USER MANUAL PHKSAP 12 B2 PARKSIDE

Exterior view of a modern open-plan saw with visible blade and handle (no text or symbols)

12 V AKKU-HANDKREISSÄGE/12V CORDLESS CIRCULAR SAW/12 V SCIE CIRCULAIRE SANS FIL PHKSAP 12 B2

DE AT CH

12 V AKKU-HANDKREISSÄGE

Operation and safety notes

Translation of the original instructions

FR BE

12 V SCIE CIRCULAIRE SANS FIL

The battery pack may only be charged using chargers of the X 12V TEAM series. The battery pack has the following charging times depending on the charger:

NOTE: The actual charging time may be slightly different from the above stated depending on the ambient temperature and the condition of the battery pack. The information is subject to change without prior notice.

List of pictograms used ...... Page 30

Introduction Page 31

Intended use.... Page 31
Scope of delivery Page 31
Description of parts Page 32
Technical data. Page 32

Safety instructions ...... Page 34

General power tool safety warnings....Page 34
Safety instructions for all saws.... Page 37
Further safety instructions for all saws.... Page 37
Lower guard function Page 38
Additional safety warnings Page 38
Safety information for the saw blade .... Page 39
Vibration and noise reduction.... Page 39
Behaviour in emergency situations. Page 40
Residual risks Page 40
Original accessories/auxiliary equipment.... Page 40

Before first use.... Page 40

Unpacking the product.... Page 40
Accessories Page 40

Preparation.... Page 41

Inserting/removing the battery pack. Page 41
Checking the battery pack charge status. Page 41
Charging the battery pack Page 41
Checking the guard Page 42
Fitting/changing the saw blade 42
Attaching the rip fence Page 43
Connecting a dust extractor.... Page 43

Use Page 43

Switching on/off Page 43
Setting the cutting angle. Page 43
Setting the cutting depth Page 43
Overload warning ...... Page 44

Working instructions Page 44

Maintenance....Page 44
Storage Page 44
Transportation. Page 44
Replacement parts/Accessories. Page 44

Troubleshooting Page 45

Disposal Page 45

Warranty Page 46

Warranty claim procedure.... Page 46

Service Page 47

EU declaration of conformity.... Page 48

List of pictograms used
	Read the instruction manual.		Wear eye protection!
			Wear hearing protection!
	DANGER! - Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)		Wear a dust mask!
			Wear protective gloves!
	WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)		Overload warning indicator 2
			Charging level indicator 3
	CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)		Rotational direction arrow shown on saw blade 25 and guard 22
			No-load speed
	NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)		Alternating current/voltage
			Direct current/voltage
	Max. cutting depth at 0°.		Saw blade diameter
	Use the product in dry indoor spaces only.		Fuse
		min^-1	Revolutions per minute
	Protection class II (double insulation)		Protect the battery pack 8 from heat and continuous intense sunlight.
	Protect the battery pack 8 from fire.		Protect the battery pack 8 from water and moisture.
	CE mark indicates conformity with relevant EU directives applicable for this product.		Safety information Instructions for use

12V CORDLESS CIRCULAR SAW

● Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This cordless circular saw (hereinafter “product” or “power tool”) is suitable for plunge sawing with longitudinal and cross cuts into following firmly supported materials:

-Wood

-Plastic

-Lightweight building materials (e.g. plasterboard)

■ Sawing metal is not permitted.
A rip fence is included for parallel cuts.
■ Use the product in dry indoor spaces only.
■ Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage.

■ The manufacturer is not liable for any damages caused by improper use.
The operator or user of the product is responsible for any accidents or personal injury and/or material damage to third parties or their property.
■ The product is exclusively intended for domestic use.
■ The product is not intended for commercial use or for similar uses.
- Observe all applicable local safety regulations, standards and ordinances. The use of noise emitting power tools may be restricted to certain times by national or local regulations.

- Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

NOTE

▶ Battery pack and charger are not included.

