift or carry the lawn mower while the motor is running. Wait until the cutter has come to a standstill and pull off the spark-plug connector.
• Always cut across a slope. Never mow up or down slopes or at an incline greater than 15^ .
• Caution when changing direction of travel or when mowing backwards.
• Guide the lawn mower at walking pace only.
• Keep muffer and engine free of leaves, grass and any spilt oil
• Do not leave the lawn mower unsupervised. Warning! Petrol is highly flammable!
• Store petrol in designated containers only.
• Fill up with petrol outdoors only. Do not smoke while filling up with petrol!
• Do not open the tank cap or refill with petrol while the engine is running or when the machine is hot.
• If petrol overflows, do not start the engine. Clean the unit and do not start the engine until the petrol vapours have dispersed.
• For reasons of safety replace a damaged petrol tank and/or tank cap.
• When filling up with petrol, use a funnel filling tube to prevent fuel running from tank onto the engine, the housing or the lawn.

Risk of burns!

The exhaust and the areas around the exhaust may rise to and they can reach high temperatures.

Replace damaged mufflers.

• Do not change the governor settings of the engine.
• Never leave a combustion engine running in closed areas. Risk of poisoning!

Maintenance and storage

Before performing any work on the unit:

• Switch off the engine, wait until the blade has come to a standstill and pull off the spark-plug connector.

• If working near the blade, always wear protective gloves.

• If there is petrol in the tank, never store the lawnmower in buildings in which petrol vapours may come into contact with a naked flame or sparks - Risk of explosion!

• The petrol tank should be drained outdoors only.
• Before storing the machine in a closed room, leave the engine to cool down.
• Do not spray the lawn mower with water.
• The lawn mower must be repaired by authorised specialist companies only.

Spare parts and accessories

• Use original spare parts and accessories only.
• We reserve the right to introduce changes to the design and model without prior notice.

Safety devices

Safety lever

Release the safety lever in case of danger.

Motor and cutter will stop in few seconds.

Do not disable the function of the safety lever.

Protective devices

Rear flap (gravel guard)

Protective devices prevent injury from objects ejected by the cutter.

Do not operate the lawn mower without protective devices. or

Do not operate the machine in the rain or during thunder storms, particularly when there is a risk of lightning strike.

The risk of accidents is higher if the ground is damp due to increased danger of slipping.

Particular caution should be exercised during working in order to prevent slipping.

If possible, avoid using the machine when the ground is damp.

Always wear hearing protection when working with the machine.

Caution: Danger to health due to vibrations!

Excessive exposure to vibrations can result in damage to the cardiovascular or nervous system, particularly in persons with cardiovascular problems. Please consult a physician if you experience symptoms that may have been caused by vibrational loads.

Symptoms of this kind principally affect the fingers, hands or wrists and include (incomplete list):

-numbness,
-pain,
-muscular weakness,
- skin discolouration,
- unpleasant tingling sensation.

Transporting the machine

Always wear gloves in order to prevent injuries due to sharp-edged and hot components.

Do not transport the machine with the engine running. Switch off the engine, let the blades come to a standstill and remove the spark plug socket prior to transport.

Only transport the machine once the engine has cooled down and with an empty fuel tank.

Use suitable loading aids (loading ramps, lifters). Secure the machine and any machine components being transported (e.g. grass catcher box) on the load floor using fastening material of adequate size (belts, ropes etc.).

Avoid contact with the mowing blade when lifting and carrying the machine.

When transporting the machine, always observe regional legislation, especially regarding load security and the transport of objects on load floors.

Remember that when loading or unloading the mower, do not tilt it in any direction, as this may cause contamination of the oil filter or oil leakage.

Procedure with used machinery, environment protection.

If one day you come to the conclusion that your device needs to be replaced or you do not need it anymore, remember to protect the environment and dispose of in an environmentally safe manner, in accordance with local regulations. Some authorized Service Points and sales outlets accept old equipment and utilize it in an environmentally safe manner. In case of any uncertainties or doubts concerning the operation of the device, please contact an authorized service center or the seller.

Additional information on the operating instructions for the unit, section entitled "For your safety".

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruc-tion concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

2 EXPLANATION OF THE SYMBOLS ON THE UNIT

1 Manufacturer
6 Revs
2 Model
7 Year built
3 Type
8 Power
4 Serial number
9 Sound power level
5 Netweight

Before using the lawn mower for the first time, read the operating manual!

Keep other people out of the working area!

Before working on the cutter, pull off the spark-plug connector!

Warning Danger! Keep hands and feet away from the cutters!

Danger of intoxication. Do not used in closed areas.

Danger of explosion. Switch off the engine when filling up fuel.

Danger. Do not touch hot parts.

DO NOT USE Pressure Washers to clean mechanical parts, bearings and seals.

In this operating manual

Danger! Non-compliance could result in personal injury.

Do not wear clothes that could get caught in the wood, in the scrub or in the moving parts of the equipment. Do not wear scarves, ties or jewellery. Always keep long hair tied and protected (wear a scarf, hat, helmet, etc).

Danger of death by suffocation!

Never let children play with the packaging material, they may risk death by suffocation. Keep the packaging material out of the reach of children.

Wear working boots with nonslip sole and steel tip. Never work barefoot or, for example, with sandals.

Do not tamper with this machine to increase the engine or electric motor's power or rpm

To reduce the risk of eye injury, wear well-fitting EN 166 compliant safety glasses. Pay attention to the correct position of the safety glasses. Wear the safety helmet in thinning work, when working in tall scrub and in places with danger of falling objects. Always wear safety glasses before sharpening the blade!

Instructions for correct assembly of the starter cord guide hook for petrol engine lawnmowers.

Always wear hearing protection when using this equipment.

Lawnmowers with quick release levers

The starter cord guide hook must be mounted on the right side and inside the handle as shown

Always wear sturdy work gloves made of resistant material (e.g. leather).

Work gloves will protect you from accidental injuries. Never underestimate all possible dangers. Always wear gloves when using this lawnmower.

Lawnmower with handle locking knobs.

The starter cord guide hook must be mounted on the right side of the handle as shown.

3 DESCRIPTION I

1 upper handle
2 self propulsion lever
3 brake lever
4 accelerator lever
5 stone guard
6 lower handle
7 engine
8 front wheel
9 chassis
10 back wheel
11 collection basket
12 blade support
13blade
14 blade screw
15 adjusting levers for cutting height
16 oil cap
17 fuel cap
18 flexible cables
19 water infeed coupling unit (optional)

4 INTENDED USE

This lawn mower has been designed for cutting grass. Any other use is not permitted.

The lawn mower is suitable for private use in the garden only. Lawn mowers for private use are those which are used for cutting grass and lawns in the garden, however not for cutting grass in public parks, playing fields or on farms or in forests.

Non-permitted users:

Persons who are not familiar with the operating manual, children, young people under the age of 16 as well as persons under the influence of alcohol, drugs or medication must not operate the unit.

Operating times for petrol lawnmowers

(in compliance with the Control of Pollution Act). Please also observe the municipal regulations on the operation of lawn mowers!

Monday - Saturday Not allowed on Sundays

7.00-12.00

and bank holidays!

15.00-19.00

5 ASSEMBLY

When assembling this appliance, please follow the instructions for assembly printed towards the end of the manual.

