USER MANUAL ULGD 1.0 A2 ULTIMATE SPEED

VEHICLE BATTERY CHARGER ULGD 10 A2 KFZ-BATTERIELADEGERÄT ULGD 10 A2 CHARGEUR DE BATTERIE POUR VOITURE ULGD 10 A2

GB IEN CYMT

VEHICLE BATTERY CHARGER

Translation of the original instructions

FRBE CH

CHARGEUR DE BATTERIE POUR VOITURE

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

DE AT CH

GB/IE/NI/CY/MT Translation of the original instructions Page 5

Table of pictograms used

Introduction

Intended use Page 8
Scope of delivery . Page 8
Equipment . 8
Technical Specifications.. 9
Charging characteristics.. 10

Safety instructions.. 10

Specific safety instructions.. 15

Before use.. 15

Using the device . 16

Connection.. 16
Disconnecting 17
Standby / Measuring battery voltage.. Page 17
Battery recognition.. 17
Revival 18
Selecting programs.. 18

Maintenance and care 22

Information about recycling and disposal 23

EC Declaration of Conformity 24

Warranty and service information 25

Warranty conditions . 25
Warranty period and statutory claims for defects.. 25
Extent of warranty.. 25
Processing of warranty claims 26

Table of pictograms used
	Read the operating instructions for this product attentively and with care before use.	220 - 240 V~50 Hz - 60 Hz	Alternating voltage 220-240 V with a frequency of 50 Hz - 60 Hz
	PLEASE NOTE: This symbol indicates additional information and explanations on the product and its use.		Caution! Possible risks!
			Caution! Explosion hazard!
	You are legally obliged to place devices marked as such in a collection which is separate from unsorted municipal waste. Disposal through household waste is prohibited.		Caution! Danger of electric shock!
		IP54	Protected against dust in damaging quantities and against splashing water
T3.15A	Internal fuse		Do not dispose of any electrical devices in domesticwaste!
	Only for use in closed, ventilated rooms!		Dispose of the device and packaging in an environmentally friendly manner!
PAP	Packaging material – Other cardboard		Made from recycled material
1	Charging current 5 A (in 12 V mode) Charging current 2.5 A (in 24 V mode)	2	Charging current 10 A (in 12 V mode) Charging current 5 A (in 24 V mode)
1	Charging current 5 A (in 12 V mode) Charging current 2.5 A (in 24 V mode)	2	Charging current 10 A (in 12 V mode) Charging current 5 A (in 24 V mode)
12 V	Suitable for the charging of 12 V batteries	24 V	Suitable for the charging of 24 V batteries
= = =	Direct current		Appliance class II
12 V	12 V mode (programs 1, 2, 3, 4 and 9)	24 V	24 V mode (programs 5, 6, 7, 8 and 10)
24 V	Disconnect from the mains before closing or opening any of the connections to the battery.		Ensure sufficient ventilationwhen charging!
1 W	Connect the battery first, then establish the connection with the mains!		Protect electrical connections from rain!
	Avoid flames and sparks! Do not smoke!
	Winter AGM mode (programs 2, 4, 6 and 8)	+	Supply program (programs 9 and 10)
	suitable for trickle charging for longer periods of non-use

VEHICLE BATTERY CHARGER ULGD 10 A2

Introduction

Congratulations! You have purchased one of our high-quality products. Please familiarise yourself

with the product before using it for the first time. To do this, please read through the following operating and safety instructions carefully.

KEEP OUT OF THE REACH OF CHILDREN!

- Intended use

The Ultimate Speed ULGD 10 A2 is a multi-level vehicle battery charger, which is suitable for charging and trickle charging 12V (6 cells) or 24V (2x6 cells) lead acid batteries (maintenance free batteries (MF), open) with electrolyte solution (WET), with electrolyte absorbing mats (AGM), with gel gel-type electrolyte (GEL) or calcium batteries. The device is not suitable for charging lithium-ion batteries!

