USER MANUAL Q10000 INTENSO

Read these instrucons carefully and please observe and heed all references made in these instrucons to guarantee a long life and reliable use of the device. Please keep these instrucons ready to hand and pass them on to other users of the device. About these instructions GENERAL Declaration of conformity The CE marking says that this product meets the requirements of all EU Direcves applicable for this product. Delivery scope OVERVIEW This Powerbank is intended exclusively for the power supply of devices with an operang voltage of 5V direct current (mobile phone, MP3 player, etc.) as well as devices which support the Qualcomm® Quick Charge™ Technology Standard. Another use, or one going beyond this, is deemed as not intended and can lead to damages and injuries. This product is not intended for commercial use or for medical and special applicaons, where the failure of the product can cause injuries, mortalies or considerable material damages. Claims of any kind due to damages from improper use or non-observance of safety instrucons are excluded. Intended useEN - Page 3 of 7

By briey pressing the key, the current baery status is displayed through the LED lights and the Powerbank is acvated. If no device is connected to the Powerbank, or the connected device is fully charged, the Powerbank changes automacally into standby mode aer a me interval of approx. 5 seconds. Operation LED light % Energy LED 1 LED 2 LED 3 LED 4 1 % - 25 % 26 % - 50 % 51 % - 75% 76 % - 100 %

3. Commissioning / Charging the Powerbank / Charging connected Devices

a) Charging the Powerbank Connect the supplied microUSB cable with the microUSB port (IN) of the Powerbank and connect the other end of the USB cable with a standard USB port of a computer or USB power supply. The charging process and the current charge status is signalled via the LED status lights When the Powerbank is fully charged, the LED status lights are permanently on. The required charging me of the Powerbank is dependent on the selected charging source and its output (max. 5V / 2.1A).

The individual LEDs display the remaining energy of the Powerbank:EN - Page 4 of 7 b) Charging devices with the Powerbank This Powerbank has a USB A port (USB OUT) (Output 5V 3.1A max.) and a Qualcomm Quick Charge 3.0 USB A port (USB QC OUT) (Output normal 5V 3.1A max.; Output Quick Charge 5-6V 3.1A max., 9V 2.0A max., 12V 1.5A max.). Normal charging: Connect the supplied USB cable with the USB A port (USB OUT) on the Powerbank and the other end of the USB cable with the microUSB port of the device to be charged (5V 3.1A max. Output). Charging with Qualcomm Quick Charge 3.0: To be able to use the Quick Charge Technology (you can nd more informaon at www.qualcomm.com/products/snapdragon/quick-charge) you require a terminal device which supports this standard (if necessary, ask the manufacturer of your terminal device). Connect the supplied USB cable with the Quick Charge USB A port (USB QC OUT) to the Powerbank and the other end of the USB cable with the microUSB port of the device to be charged and compable with Quick Charge. The intelligent control of the Quick Charge 3.0 Technology now adapts the charge process to your connected device (5-6V 3.1A max., 9V 2.0A max., 12V 1.5A max.). Quick Charge 3.0 is downward compable to earlier versions, you can therefore , for example, charge a Quick Charge 2.0 device with the advantages of the Quick Charge 2.0 Technology with this Powerbank. You can also operate a device not compable with Quick Charge on the USB QC OUT port, or a Quick Charge compable device on the normal USB OUT port (Output 5V 3.1A max.). You can charge two devices simultaneously with the Powerbank, for example a Tablet at the normal USB A port (USB OUT) and a Smartphone at the Quick Charge (USB QC OUT) port. However, the Quick Charge Technology is only supported when only one Quick Charge capable device is connected to the USB QC OUT. When two devices are connected simultaneously, the normal charging standard is used for both ports and the maximum output voltage is shared between both ports (Output 5V 3.1A max.) Of course you can also use your own USB charging cable to connect the Powerbank with your device. However, please note that devices can only be charged via the USB A ports (USB A OUT / USB QC OUT) of the Powerbank and you require a Quick Charge capable USB cable for the Quick Charge Technology (if necessary, ask the manufacturer of your USB cable). If a device is charged with the Powerbank and the capacity of the Powerbank is almost exhausted, this is signalled by blinking of the last status LED. Please re-charge the Powerbank. Please note that while charging a device with a Powerbank, about 30% of the total capacity is used up just through the charging process. This is due, for example, through the loss of power from circuit warmth and voltage conversion. The Powerbank has to be used regularly for opmum performance. If this is not the case, charge the Powerbank fully at least every three months. Make sure that the warmth created through the charging process can be emied from the device (ideally place the Powerbank on a rm and heat-resistant base while in use).EN - Page 5 of 7 Do not use the device in extremely cold, hot, humid or dusty areas. Do not subject it to direct sunlight. Protect the product from open re. There is danger of explosion! Protect the device in every operang state against impact and falling. This device is sensive to electrostac discharge. Therefore protect the device against every possible electrostac discharge. To avoid malfuncons, do not connect the USB output ports of the device with USB ports of computers or other devices. They are only intended for charging devices. Do not disassemble to device into its component parts and do not try to repair it yourself. It does not contain any parts requiring maintenance and the guarantee expires in this case. Do not insert any items, which are not intended for its use, into the openings of the product. This could lead to an electrical short-circuit and a resultant re. Do not operate this device with wet hands. Please do not use water or chemical soluons to clean the device. Please use only a dry cloth for this purpose. Do not try to repair the device yourself. The guarantee expires in this case. The device develops warmth when in use, this is normal. Do not cover the device when this is in use. Do not use the device when it shows visible damage or has become moist. OPERATING CONDITIONS Operate the device at 0 to 40 degrees Celcius at max. 90% relave humidity (for a short me). If you do not use the Powerbank for a longer period of me, store it at between -10 and 45 degrees Celsius at max. 90% relave humidity (for a short me) and charge this every three months to retain the full performance. SAFETY INSTRUCTIONS Children oen underesmate dangers or do not recognise them at all. This device is not intended to be used by persons (including children) with restricted sensory, physical or mental abilies or lack of experience and/or knowledge, unless they are supervised by a person responsible for their safety or received instrucons from the person on how to use the device and they have understood the resultant dangers. Unsupervised children should not have access to the device. Make sure that children do not play with the device. Dangers for children and persons with restricted physical, sensory or mental abilities: GeneralEN - Page 6 of 7 Disposal of old baeries: The devices marked with this symbol are subject to the European Direcve 2006/66/EC All old baeries must be disposed of separate from the municipal waste stream via designated collecon facilies appointed by the government or the local authories You avoid environmental damage with the proper disposal. Disposal of old electronic equipment: The devices marked with this symbol are subject to the European Direcve 2012/19/EC. All electrical appliances and old electrical appliances must be disposed of separate from the municipal waste stream via designated collecon facilies appointed by the government or the local authories You avoid environmental damage with the proper disposal of old electrical equipment. Packaging: Packaging is raw material. The packaging material of this product is suitable for recycling and can be re-used. Please pay aenon to the local recycling provisions when disposing of any materials. DISPOSAL

