USER MANUAL PDSA 20-Li C2 PARKSIDE

Operation and safety notes

Translation of the original instructions

FR BE

12 V/20 V PULVÉRISATEUR À PRESSION SANS FIL

GB/IE Operation and safety notes Page 33

List of pictograms used 34

Introduction 35

Intended use. Page 35
Scope of delivery. Page 35
Parts list . Page 35
Technical data. Page 36

General safety instructions. 39

General power tool safety warnings . Page 39
Sprayer safety warnings. Page 42
Battery charger safety warnings. Page 45
Residual risks. 46

First set-up of the product. 46

Unpacking the product. Page 46
Assembling the spray lance. 46
Assembling the carrying strap . 47
Filling the tank. Page 47
Inserting/removing the battery pack. Page 48

20 V battery pack - charging information. 48

Checking the battery pack charging level . Page 48
Charging the battery pack. Page 48

12 V battery pack - charging information. 49

Charging the battery pack. Page 49
Checking the battery charge level on the product . 50

Operation. 50

Switching the product on/off 50
Adjusting the nozzle. 50
Spraying. Page 51

Troubleshooting 51

Cleaning and maintenance. 52

Cleaning. Page 52
Maintenance . 53
Storage. Page 53
Transportation. Page 53

Disposal. 53

Warranty. 54

Warranty claim procedure.. Page 54

Service 55
EU declaration of conformity. 56

List of pictograms used
Read the instruction manual. Wear eye protection!
DANGER! This symbol in combination with the signal word “Danger” marks a high-risk hazard that if not prevented could result in death or serious injury.	Wear a dust mask!
	Wear protective gloves!
WARNING! This symbol in combination with the signal word “Warning” marks a medium-risk hazard that if not prevented could result in death or serious injury.	Wear protective clothing!
	Wear ear protection!
CAUTION! This symbol in combination with the signal word “Caution” marks a low-risk hazard that if not prevented could result in minor or moderate injury.	Keep bystanders away during spraying.
	Switch off the product and remove the battery pack 2134 before replacing attachments, cleaning and when not in use.
NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)	Direct current/voltage
CE mark indicates conformity with relevant EU directives applicable for this product.	Safety information Instructions for use

12V/20V CORDLESS PRESSURE SPRAYER

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

The product is used for spraying water in private applications such as gardens, houses or greenhouses.
The product is not suitable for the food sector.
More viscous flowing liquids cannot be sprayed.
This product is not suitable for commercial use. The warranty is void in the case of commercial use.
Improper use includes, in particular, the spraying of:

-Solvents
Liquids containing solvents
-Disinfectants
-Oils, greases
Lacquers, glazes
- Impregnating agents
Highly flammable liquids
Corrosive liquids such as acids or alkalis
-Pesticides

The user or operator is responsible for accidents causing injury to other people or damage to property.

The manufacturer is not liable for damages caused by unspecified use or incorrect operation.
Any other use that is not explicitly approved in this user manual may result in damage to the equipment and represent a serious danger to the user.

Scope of delivery

1 Cordless pressure sprayer
1 Spray lance
1 User manual

Battery pack and battery charger are not included in the scope of delivery.

Parts list

Before reading, unfold the pages containing the illustrations and familiarise yourself with all functions of the product.

(Fig. A)

1Pistol grip
Trigger lever
3Metal pipe
4 Hose
5Strap fastening
6 Holder for spray lance
7Spray lance
Spray nozzle
9 Carrying strap
10Container
10dFilter
11Screw cap
12Carrying handle
13 Clamping nut for hose connection
Spring housing
15 Battery cover
16Scale
17 On/off switch
18 Battery status display
19 Battery compartment
20Release button
21 Battery pack

• Battery pack and battery charger are not included in the scope of delivery.

(Fig. B)

22 Clamping nut for spray pipe
23Connecting pipe

(Fig. D)

24Length adjustment of carrying strap

(Fig. F)

25 Battery compartment 12 V
26 Battery compartment 20 V

(Fig. G)

27 Battery control button
(Fig. H)
Charging level LEDs (red/yellow/green)
29 button (charging level)

(Fig. 1)

30Mains cord with mains plug
31 Battery charger (rapid battery charger) *
32Charging control LED - Red
33Charging control LED - Green

(Fig. J)

34Battery pack *
35Release button
36 Battery charger (rapid battery charger) *
37 Charging control LED - Red
38 Charging control LED - Green
39Mains cord with mains plug

• Battery pack and battery charger are not included in the scope of delivery.