You can also regenerate discharged batteries (depending on the battery type). The vehicle battery charger has a safety circuit against sparking and overheating. Keep these instructions in a safe place.

The supply program enables you to change a vehicle battery without interrupting the voltage supply.

Ensure you hand over all documentation when passing the product on to anyone else. Any use that differs to the intended use as stated above is prohibited and potentially dangerous. Damage or injury caused by misuse or disregarding the above warning is not covered by the warranty or any liability on the part of the manufacturer. The device is not intended for commercial use and should only be used indoors. Commercial use will void the guarantee.

The product must only be started up initially by people who have been trained to do so.

Please note:

The vehicle battery charger cannot charge any electrical vehicles with integrated rechargeable battery.

Please note:

It is not possible to jumpstart 12 V or 24 V batteries.

- Scope of delivery

1 Vehicle battery charger
1 Operating instructions
1 Connecting cable with clamps
1 Connecting cable with loops

Equipment

For this see Fig. A, B: After unpacking the product, please check that all of the package contents are present and that the battery charger is in perfect condition. Do not use the device if it is defective.

1	Vehicle battery charger
2	24 V 24 V mode (Programs 5, 6, 7, 8 and 10)
3	12 V, 12 V mode (Programs 1, 2, 3, 4 and 9)
4	Charging current 5 A (in 12 V mode) Charging current 2.5 A (in 24 V mode)
5	Charging current 10 A (in 12 V mode) Charging current 5 A (in 24 V mode)
6	Winter AGM mode (programs 2, 4, 6 and 8)
7	Supply program (programs 9 and 10)
8	Program selector button
9	Charging display
10	Status display
11	Voltage display
12	Mains cable
13	Red loop (positive pole)
14	Black loop (negative pole)
15	Output cable with plug
16	Cover cap connecting cable with loops
17	Connecting cable with loops
18	Connecting cable with clamps
19	Positive pole connection terminal (red)
20	Cover cap for connecting cable with clamps

21	Negative pole connection terminal (black)

Please note:

The use of the term 'product' or device' in the following text refers to the vehicle battery charger named in these operating instructions.

Technical Specifications

Model: ULGD 10	A2
Rated voltage:	220-240 V~50 Hz - 60 Hz
Rated intake current:	2.0 A
Rated output DC voltage:	12 V---/24 V---
Rated output direct current at 12 V:	10.0 A / 5.0 A
Rated output direct current at 24 V:	5.0 A / 2.5 A
Ambient temperature:	-20 °C to 50 °C
Housing protectiontype:	IP 54
Appliance class:	II (dual insulation)
Battery types:	12 V lead acid battery20 Ah-300 Ah24 V lead acid battery20 Ah-150 Ah

- Charging characteristics PRODUCT AND MUST BE AVAILABLE AT ALL TIMES!

For this see Fig. C:

①	Polarity reversal protection / Battery diagnosis
②	Pulse charging Revival (desulphurisation)
③	Main charge
④	Preservation charging up to 80%
⑤	Recharging to 100% (Absorption)
⑥	Battery monitoring
⑦	Charge maintenance

Changes to technical and visual aspects of the product may be made as part of future developments without notice. Accordingly, no warranty is offered for the physical dimensions, information and specifications in these operating instructions. The operating instructions cannot therefore be used as the basis for asserting a legal claim.

- Safety instructions

PLEASE READ THROUGH THE OPERATING INSTRUCTIONS CAREFULLY BEFORE USE. THESE FORM PART OF THE

KEEP OUT OF THE REACH OF CHILDREN!

The charger is only suitable for indoor operation!

DANGER!

Avoid danger to life and danger of injury from improper use!

CAUTION!

Do not operate the device with a damaged cable, mains cable or mains plug. Damaged mains cables pose danger to life from electric shock.

In case of damage, the mains cable must only be repaired by authorized and trained specialists! Contact the service point of your country if you need any repairs!

