Type	Car Dash Camera
Brand	Navitel
Model	MR450 GPS
Dimensions (approx.)	90 x 55 x 40 mm
Weight (approx.)	100 g
Power Supply	5V 1A via USB car charger
Built-in Battery	200 mAh Li-Polymer
Video Resolution	Full HD 1080p (1920x1080)
GPS	Built-in GPS module for speed and location logging
G-Sensor	Yes, for automatic event recording
Night Vision	Infrared LED support
Loop Recording	Yes, overwrites oldest files
Parking Mode	Motion detection and impact activation
Viewing Angle	130° wide angle
Memory Card Slot	Micro SD, up to 32 GB (Class 10)
Display	2.0 inch LCD screen
Mounting	Suction cup bracket
Maintenance	Clean lens with soft cloth; format SD card monthly
Safety	Do not mount in airbag deployment zone; secure cable routing
Spare Parts Included	Suction mount, car charger, USB cable
Operating Temperature	-10°C to 60°C

Frequently Asked Questions - MR450 GPS Navitel

How do I install the Navitel MR450 GPS camera?

Clean the windshield area, attach the suction mount, and press firmly. Insert a micro SD card (Class 10, up to 32 GB). Connect the car charger and route the cable neatly. Adjust the lens angle so the road is centered.

How do I format the SD card?

Go to Menu > Setup > Format. Confirm to erase all data. Format every month to maintain performance.

How do I enable parking mode?

Parking mode activates automatically when the car is off and the camera detects motion or impact. Ensure the camera is hardwired or has battery. You can adjust sensitivity in Menu > Parking Mode Settings.

How does the GPS function work?

The built-in GPS logs your route, speed, and location. Data is embedded in the video file. You can view it using compatible software on PC. Make sure the camera has a clear view of the sky for better satellite reception.

How can I view recorded videos?

You can watch videos directly on the camera's screen by pressing the Playback button. For detailed review, remove the SD card and insert it into a computer using an adapter. Use a video player that supports MP4 format.

How do I adjust the video resolution?

Go to Menu > Video Settings > Resolution. Options typically include 1080p, 720p, and 480p. Higher resolution uses more storage.

What should I do if the camera stops recording?

Check if the SD card is full or damaged. Try formatting the card. Ensure the charger is providing power and the cable is secure. If the issue persists, reset the camera by pressing the reset button with a pin.

How do I update the firmware?

Download the latest firmware from the Navitel support website. Copy the firmware file to the root of a formatted SD card. Insert the card into the camera while it is off. Turn on the camera; it will update automatically. Do not turn off during update.

How do I clean the camera lens?

Use a soft, dry microfiber cloth to gently wipe the lens. Avoid using liquids or abrasive materials. For stubborn dirt, slightly dampen the cloth with water.

What is the warranty period?

The Navitel MR450 GPS typically comes with a 1-year warranty. Check your purchase receipt for details. Warranty covers manufacturing defects but not physical damage or misuse.

USER MANUAL MR450 GPS Navitel

Exterior view of a Navitel autonomous driving mirror with dual lenses and a highway ahead (no text or symbols visible)

NAVITEL MR450 GPS

Digital Video Recorder

Úvod

Vážený zákazníku!

- Kamerasymbole [D],

Line drawing of a Navitel real Full HD video camera with no text or symbols on the device itself

1. Videokaabli port

Thank you for purchasing this NAVITEL® product.

NAVITEL MR450 GPS is a multifunctional high-definition DVR with many functions and features that are described in this User Manual. Please read the manual carefully before using the device and keep it for future reference.

Device layout

1. Display 12. MicroSD slot
2. Video resolution 13. Mini-USB port
3. Recording time 14. Rear camera port (AV-IN)
4. Date and time 15. Button Power
5. Info about battery 16. GPS-antenna
6. Button Menu 17. Speaker
7. Button Record 18. Clamps
8. Button Capture 19. Microphone

9. Button Microphone 20. Lens

10. Button Protect

11. Button Reset

Package contents

1. DVR NAVITEL MR450 GPS 6. Microfiber cloth
2. Car charger 12/24 V 7. User manual
3. Rear camera 8. Warranty card
4. Mini-USB -USB cable 9. Gift voucher
5. Video cable for the rear camera

