USER MANUAL TUL 2 A1 TRONIC
Operating instructions
FR BE
STATION DE CHARGE USB
Mode d'emploi
CZ
USB NABIJECKA
Návod k obsluze
SK
USB NABIJAÇKA
Návod na obsluhu
DK
USB LADESTATION
GB/IE Operating instructions Page 1
Information about these instructions for use 2
Notes on trademarks 2
Intended use 2
Warnings and symbols used 2
Safety 3
Basic safety instructions 3
Description of components 4
Use 4
Check package contents 4
Fitting the stand 4
Using the USB charging station 5
Troubleshooting 6
Cleaning. 6
Storage when not in use 6
Disposal 6
Disposal of the device 6
Disposal of the packaging 7
Attachment 7
Technical data 7
Kompernass Handels GmbH warranty 8
Service 9
Importer 9
Introduction
Information about these instructions for use
Congratulations on the purchase of your new device. You have selected a high-quality device. The operating
instructions are part of this device. They contain important information about safety, usage and disposal. Before using the device, please familiarise yourself with all operating and safety instructions. The device may only be used as described and for the specified application areas. Hand over all documents when passing the device on to third parties.
Notes on trademarks
USBis a registered trademark of USB Implementers Forum, Inc.
The Tronic trademark and the trade name are the property of their respective owner.
All other names and products may be trademarks or registered trademarks of their respective owner.
Intended use
This USB charging station is an electronic device and is intended for charging and operating USB devices that are charged or operated via a USB port as standard. The integrated Power Delivery 3.0 technology on the two USB-C ports of the USB charging station allows for fast charging of compatible devices. Compatible connected devices are automatically detected and provided with the appropriate output voltage and output current from the USB charging station.
Any other use or use beyond that specified is considered improper use. The device is not intended for use in commercial or industrial environments.
The manufacturer accepts no responsibility for damage caused by failure to observe these instructions, improper use or repairs, unauthorised modifications or the use of unapproved replacement parts. The operator bears sole liability.
Warnings and symbols used
The following warnings and symbols are used in these operating instructions, on the packaging and on the device:
| WARNING! A warning with this symbol and the signal word "WARNING" indicates a potentially hazardous situation which could result in death or serious injury if not avoided. | |
| ATTENTION! A warning with this symbol and the signal word "ATTENTION" indicates a potential situation which could result in property damage if not avoided. | |
| Note: A note identifies additional information that facilitates the use of the device. | |
| Protection class II: Protection by double or reinforced insulation between live and touchable parts. | |
| Use the device indoors only. | |
| DC current/voltage | |
| AC current/voltage | |
| PB Power Delivery | Technology that enables reduced charging times for compatible devices. |
Safety
This section contains important safety instructions for handling the device. This device complies with the statutory safety regulations. Improper use may result in personal injury and property damage.
Basic safety instructions
WARNING! To ensure safe operation of the device, follow the safety guidelines set out below:
Check the device for visible external damage before use. Do not operate a device that has been damaged or dropped.
This device may be used by children aged 8 years old and above and by persons with limited physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the device safely and are aware of the potential risks. Do not allow children to use the device as a toy. Cleaning and user maintenance tasks may not be carried out by children unless they are supervised.
Do not allow children to play with the packaging material! Keep all packaging materials away from children.
The device is for indoor use only.
The power outlet must be easily accessible so that the device can be quickly disconnected in an emergency.
Connect the power plug only to correctly installed and earthed power outlets. Ensure that the rating for your local power supply corresponds with the details on the rating plate of the device.
The device draws current even if no other device is connected for charging. This means that the device should always be disconnected from the mains power supply when not in use. The device must be disconnected from the mains power supply for complete isolation, e.g. in emergency situations.
Never hold the power plug or the cable itself with wet hands, since this can cause a short-circuit or an electric shock.
When disconnecting the device from the mains power supply, always pull on the plug itself and never on the cable.