Protection of the environment, disposal

Packing elements (plastic bags, polystyrene foam, nails, boxes, etc.) must not be left within the reach of children, as they are potentially dangerous.

Packing materials are potential environmental pollutants.

Dispose of through authorised waste disposal companies.

Marked on the machine rotation speed during the rpm test.

6 SWITCHING ON THE UNIT

Do not switch on the unit until it has been completely assembled.

Always comply with the petrol engine operating manual supplied by the engine manufacturer.

Before switching on the machine for the first time, fill up with oil and petrol!

Petrol: Standard petrol - lead-free

Engine oil: See operating manual supplied by the engine manufacturer.

Filling up with petrol: The tank cover is situated on the petrol tank and is identified by the symbol "petrol pump" (petrol station).

Filling up with oil: Capacity approx. 0.6 litres

Starting the engine

The engine cannot be started until the blade has been attached (balance weight)!

Starting the engine manually a) Without throttle remote control

1) Press the primer button 3x at intervals of approx. 2 seconds.

At temperatures below 10^ press the primer button 5x.

If the engine is warm, do not press the primer button!

2) Pull the engine brake handle towards the upper handle and hold in position - the engine brake handle does not lock into position III
3) Quickly pull out the starter cable and then let it slowly wind up again. IV
The engine has a fixed throttle setting. Speed control is therefore not possible.

b) With throttle remote control

1) Throttle to position (start)

2) Press the primer button 3x at intervals of approx. 2 seconds.

At temperatures below 10^ press the primer button 5x.

If the engine is warm, do not press the primer button!

3) Pull the engine brake handle towards the upper handle and hold in position - the engine brake handle does not lock into position. III
4) Quickly pull out the starter cable and then let it slowly wind up again. IV

As soon as the engine is running, position the throttle between (start) and (stop) according to the desired engine speed.

Starting the engine electrically

5) Throttle to position (start)
6) Press the primer button 3x at intervals of approx. 2 seconds.

At temperatures below 10^ press the primer button 5x.

If the engine is warm, do not press the primer button!

7) Pull the engine brake handle towards upper handle and hold in position - the engine brake handle does not lock into position. VI
8) Press the power button. Release the button when the engine is running. VII

Position the throttle between (stop) according to the speed.

( start ) and desired eng

(A) Security key and start-up
(B) Battery
(C) Battery charger

Switching on the wheel drive

Applies only to units with a wheel drive!
Do not engage the gears while the engine is at a standstill!
9) Press the gear switch lever against the upper handle and keep hold - the gear switch lever does not lock into position. VIII

Driving speed: approx. 3,7km / h

Switching off the wheel drive

10) Release the gear switch lever.

Switching off the motor

11) push the throttle to position (stop). X
12) Release the engine brake handle. XI

When the motor has been switched off, the cutter continues running for several seconds – therefore do not touch the underside of the mower until the cutter has come to a standstill!

Setting the cutting height

All wheels must be at the same height!

Speed advancing variator (VW) XIII

On lawn mowers with VVmark you have the possibility to change the advancing speed from 2,5 to 5Km / h . This advancing speed can be modified only when engine is working. In order to do it you have to start the left-hand lever on the operating panel. The tortoise symbol on the operating panel means slow, the hare symbol means fast.

3-speed transmission (3V)

Models marked with the 3V symbol have transmission that makes it possible to choose between 3 different advancing speeds:

1st speed - 2.5 km/h

2nd speed - 3.5 km/h

3rd speed - 4.5 km/h

The advancing speed can only be changed while the engine is running. To do this, you must activate the left-hand lever, located on the operating panel, setting it to the desired speed.

Brake blade (BBC) XIV

Lawn mowers with BBC mark have the possibility to start and stop the blade keeping the engine working. In order to make the blade starting, you have to draw lever toward the handle and push lever 2 down. To stop it you have to release the lever.

Attention: the blade needs same seconds to stop.

7 MAINTENANCE AND CARE

Before carrying out any maintenance or cleaning work, pull off the sparkplug connector!

Do not spray the unit with water. Water which gets into the ignition system or the carburetor may result in malfunctions.

Clean the unit with a cloth, hand brush, etc.

When the mower is tilted to the side, the carburettor must be pointing upwards!

Expert inspection is required:

• if the lawn mower strikes an object
• if the motor stops suddenly
• if the blade is bent (do not align!)
• if the motor shaft is bent (do not align!)
• if the gears are damaged
• if the V-belt is defective

Changing the oil / air filter / spark plug

See operating manual supplied by the engine manufacturer.

Drive gears

The gears are maintenance-free.

Replacing and sharpening the mowing blade

At the end of the mowing season always sharpen the mowing blade or, if required, replace the mowing blade with a new one. Always have the mowing blade sharpened or replaced by a customer service centre (measurement of imbalance).

Unbalanced blades will cause the lawn mower to vibrate violently - risk of accident!

Mulching cut (optional) XV

1) turn off the machine and ensure the blade has stopped.
2) lift the back stone-guard and fit the plug provided.
3) release the stone-guard.

Side discharge (optional) XVI

1) fit the mulching plug as per point
2) lift the side stone-guard and position the deflector.
3) release the side stone-guard.

Deck washing (optional) XVII

When the machine has stopped and is switched off:

• Connect the coupler (19) on the deck to the water-supply tap.

Turn on the tap.

• Switch on the engine (the blade should be spinning) and let it run for a few minutes.
• When the machine is clean, switch off the engine. Turn off the tap and remove the hose from the coupler.

8 TROUBLESHOOTING

Before carrying out any maintenance or cleaning work, pull off the spark-plug connector!

Fault Remedial action

Engine does not start Fill up with petrol
	Move throttle to position (start)
	Pull the engine brake handle towards the upper handle
	Check the spark plug and, if required, replace
	Clean the air filter
	Start on short grass or on an area which has already been mown
	Clean discharge channel / housing → the mowing blade must rotate freely
	Recharge the starter battery
Motor power drops Correct the cutting height
	Sharpen/replace the mowing blade → customer-service centre
	Clean discharge channel / housing
	Clean the air filter
	Reduce the stepping speed
Inexact cut	Sharpen/replace the mowing blade → customer-service centre
	Correct the cutting height
Grass catcher is not filled sufficiently	Correct the cutting height
	Allow the lawn to dry
	Sharpen/replace the mowing blade → customer-service centre
	Clean the grille on the grass catcher
	Clean discharge channel / housing
Wheel drive does not function Adjust the flexible cable
	V-belt defective → customer-service workshop
	Transmission defective → customer-service centre
Wheels do not turn when the transmission is engaged	Retighten wheel bolts
	Wheel hub defective → new wheel
	V belt or defective transmission → customer-service centre

Faults which cannot be rectified with the aid of this table may be rectified by a specialist company only (customer service centre).

