USER MANUAL HTW5618ENPT HAIER

User Manual Refrigerator-Freezer *=colour code: PT, MG, MP, PD, PK, PW

Символът показва, че съществува опасност от пожар, тъй като се използват запалими материали. Внимавайте да не предизвикате пожар чрез подпалване на запалим материал. Symbolen indikerar att det finns en brandrisk eftersom brandfarliga material används. Var försiktig för att undvika att brandfarliga material fattar eld. UPOZORENJE: opasnost od požara / zapaljivog materijala HR Simbol označava opasnost od požara jer se upotrebljavaju zapaljivi materijali. Pazite da ne prouzročite požar paljenjem zapaljivog materijala. VAROVANIE: Riziko požiaru/horľavý materiál SK Symbol označuje nebezpečenstvo požiaru, pretože sa používajú horľavé materiály. Dávajte pozor, aby ste zabránili vzniku požiaru vznietením horľavého materiálu.EN Contents 5 Safety information 10 Intended use 11 Product description 15 Control panel 24 Equipment 28 Energy saving tips 29 Care and cleaning 32 Troubleshooting 36 Installation 16 Use 40 Technical data 46 Customer service Please click the contents to look at the detail information. Before rst use 6 Installation 6 Daily use 7 Adjust the temperature for fridge 17 Adjust the temperature for freezer 17 Adjust the temperature for My Zone 17 Super-Cool function 18 Super-Frz function 19 3EN Thank you Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance. Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the appliance. If you sell the appliance, give it away, or leave it behind when you move house, make sure you also pass this manual so that the new owner can become familiar with the appliance and safety warnings. Hinge Cover Accessories Check the accessories and literature in accordance with this list: Energy lable User manualWarranty card Ice cube tray Egg tray Door hinges Cap insert 4EN WARNING – Important Safety information NOTICE-General information and tips Environmental information Safety information Disposal Help protect the environment and human health. Put the packaging in applicable containers to recycle it. Help to recycle waste of electrical and electronic appliances. Do not dispose appliances marked with this symbol with the house- hold waste. Return the product to your local recycling facility or contact your municipal oce. WARNING! Risk of injury or suocation! Refrigerants and gases must be disposed of professionally. Ensure that the tubing of the refrigerant circuit is not damaged before being properly disposed of. Disconnect the appliance from the mains supply. Cut o the mains cable and dispose of it. Remove the trays and drawers as well as the door catch and seals, to prevent children and pets to get closed in the appliance. 5EN Safety information Before switching on the appliance for the rst time read the following safety hints!: WARNING! Before rst use ▶ Make sure there is no transport damage. ▶ Remove all packaging and keep out of children´s reach. ▶ Wait at least two hours before installing the appliance in order to ensure the re- frigerant circuit is fully ecient. ▶ Handle the appliance always with at least two persons because it is heavy. Installation ▶ The appliance should be placed in a well-ventilated place. Ensure a space of at least 10 cm above and around the appliance. ▶ Never place the appliance in a damp area or location where it might be splashed with water. Clean and dry water splashes and stains with a soft clean cloth. ▶ Do not install the appliance in direct sunlight or in the near of heat sources(e.g. stoves, heaters). ▶ Install and level the appliance in an area suitable for its size and use. ▶ Keep ventilation openings in the appliance or in the in-built structure clear of obstruction. ▶ Make sure that the electrical information on the rating plate agrees with the power supply. If it does not, contact an electrician. ▶ The appliance is operated by a 220-240 VAC/50 Hz power supply. Abnormal voltage uctuation may cause the appliance to fail to start, or damage to the temperature control or compressor, or there may be an abnormal noise when operating. In such case, an automatic regulator shall be mounted. ▶ Do not use multi-plug adapters and extension cables. ▶ Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. ▶ Ensure that the power cable is not trapped by the refrigerator. Do not step on the power cable. 6EN Safety information WARNING! ▶ Use a separate earthed socket for the power supply which is easy accessible. The appliance must be earthed. Only for UK: The appliance’s power cable is tted with 3-cord (grounding) plug that ts a standard 3-cord (grounded) socket. Never cut o or dismount the third pin (grounding). After the appliance is installed, the plug should be acces- sible. ▶ Do not damage the refrigerant circuit. Daily use ▶ This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. ▶ Children aged from 3 to 8 years are allowed to load and unload, but not allowed to clean or install the refrigerating appliances. ▶ Keep away children under 3 years of age from the appliance unless they are con- stantly supervised. ▶ Children shall not play with the appliance. ▶ If cool gas or other inammable gas is leaking in the vicinity of the appliance, turn o the valve of the leaking gas, open the doors and windows and do not unplug a plug in the power cable of the refrigerator or any other appliance. ▶ Notice that the appliance is set for operation at a specic ambient range be- tween 10 and 43°C. The appliance may not work properly if it is left for a long period at a temperature above or below the indicated range. ▶ Do not place unstable articles (heavy objects, containers lled with water) on top of the refrigerator, to ovoid personal injury caused by falling or electric shock caused by contact with water. ▶ Do not pull on the door shelves. The door may be pulled slant, the bottle rack, may be pulled away, or the appliance may topple. ▶ Open and close the doors only with the handles. The gap between the doors and between the doors and the cabinet is very narrow. Do not extend your hands in these areas to avoid pinching your ngers. Open or close the refrigerator doors only when there are no children standing within the range of door movement. 7EN Safety information WARNING! ▶ Do not store or use inammable, explosive or corrosive materials in the appli- ance or in the vicinity. ▶ Do not store medicines, bacteria or chemical agents in the appliance. This ap- pliance is a household appliance. It is not recommended to store materials that require strict temperatures. ▶ Never store liquids in bottles or cans (besides high percentage spirits) especially carbonated beverages in the freezer, as these will burst during freezing. ▶ Check the condition of food if a warming in the freezer has taken place. ▶ Do not set unnecessarily low temperature in the refrigerator compartment. Mi- nus temperatures may occur at high settings. Attention: Bottles can burst ▶ Do not touch frozen goods with wet hands (wear gloves). Especially do not eat ice lollies immediately after removal from the freezer compartment. There is the risk to freeze or the formation of frost blisters. FIRST aid: keep immediately un- der running cold water. Do not pull away! ▶ Do not touch the inside surface of the freezer storage compartment when in operation, especially with wet hands, as your hands may freeze onto the surface. ▶ Unplug the appliance in the event of a power interruption or before cleaning. Al- low at least 7 minutes before restarting the appliance, as frequent starting may damage the compressor. ▶ Do not use electrical devices inside the food storage compartments of the ap- pliance, unless they are of the type recommended by the manufacturer. Maintenance / cleaning ▶ Make sure children are supervised if they carry out cleaning and maintenance. ▶ Disconnect the appliance from the electrical supply before undertaking any rou- tine maintenance. Allow at least 5 minutes before restarting the appliance, as frequent starting may damage the compressor. 8EN Safety information WARNING! ▶ Hold the plug, not the cable, when unplugging the appliance. ▶ Do not clean the appliance with hard brushes, wire brushes, detergent powder, petrol, amyl acetate, acetone and similar organic solutions, acid or alkaline solu- tions. Please clean with special refrigerator detergent to avoid damage. ▶ Do not scrape o frost and ice with sharp objects. Do not use sprays, electric heaters like heater, hair dryer, steam cleaners or other sources of heat in order to avoid damage to the plastic parts. ▶ Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. ▶ If the supply cord is damaged, it must be replaced by the manufacturer, its ser- vice agent or similarly qualied persons in order to avoid a hazard. ▶ Do not try to repair, disassemble or modify the appliance by yourself. In case of repair please contact our customer service. ▶ Eliminate the dust on the back of the unit at least once in the year to avoid haz- ard by re, as well as increased energy consumption. ▶ Do not spray or ush the appliance during cleaning. ▶ Do not use water spray or steam to clean the appliance. ▶ Do not clean the cold glass shelves with hot water. Sudden temperature change may cause the glass to break. WARNING! The appliance contains the ammable refrigerant ISOBUTANE (R600a). Make sure the refrigerant circuit is not damaged during transportation or installation. Leaking refrigerant may cause eye injuries or ignite. If a damage has occurred, keep away open re sources, thoroughly ventilate the room, do not plug or unplug the power cords of the appliance or any other appliance. Inform the customer service. In case of eyes get into contact with the refrigerant, rinse immediately it under running water and call immediately the eye specialist. Refrigerant gas information 9EN Intended use Intended use This appliance is intended for cooling and freezing food. It has been designed exclusively for use in household and similar applications such as sta kitchen areas in shops, oces and other working environments; farm houses and by clients in hotels, motels and other residential type environments as well as in bed-and-bre- ackfast and catering business. It is not intended for commercial or industrial use. Changes or modications to the device are not allowed. Unintended use may cause hazards and loss of warranty claims. Standards and directives This product meets the requirements of all applicable EC directives with the corre- sponding harmonised standards, which provide for CE marking. 10EN Product description NOTICE Due to

