USER MANUAL PSGA 20-Li A1 PARKSIDE

Mechanical device with a mounted bracket and chain base, no visible text or symbols

PDF ONLINE www.lidl-service.com

Akku-Sägekettenschärfgerät 20 V / Cordless Chainsaw Sharpener 20V / Aff üteuse de chaînes de tronçonneuse sans fi l 20 V PSGA 20-Li A1

DE AT CH

Cordless Chainsaw Sharpener 20V

Translation of the original instructions

NL BE

Accu-zaagkettingslijper 20 V

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Service-Center....22

Importeur ......22

Original-EG-

3D mechanical part diagram showing a flanged component with two circular holes and an angled cut (no text or symbols)

General description......24

Scope of delivery....24

Overview....24

Description of functions....24

Technical data....25

Charging times 26

Safety information......26

Symbols on the device....26

Symbols used in the instructions .....27

General Safety Directions for

Power Tools 27

Special safety instructions for the

chain sharpener device....30

Assembly....31

Assembling the grinder....31

Setting up the device 31

Working with the device ......32

Removing/inserting the battery......32

Checking the charge level of the

battery....32

Charging the battery 32

Switching on and off 33

Sharpening the saw chain....33

Maintenance and cleaning .....35

Cleaning....35

Replacing the grinding disc....35

Transport 36

Storage....36

Waste disposal/environmental

protection 36

Guarantee 37

Repair Service....38

Service-Center....38

Importer 38

Replacement parts/Accessories ..38

Translation of the original

EC declaration of conformity ....282

Exploded Drawing ......297

Introduction

Congratulations on the purchase of your new device. With it, you have chosen a high quality product. During production, this equipment has been checked for quality and subjected to a final inspection. The functionality of your equipment is therefore guaranteed.

The operating instructions constitute part of this product. They contain important information on safety, use and disposal. Before using the product, familiarise yourself with all of the operating and safety instructions. Use the product only as described and for the applications specified. Keep this manual safely and in the event that the product is passed on, hand over all documents to the third party.

Proper use

The chain sharpener is suitable for sharpening all common types of saw chain. The device is not intended for any other type of application (e.g. grinding with a coolant solution, grinding other workpieces or hazardous materials such as asbestos). The device is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. Commercial use will invalidate the guarantee.

The device is intended for use by adults. Children under the age of 16 may not use the device, except under supervision. The manufacturer is not liable for damage caused by improper use or incorrect operation.

The device is part of the X 20 V TEAM series from Parkside and can be operated using batteries of the X 20 V TEAM series from Parkside. The batteries may only be charged using chargers of the

X 20 V TEAM series from Parkside.

General description

The illustration of the most important functional components

can be found on the front and the back fold-out pages.

Scope of delivery

Unpack the device and check for completeness:

• Chain sharpener with pre-installed grinding discs
• Chain tensioning unit with retaining screw
• Adjusting screw with fixing nut
• Two screws with nuts and washers for fixing to the table

The rechargeable battery and charger are not included in delivery.

Dispose of the packaging material properly.

Overview

1 On/off switch
2 Grinding head
3 Grinding disc cover
4 Handgrip
5 Mounting screws for grinding disc cover
6 Adjusting screw with adjusting nut for the depth stop
6a Adjusting screw
6b Adjusting nut
7 Chain guide rail
8 Grinding base
9 Adjusting nut for the chain tensioning unit
10 Scale for sharpening angle (+35° to -35°)

11 Chain tensioning unit with rotary plate
12 Tension lever for fixing chain
13 Adjusting screw with adjusting nut for the chain feed
13a Adjusting screw
13b Adjusting nut
14 Stop
15 Grinding disc
16 Viewing guard
17 Screws
17a Washers
17b Nuts
18 Charger
19 Battery
19a Release button
19b Button
19c Charge level indicator

B 20 Stop notch
21 Cutting tooth
c 22 Depth gauge nib
D 23 Ventilation holes
E 24 Grinding disc nut

Description of functions

The device must be securely fixed to a work-top before the initial start-up. It is powered by an electric motor with thermal protection and restart stop for additional safety. The sharpening angle can be easily adjusted from -35^ to +35^ . The chain guide rail has a variably adjustable stop. Sharpening is carried out by swivelling the grinding head. The device is provided with a viewing guard for the protection of the user. Please refer to the descriptions below for information on how the operating elements work.