EC DECLARATION OF CONFORMITY

MA.RI.NA. Systems srl - via F. Baracca 3, 24034 Cisano Bergamasco (Bg) - Italy

Declare that the machine lawnmower with internal combustion engine

Model (a)
Power (b)
Cutting width (c)
Weight (d)
- Serial number (e)

n compliance with the requirements of the following EC directives

1) 2006/42/EC
2) 2000/14/EC + 2005/88/EC
3) 2014/30/EU
4) 2011/65/EC
5) 2012/46/EU

In accordance with the following norms:

1) EN ISO 12100:2010
2) EN ISO 5395-1:2013; EN ISO 5395-2:2013
3) EN ISO 3744:2010

Also declares that the technical manual is kept at:

MA.RI.NA. Systems srl - via F. Baracca 3, 24034 Cisano Bergamasco (Bg) - Italy

Tested by: (m)

Directive 2000/14/EEC : conformity valuation procedure followed (Annex VI) tested by : (n)

• Measuring conditions (f)
  Grip vibrations (g)
  Measured sound power (h)
• Guaranteed sound power (k)
  Sound pressure at operator's ear (measuring uncertainty 2dB) (y)

Cisano Bergamasco, 18/01/2017

Christian Rivolta C.E.O.

Consult the levels measured and shown on the label on the last page

Transmission 3 Vitesses (3V)

Frein lame (BBC) XIV

Christian Rivolta C.E.O.

Freno Iama (BBC) XIV

Benzine:normale loodvrije benzine.

Christian Rivolta C.E.O.

7 MANUTENÇÂO E LIMPEZA

DEKLARACA ZGODNOSCI WE

MA.RI.NA. Systems srl - via F. Baracca 3, 24034 Cisano Bergamasco (Bg) - Italy

Christian Rivolta C.E.O.

Brzda Čepele (BBC) XIV

U kosaciek s označením BBC mate možnost spustit' a zastavit' Čepel', kým je motor v prevadzke. Pre spustenie Čepele musite potiahnut' páčku k rukovāti a zatlačit' páčku 2 dolu. Pre zastavenie Čepele musite uvol'nit páčku.

Pozor: Čepel' sa zastaví až po niekol'k'ych sekundách.

7 UDRŽBA A OŠETROVANIE

Pred vsetkymi udrzbarskymi a cistiacimi pracami stiahnite koncovku zapal'ovacieho kabela!

Sekacku travy neostrekujte vodou. Voda prenikutá do zapalovacej sustavy, popr. karburatóramöze viest'k poruchám.

• Uyactok, Ha KOTOPOM 6ydyT npoBODtbcra pa60tbI NO cKaunBaHNO TpaBBI, Heo6xOIMO TsaTeJIbHO OCMOTpeB. Bce noCTOpOHne npedMeTbI, TaKHe KaK KaMHN, NaIKN, npoBOJOKa, KOCTn I T.D., CJeDyET y6paTb.
• EcHn Ha pa6ooyem yactke HaxoJrTcNoCTOpOHHe (oco6eHHO Detn) nIIN XNBOTbIe (TaK MmKooopraHn3MbI),TOHaHnHaTb Kocb6y HeNb3r.

HopmnpoBaHHoe pa6ooye Bpemr

-Heo6xOJMo CO6JIHOdaTb yCTaHOBJIeHHOe B BaWeI cTpaHe HOpMnPOBaHHOe BpeMraJcKaUWBaHn TpaBbHa ra3OHax (C ceJIbTO 3aunTbI rpaXdAn OT Wyma). Kpome ToRo, yHTbIBaIte DaHHbIe OTHOCHTeJbHO HopMnPOBaHHO pa6Oyero BpeMeHN, eRINBEDeEHbIE B daHHoN INCTpyKuIN.
-Kocb6y Heo6xOdmo BblnoJHrTb npn DHeBHOM CBTe INX OPOWeM NCKycCTBeHHOM OCBeueHIN.

3Kcnnyatauia

-перд наразом Испльбзовая ra3онокослки BCERда пювордente ee Bn3yaЛьньй OCMOTp.
-перед IncnoIb3OBAHnem npOBepntb,уToJIe3BnI,NxДерЖateJIИ KpeJexKhIe BnHTblHe n3HoWeHbI He nobpeJdeHb.I B clyuae3aMeHbI, Heo6XoDIMO 3aMeHnTb BCEJIe3BnI KpeJexKhIe BnHTblДЯ COxpaHeHnpaBnHbO6BaJaHCnPOBKn yCTpOJCTBa.
- Hn B Koem cnyae He cneDyeT nCNoIb3OBaTb ra3OHOKOcNkY npn HaJIuHn DeΦeKTHbIX NIN NOBpeXdEHHbIX 3aUHTbIX yCTpOiCTB, a TEM 6oJee npn OTCyTCTBn TAKx YCTpOiCTB, KaK DeΦJIeKTopbl NN C6OpHbIMeWOk.
- Heo6xOJMo OCTaHOBnTb DBnraTeIb N OTCoeDHHnTB KOJIpaQOK CBeu: -PpeKdyeem ycTpaHrTb BO3MOXHbIe 3aeJaHn IIN OCBO6OJDaTb TpaHCnOpTep;
- TOrO KaK MaunHa HaToJKNHJaCb Ha eNoTropOHnI npEdMeT; -EcnMaunHa NaunHaet CnUWKOM CNNbHO Bn6pnpoBaTb.

-CneNyET noDepxNBAbB BCE raIKn, BnHTbIBXopo0o 3aTAYTom COCTOAHINДЯ rapaHTm6e3OpacHOpaBOtMaunHbl.
- CnejyeT qacto npOBepaTb, yTo MeWOK He N3HOWeH He NOBpeXdEh.

Ipeud hauanom IIO6bIX pa6oT texo6cnyxINBaHnIO yCTpOJCTBa:

• BbIKIOUHTe DBIgATEJIb, NOOxIDNTe, NOKa He octaHOBHTcpeKyuHn HOX, n 3aTeM CHIMITE WTEKeP CBeu 3aJINrAHN.
  -Повржденийи ИИн 3НОСИВИЕСЯЗЛЕМЕNTы KOHCTpyKци Спедует HeMeДпeнHO 3aMeHHTb.
  -「Ta3OHOKOcNlKo pa3peUaETcra NOb3OBaTbcr TOIbKO,ecn OHa HaxoNTcB TExHnueckOM COCTOHN,ONpeJeHHom ee N3ROTOBtJeM.
  -Пиц,пОьь3уОUIеСЯ ra3OHOKOCHIKон, HeCET OTBETCTBEHNOCTb 3a HecyactHbIe CnyuaH, CBЯЗHHbIe C TpaBMIpOBaHnEM DpyrNx JIuC IJIH NaHeceHnEM BpeDa INX CO6CTBeHNOCTn.

• Ecnn Heo6xOdHMo nepeceyb yHa He noJLexKaUne o6pa6OTke c NOMOuIra3OHOKOCnIKN, To ee DBURAteJIb npN 3TOM CJeDyET BvIKJIOUaTb.
  -He BKNIOUaIte DBNrAteJIb KOCNJKN,ecnBbI CTOnTe KaK pa3 HAnpoTINB KaHaja Bbl6pOca (JIA KOCNJKN C Bbl6pOcOM TpaBbI c60ky).

• KocnIKoM MoXHo NOpb30BaTbcr TOnbKO dJIaCKaUWBaHnra TpaBbHa ra3OHax.