t models, some of the illustrations in this manual may differ from model. (HTW5620EN*, HTW5620DN*, HTW5620CN*)

9- frUpper eezer storage drawer

10-Freezer tray 11-Lower freezer storage drawer 12-Adjust le feet

13-Door b lcony 11EN Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HTW5618DN*, HTW5618CN*, HTW5618EN*) 1-Refrigerator LED lamp 2-Wine rack 3-Foldable shelf 4-Hu4- midity Zone drawer c 5-Humidity Zone drawer 6-My Z ne drawer covero 7-My Zone drawer Upper freezer storage drawer8- 9-Freeze trayr 10-Lower freezer storage drawer 11-Adjus le feet bal tab 12-Door cony

12EN Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HTW3620EN*, HTW3620DN*, HTW3620CN*) 1-Refrigerator LED lamp 2-Glass shelf 3-Glass shelf 4-Glass shelf 5-Glass shelf 6-My Zone drawer cover 7-My Zone drawer 8-Upper freezer storage drawer 9-Freezer tray 10-Lower freezer storage drawer 11-Adjustable feet 12-Door balcony

949EN Product description NOTICE Due to technical changes and different mod els, some of the illustrations in this manual may differ from model. (HTW3618EN*, HTW3618DN*, HTW3618CN*) 1-Refrigerator LED lamp 2-Glass shelf 3-Glass shelf 4-Glass shelf 5-My Zone drawer cover 6-My Zone drawer 7-Upper freezer storage drawer 8-Freezer tray 9-Lower freezer storage drawer 10-Adjustable feet 11-Door balcony