Technical data

Chain Sharpener .....PSGA 20-Li A1

Motor voltage

U ....20 V === (Direct current)

Type of battery....Li-ion

Rated idle speed n_0 6500 min ^-1

Adjustment angle 35^ left/right

Grinding disc dimensions

Outer diameter .... max. ∅ 108 mm

Bore hole....Ø 23,2 mm

Thickness ....max. 3.2 mm

Rotational speed .... max. 40 m/s*

Weight (incl. accessories)..approx. 1.7 kg

Sound pressure level

(L_pA) 66 dB; K_pA=3 dB

Sound power level ( L_wA )

measured....79 dB; K _wA = 3 dB

Vibration (a) .... 2,631 m/s ^2 ; K= 1.5 m/s ^2

Temperature.....max. 50 °C

Charging 4-40°C

Operation....-20 - 50°C

Storage....0-45°C

For use with smart batteries

(Smart PAPS 204 A1/Smart PAPS 208 A1)

Operating frequency/Frequency band.....

2400 - 2483.5 MHz

Max. transmission power ....≤ 20 dBm

* The grinding disc must withstand a rotational speed of at least 40 m/s.

** The rated idle speed of the device with which the grinding disc is used must be less than 7050 rpm

The specified noise emission value has been measured according to a standardised testing method and may be used for comparison with another power tool.

The specified noise emission value may also be used for an introductory assessment of the exposure.

Warning: The noise emission value whilst actually using the power tool may vary from the given values regardless of the type and way in which the power tool is used.

Try to keep the exposure to vibrations as low as possible. Examples of measures to reduce vibration exposure are the wearing of gloves when using the tool and limiting the working hours. All parts of the operating cycle have to be considered while doing so (for example, times when the power tool is switched off and times when it is switched on but running without any load).

Grinding disc PA 108 WA 100 (from scope of delivery):

Idling speed n_0 ...... max. 7050 min ^-1

Rotational speed .... max. 40 m/s*

Outer diameter .... 0 108 mm

Bore hole ....∅ 23,2 mm

Thickness 3.2 mm

For all standard saw chains with link size 1/4". Also suitable for 0.325" and 3/8" links that can be processed with 3.2mm thick grinding wheels (please note of the information provided by the chain manufacturer).

Information on reordering grinding discs can be found under "Spare parts/accessories".

Charging times

The device is part of the X 20 V TEAM series from Parkside and can be operated using batteries of the X 20 V TEAM series from Parkside. Batteries of the X 20 V TEAM series from Parkside may only be charged using chargers of the X 20 V TEAM series from Parkside.

We recommend operating this device with the following batteries only: PAP 20 B1, PAP 20 B3, Smart PAPS 204 A1, Smart PAPS 208 A1 We recommend charging these batteries with the following chargers: PLG 20 A3, PLG 20 A4, PLG 20 C1, PLG 20 C3, PLG 201 A1, PDSLG 20 A1, PDSLG 20 B1, Smart PLGS 2012 A1

Charging time(minutes)	PAP 20 A1PAP 20 A2PAP 20 B1	PAP 20 A3PAP 20 B3	SmartPAPS 204 A1	SmartPAPS 208 A1
PLG 20 A1PLG 20 A4PLG 20 C1	60 120 120 240
PLG 20 A2PLG 20 A3PLG 20 C3	45 60 60	150
PLG 201 A1 135	250 250 500
PDSLG 20 A1PDSLG 20 B1	45 60 60	150
SmartPLGS 2012 A1	35 45 45	50

The charging time is influenced by factors such as the temperature of the environment and the battery, as well as the mains voltage applied, and may therefore deviate from the specified values.

