| Product type | LED work light |
| Brand | Parkside |
| Model | PAS 10 A3 |
| Power supply | 220–240 V~, 50/60 Hz |
| Rated power | 10 W |
| Light source | 14 LEDs (energy efficiency class F) |
| Luminous flux | 1000 lm (Φ : 910 lm) |
| Protection rating | IP65 (product) / IP44 (mains plug) |
| Protection class | I (equipotential conductor) |
| Dimensions (with bracket) | 20 x 16.5 x 5 cm |
| Weight | 955 g |
| Tilt angle | Up to 180° |
| Usage | Indoor and outdoor (not for permanent indoor lighting) |
| Dimming | Not dimmable |
| Cable type | Non-replaceable power cable |
| Mounting | Floor standing or suspended by hook |
| Package contents | 1 spotlight, 1 instruction manual |
| Warranty | 3 years |
| Customer service | 00800 80040044 (France, Belgium, Switzerland) |
| Maintenance and cleaning | Clean with a dry lint-free cloth; do not immerse |
Frequently Asked Questions - PAS 10 A3 PARKSIDE
User questions about PAS 10 A3 PARKSIDE
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your LED Lighting in PDF format for free! Find your manual PAS 10 A3 - PARKSIDE and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PAS 10 A3 by PARKSIDE.
USER MANUAL PAS 10 A3 PARKSIDE
PAS 10 A3
CZ
PRACOVNÍ LED REFLEKTOR 10 W
Operating and safety information
IT MT CH
LAMPADA DA LAVORO A LED 10 W
GB IE NI CY MT Before you start reading, please fold out the illustrations page and familiarise yourself with all of the item's functions.
Explanation of symbols....38
Intended use 38
Included in package....39
Description of parts....39
Technical data 39
Safety instructions....39
Before first-time use....40
First-time operation....41
Cleaning and storage 41
Disposal 41
Warranty 42
Service 43
HU
Bevezető 43
- Introduction
Congratulations on the purchase of your new product. You have chosen a high-quality product. Please read these operating instructions thoroughly and carefully. These instructions are an essential part of the product and contain important information on first-time use and handling. Always observe all safety instructions. If you have any questions or are unsure how to operate the product, please contact your retailer or service centre. Please keep this manual in a safe place and pass it on to third parties where necessary.
Name of product as referred to below: "Spotlight".
- Explanation of symbols
Read the operating instructions!
Issue date of instruction manual (month/year)
Date of manufacture (month/year)
Direct current
Phi (luminous flux) indicates a light source's light power.
Risk of fatal injury and accidents for infants and children!
Observe warning notices and safety instructions!
Caution! Risk of skin burns from hot surfaces!
Warning!
Risk of electric shock!
Not suitable for indoor lighting
Not dimmable
Lamp suitable for rugged use
Cable length
(Product)
(Power plug)
Protected against ingress of dust (dust-proof, fully contactproof) and jet proofed from any direction.
Protected against solid foreign objects with a diameter of ≥ 1.0 mm, splash-proof
Protection class I: the user and third parties are protected against electric shock by a protective earth (PE) conductor.
A cracked protective cover must always be replaced. Discontinue use of the product immediately if damaged in any way, and contact the service address.
The "GS" symbol stands for safety-tested. Products that are marked with this symbol meet the requirements of the German Product Safety Act (Produktsicherheitsgesetz). Dispose of packaging and product in an environmentally friendly manner!
Packaging made of FSCcertified wood mix
With the CE label, the manufacturer confirms that this product complies with the applicable European directives.
- Intended use
The product is not intended for use as a hand-held light. The lamp can withstand extremely high levels of physical stress in the form of shocks (1 m ^2 /s ^3 , 200 - 2,000 Hz).
This product is intended for use in private households only. Suitable for indoor and outdoor use. Any type of use other than that described above or any modification of the product is prohibited and likely to cause damage or even personal injury. The manufacturer or retailer accepts no liability for loss or damage that occurs as a result of use other than intended or incorrect use. This product uses a light source with a Class F energy efficiency rating.
- Included in package
1 x LED work spotlight 10 W
1 x Instruction manual
• Description of parts
1 Handle
2 Hook
3 Lamp
4 Hand knob
5 Stand
6 LED module
7 Mains connector
- Technical data
Model number: 1084-AL
Power supply 220-240 V\~
voltage: 50/60 Hz
Light source: 14 x LED
Power consumption: 10 W
Luminous power: 1000 lm (Φ : 910 lm)
Protection rating: IP65 (Product) IP44 (Mains connector)
Protection class: I
Maximum projection area: 33.90 cm²
Weight: 955 g
Dimensions: 20 x 10,5 x 5 cm (including stand)
- Safety instructions
Safety instructions
!WARNING!