950EN Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HDPW5620DN*, HDPW5620CN*, HDPW5620BN*, HDPW5620AN*) 1-Refrigerator LED lamp 2-Wine rack 3-Glass shelf 4-Foldable shelf

7-My Zone drawer cover 8-My Zone drawer

9- frUpper eezer s rage drawer

10-Middle freezer storage drawer 11-Lower freezer storage drawer 12-Adjustable feet 13-Door balcony

15EN Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HDPW5618DN*, HDPW5618CN*) 1-Re igerator LED lampfr 2-W e rackin 3-Fo able shelfld 4-H idity Zone drawer coverum 5-Humidity Zone drawer 6-My Zone drawer cover 7-My Zone drawer 8-Up er freezer storage drawerp 9-Middle freezer storage drawer 10-Lower freezer storage drawer

16EN Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HDPW3620DN*, HDPW3620CN*)

1-Refrigerator LED lamp 2-Glass shelf 3-Glass shelf 4-Glass shelf 5-Glass shelf 6-My Zone drawer cover 7-My Zone drawer 8-Upper freezer storage drawer 9-Middle freezer storage drawer 10-Lower freezer storage drawer 11-Adjustable feet 12-Door balcony 953EN Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HDPW3618DN*, HDPW3618CN*)

1-Refrigerator LED lamp 2-Glass shelf 3-Glass shelf 4-Glass shelf 5-My Zone drawer cover 6-My Zone drawer 7-Upper freezer storage drawer 8-Middle freezer storage drawer 9-Lower freezer storage drawer 10-Adjustable feet 11-Door balcony 954EN Control panel Control panel Before rst use Remove all packaging materials, keep them out of children’s reach and dispose them in an environment friendly way. Clean the inside and outside of the appliance as well as the interior and accessories with water and a mild detergent, and dry it well with soft cloth. After the appliance has been levelled and cleaned, please wait for at least 2 hours before connecting it to the power supply. See Section INSTALLATION. Precool the compartments at high settings before loading with food. The function Super Freeze helps to cool down the freezer compartment quickly

Eco ModeWi-FiHolidaySuper FreezeSuper Cool ZONE ARTIFICIALINTELLIGENCE Fridge My Zone Freezer Indicators: A Fridge compartment B Chill compartment (My Zone) C Freezer compartment D Temperature display E Super Cool function F Super Freeze function G Holiday function H Eco Mode function I Wi-Fi function Buttons: K1 Decrease temperature K2 Fridge, My Zone and Freezer selection K3 Super Cool function on/o K4 Super Freeze function on/o K5 Holiday function on/o K6 Eco Mode function on/o K7 Wi-Fi function on/o K8 Increase temperature 19EN Use NOTICE The appliance is preset to the recommended temperature of 5℃ (refrigerator) and -18℃(freezer). My Zone temperature is preset to about 2℃. These are the recom- mended settings. If desired, you can change these temperatures manually. Sensor keys The buttons on the control panel are sensor keys, which already respond when lightly touched with the nger. Switch on /o the appliance The appliance is in operation as soon as it is connected to the power supply. When the appliance is powered on for the rst time, temperature indicators “D” shows the presetting values (refer to the below Notice). Adjust the temperature The indoor temperatures are inuenced by the following factors: ▶ Ambient temperature ▶ Frequency of door opening ▶ Amount of stored foods ▶ Installation of the appliance Door opening alarm When the refrigerator door is open for more than 3 minutes, the door opening alarm will sound. The alarm can be silenced by closing the door. If the door is open for more than 7 minutes, the light inside the refrigerator and control panel illumination will automat- ically turn o. 20EN Use Adjust the temperature for fridge

1. Press the button “K2” (Fridge/ (My Zone)/ Freezer selection) to select the Fridge

compartment. Icon “A” (Fridge compartment) and “D” (Temperature display) are bright.

2. Press the button “K1/K8” to set the fridge temperature.

The temperature increases in sequences of 1°C, from a minimum of 2°C to a max- imum of 8°C. The optimal temperature in the refrigerator is 5°C.Colder tempera- tures mean unnecessary energy consumption.

3. After about 5s, temperature icon “D” (Temperature display) will be bright perma-

nently and the setting is conrmed. Adjust the temperature for freezer

1. Press the button “K2” (Fridge/ (My Zone)/ Freezer selection) to select the freezer

compartment.Icon “C” (Freezer compartment) and “D” (Temperature display) are bright.

2. Press the button “K1/K8” to set the freezer temperature.

The temperature increases in sequences of 1°C, from a minimum of -24°C to a maximum of -16°C. The optimal temperature in the refrigerator is -18°C . Colder temperatures mean unnecessary energy consumption.

3. After about 5s, temperature indicator “D” (Temperature display) will be bright

permanently and the setting is conrmed. Adjust the temperature for My Zone The fridge compartment is equipped with a My Zone drawer. In accordance with the food storage demands, the most suitable temperature can be selected to get the optimal nutritional value of the foods.