If the mains connection cable or connections are damaged, have them replaced by an authorised specialist or the Customer Service department.
- Protect the mains connection cable from hot surfaces and sharp edges. Ensure that the mains connection cable is not stretched tightly or kinked. Do not leave the mains connection cable hanging over edges (tripping hazard).
Always place the device on a stable and level surface. It can be damaged if dropped.
Do not place any objects on the device.
Do not place the device near heat sources such as radiators or other heat-generating devices.
Do not expose the device to direct sunlight or high temperatures. Otherwise, it may become overheated and irreparably damaged.
Ensure sufficient air circulation to prevent heat build-up. Never cover the device. There is a risk of fire!
- Do not operate the device close to naked flames (e.g. candles) and do not place burning candles on or next to the device. This serves to prevent fires.
The device is not designed for use in rooms with high temperature or humidity (e.g. bathrooms) or excessive dust. - Do not expose the device to water spray or dripping water, and do not place liquid-filled objects such as vases or open drink containers on or near the device.
Do not use the device immediately after moving it from a cold room to a warm room. Always allow the device to acclimatise before turning it on.
Never leave the device unattended during use.
In the event of malfunctions - and during thunderstorms - disconnect the plug from the power outlet.
Before cleaning, always disconnect the power plug from the power outlet. - Disconnect the cable from the device immediately if you notice unusual noises, a burnt smell or smoke. Have the device checked by a qualified specialist before using it again.
- Never open the device housing. There are no parts inside the device that require user maintenance. If the housing is opened, there is a risk of receiving a potentially fatal electric shock. All repairs to the device must be carried out by authorised specialist companies or by the Customer Service department. Improper repairs may put the user at risk. They will also invalidate any warranty claims.
Repairs to the device during the warranty period may only be carried out by a customer service department authorised by the manufacturer. Otherwise, no warranty claims will be held for any subsequent damages.
Defective components must always be replaced with original replacement parts. Compliance with the safety requirements can only be guaranteed by using these replacement parts.
Description of components (See fold-out page for illustrations)
USB port type C (PD MAX 18 W)
USB port type C (PD MAX 18 W)
USB ports type A (MAX 12 W)
4 Mains connection
5 Stand
6 Mains connection cable
Operating instructions (symbol)
Use
Check package contents
- USB charging hub
- Stand 5
- Mains connection cable 6
These operating instructions 7
Remove all components from the packaging. Remove all packaging material.
Note: Check the package for completeness and signs of visible damage. If the delivery is incomplete or damage has occurred as a result of defective packaging or during transport, contact the service hotline (see section Service).
Fitting the stand
1 ATTENTION! Damage to the device! Always use the USB charging station on the stand 5.
Place the USB charging station on the stand 5 from above until it snaps into the retaining tabs.
Using the USB charging station
1 ATTENTION! Damage to the device! Make sure that the power consumption of your device does not exceed 12.0 W when using one of the USB ports type A 3. When using one of the USB ports type C 1/2, the power consumption of your device must not exceed 18.0 W. The total power consumption of the devices connected to all USB ports 1/2/3, must not exceed 30.5 W. Refer to the operating instructions of your device for more information.
Note: If your device is equipped with USB Power Delivery 3.0 (PD), you can use a USB-C to USB-C cable (not included) to connect the USB-C input of your device with one of the USB ports type C 1/2 of the USB charging station for faster charging. Charging starts automatically as soon as the connection is made.
