USER MANUAL BH 18V26 F Professional BOSCH
(11) Rotational direction switch (12) Handle (insulated gripping surface) (13) On/off switch (14) Battery
(15) Release button for impact/mode selector switch (16) Impact/mode selector switch (17) Worklight (18) Button for depth stop adjustment (19) Auxiliary handle (insulated gripping surface) (20) Depth stop (21) Securing screw for keyed chuck (GBH18V-26)
(22) Keyed chuck (GBH18V-26)
(23) SDS plus shank for drill chuck (GBH18V-26)
Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Technical Data Cordless rotary hammer GBH18V-26 GBH18V-26F Article number 3611J090.. 3611J10... Speed control ● ● Stop rotation ● ● Clockwise/anticlockwise rotation ● ● Quick-change chuck − ● Rated voltage V= 18 18 Rated power input W 425 425 Impact rate
0–4350 0–4350 Impact energy per stroke according to EPTA-Procedure 05:2016 J 2.6 2.6 Rated speed – Clockwise min
0–980 0–980 Tool holder SDS plus SDS plus Spindle collar diameter mm 50 50 Max. drilling diameter: – Concrete mm 26 26 – Masonry (with hollow core bit) mm 68 68 – Steel mm 13 13 – Wood mm 30 30 Weight according to EPTA-Procedure 01:2014 kg 3.2−4.2 3.3−4.4 Length mm 347 378 Height mm 225 225 Recommended ambient temperature dur- ing charging °C 0 to +35 0 to +35 Permitted ambient temperature during op- eration
Noise emission values determined according to EN60745-2-6. Typically, the A-weighted noise level of the power tool is: Sound pressure level dB(A)
(triax vector sum) and uncertainty K determined according to EN60745-2-6: Hammer drilling into concrete:
Drilling into metal:
EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regulations listed below and are in conformity with the following standards. Technical file at: * Cordless rotary hammer Article number