DANGER OF ELECTRIC SHOCK!

Ensure that the vehicle is not in operation if the battery is permanently installed in the vehicle! Switch off the ignition and put the vehicle into the parking position, with the parking brake engaged (e.g. car) or the rope attached (e.g. boat)!

DANGER OF ELECTRIC SHOCK!

Disconnect the vehicle battery charger from the mains before removing the connection terminals.

• Connect the connection terminal that is not connected to the car body first.

• Connect the other connection terminal to the car body away from the battery and the petrol line.

• Connect the vehicle battery charger to the supply grid only after doing this.

• Disconnect the vehicle battery charger from the supply grid after charging.

• Only then disconnect the connection terminal from the car body. Then disconnect the connection terminal from the battery.

DANGER OF ELECTRIC SHOCK!

Only touch the pole connection terminals (^ - ^ and ^ + ^ ) in the insulated area!

DANGER OF ELECTRIC SHOCK!

Conduct the connection to the battery and the socket of the mains grid completely protected from moisture!

DANGER OF ELECTRIC SHOCK!

Perform installation, servicing and maintenance of the vehicle battery charger only when the mains current is not connected!

DANGER OF ELECTRIC SHOCK!

First disconnect the negative pole connection cable of the vehicle battery charger from the negative pole of the battery upon completing the charging and trickle charging process, if the battery is continually connected in the vehicle.

• Do not leave any toddlers or children unsupervised around the vehicle battery charger!
  Children cannot assess possible dangers in the use of electrical devices. Children must be supervised to ensure that they do not play with the device.

EXPLOSION HAZARD!

Protect yourself from highly explosive oxyhydrogen reactions! Gaseous hydrogen can escape during charging or trickle charging of the battery. Oxyhydrogen is a potentially explosive mix of gaseous hydrogen and oxygen. The

oxyhydrogen reaction occurs on contact with open fire (flames, smouldering or sparks)! Perform charging and trickle charging in a weather-protected space that is well ventilated. Ensure that there are no naked flames (flames, embers or sparks) during charging or trickle charging!

EXPLOSION AND FIRE HAZARDS!

Ensure that explosive or flammable substances, such as petrol or solvents cannot be ignited when you are using the vehicle battery charger!

EXPLOSIVE GASES!

Avoid flames and sparks!

• Ensure sufficient ventilation when charging.
  Put the battery onto a well-ventilated surface when charging. Otherwise, the device can be damaged.

EXPLOSION HAZARD!

Ensure that the positive pole connection cable has no contact with a fuel line (e.g. petrol line)!

DANGER OF CAUSTIC BURNS!

Protect your eyes and skin from caustic burns from the acid (sulphuric acid) when it comes

into contact with the battery!
Use: acid-resistant safety goggles, clothing and gloves! If your eyes or skin have come into contract with the sulphuric acid, flush the affected body region with plenty of clear, running water and seek medical advice at once!
- Avoid electrical short circuits when connecting the vehicle battery charger to the battery. Connect the negative pole connection cable only to the negative pole of the battery or the car body. Connect the positive pole connection cable only to the positive pole of the battery!
Before connecting to the mains, verify the mains power has the required 230V 50Hz a 16 A fuse and an ELCB switch (earth leakage circuit breaker)! Otherwise, the device can be damaged.
- Do not use the vehicle battery charger near any fires, heat and long periods when the temperature is above 50^ At higher temperatures, the output power of the vehicle battery charger will drop automatically.
Only use the vehicle battery charger with the original parts it was delivered with!

• Do not cover the vehicle battery charger with any objects! Otherwise, the device can be damaged.

• Protect the electrical contact surfaces of the battery from short circuit!

• Only use the vehicle battery charger for the charging and trickle charging of undamaged 12 V-/24 V-lead batteries (with electrolyte solution or gel)!

• Otherwise, property damage may be the consequence.

