TEJS 18 - Electric saw EINHELL - Free user manual and instructions

Product type	Cordless jigsaw
Brand	Einhell
Model	TEJS 18
Rated voltage	18 V DC
Stroke rate	0-2400 spm
Stroke height	25.4 mm
Cutting depth (wood)	80 mm
Cutting depth (plastic)	12 mm
Cutting depth (iron/aluminum)	10 mm
Miter cut	Up to 47° (left and right)
Weight	1.6 kg
Battery type	Li-ion, 18 V, 2.0 Ah, 5 cells
Charger	21 V DC, 3 A, mains 200-260 V~50-60 Hz
Sound pressure level	84 dB(A)
Sound power level	95 dB(A)
Vibration (wood)	7.417 m/s² (K=1.5 m/s²)
Vibration (sheet metal)	2.619 m/s² (K=1.5 m/s²)
Main features	Adjustable pendulum stroke (4 positions), LED light, tiltable foot, parallel stop, cut line guide, splinter guard, chip extraction adapter
Maintenance and cleaning	Clean with a damp cloth and mild soap; no parts requiring maintenance
Safety	Blade guard, switch lock, safety instructions included
Spare parts and repairability	Wear parts available (guide roller, battery, splinter guard, saw blades); repair via customer service
Warranty	24 months

Frequently Asked Questions - TEJS 18 EINHELL

How to change the saw blade on the TEJS 18?

First remove the battery. Set the pendulum stroke switch to position D. Remove the protective cover. Press the blade holder and insert the new blade until it stops, teeth facing forward. Release the holder and check that the blade is properly locked in the guide roller.

How to charge the battery?

Pull out the battery by pressing the release button. Connect the charger to mains (200-260 V~). Insert the battery into the charger. The green LED flashes during charging. When the LED goes out, the battery is charged to 85% (approx. 40 min for 2 Ah). Remove the battery for a full charge.

How to adjust the cutting angle?

Loosen the foot locking lever. Pull the foot slightly forward, then tilt it up to 47° left or right. For preset angles (0°, 15°, 30°, 45°), push the foot back until it clicks into place. Tighten the lever.

How to use the parallel stop?

Loosen the two fixing screws under the foot. Insert the parallel stop into the guides of the foot, guide bar facing down. Set the desired distance using the scale, then tighten the screws.

How to clean the jigsaw?

Remove the battery before any cleaning. Use a damp cloth with a little mild soap. Do not use harsh detergents. Avoid water entering the appliance interior. Clean the ventilation slots regularly.

What to do if the blade does not hold?

Check that the blade holder has returned to its initial position after insertion. Make sure the blade is pressed in until it stops and the teeth are facing forward. If the problem persists, replace the guide roller (wear part).

How to adjust the pendulum stroke?

Use the pendulum stroke switch (pos. 8). Position A: no oscillation (hard materials). B: small oscillation (plastic, wood). C: medium (wood). D: large oscillation (soft wood, ripping). Adjust according to the material.

What is the meaning of the LED indicators on the charger?

Red LED off, green flashing: ready. Red on, green off: fast charging. Both off: charged to 85%. Red flashing, green off: slow charging (deep discharge or abnormal temperature). Both flashing: battery defective. Both on: thermal disturbance.

How to perform a plunge cut?

Drill a 10 mm hole in the area to be cut. Insert the saw blade into the hole, then turn on the tool and guide the blade along the cut line.

What accessories are included with the TEJS 18?

The delivery includes: cordless jigsaw, a parallel stop, a chip extraction adapter, a cut line guide, a splinter guard, a charger, a Li-ion battery, the user manual, and safety instructions.

USER MANUAL TEJS 18 EINHELL

1. Safety regulations
2. Layout and items supplied
3. Proper use
4. Technical data
5. Before starting the equipment
6. Operation
7. Cleaning, maintenance and ordering of spare parts
8. Disposal and recycling
9. Storage
10. Charger indicator

GB

Danger! - Read the operating instructions to reduce the risk of inquiry

Caution! Wear ear-muffs. The impact of noise can cause damage to hearing.

Caution! Wear a breathing mask. Dust which is injurious to health can be generated when working on wood and other materials. Never use the device to work on any materials containing asbestos!

Caution! Wear safety goggles. Sparks generated during working or splinters, chips and dust emitted by the device can cause loss of sight.

Store the battery only in dry rooms with an ambient temperature of +10^ to +40^ . Place only charged batteries in storage (charged at least 40% ).

Safety class II

For use in dry rooms only.

GB

Danger!

When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating instructions and safety regulations with due care. Keep this manual in a safe place, so that the information is available at all times. If you give the equipment to any other person, hand over these operating instructions and safety regulations as well. We cannot accept any liability for damage or accidents which arise due to a failure to follow these instructions and the safety instructions.

1. Safety regulations

The corresponding safety information can be found in the enclosed booklet.

Danger!

Read all safety regulations and instructions. Any errors made in following the safety regulations and instructions may result in an electric shock, fire and/or serious injury.

Keep all safety regulations and instructions in a safe place for future use.

2. Layout and items supplied

2.1 Layout (Fig. 1,2,3)

1. Handle
2. Locking button for On/Off switch
3. On/Off switch
4. LED lamp
5. Adapter for dust extraction system
6. Line guide
7. Adjustable soleplate
8. Selector switch for pendulum action
9. Dial scale for soleplate
10. Guide roller
11. Parallel stop
12. Saw blade
13. Locking screws for parallel stop
14. Blade holder
15. Safety guard
16. Locking lever for soleplate
17. Splinter guard

2.2 Items supplied

Please check that the article is complete as specified in the scope of delivery. If parts are missing, please contact our service center or the sales outlet where you made your purchase at the latest within 5 working days after purchasing

the product and upon presentation of a valid bill of purchase. Also, refer to the warranty table in the service information at the end of the operating instructions.

• Open the packaging and take out the equipment with care.
• Remove the packaging material and any packaging and/or transportation braces (if available).
  Check to see if all items are supplied.
• Inspect the equipment and accessories for transport damage.
  If possible, please keep the packaging until the end of the guarantee period.

Danger!

The equipment and packaging material are not toys. Do not let children play with plastic bags, foils or small parts. There is a danger of swallowing or suffocating!

• Cordless jigsaw
• Parallel stop
• Adapter for dust extraction system
  Line guide
  Splinter guard
  Battery charger
  Battery
  Original operating instructions
  Safetyinstructions

3. Proper use

The jigsaw is designed for sawing wood, metals, non-ferrous metals and plastics using the appropriate saw blade.

The equipment is to be used only for its prescribed purpose. Any other use is deemed to be a case of misuse. The user / operator and not the manufacturer will be liable for any damage or injuries of any kind caused as a result of this.

Please note that our equipment has not been designed for use in commercial, trade or industrial applications. Our warranty will be voided if the machine is used in commercial, trade or industrial businesses or for equivalent purposes.

GB

4. Technical data

Motor power supply: 18 V DC

Stroke speed: 0 - 2,400 min

Stroke height: 25.4 mm

Cutting depth, wood: 80 mm

Cutting depth, plastic: 12 mm

Cutting depth, iron/aluminium: 10 mm

Miter cut: up to 47^ (left and right)

Battery charger output voltage: 21 V d. c.

Battery charger output current: 3 A

Mains voltage for charger: .. 200-260V~ 50-60 Hz

Battery type: Lithium-ion

Number of battery cells: 5

Battery capacitance: 2.0 Ah

Weight: 1.6 kg

Danger!

Sound and vibration

Sound and vibration values were measured in accordance with EN 60745.

L_DA sound pressure level 84 dB(A)

K uncertainty 3 dB

Lsound power level 95 dB(A)

K_WA uncertainty 3 dB

Wear ear-muff s.

The impact of noise can cause damage to hearing.

Total vibration values (vector sum of three directions) determined in accordance with EN 60745.

Sawing particleboard

Vibration emission value a_h = 7.417 m/s^2

K uncertainty = 1.5m / s^2

Sawing sheet metal

Vibration emission value a_h = 2.619 m/s^2

K uncertainty = 1.5 m/s^2

The specified vibration value was established in accordance with a standardized testing method. It may change according to how the electric equipment is used and may exceed the specified value in exceptional circumstances.

The specified vibration value can be used to compare the equipment with other electric power tools.

The specified vibration value can be used for initial assessment of a harmful effect.

Keep the noise emissions and vibrations to a minimum.

Only use appliances which are in perfect working order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
- Have the appliance serviced whenever necessary.
- Switch the appliance off when it is not in use.
Wear protective gloves.

Caution!

Residual risks

Even if you use this electric power tool in accordance with instructions, certain residual risks cannot be rules out. The following hazards may arise in connection with the equipment's construction and layout:

1. Lung damage if no suitable protective dust mask is used.
2. Damage to hearing if no suitable ear protection is used.
3. Health damage caused by hand-arm vibrations if the equipment is used over a prolonged period or is not properly guided and maintained.

5. Before starting the equipment

Warning!

Always remove the battery pack before making adjustments to the equipment.

5.1 Safety guard (Fig. 2/Item 15)

The safety guard (15) protects the user from accidentally touching the saw blade (12) but still gives you an unobstructed view of the cutting area.
The safety guard (15) must always be fitted and in position before starting any sawing work.
The safety guard (15) can be pulled up as shown in Fig. 2.

GB

5.2 Changing the saw blade (Fig. 3/Item 12) Warning!

Remove the battery pack before you fit or replace a saw blade.

• You can fit or replace saw blades without using any other tools.
• Set the selector switch for pendulum action (8) to position D (see Fig. 14).
  The teeth of the saw blade are very sharp!
• Remove the safety guard (15).
• Press the blade holder (14) and insert the saw blade (12) into the blade holder (14) as far as the stop (Fig. 3). The teeth on the saw blade must be pointing forwards.
• Allow the blade holder (14) to slide back to starting position. The saw blade (12) must sit in the guide roller (10).
• Check that the saw blade (12) is securely mounted in the blade holder.
  To remove the saw blade, follow the instructions above in reverse order.

5.3 Installing the parallel stop (Fig. 4/Item 11)

The parallel stop (11) enables you to saw parallel cuts.
- Undo the two locking screws (13) on the soleplate (7).
Now slide the parallel stop (11) into the guides on the soleplate (7). You can fit the parallel stop (11) on either the left or right of the equipment.
- The guide strip must always face downwards. Set the required distance using the measurement scale on the parallel stop (11) and tighten the locking screws (13) again.

5.4 Setting the soleplate for miter cuts (Fig. 5)

• Undo the locking lever (16) on the soleplate.
  Pull the soleplate (7) slightly forward. The soleplate can now be swiveled a maximum 47^ to the left and right.
  If the soleplate (7) is pushed back to the rear again it will only function in the locking positions at 0^ , 15^ , 30^ and 45^ , which are marked on the graduated scale for the soleplate (9). Move the soleplate into the required position and refasten the locking lever (16).
  However, the soleplate (7) is also easily set to another angle. To do so, slide the soleplate (7) forwards, set the desired angle and refasten the locking lever (16).

Note! For miter cuts you must remove the locking screws for the parallel stop (13) and the splinter guard (17).

5.5 Adapter for dust extraction system (Fig. 6/Item 5)

• Connect your jigsaw to a vacuum cleaner using the adaptor for dust extraction (5). This will ensure optimum dust extraction from the workpiece. The benefits are that you will protect both the equipment and your own health. Your work area will also be cleaner and safer.
• Dust created when working may be dangerous. Refer to the section entitled "Safety information".
• Fit the adapter (5) as shown in Fig. 6. The adapter (5) must audibly engage to ensure that it is secure in the soleplate (7). The adapter for chip extraction (5) cannot be used for miter cuts.
• Fit the vacuum tube of the vacuum cleaner onto the adaptor opening (5). Check that the connections are air-tight.

5.6 Line guide (Fig. 7-9/Item 6)

Using the line guide (6) you can carry out exact cuts following cutting lines marked on the workpiece. Fit the line guide by mounting it on the top of the soleplate (7) and letting it lock in place at the bottom, as shown in Fig. 7. Use the mark (a) for the 0^ angle setting (Fig. 8) and the mark (b) for the 45^ angle setting (Fig. 9). See point 5.4 for information about the angle setting. Important! Carry out a trial cuts in a piece of waste wood.

5.7 Splinter guard (Fig. 10/Item 17)

The splinter guard ensures that the material you want to cut does not splinter or crack during sawing. Insert it into the soleplate from underneath as shown in Fig. 10.

Note! The splinter guard can be used only for 0^ cuts and must be removed for miter cuts up to 47^ !

5.8 Charging the Li battery pack (Fig. 11-12)

1. Remove the battery pack (d) from the handle, pressing the pushlock button (c) downwards to do so.
2. Check that your mains voltage is the same as that marked on the rating plate of the battery charger. Insert the power plug of the charger (e) into the mains socket outlet. The green LED will then begin to f1 ash.
3. Push the battery pack onto the battery charger.

GB

In section 10 (Charger indicator) you will find a table with an explanation of the LED indicator on the charger.

If the battery pack fails to charge, check for the following:

• voltage at the power socket
  whether there is good contact at the charging contacts of the charging unit

If the battery pack still fails to charge, send

the charger and charging adapter
and the battery pack

to our customer service center.

5.9 Battery capacity indicator (Fig. 11/Item f)

Press the button for the battery capacity indicator (g). The battery capacity indicator (f) shows the charge status of the battery using 3 LEDs.

All 3 LEDs are lit:

The battery is fully charged.

2 or 1 LED(s) are lit:

The battery has an adequate remaining charge.

1 LED blinks:

The battery is empty, recharge the battery.

All LEDs blink:

The battery pack has undergone exhaustive discharge and is defective. Do not use or charge a defective battery pack!

6. Operation

6.1 On/Off switch (Fig. 13/Item 3)

To switch on:

Press the locking button (2) and the On/Off switch (3).

Infinitely variable stroke speed control is possible with the On/Off switch (3). The further you push the switch, the higher the stroke speed.

To switch off :

Release the locking button (2) and the On/Off switch (3).

6.2 Setting the pendulum action (Fig. 14/Item 8)

The strength of the pendulum action of the saw blade (12) can be adjusted using the selector switch for pendulum action (8).

You can adjust the cutting speed, cutting performance and appearance of the cut to the workpiece you want to saw.

Set the selector switch for pendulum action (8) to one of the following positions:

Position A = no pendulum action

Material: Rubber, ceramic, aluminium, steel

Please note: For fine and clean cuts, thin materials (e.g. sheet steel) and hard materials.

Position B = small pendulum action

Material: Plastic, wood, aluminium

Please note: For hard materials.

Position C = medium pendulum action

Material: Wood

Position D = large pendulum action

Material: Wood

Please note: For soft materials and sawing along the grain

The best combination of speed and pendulum

action depends on the material you want to saw.

We recommend you to make a trial cut on a waste piece in order to check the ideal settings.

6.3 Making cuts

Caution!

Make sure that the On/Off switch (3) is not depressed. Only then should you connect the battery pack to the equipment.
- Do not switch on the jigsaw until you have fitted a saw blade.
Use only saw blades that are in perfect condition. Replace blunt, bent or cracked saw blades immediately.
- Place the saw foot flat on the workpiece you want to saw. Switch on the jigsaw.
- Allow the saw blade to accelerate until it reaches full speed. Then slowly move the saw blade along the cutting line. Exert only gentle pressure on the saw blade as you do so.
- When cutting metal, apply a suitable coolant along the line you want to cut.

GB

6.4 Sawing out sections (Fig. 15)

Drill a 10mm hole in the section you want to saw out. Insert the saw blade into this hole and start to saw out the required section.

6.5 Making parallel cuts (Fig. 16)

• Mount the parallel stop and adjust as required (see section 5.3).
  Observe the instructions in section 6.3.
  Cut as shown in Fig. 16.

6.6 Miter cuts (Fig. 9)

• Set the angle on the soleplate (see section 5.4).
  Observe the instructions in section 6.3.
  Cut as shown in Fig. 9.

6.7 LED lamp (Fig. 1/Item 4)

The LED lamp (4) can be used in poor lighting conditions to additionally illuminate the cutting position. The LED light (4) will come on automatically as soon as you press the On/Off switch (3).

7. Cleaning, maintenance and ordering of spare parts

Danger!

Always remove the battery pack before making adjustments to the equipment.

7.1 Cleaning

• Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the equipment with a clean cloth or blow it with compressed air at low pressure.
  We recommend that you clean the device immediately each time you have finished using it.
  Clean the equipment regularly with a moist cloth and some soft soap. Do not use cleaning agents or solvents; these could attack the plastic parts of the equipment. Ensure that no water can seep into the device. The ingress of water into an electric tool increases the risk of an electric shock.

7.2 Maintenance

There are no parts inside the equipment which require additional maintenance.

7.3 Ordering replacement parts:

Please quote the following data when ordering replacement parts:

Type of machine
Article number of the machine
- Identification number of the machine

• Replacement part number of the part required For our latest prices and information please go to www.isc-gmbh.info

8. Disposal and recycling

The equipment is supplied in packaging to prevent it from being damaged in transit. The raw materials in this packaging can be reused or recycled. The equipment and its accessories are made of various types of material, such as metal and plastic. Never place defective equipment in your household refuse. The equipment should be taken to a suitable collection center for proper disposal. If you do not know the whereabouts of such a collection point, you should ask in your local council offices.

9. Storage

Store the equipment and accessories in a dark and dry place at above freezing temperature. The ideal storage temperature is between 5 and 30

°C. Store the electric tool in its original packaging.

10. Charger indicator

Indicator status		Explanations and actions
Red LED Green LED
Off	Flashing	Ready for use The charger is connected to the mains and is ready for use; there is no battery pack in the charger
On Off Charging		The charger is charging the battery pack in quick charge mode.
Off On The battery is 85% charged and ready for use. (Charging time for 1.5 Ah battery: 30 min) (Charging time for 2.0 Ah battery: 40 min) (Charging time for 3.0 Ah battery: 60 min) (Charging time for 4.0 Ah battery: 80 min) (Charging time for 5.2 Ah battery: 130 min) The unit then changes over to gentle charging mode until the battery is fully charged. (Total charging time for 1.5 Ah battery: approx. 40 min) (Total charging time for 2.0 Ah battery: approx. 50 min) (Total charging time for 3.0 Ah battery: approx. 75 min) (Total charging time for 4.0 Ah battery: approx. 100 min) (Total charging time for 5.2 Ah battery: approx. 140 min) Action: Take the battery pack out of the charger. Disconnect the charger from the mains supply.
Flashing Off	Adapted charging	The charger is in gentle charging mode. For safety reasons the charging is performed less quickly and takes more than 1 hour. The reasons can be: - The battery pack has not been used for a very long time or an already fl at battery was further discharged (exhaustive discharge). - The battery pack temperature is outside the ideal range (between 25°C and 45°C). Action: Wait for the charging to be completed; you can still continue to charge the battery pack.
Flashing Flashing Fault		Charging is no longer possible. The battery pack is defective. Action: Never charge a defective battery pack. Take the battery pack out of the charger.
On On Temperature fault		The battery pack is too hot (e.g. due to direct sunshine) or too cold (below 0°C). Action: Remove the battery pack and keep it at room temperature (approx. 20°C) for one day.

GB

For EU countries only

Never place any electric power tools in your household refuse.

To comply with European Directive 2012/19/EC concerning old electric and electronic equipment and its implementation in national laws, old electric power tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g. by taking to a recycling depot.

Recycling alternative to the return request:

As an alternative to returning the equipment to the manufacturer, the owner of the electrical equipment must make sure that the equipment is properly disposed of if he no longer wants to keep the equipment. The old equipment can be returned to a suitable collection point that will dispose of the equipment in accordance with the national recycling and waste disposal regulations. This does not apply to any accessories or aids without electrical components supplied with the old equipment.

The reprinting or reproduction by any other means, in whole or in part, of documentation and papers accompanying products is permitted only with the express consent of the iSC GmbH.

Subject to technical changes

This consignment contains lithium-ion batteries.

In accordance with special provision 188 this consignment is not subject to the ADR regulations. Handle with care. Danger of ignition in case of damage to the consignment package. If the consignment package is damaged: Check and if necessary repackage. For further information contact: 0049 1807 10 20 20 66 (fixed network 14 ct/min, mobile phone max. 42 ct/min) Outside Germany charges will apply instead for a regular call to a landline number in Germany.

GB

Service information

We have competent service partners in all countries named on the guarantee certificate whose contact details can also be found on the guarantee certificate. These partners will help you with all service requests such as repairs, spare and wearing part orders or the purchase of consumables.

Please note that the following parts of this product are subject to normal or natural wear and that the following parts are therefore also required for use as consumables.

Category Example
Wear parts* Guide roller, Battery, Splinter guard
Consumables* Saw blade
Missing parts

• Not necessarily included in the scope of delivery!

In the effect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Please ensure that you provide a precise description of the problem and answer the following questions in all cases:

Did the equipment work at all or was it defective from the beginning?
- Did you notice anything (symptom or defect) prior to the failure?
What malfunction does the equipment have in your opinion (main symptom)?

Describe this malfunction.

GB

Warranty certificate

Dear Customer,

All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card. You can also contact us by telephone using the service number shown. Please note the following terms under which guarantee claims can be made:

1. These guarantee terms apply to consumers only, i.e. natural persons intending to use this product neither for their commercial activities nor for any other self-employed activities. These warranty terms regulate additional warranty services, which the manufacturer mentioned below promises to buyers of its new products in addition to their statutory rights of guarantee. Your statutory guarantee claims are not affected by this guarantee. Our guarantee is free of charge to you.
2. The warranty services cover only defects due to material or manufacturing faults on a product which you have bought from the manufacturer mentioned below and are limited to either the rectification of said defects on the product or the replacement of the product, whichever we prefer. Please note that our devices are not designed for use in commercial, trade or professional applications. A guarantee contract will not be created if the device has been used by commercial, trade or industrial business or has been exposed to similar stresses during the guarantee period.

3. The following are not covered by our guarantee:

4. Damage to the device caused by a failure to follow the assembly instructions or due to incorrect installation, a failure to follow the operating instructions (for example connecting it to an incorrect mains voltage or current type) or a failure to follow the maintenance and safety instructions or by exposing the device to abnormal environmental conditions or by lack of care and maintenance.

5. Damage to the device caused by abuse or incorrect use (for example overloading the device or the use or unapproved tools or accessories), ingress of foreign bodies into the device (such as sand, stones or dust, transport damage), the use of force or damage caused by external forces (for example by dropping it).

6. Damage to the device or parts of the device caused by normal or natural wear or tear or by normal use of the device.

7. The guarantee is valid for a period of 24 months starting from the purchase date of the device. Guarantee claims should be submitted before the end of the guarantee period within two weeks of the defect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains applicable to the device even if repairs are carried out or parts are replaced. In such cases, the work performed or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active for the work performed or parts fitted. This also applies if an on-site service is used.

8. To make a claim under the guarantee, please register the defective device at: www.isc-gmbh.info. Please keep your bill of purchase or other proof of purchase for the new device. Devices that are returned without proof of purchase or without a rating plate shall not be covered by the guarantee, because appropriate identification will not be possible. If the defect is covered by our guarantee, then the item in question will either be repaired immediately and returned to you or we will send you a new replacement.

Of course, we are also happy offer a chargeable repair service for any defects which are not covered by the scope of this guarantee or for units which are no longer covered. To take advantage of this service, please send the device to our service address.

Also refer to the restrictions of this warranty concerning wear parts, consumables and missing parts as set out in the service information in these operating instructions.

F

Sommaire

Chere cliente, cher client,

Material: plast, tra, aluminium

Obs! For hards material

Position C = Medelstark pendelmörse

Material: tra

Position D = Kraftig pendelrörese Material: trä

Voeding motor: 18 V DC

6.4 Recortar areas (Fig.15)

Evaakrih h avakkawon avi ia iotpoi

O iokntnc nnc nkeptiknc uokveutn untx nnc entpohc va oubaleo t wotn avakkwn oepintwnonouevvuxieva xnpouonoei ouokeun H nlaoukeun npotei va napaxwnel o kevtpo n eitpocns nkektkwovukewu mTv evvoia twv evikwv vowy avakkwn kai diaxepionc anoBantw. Dev uupneiaapavovta ta tumata uawekuvkai ta bonentka otoixia xwpi nkeptikac efaptnhata.

H avatunwnn nooiaaonnte aannc npoohns avanapayyn ntc teknpiowns n aaawv
deltaoyntikw vou avadepovtal ota npoiovta, akoun kai anoanaatika, enitpenetai mvo e
pntn ouykataeon tnsc GmbH.

Me eiuulaaen Teyivkowpontonnoeaw

GR

Evnpwon yia to epbic

6.7 Lampa LED (Fig.1/Poz.4)

Lampa LED (4) face posibila iluminarea suplementarà a locului de tāiere. Lampa LED
(4) se aprinde automat de indata ce actionati intrerupatorul de pornire/oprise (3).

7. Curatirea, intretnerea si comanda pieselor de schimb

Pericol!

Inaintea tuturor lucrarilor de curatire scoateti stecherul din przya.

7.1 Curatarea

Stimata clienta, stimate client,

produsele noastre sunt supuse unui control de calitate riguros. Daca totusi vredata acest aparat nu va functiona ireprosabil, ne pare foarte rau si va rugam sa va adresati centrului notreu service, la adresa indica tla finalul acestui certificat de garantie. Bineinteles ca va stam si la Telefon cu placere la disposiztie, la numeroile de service mentionate. Pencru revendicare apretiilor de garantie trebuie tinut cont de urmatoarele:

GB explains the following conformity according to EU directives and norms for the following product

□90/396/EC_2009/142/EC

89/686/EC_96/58/EC

2011/65/EU

2006/42/EC

Annex IV

Notified Body.

Notified Body No.: Dr. N

Reg.No.

2000/14/EC_2005/88/EC

Annex V

Annex VI

Noise: measured LPA = dB (A); guaranteed LPA = dB (A)

P = KW; L/0 = cm

Notified Body:

2004/26/EC

Emission No.:

Standard references: EN 60745-1; EN 60745-2-11; EN 62233; EN 60335-1; EN 60335-2-29; EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3

Subject to change without notice

Archive-File/Record: NAPR013792

Documents registrar: Riedel Georg

Wiesenweg 22, D-94405 Landau/Isar

EH 02/2016 (01)