1. Press the button “K2” (Fridge/ (My Zone)/ Freezer selection) to select the My

Zone compartment. Icon “B” (My Zone compartment) and “D” (Temperature dis- play) are bright.

2. Press the button “K1/K8” to set the My Zone temperature.

The temperature increases in sequences of 1°C, from a minimum of 0°C to a maxi- mum of 5°C.

3. After about 5s, temperature icon “D” (Temperature display) will be bright perma-

nently and the setting is conrmed. 21EN Use NOTICE From the App it is possible to customize the temperature for fridge, freezer and My Zone. The temperature can be set with 1°C sensitivity. NOTICE After setting the temperature, if other buttons are pressed within 5 seconds, the current temperature setting will be conrmed immediately. If no button operation is performed within 5 seconds, the current set temperature is displayed until the screen extinguishes. Super Cool function

1. It is suggested to switch on the Super Cool function if larger quantity of food

should be stored (for example after the purchase). The Super Cool function accelerates the cooling of fresh food and protects the food already stored from undesirable warming.

2. Press button "K3" or turn it on from the App, icon "E" (Super Cool function) is

bright and the function is activated. NOTICE

1. You can set the temperature of the My Zone compartment in the middle level

(2°C), in order to preserve your food in the optimal storage environment.

2. Due to dierent water contents of meat, some meat with higher moisture will

be frozen at temperatures lower than 0°C, so “immediately cut” meat should be stored in My Zone drawer, with minimum temperature 0°C.

Cold-sensitive fruit like pineapples, avocados, bananas, grapefruits and vegeta- bles such as potatoes, aubergines, beans, cucumbers, zucchini and tomatoes and cheese should not be stored in the My Zone drawer. If the fridge temperature lower than My Zone temperature, it is normal the My Zone temperature lower than the My Zone setting temperature. 22EN Use Super Freeze function

1. Fresh food should be frozen as quickly as possible to the core. This can preserve

the best nutritional value, appearance and taste. The Super Freeze function accelerates the freezing of fresh food and protects the food already stored from undesirable warming. If you need to freeze a large amount of food at once, it is recommended to set the Super Freeze function on ahead for 24h before the usage of frozen room.

2. Press button "K4" (Super Freeze function setting) or turn it on from the App, the

icon "F" (Super Freezer function) is bright and the function is activated. Holiday function The Holiday function can be used to reduce the energy consumption of the appliance, when it is not used regularly. When the function is on, the fridge is turned off, whereas the freezer will keep working normally. The function sets the fridge temperature permanently to 17°C. This allows to keep the door of the empty refrigerator closed without causing an odour or mold-during a long absence (e.g. during holiday). The freezer compartment is free for your setting.

1. Press button "K5" (Holiday function on/off) or select the function from the App,

the icon "G" (Holiday function) is bright and the function is activated.

2. The function can be deactivated by pressing button "K5" (Holiday function

on/off) again or by setting the fridge temperature or by performing any other setting, or turning it off from the App. NOTICE

1. The appliance quits "Super Cool function" after entering "Super Cool function"

for 6 hours or pressing button "K3" when the icon "E" (Super Cool function) is bright or turn it off from the App.

2. In the state of Super Cool, if the temperature of the fridge compartment is

adjusted, icon "E" (Super Cool function) flashes to indicate that this operation cannot be done. NOTICE

1. The appliance quits "Super Freeze function" after entering "Super Freeze

function" for 50 hours or pressing button "K4" when the icon "F" (Super Freeze function) is bright or turn it off from the App.

2. In the state of Super Freeze, if the temperature of the freezercompartment is

adjusted, icon "F" (Super Freezer function) flashes to indicate that this operation cannot be done. 23EN Use Eco Mode function The Eco Mode can be activated to optimize the performance of the appliance, whereas obtaining the best food storage. If you do not have any special requirements, we recommend that you use Eco Mode function. This mode the fridge temperature is 5°C, the freezer temperature is -18°C.

2. Icon "H" (Eco Mode function) is bright and the function is activated.

By repeating the above steps or selecting another function or turning off from the App, this function can be switched off again. The previously set cooling levels are restored. NOTICE

1. During the Holiday function, no food should be stored in the fridge

compartment. The temperature of 17°C is too high for storing food.

2. When Holiady function is on, My Zone icon keeps off and fridge function is

locked. If the temperature of the fridge compartment is adjusted, icon "G" (Holiday function) flashes to indicate that this operation cannot be done. NOTICE During the Eco Mode function, if the temperature of the fridge/freezer compartment are adjusted, icon "H" (Eco Mode function) flashes to indicate that this operation cannot be done. 24EN Use NOTICE

1. This product is not intended for commercial use.

1. Follow in App instructions to configure the Wi-Fi.

2. Once the Wi-Fi is configured and the connection established, the Wi-Fi icon "I" is

3. If the Wi-Fi has already been configured, it will automatically reconnect according

to the configuration information if turns on the Wi-Fi. Step 1 Download the hOn-App from the stores. S t e p 2 C r e a t e y o u r a c c o u n t i n t h e hOn-App or log in if you already have an account. Step 3 Follow pairing instructions in the hOn-App. NOTICE 1.To turn off the Wi-Fi, press Wi-Fi button "K7"and the Wi-Fi icon "I" turns off.

2. To turn on the Wi-Fi and start the configuration, press Wi-Fi button "K7" and the

Wi-Fi icon "I" starts flashing slowly. If want to configure Wi-Fi function, press the button "K7" for 3 sec, the Wi-Fi icon flashes quickly and enters the configuration mode. If want to turn off the Wi-Fi function, press button "K7" once.The above steps are repeated.

3. If the product has been configured and the Wi-Fi function was turn off, the

refrigerator will not enter the configuration mode after reconnecting the power. 25EN Use Storing into the refrigerator compartment

• Keep your fridge temperature below 5°C.

• Hot food must be cooled to room temperature before storing in the appliance.

• Foods stored in the refrigerator should be washed and dried before storing.

• Food to be stored should be properly sealed to avoid odor or taste alterations.

• Do not store excessive quantities of food. Leave spaces between foods to allow cold air flowing around them, for a better and more homogeneous cooling.

• Foods eaten daily should be stored at the front of the shelf.

• Leave a gap between foods and the inner walls, allowing air flowing. In any way, don't store foods against the rear wall: foods could freeze against the rear wall. Avoid direct contact of food (especially oily or acidic food) with the inner liner, as oil/acid can erode the inner liner. Clean away oily/acid dirt whenever it is found.

• Frozen food can be gently defrizzed in the refrigerator compartment. This saves energy.

• The ageing process of fruit and vegetables such as courgettis, melons, papaya, bananas, pineapples, etc. can be accelerated in the refrigerator. Therefore, it is not recommended to store them in the refrigerator. However, the ripening of strongly green fruits can be promoted for a certain period. Onions, garlic, ginger and other root vegetables should also be stored at room temperature.

• Unpleasant odours inside the fridge are a sign that something has spilled and cleaning is required. See Care And Cleaning.

• Different foods should be placed in different areas according to their properties. Storage into the freezer compartment

• Keep the freezer temperature at- 18°C.

• 24 hours before freezing, switch on the Super-Freeze function. For little quantities of food, 4-6 hours are sufficient.

• Hot food must be cooled to room temperature before storing in the freezer compartment.

• Food cut into small portions will freeze faster and be easier to defrost and cook. The recommended weight for each portion is less than 2.5 kg

• It is better to pack food before putting it into the freezer. The outside of the packaging must be dry to avoid bags sticking together. Packaging materials should be odour-free, airtight, non-poisonous and nontoxic.

• In order to avoid expiration of storage periods, please note the freezing date, time limit and name of the food on the packaging according to the storage periods of different foods. 26EN Use WARNING! ▶ Acid, alkali and salt etc. could erode the internal surface of the freezer. ▶ Do not place the food with these substances (e.g. sea sh) directly on the inter- nal surface. Salt water in the freezer should be cleaned up immediately. ▶ Do not exceed the food storage time recommended by the manufacturers. Only take the required amount of food out of the freezer. ▶ Consume defrosted food quickly. Defrosted food cannot be re-frozen unless it is rst cooked, otherwise it may be less edible. ▶ Do not load excessive quantities of fresh food in the freezer compartment. Re- fer to the freezing capacity of the freezer - See TECHNICAL DATA or data at the type plate. ▶ Food can be stored in the freezer at a temperature of at least -18°C for 2 to 12 months, depending on its properties (e.g. meat: 3-12 months, vegetables: 6-12 months) ▶ While freezing fresh food, avoid bringing them in contact with already frozen food. Risk of thawing! When storing commercially frozen foods, please follow these guidelines:

• Always follow manufacturers’ guidelines for the length of time you should store food for. Do not exceed these guidelines!

• Try to keep the length of time between purchase and storage as short as possible to preserve food quality.

• Buy frozen food, which have been stored at a temperature of -18°C or below.

• Avoid buying food which has ice or frost on the packaging - This indicates that the products might have been partially defrosted and refrozen at some point- temperature rising affects the quality of food. 27EN NOTICE shelf areEnsure that all ends of a level. NOTICE Due to different models, your product may not have all of the following features. Please refer to chapter Product Description.l. removed for cleaning: lift the balcony, it upwards Removable door balcony The door balcony can be Place hands on each side of to insert the door balcony, the above steps are carried (1) and pull it out (2). In order out in a reverse order. Multi-air-ow The refrigerator is equipped with a multi- air-flow system, with which cool air flows are located on every shelf level. This helps to maintain a uniform temperature to ensure that your food is kept fresher for longer. Adjustable shelf

1. The height of the shelves can be

adjusted to fit your storage needs.

2. To relocate a shelf, remove it first by

uplifting its hind edge ① and pulling it out ②.

