MBL-37 - Blender MPM - Free user manual and instructions

USER MANUAL MBL-37 MPM

EN We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances

Black and white photo of a blender with a clear glass handle and control knob (no visible text or symbols)

MBL-37

STO NIM XER

TASSE NIMEN TASS BIENDE

ФИЗАЯ МИТЕНТЕР

CU-PBLENOLR

VASO DE BAT DO BA

TASSE DE MIXEOR CELSO UBMIXCLR

LAZZADTRULLATORI

FUODLLIS MAISY UVO

TASTE BLENDERS

Exploded view diagram of a blender with numbered parts for identification

• Read the operating instructions carefully before use.
• Do not hold the device with wet hands.
  -Be especially careful when there are children near the appliance.
  -Do not use the appliance for any purpose other than its intended purpose.
• Do not immerse the appliance, cord and plug in water or other liquids.
  -Do not allow the power cord to dangle from the edge of the table/countertop.
• Do not leave the device unattended during operation.

- Do not use the damaged device, even if the mains cord or plug is damaged — in this case, return the device to an authorized service center for repair.

- Do not use the appliance in the open air.

- Do not hang the power cord on sharp edges and do not allow it to come into contact with hot surfaces.

- Do not place the device on hot surfaces.

-Do not place the appliance near other electrical appliances, burners, stoves, ovens, etc.

- The device must be placed on a dry, flat and stable surface.

- The device is intended for home use only.

-Always before starting work, make sure that all components of the device are installed correctly.

- The use of accessories not recommended by the manufacturer may cause damage to the device, fire or personal injury.

-The device may be used by persons with reduced physical, sensory or mental capabilities, and who do not have knowledge or experience in the use of such devices, provided that they are supervised or instructed on the safe use of the devices and are informed of the potential hazards and understand the risks involved.

-The device can not be used by children. Keep the appliance and cord out of the reach of children.

- Children are not allowed to carry out cleaning and maintenance activities.

-Attention should be paid to children so that they do not play with the device.

• Do not pull the plug from the mains socket by pulling the cord.
  -The equipment is not intended to operate with external timers or a separate remote control system.
• Do not connect the plug to the mains socket with wet hands.

- For the safety of children, please do not leave parts of the packaging freely accessible (plastic bags, cartons, styrofoam, etc.).

- WARNING! Do not allow children to play with foil. Danger of suffocation!

-Check that the power parameters on the rating plate of the device correspond to those of your power supply network.

- ATTENTION! Before starting cleaning and maintenance, dis connect the appliance from the mains and wait for it to cool completely after operation. Do not immerse the device in water!

- ATTENTION! Do not use sharp objects, abrasive pastes, solvents and other strong chemicals for cleaning – their use may damage the device.

-Before first use, remove all bags, stickers, straps and transport locks from the appliance and its equipment.

-Disconnect the appliance from the power supply if left unattended and before assembly, disassembly or cleaning.

-Before starting work, make sure that you have not left a hard tool (e.g. spoon, spatula) in the blender jug or bottle by mistake, as this can lead to permanent damage to the device or personal injury.

- Before starting, make sure that the jug (bottle) is properly fixed on the blender housing.

- Wait until the engine stops completely before disassembling.

-Take special care in contact with the cutting blades, especially when removing them and when washing.

- Do not exceed the maximum capacity indicated on the blender container.

- Allow the hot ingredients to cool before processing.

-Cleaning of the appliance, in particular parts in direct contact with food, must be carried out before the first use, immediately after the end of the work or if the appliance has not been used for a long time — the procedure is described in the section “CLEANING AND MAINTENANCE”.

-Keep your hands away from moving parts while the appliance is operating.

- Do not remove the jug (bottle) of the blender during operation of the device.

-When mixing, do not put any objects in the jug (bottle), e.g. spoons, spatulas, etc.

- ATTENTION! The cutting blades are very sharp, avoid physical contact when emptying and cleaning the unit – you can seriously injure yourself.

-ATTENTION! Do not use the blender without the jug lid installed correctly!

-ATTENTION! Before pouring the contents from the jug (bottle), wait until the knife stops!

-ATTENTION! Do not exceed the permissible operating time indicated on the nameplate. Wait for the device to cool down before starting the next time.

-ATTENTION! Do not fill the jug (bottle) of the blender with boiling liquids.

-ATTENTION! Do not start the blender with an empty jug (bottle).

APPLIANCE DESCRIPTION

1. Blender housing

2. ON/OFF knob – two-speed operation and PULSE function

3. Jug mounting socket

4. Rubber seal

5. Pitcher base ring with stainless steel knife

6. 1500 ml glass blender jug

7. Jug handle

8. Jug cover

9. Jug cover cap

10. Non-slip feet

1. Make sure that a rubber seal seal is properly installed inside the jug base ring (5).

CAUTION! The blades are sharp. Handle with care. Handle the knife only by its plastic base.

