USER MANUAL Markant 05 Ritter

Operating instructions | Food slicer

Variable adjustment (for markant

Kundendienst in Deutschland: ritterwerk GmbH Zentralkundendienst Industriestraße 13 82194 Gröbenzell Telefon (08142) 440 16-60 Telefax (08142) 440 1670 kundendienst@ritterwerk.de www.ritterwerk.de TECHNISCHE DATEN Das Gerät entspricht den CE-Vorschriften. Netzspannung/Leistungs- aufnahme: siehe Typenschild an der Unterseite des Gerätes Schnittstärke: 0 mm bis ca. 14 mm Deutsch7 GARANTIE-ERKLÄRUNG Für diesen ritter Allesschneider leisten wir eine 2-jährige Hersteller-Garantie, gerechnet ab Kaufdatum und nach Maßgabe der EU-Gewährleistungs- richtlinien. Ihre gesetzlichen Gewährleistungsansprüche nach § 437 󰀨. BGB bleiben von dieser Regelung unberührt. Die Herstellergarantie gilt für alle innerhalb der europäischen Union verkauften Geräte. Die Garantiebedingungen können Sie unter www.ritterwerk.de/garantie einsehen. Deutsch SYMBOLERKLÄRUNG Symbol Erklärung CE-Kennzeichnung: Das Produkt ist konform mit den geltenden Anforderungen der Europäischen Union. Das Produkt wurde nach dem 13. August 2005 in Verkehr gebracht. Es darf nicht über den normalen Hausmüll entsorgt werden. Das Symbol der durchgestrichenen Mülltonne weist auf die Notwendigkeit der getrennten Sammlung hin. Für den Kontakt mit Lebensmitteln geeignet Gerät der Schutzklasse II8 GENERAL SAFETY INSTRUCTIONS To avoid personal injury or dam- age to the appliance, please observe the following safety instructions: – The food slicer is to be used for domestic purposes only and must not be used commercially. – Never set the appliance down on hot surfaces or close to a naked ame. – Use the accessories included in the delivery specication only. – Use suitable extension cables only. – Do not bend the power cord. Never wrap the cable around the appliance. – Route the power cord so that it does not come into con- tact with hot or sharp-edged objects. – Only start to use the appliance after it has been securely set up. – Persons with reduced physi- cal, sensory or intellectual capabilities or lacking in relevant experience and/or knowledge may only use this appliance if they do so under supervision or have been instructed in the safe use of the appliance and understand the potential risks associated with its use. – Do not allow children to play with the appliance. – Always disconnect the appli- ance from the mains whenever it is to be left unsupervised, and also prior to assembly, dismantling and cleaning. – This appliance must not be used by children. Keep the appliance and its connection cable out of reach of children. – Only connect the appliance to a suitable AC power source that complies with the speci- cations on the type label. – Never leave the appli- ance unattended while it is operating. – Do not use it to cut frozen foods, hot foods, bones, food containing large stones, roast meats encased in netting or packaged foods! – Never allow the appliance to run for more than 5 minutes at a time. English9 Risk of electric shock – Always remove the power plug from the socket in the event of a malfunction, before cleaning and when the appliance is not in use. When doing so, pull on the plug and not on the cable. – Never immerse the appliance in water. Never expose the appliance to rain or any other form of moisture. If the appli- ance falls into water, unplug the cable from the mains socket before removing the appliance from the water. Have the appliance inspected at an authorized service loca- tion before using it again. – Always ensure that your hands are completely dry before using the appliance. Do not use the appliance if it is wet or damp or while you are stand- ing on a damp surface. Do not use the appliance outdoors. – Stop using the appliance immediately if any parts are damaged and contact the ritter after-sales service. – If the power cord is damaged, it must be replaced by the manufacturer, the manufac- turer's after-sales service or a similarly qualied person to eliminate risk of personal injury. Risk of injury – This appliance must not be used without a slice carriage or a left-over holder, unless the size and shape of the food to be sliced means that these parts cannot be used. – Before replacing accessories or add-on parts that move when operated, the appliance must be switched o󰀨 and dis- connected from the mains. – The rotary blade is extremely sharp. – Never touch the rotating blade when operating the appliance! – Switch the appliance o󰀨 before cleaning it; pull the power plug out of the socket and turn the slice thickness adjustment knob to the "0" position. – The rotary blade will continue to run for a short time after being switched o󰀨. English10 Unfold the illustrations at the front and back of this manual. Please read these instructions thoroughly before you start to use the appliance. Keep these operat- ing instructions in a safe place and ensure that they are included with the appliance if passing it on to a third party. Alternatively, the current operat- ing instructions are available at www.ritterwerk.de. INTENDED USE The food slicer is used to slice household foods. The food slicer is suitable for contact with foodstu󰀨s. If the appliance is used for a purpose other than this, or if it is operated incorrectly, severe inju- ries may occur or the appliance may be damaged. All warranty and liability claims will be ren- dered null and void in this case.

