USER MANUAL Lono Glas WMF

Jug with MIN/MAX lines

Device base with cable-winding tabs

Programme selector and on/off button

Chocolate basket 2| BEFORE USE Read the operating instructions carefully. They con- tain important information on operating and main- taining the appliance as well as safety instructions. Keep the instructions in a safe place and pass them on to any future users. Incorrect use can cause damage. The appliance should only be used for the intended purpose and in accordance with the operating instructions. Always refer to the safety instructions when using the appliance. Before assembling and using the appliance for the first time, remove any stickers that may be present and clean the parts which come into contact with food as well as the removable parts as described in the chapter “Cleaning and care”. 3| UNPACKING Danger of suffocation! Children could pull packaging material over their heads or wrap themselves in it and suffocate. Keep the packaging material out of the reach of children. Do not allow children to play with the packaging material. Children can inhale or swallow small parts and suffocate. Keep small parts out of the reach of children. Do not allow children to play with the small parts.

Remove the protective films and packaging material in full. No packaging should remain inside the appliance.

Recycle all packaging material (paper, card- board and plastic).

Check that the appliance and accessories are complete and not damaged.

If any parts are missing or damaged, do not operate the appliance and notify Customer Service. WMF Consumer Service Tel.: +49 (0)7331 256 256 eMail: contact-de@wmf.com 4| IMPORTANT SAFETY INSTRUCTIONS WARNING indicates a hazardous situa- tion that can cause serious injuries (e.g. burns caused by steam or hot surfaces). CAUTION indicates a potentially hazardous situation that can lead to minor or moderate injuries. ATTENTION indicates a situation that can lead to material damage. NOTE provides additional information regard- ing safe handling of the product. observe and follow the symbols and indications.

These devices can be used by children older than eight years old as well as by persons with limited physical, sensory or mental capabili- ties, persons lacking experience and/or lack- ing knowledge if they are supervised or have received instructions regarding how the device is to be used safely and have understood the resulting risks. Children must not play with the device. Children should be supervised in order to ensure that they do not play with the device.

Cleaning and user maintenance shall not be made by children, unless they are older than 8 years old and supervised.

Keep the device and its cable out of the reach of children under eight years old.

Only operate the appliance with the appropri- ate base.

Never immerse the appliance in water.

Take care not to spill water on the base.

WARNING Risk of burns! The temperature of accessible surfaces can become very hot. They also remain hot for some time after the appliance has been switched off.

WARNING the mixing arm on the milk frother DISC can also get hot.

Always use the appliance in accordance with these instructions. Improper use can result in electric shocks and other hazards.

If the appliance’s connection cable is damaged then it must be replaced by the manufacturer’s central customer service department or by a similarly qualified person. Improper repairs may constitute a serious threat for users.

This appliance is designed for use in households and similar environments, such as: Staff kitchens in shops, offices and other working environments; Farm houses; By guests at hotels, motels and other resi- dential facilities; Bed-and-breakfast establishments

The appliance is not intended for commer- cial use.

Clean after use all surfaces, which have got in contact with food. Follow the notes in chapter „Cleaning and care“. 4.1| SAFETY INSTRUCTIONS

Only connect the device to properly installed earthed sockets. The wire and plug must be dry.

Do not pull the connecting cable over sharp edges or clamp it. Do not let it hang down and protect it from heat and oil.

Never disconnect the mains plug from the socket by the cord or with wet hands.

Stop using the appliance and/or disconnect it from the mains plug immediately if: The appliance or mains cable is damaged; the device is not leak-proof; there is any suspicion of a fault after drop- ping the appliance or similar. In such cases, send the appliance to be repaired.

Do not place the appliance on hot surfaces, such as hot plates or similar, or near open flames. It could melt. TR SV RU NO NL FI DA IT ES FR EN DE• Do not place the device on water-sensitive surfaces. Spray may damage them.

Never operate the appliance unattended.

Do not switch on the device without milk.

Take the pot for fi lling from the base.

Only use the appliance to heat up or froth milk. Do not use it to process any other ingredients.

Do not move the device during operation and do not pull on the mains cable.

Underside of the jug must be dry before using the appliance.

WARNING the device is hot.

The mains plug is to be pulled: if malfunctions occur during use, before cleaning and care, after use.

The glass milk frother is intended for heating and frothing milk and milk substitutes. In gen- eral, the following milk types can be used: fresh milk, UHT milk (including from cows, sheep and goats) and lactose-free milk as well as milk sub- stitutes (such as soya milk) with various fat contents. The quality and volume of the milk foam depends on the type and characteristics of the milk being used (e.g. the fat and protein con- tent, temperature, etc.). Prior to initial use, clean the device as described in the section entitled „Cleaning and care”. Con- nect the mains plug to an earthed wall socket. When pressing the lid (1) on the jug (4), make sure that the indentation in the seal- ing ring of the lid (2) is placed in the direc- tion of the handle.