3. To reinstall it, put it on the lugs on both

sides and push it to the most rearward the rear of the shelf is fixed untilposition inside the slots in the sides Equipment 28EN My Zone drawer For using and setting the My Zone compartment , please check section USE (My Zone).. Humidity Zone drawer In this compartment the humidity level is controlled automatically by the system and it is suitable to store fruits, vegetables, salads etc. Removable drawer To remove the drawer out of the fridge or freezer compartment, pull out to the maximum extent (1), lift and remove (2). In order to insert the drawer, the above steps are carried out in a reverse order. Freezer drawer The freezer drawer can be extended straightly and completely. They are mounted on easy roll telescopic rail. So that you can store and remove the freezing good comfortably. Because of the automatic door closing mechanism, the handing is easy and you can save energy. Equipment 29EN WARNING! Do not overload the drawers: Maximum load of each drawer: 35kg! The Light The LED interior light comes on when the door is open. The performance of the lights is not affected by any other appliances settings.. Foldable shelf The foldable shelf will allow the user to put high bottles or items on the shelves. The shelf can be folded at the back and the available space of the lower shelf will be larger. The shelf can be folded following Step 1~3. If want to return to the original location, reverse the following procedures. Step 1: Push the front of the shelf slowly to the end. Step 2: Push the shelf upward slowly to its vertical location. Step 3: The shelf is vertical. It will save space. Equipment 30EN Foldable wine rack For normal use 1.Pull down the brackets of the wine rack 2.Fit the bottles into the rack When not use, the wine rack can be folded back in order to save space. Max:10kg Equipment 31EN Energy saving tips Energy saving tips ▶ Make sure the appliance is properly ventilated (see INSTALLATION). ▶ Do not install the appliance in direct sunlight or near the heat sources (eg. stoves, heaters). ▶ Avoid unnecessarily low temperature in the appliance. The energy consump- tion increases with the decreasing of the setting temperature in the appliance. ▶ Functions like SUPER FREEZE consume more energy. ▶ Allow warm food to cool down before placing it in the appliance. ▶ Open the appliance door as little and briey as possible. ▶ Do not overll the appliance to avoid obstructing the air ow. ▶ Avoid air within the food packaging. ▶ Keep door seals clean so that the door always closes correctly. ▶ Defroze frozen food in the fridge storage compartment or use the D-Frost function in the My Zone drawer. ▶ The most energy-saving conguration requires drawer, food box and shelves to be positioned in the appliance in a factory-fresh condition, and food to be placed without blocking the air outlet of the duct. 32EN Care and cleaning Disconnect the appliance from the power supply before cleaning. Cleaning Clean the appliance when only little or no food is stored. The appliance should be cleaned every four weeks for good maintenance and to prevent bad stored food odors. WARNING! ▶ Do not clean the appliance with hard brushes, wire brushes, detergent powder, petrol, amyl acetate, acetone and similar organic solutions, acid or alkaline so- lutions. Please clean with special refrigerator detergent to avoid damage. ▶ Do not spray or ush the appliance during cleaning. ▶ Do not use water spray or steam to clean the appliance. ▶ Do not clean the cold glass shelves with hot water. Sudden temperature change may cause the glass to break . ▶ Do not touch the inside surface of the freezer storage compartment, especial- ly with wet hands, as your hands may freeze onto the surface. ▶ In case of heating check the condition of frozen goods. WARNING! ▶ Always keep the door gasket clean. ▶ Clean the inside and housing of the applian- ce with a sponge dampened in warm water and neutral detergent. ▶ 1. Please scrub the interior and exterior of the refrigerator, including door sealing, door rack, glass shelves, boxes and so on, with a soft towel or sponge dipped in warm water (you may add neutral detergent into the warm water). Defrosting The defrosting of the refrigerator and the freezer compartment are done automatically; no manual operation is needed. ▶ 2. If there is liquid spilled, remove all the contaminated parts, directly rinse with the ow water, dry and place it back into the fridge. ▶ 3. If there is spilled cream (such as the cream, melting ice cream), please re- move all the contaminated parts, put into the warm water with about 40 °C for some time, then rinse with the ow water, dry and place it back into the fridge. ▶ 4. In case some small part or component gets stuck inside of the fridge (bet- ween shelves or drawers), use small soft brush to release it. If you could not reach the part, please contact Haier service ▶ Rinse and dry with soft cloth. ▶ Do not clean any of the parts of the appliance in a dishwasher. ▶ Allow at least 5 minutes before restarting the appliance as frequent starting may damage the compressor. 33EN Care and cleaning NOTICE Turn the appliance off only if strictly necessary. WARNING! Do not replace the LED lamp yourself, it must only be replaced by either the manufacturer or the authorised service agent. Non-use for a longer period If the appliance is not used for an extended period of time, and you will not use the Holiday-function for the refrigerator: Take out the food. Unplug the power cord. Clean the appliance as described above. Keep the doors open to prevent the creation of bad odours inside. The lamps adopts LED as its light source, featuring low energy consumption and long service life. If there is any abnormality, please contact the customer service . See CUSTOMER SERVICE. Parameters of the lamps: Replacing the LED-lamps Part LED lamp Voltage 12V Max Power 1.5W LED Spec White-2835 LED e󱐲ciency class

Usage temperature -40~80℃ 34EN Care and cleaning WARNING! ▶ Do not lift the appliance by its handles. ▶ Never place the appliance horizontally on the ground. Removable auxiliary door gaskets There are six auxiliary door gaskets on the upper and lower freezer drawers. 1.Locate the five indicated door gaskets on the upper and lower freezer drawers. 2.Make sure the bent slices of the gaskets point inwards while attaching. 3.Loacte the lower gasket of the upper drawer as indicated. 4.Make sure the bent slice of this gasket points downwards while attaching. You get these gaskets as well as the revolving door/drawer gaskets via the customer service(see warranty card). Moving the appliance

1. Remove all food and unplug the appliance.

2. Secure shelves and other moveable parts in the fridge and the freezer with

3. Do not tilt the refrigerator more than 45° to avoid damaging the refrigeration

system. 35EN Troubleshooting Many occuring problems could be solved by yourself without specific expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! ▶ Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.