Specifications

Main camera	Camera sensor SONY	307 (night vision)
	Video resolution 1920×1080, 30 fps
	Image resolution 2 MP
	View angle 160°
	Lens 4-layer glass
Rear camera	Camera sensor GC2053
	Video resolution	1920×1080
	Image resolution 2 MP
	View angle 100°
Processor MSTAR MSC8339
Display 5,5", IPS, 960×480, touchscreen
Recording format MOV
Image format JPG
MicroSD card capacity Max. 64 GB

USB mini-USB
AV-IN micro-jack (2.5 mm)
Battery Li-Pol, 400 mAh
Power 5 V, 2 A
Wi-Fi	Yes
GPS-alert	cameras / warnings / speed
Language	Czech, English, French, German, Hungarian, Italian, Polish, Romanian, Russian, Slovak, Spanish, Ukrainian

Installation

1. Put the microSD card into the DVR. Use a high-speed SD card (Class10 or above); capacity should be within 8-64 GB.

• To avoid malfunctions of the DVR and / or SD-card, don't insert and remove SD-card during DVR operation.

• Before using a microSD card, please format it inside the DVR to avoid data errors. For formatting the SD-card in Menu mode select Format SD-card and confirm it.

• Install DVR on your car mirror with the clamps. Do not use excessive force to avoid any damages.

• Connect the car charger to the cigarette lighter socket.
• Connect the car charger to the DVR input (mini-USB).
• Turn the power on; the DVR will start up and begin recording automatically.
• Adjust the DVR position.

Precautions

• The built-in battery is designed only for recording an emergency event in parking mode and turning off the device correctly when the power is turned off; for the full operation of the device in any mode, a constant power connection is required.
• Use only the original charger adapter. Using another adapter may negatively affect the device's battery. Use accessories only approved by manufacturer.
  • Permissible ambient temperature in operating mode: 0 to +35 °C. Storage temperature: +5 to +45 °C. Relative humidity: 5% to 90% without condensation (25 °C).
• Put the device away from fire sources to avoid explosion or fire.
• Do not expose the device to physical impacts.
• Avoid contacting the device with sources of electromagnetic radiation.
• Keep the lens clean. Do not use chemicals or detergents to clean the product; always turn off the device before cleaning.
• Strictly follow the laws and regulatory acts of the region where the device is used. This device can not be used for illegal purposes.
• Do not disassemble or repair device by yourself. In case of device failure, contact the service center.

Buttons

Button Functions
Power	Press shortly to turn the device on.Press and hold for 2 seconds to turn the device off.When the device is on press shortly to switch the screen on / off.
Microphone Press to	turn the microphone on / off.
Record	Press to start recording.Press again to stop recording.
Capture Press to take a picture.
Protect file	In Record mode (REC), press to protect / unprotect the current recording (protected file cannot be deleted or overwritten).
Menu Press to enter Menu mode.
Display Touch to switch between the main and rear camera views
Reset If the device is not responding, press to reset.

Note:
• The specifications may change due to upgrades.
- The built-in battery is designed only for recording an emergency event in parking mode and turning off the device correctly when the power is turned off; for the full operation of the device in any mode, a constant power connection is required.

For the convenience of working with the DVR's video files and embedded data, use Navitel DVR Player.