The table below shows the different output power levels depending on the USB ports used:
| Number of USB ports | USB port and output power |
| 1 USB port | USB-C: 18.0 W |
| USB-A: 12.0 W | |
| 2 USB ports | USB-C ①: 18.0 W + USB-C ②: 7.5 W, max. 25.5 W |
| USB-C ①: 18.0 W + USB-A: 12.0 W, max. 30.0 W | |
| USB-C ②: 18.0 W + USB-A: 5.0 W, max. 23.0 W | |
| 2× USB-A: max. 12.0 W (shared) |
| Number of USB ports | USB port and output power |
| 3 USB ports | USB-C ①: 18.0 W + USB-C ②: 7.5 W + USB-A: 5.0 W, max. 30.5 W |
| 3× USB-A: max. 12.0 W (shared) | |
| 4 USB ports | USB-C ①: 18.0 W + USB-C ②: 7.5 W + 2× USB-A: 5.0 W (shared), max. 30.5 W |
| USB-C ①: 18.0 W + 3× USB-A: 12.0 W (shared) | |
| USB-C ②: 18.0 W + 3× USB-A: 5.0 W (shared) | |
| 5 USB ports | USB-C ①: 18.0 W + USB-C ②: 7.5 W + 3× USB-A: 5.0 W (shared), max. 30.5 W |
Insert the connector plug of the mains connection cable 6 into the mains connection 4 of the USB charging station.
Plug the power plug of the mains connection cable 6 into a properly installed mains power outlet.
Connect your device to the USB charging station. Use the original USB cable supplied with your device to optimise the charging process.
If required, you can switch on your connected device and continue using it.
Note: Monitor the charging status on your connected device.
Disconnect your connected device from the USB charging station once the device has completed charging.
Disconnect the power plug from the power outlet if you no longer require the USB charging station.
Troubleshooting
Connected devices are not charged by the USB charging station.
Insert the power plug of the USB charging station into a properly installed power outlet.
Check your house fuses.
Check the USB cable connection between the connected devices and the USB charging station.
Check the charging connection of the connected devices for functionality.
Connected devices are only charged slowly by the USB charging station.
Only the USB ports type C 1/2 of the USB charging station have the USB Power Delivery 3.0 (PD) technology for faster charging.
Check whether the connected devices are compatible with USB Power Delivery 3.0 (PD).
Cleaning
WARNING! Risk of electric shock! Remove the power plug from the power outlet before starting to clean the device.
ATTENTION! Damage to the device! To avoid irreparable damage to the device, make sure that no moisture can get into it during cleaning.
Clean the surfaces of the device with a soft, dry cloth.
Use a lightly moistened cloth and a mild detergent to remove stubborn dirt residues.
Storage when not in use
If you decide not to use the device for a long period, disconnect it from the mains power supply and store it in a clean, dry place away from direct sunlight.
Disposal
Applies only to France:
The product, its packaging and the operating instructions are
recyclable. They are subject to an extended manufacturer responsibility and will be collected separately.
Disposal of the device
The adjacent symbol of a crossed-out wheelie bin means that this device is subject to Directive 2012/19/EU. This directive states that this device may not be disposed of in the normal
household waste at the end of its useful life, but should be handed in at specially set-up collection locations, recycling depots or disposal companies.
This disposal is free of charge for the user. Protect the environment and dispose of this device properly.
If your old device has stored any personal data, you are responsible for deleting it yourself before returning it.
Your local community or municipal authorities can provide information on how to dispose of the worn-out product.
Disposal of the packaging
The packaging materials have been selected for their environmental friendliness and ease of disposal and are therefore
recyclable. Dispose of packaging materials that are no longer needed in accordance with the applicable local regulations.
Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material components
for disposal, if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings:
1-7: plastics, 20-22: paper and cardboard, 80-98: composites.
Applies only to Spain:
The packaging contains paper and/or cardboard components.
The packaging contains plastic and/or metal components.