5.1| KEY FUNCTION INTRODUCTION

The WMF Glass Milk Frother has fi ve programmes: Symbol Program Scope of application DISC Capacity Hot milk foam This thick foam is perfect for cappuccino or latte macchiato. WMF Milk System (Fig. A) MIN 150 ml MAX 250 ml Hot vegan foam This thick foam is perfect for vegan cappuccino or latte macchiato. MIN 150 ml MAX 250 ml Cold milk foam This cold, creamy milk foam is especially well suited for frappé, cocktails, iced coffee and desserts. MIN 150 ml MAX 250 ml Hot milk This programme provides a quick and easy way to heat milk, e.g. for latte coffees or cups of warm milk. MIN 150ml MAX 250ml Hot chocolate Use this programme to make hot chocolate drinks using crumbled chocolate. WMF Choc System (Fig. B) Milk MIN 150 ml MAX 250 ml chocolate MAX 34 g

Hold the WMF Milk System (A) by its handle and stand it vertically within the jug. A mag- net then holds the WMF Milk System (A) to the fl oor of the jug.

Fill the jug (4) with chilled milk, observing the MIN and MAX level indicators (see chart). Do not exceed the indicated maximum, otherwise milk may slosh out during preparation.

Place the lid (1) on the jug (4) and apply slight pressure to ensure that it seals. Ensure that the end of the handle of the WMF Milk System (A) is positioned within the lid mechanism. TR SV RU NO NL FI DA IT ES FR EN DE• Now press the On/Off button (6) repeat- edly until the LED next to the symbol of the desired programme lights up.

Approx. 3 seconds later, the preparation begins automatically. The process may be interrupted at any time by pressing the On/ Off button (6) again.

Once the programme has finished, the device beeps and the programme selector blinks 3 times before switching off automatically.

Note: the device‘s fans may continue to run beyond the end of the programme.

WARNING the jug and handle of the WMF Milk System may be hot!

Hold the WMF Choc System (B) by its handle and stand it vertically within the jug. A mag- net then holds the WMF Choc System (B) to the floor of the jug.

Fill the jug (4) with chilled milk, observing the MIN and MAX level indicators (see chart). Do not exceed the indicated maximum, otherwise milk may slosh out during preparation.

Add crumbled chocolate to the milk. For opti- mal results, we recommend breaking the chocolate into small chunks. Alternatively, you can use ground or powdered chocolate.

Place the lid (1) on the jug (4) and apply slight pressure to ensure that it seals. Ensure that the end of the handle of the WMF Choc System (B) is positioned within the lid mechanism.

Press the On/Off button (6) repeatedly until the LED next to the „Hot Chocolate“ symbol lights up.

Approx. 3 seconds later, the preparation begins automatically. The process may be interrupted at any time by pressing the On/ Off button (6) again.

Once the programme has finished, the device beeps and the programme selector blinks 3 times before switching off automatically.

Note: the device‘s fans may continue to run beyond the end of the programme.

The jug (4) can now be removed from the base (5). To pour out the contents, remove the lid (1) and take out the WMF Choc System (B). WARNING the jug and handle of the WMF Choc System (B) may be hot! CAUTION do not place the hot jug (4) on delicate surfaces. WARNING Always place the lid (1) on the device before switching it on. Never remove the lid (1) while the device is running. NOTE An automatic switch-off prevents the appliance from overheating. During the cooling phase, the hot functions (hot milk foam, hot milk and hot chocolate) cannot be started, the correspond- ing function programme flashes. As soon as the cooling phase is over, the programme can be started by pressing the respective function key.

6| CLEANING AND CARE

Clean the device and the WMF Milk/Choc Sys- tem after each use.

Unplug the mains cord and allow the appli- ance to cool down.

The device base (5) is not dishwasher safe and may be cleaned only by wiping down with a damp cloth.

The lid (1), WMF Milk/Choc System (A/B) and jug (4) are dishwasher safe. For ease of clean- ing, remove the sealing ring (2) from the lid (1) and disassemble the WMF Milk/Choc Sys- tem into its individual components (see “WMF Milk/Choc System”). We recommend placing smaller components in the cutlery basket.

Do not use aggressive cleaners, scouring agents or solvents. Dishwasher safe Can be rinsed under running water Wipe with a damp cloth Lid (1) Sealing ring (2) WMF Milk/Choc -DISC (A/B) Glass jug (4) Base unit (5) TR SV RU NO NL FI DA IT ES FR EN DE1.

To reassemble, push the milk DISC (9) into the DISC bracket (8) with the notch facing upwards. Then screw the handle (7) all the way into the DISC bracket (8) from above. The milk DISC (9) is now affixed flexibly to the bracket.

WMF Choc System (B) To prepare hot chocolate, you‘ll need the WMF Choc System (Fig. B). For ease of cleaning, the WMF Choc System can be disassembled into its individual components. To do so, pull the chocolate basket (10) up and out. Unscrew the handle (7) from the DISC bracket (8) and remove the milk DISC (9) from the bracket.

To reassemble the WMF Choc System, push the milk DISC (9) into the DISC bracket (8). Then screw the handle (7) all the way into the DISC bracket (8) from above. The milk DISC (9) is now affi xed fl exibly to the bracket. Next push the chocolate basket (10) onto the handle (7) from above and push downwards until it clicks into place. 7| TECHNICAL SPECIFICATIONS Nominal voltage: 220 - 240 V~ 50 – 60 Hz Power consumption: 550-650 W Protection class: I The appliance complies with European directives 2014/35/EU, 2014/30/EU and 2009/125/EU At the end of its life, this product must not be disposed of in normal household waste but must instead be delivered to a collection point for recycling electrical and electronic appliances. The materials are recycla- ble in accordance with their labelling. By reus- ing, recycling or other forms of reutilising old appliances, you are making an important contri- bution towards protecting our environment. Please ask your local authorities for information about the appropriate disposal point. Subject to change
