USER MANUAL GCT 30-42 Professional BOSCH

43x18x42mm Rubber band length 240mm Protection class IP54 Data transfer Bluetooth® Bluetooth® 4.2 (Low Energy) Frequency range used 2402–2480MHz Output power <10mW Energy supply Bluetooth® Low Energy module Coin cell 3V lithium battery, CR2032 A) Without rubber band Values can vary depending upon the product and are subject to application and environmental conditions. For further information www.bosch-professional.com/wac. Assembly and Operation Mounting the Auto-Start Remote – Attach one end of the rubber band(5) to one of the two fastening hooks(4). 1 609 92A 7U1 | (30.06.2023) Bosch Power ToolsEnglish | 13 – Secure the Auto-Start remote(1) to the cordless tool. To do so, tighten the rubber band(5) and attach the free end to the second fastening hook(4). Cut the rubber band to the correct length, as necessary. Appropriate places are those at which the cordless tool generates suffi- cient vibration during operation. Never fasten the Auto-Start remote to places which are required to operate the cordless tool (such as gripping surfaces, switches, displays). Starting operation – Connect theGCT 30-42 Auto-Start remote to theGCA 30-42 receiver or to the appropriate Bosch Professional dust extractor. Read the Starting Operation and Establishing a Connection sections in the operating instructions for the GCA 30-42 + GCT 30-42 Auto-Start system or the dust extractor that is being used. When changing a coin cell, the following shall apply: – If the GCT 30-42 transmitter module was connected to the GCA 30-42 re- ceiver module before changing the coin cell, the connection is automatic- ally re-established after changing the coin cell. – If the modules were not connected before replacing the coin cell, the con- nection needs to be established. After a reset, the Auto-Start remote and the receiver must be reconnected. Auto Starting the Dust Extractor – Insert the extraction hose into the dust extraction attachment of the cord- less tool. Vibration Detection The GCT 30-42 transmitter module is equipped with vibration detection. If it detects the vibrations of the activated cordless tool, the dust extractor will switch on automatically. If you switch off the cordless tool, the dust extractor switches off automatic- ally after a certain run-on time. Switching On and Off Manually – Briefly press the start/stop button(3) on the Auto-Start remote(1). The dust extractor switches on. – To switch off the dust extractor, press the start/stop button(3) on the Auto-Start remote again. Note: If you switch off the dust extractor with the start/stop button(3) on the Auto-Start remote, the dust extractor will automatically switch on again once the Auto-Start remote(1) detects the vibrations of the cordless tool. Bosch Power Tools 1 609 92A 7U1 | (30.06.2023)14 | English Resetting to Factory Settings – Press and hold the start/stop button(3) until the LED status indicator(2) flashes blue four times in quick succession. Status indications

status indicator (user interface)(2) Meaning/cause Solution Blue – Connection is estab- lished

– Data is being transmit- ted

Green – Connection established – Coin cell sufficiently charged

Yellow – Coin cell nearly empty Change coin cell soon Red – Connection not estab- lished

– Coin cell empty – Restart the connection attempt

Bluetooth®4.2 (Low Energy)

1 609 92A 7U1 | (30.06.2023) Bosch Power Tools| 187 Licenses Copyright © 2012–2020 STMicroelectronics All rights reserved. Redistribution and use in source and binary forms, with or without modificati- on, are permitted provided that the following conditions are met: – Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. – Redistributions in binary form must reproduce the above copyright noti- ce, this list of conditions and the following disclaimer in the documentati- on and/or other materials provided with the distribution. – Neither the name of STMicroelectronics nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRI- BUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DI- RECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTI- TUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSI- NESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILI- TY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NE- GLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Copyright © 2011 Petteri Aimonen This software is provided 'as-is', without any express or implied warranty. In no event will the authors be held liable for any damages arising from the use of this software. Permission is granted to anyone to use this software for any purpose, inclu- ding commercial applications, and to alter it and redistribute it freely, subject to the following restrictions:

1. The origin of this software must not be misrepresented; you must not claim

that you wrote the original software. If you use this software in a product, an acknowledgment in the product documentation would be appreciated but is not required.

2. Altered source versions must be plainly marked as such, and must not be

misrepresented as being the original software.

3. This notice may not be removed or altered from any source distribution.
