USER MANUAL TH3002Y LAICA

THERMOMETRE NUMERIQUE POUR ENFANTSYour new digital thermometer thanks to its pacifier sensor detects the body temperature of your baby in an absolute precise and painless way. It is equipped with LCD-display for an easy reading as well as with an acoustic signal for ended measurement. It measures the body temperature in about 3 minutes. It stores the last temperature measured to assess future changes. It is very easy to use and it is possible to use the protection cover to avoid the risk of breaks and to keep it cleaner. It has a washable silicone pacifier as well as an automatic switching-off function. Produced using atoxic materials. Laica S.p.A. - Viale del Lavoro, 10 - Fraz. Ponte 36021 Barbarano Vicentino (VI) - ITALY Fax: [phone] Made in China Before use it is important to read the instructions and warnings contained in this booklet carefully and thoroughly, as well as to preserve the same carefully. GENERAL WARNINGS

1) This digital thermometer can be used by babies under the age of 4.

2) Do not use the digital thermometer as a common pacifier.

3) Never leave the device work unattended and do not allow the device to be used

by babies, invalid or disabled people; keep the product out of their reach. This device is not a toy!

4) This device has to be destined exclusively to the use for which it was developed

and in the way described in the instructions for use. Any other use shall be considered improper and therefore dangerous. The manufacturer cannot be made liable for any damages resulting from improper use or misuse.

5) This device has always to be used under the surveillance of an

6) Before use, make sure that the device is integral and does not show any visible

damages. In case of doubt, do not use the device and refer to the own dealer.

7) Before each use, verify the integrity of the thermometer by slightly pulling a part

of the silicone pacifier. Do not use the thermometer, if the pacifier is broken or damaged.

8) This digital thermometer for babies is designed to measure oral temperature.

Do not use it to measure front, underarm or rectal temperature.

9) This thermometer with pacifier was designed with a standard size to allow its

use for babies of different ages. Before using the thermometer for the first time, make sure it is not too big for your baby in order to avoid any risk of suffocation.

10) In case of fault and/or malfunction, switch off the device immediately, without

tampering it. For any repairs always refer to your dealer.

11) This thermometer is a sensitive instrument. Handle it with care and do not

expose it to mechanical bumps. Do not press or bend it, let it fall or break it up: some components may be dangerous if ingested. In this case, immediately seek medical advice.

12) Do not expose the thermometer to extreme temperatures and to direct sunlight.

Preserve in a dry and clean place.

13) Do not immerse the thermometer in water or other liquids.

14) Keep the device away from magnetic sources.

15) Do not let the unit fall or hit it.

Instructions and guarantee

DIGITAL THERMOMETER FOR BABIES16) The battery is not replaceable. Do not try to remove it. FEVER Fever has to be considered as a symptom and not as an illness: in general, it signals that the body is fighting against an infection. In fact, it represents a body defense reaction characterized by the increase in body temperature beyond 37°C and by an increase in the heart and respiration rate. Usually, temperature within our body is of about 37.5°C and this is in fact the value measured using the rectal method; temperature measured in the mouth is lower by about 0.5°C (37°C); while underarm temperature is lower by 1°C ( 36.5°C). Therefore, it can be inferred that the correct temperature measurement is extremely important and has to be carried out using solid means and possibly not in moments, in which body temperature may be physiologically higher (when waking up, after meals). In a healthy person, temperature is influenced by many factors:

• individualvalueofsuchperson(individualmetabolism);

• age(nurslingsandyoungbabiesshowahigherbodytemperature,which decreases with age. In case of babies, temperature changes more intensely, faster and more often);

• phaseofthemenstrualcycle. It is necessary to consider that skin temperature can be affected particularly by the room temperature. Underarm temperature measurement is, in fact, less reliable than oral and rectal measurement. Therefore, the measurement method of your new digital thermometer with pacifier is very appreciated since it is not invasive, as well as precise and reliable. It is necessary to consider that the thermometer shall be already in the room, in which the measurement will be carried out, half an hour before the actual measurement performance; the baby, instead, shall be staying in the room for at least 10 minutes before performing the measurement. The following table shows a list of the "usual" average temperature values: in any case, it is recommended to get used to recognize the common temperature of the own baby when he/she is healthy in order to be able to interpret the various detected values correctly.

MEASUREMENT METHOD COMMON AVERAGE

UNDERARM 36.5°C ORAL 37°C RECTAL 37.5°C EAR 37°C Every type of thermometer is suitable for the measurement of body temperature in a specific area of the body: front thermometer is suitable only for performing measurements on the front; ear thermometer is suitable only for performing measurements in the ear; quicksilver thermometer is suitable for performing the traditional rectal, underarm and oral measurement; the thermometer with pacifier is suitable only for oral measurement. According to the point, in which the measurement is carried out, a different

Instructions and guarantee

DIGITAL THERMOMETER FOR BABIEStemperature value is detected. The change can be equal to 0.2-1°C. It is not possible to compare the temperature detected using different measurement methods. Therefore, it is necessary to consider in case of self-diagnosis or when referring to the own physician, the type of thermometer used and the area of the body where the temperature was measured.