• Do not use the vehicle battery charger for the charging and trickle charging of non-rechargeable batteries. Otherwise, property damage may be the consequence.

• Do not use the vehicle battery charger for the charging and trickle charging of damaged or frozen batteries! Otherwise, property damage may be the consequence.

Please refer to the original operating instructions about the maintenance of your battery prior to connecting the vehicle battery charger!

Otherwise, there is a danger of injury and/or the risk of damage to the device.

Before connecting the vehicle battery charger to a battery

that is continually connected to the vehicle, learn about compliance with the electrical safety and maintenance in the original operating instructions of the vehicle! Otherwise, there is a danger of injury and/or the risk of property damage.

• Disconnect the vehicle battery charger from the mains current when it is not is use, to protect the environment as well! Note that power is consumed in standby operation as well.

Always pay attention and be aware of what you are doing. Proceed sensibly and do not put the vehicle battery charger into operation when you are not focused or not feeling well.

Personal safety:

This device may be used by children aged 8 years and older, and by persons with reduced physical, sensory or mental capacities, or a lack of experience and knowledge, if they are supervised or have been instructed in how to use the device safely and understand the dangers that may arise when using it. Do not allow children to play with the

device. Cleaning and day-to-day maintenance must not be performed by children without supervision.

Children must be supervised to ensure that they do not play with the device.
- Keep the device away from people - especially children - and household pets.
Within the working area, the user is responsible for any damage or injury to third parties that was caused by the use of the device.
Do not leave the device charging unattended.
- Keep the device in a dry location and out of the reach of children.

This helps prevent device damage and possible personal injuries that could result from it:

Working with the device:

Before setup or first use, check the device for any damage and do not use unless in perfect working order.
Make sure that the mains plug and connection terminals do not get wet. Do not

expose the device to rain or wet weather. Do not let the device come into contact with water. Do not immerse the device in water. There is a risk of electric shock!

In hot weather, do not leave the device in a car. This could permanently damage the device.
Do not operate the device near to flammable liquids or gases. Failure to do so risks causing a fire or explosion!
- Switch the device off and remove the mains plug from the socket in the following cases:

• if you are not using the device;
• if you are leaving the device unsupervised;
• if you are doing cleaning work;
• if the connection cable is damaged;

Only use the accessories supplied and recommended by the manufacturer.

• Do not disassemble or modify the vehicle battery charger. This device must only be repaired by a maintenance technician.
  Do not use the device in areas with a risk of expo

sion, e.g. near flammable liquids, gases or powders.

• Do not expose the device to any source of heat.
  When the charger is not being used, always put the cover caps 20 and 16 onto the connecting cable 18 and 17. This prevents any possible short circuit through contact with rain or splashed water.

CAUTION: How to avoid accidents and injuries resulting from electric shock:

Electrical safety:

• Do not carry the device by the cable. Do not unplug the plug from the socket by pulling on the cable. Protect the cable from heat, oil and sharp edges.
  If the cable is damaged, unplug the plug immediately from the socket.

- Specific safety instructions

A slightly higher temperature during charging is absolutely normal and not a malfunction.

Protect the vehicle battery charger from moisture and high temperatures, including fires.
Store the vehicle battery charger in a dry place and protect the device from moisture and corrosion.
Do not drop the vehicle battery charger while it is being used.

- Before use

Take all parts from the packaging and check whether the device or parts show any damage. If this is the case, do not use the device. Contact the manufacturer via the indicated service address. Remove all transport packaging. Check that the delivery is complete.
Always remove the mains plug from the socket before you perform any work on the vehicle battery 1 charger.
Before connecting the charger please read the operating instructions for the battery.
In addition, you must adhere to the instructions from the vehicle manufacturer where a battery is continuously connected in the vehicle. Secure the vehicle, switch the ignition off.

Clean the battery poles. Make sure that the dirt does not come into contact with your eyes.
Make sure that there is sufficient ventilation.