RISK OF FATAL INJURY AND ACCIDENTS FOR INFANTS AND
CHILDREN! Never leave children unsupervised with the packaging material. There is a danger of suffocation from the packaging material. Children often underestimate the dangers. Always keep children away from the product.
This product may be used by children aged 8 years or above and by persons with limited physical, sensory or mental capabilities or lacking in experience and knowledge if they are supervised or have been instructed as to the safe use of the product and understand the resulting risks. Do not let children play with the product. Cleaning and maintenance may not be carried out by children without proper supervision.
- Keep children under the age of 8 away from the product's power cable.
- Do not leave the product unattended while in use.
AVOID THE RISK OF FATAL INJURY FROM ELECTRIC SHOCK!
■ Always check the product for any damage before connecting it to the mains power supply. Never use the product if it has any signs of damage.
■ Protect the mains power cable from sharp edges, mechanical stress and hot surfaces.
■ Never touch the mains adapter if your hands are wet.
- When connecting or disconnecting the cable to/from the power supply, only hold the insulated part of the mains plug!
■ Never carry the product by the mains power cable.
■ The power cable of this product cannot be
replaced; if it is damaged, the product must be disposed of.
■ Fully unwind the cable before using the product.
- You should only connect the product to an easily accessible power outlet socket so that you can quickly disconnect it from the power supply in the event of a fault.
■ Always unplug the mains power cable before assembling, dismantling or cleaning the product.
■ Always disconnect the product from the mains power supply if it is not going to be used for an extended period (e.g. holiday) or if you want to set it up in a different place.
- Do not immerse the product in water or any other liquids.
- Keep the product away from naked flames and hot surfaces.
■ Never tamper with or modify the product.
- Do not open up the casing and only have the product repaired by qualified professionals. To that end you should contact a specialist repairer. No liability or warranty claims are accepted in cases where repairs have been carried out by unauthorised persons or the product has been incorrectly wired or used.
Before using the product, make sure that the mains power supply voltage matches the supply voltage required by the product (see „Technical data“).
AVOID THE RISK OF FIRE AND INJURY!
RISK OF BURNS FROM HOT
SURFACES! To avoid the risk of burns, make sure that the product is
switched off and has cooled down before you touch it. Light sources generate a large amount of heat.
- Do not cover over the product with other objects. Excessive heat build-up can cause a fire.
- Do not leave the product unattended while in use. Excessive heat build-up can cause a fire.
RISK OF INJURY! Incorrect handling of the product may potentially result in personal injury.
The LED module 6 cannot be dimmed.
■ Never look directly into the light source (illuminant, LED, etc.). Never look at the light source (illuminant, LED, etc.) through an optical instrument (e.g. magnifying glass).
- Should the protective cover be split or cracked, it must be replaced.
■ Never direct the LED light beam at reflective surfaces or towards people or animals.
Failure to follow the above instructions may cause people or animals to suffer eye injuries and/or to lose their sight. Even a weak LED light beam is capable of causing eye damage.
RISK OF DAMAGE! Improper handling of the product may result in damage to the product.
■ The light source may only be replaced by the manufacturer, service technician or a similarly qualified person.
- Do not use the product if you notice any damage.
- Before first-time use
Please note: Take the product out of its packaging and remove all packing material.
- Check that all package contents are present.
- Check if the product or individual parts are damaged. Should you detect damage, do not use the product. Please contact the retailer via the service address indicated.
Setting up your product
The handle 1 (see Fig. A) is intended for
moving the product to a different position. The product must be disconnected from the power supply while it is being moved.
Please note: Protect easily damaged surfaces before setting up the product.
Fully unwind the power cable.
Loosen the hand knobs 4 on either side of the product (left and right) by turning them counter-clockwise in order to position the stand 5 as desired (see Fig. B).
You can tilt the lamp head 3 continuously at any angle of up to 180°.
Simply fix it in position by tightening the hand knobs 4 (see Fig. B).
Set up the product in the desired place.
- First-time operation
Turning the product on/off
TRIPPING HAZARD! Please make sure that the power cable is positioned in such a way that
nobody can tread on or trip over it.