1 12V Cordless circular saw 61 Rip fence
1 Adapter for dust extraction
1 Hex key (attached to the housing)
1 Saw blade (pre-assembled)
1 Storage case
1 User manual

• Description of parts

Before reading, unfold the pages containing the illustrations and familiarise yourself with all functions of the product.

Figure A:

1	Auxiliary handle
2	Overload warning indicator
3	Charge status indicator
4	Lock button
5	Switch trigger
6	Handle
7	Release button for battery pack
8	Battery pack*
9	Hex key
10	Cutting depth scale
11	Locking lever (cutting depth adjustment)
12	Spindle lock
13	LED work light
14	Rip fence
15	Wing screw (rip fence slot)
16	Base plate
17	Scale on the base plate
18	Wing screw (cutting angle adjustment)
19	Cutting angle scale

Figure B:

20	Chip ejector
21	Retraction lever (blade guard)
22	Guard
23	Clamping screw
24	Clamping flange
25	Saw blade
26	Rip fence slot

Figure C:

27	Adapter for dust extraction
28	High-speed charger*
29	Green LED
30	Red LED

Figure D:

24a	Inner clamping flange
Not illustrated:
31	Storage case

• Technical data

12V Cordless circular saw PHKSAP 12 B2
Model number: HG13148
Rated voltage: 12 V	---
No-load rotation speed n0: 3,600 min	-1
Max. cutting depth: At 0°: At 45°:	approx. 44 mm approx. 33 mm
Thread size: M6

Saw blade
Model number: HG13149
Outer ∅: 140 mm
Borehole ∅: 20 mm
Cutting width (teeth thickness): 1.6 mm
Number of teeth:	20
No-load rotation speed n0:	max. 7,000 min-1

Battery pack*	PAPK 12 A4
Model number: HG10031
Type:	Lithium-Ion
Rated voltage: 12 V	---
Capacity: 2.0 Ah

Charger*	PLGK 12 A3
Model number:
VDE plug:	HG10038
UK plug:	HG10038-BS
Input
Rated voltage: 220–240 V~,50–60 Hz
Rated power consumption: 50 W
Fuse (internal): 2 A/
Output
Rated voltage: 12 V	---
Rated current: 2.4 A
Charging time: approx. 60 min
Protection class:	II/□ (double insulation)

Recommended battery pack capacity (depending on the material)

Capacity Material
2.0 Ah	Soft material (e.g. pine, with thickness ≤10 mm)
4.0 Ah	Hard and thicker material
5.0 Ah

Recommended ambient temperature

While charging:	+4 °C to +40 °C
During operation:	+4 °C to +40 °C
During storage:	+20 °C to +26 °C

Noise emission value

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the product is typically as follows:

Sound pressure level L_pA : 82.4 dB
Uncertainty K_pA : 3.0 dB
Sound power level L_WA : 90.4 dB
Uncertainty K_WA : 3.0 dB

WARNING!

Wear hearing protection!

Total vibration value

Total vibration values (triaxial vector sum) determined in accordance with EN 62841:

Vibration – Main handle
Sawing in wood ( a_h,w ): 1.3	38 m/s ^2
Uncertainty K: 1.5 m/s	2
Vibration – Auxiliary handle
Sawing in wood ( a_h,w ): 2.8	61 m/s ^2
Uncertainty K: 1.5 m/s	2

NOTE

The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

WARNING!

The vibration and noise emissions during actual use of the product can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed.

WARNING!

Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the product is switched off and when it is running idle in addition to the trigger time).

Safety instructions

● General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of

drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools diligently. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Battery tool use and care

a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.

e) Do not use a battery pack for tool that is damaged or modified. Damaged or modified batteries exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above +130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of the fire.

CAUTION! RISK OF EXPLOSION! Never charge non-rechargeable batteries.

Protect the rechargeable battery from heat (for example, from continuous exposure to sunlight), fire, water and moisture. There is a risk of explosion.

Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should be only be performed by the manufactured or authorized service providers.

● Safety instructions for all saws

Cutting procedures

a)

DANGER: Keep hands away from cutting area and the blade. If both hands are holding the saw, they cannot be cut by the blade.

b) Do not reach underneath the workpiece. The guard cannot protect you from the blade below the workpiece.
c) Adjust the cutting depth to the thickness of the workpiece. Less than a full tooth of the blade teeth should be visible below the workpiece.
d) Never hold the workpiece in your hands or across your leg while cutting. Secure the workpiece to a stable platform. It is important to support the work properly to minimise body exposure, blade binding, or loss of control.
e) Hold the power tool by insulated gripping surfaces, when performing an operation where the cutting tool may contact hidden wiring. Contact with a “live” wire will also make exposed metal parts of the power tool “live” and could give the operator an electric shock.
f) When ripping, always use a rip fence or straight edge guide. This improves the accuracy of cut and reduces the chance of blade binding.
g) Always use blades with correct size and shape (diamond versus round) of arbour holes. Blades that do not match the mounting hardware of the saw will run off-centre, causing loss of control.

h) Never use damaged or incorrect blade washers or bolt. The blade washers and bolt were specially designed for your saw, for optimum performance and safety of operation.

● Further safety instructions for all saws

Kickback causes and related warnings

• Kickback is a sudden reaction to a pinched, jammed or misaligned saw blade, causing an uncontrolled saw to lift up and out of the workpiece toward the operator.
• When the blade is pinched or jammed tightly by the kerf closing down, the blade stalls and the motor reaction drives the unit rapidly back toward the operator.
  If the blade becomes twisted or misaligned in the cut, the teeth at the back edge of the blade can dig into the top surface of the wood causing the blade to climb out of the kerf and jump back toward the operator.

Kickback is the result of saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below.

a) Maintain a firm grip on the saw and position your arms to resist kickback forces. Position your body to either side of the blade, but not in line with the blade. Kickback could cause the saw to jump backwards, but kickback forces can be controlled by the operator, if proper precautions are taken.
b) When blade is binding, or when interrupting a cut for any reason, release the trigger and hold the saw motionless in the material until the blade comes to a complete stop. Never attempt to

remove the saw from the work or pull the saw backward while the blade is in motion or kickback may occur. Investigate and take corrective actions to eliminate the cause of blade binding.

c) When restarting a saw in the workpiece, centre the saw blade in the kerf so that the saw teeth are not engaged into the material. If a saw blade binds, it may walk up or kickback from the workpiece as the saw is restarted.
d) Support large panels to minimise the risk of blade pinching and kickback. Large panels tend to sag under their own weight. Supports must be placed under the panel on both sides, near the line of cut and near the edge of the panel.
e) Do not use dull or damaged blades. Unsharpened or improperly set blades produce narrow kerf causing excessive friction, blade binding and kickback.
f) Blade depth and bevel adjusting locking levers must be tight and secure before making the cut. If blade adjustment shifts while cutting, it may cause binding and kickback.
g) Use extra caution when sawing into existing walls or other blind areas. The protruding blade may cut objects that can cause kickback.

● Lower guard function

a) Check the lower guard for proper closing before each use. Do not operate the saw if the lower guard does not move freely and close instantly. Never clamp or tie the lower guard into the open position. If the saw is accidentally dropped, the lower guard may be bent. Raise the lower guard with the

retracting handle and make sure it moves freely and does not touch the blade or any other part, in all angles and depths of cut.

b) Check the operation of the lower guard spring. If the guard and the spring are not operating properly, they must be serviced before use. Lower guard may operate sluggishly due to damaged parts, gummy deposits, or a build-up of debris.
c) The lower guard may be retracted manually only for special cuts such as “plunge cuts” and “compound cuts”. Raise the lower guard by the retracting handle and as soon as the blade enters the material, the lower guard must be released. For all other sawing, the lower guard should operate automatically.
d) Always observe that the lower guard is covering the blade before placing the saw down on bench or floor. An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is in its path. Be aware of the time it takes for the blade to stop after switch is released.