Technical data

Cordless pressure sprayer	PDSA 20-Li C2
Voltage:
-U1: 20 V	---
-U2: 12 V	---

Pump: - Maximum pressure p max: 1.5 bar -Flow capacity: 350 ml/min (water)
Range: 50–60 cm
Spray angle: 45°
Tank capacity/nominal volume: 5 L
Spray volume: 12 min continuous operation, at 5 L tank filling	continuous operation, at 5 L tank filling
Technical residue: <0.1 L
Mesh size of the filter: 1 × 1 mm
Weight (empty, without battery pack) m0:	1.8 kg
Weight (full, without battery pack):	6.8 kg
Runtime:	approx. 100 min (2.0 Ah)
Hose length:	1.2 m
Metal lance length:	60 cm
Protection type:	IPX1

Battery pack	PAP 20 B1 *
Type:	Lithium-Ion
Rated voltage:	20 V---max.
Capacity:	2.0 Ah
Energy value:	40 Wh
Number of cells:	5
Battery pack PAP 20	B3 *
Type: Lithium-ION
Rated voltage: 20 V	--- max.
Capacity: 4.0 Ah
Energy value: 80 Wh
Number of cells: 10

Battery pack PAPK	12 A4 *
Type: Lithium-lon
Rated voltage: 12 V	--- max.
Capacity: 2.0 Ah
Energy value: 24 Wh
Number of cells: 3

Battery pack PAPK	12 B4 *
Type: Lithium-ION
Rated voltage: 12 V	--- max.
Capacity: 4.0 Ah
Energy value: 48 Wh
Number of cells: 6

Rapid battery charger	PLG 20 C3 *
Input:
Rated voltage: 230-240 V~
Rated frequency: 50 Hz
Rated power: 120 W
Fuse (internal):	3.15 A/ T3.15A
Output:
Rated voltage: 21.5 V	---
Charging current: 4.5 A
Protection class:	II/□

• Battery pack and battery charger are not included in the scope of delivery.

Recommended ambient temperature

Maximum temperature total: +50 °C
While charging: +4 °C	to +40 °C
During operation:	+4 °C to +50 °C
During storage:	0 °C to +45 °C

Noise emission value

The measured values were determined in accordance with the standards and regulations stated in the declaration of conformity.

Sound pressure level LpA:	66.8 dB
Uncertainty KpA:	3 dB
Sound power level LWA:	74.8 dB
Uncertainty KWA:	3 dB

WARNING!

Wear ear protection!

Vibration emission value

Vibration total values (triaxial vector sum) determined according to EN 62841-1:

Vibration \( {a}_{h} \) :	<2.5 m/s2
Uncertainty K:	1.5 m/s2

NOTE

The vibration emission values and the noise emission values given in these instructions have been measured in accordance with a standardised test procedure and can be used for comparison of the power tool with another tool.

NOTE

The specified total vibration values and the noise emission values can also be used to make a provisional load estimate.

WARNING!

Depending on the manner in which the power tool is being used, and in particular the kind of workpiece being worked, the vibration and noise emission values can deviate from the values given in these instructions during actual use of the power tool.

WARNING!

Try to keep the vibration loads as low as possible. Measures to reduce the vibration load are, e.g. wearing gloves and limiting the working time. Wherein all states of operation must be included (e.g. times when the power tool is switched off and times where the power tool is switched on but running without load).

Charging times

The product is part of the X 20 V TEAM and X 12 V TEAM series from Parkside and can only be operated using batteries of the X 20 V TEAM and X 12 V TEAM series from Parkside. The batteries may only be charged using chargers of the X 20 V TEAM and X 12 V TEAM series from Parkside.

The batteries have the following charging times depending on the charger:

X 20 V TEAM ** PAP 20 B1 2 Ah	** PAP 20 B3 4 Ah
* PLG 20 A4/C1 (max. 2.4 A) 60 min 120 min
* PLG 20 C2 (max. 3.5 A) 45 min 80 min
* PLG 20 A3/C3 (max. 4.5 A) 35 min 60 min
* PDSLG 20 A1 (max. 4.5 A) 35 min 60 min
* Battery charger ** Battery pack

X 12 V TEAM ** PAPK 12 A3/A4 2 Ah	** PAPK 12 B3/B4 4 Ah	** PAPK 12 D1 5 Ah
* PLGK 12 A3 (max. 2.4 A) 60 min 120 min 150 min
* PLGK 12 B2 (max. 4.5 A) 30 min	60 min	80 min
* PDSLG 12 A1 (max. 4.5 A) 30 min 60 min 80 min
* PDSLG 12 A2 (max. 4.5 A) 30 min 60 min 80 min
* Battery charger ** Battery pack

General safety instructions

• General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

1) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

3) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

1) The mains plug of the power tool must fit into the socket. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
2) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
3) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
4) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.

5) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
6) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

1) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
2) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
3) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
4) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.

5) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
6) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
8) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

1) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
2) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
3) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

4) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
5) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
7) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
8) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Battery tool use and care

1) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.

2) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
3) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
4) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
5) Do not use a battery pack for tool that is damaged or modified. Damaged or modified batteries exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
6) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130^ may cause explosion.
7) Follow all charging instruction and do not charge the battery pack or tool outside the temperature range specified in the instruction. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of the fire.

Service

1) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
2) Never service damaged battery packs. Service of battery packs should be only be performed by the manufactured or authorized service providers.

- Sprayer safety warnings

The sprayer shall be used only with water.
- Keep the area clear of all bystanders, children and pets while spraying.
Risk of fire! Do not spray flammable liquids such as gasoline.
Risk of explosion! Do not place in direct sunlight.
Only use the parts supplied or approved by the manufacturer.
- Do not spray into wind, water or drinking water source.
Hold the spray lance away from the operator.
- Properly tighten the spray tank cover after pouring liquids into the spray tank.

Use only consumer-grade water-based chemicals.
- Do not use alkali self-heating or corrosive liquids with the product. These can corrode metal parts or weaken the tank and hose.
- Do not leave residue or spray material in the spray tank after using the product. Clean the product after each use.
- Do not add liquids with a temperature of more than 45^ C to avoid damaging the hose or spray tank.
Do not overfill the tank.
- Do not operate the product in narrow or enclosed spaces. Always spray in a well-ventilated area. Do not smoke, eat or drink while using the product.
Do not smoke in areas where the product is used.
Always wear appropriate personal protection equipment.
Do not discharge the spray materials directly against skin.

• Aim the nozzle directly at the plants or objects intend to spray.
  Ensure that the spray materials are directed at an area that will not be damaged by the spray materials.
  Electric shock hazard! Do not spray towards electric outlets.
  After every use, thoroughly wash your hands and any area where skin has been exposed to the spray materials.
  Remove the battery pack from the product before draining, cleaning or storing the product to avoid accidental starting.
  Thoroughly inspect both the inside and outside of the product and examine all components before each use.
  Check for cracked and deteriorated hoses, leaks, clogged nozzles, and missing or damaged parts.

A damaged hose or loose hose connection can result in accidental contact with the spray solution, causing serious injury or property damage.
If damaged, have the product repaired before use. Many accidents are caused by poorly maintained products.
- Do not lift or carry the product by the hose or shut-off valve. Carry the product by the handle and the shoulder strap only.
Never use the product in a room where there is a danger of explosion or in the vicinity of flammable liquids or gases.
- Do not immerse the product in water or other liquids. Do not place the product where it can fall or be pulled into a tub or sink.
Only operate the product when it is in an upright position.
- Do not operate the product with an empty spray tank.

It is necessary to provide the appropriate training in safe operation.
Do not use the product while tired, ill or under the influence of alcohol, drugs or medicaments.
Always carry out a visual inspection before using the product. Do not use the product if it is damaged. If the product is damaged, have it checked by qualified personnel.
Always check the product for leaks. If any are found, correct them before using the product.
When assembling or removing accessories, do not point them towards yourself or other persons.
The product must only be operated by 1 person at a time. Nobody else must be within a radius of 15 metres at the same time.
If there is no spray coming out from the nozzle or the spray amount is decreased, the hose and spray system may be blocked. Rinse

and clean all parts of the hose and spray system with clean water.

After the product has been stored for a long time (e.g. during winter), fill the spray tank with clean water. Carry out a test run to check if there are any leakages or cracks.
- Release the residual pressure in the spray tank after each use and especially before removing the spray tank cover. Do so by pressing the trigger.
- Do not modify the product under any circumstance. Modifications may result in serious injury.
All servicing and maintenance, other than the items listed in this instruction manual, should be performed by an authorised service centre.

Only use spare parts and accessories provided by the manufacturer. All other repairs shall only be carried out by an authorised service centre. Improper maintenance, use of non-conforming components and removal of safety devices can lead to a hazardous situation, such as death, life-threatening injuries and damage.

Pay attention to the volume application rate during operation.

Battery chargersafety warnings

This appliance can be used by children aged from 16 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

• Do not charge non-rechargeable batteries. Disregarding this instruction is hazardous.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

• Protect the electrical parts against moisture. Do not immerse such parts in water or other liquids to avoid electrical shock. Never hold the appliance under running water. Pay attention to the instructions provided for cleaning, maintenance and repair.

ATTENTION! This charger is only designed for charging the battery pack types:

Parkside 20 V battery pack
PAP 20 B1 2	Ah 5 cells
PAP 20 B3	4 Ah	10 cells
PAPK 12 A4	2 Ah 3 cells
PAPK 12 B4	4 Ah 6 cells

Customers can obtain compatible replacement batteries and chargers from the LIDL online shop www.lidl.de.

Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

Lung damage if a suitable protective mask is not worn.
- Contact with hazardous substances. Spray materials can be harmful if they are inhaled, swallowed or come into contact with skin or eyes. Follow the instructions and wear suitable protective equipment.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

- First set-up of the product

Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

- Assembling the spray lance

(Fig. B)

NOTICE!

Check the hose connections before operation. Any leaks must be repaired immediately.

NOTE

The spray lance can be inserted into the holder for transport or when not in use.

1. Insert the spray lance 7 into the connecting pipe 23 of the metal pipe 3.

2. Screw the spray lance 7 tight with the clamping nut 22.

Assembling the carrying strap

(Fig. D)

NOTE

The carrying strap can be hooked onto the sides of the container for fatigue-free work.
The product can be carried over the shoulder with the carrying strap or on the carrying handle.
For optimal wearing comfort: Keep the strap fastening 5 at hip level if you wear the carrying strap 9 over your shoulder.

1. Slide the openings of the carrying strap over the strap fastening 5 on both sides of the container 10.
2. Adjust the desired strap length: Use the length adjuster 24.

Filling the tank

(Fig. E)

WARNING!

Wear eye protection!

Wear a dust mask!

WARNING!

Take precautions against contact with and/or inhalation of hazardous substances.
Wear suitable personal protective equipment.

WARNING!

Do not fill the container10 with:
-Acidic, corrosive or flammable liquids.
Impregnating agents
-Disinfectants
-Varnishes
Glazes
Greases
Mineral oils
-Synthetically produced oils
Pesticides

NOTICE!

Do not exceed the maximum filling quantity of the container 10 that is shown on the scale 16.
The filter10q is pre-installed in the container 10.
Always use the filter to prevent large debris in the container.

NOTE

Fill the container 10 with water only (max. 5 litres).

1. Place the product on a level surface.
2. Open the container 10: Turn the screw cap 11 in anticlockwise direction.
3. Pour the liquid through the filter into the container 10. Pay attention to the scale 16 on the container.
4. Close the container [10]: Screw the screw cap [11] in clockwise direction with both hands. Check that the screw cap fits tightly.

- Inserting/removing the battery pack

(Fig. F, G)

WARNING!

Switch off the product and remove the battery pack [21] [34] before replacing attachments, cleaning and when not in use.

NOTE

The product can be operated either with X 20 V TEAM or X 12 V TEAM battery packs.

1. Fold up the battery cover 15.

2. There are 2 different battery compartments:

3. The upper battery compartment 25 is intended to be used with the 12V battery pack.

4. The lower battery compartment [26] is intended to be used with the 20 V battery pack.

3. Inserting the battery pack:

• 12 V: Insert the battery pack 34 fully into the upper battery compartment 25 until it clicks into place.
  -20 V: Insert the battery pack 21 fully into the lower battery compartment 26 until it clicks into place.

• Removing the battery pack: Press the release button 2035 on the battery pack 2134.Pull out the battery pack.

20 V battery pack - charging information

- Checking the battery pack charging level

(Fig. H)

Check battery pack charge level:

Press the button 29. The charging level LEDs 28 light up:

LED Charging level
Red/yellow/green Maxium
Red/yellow Medium
Red Low

- Charging the battery pack

(Fig.1)

NOTE

If the battery pack [21] is warm: Allow the battery to cool down completely before charging.
The battery pack 21 may be charged at any time without reducing the life.
Interrupting the charging process does not damage the battery pack [21].
Charge the battery pack21 before operation when it is at medium or low charging level.

1. The charging control LEDs (green 33 and red 32) indicate the status of the charger 31 and the battery pack 21:

LED Status
Red LED lights up	Battery pack charges
Green LED lights up	Battery pack fully charged
Green and red LED flashing	Battery pack defective
Red LED flashing Battery	Battery pack too cold or too warm
Green LED lights up (without battery pack)	Charger ready

1. Insert the battery pack 21 into the charger 31.
2. Connect the mains cord with mains plug 30 of the charger 31 to the mains socket.
3. When the battery pack 21 is fully charged: Remove the battery pack from the charger 31. Then disconnect the mains plug 30 of the charger from the mains socket.

12 V battery pack - charging information

(Fig. J)

- Charging the battery pack

WARNING!

Charge the battery pack34 in a dry room only. Prior to inserting the battery into the battery charger36, check that the outer surface of the battery pack is clean and dry. There is a risk of injury due to electric shock.

CAUTION!

Do not expose the battery pack [34] to extreme conditions such as heat or impact. Risk of injury from escaping electrolytic solution! After eye/skin contact, rinse the affected areas with water or a neutraliser and consult a doctor.

NOTE

The battery pack 34 only reaches its full capacity once it has been charged several times.
Charge the battery pack34 before using it for the first time.
Only use chargers from the X 12 V TEAM series to recharge the battery pack [34].
If a fully recharged battery pack [34] lasts for considerably shorter operating times, the battery pack is used up and needs to be replaced. Only use an original replacement battery pack from the X 12 V TEAM series.
Let the battery pack 34 cool down before charging.
The battery pack may be charged at any time without reducing the lifetime of the battery pack.
Interrupting the charging process does not damage the battery pack [34].

Charge the battery pack 34 before use when it is at medium or low charging level.
The charging control LEDs (green 38 and red 37) indicate the status of the battery charger 36 and the battery pack 34:

LED Status
Green LED lights up without battery inserted	Charger ready for use
Green LED lights up	Battery fully charged
Red LED lights up	Battery charging

1. Remove the battery pack 34 from the product.
2. Insert the battery pack 34 into the battery charger 36.
3. Connect the mains plug 39 to a socket-outlet.
4. When the battery pack 34 is fully charged: Remove the battery pack from the battery charger 36. Disconnect the mains plug 39 from the socket-outlet.

- Checking the battery charge level on the product

NOTE

The battery pack34 must be inserted in the product to check the charge level.
The charge level of the battery pack [34] is indicated by the battery status display [18] on the product.

Switch the product on.
The charge level of the battery pack 34 is indicated by illumination of the corresponding LED lights:

LED Status
red - yellow - green	Battery pack fully charged
red - yellow Battery pack half charged
red Battery pack needs to be charged

Operation

WARNING!

Wear eye protection!

Wear a dust mask!

WARNING!

Check the product for obvious defects (e.g. cracks) before each use. Check the proper functioning of the spray nozzle 8.

WARNING!

Switch off the product and remove the battery pack 2134 before replacing attachments, cleaning and when not in use.

- Switching the product on/off

• Switching on: Move the on/off switch [17] to position I.
• Switching off: Move the on/off switch 17 to position O.

Adjusting the nozzle

NOTICE!

If you turn the spray nozzle too far to the right, the spray nozzle can be unscrewed.

NOTE

The spray nozzle can be infinitely adjusted from spray mist to jet.

Spray mist: Turn the spray nozzle 8 to the left from the user's viewpoint.
- Jet stream: Turn the spray nozzle 8 to the right from the user's viewpoint.
Turning the spray nozzle 8 to the right makes the beam selectively more intense.

Spraying

NOTICE!

Recoil forces may occur when pressing the trigger lever 2 on the pistol grip 1. Always keep a good hold on the pistol grip.

NOTE

Always spray directly and solely onto the plants or objects to be sprayed.
To avoid damage to the environment, the operator or bystanders, select an appropriate nozzle setting.
Located on the trigger gun is a small lever which blocks the trigger lever 2 against unintentional pressing.

Starting spraying

1. Hold the spray nozzle 8 at the surface to be sprayed.

Troubleshooting

Problem Possible cause	Solution
The product does not function.	The battery pack 2134 is discharged.	Charge the battery pack 2134.
	The battery pack 2134 was not inserted into the product.	Insert the battery pack 2134 into the product (see “Inserting the battery pack”).
	The on/off switch 17 is broken.	Contact the customer service.