Attachment
Technical data
| Manufacturer | KOMPERNASS HANDELS GMBH, BURGSTRASSE 21, 44867 BOCHUM, GERMANY, Registered court: AG Bochum, Register number: HRB 4598 |
| Model designation | TUL 2 A1 |
| Input voltage | 100-240 V ~ |
| Input AC frequency 50/60 Hz | |
| Output voltage USB type A | 5.0 V = |
| Output current USB type A | 2.4 A (per port) |
| Output voltage USB type C (PD) | 5.0 V =, 9.0 V = or 12.0 V = |
| Output current USB type C (PD) | 3 A (for 5.0 V =) 2 A (for 9.0 V =) 1.5 A (for 12.0 V =) |
| Output power (when using one USB port) | 12.0 W (USB type A) 18.0 W (USB type C) |
| Output power (when using all five USB ports) | 30.5 W |
| Average efficiency in operation | 81.4% |
| Efficiency at low load (10%) | 72.7% |
| Power consumption at no load | 0.13 W |
| Power consumption 0.65 A | |
| Protection class | II / ☑ |
| Operating temperature | +10°C to +35°C |
| Storage temperature 0°C to +45°C | |
| Humidity (no condensation) | ≤75% |
| Dimensions (USB charging station) | approx. 8.8 × 6.4 × 3.0 cm |
| Weight (USB charging station) | approx. 175 g |
This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.
This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
Please have the till receipt and the item number (IAN) 456442_2404 available as proof of purchase.
You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com.
This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 456442_2404.
Service
GB Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
IE Servicelreland
Tel.: 1800 101010
E-Mail: kompernass@lidl.ie
IAN456442_2404
Importer
Please note that the following address is not the service address. Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Inhaltsverzeichnis
Einführung 12
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
DEUTSCHLAND
www.kompernass.com
Table des matieres
Introduction 22
Chere cliente, cher client,
Chere cliente, cher client,
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
ALLEMAGNE
www.kompernass.com
Inhoud
Inleiding 34
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
DUITSLAND
www.kompernass.com
Obsah
Uvod 44
Informace k tomo navodu k obsluze 4 4
Informace o ochrannych známkach 44
Pouzitivsouladusurcenim 44
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NEMECKO
www.kompernass.com
Spistresci
Wstep. 54
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NIEMCY
www.kompernass.com
Obsah
Uvod 64
Informacao o toto navode na obsluhu 64
Upozornenia tykajuce sa ochrannych znamok 64
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NEMECKO
www.kompernass.com
Indices
Introduccion 74
| Número de puertos USB | Puerto USB y potencia de salute |
| 1 puerto USB | USB-C: 18,0 W |
| USB-A: 12,0 W | |
| 2 puertos USB | USB-C ①: 18,0 W +USB-C ②: 7,5 W,max. 25,5 W |
| USB-C ①: 18,0 W +USB-A: 12,0 W,max. 30,0 W | |
| USB-C ②: 18,0 W +USB-A: 5,0 W,max. 23,0 W | |
| 2 puertos USB-A: máximo 12,0 W (partidos) | |
| 3 puertos USB | USB-C ①: 18,0 W +USB-C ②: 7,5 W +USB-A: 5,0 W,max. 30,5 W |
| 3 puertos USB-A:max. 12,0 W (partidos) | |
| 4 puertos USB | USB-C ①: 18,0 W +USB-C ②: 7,5 W +2 puertos USB-A: 5,0 W(repartidos), max. 30,5 W |
| USB-C ①: 18,0 W +3 puertos USB-A: 12,0 W(repartidos) | |
| USB-C ②: 18,0 W +3 puertos USB-A: 5,0 W(repartidos) | |
| 5 puertos USB | USB-C ①: 18,0 W +USB-C ②: 7,5 W +3 puertos USB-A: 5,0 W(repartidos), max. 30,5 W |
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
ALEMANIA
www.kompernass.com
Indholdsfortegnelse
Introduction 84
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
TYSKLAND
www.kompernass.com
Indice
Introduzione 94
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANIA
www.kompernass.com
Tartalomjegyzék
Bevezeto 104
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
NÉMETORSZÁG
www.kompernass.com
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Last Information Update · Stand der Informationen · Version des informations · Stand van de informatie · Stav informacioni · Stan informacioni · Stav informacioni · Estado de las informaciones · Tilstand af information · Versione delle informazioni Informacionk allasa: 07/2024 · Ident.-No.: TUL2A1-032024-3