1. Turn the blender jug (6) so that the opening for screwing the base on is pointed upwards.

2. Place the jug base ring (5) over the hole with the knife facing the inside of the jug and screw it in clockwise, taking care to fit the threads correctly.

In case of deinstallation of the jug base ring (5), act in a reverse order.

USING CUP BLENDER

Note: The appliance is equipped with a safety system to prevent accidental start-up. If the jug is incorrectly fitted, the blender will not start.

NOTE: The appliance is designed for blending food at a temperature of no more than 50^ C.

1. Place the blender housing (1) on a dry, hard and even surface.
2. After making sure that all blender jug parts are assembled correctly, put the blender jug (6) on the blender enclosure (1) and gently turn it clockwise. Ensure that the latches fit correctly.
3. Cut the products into smaller parts to make mixing easier. Put ingredients into the jug only when the motor is stopped.

NOTE! Do not fill the jug above the mark of 1500ml (6).

1. Place the lid with the hole plug.
2. Plug the appliance into the power supply socket.
3. Turn it on with the knob (2), choosing one of two operating modes.
4. During mixing always hold the lid. If you need to add ingredients when the cup blender is running, remove the hole plug from the lid (9) and feed the ingredients through the hole, and then replace the plug (9).
5. When mixing is complete stop the appliance by turning the knob (2) to the <<0>> position and unplug the power supply plug from the socket.
6. Certain products, e.g. ice cubes, should be crushed by repeatedly using the PULSE function. The PULSE function works by turning and holding the switch knob to the left as far as it will go. To improve crushing of the ice cubes, pour a small amount of water.

ATTENTION! Before pouring out the content of the jug wait until the knife stops rotating!

NOTE! Do not start the motor for more than 1 minute, because it may become overheated. After these 1 minutes stop the appliance and wait until it cools down but not less than 3 minutes.

INSTRUCTIONS FOR USE

1. Boiled vegetables and fruit should cool down before putting them into the blender jug.
2. Blender is not designed for the following:
3. grating potatoes
   • whipping eggs or dairy products substitutes
4. mincing raw meat
5. whipping or kneading dough (danger of forming a ball of dough which may damage the appliance)
6. juicing vegetables and fruit.

ATTENTION! If the motor stops, immediately switch off the blender, remove the jug from the main unit and remove excess ingredients from the jug.

CLEANING AND MAINTENANCE

CAUTION! Before cleaning, always unplug the appliance from the mains outlet and wait until it has completely cooled down.

CAUTION! Do not immerse the blender housing in water or other liquids.

CAUTION! The blades are very sharp. Handle with care to avoid injury.

1. Blender components are corrosion-proof and easy to clean.
2. Each time before and after using, disassemble the appliance and wash its parts in warm water with detergent, rinse and dry them thoroughly.

3. They should not be used in washing machines.

4. Periodically check all operating components of the appliance before using them. Do not use the blender if the blades got stuck or rotate with difficulty. Turn them clockwise to check if they operate properly. Be careful no to get injured. The blades should rotate easily.

5. Do not use the appliance if the jug gets damaged, leaks or has fractures of cracks. Otherwise it may crack while in use.
6. In order to clean the blender housing unplug the appliance and then wipe it with a damp cloth. If water gets to the top of the appliance, it will go down and through the drain hole under the housing.
7. The motor does not require any additional maintenance. Do not clean the appliance using harsh or abrasive cleaning agents, materials or steel wool, which may cause damage.

TECHNICAL DATA

Model	MBL-37
Power supply 220-240V	~50/60Hz
Rated power 500W
Maximum power 750W
Availability of the shutdown and standby mode	available
Power consumption in standby mode -
Power consumption in the shutdown mode	-
Power consumption in network standby mode	-
Automatically goes into standby mode after -
Automatically goes into the shutdown mode after -
Network standby mode, if the device has a connection function with the appli cation	-
Length of mains cable 1,0 m

NOTE! MPM agd S.A. reserves its right to modify the technical data.

Proper disposal of the product (waste electrical and electronic equipment)

Marking on the product indicates that after the service-life of the product expires, it should not be disposed with other type of municipal waste. Used equipment may have a negative impact on the environment and health of people due to potentially containing hazardous substances, mixtures and components. Mixing electric waste with other types of waste or disassembling those in an unprofessional manner may cause a release of substances that are hazardous to the environment and health.

Used equipment should be handed-over to a point for collection of electric waste. In order to obtain detailed information regarding the electric waste collection points, the user should contact the municipal point of electric waste collection or used equipment processing department.