Please note: The ambient temperature is measured in the charger. Hence, for optimum function, make sure the battery exhibits the same temperature as the environment.

Using the device

- Connection

! Please note:

Always observe the instructions from the vehicle manufacturer or the battery manufacturer.

Charging using the battery clamps:

• Disconnect the negative pole connection cable (black) of the vehicle from the negative pole of the battery first before charging and trickle charging if the battery is continually connected in the vehicle. The negative pole of your battery is usually connected to the car body of the vehicle.

• Then disconnect the positive pole connection cable (red) of the vehicle from the positive pole of the battery.

• Connect the output cable with the plug 15 to the connecting cable with clamps 18.

• Only then connect the "+" pole quick-contact connection terminal (red) 19 of the vehicle battery charger to the "+" pole of the battery.
• Connect the "−" pole quick-contact connection terminal (black)
  21 to the "−" pole of the battery.
• Connect the mains cable of the vehicle battery charger to the socket.

Charging using loops:

The connecting cable with loops must be permanently connected to the battery.
- Disconnect the battery from the vehicle. Loosen the nut on the battery's positive terminal (red). Now insert the red loop 13 under the nut connected to the battery's positive terminal, and then retighten the nut. Make sure that the loop 13 does not slip when tightening the nut.
Repeat with the black loop on the battery's negative terminal.
- Afterwards, reconnect the battery to the vehicle.
Put the cover cap of the connecting cable with loops over the contacts of the connecting cable with loops. When the charger is not being used, this must

always be carried out in order to prevent a short circuit.

Remove the cover cap of the connecting cable with loops 17, before you start charging.
- Connect the output cable with the plug 15 with the connecting cable with loops 17.
- Connect the mains cable of the vehicle battery charger to the socket.

- Disconnecting

Stop charging using the battery clamps:

• Disconnect the device from the mains current.
• Disconnect the “-” pole quick-contact connection terminal (black) 21 from the “-” pole of the battery.
• Disconnect the "+" pole quick-contact connection terminal (red) from the "+" pole of the battery.
• Reconnect the positive pole connection cable of the vehicle to the positive pole of the battery.
• Reconnect the negative pole connection cable of the vehicle to the negative pole of the battery.

Stop charging using loops:

• Disconnect the device from the mains current.

Pull out the plug which connects the output cable with the plug 15 with the connecting cable with loops 17.
- Cover the contacts of the connecting cable with loops 17 with the attached cover cap of the connecting cable with loops 16 .

- Standby / Measuring battery voltage

After connecting the mains supply, the device is in standby mode. The display is in use. When the connection terminals are connected, the battery voltage is displayed on the display (voltage display [1]). The segments of the status display [10] are empty. If the measured voltage is below 2V , then this means the battery is not charging.

- Battery recognition

If a battery with a voltage over 2V is connected, the charging process will start once the charging program is selected. Deeply discharged batteries can also be charged, as long as they are not defective. If a battery with a voltage of over 15.6V is connected, in 12V mode, "Err" will be shown in the voltage display [1]. The charging process starts in 24V mode.

If the charger is connected to a battery with the poles reversed,

"POL" will be shown on the display. The charging process will not be activated.

Revival

After battery recognition, depending on the battery status, the revival process will be activated. Pulsating current ensures that a battery which is not used for a long period of time will still be able to be charged. If the revival is not successful after 10 minutes, then "Err" will be shown on the display.

If a 24 V charging program is selected accidentally and a 12 V battery is connected, then after 10 mins, "Err" will appear on the display.

- Selecting programs

Please note:

Before a charging program is carried out, the battery must be connected to the charger as described in the "Connection" section. The charging process continues automatically. Depending on the program selected, the charging characteristics for voltage, time and temperature are monitored. The charging process contains a diagnosis program, a revival mode and a trickle charge function.

