USER MANUAL Tour ANC 00184025 HAMA

“Tour ANC” Bluetooth

G Operating instruction Controls and Displays

1. Volume +/Next song

2. Volume -/Previous song

3. ANC ON LED indicator

10. Micro-USB charging socket

Thank you for choosing aHama product. Take your time and read the following instructions and information completely.Please keep these instructions in asafe place for futurereference. If you sell the device, please pass these operating instructions on to the new owner.

1. Explanation of Warning Symbols and Notes

Warning This symbol is used to indicate safety instructions or to draw your attention to specichazards and risks. Note This symbol is used to indicate additional information or important notes.

• 1xMicro-USB charging cable

• 1x3.5-mm stereo AUX cable with microphone

• These operating instructions

• The product is intended for private, non-commercial use only.

• Protect the product from dirt, moistureand overheating, and only use it in adry environment.

• Donot drop the product and do not expose it to any major shocks.

• Donot operate the product outside the power limits given in the specications.

• Donot open the device or continue to operate it if it becomes damaged.

• Since the battery is integrated and cannot be removed, you will need to dispose of the product as awhole. Do this in compliance with the legal requirements.

• Dispose of packaging material immediately according to locally applicable regulations.

• Donot modify the product in any way.Doing so voids the warranty. Warning -Battery

• Only use suitable charging devices or USB connections for charging.

• Asarule, do not charge devices or USB connections that are defective and do not try to repair them yourself.

• Donot overcharge the product or allow the battery to completely discharge.

• Avoid storing, charging or using batteries in extreme temperatures.

• When stored over along period of time, batteries should be charged regularly (at least every three months). Warning -High volumes

• Toprevent hearing loss, avoid listening at high volume levels for long periods.

• Always keep the volume at areasonablelevel. Loud volumes, even over short periods, can cause hearing loss.

• Using this product limits your perception of ambient noise. Forthis reason, do not operate any vehicles or machines while using this product.

• The headset is equipped with arechargeablebattery.The battery must be fully charged beforeusing the device for the rst time.

• Ensurethat the headset is switched off beforecharging it.

• Begin charging by connecting the included USB charging cable to the charging socket (10) as well as to the USB connection of aPC/laptop.

• Alternatively,you can charge the headset using asuitable USB charger.Please refer to the operating instructions for the USB charger used.

• The LED (9) is constantly lit redduring charging.

• Ittakes around 2-3 hours until the battery is completely charged.

• Once the charging process is complete, the LED (9) is lit green.

• Disconnect all cable and mains connections after use.3 Note

connection remains available during charging.

• Ifthe battery level is low when using the headset, avoice says ‘Low Battery’.Connect the headset to asuitable USB port using the charging cable.

Switching the headset off/on

• Press and hold the MFB button (6) for about 3seconds until avoice says ‘Hello’ and the LED (5) ashes alternating red and blue.

• Toswitch the device off,press and hold the MFB button (6) for about 5seconds until avoice says ‘Goodbye’ and the red LED (5) ashes and goes out. Note The functions described in this section areonly available for Bluetooth

• Make surethat your Bluetooth

-capable terminal device is on and Bluetooth

• Make surethat your Bluetooth

-capable terminal device is visible for other Bluetooth

• For moreinformation, please refer to the operating instructions of your terminal device.

• The headset and the terminal device should not be any further than 1metreaway from each other.The smaller the distance, the better.

• Switch the headset on using the MFB button (6).

• Press and hold the MFB button (6) for about 5seconds until avoice says ‘Hello’ and the LED (5) ashes alternating redand blue. The headset is searching for aBluetooth

settings on your terminal device and wait until Hama BTH TOUR ANC appears in the list of Bluetooth

• Select Hama BTH TOUR ANC and wait until the headset is listed as connected in the Bluetooth

settings on your terminal device. Note –Bluetooth

password Some terminal devices requireapasswordinorder to connect to another Bluetooth

• Ifyour terminal device requests apasswordfor connection with the headset, enter 0000. Note

• Ifthe connection was successful, the LED (5) ashes and a voice says ‘Your device is connected’.

• Ifthe connection attempt takes longer than 600 seconds to complete, it is cancelled and the LEDs go out. In this case, repeat the steps listed previously under 5.1 Bluetooth

connection (after successful pairing) Note

• Make surethat your Bluetooth

-capable terminal device is on and Bluetooth

• Make surethat your Bluetooth

-capable terminal device is visible for other Bluetooth

• For moreinformation, please refer to the operating instructions of your terminal device.

• Switch the headset on using the MFB button (6). The blue LED begins to ash and the headset automatically connects with the last terminal device used. Note

• Ifthe connection was successful, the LED (5) ashes and a voice says ‘Your device is connected’.