• Hn B KOem Cnyuae HeJb3B BbIBOINTb N3 npedoxpaHHTeBhIe N 3aUHTbIe pncIOco6neHry.
  -Дя 3anycka ra3OHOKOCHJKN Heo6xoJIMO,уTO6blpejUyIeMEXaHN3M MOr COBepueHHO CBO6OJHO BpaAatbcr. IMeIOuIeCn npIBoHbIe MExaHN3MbI cNeDyET OTCOEINHTb.
• EcI,ДЯ TORO yTO6bI 3aNyCTnTb ra3OHOKOcNlKy, ee cIeIyET npINoHЯTb, To peK MEXaHN3M Heo6xOdIMo NOBepHyTb B CTOpOHy, IPOTNBOJNOJXHyIO OT NOJIb3OBaTeJI.
• HnKoIa He nOdHocHTe HOrn npyKn 6n3KO K BpaauoUcMcyJNemEHTam KOHCTpyKuIN KOCNIK.
  -Пользоватбая ra3OHOKOCNko MOKTOЛько,co6JIIODAЯ 6e3OanacHoepacCToHne,ONpeДELЯEMOEДINHOI npBODHOpyKOATKN.
• Bcerda 3aHIMaiTe npu Koc6e yctOINHBOe nIOIOKeHne.
• HnKOrda He NODHMaIte He nepe Ra30HOKOcNkCy C BKJIQUeHHbIM DBNrATeJl POnoXdnte, noka He OCTaHOBNTcpeK MExAHIN3M, IN 3aTEM CHIMITE LTeKEp CBeu 3axnraHn.
• Henb3я nepemeuatab kocnilky Bbepxи BHN3 NO

60ntb cKNOHy, a TaKKe cKaUHbTa b TpaBy Ha cKIOHax C yrnom haknoHa 6oJee 15^ . Bcerda BblOJIHnTe Kocb6y B NonepeuHOM HnPaBHeHn K cKIOHy.
6OpHcTOpOxHO npn n3MeHnHn HnPaBHeHn nepeMeueHnI nn pN KOc6e o6paTHbIM XoJOM.

BbINOJIHeHn pa6OT B HeNOCpeCTBeHHoJ 6JIN3OCTn OT HOKeI KOCUNKn BCerJa HaDeBaITe

3aUHTbIe NepuATkn.

HnKOrda HeIb3x XpaHnTb Ra3OHOKOCNky C 6eH3INOM B 6eH3o6ake B NOMEuEHN, B KOTOpM napbl 6eH3INa MOryt BCTyInTb BO B3aIMoDeyCTBNE C OTKpbITbIM PnAmHeHm INN NCKpAMN -3TO B3pbIBOONacHO!
CnBaTb 6eH3nH n3 6eH3o6aKa MoXHO TOIbKO Ha yniue.
- PpexKde Yem NocTaBnTb raoHOKoCnIky Ha xpaHeHne B 3aKpbItoe NOMEuEHHe, DaITe DnRrTeJIO OCTbITb.
- Ra3OHOKOCHIKy HeIb3a MbITb, NOpINBaA ee BOIOJn3
- PEmoHT ra3OHOKOCnIKn DOJXeH BbINOJIHTbcr TOIbKO CINaMn KBaIINΦNcIpyOBaHHbIX CneUaJINCTOB cepBnCHbIX MaCTepCKNX, IMeIoUnx pa3peUeHne Ha peMOHT n3dJI N HAWe ΦnpMbI.

3anyactn npHnAdJeXHoCTN

• CneJyET nCnOJb3OBaTb TOnbKO fnpMeHHbIe 3aNactn I npHaIeXHOCTn.
  -Право на Вhecене ИЗмehн, Касюцхся KOHCTpyKUIMИ NGONHEHЯ KOCJIKN, OCTaBJIeM 3a co6oI.

PpeoxpaHntbHbIe npncnoc6neHn PpeoxpaHntbHa rpuka

B MOMENT onachoctn onyctnte pyu DBURATeIbN pekUm MEXaHn3M OCTaHOBtC

IpeoXpaHHTeJIbHyO pyKy HN B KOem cIyae HeIb3a BBIOIDNTb I3 CTPOJ.

3aunthbIe npncno6neHna

3aHnKpBbIka (kAMHe3aHTnapeWtKa)

3aunthbIe npncnocobJeHn 3aunuauoT pa6oTHnKa OT TpaBMnpOBaHnI ppeMTeAMN,OTNeTaHOUMn PnKocb6e.Γa3OHOKOcJIka HNKOrda He DOJXHa BBOIDITbcB B EKcPnyatauH 6e3 aunThbIX npncnocobHeHn.

TpaHcnpTIpOBka

TpaHcnpTnpoBka: B cnyae Heo6xOJIMOCTH TpaHCnOpTnpoBKN KOCUNK, CNeJeYET CNTb TOINHBiB 6ak N BBInyTB CBeu 3aXnraHna.

PnpnoBedeHn onepaun 3arpy3kn BbIrpy3Kn KocnIKN, He cIeDyET HAKNOHrTb ee B KaKOM-1N6o HnpaBHeHn, B CBy3N C TeM, YTO 3TO MOKeT PnIBecTN K 3acopeHIO fHbTpau Nn yTeuKaM Macna.

Ipn TpaHcnpTnpoBKe He cJeDyET nepemeeaTb Kocnky B 3OHe 3aRpy3Ke Ha TpaHcnpTHoe CpeDCTBa.

MOHTIPOBaTb yCTpOJCTBO B yCJIOBnJx 6e30NaCHOCTn npNcNoJIb3OBaHn COOTBeTCTByUoX px pEmHei I
7ai6.

Y6eNTbC, YTO 30Ha 3aRpy3Kn TpaHcNOpTHORO cpeCTBa XopoIo npOBetpNBaeTc TaKIM o6pa3OM, YTObI ppeDyPepdITb CKONJIeHn BOCNJaMeHryHOUxxCra3OB. Pn HEO6XoDmOCTn NepeHoCA KocNIkC OndHO r30Ha Ha dpyTo, CneDyET BceTaB bblKIOuAtb DBIrataJIb N NOdoXdaTb npeKpaUeHn BpaUeHn HOka.

IeInCTBnC 6bIBWm B ynoTe6JIeHn ycTpoiCTBOM, oxpaHa OkpyKaIOUe Cpebl.

EcnBbI npHXoHTe K BbIBOdy, YTO yCTPOINCTBO Ky: HOpJnEXKNT 3aMeHe NJI B HEM 60JbIe Heo6XoDMOCIn, NOMHIne o6 oxpaHe OkpykaIOUe Cpebl N yTINN3aCNI yCTPOINCTBa 6e3OnaChbIM dJa OKpykaIOUe Cpebl O6pa3OM, B COOTBEcTCTBUN C Tpe6OBAHnM MeCTHbIX HOPM.

HeKoTOpbIe cepBnCHbIe cnyXbI n aBTOpn3OBaHHbIe TOpROBbIe ToUKN PpHIMaOT CTapoe o6OpyDoBaHne Cero yTuIN3aCnei 6e3OnaChbIM dJa OkpyKaIOUe IcpeDbI O6pa3OM.

B cnyae comHeHn IIN BONPOC B OTHOWeHn yHKUHOHPoBAHnYcTpoIcTBa, CneJeT o6paTaBcra B aBTOpN3OBaHHbI CepBnCHbI ueHTp IIN K dInNepy.

Дононтельная Иформаця Дд РуковodCTBa no 3Kcплуataци n3deлг,В pa3дeЛ "Дп BAшев 6e3oNaChoctn".