● Additional safety warnings

a) Do not allow the ejected cutting chip come into contact with your hands. You may be injured or cut by high-speed saw chip.
b) Do not use the saw above the level of your head. Doing so will mean you have inadequate control of the power tool.
c) Do not use grinding discs with this tool. It will be broken easily and cause personal injury.
d) Use suitable detectors to determine if utility lines are hidden in the work area or call the local utility company for

assistance. Contact with electric lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes property damage or may cause an electric shock.

e) Do not modify and operate the power tool as stationary tool. It is not suitable for operation as a table saw.
f) Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure than by hand.
g) Do not use HSS (High Speed Steel) saw blades. Such saw blades can easily break and jam into wood during cutting works.
h) Do not saw any ferrous metals. Hot chips may ignite the plastic parts of the tool. Metal cutting dust goes into motor and electrical circuit will cause electric shock.

● Safety information for the saw blade

■ Use only saw blades with diameters corresponding to the label on the saw.
- When working with wood or materials that produce dust hazardous to health, the appliance must be connected to a suitable, tested extraction appliance.

■ Wear a dust mask when sawing wood.

■ Only use recommended saw blades.
■ Always wear ear muffs.
- Avoid overheating the sawtooth tips.
- When sawing plastic, avoid melting the plastic.
■ Use the correct saw blade according to the material to be sawn.
Use only saw blades specified by the manufacturer which, if intended for cutting wood or similar materials, comply with EN 847-1.

■ Tools may only be used by trained and experienced persons who are familiar with the use of tools.
■ Circular saw blades with torn bodies must be taken out of service (repair is not permitted).
The maximum speed indicated on the tool must not be exceeded. If specified, the speed range must be observed.

WARNING!

Wear protective gloves!

Wear breathing protection!

Wear safety goggles!

Wear hearing protection!

● Vibration and noise reduction

To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment.

Take the following points into account to minimise the vibration and noise exposure risks:

■ Only use the product as intended by its design and these instructions.
■ Ensure that the product is in good condition and well maintained.
■ Use correct accessory tools for the product and ensure they are in good condition.
- Keep tight grip on the handles/grip surface.

• Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate).
• Plan your work schedule to spread any high vibration tool use across a longer period of time.

● Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

■ Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
■ Switch the product off if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

- Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

■ Cutting injuries
■ Hearing damage if suitable ear protection is not worn
■ Health injuries resulting from the effect of vibration on the hands and arms in the event that the product is used over a longer period of time or is not used and maintained properly.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

● Original accessories/auxiliary equipment

■ Only use the accessories and additional equipment that are specified in the operating instructions and compatible with the product.

● Before first use

● Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

Accessories

To operate this product safely and correctly, accessories, i.e. tools and saw blades, are necessary.
- Accessories and saw blades are available through your authorised dealer. When buying always consider the technical requirements of this product (see “Technical data”).

If you are not certain, ask a qualified specialist and get advice from your trusted dealer.

● Preparation

- Inserting/removing the battery pack

CAUTION! Risk of injury!

When inserting/removing the battery pack, hold the product in such a way that you do not accidentally press the switch trigger or the lock button.

Inserting the battery pack:

1. Slide the battery pack 8 into the handle 6.
2. Ensure that the battery pack 8 clicks into place.

Removing the battery pack:

1. Press the release button 7 on the battery pack 8.
2. Pull the battery pack 8 off the handle 6.

- Checking the battery pack charge status

☐ Switch on the product to check the charge status of the battery pack 8 (see 'Switching on/off').
■ The charge status indica 3 lights up:

Colour Charge status

Red/orange/green Maximum

Red/orange Medium

Red Low

● Charging the battery pack

WARNING!