Safety information

CAUTION!

The following basic safety precautions must be observed while using power tools to protect against electric shock, injury and risk of fire. Please read all instructions before using this power tool and keep the safety instructions in a safe place.

Symbols on the device

Caution!

Injury hazard caused by rotating tool! Keep hands away.

Danger of electric shock! Remove the rechargeable battery from the device before cleaning.

Do not expose device to rain.

Please read and comply with the operating instructions for the device!

Risk of injury!

Wear eye and hearing protection!

Wear respiratory protection.

Cutting hazard!

Wear cut-resistant work gloves.

Electrical devices do not belong in domestic waste.

Grinding disc dimensions

Additional graphical symbols on the grinding disc

Never use faulty grinding discs

Symbols used in the instructions

Hazard symbol with information on the prevention of personal injury or property damage

Hazard symbol with information on damage prevention

Advisory symbol with information on how to best use the device

Wear protective gloves

General Safety Directions for Power Tools

WARNING! Read all safety notices, instructions, illustrations and technical data that have been provided with this power tool. Omissions in the compliance with safety directions and instructions can cause electrical shock, fire and/or severe injuries.

Retain all safety directions and instructions for future use.

The term „power tool“ in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool).

1) WORK AREA SAFETY

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

2) ELECTRICAL SAFETY

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.

GBMT

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operation of the power tool in a damp environment is unavoidable, please use a residual current circuitry. The use of a residual current circuitry reduces the risk of an electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention white operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or

hearing protection used for appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If dust extraction and collection devices can be installed, make sure that these are connected and used correctly. Use of dust collection can reduce dust-related hazards.
h) Do not allow yourself to be lulled into a false sense of security and do not disregard the safety rules for power tools, even if you are familiar with the power tool after using it many times. Careless action can lead to serious injuries within a fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool

will do the job better and safer at the rate for which it was designed.

b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

c) Remove the plug from the wall socket and/or remove the rechargeable battery before you change the device's settings, change accessory parts or put away the power tool. Such preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

e) Look after the power tool and application tool carefully. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

h) Keep handles and grip surfaces dry, clean and free from oil and grease. Slippery handles and grip surfaces do not permit safe operation and control over the power tool in unexpected situations.

5) Use and treatment of this battery-powered tool

a) Only recharge batteries using chargers recommended by the manufacturer. If a charger that has been designed for a particular type of battery is used to charge other batteries, there is a risk of fire.

b) Only use batteries that are intended for the power tool. The use of other batteries may create a fire hazard and lead to injury.

c) When not in use, keep batteries away from paper clips, coins, keys, nails, screws or other small metal objects that could cause the contacts to be bridged. A short circuit between battery contacts can result in burns or a fire.

d) When misused, fluid may leak from the battery. Avoid any contact with it. On accidental contact, wash in running water. If the fluid comes into contact with the eyes, also seek medical assistance. Leaking battery fluid can cause skin irritation or burns.

e) Do not use damaged or altered batteries. Damaged or altered batteries can be unpredictable and lead to fire, explosion or risk of injury.

f) Do not expose batteries to fire or elevated temperatures. Fire on temperatures over 130 °C can cause an explosion.

GBMT

g) Follow all instructions for charging, and never charge the battery or the battery-powered tool outside the temperature range stated in the instruction manual. Incorrect charging or charging outside the permitted temperature range may destroy the battery and increase the risk of fire.

6) Service

a) Have your power tool repaired only by qualified specialists and only with original spare parts. This will ensure that the power tool remains safe. b) Never repair damaged batteries. All battery repairs should be carried out by the manufacturer or authorised customer service centres only.