Plug the mains connector 7 into a socket that has been correctly installed to switch the product on.
Please note: When using the product outdoors, use an IPX4 socket for the mains connection to ensure splash protection.
To turn the product off, disconnect the mains connector from the power outlet.
Using the hook
RISK OF ELECTRIC SHOCK!
Before moving the product to another position, disconnect it from the power outlet.
Use the hook 2 to hang the product (see Fig. A). Make sure that you only hang the product to an object that is capable of bearing the product's weight.
Please note: Pay attention to the length of the cable.
- Cleaning and storage
RISK OF ELECTRIC SHOCK!
Always unplug the mains power cable from the socket before cleaning the product.
For reasons of electrical safety, the product must never be cleaned with abrasive cleaning agents or immersed in water.
RISK OF BURNS FROM HOT SURFACES! Allow the light bulb to cool down completely.
- Do not use any solvents, petrol or the like. Doing so would damage the product.
Use only a dry, lint-free cloth for cleaning. If the product is very dirty, dampen the cloth slightly.
- Disposal
Note the labels on the packaging materials when sorting the waste; they are marked with abbreviations (a) and numbers (b) with the following meanings:
1-7: Plastics
20-22: Paper and cardboard 80-98: Composite materials
You can find out how to dispose of the used product by contacting your local district or city council.
The product and packaging materials are recyclable. Please dispose of them separately for better treatment of waste. The Triman logo is only applicable to France.
In the interest of environmental protection, when the product has reached the end of its useful life, do not dispose of it as general household waste but have it properly recycled. For information on recycling centres and their opening times, please contact your local council.
- Warranty
Dear customer, This product comes with a 3-year warranty from the date of purchase. In the event that this product is faulty, you have legal rights against the seller of the product. These statutory rights are not restricted by our warranty as set out below.
Warranty terms
The warranty period begins with the date of purchase. Please keep the original receipt in a safe place. It is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase, we will repair or replace the product for you free of charge, or refund the purchase price, at our discretion. This warranty service is granted provided that the faulty device and the proof of purchase (receipt) are presented within three years, along with a brief written description of the fault and of when it occurred. If the fault is covered by our warranty, we will return the fixed product or send you a new one. No new warranty period shall begin upon repair or replacement of the product.
Warranty period and statutory warranty claims
The warranty period is not renewed after a warranty service has been granted. This rule shall also apply for any replaced or repaired parts. Any damage or faults that already existed when buying the product must be reported immediately upon unpacking the product. A fee is charged for any repairs that are carried out after the end of the warranty period.
Warranty scope
The device was carefully manufactured according to the strictest quality guidelines and thoroughly tested before delivery. The warranty applies to material or manufacturing defects. This warranty does
not apply to product parts that are subject to normal wear and tear and can therefore be regarded as wearing parts, or damage to fragile parts, such as switches, rechargeable batteries or parts that are made of glass. This warranty is void if the product has been damaged, improperly used or serviced. To ensure proper use, all instructions included in the manual must be followed carefully. All uses and actions that users are discouraged from or warned of in the manual must be avoided under all circumstances. The product is intended for private household use only, and not for commercial activities. The warranty is void, if the product is treated inappropriately, if force is applied, and in the case of any manipulation that is not carried out by our authorised service branch.
Warranty processing
To ensure your request is handled swiftly, please observe the following
Notes:
Please have the receipt and the article number (e.g. IAN 123456) ready as proof of purchase for all enquiries.
Please refer to the type plate on the product, an engraving on the product, the cover of the manual (bottom left) or the sticker on the back or base of the product to find out the product number.
In the case of any malfunctions or other defects, please call or email the service department indicated below as a first step.
After your product has been registered as faulty, you can send it to the specified service address, free of charge. Please include the proof of purchase (receipt) and information about the defect and about when it occurred.
- Service
GB
Service Great Britain
Tel.: 00800 80040044
E-Mail: administration@mynetsend.de
IE NI
Service Ireland
Tel.: 00800 80040044
E-Mail: administration@mynetsend.de
CY
Service Cyprus
Tel.: 00800 80040044
E-Mail: administration@mynetsend.de
MT
Service Malta
Tel.: 00800 80040044
E-Mail: administration@mynetsend.de
IAN 380703\_2110
Please have the receipt and the article number (e.g. IAN 123456) ready as proof of purchase for all enquiries.
You can find an up-to-date version of the operating instructions at: www.citygate24.de