Данный пибор He педанзануен Дя И сплььовая Лцам (ВТ.Ч.дтм) C orpaHnueHHbIMN ΦИЗчecKMN, ceHCOPHBIMN IIN yMCTBEHHbIMN cnoCo6HOCTaM NII C HeIOCTaTKOM OblTa W/ IIN 3HaHNI, 3a IckIIOUeHHeM clyuaeB, KOrda OHI HaxOJrTc NOd pIpcMOTpOM OTBeTCTBeHHbIX 3a INX 6e3OJaCHOCtB IIN IIN IONyUHNI OT HIX yKa3aHIn, KaK IONb3OBaTbcRпрбopom. Bo n36exaHne Inp c пиборOM DeTn DoJIxHbI NaXODITbcR NOd pIpcMOTpOM.

2 3haueHne cIMBOJIOB, n3o6paXeHHbIX Ha KocNJke

1 PpOn3BODnTeIb 6 KOnNuYeCTBO o6OpOTOB
2 MoDJIb 7 ToI n3rTOBJeHnA
3 Tn 8 Macca
4 CepinHbI Homep 9 YpoBEnb 3ByKOBOi
5 Bec HeTTO MOLUHOCTN

IepeB BbOdom B 3KcNpyatauHnnpemehno npoHTte Hnctpykunio!

IepeBvOdom B 3KcnpnyatauHnHe npemehno npoHTte nHCTpyKnIO!

Ipeed hauanom pa6ot no Texo6cnyxnbAHIO pexyuzero MexaHn3Ma Bcerda ChmajTe wTekep cBeu 3axnraHna!

BhmuHne, onachoctb!
Depxnte Horn npknoaJIbwe ot pexyuzero
mexaHn3Ma!

Onachoctb OTPaBneHn. He nCnoJb3OBaTb B 3aKpbItbIX NOMeueHnX.

Onachoctb B3pbIbA. BbIKIOUaTb DBnraTeIb np 3aONHeHn TOnJIHBOM.

Onachoctb. He doTpaRnBaTbcra Do ropeuX qacteN.

He nCnoJIb3OBAtB CtpuN BOdblHa MexaHnuecknx KOMNoHErTaX,NOdUnnHKax N pOknaKax.

CnmbonblB daHHoH nHctpyKcuN no 3Kcnnyatau

Onachoctb!

Ipn Heco6JIODeHnn yka3aHn, OTMeueHHbIX TaKIM o6pa3OM, He NCKJIIOUeHO TpaBMIpOBaHne IIOJeN.

He nCnoB3yIte OeJdy KOTOPa MoKet 3anyTatbC8 B DepeBbAx, KyCTax NДВnxUxxCa DeTaJx UcTpoiCTBa. He Hocnte WapΦOB, rAnctyKOB uKpaWeHn. Co6epnte m 3aBaxNTe dInHHbIe BONoCbl (PNaTOK, WanoUka, Kacka nT.D.).

Onachoctb cmeptn B CBra3nc ydyubem!

He octabJrTe DeTei ngpaTb C ynaKOBOHyIM MaTePnAIOB CB83N C HAIuHMe OMaChOCTNyDySb. O6raTeJIbHO DepXHTe ynaKOBOHyI MaTePnAIN BHe DOCTyna DeTei.

HaedeBaIte 3aunTHbIe caonr c npOTnBocKoJIb3Jxuei NOOuBOu NCTaJIbHbIM HOCOM. He pa6oTaIte 6ocNKOM nI, HApnPmep, B caHdaIInx.

B yactnoctn, 3anpeuetaetc B Hocntb NImeHnB ycpoiCTBO,B cIeJX NOBliueHn ero MOUHOCTN INK OJIINueCTBa o6opOTOB D BNrataTEn BHyTpehero cropanuHn INI nI neKTPODBNrataTeJI.

B ueJx cHxEHHa BO3MOxHocTn ONaCHocTn TpaBM rna3, OeBaIte XopoOo npNleraIOuIne 3aunTHbIe OUY, B COOTBETCTBUN Tpe6OBaHnMa HOpMbI EN

166.CJeInte 3a npabnIbHbIM nOIOKeHnEM 3aUHTbIX OuyKOB.Hocnte 3aUHTHyo KACKy npBbINOJIHeHn pa60T pa3peXeHn， B BBICOKNX KyCTapHnKaX， a TaKxemeCTax COnaCHOCTbIO NaDeHn IpeMToB. PpN 3aTOUKe HOka, BCERda NcNoJIb3yIte 3aUHTbIe OUYK!

Hnctpykun no COOTBETCTBYUoeme MyMOHTaxy HnpaBnaIooero KpOuKaTPOcNkA Dnra3OHOKOCNKn C DnRaTeJeM BHyTpehHrero CropaHn.

Ta3OHOKOcNkacpbIyaraMn 6bICTporo paCenHeHna.

Ha npab JIyUoN KpOuOK TPOcNka DoJIxKeH MOHTnpOBaTbcr Cnpaba CBHyTpEHHe CTOpOHbI pyKoRTKn, B COOTBETCTBn C yKa3aHnA Mn PnCyHka.

Pnpapobote c yctpoicTBOM Bcerga noIb3y Tecb CpeDCTBaMn 3aunTbl Cnyxa.

Ta3OHOKOcNJa c KpeNeXHbIMn pyKamn pyKoTKn.

Hapabnauoui Kpouok Tpocka DOJIKeH MOHTnpOBaTbcB B npaBoi CTOpOHe pyKoAeTKN, B COOTBeTCTBnC yKa3aHnA Mn PucyHa.

HaedeBaIte pa6oue nepaTkn
n3 npOuHOro MaTePnaJa
(hanpImep, kOka).
3aunTHbIe nepaTkn
obecneuBAOT 3aunTy ot
cnyaHbIX TpaBM. HkoRda
He HeDOoUeHNBaIte yPOBeHb
BO3MOxHOOnaChOCTN. Ppi
pa6ote c ra3OHOKocnKoB
BCerDa ODeBaIte nepaTkn.

3 Ommcannne I

1 BepxHpa yka
2 pyuar DnHexnna
3 pbIur TopMo3a
4 pybIar yckOpnteJIa
5 kamHe3aunTHna peWetKa
6 HIXHry pyka
7 甲BnrgateJb
8 nepeDHee Koneco
9 Ky3OB
10 3aDHee Koneco
11 c6opouha KOp3nHa
12 onopa Hoxa
13 HOX
14 BnHT HOXa
15 perynpoBouHbIe pbuHaN dJa BblcoTbI cpe3aHnA
16 macJyHoro
17 TOnJIbHnA KpbIiKa
18 r6ke Ka6eJn
19 coeHHeHne BOdbI (onu)

4 IcnoIb3OBaHne no Ha3HaueHnIO

JaHHa 2a30Hokocunka npedHa3NayeHa dna cKawueaHua mpa6bl Ha 2a3oHax. NcnoJb3ObaHue ee dna dpyux ueneu He donycmumo.