1. Fold the small lever into the trigger lever 2.
2. Press the trigger lever 2 on the pistol grip 1. The liquid is sprayed from the spray nozzle 8.

Stopping spraying

Release the trigger lever 2.

Secure the trigger lever against unintentional operation

1. Fold out the small lever on the trigger lever 2
2. Place the small lever against the black trigger gun.

Continuous operation

1. Press the trigger lever 2 against the trigger gun.
2. Lock the trigger lever 2:Push the small lever on the trigger lever forward.

Problem Possible cause Solution
The tank is full but the product does not spray or sprays at a low rate.	The spray nozzle 8 is completely or partially blocked.
	The liquid is too thick and therefore unsuitable.
The motor stops suddenly.	The battery pack 2134 is discharged.

- Cleaning and maintenance

WARNING!

Switch off the product and remove the battery pack [2134 before replacing attachments, cleaning and when not in use.

Cleaning

WARNING! Risk of electric shock!

The product must not be sprayed with water or cleaned under running water.

NOTICE!

Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.
Wear protective equipment (e.g. gloves, safety googles) during cleaning.
Never blow the spray nozzle out with your mouth.

NOTE

Clean the product immediately after each use.
Regular proper cleaning helps to ensure safe use and prolongs the life of the product.
Foreign bodies can accumulate in the spray nozzle 8 and block the spray nozzle.

Cleaning the container

1. Clean the container 10 with clean water.
2. Release the water via the filler opening.
3. Allow the container 10 to dry out completely.

Cleaning the housing

Clean the housing with a damp cloth.

Cleaning when the spray nozzle is clogged

1. Clean the hole in the spray nozzle 8 of residue with a needle or thin wire (not included in the scope of delivery).
2. Rinse the spray nozzle 8 with clear water.
3. Allow the spray nozzle 8 to dry completely.

Maintenance

The product is maintenance-free.

Storage

NOTE

Empty the water fully from the container [10]. The product and accessories may be destroyed by frost if they are not fully emptied of water.

1. Switch off the product. Let the product cool down.
2. Remove the battery pack 2134 from the product before storing it for a longer period of time (e.g. winter storage).
3. Clean the product (see "Cleaning").
4. Store the spray lance 7 inserted in the holder 6 with the spray nozzle 8 pointing downwards.
5. Store the product and its accessories in a dark, dry, frost-free, dust-protected and well-ventilated place.
6. Always store the product in a place inaccessible to children.
7. The storage temperature for the battery pack 2134 and the product is between 0 and +45^ . Avoid extreme cold or heat during storage to prevent the battery pack from losing power.

Reusing the product after the winter

1. Check the battery compartments 19 and the spray nozzle 8 for any dirt. Clean them if necessary.
2. Test the system and the water supply line for leaks.

Replacement parts

Customers can obtain compatible replacement batteries and chargers from the LIDL online shop www.lidl.de.
□ If you are not sure where you can purchase compatible parts, please contact the Lidl Service Hotline (see "Service").

- Transportation

1. Switch off the product. Remove the battery pack 2134 from the product.
2. Transport the spray lance 7 inserted in the holder 6
3. Protect the product against shocks and strong vibrations that occur especially during transport in vehicles.
4. Secure the product against slipping and falling over.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries/rechargeable batteries must be recycled. Return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Remove the batteries/battery pack from the product before disposal.

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/ rechargeable batteries at a local collection point.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 465846_2404) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 465846_2404 takes you to the operating instructions for your item.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

EU declaration of conformity

EU DECLARATION OF CONFORMITY (No 465846_2404)
IAN:	465846_2404
Product id entification:	"PARKSIDE" Cordless Pressure Sprayer 12V / 20V
Model Number:	HG10607

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 62841-1:2015/A11:2022

EN ISO 19932-1:2013

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

The object of the declaration described above is in conformity with Directive 2011/ 65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Directive 2006/42/CE

Directive 2014/30/UE

EU PROHLÁŠENÍ O SHODE (c. 465846_2404)

IAN:

465846 2404

Identifi kace produktu: "PARKSIDE" Aku tlakovy postrikovač 12 V / 20 V

Cislo modelu:

HG10607

EU VYHLÁSENIE O ZHODE (c. 465846_2404)

IAN:

465846 2404

Identifi kacia produktu:

"PARKSIDE" Aku tlakovy postrekovač 12 V/20 V

Cislo modelu:

HG10607