Observe the safety instructions and the instructions on charging and correct use given in the operating instructions for your XJME team series battery pack and charger.

A detailed description of the charging process and further information can be found in these separate user manuals.

⚠ NOTICE! Risk of damage to the battery pack!

Do not expose the battery pack to direct sunlight for long periods and do not place it on a radiator. Observe an ambient temperature of max. +40 °C.

NOTE

Charge the battery pa8 if its charge status is medium or low (see „Checking the battery pack charge status’).
You can charge the battery pa8k at any time without shortening its service life.
Interrupting the charging process will not damage the battery pack 8.
If the battery pa8 is still warm, allow it to cool down before charging.

The LEDs (gre29 and red 30) provide information on the status of the charger 28 and the battery pack 8:

LED Status
Red LED 30 lights up	Battery pack 8 charging
Green LED 29 lights up	Battery pack 8 fully charged
Green LED 29 and red LED 30 flash	Battery pack 8 defective
Red LED 30 flashes	Battery pack 8 too cold or too warm
Green LED 29 lights up (without battery pack 8)	Charger 28 ready

1. Insert the battery pack 8 into the charger 28.
2. Connect the mains plug of the charger 28 to a socket.
3. When the battery pack 8 is fully charged:

- Disconnect the mains plug of the charger 28 from the socket.

-Remove the battery pack 8 from the charger 28.

- Checking the guard

NOTE

The gua22 must be able to move without jamming and return to its original position automatically when the retraction lever 21 is released.

☐ Pull the retraction lever 21 back as far as it will go.

● Fitting/changing the saw blade

(Fig. D)

⚠ WARNING! Risk of injury!

▶ Switch off the product and remove the battery pack before carrying out any work.

NOTE

▶ Turn the saw bla25 slowly either in clockwise or anti-clockwise direction so that the spindle lock 12 can engage.
The inner clamping flan24a can be removed. Ensure correct alignment when reinserting the inner clamping flange.
The saw bla25 must be suitable for the speed of the product.
The arrow on the saw bla ^25 must match the direction of rotation arrow (direction of rotation, marked on the guard 22).

1. Press the spindle lock 12 until it engages. Continue to hold the spindle lock.
2. Use the hex key 9 to loosen the clamping screw 23 (anti-clockwise).
3. Remove the clamping screw 23 and the clamping flange 24 .
4. Pull the guard 22 back by using the retraction lever 21 . Hold the guard in this position.
5. Carefully remove the saw blade 25 from the bottom of the product.
6. Fit the new saw blade 25 in reverse order.
7. Press the spindle lock 12 until it engages. Continue to hold the spindle lock.
8. Use the hex key 9 to tighten the clamping screw 23 (clockwise).

- Attaching the rip fence

1. Loosen the wing screw 15.
2. Slide the rip fence 14 into the rip fence slot 26. The wing screw 15 must be able to grip the rip fence.
3. Set the desired width of the cut.
4. Tighten the wing screw 15 to secure the rip fence 14.

HINT: In order to obtain an accurate cutting width, after setting up the rip fence 14, process a trial cut to make a short cutting slot on the workpiece (see "Working instructions"). Measure the actual width obtained. If the measured width deviates from the desired cutting width, readjust the rip fence until you have reached the required cutting width.

- Connecting a dust extractor

NOTE

When sawing wood or other materials that create dusts that are hazardous to health, always connect the appliance to a suitable, certified suction appliance.

☐ Attach the adapter 27 to the chip ejector 20, depending on the diameter of your dust and chip extraction system (Fig. E).
□ Connect an approved dust and chip extraction device.

Use

- Switching on/off

Switching on:

1. Press and hold the lock button 4 to the left or right.
2. Press the switch trigger 5.
3. The LED work light 13 lights up.
4. The charge status indicator 3 lights up.

-Once the product has started up: Release the lock button 4.