• Ifthe connection attempt takes longer than 600 seconds to complete, it is cancelled and the LEDs go out. In this case, repeat the steps listed previously under 5.1.

• Itmay be necessary to make settings on your terminal device to enable automatic connection with the paired headset.4 Note –Connection impaired After the headset and terminal device have been paired, a connection is established automatically.Ifthe Bluetooth

connection is not established automatically,check the following:

settings of your terminal device to see whether Hama BTH TOUR ANC is connected. If not, repeat the steps listed under 5.1. Bluetooth

• The performance can also be affected by aweak battery. 5.3. Bluetooth

multipoint connection This headset can be connected with two Bluetooth

-enabled terminal devices simultaneously.

• First connect the headset withthe rst terminal device as described in 5.1.

on that terminal device.

• Next, connect the headset with the second terminal device as described in 5.1.

on the rst terminal device once more. The headset now connects to that terminal device automatically. 5.4. Audio playback Note

• Note that the functions described under 5.4.and 5.5.are only possible with an active Bluetooth

• Your terminal device must also support the individual functions.

• For moreinformation, please refer to the operating instructions of your terminal device.

• Functions can still be controlled directly via the terminal device.

• Set the volume on your terminal device to alow level.

• Ifthe connection was successful, avoice says ‘Your device is connected’ and the blue LED (5) ashes.

• Start audio playback on the connected terminal device.

• Press Volume + (1) to increase the volume.

• Press Volume -(2) to reduce the volume.

• Press the MFB button (6) to start or pause audio playback.

• Press and hold Volume + (1) to skip to the next title.

• Press and hold Volume - (2) to skip to the previous title. 5.5. Hands-free function

• Press the MFB button (6) once to answer an incoming call.

• Press the MFB button(6) twice or use your telephone to reject an incoming call.

• During acall, press the MFB button (6) once to end the call. Note –Call quality To increase the call quality,make surethat you arenear the headset with your mobile phone during the call. 5.6. ANC function This headset comes with anoise cancelling function (ANC) to reduce unwanted ambient noise (for example, the noise of an air-conditioning system). To switch on the function, press and hold the ANC button (4) until the LED (3) lights up. To switch this function off again, press the ANC button (4) once more. The LED (4) goes out. 5.7. Audio input socket In addition to connecting this headset via Bluetooth

,you can connect it using the included AUX cable. To do so, insert one end of the cable into the terminal device and the other end into the Audio input socket (6) on the left side of your headset. The Bluetooth

connection is automatically ended when you plug in the audio cable. The headset now functions as awired headset. 5.8. Disconnecting the headset

• Switch the headset off.

• Disconnect the headset via the Bluetooth

settings on your terminal device.

6. Care and Maintenance

Only clean this product with aslightly damp, lint-free cloth and do not use aggressive cleaning agents. Make surethat water does not get into the product.

7. Warranty Disclaimer

Hama GmbH &CoKG assumes no liability and provides no warranty for damage resulting from improper installation/mounting, improper use of the product or from failuretoobserve the operating instructions and/or safety notes.

8. Service and Support

Please contact Hama Product Consulting if you have any questions about this product. Hotline: +49 9091 502-115 (German/English) Further support information can be found here: www.hama.com5

technology v4.1 +EDR Prole HFP V1.6 /HSP V1.2 /A2DP V1.2/

20h/18h Talking time /Music playback time with Bluetooth

Note on environmental protection: After the implementation of the European Directive 2012/19/EU and 2006/66/EU in the national legal system, the following applies: Electric and electronic devices as well as batteries must not be disposed of with household waste. Consumers areobliged by law to return electrical and electronic devices as well as batteries at the end of their service lives to the public collecting points set up for this purpose or point of sale. Details to this aredened by the national law of the respective country.This symbol on the product, the instruction manual or the package indicates that aproduct is subject to these regulations. By recycling, reusing the materials or other forms of utilising old devices/Batteries, you aremaking an important contribution to protecting our environment.

11. Declaration of Conformity

Hereby,Hama GmbH &CoKG declares that the radio equipment type [

]isincompliance with Directive 2014/53/EU.The full text of the EU declaration of conformity is available at the following internet address: www.hama.com ->

->Downloads. Frequency band(s) 2402MHz –2480 MHz Maximum radio-frequency power transmitted

(couplage) Remarque –Couplage

v4.1 +EDR Prols HFP V1.6 /HSP V1.2 /A2DP V1.2/

HFP V1.6 /HSP V1.2 /A2DP V1.2/

3. Led-indicator ANC IN

wordmarkand logosare registe re dtrademarksowned by Bluetooth SIG, Inc. andany useofsuchmarks by Hama GmbH &CoKGisunder license. Other trademarksand tradenames are thoseoftheirrespectiveowners.