Special safety instructions for the chain sharpener device

• Never grind using the side surfaces of the grinding discs. Grinding using the side surfaces can cause the grinding disc to burst and fly apart.
• Only use attachment tools with a diameter corresponding to the label.
• Always ensure that the bench grinder is stable and secure.
• Adjust the spark deflector and the work-piece support periodically to compensate for wear on the grinding disc.
• Always use the protective hood, workpiece support, viewing window and spark arrester as required for the attachment tools.
• Ensure that you and all persons in the vicinity keep out of the plane of the rotating grinding disc. The protective

guard is designed to protect the operator from flying debris and accidental contact with the abrasive surface.

• The permissible rotation speed of the attachment tool must be at least as high as the highest rotation speed indicated on the power tool. Accessories that run faster than the allowable speed can break and fly apart.
• Grinders may only be used for the recommended attachment options.
• Use undamaged clamping flanges of the correct size and shape for the grinding disc you selected. Suitable flanges support the grinding disc and thus reduce the danger of the grinding disc breaking.
• The outer diameter and thickness of the attachment tool must correspond to the dimensional specifications of your power tool. Attachment tools which are wrongly dimensioned cannot be sufficiently shielded or controlled.
• The grinding discs and flanges must fit the grinding spindle of your power tool precisely.
• Never use damaged grinding discs. Check attachment tools such as grinding discs for chipping or cracks before each use. If the power tool or the grinding disc falls down, check if it is damaged or use an undamaged grinding disc. When you have checked and inserted the grinding disc, keep yourself and nearby persons out of the plane of the rotating grinding wheel and let the device run at maximum rotational speed for 1 min. Damaged grinding discs usually break during this test period.
• Wear personal protective equipment. Depending on the application, use full face shields, eye protection or safety goggles. In so far as it is appropriate,

wear dust masks, ear protection, gloves or special aprons which keep small grinding and material particles away from you. Eye protection must be worn to protect against foreign matter flying around during the various applications. Dust or breathing masks should filter the dust that is created during operation. If you are exposed to loud noise for a long time, you may suffer hearing loss.

• Ensure that other people are at a safe distance from your working area. Anyone who enters the working area should wear personal protective equipment. Broken bits from the work-piece or broken attachment tools can fly away and cause injuries even beyond the direct working area.
• Clean the ventilation slits of your power tool routinely. The motor air pulls dust into the housing and, should too much metallic dust collect, could cause electrical hazards.
• Never use the power tool near flammable materials. Never use the power tool when it is standing on a flammable surface such as wood. Sparks could ignite this material.
• Do not use attachment tools which require liquid coolant. Using water or another liquid coolant could lead to electrical shock.

Assembly

Always fasten the device on to the worktop with screws of sufficient length and thickness in order to maintain control of the device. If necessary, use the screws provided.

Ensure that you have sufficient space in which to work, and that you do not endanger other people.

Assembling the grinder

Assemble the chain tensioning unit: Illustration A :

1. Remove the cable tie (if necessary with the help of a side cutter).
2. Place the chain tensioning unit (11) on the grinding base (8) and tighten it with the retaining nut (9).
3. Screw the set screw with adjusting nut (13) into the chain tensioning unit (11).

Fixing adjusting screw:

- Screw the adjusting screw with the adjusting nut for the depth stop (6) through the threaded hole on the back of the device.

Setting up the device

for screws supplied Screw gauge: M10:

• Thickness of table edge: 20-30 mm
• Drill diameter: 10.5 mm

Illustration B :

1. Position the device on the work surface/workbench using the stop notches (20). The grinding base (8) must project over the edge of the table.
2. Mark the drill holes with a pen and remove the device.
3. Drill two holes in the work surface/workbench.
4. Screw the grinding base to the work surface/workbench using the enclosed screws (17), washers (17a) and nuts (17b).

