USER MANUAL LC-40FI3222EW SHARP

Important safety instructions

Please, read these safety instructions and respect the following warnings before the appliance is operated:

In order to prevent fire always keep candles and other open flames away from this product.

• Television sets with 43^ size screens or more must be lifted and carried by at least two people.

• This TV does not contain any parts which could be repaired by the user. In case of a fault, contact the manufacturer or the authorised service agent. Contact with certain parts inside the TV might endanger your life. The guarantee does not extend to faults caused by repairs carried out by unauthorized third parties.

• Do not remove the rear part of the appliance.
  This appliance is designed for the receiving and reproduction of video and sound signals. Any other use is strictly forbidden.

• Do not expose the TV to dripping or splashing liquid.
• To disconnect the TV from mains please unplug the mains plug from the mains socket.
• If the supply cord is damaged, it must be replaced by the manufacturer, a service agent or similarly qualified persons in order to avoid a hazard.
• The suggested distance to watch HD TV is approximately three times longer than the screen diagonal size. Reflections on the screen from other light sources can make the quality of the picture worse.
• Ensure the TV has sufficient ventilation and is not close to other appliances and other pieces of furniture.
  Install the product at least 5cm from the wall for ventilation.
• Ensure that the ventilation openings are clear of items such as newspapers, table-cloths, curtains, etc.
• The TV set is designed to be used in a moderate climate.
• The TV set is designed exclusively for operation in a dry place. When using the TV outside, please, make sure it is protected against moisture (rain, splashing water). Never expose to moisture.
• Do not place any objects, containers filled with liquids, such as vases, etc. on the TV. These containers might get pushed over, which would endanger electric safety. Place the TV exclusively on flat and stable surfaces. Do not place any objects such as newspaper or blankets, etc. on or under the TV.
• Make sure the appliance does not stand on any power cables as they might get damaged. Mobile phones and other devices such as WLAN adapters, monitoring cameras with wireless signal transmission, etc. might cause electromagnetic interference and they should not be placed near the appliance.
• Do not place the appliance near heating elements or in a place with direct sunlight as it has a negative effect on cooling of the appliance. Heat storage is dangerous and it can seriously reduce the lifetime of the appliance. In order to ensure the safety, ask a qualified person to remove the dirt from the appliance.
• Try to prevent damage to the mains cable or mains adapter. The appliance can only be connected with the supplied mains cable/adapter.

• Storms are dangerous for all electric appliances. If the mains or aerial wiring is struck by lightening the appliance might get damaged, even if it is turned off. You should disconnect all the cables and connectors of the appliance before a storm.

• To clean the screen of the appliance use only a damp and soft cloth. Use only clean water, never detergents and in no case use solvents.

• Position the TV close to the wall to avoid the possibility of it falling when pushed.
• WARNING - Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as:
• Use cabinets or stands recommended by the manufacturer of the television set.
• Only use furniture that can safely support the television set.
• Ensure the television set is not overhanging the edge of the supporting furniture.
• Not place the television set on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the television set to a suitable support.
• Not place the television set on cloth or other materials that may be located between the television set and supporting furniture.
  Educate children about the dangers of climbing on furniture to reach the television set or its controls.
• Ensure that children do not climb or hang onto the TV.
• If your existing television set is being retained and relocated, the same considerations as above should be applied.
• The instructions shown below are a safer way to set up the TV, by fixing it to the wall and will avoid the possibility of it falling forwards and causing injury and damage.
• For this type of installation you will need a fastening cord A) Using one/both of the top wall-mounting holes and screws (the screws are already supplied in the wall mounting holes) fasten one end of the fastening chord/s to the TV. B) Secure the other end of the fastening chord/s to your wall.
• The software on your TV and the OSD layout can be changed without notice.
• Note: In case of electrostatic discharge (ESD) the apparatus may show incorrect function. In such case, switch the TV off and back on. The TV will work normally.

Warning:

• Do not use TV set directly after unpacking. Wait until TV warms up to the room temperature before using it.
• Never connect any external devices to a live appliance. Switch off not only the TV but also the devices which are being connected! Plug the TV plug into the wall socket after connecting any external devices and the aerial!
  Always make sure there is free access to the TV mains plug.
• The appliance is not designed for a use in a workplace fitted with monitors.
• The systematic use of headphones at high volume might lead to irreversible hearing damage.
• Ensure environmental disposal of this appliance and any components including batteries. When in doubt, please, contact your local authority for details of recycling.
• While installing the appliance, do not forget that furniture surfaces are treated with various varnishes, plastics, etc. or they might be polished. The chemicals contained in these products might have a reaction with the TV stand. This could result in bits of the material sticking to the furniture surface, which are difficult to remove, if not impossible.
• The screen of your TV has been produced under top quality conditions and was checked in detail for faulty pixels several times. Due to the technological properties of the manufacturing process, it is not possible to eliminate the existence of a small number of faulty points on the screen (even with maximum care while in production). These faulty pixels are not considered faults in terms of guarantee conditions, if their extent is not greater than the boundaries defined by DIN norm.
• The manufacturer cannot be held responsible, or be liable, for customer service-related issues related to the third party content or services. Any questions, comments or service-related inquiries relating to the third party content or service should be made directly to the applicable content or service provider.
• There are a variety of reasons you may be unable to access content or services from the device unrelated to the device itself, including, but not

limited to, power failure, the Internet connection, or failure to configure your device correctly. Universal Media Corporation, its directors, officers, employees, agents, contractors and affiliates shall not be liable to you or any third party with respect to such failures or maintenance outages, regardless of cause or whether or not it could have been avoided.