EXCLUSION OF LIABILITY

The rmware and/or hardware may be changed at any me without prior noce. For this reason it is possible that parts of these instrucons, technical data and images in this documentaon dier slightly from the product in your possession. All points described in these instrucons only serve the purpose of claricaon and must not inevitably correspond to a certain situaon. Legal claims cannot be made on the basis of these instrucons. TECHNICAL DATA Dimensions: 141 x 74,4 x 14 mm Power consumpon (input): 5V / 2.1A Charging current delivery (Output) USB OUT + USB QC OUT: 5V - 3.1A (total) USB QC OUT (QC 3.0): 5V/6V - 3.0A, 9V - 2A, 12V - 1.5A Internal baery: 10.000 mAh / 3.7 V Lithium Polymer baery Status display: 4 LED lights Integrated overcharge protecon / discharge protecon / overvoltage protecon / short circuit fuse: Yes Standby me: Up to 3 monthsGUARANTEE CONDITIONS AND COMPLAINTS PROCEDURE EN - Page 7 of 7 Intenso Internaonal GmbH grants a two-year guarantee for this product in addion to the statutory warranty. The guarantee applies only to material and producon errors. Intenso International GmbH is not liable for the loss of data. The free-of-charge guarantee relates to the repair or exchange of faulty parts. You are responsible for the safe elimination of your data which is not carried out by us. The sales receipt must be retained for the determination of the guarantee period. Please understand that we cannot provide a guarantee service in the case of, e.g.: Non-observance of the Operang Instrucons Abusive or improper treatment, installaon or use Damages, scratches or wear Arbitrary modicaons, opening the housing, intervenons or repairs Damage through other devices, force majeur or transport Guarantee conditions: In the case of a complaint, please proceed as follows:

1. Only returns with sales receipt and full accessories will be accepted.

2. Furthermore, an RMA number is absolute precondion for returns. You can request this

RMA number via the homepage, by email or via the service hotline. It must be aached clearly visible on the parcel.

3. Please pack the product including the sales receipt and complete accessories in a

transport-proof manner. The parcel must have sucient postage. Please send the parcel to the following address:
