USER MANUAL TH1001 LAICA

Please read the instructions and warnings given in this handbook carefully before use, and always keep it in a safe place. Your new forehead thermometer detects body temperature in an absolutely precise and painless way. It is ideal to carry out measurements on babies, even while they are sleeping. The new infrared measurement technology offers a greater reliability and above all a longer life of the instrument. It is equipped with a wide LCD display for an easy reading. It has also an acoustic signal for completed measurement of the body temperature and of automatic switching-off after one minute of inactivity, which allows to extend the duration of the batteries. It is really easy to be used and allows the measurement of body and room temperature. It measures temperature in Celsius (°C) and Fahrenheit (°F) degrees. It stores in memory the last 25 measurements performed to evaluate eventual variations. NB: the temperature shown on the display is equal to the oral temperature, i.e. temperature measured on the forehead is translated as if it were measured in the mouth. Laica S.p.A. - Viale del Lavoro, 10 - Fraz. Ponte - 36021 Barbarano Vicentino (VI) - ITALY Fax: [phone]Made in China GENERAL WARNINGS

1) Self-measuring means control, it does not mean diagnosis or

treatment. Any unusual levels should always be discussed with your doctor. Under no circumstances must you change the dose of medicines prescribed by your Doctor.

2) The forehead thermometer is a very sensitive instrument.

Please handle it with care and avoid knocks. Do not press, bend, drop or break the thermometer into small pieces.

3) Keep it out of the reach of children.

4) The thermometer must not be exposed to extreme temperatures,

direct sunlight or sources of heat. It must be kept in a cool, dry and clean place.

5) Do not touch the probe with your fingers.

Do not dismantle the thermometer.

6) Do not immerse the thermometer in water or other liquids.

7) The forehead thermometer must not be used for rectal, oral or

armpit temperature reading.

8) The precision of the measurement can be jeopardized by: great

perspiration of the forehead, use of vasoconstrictive drugs and skin irritations.

9) Clean the temple where the probe will lean before performing

10) Measure the temperature far from direct sunlight and wind.

11) This thermometer has to be used to measure temperature on

forehead (with skin contact) as shown on the cover page.

A high temperature should be considered a symptom and not an illness.

Usually it is the sign that our organism is fighting against an infection. In fact, it represents a defensive reaction of our organism that is characterised by an increase in body temperature above 37°C and by an increase in heartbeat and breathing frequency. The normal temperature inside our organism is around 37.5°C, which is the value read with the rectal method, the temperature in the mouth is lower by about 0.5°C (37°C), while that under the armpit is lower by 1°C (36.5°C). Therefore it is very important that the temperature is correctly measured using the most effective method, and preferably not in those moments when body temperature could be higher (on waking, after meals). The temperature of a healthy person is also affected by the following factors:

• Theperson’sindividuallevel(individualmetabolism).

• Age(bodytemperatureishigherinbabiesandsmallchildrenandfallswith increasing age. Greater temperature fluctuations occur in children faster and more often.).

• Precedingphysicalactivity.

• Phaseofthemenstrualcycle. You should remember that skin temperature is easily affected by the room temperature; in fact, taking the temperature under the armpit is much less reliable with respect to oral and rectal readings. However, the temperature that is read on the forehead is extremely reliable and close to the real body temperature, as just a few mm from the skin on the forehead the temporal artery passes which carries the blood to the brain. This means that your new infrared forehead thermometer measures the temperature of the blood in the artery that passes underneath the skin. This is a highly appreciated method as it is very simple, precise and reliable. The graph below shows a list of the average "normal" temperatures. Please remember, that the thermometer must be in the room where the temperatures is to be taken at least half an hour beforehand, while the person must be present at least 10 minutes beforehand. However, we recommend that you learn to recognise your normal body temperature when you are well, to correctly interpret the different readings.

MEASURING METHOD NORMAL AVERAGE

ARMPIT 36.5°C ORAL 37°C RECTAL 37.5°C EAR 37°C These different thermometers are suitable for measuring the temperature in different parts of the body: forehead thermometer: measurement only on the forehead, ear thermometer: measurement only in the ear, rod thermometer: rectal (conventionally in the back passage), axillary (under the arm) or buccal measurement (inside the cheek) and under the tongue (sublingual). The temperature varies depending on the part of the body where it is measured. Instructions and guarantee

The variation can be between 0.2 - 1° C. Temperatures measured with different thermometers cannot be compared with one another. Tell your doctor or take into account when diagnosing yourself what thermometer you used in what part of the body to measure the temperature.

INSERTING/REPLACING THE BATTERY

The battery has to be urgently replaced when on the display the symbol of "discharged battery" appears.Before replacing the battery, switch off the thermometer to avoid damaging the mechanism.

1) extract the screw from the cover of the battery compartment.

2) open the cover and remove the battery

3) insert the new battery and place the positive pole upwards.

4) place the cover back on the battery compartment.

5) screw the screw in the cover.

Extract the batteries and dispose them as special waste at the specific collection points forecast for recycling. For more information about the disposal of run down batteries, please contact either the store where the device containing the batteries was purchased, or the Municipality, or the waste disposal local service. Caution: For greater safety, children younger than 12 years shouldnot remove the batteries.

1) Make sure that the probe is clean and integral.

2) Clean the temple where the probe will lean.

3) Switch on the thermometer, by pressing the key “ON/MEM”.

On the display appear all the function symbols (self-test); after few seconds, the display shows the message “HEAD-°C” and emits two beeps. At this point, the thermometer is ready for use.

4) Lean the probe on the right or left temple; press the key SCAN and keep it

pressed, then slowly move the probe around the temple. The thermometer emits beeps indicating that the measurement is taking place.

5) A longer and more intense acoustic signal indicates that the measurement

has ended (Time necessary to perform the measurement ranges from 5 to 30 second according to the temperature of the person). Should the temperature exceed 37.5°C, the thermometer emits a long beep followed by other three shorter beeps.

6) Release the key SCAN and then detach the probe from the temple; read the

measured value on the display Important: the temperature shown on the display is equal to the oral temperature, i.e. temperature measured on the forehead is translated as if it were measured in the mouth.

7) The device switches off automatically after 1 minute, if it is not used.

MEASUREMENT OF THE ROOM TEMPERATURE ( ) This thermometer allows the measurement of the room temperature.

1) Switch on the thermometer, by pressing the key “ON/MEM”. On the display

appear all the function symbols (self-test); after few seconds, the display shows the message “HEAD-°C” and emits two beeps.

2) Keep the key “ON/MEM” pressed and then press the key SCAN.

3) If you wish to measure the temperature on a precise point, press the key

SCAN. The thermometer measures the temperature in 0.6 seconds. If the SCAN key is kept pressed, temperature is updated continuously.

4) The device switches off automatically after 1 minute, if it is not used.

When it is switched on again, the display shows the forehead temperature measurement function (HEAD). CELSIUS/FAHRENHEIT This thermometer can measure temperature both in Celsius and Fahrenheit degrees. Each time you wish to change the measurement unit, proceed as follows:

1) With switched off thermometer, keep the key SCAN pressed without

releasing it for some seconds, and then press contemporaneously the key ON/MEM until the displays shows °F (or °C).

2) The thermometer emits two beeps; at this point, release the key SCAN and

the key ON/MEM. Now the measurement unit has been changed. Proceed with the measurement according to paragraph “INSTRUCTIONS FOR A CORRECT USE”. MEMORY FUNCTION This device stores in memory the last 25 measurements performed to evaluate eventual variations. The measurements are stored automatically after that the thermometer has switched off. Only forehead temperatures (HEAD) included between 22°C and 42.2°C (71.6°F and 108.0 °F) are stored. After the first 25 measurements, the oldest data are erased automatically. To call up saved measurements, switch on the thermometer, and press the key ON/MEM (Every time the key is pressed, saved data are scrolled). On the upper part of the display appears the symbol “M” and before each stored data appears the corresponding number (1= most recent measurement - 25 oldest measurement). The stored measurements are displayed for about 1 minute. After about 1 minute from releasing the ON/MEM key, the device switches off automatically.

CLEANING AND MAINTENANCE

Before and/or after each use, clean the probe of the thermometer with a soft cotton cloth moistened with water or alcohol to assure accurate measurements and to avoid microbial contaminations. The probe is the most delicate part of the thermometer; pay utmost care during the cleaning. Let the probe dry completely for about 30 minutes. The thermometer body has to be cleaned with a soft and dry cloth. THE BODY OF THE THERMOMETER HAS NOT TO BE WASHED WITH WATER. Absolutely neither use abrasive products, nor plunge the thermometer in water or other liquids. Store the thermometer in a dry and clean place away from direct sunlight. Instructions and guarantee

TROUBLE SHOOTING Drawing 1 Problem: The “HEAD” writing blinks: the mechanism is adjusting itself. Solution: Await some seconds until the “HEAD” message stops to blink. Drawing 2 Problem: Discharged battery Solution: Replace the battery Drawing 3 Problem: The thermometer detects rapid room temperature changes. Solution: It is necessary to consider that the thermometer has to be in the room where the measurement is performed about half an hour before performing the measurement, while the person has to be in the room at least 10 minutes before. (Room temperature has to range between +10°C and +40°C / between 50°F and 104°F) Drawing 4 Problem: Room temperature is not included between +10°C and +40°C / between 50°F and 104°F. Solution: It is necessary to consider that the thermometer has to be in the room where the measurement is performed about half an hour before performing the measurement, while the person has to be in the room at least 10 minutes before. (Room temperature has to range between +10°C and +40°C / between 50°F and 104°F) Drawing 5 Problem: Error 5~9, the device does not work correctly. Solution: Remove the battery, await 1 minute and then place it again in the proper compartment. Should the error persist, contact your dealer. Drawing 6 Problem: Temperature exceeds 42.2 2°C - 108°F. Solution: Verify the integrity of the probe and perform a new measurement. Drawing 7 Problem: Temperature is lower than 22°C - 71.6°F. Solution: Verify that the probe is clean and perform a new measurement. Drawing 8 Problem: The device blocks on self-test. Solution: Replace the battery TECHNICAL DATA Caution: check the instructions for use BF Type device Battery: 1 x CR2032LI Display: liquid crystals Switching-off: automatic, after one minute, if not used Measuring range: -22°C and 80°C (-7.6°F and 176.0°F) Resolution: 0.1°C Operation conditions: 10°C to 40°C

Storage conditions: 10°C to 50°C Tolerance: less than 22°C; +/- 2.0°C From 22°C to 42.2°C;+/-0.3°C More than 42.2°C; +/-2.0°C DISPOSAL PROCEDURE (DIR. 2002/96/EC - WEEE) The symbol on the bottom of the device indicates the separated collection of electric and electronic equipment. At the end of life of the device, do not dispose it as mixed solid municipal waste, but dispose it referring to a specific collection centre located in your area or returning it to the distributor, when buying a new device of the same type to be used with the same functions. This procedure of separated collection of electric and electronic devices is carried out forecasting a European environmental policy aiming at safeguarding, protecting and improving environment quality, as well as avoiding potential effects on human health due to the presence of hazardous substances in such equipment or to an improper use of the same or of parts of the same. Caution! The wrong disposal of electric and electronic equipment may involve sanctions. WARRANTY This equipment is covered by a 2-year warranty elapsing from the purchase date, which has to be proven by means of the stamp or signature of the dealer and by the fiscal payment receipt that shall be kept enclosed to this document. This warranty period complies with the laws in force (Italian legislative decree No. 24 dated Feb. 02, 2002 and following “Consumers’ Act” Italian legislative decree No. 206 dated Sep. 03, 2005) and applies only in case the consumer is a private entity. Laica products are designed for domestic use; therefore, their use in public businesses is forbidden. The warranty covers only production defects and is void, if the damage is caused by accidental events, wrong use, negligence or improper use of the product. Use the supplied accessories only; the use of other accessories may lead to warranty voidness. Do not open the equipment for any reason whatsoever; in case of opening or tampering of the equipment, warranty decays definitively. Warranty does not apply to parts subject to tear and wear along the use, as well as to batteries, when they are standard supplied. Warranty decays after 2 years from the purchase date. In this case, technical service interventions will be carried out against payment. Information on technical service interventions, under warranty terms or against payment, may be requested by writing at [e-mail]. Nothing shall be owed for the repairing or replacement of products covered by the warranty terms. In case of faults, refer to a dealer; DO NOT send anything directly to LAICA. All interventions covered by warranty (including product replacement or the replacement of any of its parts) shall not be meant to extend the duration of the original warranty period of the replaced product. The manufacturer cannot be made liable for any damages that may be caused, directly or indirectly, to people, things and pets resulting from the inobservance of the provisions contained in the suitable user manual, especially with reference to the warnings related to installation, use and maintenance of the equipment. Being constantly involved in improving its own products, Laica reserves the right to modify its product, totally or partially, with reference to any production need, without that this involves any responsibility whatsoever by Laica or its dealers. Instructions and guarantee
