USER MANUAL GGS 30 LS Professional BOSCH

äußeren Abmessung größer als 25cm sind, im Einzel- handelsgeschäft oder in unmittelbarer Nähe hierzu un- entgeltlich zurückzunehmen; die Rücknahme darf nicht an den Kauf eines Elektro- oder Elektronikgerätes ge- knüpft werden und ist auf drei Altgeräte pro Geräteart beschränkt. Der Vertreiber hat beim Abschluss des Kaufvertrags für das neue Elektro- oder Elektronikgerät den Endnutzer über die Möglichkeit zur unentgeltlichen Rückgabe bzw. Abholung des Altgeräts zu informieren und den Endnutzer nach seiner Absicht zu befragen, ob bei der Auslieferung des neuen Ge- räts ein Altgerät zurückgegeben wird. Dies gilt auch bei Vertrieb unter Verwendung von Fernkom- munikationsmitteln, wenn die Lager- und Versandflächen für Elektro- und Elektronikgeräte mindestens 400m² betragen oder die gesamten Lager- und Versandflächen mindestens 1 609 92A A6Z | (15.01.2025) Bosch Power ToolsEnglish | 13 800m² betragen, wobei die unentgeltliche Abholung auf Elektro- und Elektronikgeräte der Kategorien 1 (Wärmeüber- träger), 2 (Bildschirmgeräte) und 4 (Großgeräte mit mindes- tens einer äußeren Abmessung über 50cm) beschränkt ist. Für alle übrigen Elektro- und Elektronikgeräte muss der Ver- treiber geeignete Rückgabemöglichkeiten in zumutbarer Ent- fernung zum jeweiligen Endnutzer gewährleisten; das gilt auch für Altgeräte, die in keiner äußeren Abmessung größer als 25cm sind, die der Endnutzer zurückgeben will, ohne ein neues Gerät zu kaufen. English Safety Instructions General Power Tool Safety Warnings WARNING Read all safety warnings and all in- structions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains- operated (corded) power tool or battery-operated (cord- less) power tool. Work area safety u Keep work area clean and well lit. Cluttered or dark areas invite accidents. u Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. u Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. Electrical safety u Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. u Avoid body contact with earthed or grounded sur- faces, such as pipes, radiators, ranges and refrigerat- ors. There is an increased risk of electric shock if your body is earthed or grounded. u Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of elec- tric shock. u Do not abuse the cord. Never use the cord for carry- ing, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. u When operating a power tool outdoors, use an exten- sion cord suitable for outdoor use. Use of a cord suit- able for outdoor use reduces the risk of electric shock.. u If operating a power tool in a damp location is un- avoidable, use a residual current device (RCD) protec- ted supply. Use of an RCD reduces the risk of electric shock. Personal safety u Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inatten- tion while operating power tools may result in serious per- sonal injury. u Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal in- juries. u Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or en- ergising power tools that have the switch on invites acci- dents. u Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal in- jury. u Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. u Dress properly. Do not wear loose clothing or jew- ellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. u If devices are provided for the connection of dust ex- traction and collection facilities, ensure these are con- nected and properly used. Use of dust collection can re- duce dust-related hazards. Power tool use and care u Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was de- signed. u Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. u Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. u Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or Bosch Power Tools 1 609 92A A6Z | (15.01.2025)14 | English these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. u Maintain power tools. Check for misalignment or bind- ing of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. u Keep cutting tools sharp and clean. Properly main- tained cutting tools with sharp cutting edges are less likely to bind and are easier to control. u Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into ac- count the working conditions and the work to be per- formed. Use of the power tool for operations different from those intended could result in a hazardous situation. Service u Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Safety instructions for all operations Safety warnings common for grinding, wire brushing, polishing or carving u This power tool is intended to function as a grinder, wire brush, polisher or carving tool. Read all safety warnings, instructions, illustrations and specifica- tions provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. u Operations such as sanding or cutting-off are not re- commended to be performed with this power tool. Op- erations for which the power tool was not designed may create a hazard and cause personal injury. u Do not use accessories which are not specifically de- signed and recommended by the tool manufacturer. Just because the accessory can be attached to your power tool, it does not assure safe operation. u The rated speed of the grinding accessories must be at least equal to the maximum speed marked on the power tool. Grinding accessories running faster than their rated speed can break and fly apart. u The outside diameter and the thickness of your ac- cessory must be within the capacity rating of your power tool. Incorrectly sized accessories cannot be ad- equately controlled. u The arbour size of wheels, sanding drums or any other accessory must properly fit the spindle or collet of the power tool. Accessories that do not match the mounting hardware of the power tool will run out of balance, vibrate excessively and may cause loss of control. u Mandrel mounted wheels, sanding drums, cutters or other accessories must be fully inserted into the collet or chuck. If the mandrel is insufficiently held and/or the overhang of the wheel is too long, the mounted wheel may become loose and be ejected at high velocity. u Do not use a damaged accessory. Before each use in- spect the accessory such as abrasive wheels for chips and cracks, sanding drum for cracks, tear or excess wear, wire brush for loose or cracked wires. If power tool or accessory is dropped, inspect for damage or in- stall an undamaged accessory. After inspecting and installing an accessory, position yourself and bystand- ers away from the plane of the rotating accessory and run the power tool at maximum no-load speed for one minute. Damaged accessories will normally break apart during this test time. u Wear personal protective equipment. Depending on application, use face shield, safety goggles or safety glasses. As appropriate, wear dust mask, hearing pro- tectors, gloves and workshop apron capable of stop- ping small abrasive or workpiece fragments. The eye protection must be capable of stopping flying debris gen- erated by various operations. The dust mask or respirator must be capable of filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss. u Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation. u Hold power tool by insulated gripping surfaces only, when performing an operation where the cutting ac- cessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live" wire may make ex- posed metal parts of the power tool "live" and could give the operator an electric shock. u Always hold the tool firmly in your hand(s) during the start-up. The reaction torque of the motor, as it acceler- ates to full speed, can cause the tool to twist. u Use clamps to support workpiece whenever practical. Never hold a small workpiece in one hand and the tool in the other hand while in use. Clamping a small work- piece allows you to use your hand(s) to control the tool. Round material such as dowel rods, pipes or tubing have a tendency to roll while being cut, and may cause the bit to bind or jump toward you. u Position the cord clear of the spinning accessory. If you lose control, the cord may be cut or snagged and your hand or arm may be pulled into the spinning accessory. u Never lay the power tool down until the accessory has come to a complete stop. The spinning accessory may grab the surface and pull the power tool out of your con- trol. u After changing the bits or making any adjustments, make sure the collet nut, chuck or any other adjust- ment devices are securely tightened. Loose adjustment devices can unexpectedly shift, causing loss of control, loose rotating components will be violently thrown. u Do not run the power tool while carrying it at your side. Accidental contact with the spinning accessory 1 609 92A A6Z | (15.01.2025) Bosch Power ToolsEnglish | 15 could snag your clothing, pulling the accessory into your body. u Regularly clean the power tool’s air vents. The motor’s fan will draw the dust inside the housing and excessive accumulation of powdered metal may cause electrical hazards. u Do not operate the power tool near flammable materi- als. Sparks could ignite these materials. u Do not use accessories that require liquid coolants. Using water or other liquid coolants may result in electro- cution or shock. Kickback and related warnings Kickback is a sudden reaction to a pinched or snagged rotat- ing wheel, sanding band, brush or any other accessory. Pinching or snagging causes rapid stalling of the rotating ac- cessory which in turn causes the uncontrolled power tool to be forced in the direction opposite of the accessory’s rota- tion. For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the wheel that is entering into the pinch point can dig into the surface of the material causing the wheel to climb out or kick out. The wheel may either jump toward or away from the operator, depending on direc- tion of the wheel’s movement at the point of pinching. Abras- ive wheels may also break under these conditions. Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below. u Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces. The operator can control kickback forces, if proper precautions are taken. u Use special care when working corners, sharp edges etc. Avoid bouncing and snagging the accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback. u Do not attach a toothed saw blade. Such blades create frequent kickback and loss of control. u Always feed the bit into the material in the same dir- ection as the cutting edge is exiting from the material (which is the same direction as the chips are thrown). Feeding the tool in the wrong direction causes the cutting edge of the bit to climb out of the work and pull the tool in the direction of this feed. u When using rotary files, high-speed cutters or tung- sten carbide cutters, always have the work securely clamped. These wheels will grab if they become slightly canted in the groove, and can kickback.When the rotary file, high-speed cutter or tungsten carbide cutter grab, it may jump from the groove and you could lose control of the tool. Safety warnings specific for grinding and abrasive cutting-off operations u Use only wheel types that are recommended for your power tool and only for recommended applications. For example: do not grind with the side of a cut-off wheel. Abrasive cut-off wheels are intended for peri- pheral grinding, side forces applied to these wheels may cause them to shatter. u For threaded abrasive cones and plugs use only un- damaged wheel mandrels with an unrelieved shoulder flange that are of correct size and length. Proper man- drels will reduce the possibility of breakage. u Do not “jam” a cut-off wheel or apply excessive pres- sure. Do not attempt to make an excessive depth of cut. Overstressing the wheel increases the loading and susceptibility to twisting or snagging of the wheel in the cut and the possibility of kickback or wheel breakage. u Do not position your hand in line with and behind the rotating wheel. When the wheel, at the point of opera- tion, is moving away from your hand, the possible kick- back may propel the spinning wheel and the power tool directly at you. u When wheel is pinched, snagged or when interrupting a cut for any reason, switch off the power tool and hold the power tool motionless until the wheel comes to a complete stop. Never attempt to remove the cut- off wheel from the cut while the wheel is in motion otherwise kickback may occur. Investigate and take corrective action to eliminate the cause of wheel pinching or snagging. u Do not restart the cutting operation in the workpiece. Let the wheel reach full speed and carefully re-enter the cut. The wheel may bind, walk up or kickback if the power tool is restarted in the workpiece. u Support panels or any oversized workpiece to minim- ize the risk of wheel pinching and kickback. Large workpieces tend to sag under their own weight. Supports must be placed under the workpiece near the line of cut and near the edge of the workpiece on both sides of the wheel. u Use extra caution when making a “pocket cut” into ex- isting walls or other blind areas. The protruding wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback. Safety warnings specific for wire brushing operations u Be aware that wire bristles are thrown by the brush even during ordinary operation. Do not overstress the wires by applying excessive load to the brush. The wire bristles can easily penetrate light clothing and/or skin. u Allow brushes to run at operating speed for at least one minute before using them. During this time no one is to stand in front or in line with the brush. Loose bristles or wires will be discharged during the run-in time. u Direct the discharge of the spinning wire brush away from you. Small particles and tiny wire fragments may be discharged at high velocity during the use of these brushes and may become imbedded in your skin. Additional safety information u Do not touch grinding discs until they have cooled down. The discs can become very hot while working. Bosch Power Tools 1 609 92A A6Z | (15.01.2025)16 | English u Use suitable detectors to determine if utility lines are hidden in the work area or call the local utility com- pany for assistance. Contact with electric lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes property dam- age or may cause an electric shock. u Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure than by hand. u This power tool is not suitable for bench-mounted use. It must not be clamped into a vice or fastened to a work- bench, for example. u Products sold in GB only: Your product is fitted with an BS 1363/A approved elec- tric plug with internal fuse (ASTA approved to BS 1362). If the plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place by an authorised customer service agent. The replacement plug should have the same fuse rating as the original plug. The severed plug must be disposed of to avoid a possible shock hazard and should never be inserted into a mains socket elsewhere. Product Description and Specifications Read all the safety and general instructions. Failure to observe the safety and general in- structions may result in electric shock, fire and/or serious injury. Please observe the illustrations at the beginning of this oper- ating manual. Intended Use The power tool is intended for grinding and deburring metal with corundum grinding tools, as well as for working with sanding belt tools. The power tool is additionally intended for brushing and pol- ishing metal. Product Features The numbering of the product features refers to the diagram of the power tool on the graphics page. (1) Collet (2) Clamping nut (3) Grinding spindle (4) Spindle collar (insulated gripping surface) (5) On/off switch (GGS30LS / GGS30S) (6) Speed preselection thumbwheel (7) Handle (insulated gripping surface) (8) Open-ended spanner on the grinding spindle