DaHHa Ra3OHOKOcNkA DOJXHa NCNOB3OBaTbcr TObKO B NnHbIX cIeJx Ha npUyCaDe6Hom yactke. Ra3OHOKoNkN daHHoro TnnpedHa3HaueHHbIe Dn IcNoJb3OBaHnra ToJIbKO B NnHbIX cIeJx Ha npUyCaDe6Hom yactke, Hn B Koem Cnyae He DoJXhbl NCNOJb3OBaTbcR B O6uEcTBeHHbIX caJax, NapKax, Ha cTaAnHOHax, a TaKKe B CeJbCKOM INeCHOM XO3raCTbax.

Komy He pa3pewaemcnoIb306ambcra 2a3OHOKOCUKNOJ:

JIuam, He O3HaKOMNBWUMCc Da HNCTpykUnei NO 3Kcnnyatauun, DeMOJIOdbIM JIOdAm, He DOCTnURWM 16-NeTHERO BO3pacta, a TaKxe JIuaam, HaxoJyUmCMr POD BO3DeIcTBnEM aJNKORoJ, HApKOTIKOB IIN CINbHbIX MeINKaMeHTOB, POJb3OBaTbcra3OHOKOcNkoHpeWaaetc.

BpeM, e meyeHue komopo2o pa3peuwaemcpa6omamb c 2a30HOKOCUKNKou c 6eH3uHO6bIMdeuzamelem (corlaacHO FeepaIbHOMy 3aKOHyO 3aunTE OT BpeDhbIX N3nyeHn).

YuHTbIBaIte, NOKajNyIcTa, TaKKe IpeDnIcaHn MeCThBIX KOMMyHaJIbHbIX OprAHOB OTHOCITeJIbHO BpemeHn 3KcIIpyaTuIN Ra3OHOKOciNk! POnHeDeJIbHnK-cy66Ota-Ponb3OBaTbcra

7.00-12.00 yacob; ra3OHOKOJIKAAMN

15.00-19.00 yacob. B BOCKpeceHbe n B npa3dHnUHbIe dHn 3anpeuaeTc!

5 MoHTax

IIMaMOHTaKa DaHHoro yCTpOiCTBa cJeDyIte HnHCTpyKUmaM MOHTaKa, PnBEdEHHbIM Ha NocIeHNx CTpaHnLax pyKOBoIDCTBa.

3aunTa OkpykaIouei cpebl, yTnIn3aunia

IetaynyaKOBKn (nlaactNKOBbie naKeTbI, neHONOINCTnpON, rBO3n, KapTOH n T. d.) He cJeNyET OCTaBnTb B MeCTax, DOCTyNHbIX DnA DeTeN, TaK KaO OH NMOY TnpEcdTaBnTb NOTeHuaNbHyo ONaCHOCTb.

YnakoobHbIMaTePnaJI 3TO NToEHcuaJIbHbI INCTOuHnK 3aqrpa3HeHnOkpyKaUoSei cpebl.

No Bonpocam yTnIIN3aCIn cIeDyET oBaPauTaBcK CneuAIN3HPOBAHHbIM npEINpNtTuM.

6 BbOДВ 3KcPnyaTaцио

Ta3oHokocuky MoXHo 86oDumb 8 3KcNlyamauUo molbko, ecNu MOHmak 6bl nonHocmb 3aepweH.

B 063aTeJbHOM nopAKe CneJeT BbINOJIHrTb yka3aHn, npBedeHHbE B HcTpkyCun No 3KcPnyatau 6eH3nHOBO r DBrTaTeJra, pa3pa6oTaHHo erO n3rOToBtTeIeM.

Ipeod 6eodom 2a3oHokocunku 8 eknnyamauio 8 nepbui pa3 3anpaebme ee 6eH3UHOM u cMa3OHybIM MacnOM!

Бeнзин: obiyнь 6eH3ин 6e3 coidepxaHnca CBnHca.

Cma3ka DnA DBnraTeJ: cm. HNCTpyKuIO no 3KcNpIyatauIN DnBraTeJI, pa3pa6oTaHHyO erO N3ROTOBnTeJEM.

3anpaBka 6eH3nHOM: KpbIuKa 6eH3o6aKa HaxOJNTcHa cAmOM 6ake N o6o3HaueHa CIMBOJOM «BeH3OKOJHOHa>.

3aINBka cMa3Kn: B KOJIInueCTBe npn6JI. 0,6 JI.

3anyck DBrataTeJia

3aynck DnBnraTeNa BO3MOxKeH TOJbKO Nocne yCTaHOBKn peKyuIero HOKa (NHePcUHOHHa MaCCa)!

3anyck deusamenaepyhyu

a)Be3 cucmembl ducmaHuOHHO

peynuopeku obopomoe deuaamea:

HaKmTe Ha NcKOByo KHOJky Tpn pa3a c HHTepBaJAmn B DBe CeKyHdbI.

Pn TemnepaType Hnke 10° C Ha nycKObyIO KHOKNy cneDyET HaxaTb 5 pa3.

Ecnu dusamelb npoepem do pa6oey meMnepamypbl, mo nyckoob KhoNkoI noB30aambcH He HxHo!

2)Пижмnte pyky TOPMOxeHЯ DBuRaTeJIa K BepxHeI qactn pykoTkn r30HOKOCnIKN IN KpeNKo DePKeNTe ee, TaK KaK B 3TOM NOLOXeHIn pyka TOpMOxeHЯ He qHKcnpyeTcra III
3)БьICTpo NOTaHNTe 3a CTapTePbI Tpoc N 3aTEM MeDJIeHHO OTNcyCTnTe erO, YTO6bl OH CHOBA HAMOTaJcR IV

Deuzamelh Hacmpoeh Ha pa6omy npu nocmoHHom yucne obopomoe, komopoe He moxem 6bimb u3MeHeHo.

b) C cnCTeMoN dNCTaHcNoHHopeRyInpOBKn 06OpOTOB dBurTaTeJr:

1) NpeBEnTe akceIepaTop B noIooKeHne (nyck). V

2) Haxmnte Ha nycOByIO KhoNky Tpu pa3a C INHTepBaJnAMN B DBe CeKyHdbI.
Pn TempeType Hxke 10^ C Ha nycOByIO KhoNky cJeDyeT hKaTb 5 pa3.
Ecnn Dbratel nporpet do pa6oey Temnepatypbl, To nyckoBo KNHkOINoIb30BaTbcr He HxHo!
3)ПижмTepyкуTopMOxehнЯДВиraTeJIЯ KВерхнйчactn pykoTkn ra3OHOKOCNkIn I KpenKOdepKHTe ee,Tak KaK B 3TOM NOJIOxehnpyka TopMOxehнЯ HeФИКСИPyETcI III
4)БыстpoNotянITE3a cTapTepeHbI Tpoc N 3aTeM MeДлЕнHо OTПуCTHTe erO, YTOБbl OH CHOBA HAMOTaJIcR. IV

KaT OToIbKO DnBraTeIb 3apa6oTaET, npeBeInte akceIepaTOP B NoIOXKeHne, COOTBeTCTByHOuIee Heo6xOIMOMy Bam YncNy obopOTOB DnBraTeIy I paCNOJoxEHHoe MeJdy CmMBOJaM (nyck) N (ocTaHOB).