FIRST TIME Preparation Remove the appliance carefully from the packaging. Remove all packaging parts and keep these together with the packaging in a safe place. Clean the appli- ance before allowing it to come into contact with any food (see CLEANING). Setting up the appliance

• Set the appliance down on a at, nonskid surface close to a mains socket. On the positioning plate (6) remove the left-over holder (8), the nger protection (7a) and the slide unit (7b) one after the other by pulling them out and up. Mounting the slice car- riage (7): Insert the nger protec- tion into the slot in the base of the carriage and fasten it in place by sliding it in the direction of the arrow. Unwind the power cord (11) to the length required from the cable compartment (4) under the appliance. In doing so, fasten the power cord in the slot provided for it on the base of the appliance. Swivel the positioning plate fully downwards into the working position. Place the slice carriage's guide runner onto the positioning plate's lateral guide groove at an incline. Swivel the slice carriage downwards in the direction of the positioning plate. The slice carriage's guide runner must be fully mounted onto the positioning plate's guide groove. Slide the left-over holder (8) onto the nger protection (7a).

• Plug the cable into the socket. SLICING Use the slice thickness adjust- ment knob (2) to set the required thickness. Place the food to be sliced onto the slice carriage (7). Use the left-over holder (8) to press it up against the stop plate (3). Protect your hands, by always using the slice carriage and, where applicable, the left-over holder. Exception: Excessively large foods to be sliced. Turn the appliance on using the power switch (1). Two operat- ing modes are available: Temporary operation: Press the power switch and slide it towards the arrow until you feel some resistance. The rotary blade (10) runs as long as the power switch is pressed and held down in this position. Continuous operation: Press the power switch and slide it towards the arrow beyond the resistance point until it latches into place. The rotary blade runs without the power switch having to be pressed and held down, until you push the power switch back into the "0" position. Note: Never use the appliance for more than a maximum of 5 minutes in continuous operation. For markant

Adapt the slicing speed using the electronic rpm adjustment (12) to suit the food to be sliced. When slicing soft food, set a low slicing speed. Set a higher speed for hard food.

• With the appliance running, gently feed the food to be sliced into the path of the rotary blade.

• When nished slicing, wait until the rotary blade has come to a complete stop.

• After each use, turn the slice thickness adjustment knob to the "0" position, in order to cover up the sharp rotating blade and to avoid any injuries. CLEANING Caution: Switch the appliance o󰀨 before cleaning it; pull the power plug out of the socket and turn the slice thickness adjustment knob (2) to the "0" position. Clean the food slicer regularly to prevent the accumulation of food residue. The rotary blade must also be cleaned regularly as described below to prevent its surface from rusting. Note: Over time, an accumulation of food residue may cause damage to the surface of the rotary blade, causing it to rust. Preparation

• Remove the left-over holder (8) and the slice carriage (7). English11 Removing the rotary blade: Open the blade catch (9), by turning it in a clockwise direction. Take hold of the rotary blade at its rotational centre and remove it. Cleaning after each use

• Wipe down the housing and all removed parts, including the rotary blade, with a damp cloth. Occasional cleaning

• Give all removed parts, includ- ing the rotary blade, a thorough wash in warm soapy water (not in the dishwasher!).

• Clean the housing behind the blade using a dry cloth/brush. Note: Do not use any abrasive cleans- ers, sponges with rough surfaces or hard brushes.

• Dry all parts that you have washed.

• Grease the rotary blade's gear wheel with a little ritter mainte- nance grease (alternatively with a little Vaseline). Assembling the appliance

• Carefully insert the rotary blade.

• Insert the blade catch.

• Close the blade catch by turning it in an anticlockwise direction.

• Mount the slice carriage (7). MAINTENANCE Your food slicer is maintenance- free. However, we recommend that you occasionally apply a little extra ritter maintenance grease or Vaseline to the rails of the slice carriage to keep them lubricated and ensure that the carriage continues to move easily. STORAGE Keep the appliance out of the reach of children. To store the cable, always use the cable compartment integrated into the appliance. DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol indicates that this product must not be disposed of with unsorted municipal waste. There is a separate (free) system for the collection and return of waste electrical and electronic equipment. For more information, please contact your local authority or the shop where you purchased the product. By ensuring that this product is disposed of correctly, you will help prevent potential negative consequences for the environ- ment and human health and contribute to the conservation of natural resources. REACH DIRECTIVE See www.ritterwerk.de SPECIAL ACCESSORIES A non-toothed rotary blade is also available specically for sliced meat, sausage and ham. The original ritter maintenance grease is available for delivery for maintaining (regreasing) the food slicer.

SERVICE, REPAIRS AND

SPARE PARTS Please contact your local after- sales service for all service, repairs and spare parts matters! See www.ritterwerk.de TECHNICAL DATA The appliance complies with the CE specications. Mains voltage/power consump- tion: Refer to the type label on the underside of the appliance. Slice thickness: 0 mm to approx. 14 mm WARRANTY This ritter appliance comes with a two-year manufacturer’s war- ranty, starting with the date of purchase and in accordance with the EU warranty directives. Your legal warranty claims according to § 437 󰀨. BGB (German Civil Code) remain una󰀨ected by this regulation. The manufacturer warranty applies to all devices sold within the European Union. For details of the warranty condi- tions, see www.ritterwerk.de/ warranty. English

EXPLANATION OF SYMBOLS

Symbol Explanation CE marking: The product complies with the applicable requirements of the European Union. The product was put on the market after 13 August 2005. It must not be disposed of as normal domestic waste. The crossed-out wheelie bin symbol indicates that sepa- rate collection is required. Suitable for contact with foodstu󰀨s Protection class II equipment12 INSTRUCTIONS DE