• All third party content or services accessible via this device is provided to you on an "as-is" and "as-available" basis and Universal Media Corporation and its affiliates make no warranty or representation of any kind to you, either express or implied, including, without limitation, any warranties of merchantability, non-infringement, fitness for a particular purpose or any warranties of suitability, availability, accuracy, completeness, security, title, usefulness, lack of negligence or error-free or uninterrupted operation or use of the content or services provided to you or that the content or services will meet your requirements or expectations.
• 'Universal Media Corporation' is not an agent of and assumes no responsibility for the acts or omissions of third party content or service providers, nor any aspect of the content or service related to such third party providers.
• In no event will 'Universal Media Corporation' and/or its affiliates be liable to you or any third party for any direct, indirect, special, incidental, punitive, consequential or other damages, whether the theory of liability is based on contract, tort, negligence, breach of warranty, strict liability or otherwise and whether or not Universal Media Corporation and/or its affiliates have been advised of the possibility of such damages.

Important information regarding use of video games, computers, captions and other fixed image displays.

• The extended use of fixed image program material can cause a permanent "shadow image" on the LCD screen (this is sometimes incorrectly referred to as "burnout to the screen"). This shadow image is then permanently visible on the screen in the background. It is irreversible damage. You can avoid such a damage by following instructions below:
• Reduce the brightness/contrast setting to a minimum viewing level.
• Do not display the fixed image for a long period of time. Avoid displaying of:

» Teletext time and charts,
TV/DVD menu, e.g. DVD contents,
In the n Pause mode (hold): Do not use this mode for a long time, e.g. while watching a DVD or a video.
Turn off the appliance if you are not using it.

Batteries

• Observe the correct polarity when inserting the batteries.

• Do not expose batteries to high temperatures and do not place them on locations where the temperature might increase quickly, e.g. near the fire or on the direct sunshine.

• Do not expose batteries to excessive radiant heat, do not throw them into the fire, do not disassemble them and do not try to recharge un-rechargeable batteries. They could leak or explode.

Never use different batteries together or mix new and old ones.
» Dispose of batteries in an environmentally friendly way.
» Most of the EU countries regulate the disposal of batteries by law.

CAUTION:

CLASS 1 LASER PRODUCT (Applies to models with built in DVD player) This caution label is located on the rear panel of the unit
- THIS UNIT IS A CLASS 1 LASER PRODUCT. THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED.
- WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.

• USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
• DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

Disposal

• Do not dispose of this TV as unsorted municipal waste. Return it to a designated collection point for the recycling of WEEE. By doing so, you will help to conserve resources and protect the environment. Contact your retailer or local authorities for more information.

CE Statement:

• Hereby, UMC Poland Sp. z o.o. declares that this LED TV is in compliance with the essential requirements and other relevant provisions of RED Directive 2014/53/EU. http://www sharp.eu/av/documents-of-conformity

Trademarks

• The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
  The "HD TV" Logo is a trademark of DIGITALEUROPE.
  The "HD TV 1080p" Logo is a trademark of DIGITALEUROPE.
• The DVB logo is the registered trademark of the Digital Video Broadcasting - DVB - project.
• Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories.
• For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks. DTS TruSurround is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.

Cd

What is included in the box

Supply of this TV includes following parts:

1xTV

1xTV stand installation packet

1x Remote control

1x Quick Start Guide

2x AAA batteries

• 1x SCART adapter cable*

1x Mini Component adapter cable***

1x Mini Composite adapter cable**

• • supplied only for models without SCART connector
    - Aviable only for models with Mini Composit
    * - Aviable only for models with Mini Component

Attaching the Stand

Please follow the instructions in Technical leaflet, located in the accessories bag.

Wall mounting the TV

1. Remove the four screws that are supplied in the wall mounting holes.
2. The wall mount can now be easily attached to the mounting holes on the rear of the TV.
3. Install the wall mounting bracket to the television as advised by the bracket manufacturer.

Connections

Connecting external devices see last page in this IM.

Getting started - initial set up

1. Using the RF cable, connect the TV to the TV Aerial wall socket.
2. Insert the batteries supplied into the Remote control.
3. Connect the power cable to the Electrical outlet.
4. Then press Standby button to power on TV.
5. After turning the TV on, you will be welcomed by the First Time Installation menu.

If it does not appear, on the remote control, please press [MENU] then 8-8-8-8 and the menu will appear.
If you wish to make changes to any of the default settings, use the scroll / / buttons. To exit this menu at anytime, press [EXIT] button.
6. Please set desired settings in FIRST TIME INSTALLATION screen.