3JIeKtpnueckn 3anyck DnuratTeJIA

5) IpeBcTe aKceIepaTOp B nIoXeHne (nyck). V

6)HaKmTe Ha nycOByIO KHOKNY TPN pa3a C INHTepBaJAmN B DBe CeKyHDbI. II
Ipn TeMnepaType Hnke 10^ C Ha nycKObyIO KHONKY cJeDyET hKaTb 5 pa3.
Ecnn Dbrarntb nporpet do pa6oey Temnepatypbl, To nyckoBOn KHOKNo N0JIb3OBAtbcra He HyxHo!
7)ПиЖМTepyKу TOPMOXeHЯДВИraTeJIa KВерхнeЧаСТи pyKoTKN Ra3OHOKOCnIKN I KpenKO DePxNte ee,Тak KaK B 3TOM NOLOXeHnPyuKa TOPMOXeHЯ HeФИКсИруETc. VI
8) HaxMMTe KhoNky NHTaHnY. VII

OTnyctnte KhoNky, KOrda DBnraTeJIb pa IpepeBeIte akceIepaTOp B noLoXeHne, COOTBETCTByIOUee Heo6xOdMOMy Bam uCny O6opOtOB DBnraTeJIy n pacNoJIoXeHHoe MExdy CmMBOJaM (NyCK) N (OCTaHOB).

(A) KIIOU 6e3oNaChOCTn 3aNyCK
(B) AkkymyTOp
(C) 3apraHoe yCTpoiCTBO

BkIIOueHne KOleChoro npIBOda

ToIbKO dIy KocNIOK c TaKIM npuBODOM! Pedykmop HeIb3a nOdknIouamb npu BbIKNoueHHOM deUzamele!

9)Прижмпе руку BKюченя peДуКТopa KpyКоЯтke КOCинИ КрENKO DeрЖиTe ee-B 3TOMnoLOXeHnpyKa HeФИСИСРУЕТС. VIII

Ckopoocb nepemeeHnKocnKn:ok.3,7 km/4.

BbikloueHne kOlechoro npVBoda

10) OTnIyCTnTe pyuKy BkHIOueHnpeDyKTopa. IX

BbIKIIOUeHne DBNraTeJIa

11)пени Te akcepepatop B noIOXeHne (OCTaHOB.).
12) Otnyctnte pyky TOpMOxKeHnI DvIraTeJIa. XI

PexyuHoxepaamcye HeckoKo ckyHNoCne 6bIKHOueHua deuame, Noommy H e Koem cnyae He npocoblaume pyky nok Kocunky cpa3y nocne ee 6bIKHOueHua!

YcTaHOBka BbICOTbl Cpe3aHnTpaBbl

Bce Koneca Kocuku doJxHbI Haxoumbcra Ha oduhakooe bicome!

PerylTop ckopoctn noaun (Vv) XIII

EcTB,HaMOeJx yka3aHHbIX C 6yKBOV VV, BO3MOXHOCTb N3MeHHTb CKOPOCTb NOaHn OT 2,5do 5KM/4.CKOPOCTb NDAuN MOKeT 6bITb N3MeHeHa TOIbKO C DBINrAteIeM NOI DBNXKeHnEM. IJIra TORO, YTO6bl BbINOHNb ONepaUH NoEO6xoDmO NyCTNTb JIEBb Pbyar Ha NaHEIn ynpabJeHnia, UpePaxa O6o3HaueT MeDnEHHyO CKOPOCTb, 3aAUC -6bICTpyIO CKOPOCTb.

3-x ckopocTHa Kopo6ka nepeDaay (3V)

MoJIeHn, HMeIouJne B o6o3HaueHnn CmMBOJ 3V, OcHaUeHbI Kopo6koN nepeaH, No3BOJIOUeH Bbl6paTb Ondy n3 pa3NJHbIX cKOpOCTe NODaH:

1° ckopoctb - 2.5 km/4
2^ ckopoctb-3.5 KM/4
3^ ckopoctb-4.5 km/

Ckopoocb NOdaun MOKeT 6bITb N3MeHeHa TOIbKO npn BKNIOUeHHOM DBNrAteJe. IJIa ee N3MeHHeHna Heo6xOdmo yCTaHOBt b JeBbI pbuar, paONJIOXeHHbHa npN6OpHOn naHeJIb, Ha BBpaHHyO CKopoocb.

TPO3 HOxa (BBC) XIV

MaunHbI, yka3aHHbIe C 6yKBoB BBC
HMeIOT BO3MOXHOCTb BKJIIOUHTb N BbIKJIIOUHTb
HOx, COxpaHra DBnIaTeJIb NOd DBNJKeHNHeM.
Toro, YTO6bl BKNIQUHTb HOK, TReHyTb pbIur
1 NocpeDCTBOM pyKOaTKn, a TOJKNHyTb pyKy
2 Bn3y. IINr TORO, YTO6bl BBIKNIQUHTb erO,
DOCTaTOUHO ONyCTNTb pbIur 1.

OcmopoxHo: Hoxmpaum HekomopbIe ckyHObI, npexde yem ocmaHOoumbcra.

7 Texo6cnyxmbaHne uyxo

Ipeod hauanom IIO6bIX pa6om no mexo6cnyxuaHuo u yucmke cHumaume wmekep co c6euy 3aXu2AHur!

Kocnky HeIb3a NOINBaTb BODoN 3 WnB IpOTnBHOM Cnyae BOda MoKeT NOnaCTb BCNTeMy 3axnraHna Nn Kap6HpApToP N BbIBeCTn INx IN3 CTPOJ.

YnCTKy KOCNIKIN CNeIyET NPOBOINTB C NOMOuHbTO TpAKN INN BEHnKa.

Ecnu 2a3oHokocunky Heo6xodumo HaKNoHumb, mo 3mo cne dyem bInonHumb makum o6pa30M, ymo6bl Kap6upamop okazancae eepxy!

Kocnka doJnxHa 6bItb noBepxeha Ocmotpy co cToPOhbl KBaHΦuPObaHHoro CneuaHncta, nocJe:

Hae3da Ha KaKoe-Ⅱn6o npenrTCTBne;
BHE3aHNOJ OCTaHOBKN DBNrTaTeJIa;
- npn n3rno6e HOxa (BbInpmaTb HeIb3ra!);
- n3n6e Bana Dnuratela (BbInpmaTb Henb3r!);
- IOBpeKdEHH peDyKTopa;
- DepeKTHOM KInHOBOM pemHe.

3aMeHa Cma3Kn, BO3dUshoro fNJIbTpap,CBeu 3aXnRaHn

CoOTBeTCTByUOaI HOpMaun npuBedeHa B INctpyKun no 3KcNpyataun Dnuratena, pa3pa6oTaHHo ero n3rotOBnteem.

PeykTop KOlechoro npBbOda.

PeykTop He HxkdAeTcB Texo6IyKbAHn.

3ameHa n nepeToUka HOx Ka KocnIKN

Hox Kocniln CneJyET nepeTaunBaTb Bcerda B KOHc ce30Ha. Ecn eCTb Heo6xOIMOCtB, To ero MOXHO 3aMeHHTb.

IepetoKy nn 3aMeHy HoXa CneDyET npuyatb KBaInnФuNpOBAHHbIM CneUnaHCTaM cepBnCHoH peMOHTHOJ MaCTepCKoN (n3-3a Heo6xOIMOCtN n3MepeHnA Dnc6aHaHca).