Working with the device

Caution! Only use grinding discs and accessories recommended

by the manufacturer. Using other attachment tools and other accessories may represent a risk of injury to you.

Never operate the device without a viewing guard.

Do not use any saw blades.

Remove the battery from the device before carrying out any work.

Always inspect the grinding disc before starting the device: Do not use any broken, cracked or otherwise damaged grinding discs.

Only switch the device on once it is safely fixed to the worktop.

Never operate the device without a viewing guard, chain tensioning unit or grinding disc cover.

Risk of injury!

Make sure that you have a secure footing when working and always ensure that the device is securely fastened to the worktop.

Caution! Risk of injury! Wear eye and hearing protection!

When working with the saw chain, wear cut-resistant protective gloves and, if necessary, an apron to prevent cuts.

Keep your hands away from the grinding disc and teeth of the chain when the device is in operation. Do not move the chain by hand. There is a risk of injury.

Removing/inserting the battery

Illustration : D

1. To remove the battery (19) from the device, press the release button (19a) on the battery (19) and pull the battery (19) out.
2. To insert the battery (19), push the battery (19) along the guide rail into the device. You will hear it click into place.

Checking the charge level of the battery

Red-amber-green => battery fully charged Red-amber => battery approx. half charged

Red => battery needs to be charged

The battery charge status indicator (19c) on the battery (19) shows the charge level.

Press the button (19b) on the battery (19). The charge level is indicated by illumination of the corresponding LED lights.

Charging the battery

If warm, allow the battery to cool before charging.

Charge the battery (19) when only the red LED on the level indicator is illuminated.

1. Remove the battery (19) from the device.
2. Slide the battery (19) into the charging slot of the charger (18).

3. Plug the charger (18) into an outlet.

4. Once charging is complete, disconnect the charger (18) from the mains supply.

5. Pull the battery (19) out of the charger (18).

Switching on and off

Only switch the device on once it is safely fixed to the worktop.

Connect the device to the power supply.

1. Place a battery (19) into the device.
2. To switch on, press the on/off switch (1) to position I, the device starts up.
3. To switch off, press the on/off switch (1) to position O, the device switches off.

The grinding disc still runs even after the device has been switched off. There is a risk of injury.

Thermal protection with restart stop:

If the device automatically shuts down due to being used too much, it will not restart automatically.

To switch on again, press the on/off switch (1) to position I, the device starts up.

Trial run:

Always carry out a trial run of at least 60 seconds duration without load before carrying out your first grinding procedure and after every grinding disc replacement.

Switch the device off immediately if the disc is not rotating smoothly, if considerable vibration occurs or if you hear abnormal noises.

Sharpening the saw chain

When working under dust-prone conditions, ensure ventilation holes are clear (see "Maintenance and cleaning").

An incorrectly sharpened saw chain can cause damage and increases the danger of saw kickback!

Ensure the chain is precisely aligned. Observe the correct sharpening angle and saw chain minimum dimensions. Remove as little material as possible.

Do not grind into driving links (a) or connecting links (b), otherwise the saw chain may break.

If this is not observed, there is a risk of accidents when working with the chainsaw.

Information on sharpening

• Clean the saw chain before sharpening. Remove oily wood or oil residues with a brush or cloth.
  • After sharpening, all the cutting links must have the same length and breadth.
• The chain has become worn down and must be replaced with a new saw chain when only around 4 mm of the cutting tooth remains.

Inserting the saw chain - Illustration C :

1. To open the chain guide rail, turn the tension lever (12) counterclockwise. To do this, return the tension lever to its initial position several times.

2. Place the saw chain into the chain

GBMT

guide rails (7). The cutting edges must face the grinding discs (15).

1. Fold the stop (14) down and pull back the saw chain until the cutting tooth (21) to be sharpened rests on the stop (see figure ①).

Adjusting the working angle - Illustration C :

1. Unscrew the retaining screw (9) and use the scale (10) to adjust the required sharpening angle α on the rotary plate of the chain tensioning unit (11).

3D mechanical part diagram showing a flanged bracket with two circular holes and an angled cut (no text or symbols)

Follow the instructions of the saw chain manufacturer regarding the required sharpening angle .

1. Retighten the retaining screw.

Adjusting the stop - Illustration C :

1. Move the grinding head (2) on the handgrip (4) downwards with the motor switched off.

2. Using the adjusting screw for the chain feed (13a), bring the cutting tooth (21) closer to the grinding disc (15) until the cutting tooth is in contact with the grinding disc (see figure ②). Secure the adjusting screw (13a) using the adjusting nut (13b).

3. Fix the chain links in the chain guide rail (7) by turning the tension lever (12) clockwise (see 1.).

4. Adjust the depth stop using the adjusting screw (6a) so that the grinding disc (15) touches the base of the tooth (see figure ②). Secure the grinding depth with the adjusting nut (6b).

Sharpening - Illustration :

1. Turn the device on (see "Switching on/off").

2. Press the handgrip (4) gently to move the grinding head (2) downwards and sharpen the cutting tooth (21).

The grinding disc (15) must not be brought to a standstill with the brakes. To avoid this, reduce the pressure in good time.

1. Switch off the device to move the saw chain onward.

Loosen the tension lever (12) and fix the next chain link to be sharpened using the adjusted stop (14) and the tension lever in the chain guide rail (7).

i First sharpen the teeth on one side of the chain. Then adjust the sharpening angle and sharpen the teeth on the other side.

Test depth gauge distance (see C fig ③)

The cutting parts of the chain are the cutting links which consist of a cutting tooth (21) and a depth gauge nib (22). The vertical distance between these two determines the depth gauge distance A.

1. After every third sharpening, check the depth gauge distance A according to the saw chain manufacturer's instructions.
2. File the tip of the depth gauge nib (22) with a flat file and round off the depth gauge nib slightly after resetting. The original shape must be maintained.

Maintenance and cleaning

Remove the battery from the device before carrying out any adjustments, maintenance or repair work.

Have any work on the device that is not described in this instruction guide performed by a professional. Only use original parts. Allow the device to cool off before performing any maintenance or cleaning. There is a danger of burns!

Always check the device before using it for obvious defects such as loose, worn or damaged parts, correct the positioning of screws or other parts. Examine the grinding disc in particular (15). Exchange the damaged parts.

Cleaning

Do not use any cleaning agents or solvents. Chemical substances may attack the plastic parts of the device. Never clean the device under running water.

- Thoroughly clean the device after every use.

Clean the ventilation openings ( D 23) and the surface of the device with a soft brush, a paint brush or cloth.

Replacing the grinding disc

Information on replacement:

• Never operate the device without a viewing guard (16).
• Ensure that the rotation speed stated on

the grinding disc

(15) is the same or higher than the nominal rotation speed of the device. Ensure that the disc dimensions match those of the device.

• Only use grinding discs in perfect working order (sound test).
• Only use grinding discs with a locating hole of ∅ 23,2 mm. Never re-drill a locating hole which is too small for the grinding disc to make it larger.
• Never use separate bushings or adapters in order to make grinding discs with a hole that is too large fit the device.
• Do not use any saw blades.
  • Always reassemble the device completely after replacing the grinding disc.

Switch off the device and remove the battery from the device. Allow the device to cool down.

Use protective gloves when working with grinding discs.

Illustration

E:

1. Unscrew the 3 mounting screws to the grinding disc cover (5).
2. Remove the grinding disc cover (3).
3. Unscrew the grinding disc nuts (24) by hand.
4. Remove the grinding disc from the holder (15).
5. Place the new grinding disc onto the holder and manually screw on the grinding disc nut.
6. Screw the grinding disc cover (3) back on.

The grinding disc nut must not be screwed too tightly in order to avoid a breaking of the grinding disc and nut.