Program		max. (V)	max. (A)
1	12 V 1	14.4 V 5.0 A
2	12 V 2	14.7 V 5.0 A
3	12 V 2	14.4 V 10.0 A
4	12 V 2	14.7 V 10.0 A
5	24 V 1	28.8 V 2.5 A
6	24 V 1	29.4 V 2.5 A
7	24 V 2	28.8 V 5.0 A
8	24 V 2	29.4 V 5.0 A
9	12 V 1	13.6 V 3.0 A
10	24 V 1	27.2 V 1.5 A

Program 1

记

(14.4 V / 5.0 A)

To charge 12 V batteries with a capacity of 20 Ah to 100 Ah.

Press the program selector button once to select Program 1.

The 3 and 4 symbols are shown on the display. During

the charging process, the charging display 9 flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10. When the battery is fully charged, the status display shows 10 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 2

记 再杂

(14.7 V / 5.0 A)

To charge 12V batteries with a capacity of 20 Ah to 100 Ah under cold conditions or to charge AGM batteries.

Press the program selector button twice to select Program 2.

The 24 symbols are shown on the display. During the charging process, the charging display 9 flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10. When the battery is fully charged, the status display shows 10 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 3

记

(14.4 V / 10.0 A)

To charge 12 V batteries with a capacity of 60 Ah to 200 Ah.
To maintain the charge of 12 V batteries up to 300 Ah.

Press the program selector button three times to select Program 3.

The 12 3 and 5 symbols are shown on the display. During the charging process, the charging display 9 flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10. When the battery is fully charged, the status display shows 10 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 4

2

(14.7 V / 10.0 A)

To charge 12 V batteries with a capacity of 60 Ah to 200 Ah under cold conditions or to charge AGM batteries. To maintain the charge of 12 V batteries up to 300 Ah. Press the program selector button four times to select Program 4.

The symbols are shown on the display. During the charging process, the charging display 9 flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10. When the battery is fully charged, the status display shows 10 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 5

24 V 1 (28.8 V / 2.5 A)

To charge 24 V batteries with a capacity of 20 Ah to 50 Ah.

Press the program selector button once to select Program 5. If the 24V battery is deeply discharged (below 15.6 Volt), then the charger recognises the battery as a 12V battery. In this case, the program selector button must be pressed five times, to select program 5.

The 24 symbols are shown on the display. During the charging process, the charging display flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10.

When the battery is fully charged, the status display shows 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 6

24 V 1 2.5 A) (29.4 V / 2.5 A)

To charge 24V batteries with a capacity of 20 Ah to 50 Ah under cold conditions or to charge AGM batteries.

Press the program selector button twice to select Program 6. If the 24V battery is deeply discharged (below 15.6 Volt), then the charger recognises the battery as a 12V battery. In this case, the program selector button must be pressed six times, to select program 6.

The 24 symbols are shown on the display. During the charging process, the charging display 9 flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10. When the battery is fully charged, the status display shows 10 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 7

24 V 2

(28.8 V / 5.0 A)

To charge 24 V batteries with a capacity of 40 Ah to 100 Ah.
To maintain the charge of 24 V batteries up to 150 Ah.

Press the program selector button 8 three times to select Program 7. If the 24V battery is deeply discharged (below 15.6 Volt), then the charger recognises the battery as a 12V battery. In this case, the program selector button must be pressed seven times, to select program 7.

The 24 and symbols are shown on the display. During the charging process, the charging display flashes. The progress of the charging process (1-4 bars) will be shown on the status display. When the battery is fully charged, the status display shows 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 8

24V 2 柒(29.4V/5.0A)

To charge 24V batteries with a capacity of 40 Ah to 100 Ah under cold conditions or to charge AGM batteries.

To maintain the charge of 24V batteries up to 150 Ah.

Press the program selector button 8 four times to select Program 8. If the 24V battery is deeply discharged (below 15.6 Volt), then the charger recognises the battery as a 12V battery. In this case, the program selector button 8 must be pressed eight times, to select program 8.