(9) Open-ended spanner on the clamping nut

Speed adjustment range min

kg 1.7 1.8 1.5 Protection class / II / II / II A) Weight without mains connection cable and without mains plug The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models. Values can vary depending on the product, scope of application and environmental conditions. To find out more, visit www.bosch-professional.com/wac. Noise/Vibration Information

(triax vector sum) and uncertaintyK determined according toEN60745-2-23: Surface grinding (roughing with grinding tool diameter of 25 mm):

Surface grinding (roughing with grinding tool diameter of 50 mm):

The vibration level given in these instructions has been measured in accordance with a standardised measuring pro- cedure and may be used to compare power tools. It can also be used for a preliminary estimation of exposure to vibra- tion. The stated vibration level applies to the main applications of the power tool. However, if the power tool is used for differ- ent applications, with different application tools or poorly maintained, the vibration level may differ. This can signific- antly increase the exposure to vibration over the total work- ing period. To estimate the exposure to vibration accurately, the times when the tool is switched off or when it is running but not ac- tually being used should also be taken into account. This can significantly reduce the exposure to vibration over the total working period. Implement additional safety measures to protect the oper- ator from the effects of vibration, such as servicing the power tool and application tools, keeping the hands warm, and organising workflows correctly. Fitting u Pull the plug out of the socket before carrying out any work on the power tool. Fitting Abrasive Tools Using an Open-Ended Spanner and Spindle Lock (see figureA) u Only use open-ended spanners that are suitable and undamaged (see "Technical Data"). – Clean the grinding spindle(3) and all the parts to be fit- ted. – Press the spindle lock (13) and turn the clamping nut (2) by hand until locked. – Press and hold the spindle lock and loosen the clamping nut (2) with the open-ended spanner (9) by turning it an- ticlockwise. – Insert the straight shank of the grinding tool all the way into the collet(1). – Press the spindle lock(13) and tighten the application tool by placing the open-ended spanner(9) on the span- ner flat and turning it clockwise. The grinding tools must run completely concentrically. Do not continue to use damaged grinding tools that are out of balance. If the grinding tools are out of balance, they should be replaced. u Do not, under any circumstances, tighten the collet with the clamping nut until a grinding tool has been fitted. The collet may otherwise become damaged. u Only use mounted points with an appropriate shank diameter. A mounting point with a shank diameter which Bosch Power Tools 1 609 92A A6Z | (15.01.2025)18 | English does not correspond to the tool holder of the power tool (see "Technical data") cannot be held properly and will damage the collet chuck. u The application tool must be clamped at least 10 mm. The inner shank dimension L

can be used to calculate the maximum permitted speed of the application tool from the specifications provided by the manufacturer of the application tool. It must not be less than the maximum speed of the power tool. Fitting Abrasive Tools Using Two Open-Ended Spanners (see figureB) u Only use open-ended spanners that are suitable and undamaged (see "Technical Data"). – Clean the grinding spindle (3) and all the parts to be fit- ted. – Use an open-ended spanner (8) on the spanner flat of the grinder spindle (3) to hold it in place. Loosen the clamping nut (2) by placing an open-ended spanner (9) on the spanner flat and turning it counter- clockwise. – Insert the straight shank of the grinding tool all the way into the collet (1). – Hold the grinding spindle (3) with the open-ended span- ner (8) and tighten the application tool by placing the open-ended spanner (9) on the spanner flat and turning it clockwise. The grinding tools must run completely concentrically. Do not continue to use damaged grinding tools that are out of balance. If the grinding tools are out of balance, they should be replaced. u Do not, under any circumstances, tighten the collet with the clamping nut until a grinding tool has been fitted. The collet may otherwise become damaged. u Only use mounted points with an appropriate shank diameter. A mounting point with a shank diameter which does not correspond to the tool holder of the power tool (see "Technical data") cannot be held properly and will damage the collet chuck. u The application tool must be clamped at least 10 mm. The inner shank dimension L

can be used to calculate the maximum permitted speed of the application tool from the specifications provided by the manufacturer of the application tool. It must not be less than the maximum speed of the power tool. Dust/Chip Extraction Dust from materials such as lead-containing coatings, some wood types, minerals and metal can be harmful to one’s health. Touching or breathing-in the dust can cause allergic reactions and/or lead to respiratory infections of the user or bystanders. Certain dust, such as oak or beech dust, is considered carci- nogenic, especially in connection with wood-treatment ad- ditives (chromate, wood preservative). Materials containing asbestos may only be worked by specialists. – Provide for good ventilation of the working place. – It is recommended to wear a P2 filter-class respirator. Observe the relevant regulations in your country for the ma- terials to be worked. u Avoid dust accumulation at the workplace. Dust can easily ignite. Operation Starting operation u Products that are only sold in AUS and NZ: Use a resid- ual current device (RCD) with a nominal residual current of 30 mA or less. u Pay attention to the mains voltage. The voltage of the power source must match the voltage specified on the rating plate of the power tool. u Check whether there is visible damage to the collet(1) and clamping nut(2) before each use. Switching On and Off