INSTRUCTIONS FOR A CORRECT USE

1) Remove the protective cover.

Before any use, disinfect the silicone pacifier using a cloth moistened with alcohol (70% isopropyl alcohol) or with hot water and some neutral detergent. Do not immerse the thermometer in water or any other liquids. Make sure that the silicone pacifier is integral.

2) Switch on the thermometer using the O/I key.

The device emits a short acoustic signal. On the display, all function symbols switch on just for few seconds. Then, the thermometer displays for some seconds the last measurement performed followed by L°C. When the symbol °C blinks, the device is ready for use.

3) Insert the thermometer in the mouth of the baby.

The display keeps displaying L°C till the mouth temperature is measured. It is suggested to let the thermometer in the mouth of the baby for about 6/8 minutes to allow the thermometer to measure temperature as precisely as possible. If temperature is lower than 32.0°C, the display shows “L” (Low); if the temperature exceeds 42.0°C, the display shows “H” (High). Caution! Drinking or eating hot or cold beverages and foodstuffs can alter the measurement results. It is suggested to measure the temperature after about 30 minutes from the last meal.

4) After having measured the temperature, the thermometer emits a long acoustic

signal. Switch off the thermometer by pressing the key O/I. The thermometer switches off automatically after 10 minutes.

5) It is suggested to repeat the measurement when the previous measurement is

interrupted. Should it not be possible to measure the temperature, the thermometer stores L°C. At the end of each measurement, clean the silicone pacifier and close the thermometer with its protective cover. Preserve the device in a fresh and dry place, out of reach of babies.

CLEANING AND MAINTENANCE

Cleaning operations have to be carried out before and after using the thermometer. Disinfect the silicone pacifier using a cloth moistened with alcohol (70% isopropyl alcohol) or with hot water and some neutral detergent. Dry using a soft cloth. Do not immerse the thermometer in water or other liquids. Never use chemical or abrasive products. The silicone pacifier is the most fragile part of the thermometer. Pay utmost care during its cleaning. Do not use alcohol to clean the display. Preserve the thermometer in a dry and clean place, away from direct sunlight. Do not sterilize or boil the thermometer.

Instructions and guarantee

Caution! Refer to the instructions for use Device of BF type Measurement range: from 32.0°C to 42.0°C Tolerance: +/- 0.1°C (from 35.5°C to 42.0°C) Display: LCD-display, 3.5 characters Battery autonomy: about 100 hours of continuous use Battery consumption: 0.15 mW Weight: 12 g Dimensions: 62x40x45 mm Operating conditions: from 10°C to 42°C Storage conditions: from 10°C to 50°C DISPOSAL PROCEDURE (DIR. 2002/96/EC - WEEE) The symbol on the bottom of the device indicates the separated collection of electric and electronic equipment. At the end of life of the device, do not dispose it as mixed solid municipal waste, but dispose it referring to a specific collection centre located in your area or returning it to the distributor, when buying a new device of the same type to be used with the same functions. This procedure of separated collection of electric and electronic devices is carried out forecasting a European environmental policy aiming at safeguarding, protecting and improving environment quality, as well as avoiding potential effects on human health due to the presence of hazardous substances in such equipment or to an improper use of the same or of parts of the same. Caution! The wrong disposal of electric and electronic equipment may involve sanctions. WARRANTY This equipment is covered by a 2-year warranty elapsing from the purchase date, which has to be proven by means of the stamp or signature of the dealer and by the fiscal payment receipt that shall be kept enclosed to this document. This warranty period complies with the laws in force (Italian legislative decree No. 24 dated Feb. 02, 2002 and following “Consumers’ Act” Italian legislative decree No. 206 dated Sep. 03, 2005) and applies only in case the consumer is a private entity. Laica products are designed for domestic use; therefore, their use in public businesses is forbidden. The warranty covers only production defects and is void, if the damage is caused by accidental events, wrong use, negligence or improper use of the product. Use the supplied accessories only; the use of other accessories may lead to warranty voidness. Do not open the equipment for any reason whatsoever; in case of opening or tampering of the equipment, warranty decays definitively. Warranty does not apply to parts subject to tear and wear along the use, as well as to batteries, when they are standard supplied. Warranty decays after 2 years from the purchase date. In this case, technical service interventions will be carried out against payment. Information on technical service interventions, under warranty terms or against payment, may be requested by writing at [e-mail]. Nothing shall be owed for the repairing or replacement of products covered by the warranty terms. In case of faults, refer to a dealer; DO NOT send anything directly to LAICA.All interventions covered by warranty (including product replacement or the replacement of any of its parts) shall not be meant to extend the duration of the original warranty period of the replaced product. The manufacturer cannot be made liable for any damages that may be caused, directly or indirectly, to people, things and pets resulting from the inobservance of the provisions contained in the suitable user manual, especially with reference to the warnings related to installation, use and maintenance of the equipment. Being constantly involved in improving its own products, Laica reserves the right to modify its product, totally or partially, with reference to any production need, without that this involves any responsibility whatsoever by Laica or its dealers. Instructions and guarantee