The 24 V 2, 5 and symbols are shown on the display. During the charging process, the charging display 9 flashes. The progress of the charging process (1-4 bars) will be shown on the status display 10. When the battery is fully charged, the status display shows 10 4 bars. The flashing stops and the device switches to trickle charging automatically. The display will show "FUL".

Program 9

The 24 and 7 symbols are shown on the display.

For use as a 12 V voltage supply or for buffer maintenance charging, where 100% battery power is necessary. Das supply program will work without a time limit.

Please contact the vehicle manufacturer and read the operating instructions for your vehicle, if you want to use this program to buffer your vehicle when changing a battery.

Program 10

24V

(27.2 V / 1.5 A)

Supply program 27.2V / 1.5A max. Press the program selector button 8 ten times to select Program 10.

The 24 and symbols are shown on the display.

For use as a 24 V voltage supply or for buffer maintenance charging, where 100% battery power is necessary. Das supply program will work without a time limit.

Please contact the vehicle manufacturer and read the operating instruc

tions for your vehicle, if you want to use this program to buffer your vehicle when changing a battery.

Trickle charging

In programs 1 to 8, the device has an automatic trickle charging procedure. Depending on the drop in voltage in the battery - through self-discharge - the charger reacts with different levels of charging current. The battery can remain connected to the charger over a longer period of time.

Device protection function

As soon as a different situation occurs, such as a short circuit, critical drop in voltage during the charging process, open circuit or reversed connection of the output terminals, the battery charger 1 switches off automatically. The electronic system resets the system immediately to its home position, in order to avoid damage. If the device should become too hot during charging, the output power is automatically reduced. This protects the device from damage.

- Maintenance and care

Always remove the mains cable from the socket before you perform any work on the vehicle battery charger.

The device is maintenance-free. Switch the device off. Clean the metal and plastic surfaces of the device with a dry cloth.
- Never use any solvents or other aggressive cleaning agents.

Information about recycling and disposal

DO NOT DISPOSE OF ELECTRICAL TOOLS IN HOUSEHOLD WASTE! DON'T THROW AWAY - RECYCLE!

According to European Directive 2012/19/EU, used electrical devices must be collected separately for environmentally compatible recycling or recovery. The symbol of the crossed out dustbin means that this device must not be disposed of in household waste at the end of its service life. The device must be handed in at established collection points, recycling centres or waste management depots. The disposal of defective devices which you have sent in will be carried out free of charge. In addition, distributors of electrical and electronic equipment as well as food distributors are obliged to accept returned waste. LIDL provides you with return options directly in its branches and shops. Return and disposal is free of charge for you. When buying a

new device you have the right to return an equivalent old device at no charge. In addition you have the option, regardless of whether you are buying a new device, to hand in (up to three) old devices at no charge, as long as the device is no larger than 25 cm in any dimension.

Before returning the device please delete all personal information. Before returning, please remove batteries or rechargeable battery packs which are not enclosed by the old device, as well as bulbs, which can be removed without destroying the product and take these to a separate collection point.

Batteries containing harmful substances are labelled with the adjacent symbol, which ates the prohibition on disposal usehold waste. The abbreviation for the relevant heavy metals Cd = cadmium, Hg = mercury, lead.

Take used batteries to a waste management company in your city or community or return them to your dealer. This satisfies your legal obligations while also making an important contribution to protecting the environment.

Please note the marking on the different packaging materials and separate them

as necessary. The packaging materials are marked with abbreviations (a) and digits (b) with the following definitions: 1-7: Plastics, 20-22: Paper and cardboard, 80-98: Composite materials.

- EC Declaration of Conformity

We, C. M. C. GmbH Holding

Responsible for documentation: Joachim Bettinger
Katharina-Loth-Str. 15
66386 St. Ingbert
Germany

hereby take sole responsibility for declaring that the product

Vehicle battery charger

Year of manufacture: 2025/19
IAN: 468756_2407
Model: ULGD 10 A2
Model number: 2775

meets the basic safety requirements as specified in the European Directives.