To start the power tool, slide the on/off switch(5) forwards. To lock the on/off switch(5) in position, push the on/off switch(5) forwards and down until it clicks into place. To switch off the power tool, release the on/off switch(5); or, if the switch is locked, briefly push the on/off switch(5) backwards and down and then release it. Switching On and Off GGS 30 LPS To start the power tool, first slide the lock-off button(12) to the rear, then press and hold the on/off switch(11). To switch off the power tool, release the on/off switch(11). Constant Electronic control The Constant Electronic keeps the speed at no load and un- der load virtually consistent, guaranteeing uniform perform- ance. Speed preselection You can preselect the required speed using the speed preselection thumbwheel (6), even during operation. The required speed depends on the material being worked and the diameter of the application tool. Observe the max- imal allowable speed of the application tool.

GGS 30 LS/GGS 30 LPS

At maximum speed, the maximum permitted diameter of the accessory is 40mm. GGS 30 S At maximum speed, the maximum permitted diameter of the accessory is 45mm. If you are using an accessory with a diameter of 50mm, make sure that the speed is not greater than 30000min

Thumbwheel position No-load speed (min

www.bosch-pt.com/serviceaddresses

3 mm 2 608 570 082 1/8" 2 608 570 083 6 mm 2 608 570 084 1/4" 2 608 570 085 8 mm 2 608 570 086 6 mm 15 mm 30 mm 36 000 2 608 620 035 M15 2 608 570 141 (19 mm) Bosch Power Tools 1 609 92A A6Z | (15.01.2025)248 | Legal Information and Licenses Legal Information and Licenses Copyright © 2020, Microchip Technology Inc. and its subsidiaries ("Microchip") All rights reserved. This software is developed by Microchip Technology Inc. and its subsidiaries ("Microchip"). Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: – Redistributions of source code must retain the above copyright noti- ce, this list of conditions and the following disclaimer. – Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the do- cumentation and/or other materials provided with the distribution. – Microchip's name may not be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY MICROCHIP "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL MICROCHIP BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA OR PROFITS; OR BUSINESS INTERRUPTION) HOWSOEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Warranty Disclaimer This product contains Open Source Software components which underly Open Source Software Licenses. Please note that Open Source Licenses contain disclaimer clauses. The text of the Open Source Licenses that apply are included in this manual under "Legal Information and Licenses". 1 609 92A A6Z | (15.01.2025) Bosch Power ToolsI

EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regulations listed below and are in conformity with the following standards. Technical file at: * Die grinder Article number

• Robert Bosch Power Tools GmbH (PT/ECS) 70538 Stuttgart GERMANY Thomas Donato Chairman of the Management Board Helmut Heinzelmann Head of Product Certification Robert Bosch Power Tools GmbH, 70538 Stuttgart, GERMANY Stuttgart, 18.12.2024 Bosch Power Tools 1 609 92A A6Z | (15.01.2025)IV 1 609 92A A6Z | (15.01.2025) Bosch Power Toolsi Declaration of Conformity Die grinder Article number GGS 30 LS GGS 30 LS GGS 30 S GGS 30 S 3 601 BB5 070 3 601 BB5 060 3 601 BB5 170 3 601 BB5 160 We declare under our sole responsibility that the stated products comply with all applicable provisions of the regulations lis- ted below and are in conformity with the following standards. Technical file at: Robert Bosch Ltd. (PT/SOP-GB), Broadwater Park, North Orbital Road, Uxbridge UB9 5HJ, United Kingdom The Supply of Machinery (Safety) Regulations 2008 The Electromagnetic Compatibility Regulations 2016 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 EN 60745-1:2009+A11:2010 EN 60745-2-23:2013

EN 61000-3-3:2013+A1:2019+A2:2021 EN IEC 63000:2018 Robert Bosch Power Tools GmbH, 70538 Stuttgart, Germany represented (in terms of the above regulations) by Robert Bosch Limited, Broadwater Park, North Orbital Road, Uxbridge UB9 5HJ, United Kingdom Steve Neumann Regional Business Director UK & Ireland Martin Sibley Business Operations and Aftersales Director Robert Bosch Ltd. Broadwater Park, North Orbital Road, Uxbridge UB9 5HJ, United Kingdom, as authorised representative acting on behalf of Robert Bosch Power Tools GmbH, 70538 Stuttgart, Germany Place of issue: Uxbridge Date of issue: 17/12/2024 Bosch Power Tools 1 609 92A A6Z | (15.01.2025)