Electrical equipment should be serviced only by qualied electrical experts, be- cause improper repairs can cause considerable consequential damages. A damaged supply should only be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard. Problem Possible Cause Possible Solution The compressor does not work. Mains plug is not connected in the main socket. Connect the main plug. The appliance is in the defrosting cycle. This is normal for an automatic defrosting. The appliance runs frequently or runs for a too long period of time. The indoor or outdoor temperature is too high. In this case, it is normal for the appliance to run longer. The appliance has been off power for a period of time. Normally, it takes 8 to 12 hours for the appliance to cool down completely. A door/drawer of the appliance is not tightly closed. Close the door/drawer and ensure the appliance is located on a levelled ground and there is no food or container holding the door. The door/drawer has been opened too frequently or for too long. Do not open the door/drawer too frequently. The temperature setting for the freezer compartment is too low. Set the temperature higher until a satisfactory fridge temperature is obtained. It takes 24 hours for the fridge temperature to become stable. The door/drawer gasket is dirty, worn, cracked or mismatched. Clean the door/drawer gasket or replace them through the customer service. The required air circulation is not guaranteed. Ensure adequate ventilation. Troubleshooting table 36EN Troubleshooting Problem Possible Cause Possible Solution The inside of the refrigerator is dirty and/or with smell. The inside of the refrigerator needs cleaning. Clean the inside of the refrigerator. Food with strong odour is stored in the refrigerator. Wrap the food thoroughly. It is not cold enough inside the appliance. The temperature is set too high. Reset the temperature Too warm food have been stored. Always cool down food before storing them. Too much food has been stored at one time. Always store small quantities of food. The foods are too close to each other. Leave a gap between several foods allowing air flowing. A door/drawer of the appliance is not tightly closed. Close the door/drawer. The door/drawer has been opened too frequently or for too long. Do not open the door/drawer too frequently. It is too cold inside the appliance. The temperature is set too low. Reset the temperature. The Super Freeze function is activated or is running too long. Switch off the Super Freeze function. Moisture forming on the inside of the refrigerator compartment. The climate is too warm and too damp. Increase the temperature. A door/drawer of the appliance is not tightly closed. Close the door/drawer. The door/drawer has been opened too frequently or for too long. Do not open the door/drawer too frequently. Food containers or liquids are left open. Let hot foods cool to room temperature and cover foods and liquids. Moisture accumulates on the refrigerators outside surface or between the doors/door and drawer. The climate is too warm and too damp. This is normal in damp climate and will change when the humidity decreases. The door/drawer is not closed tightly. Ensure that he door/drawer is tightly shut. 37EN Troubleshooting Problem Possible Cause Possible Solution Strong ice and frost in the freezer compartment. The foods were not adequately packaged. Always pack the foods well. closed. The door/drawer has been opened too frequently or for too long. Do not open the door/drawer too frequently. The door/drawer gasket is dirty, worn, cracked or mismatched. Clean the door/drawer gasket or replace them by new ones. Something on the inside prevents the door/ drawer to close property. Reposition the shelves, door racks, or internal containers to allow the door/ drawer to close. The appliance makes abnormal sounds. The appliance is not located on levelled ground. Adjust the feet to level the appliance. The appliance touches some object around it. Remove objects around the appliance. A slight sound is to be heard similar to that of flowing water. This is normal. / You will hear an alarm beep. The fridge storage compartment door is open. Close the door or silence the alarm manually. You will near a faint hum. The anti-condensation system is working. This prevents condensation and is normal. The interior lighting or cooling system does not work. Main plug is not connected in the main socket Connect the main plug. The power supply is not intact. Check the electrical supply to the room. Call the local electricity company! The LED-lamp is out of order. Please call the service for changing the lamp. The sides of the cabinet and door strip get warm. This is normal. / No water is coming out of the water dispenser spout Lock is not deactivated. Deactivate the lock 38EN Troubleshooting NOTICE Memory function during power interruption After the recovery of power, the appliance continues with the settings that were set before the power failure. To contact the technical assistance, visit our website: https://corporate.haier-eu- rope.com/en/ Under the section “website”, choose the brand of your product and your country. You will be redirected to the specic website where you can nd the telephone number and other ways to contact the technical assistance. Power interruption ▶ In the event of a power cut, food should remain safely cold for about 13 hours. Follow these tips during a prolonged power interruption, especially in summer. ▶ Do not put additional food into the appliance during a power interruption. ▶ If prior notice of a power interruption is given and the interruption duration is longer than 13 hours, make some ice cubes and put them in a container on the top shelf of the refrigerator compartment. ▶ An inspection of the foods is required immediately after the interruption. ▶ As temperature in the refrigerator will rise during a power interruption or other failure, the storage period and edible quality of food will be reduced. Any food that defrosts should be either consumed, or cooked and refrozen (where suit- able) soon afterwards in order to prevent health risks. 39EN Installation Unpacking Environmental conditions The room temperature should always be between 10° C and 43° C, since it can inuence the temperature inside the appliance and its energy consumption. Do not install the appliance near other heat-emitting appliances (ovens, refrigerators) without isolation. WARNING! ▶ The appliance is heavy. Always handle with at least two persons. ▶ Keep all packaging materials out of children´s reach and dispose them in an en- vironmentally friendly manner. ▶ Take the appliance out of the packaging. ▶ Remove all packaging materials. Aigning the appliance The appliance should be placed on a at and solid surface.