Download available at: www.navitel.cz/en/downloads/navitel-dvr-player

Device functions

Format SD-card	Formatting a microSD card in the DVR is necessary for the correct operation of the device. Before using a microSD card or in case of data error, please format the microSD card. For formatting the SD-card in Menu mode select Format SD-card and confirm it.
Record	Connect the device to an external power supply and it will start recording automatically. Press the Record button to stop recording. Press the Record button again to record another video. Each video will be saved automatically.
Capture Press the Capture button to take a photo (it will be saved automatically).
Video	Press Menu -> Playback -> Video File -> Back to enter Video mode. Select a file to play. In Video mode, press □/ ▶ to pause / unpause; press ◀/ ▶I to select the previous / next file.
Photo	Press Menu -> Playback -> Image File -> Back to enter Photo mode. Select a file to view. In Photo mode, press ◀/ ▶I to select the previous / next file.
Protect file	In Record mode (REC), press Protect file to protect / unprotect the current recording. In Playback mode select Protect, then Protect / Unprotect All. In Video / Photo mode select a file, then select Protect / Unprotect Current. Protected files cannot be deleted or overwritten.
Loop recording	This feature allows you to save a video as a set of files given in the duration menu. If the memory card runs out of space, the unprotected files will be overwritten in the order in which they were created.
Nigth mode Mode for record in low light.
Movie Off Time	The device turn off automatically after power cutoff. Time interval can be set in the Menu.
Record audio Record video with or without sound.
Power Off Choose the period of inactivity after which the device will turn off automatically.
Stamp This function adds date stamp to the record.
LCD OFF	The device can automatically shut off the screen to reduce power consumption. Time interval can be set in the LCD Power Save menu.
Protect Level If the vehicle is hit by something, the DVR will automatically lock the current video.
GPS location	Device supports built-in GPS chipset and GPS antenna, it can show longitude, latitude and other information on your current location. Press GPS Status to check GPS dates. Press On in the GPS Stamp menu to add GPS information to your files.
Rear camera mode	When supplying 12 V to the red wire, the rear camera mode is activated. Recommendations on how to connect this wire is given on the Rear Camera page of this manual.
Select a view mode	Pressing the top-right quarter of the screen switches the camera view modes: front only; only back; back over front (picture-in-picture).
Rear camera display mode	Choose the display mode of the rear camera-original, 180-degree rotation, horizontal reflection or vertical reflection.
USB-connection	When connecting the device to a PC using a USB cable, two connection options will appear:1) Mass Storage: play, copy and delete files.2) Record: standard mode.

Navitel DVR Center app installation

1. Download and install Navitel DVR Center to your cell phone or tablet, follow your mobile device instructions. You can download application by scan QR code in DVR's Menu (App QR Code) with your cell phone. Choose Wifi in Settings menu, press On.
2. Turn on a Wi-Fi in DVR's Menu (Wi-Fi) and in your mobile device settings.
3. Run the app. Choose your DVR in the list. The DVR's information is in DVR's Menu (Wi-Fi Navitel).
4. Connect your mobile device to the DVR through Wi-Fi. If necessary use the password. You can change it in DVR's Menu (Wi-Fi password).

5. Using the Navitel DVR Center you can:

6. update DVR's firmware;
   • control DVR functions in Settings menu: configure parking mode, impact sensor, video mode and format your SD card;

7. save, view, delete and send videos and photos as well as watch DVR's video in real time on the mobile device screen.

Digital Speed & Camera Info

The Digital speed feature is used to display time and vehicle speed calculated with the help of GPS signal [1]. Modes:

• Speed – current speed is displayed constantly [B],
• Speed + time - current speed [B] and time [C] are displayed.

The Camera info feature notifies the driver about cameras and warnings (hereinafter – Cameras) along the way. When you turn on the Camera info, the current speed and time are displayed. With the approach to the nearest camera the following information is displayed [2]:

• current speed [B],
• camera icon [D],
  • dynamic progress bar indicating approach to the nearest camera [E],
  • distance to the camera [F].

All information is displayed on a black screen.

In Record mode (REC), ●REC or ● are displayed [A].

If the vehicle is still, 0 is displayed.

If there is no GPS-signal, --- [3] is displayed.

Note. A weak GPS signal may be caused by bad weather conditions and other external factors. Please consult your vehicle speedometer.

[1]
[2] [3]

Rear camera

With the help of rear camera you can get a high-resolution image behind your car for safe parking or recording while driving. Modern double recording technology allows saving recordings both in front and behind the car for fixing any unforeseen situation.

Rear camera installation

1. Install the camera on the rear window inside the car and adjust the shooting angle.
2. Put the wire through the cabin.
3. Connect the wire to the rear camera port.

Note. It is strongly recommended that works on installing the camera and connecting +12 V should be done by qualified personnel with the necessary skills. Cable routing may require special tools or attachments. Make sure these works are safe.

Line drawing of a Navitel camera module with no visible text or symbols

1. Video cable port

NAVITEL s.r.o. hereby declares that the device NAVITEL MR450 GPS is compatible with the European directive RED 2014/53/EU. The full text of Declaration of conformity is available at the following internet address: www.navitel.cz/en/declaration_of_conformity/mr450gps