GBMT

1. Trial run: Always carry out a trial run of at least 60 seconds duration without load before carrying out your first grinding procedure and after every grinding disc replacement. Switch the device off immediately if the disc is not rotating smoothly, if considerable vibration occurs or if you hear abnormal noises.

Transport

- Always transport the device with one hand on the grinding head (2) and the other hand on the grinding base (8).

Storage

Store the device in a dry and dustproof location and out of reach of children.

The storage temperature for the rechargeable battery and the device is between 0^ C and 45^ C. Avoid extreme cold or heat during storage to ensure the battery output is not adversely affected.

Grinding discs must be dry and stored upright and should never be stacked.

Waste disposal/environmental protection

Remove the battery from the device and recycle the device, battery, accessories and packaging in an environmentally-friendly manner.

Electrical devices do not belong in domestic waste. The crossed out waste bin symbol means that this

product must not be disposed of with household waste after its service life.

Directive 2012/19/EU on waste electrical and electronic equipment: Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured.

Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.

This does not affect accessories enclosed with the old devices or tools without any electrical components.

Do not throw batteries into domestic waste, fire (risk of explosion) or water.

Li-Ion Damaged batteries can harm the environment and your health if poisonous fumes or liquids escape.

Dispose of the batteries according to local standards. Defective or used batteries must be recycled in accordance with Directive 2006/66/EC. Hand in the batteries at a used battery collection point where they are recycled in an environmentally friendly manner. For more information, please contact your local waste management provider or our service centre.

Dispose of batteries in a discharged state. We recommend covering the contacts with an adhesive strip to protect against short circuits. Do not open the battery.

Guarantee

Dear Customer,

This equipment is provided with a 3-year guarantee from the date of purchase.

In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The term of the guarantee begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase.

If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective equipment and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred. If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The equipment has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. Grinding disc) or to cover damage to breakable parts (e.g. Switches, Viewing guard).

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided. The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure quick handling of you issue, please follow the following directions:

- Please have the receipt and item number (IAN 423082_2210) ready as proof of purchase for all enquiries.

- Please find the item number on the rating plate.

- Should functional errors or other defects occur, please initially contact the service department specified below by telephone or by e-mail. You will then receive further information on the processing of your complaint.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the

address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the equipment inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

Repair Service

For a charge, repairs not covered by the guarantee can be carried out by our service branch, which will be happy to issue a cost estimate for you. We can handle only equipment that has been sent with adequate packaging and postage.

Attention: Please send your equipment to our service branch in clean condition and with an indication of the defect.

Equipment sent carriage forward or by bulky goods, express or other special freight will not be accepted.

We will dispose of your defective devices free of charge when you send them to us.

Service-Center

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IAN 423082_2210

MT Service Malta

Tel.: [phone]

E-Mail: [e-mail]

IAN 423082_2210

Importer

Please note that the following address is not a service address. Please initially contact the service centre specified above.

Replacement parts/Accessories

Spare parts and accessories can be obtained at www.www.grizzlytools.shop

If you have issues ordering, please use the contact form. If you have any other questions, contact the "Service-Center" (see page 38).

Position Description Order no.

15/24 Grinding disc + Grinding disc nut 91110357

Sommaire

Introduction ......39

Service-Center....58

Importateur ....58

3D mechanical part diagram showing a flanged edge with two circular holes and an angled cutout labeled 'a' (no text or symbols beyond the label)

Do not throw batteries into domestic waste, fire (risk of explosion) or water. Damaged batteries can harm the envi-ent and your health if poisonous fumes fluids escape.

Dispose of the batteries according to local standards. Defective or used batteries must be recycled in accordance with Directive 2006/66/EC. Hand in the batteries at a used battery collection point where they are recycled in an environmentally friendly manner. For more information, please contact your local waste management provider or our service centre.

Dispose of batteries in a discharged state. We recommend covering the contacts with an adhesive strip to protect against short circuits. Do not open the battery.