Low Voltage Directive

2014/35/EU Electromagnetic Compatibility 2014/30/EU RoHS Directive 2011/65/EU + 2015/863/EU

and the amendments to these Directives.

The object of the declaration described above meets the requirements of Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

This conformity assessment is based on the following harmonised standards:

EN 60335-1:2012/A15:2021

EN 60335-2-29:2021/A1:2021

EN 62233:2008

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/

A1:2021

EN 61000-3-3:2013/A2:2021

Warranty and service information

extended when a device is repair or replaced.

Warranty from C. M. C. GmbH Holding

Dear Customer,
The warranty for this equipment is 3 years from the date of purchase. In the event of product defects, you have legal rights against the retailer of this product. Your statutory rights are not affected in any way by our warranty conditions, which are described below.

Warranty conditions

The warranty period begins on the date of purchase. Please retain the original sales receipt. This document is required as your proof of purchase.

Should this product show any defect in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our discretion - free of charge. This warranty service requires that you retain proof of purchase (sales receipt) for the defective device for the three year period and that you briefly explain in writing what the fault entails and when it occurred. If the defect is covered by our warranty, we will repair and return your product or send you a replacement. The original warranty period is not

Warranty period and statutory claims for defects

The warranty period is not extended by the guarantee. This also applies to replaced and repaired parts. Any damages or defects detected at the time of purchase must be reported immediately after unpacking. Any incidental repairs after the warranty period are subject to a fee.

- Extent of warranty

This device has been manufactured according to strict quality guidelines and carefully inspected before delivery.

The warranty applies to material and manufacturing defects only. This warranty does not extend to product parts, which are subject to normal wear and tear and can thus be regarded as consumable parts, or for damages to fragile parts, e.g. switches, rechargeable batteries or parts made from glass.

This warranty is voided if the product becomes damaged or is improperly used or maintained. For proper use of the product, all of the instructions given in the operating

instructions must be followed precisely. If the operating instructions advise you or warn you against certain uses or actions, these must be avoided in all circumstances.

The product is for consumer use only and is not intended for commercial or trade use. The warranty becomes void in the event of misuse and improper use, use of force, and any work on the device that has not been carried out by our authorised service branch.

when it occurred free of charge to the service address given.

! Please note:

You can download this handbook and many more, as well as product videos and software at www.lidl-service.com.

With this QR code you can gain immediate access to the Lidl Service page (www.lidl-service.com) and you can open your operating instructions by entering the article number (IAN) 468756.

- Processing of warranty claims

To ensure prompt processing of your claim, please follow the instructions given below.

Please retain proof of purchase and the article number (e.g. IAN) for all inquiries.

The product number can be found on the type plate, an engraving, the cover page of your instructions (bottom left), or the sticker on the back or underside of the device.

In the event of malfunctions or other defects, please first contact our service department below by phone or email. If your product is found to be defective, you can then send your product with proof of purchase (till receipt) and a statement describing what the fault involves and

How to contact us:

GB, IE, NI, CY, MT

Website: www.cmc-creative.de

E-mail: [e-mail]

Phone: [phone]

Registered office: Germany

IAN 468756_2407

Please note that the following

address is not a service address.

Please first contact the service point

given above.

Address:

C. M. C. GmbH Holding

Katharina-Loth-Str. 15

66386 St. Ingbert

GERMANY

Ordering spare parts:

[e-mail]

[e-mail]

Telefon: [phone]

- Registering of battery

Tryk to gange pa programvalgtasten 8 for at vaelge program 2.

Tryk to gange pa programvalgtasten for at vaelge program 6.

Nome: Riku Service snc

Indirizzo Internet: www.riku-service.com

E-Mail: [e-mail]

Telefono: 0039 (0) 4711430103

Sede: Germania

IAN 468756_2407