Switching off:

☐ Release the switch trigger 5. After you have switched off the product, the LED work light 13 keeps lighting up for 10 seconds and then goes out.
- Setting the cutting angle (Fig. F)

NOTE

You can select the cutting angle using the cutting angle scale 19.
The right recess in the scale on the base plate 17 is for the cutting angle setting 0^ .
The left recess in the scale on the base plate 17 is for the cutting angle setting 45°.

1. Loosen the wing screw 18.
2. Set the desired angle on the cutting angle scale 19 using the upper edge of the metal marking.
3. Tighten the wing screw 18.

- Setting the cutting depth (Fig. G)

NOTE

▶ Select a cutting depth of approx. 3 mm more than the thickness of the material. This ensures that you achieve a clean cut.

1. Release the locking lever 11.
2. Set the desired cutting depth on the cutting depth scale 10 referring to the triangular reference mark on the metal guard.
3. Tighten the locking lever 11.

Overload warning

If the product is at risk of damage, the overload warning indicator 2 flashes 10 times.

The product switches off.

● Working instructions

NOTE

Saw forwards with moderate pressure - never backwards.

1. Hold the product with both hands: one hand on the handle 6 and the other hand on the auxiliary handle 1.
2. Place the product with the front of the base plate 16 against the edge of the workpiece.
3. Align the product using the rip fence 14 or by using a marked line.
4. Switch on the product (see "Switching on/off").
5. Slowly push the product forwards. The guard 22 opens automatically.

Maintenance

☐ The product is maintenance free.
Before each use: Check the saw blade 25 for obvious defects. Replace the saw blade, if it is blunt, bent, or damaged in any other way.
☐ Have any maintenance work on the saw blade 25 (e.g. repair or regrinding) carried out by a professional.

Storage

□ Always store the product and its accessories

-clean,
-dry,
-protected against dust,
-in the storage case31,
-out of the reach of children.

☐ The ideal long term storage (longer than 3 months) temperature is between +20 °C and +26 °C. Avoid extreme cold or heat during storage to ensure the output of the battery pack 8 is not adversely affected.
☐ Before storage: Remove the battery pack 8 from the product.

Transportation

□ Transport the product in its storage case 31.
□ Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles.
☐ Secure the product to prevent it from slipping or falling over.

● Replacement parts/Accessories

□ Customers can obtain compatible replacement parts and accessories via www.optimex-shop.com.
□ Have the order number ready for your order.
☐ You can only place orders online.

□ Contact the Lidl service hotline (see „Service“) for further information.

Part Order number
25 Saw blade	99948090201

● Troubleshooting

Problem Possible cause Solution
The product does not start.	The battery pack 8 is not inserted.	Insert the battery pack 8 (see “Inserting and removing the battery pack”).
	The battery pack 8 is discharged.	Charge the battery pack 8 (see “Charging the battery pack”).
	The switch trigger 5 is defective.	Contact our Service Centre (see “Service”).
	The motor is defective.
The product works with interruptions.	Internal loose contact Contact	our Service Centre (see “Service”).
	The switch trigger 5 is defective.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the

packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

The product and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

to protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Remove the batteries/battery pack from the product before disposal.

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 5 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 5 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 480902_2410) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

PDF ONLINE parkside-diy.com

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 480902_2410 takes you to the operating instructions for your item.

Service

Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

● EUdeclarationofconformity

EU DECLARATION OF CONFORMITY (No. 480902\_2410)

IAN: 480902_2410

Product identification:

"PARKSIDE" Cordless Circular Saw

Model Number: HG13148

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 62841-1:2015+AC:2015+A11:2022

EN 62841-2-5:2014

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

Directive 2011/65/EU

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 07.05.2025

Place Date

ppa. Budmei ppa. Jens Buchheim ppa. Dr. Thorsten Maier Authorised Signatory Authorised Signatory

EN

WAARSCHUWING! Verwondingsgevaar!

Two identical icons with Chinese characters and symbols, likely representing user accounts or system functions.