Garantie - France

Service-Center....75

Importeur ....75

Reserveonderdelen/Accessoires .75

3D mechanical part diagram showing a flanged bracket with two circular holes and an angled cut (no text or symbols)

1. Draai de borgschroef weer vast.

Service-Center....93

Importer 93

3D mechanical part diagram showing a stepped component with two circular holes and an angled cut (no text or symbols)

Service-Center......110

Importador....110

3D mechanical part diagram showing a flanged end with two circular holes and an angled cut (no text or symbols)

Service-Center....126

Importør 126

Reservedele / Tilbehør ......126

3D mechanical part diagram showing a bent edge with two circular holes and an angled cut (no text or symbols)

Service-Center....143

Importatore ....143

3D mechanical part diagram showing a flanged edge with two circular holes and an angled cut (no text or symbols)

Service-Center......159

Dovozce....159

3D mechanical part diagram showing a flanged bracket with two circular holes and an angled cut (no text or symbols)

Service-Center....175

Dovozca....175

3D diagram of a mechanical part with two circular holes and an angled cutout labeled 'a' (no text or symbols beyond the label)

3D mechanical part diagram showing a flanged end with two circular holes and an angled cut (no text or symbols)

3D mechanical part diagram showing a flanged bracket with two circular holes and an angled cut (no text or symbols)

1. Ponovno privijte nastavitveni vijak.

Pooblaščeni serviser:

Tel.: [phone]

E-Mail: [e-mail]

(Birotehnika, Hodošček Renata s.p., Lendavska ULICA 23, 9000 Murska Sobota)

Garancijski list

Service-Center......224

Proizvođač......224

Rezervni dijelovi/Pribor .....224

Prijevod originalne CE

Izjave o podudarnosti .....293

3D mechanical part diagram showing a flanged bracket with two circular holes and an angled cutout labeled 'α' (no text or symbols beyond the label)

Obratite pozornost na navode proizvođača lanca pile, u pogledu potrebnog kuta oštenja a.

1. Stezni vijak ponovo zategnite.

Introducere ......225

Service-Center......241

Importator 241

3D mechanical part diagram showing a flanged edge with two circular holes and an angled cutout labeled 'a' (no text or symbols beyond the label)

3D mechanical part diagram showing a flanged bracket with two circular holes and an angled cut (no text or symbols)

GBMT	Translation of the original EC declaration of conformity
We hereby confirm that theChain SharpenerPSGA 20-Li A1 seriesSerial number000001 - 040000conforms with the following applicable relevant version of the EU guidelines:
2006/42/EC • 2014/30/EU • 2011/65/EU* & (EU)2015/863Device including smart battery Smart PAPS 204 A1/Smart PAPS 208 A1: 2014/53/EU
In order to guarantee consistency, the following harmonised standards as well as national standards and stipulations have been applied:
EN 62841-1:2015 • PPP 58094B:2022EN IEC 55014-1:2021 • EN IEC 55014-2:2021IEC 62471:2006 • EN IEC 63000:2018Device including smart battery Smart PAPS 204 A1/Smart PAPS 208 A1:EN 301 489-1 V2.2.3:2019 • Draft EN 301 489-17 V3.2.5:2022EN 300 328 V2.2.2:2019 • EN 50663:2017
This declaration of conformity is issued under the sole responsibility of the manufacturer:
CE Grizzly Tools GmbH & Co. KGStockstädter Straße 2063762 GroßostheimGermany15.04.2023	Christian FrankDocumentation Representative

* The object of the declaration described above satisfies the provisions of Directive 2011/65/EU of the European Parliament and the Council of 8 June 2011 on limiting the use of certain harmful substances in electrical and electronic appliances.

FSC www.fsc.org MIX From responsible sources FSC® C142550

FSC www.fsc.org MIXTE Issu de sources responsables FSC® C142550