Hec6aHaHcuOpBaHbIe Hoxu 8eIyomc npuUHO cunbHO u6pauu Koculku, ymo moXem npueecmu K heCyaemhOmy clyauo!

Ctpnxka mulching (onua) XV

1) BbIKJIIOUHTb yCTPOINCTBO n y6eIITbcra, YTO Je3BnE OCTaHOBJIeHO
2) NOДНЯТь 3аДнй KaMHe3aПИТьи ΜИТOK И yCTaHOВNTь пpoБу,пpeДocТаBJЯЕМУВ П риHAДnexHOCCTя
3)OTnyctntb KaMHeaunTHbI uNTOK

OuNTka OCHOBaHnKy30Ba (OnuXVII

PnOCTaHOBHeHHoN BbIKIOUeHHoM MaHInHe.

• PoiCoeHnHTb CoeHHeHne (19) Ha ky30Be K KpaHy IoDaun BOJbl.

OTkpblb KpaH.

-3aynctntb DnBraTeIb (ne3Bue BpauaeTc), OCTabIIyHKUHOHPOBaTb Ha npotjKeHN HECKOJIbKINX MNHyT.
-Призавершениоческ:ВыIKNUOHTb DBnraTeIb.3akpbITb KpaH,OTcoeДИHITb Tpy6y OT coeДИнEHЯ/Ky3OBA

HeicnpaBHOCTb YcTpaHHeH

Двигаелов БКлючается 3алейte бени. YctahOBIne akselepaTop B поLOжehne (nuck) ПрожимITE ручky TOPMOжehня ДВигаелов К ворхнй чakтп руков ra3OHOKOcnilkn. Проконtrpoлир用车, В сakOM coSTОнн HaxODITcR CBeea Здогиня, ри HeobxodIMocTи 3amEHite ee. ПробEDITE чИСТКУ BO3dUshOrO ФильТра, ЗадуSTВ ДВигаелов, KORda KOCINKа HaxODITcR B HN3KOJ Траве пли На уже сkoшенHom учacTke. ПробEDITE чИСТКУ KAHANA Bb6PocA/Kopnyca KOCINKN (HOX KOCINKN Должен СбОБДно Врашать). ПробEDITE роДзардуКу StapTePHoB 6ВаТаpeи.

Мошость ДВигаелов надаet OTKOPPEKTIPuyte yCTAHOBKU BbICOTы cpe3aHney TpaВы. ПорочITE С顺序бервica пrobecTNпретOTуK/3amEHy HOЖа KOCINKN. ПробEDITE чИСТКУ KAHANA Bb6PocA/Kopnyca ra3OHOKOcNilkn. ПробEDITE чИСТКУ BO3dUshOrO ФильТра. ПробODITE косьуВ 3amEdlleHHom Temne.

Ечесьй порokoc ПорочITE С顺序бервica пrobecTNпретOTуK/3amEHy HOЖа KOCINKN. ОТКOPPEKTIPuyte yCTAHOBKU BbICOTы cpe3aHney TpaВы.

Прис nocoblenie对于我们сбoga Травы напOLняETСЯ He noIhOCtBu. ОТКOPPEKTIPuyte yCTAHOBKU BbICOTы cpe3aHney TpaВы. Дайte ra3OHу npocoxHyTB. ПрожимITE С顺序бервica пrobecTNпретOTуK/3amEHy HOЖa KOCINKN. ПробEDITE чИСТКУ peшETКI пresnocoblenia对于我们сбoga Травы. ПробEDITE чИСТКУ KAHANA Bb6PocA/Kopnyca ra3OHOKOcNilkn.

К一步一步 и р内的 n eOTpergUTROBaT b r6bKni Ka6elb Функционурует ПорочITE С顺序бервICA замEHнь DeΦeKTHbI KlinHOBoi pemehb. ПорочITE C顺序бервICA устразиь HeuCnpaBvHocThb peDyKTopa.

При ВкlioquenHOM п résвODE кOLeca He BpauTOTcR ПорочITE boNTb KoLec. Вышla ИЗ CTPOR STUPIZа КOLeca, NOCTabByTe HOBOe KOLeco. HeuCnpaBbI KlinHOBi peMeHь пли NepeDAua DeΦeKTHbI KlnHOBoi pemehb.

HeicnpaBHOCTN, KOtOpbIe He ydaetcra YcTpaHnTB C NOMOsbIO yka3aHNI, PnPBedeHHbIX B daHHo TAbJInce, DOJXHbI yCTpaHrTbcra ToIbKO CNJaAMn CneuHaNCTOB cepBnCHOI peMOHTHO MaCTepCKOI, IMeIoUHX Ha 3TO pa3peSeHne HauE qnPmbl

EC TEKJIAPAUH N COOTBETCTBNA

MA.RI.NA. Systems srl - via F. Baracca 3, 24034 Cisano Bergamasco (Bg) - Italy

3aBnE, TTO rAOHOKOcNJIka C DnRrTeJEM BHyTpeHHeRo CropaHnA

Moelb (a)
Mouhoctb (b)
-Ширни peзаня (c)
Bec (d)
CepnHbH Homep (e)

COOTBETCTBYET HOPMaTINBaM IInpeKTeNb:

1) 2006/42/EC
2) 2000/14/EC + 2005/88/EC
3) 2014/30/EU
4) 2011/65/EC
5) 2012/46/EU

COOTBeTCTByET CneIyUOuHm HOpMaTnBaM:

1) EN ISO 12100:2010
2) EN ISO 5395-1:2013; EN ISO 5395-2:2013
3) EN ISO 3744:2010

Kpome toro, 3aABJraT, yTO TexHnueckoe Docbe pa3pa60TaHo:

MA.RI.NA. Systems srl - via F. Baracca 3, 24034 Cisano Bergamasco (Bg) - Italy

AhaHn3npoBaHo: (m)

DInpeKTHB 2000/14/CEE: PpoceIpya BbINOJIHeHa DnAHAJIIN3a COOTBeTCTBnA (PpInOKeHne

VI) aHaJIIn3IpuObaHo: (n)

• YcnoBn CHaTna 3aMePOB (f)
  Bn6paun Ha pykoarke (g)
• 3aMepeHHa 3BykoBa MoUHocTb (h)
  -「RapaHTnPoBaHHa 3ByKOBa MoUHocTb (k)
• 3BykoBoe daBneHne Ha cnyx onepaTopa (norpseuhoctb n3MepeHna 2D5) (y)

Cisano Bergamasco, 18/01/2017

Christian Rivolta

C.E.O.

CmOTpIe BbIaBHeHHbIe 3HaueHnI n npBBeHeHbIe Ha HakNeKe Ha NocJeDHei CTrpaHnIe

Metapaaon Twv Tpwtotutwv odnyiow

TIPEIXOMENA

Christian Rivolta C.E.O.

Christian Rivolta C.E.O.

7 VEDLIKEHOLDG RENGJØRING.

Christian Rivolta C.E.O.

Christian Rivolta C.E.O.

• Model (a)
• Power / displacement (b)
• Cutting width(c)
  Weight (d)
• Serial number (e)
• Measuring conditions (f)
  Vibration of the handle (g)
  Measured sound power (h)
• Guaranteed sound power (k)
  Sound pressure at operator's ear (measurement uncertainty 2dB) (y)
• Tested by (m)
• Noise conformity evaluation by (n)