TV buttons*

Vol+ Volume up and menu right

Vol- Volume down and menu left

CH+Programme/Channel up and menu up

CH-Programme/Channel down and menu down

MENUDisplaysMenu/OSD

SOURCE Displays the input source menu

STANDBY Standby Power On/Off

* - for TV with buttons

TV Control Stick*

TV control stick is located on the lower left corner of back side of the TV. You can use it instead of remote control to control most of the functions of your TV.

While TV is in standby mode:

• short press of control stick - Power On

While watching TV:

• RIGHT/LEFT - volume up/volume down
  UP/DOWN - changes channel up/down
• long press UP (or DOWN) - Displays Sources/Inputs menu
• short press - Displays Menu
• long press - Standby Power Off

While in menu:

• RIGHT/LEFT/UP/DOWN - navigation of cursor in on-screen menus
• short press - OK/Confirm selected item
• long press - Back to previous menu
  * - for TV with control stick

Choosing Mode Input/Source

To switch between the different input/connections.

a) Using the buttons on the remote control:

1. Press [SOURCE/□] - The source menu will appear.
2. Press [ ] or [ ] to select the input you require.
3. Press [OK].

b1) Using the buttons* on the Television:

1. Press [SOURCE].
2. Scroll up/down using CH+/CH- buttons to the input/source you require.
3. Press [VOL+] to change input/source to the one selected.

b2) Using the TV control stick*:

1. Press control stick UP (or DOWN) for few seconds to enter SOURCES menu.
2. With control stick choose the input/source you require.
3. By short press of control stick to center, you will change input/source to the one selected.

* -optional

TV Menu navigation

To access this menu, press [MENU] button on the remote control. To enter a menu press [OK]. If you wish to make changes to any of the default settings, use the scroll (▲/▼/▲/▶) buttons. To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

Electronic instruction manual

To view the electronic instruction manual press the yellow [help] button.

For some standard options (picture/channel/sound etc) quick instructions are available by pressing the menu button, navigate to desired option and then press yellow [help] button.

Remote control

See in On Screen Manual in TV

Botones* de la television

Palanca* de control de la television

STANDBY Standby Taend/Sluk

b1) Paina television painikkeita*:

Digital Video Broadcasting

DOLBY AUDIO

Kas yra dezêje

Olulised ohutusjuhised

Digital Video Broadcasting

DOLBY AUDIO

TruSurround

Co sa nachadza v baleni

Vol- HamaJIraBaHe Ha CnJaTa Ha 38yKa I IpemMInHaBe He KbM MEHOTO BnBO

CH+ nporpama/kaHnHaRope n IpemHaBaHe KbM MeHIOTo rope

CH- nporpama/kahan haNDony u npemHHaBAHe kBm MeHOTOny

MENU noka3Ba MeHIO/OSD

SOURCE NOKa3BaHe Ha MeHIO 3a I3TOUHnIka Ha BXOeH CmHAn.

STANDBY BKIOHVAB/IN3KIOVbAHa NE TEJIeBnOpa, DOKATO E B PEXKIM HAI FOROTOBHOCT.

*- npu modenu c 6ymoHn ha meeneu3opa

ДжоICTNK 3a ynpablenhe Na TeleBu3opa*

Digital Video Broadcasting

DOLBY AUDIO

TruSurround

LASERSKI PROIZVOD KLASE 1 (primjenjivo na modele s ugradenim DVD reproktorom). Ova nalajepnica s upozorenjem nalazi se na strazenjem dijelu proizvoda.

SOURCE EupaviCEI TO MEVOI INHc EIaOBDou

STANDBY Evpyoioiŋn/Aevepyoioiŋn kataoaoc avaovnic

*-yia tnIeopaon koumi

Moxloc xieipioou tnaeopaonc

O oxoXcEeipiaouTNC TnLEOpaocN Bpioketai Otny kAtw apioTe npVua TNC nioW nLeupac TNC TnLEOpaocN. Mnpoeite v Tov xpoiaoioei evi To nleepioTnpiou ia Vx EeipoiTeTic NpEIOoTepe, IeIToupyiec TNC TnLopaoC

Evw n tneopaon piokei a e kataoan avaovnic:

ouvtoo natau tou loxloxieipioou-Eepeyonoin

Kata nV npapakoouoan tnIeopaonc:

• ΔΕΞΙΑ/ΑΡΙΣΤΕРΑ - Ενταση ἡχού πάνω/κάτω
  ΠANΩ/KATΩ-aλλayπΚανλiou παvω/kατω
• napataetaevo natnma PAnON (r KATΩ) - EupaviciEtaI to evou Pnyw/Eioo8w
  - O M e v o u
• nanopatetaevo natama-Avaovn Anevepyoioinon

Méσα σε μενου:

Connecting external devices

UMC Poland sp. z o.o.

Ostaszewo 57B, 87-148 Lysomice,

Poland

Assembled in Poland