1. Tilt the refrigerator slightly back-

2. Set the feet to the desired level.

Make sure the distance to the wall on the hinge side is at least 100 mm for the door to open properly.

Space recommendation Recommended space when door is opened.

Ventilaton cross-section To achieve sufficient ventilation of the appliance for safety reasons we recommend observing the space recommendation guidelines. 100 mm50 mm50 mm50 mm 40EN Installation NOTICE For a free standing appliance: this refrigerating appliance is not intended to be used as a built-in appliance

1. The stability can be checked by alternately bumping

on the diagonals. The slightly swaying should be the same in both directions. Otherwise the frame can warp; possible leaking door seals are the result. A low tendency to the rear facilitates the closing of the doors.

Waiting time To the maintenance-free lubrication oil is located in the capsule of the compressor. This oil can get through the closed pipe system during slanting transport. Before connecting the appliance to the power supply you have to wait at least 2 hours so that the oil runs back into the capsule. 2 h WARNING! To avoid risks a damaged power cord must be replaced by the customer service (see warranty card). Electrical connection Before each connection check if: ▶ power supply, socket and fusing are appropriate to the rating plate. ▶ the power socket is earthed and no multi-plug or extension. ▶ the power plug and socket are strictly according. Connect the plug to a properly installed household socket. 41EN Installation Assembly steps

1. Provide necessary tool.

2. Unplug the appliance.

3. Remove the upper hinge cover 1 and unscrew the upper hinge (three screws) on

5. Lift the loose refrigerator door carefully o the middle hinge.

6. Remove the middle hinge.

7. Remove the small cover of the front panel from left to right side.

8. Turn the door upside down and unscrew the cover (1). Take out the new cover (2)

from the necessary bag and screw them to opposite side.

9. Change the positions of the blanking plugs and the screw on the side.

10. Screw the middle hinge to the left side of the appliance. Pay attention to invert-

ing the pivot of the middle hinge, ensuring that the side with the gasket is facing upwards

11. Lift the upper door carefully on the middle hinge. And be sure the pivot ts into

the hinge barrel of the lower door.

12. Take out the new upper hinge and hinge cover from the accessary bag. Put the

connection cable through the upper hinge and x the upper hinge with three screws on left side of appliance. And the put the hinge cover over the hinge.

13. Plug in the connection cable.

14. Replace front panel and x it with ve screws.

After the change of the door, check if the door seals are located properly on the housing and all screws are tightened well. Door Reversibility Before connecting the appliance to the power supply, you should check whether the door swing must be changed from right (as delivered) to left, if this is required by the installation location and the usability. WARNING! ▶ The appliance is heavy. You need two persons to carry out the door reversibility. ▶ Before any operation, rst unplug the appliance from the mains ▶ Do not tilt the appliance more than 45°C to prevent damage of the refrigeration system. 42EN Installation

Ambient temperatures Extended temperate: this refrigerating appliance is intended to be used at ambient temperatures ranging from 10°C to 32°CTemperate: this refrigerating appliance is intended to be used at ambient tempera-tures ranging from 16°C to 32°C;Subtropical: this refrigerating appliance is intended to be used at ambient tempera-tures ranging from 16°C to 38°C;Tropical: “this refrigerating appliance is intended to be used at ambient tempera-tures ranging from 16°C to 43°C. 43EN Technical data Product parameters according to regulation (EU)2019/2016 Based on standard test results for 24 hours. Actual energy consumption will depend on how the appliance is used and where it is located Model

HTW5618DN* HTW5620DN* HTW5618EN*

Type of refrigerating appliance Refrigerator-freezer Refrigerator-freezer Refrigerator-freezer Energy efficiency class D D E Annual energy consumption (kWh/annum)

Volume Refrigerator compartment(L)

Volume Freezer compartment(L)

Volume Chill compartment(L)

Type of refrigerating appliance Refrigerator-freezer Refrigerator-freezer Refrigerator-freezer Energy efficiency class C C A Annual energy consumption (kWh/annum)

Volume Refrigerator compartment(L)

Volume Freezer compartment(L)

Volume Chill compartment(L)

595*667*1850 595*667*2050 595*667*2050 987EN Customer service We recommend our Haier Customer Service and the use of original spare parts. If you have a problem with your appliance, please rst check section TROUBLE- SHOOTING. If you cannot nd a solution there, please contact ▶ your local dealer or ▶ our European Call Service-Center (see listed phone numbers below) or ▶ the Service & Support area at www.haier.com where you can activate the service ▶ claim and also nd FAQs. To contact our Service, ensure that you have the following data available. The information can be found on the rating plate. Model _________ Serial No.. _____________ Also check the Warranty Card supplied with the product in case of warranty. European Call Service-Center Country* Phone number Costs Haier Italy (IT)
