USER MANUAL PEHWW 1300 B2 PARKSIDE

Black industrial air compressor with attached pump and control panel, labeled 'PARKSIDE' (no other text or symbols visible)

Hauswasserwerk / Domestic Water Pump / Pompe d'alimentation en eau PEHWW 1300 B2

DE AT CH BE

Hauswasserwerk

Translation of the original instructions

NL BE

Huiswaterpomp

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Service-Center....15

Importeur.... 15

- gemessen 81,0 dB; K_WA=3,16 dB

-garantiert 84 dB

Sicherheitshinweise

- Spezialschlüssel (11)

Vorgehen

Scope of delivery/accessories......17

Overview.... 18

Description of functions....18

Technical data....18

Safety information....18

Meaning of the safety information...... 18

Pictograms and symbols.... 19

Safe initial start-up of the pump...... 19

Preparation.... 22

Control elements....22

Fitting the carrying handle.... 23

Setting up the pump.... 23

Connecting the suction line.... 23

Connecting the pressure line.... 23

Filling the pump.... 23

Setting the pressure switch.... 23

Operation.... 23

Before use....23

Switching on and off....24

Operation as a pump.... 24

Cleaning, maintenance and storage..... 24

Cleaning....24

Maintenance.... 24

Checking and adjusting the back pressure.... 24

Storage.... 25

Disposal/environmental protection.....25

Service.... 25

Guarantee.... 25

Repair service.... 26

Service Centre.... 26

Importer....27

Spare parts and accessories.... 27

Translation of the original EU declaration of conformity....28

Exploded view.... 145

Introduction

Congratulations on purchasing your new domestic water system (hereafter referred to as device or power tool).

You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device. In some cases, residual amounts of water may be present on or in the device or in hose lines. This is not a flaw or a defect and is no cause for concern.

The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following uses:

- Irrigation in private gardens

• Domestic water supply

- Pumping clear water and rainwater at a temperature up to the following temperature: ≤ 35 °C

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

• Domestic Water Pump

- Paper bag

- Carrying handle

- 2× Screw

- Backflow stop

- Double nipple (G 1")

- Cap (G 1")

• Garden hose adaptor
- Special key (Pre-filter)

• Translation of the original instructions

Overview

The illustrations for the device can be found on the front fold-out page.

1 Sealing plug
2 Cover (Pre-filter)
3 Garden hose adaptor
4 Double nipple
5 Water outlet
6 Carrying handle
7 On/Off switch
8 Valve cap
9 Air valve

10 Pressure tank
11 Special key
12 Base
13 Power cord
14 Drain plug
15 Pressure indicator
16 Pressure switch
17 Connecting hose
18 Sealing cap
19 Water inlet
20 Backflow stop

Fig. A

21 Screw

Fig. B

22 Pre-filter
23 Filter holder

Description of functions

The domestic water system supplies water under pressure. This makes it possible to supply water for toilet cisterns, washbasins or irrigation with domestic water. The pump switches on depending on the pressure and fills the pressure tank until the switch-off pressure is reached.

Please refer to the descriptions below for information on how the operating elements work.

Technical data

Domestic Water Pump ....PEHWW 1300 B2

Rated voltage U ....230 V\~, 50 Hz

Rated input power P ....1300 W

Protection class .... I

Protection type IPX4

Length Power cord 2 m

Weight 14.1 kg

Container volume

-gross 24 ℓ

-net 20 ℓ

Suction height h_s ……≤8 m

Flow rate Q ....≤ 5000 l/h*

Discharge head h

- maximum .... ≤ 50 m

- Default setting ....≤ 30 m

Cut-in pressure p_1 (Default setting) .....1.5 bar

Cut-out pressure p_0 (Default setting) .. 3.0 bar

Water temperature ....≤ 35 ^ C

Hose connection ...... G1"

Sound pressure level ( L_pA )

68.0 dB; K_pA=3.16 dB

Sound power level ( L_WA )

- Measured ....81.0 dB; K_WA =3.16 dB

– Guaranteed ....84 dB

Safety information

CAUTION! The following basic safety precautions must be observed while using electrical devices to protect against electric shock, injury and risk of fire.

Meaning of the safety information

▲ DANGER! If you do not observe this safety instruction, an accident will occur. The result of which

is severe bodily injury or death.

⚠ WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.

CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.

NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols Symbols on the device

Read the instruction manual

Attention!

• Not suitable for water with high sand content.
• Warning: Protect the pump from running dry. Risk of over-heating!

Pull out the mains plug before maintenance work or if the power cord is damage

Caution! Hot surfaces, burn risk!

Guaranteed sound power level L_WA in dB.

IN Thread: G 1"; Water inlet

OUT Thread: G 1"; Water outlet

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

Symbols used in the instruction manual

Attention!

Safe initial start-up of the pump

General Information

• Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly.
• This product can be used by children aged 8 years and up as well as individuals with reduced

physical, sensory or mental abilities or a lack of experience and knowledge if they are supervised or have been instructed in the safe use of the device and understand the resulting hazards.

Children must never play with the device.

Cleaning and user maintenance must not be carried out by children if they are not supervised.

• People who are not familiar with the instruction manual may not use the device.

- The machine must not be used at altitudes over 2000 m.

- Do not use for water with abrasive particles such as sand. The pumping of aggressive, abrasive, caustic, flammable (e.g. engine fuels) or explosive liquids, salt water, detergents and foods is not allowed. The temperature of the pumped liquid must not exceed 35°C.

- Never operate the device with people in the water.

• Escaping lubricant could contaminate the liquid.
• Do not work with a damaged or incomplete device or one which has been converted without the permission of the manufacturer. Before initial start-up, have a specialist check whether the required electrical protective measures are in place.

Preparation

• Ensure that the mains voltage and mains frequency match the specifications on the rating plate.
• Prior to use, always check the power cord and extension cord for signs of damage or wear and tear. If the cord is damaged during use, it must be disconnected from the supply network immediately. DO NOT TOUCH THE CABLE BEFORE IT HAS BEEN DISCONNECTED FROM THE POWER SUPPLY. Do not use the device if the cord is damaged or worn.

- Only connect the device to a power outlet with a residual current device (RCD) with a rated residual current no more than 30 mA.

- Connect the appliance to an outlet with a fuse of at least 10 A.

- Do not work with a damaged or incomplete device or one which has been converted without the permission of the manufacturer.

- Before use, check the electrical safety. If you are not sure, ask a qualified specialist.

- Earthing, zeroing and residual current device comply with the safety regulations of the power supply companies and function perfectly.

• The electrical connections are protected against moisture.

- The plug connections are installed in a flood-proof area.

- If the power cord of this device is damaged, it must be replaced by the

manufacturer, their customer service or by a similarly qualified person in order to avoid hazards. contact the service centre.

- When operating the device, the mains plug must be freely accessible.

- Do not use the power cord to pull the plug out of the outlet. Protect the power cord from heat, oil and sharp edges.

- Use only extension cables that are splash-proof and designed for outdoor use. Always roll out the cable drum completely before use. Check the cord for damage.

- Remove the plug from the outlet before carrying out work on the device, during work breaks and when not in use.

- Use only approved extension cables of type H07RN-F that are not more than 75 m long and are designed for outdoor use. The wire cross section of the extension cable must be at least

2,5 mm ^2 . Always roll out the cable drum completely before use. Check the extension cable for damage.

- Do not carry or attach the device by the power cord or hose.

Operation

• Do not use the device near flammable liquids or gases. There is a risk of fire or explosion if this advice is not heeded.
• Wear sturdy shoes to protect against electric shock.
• The pump must not be left outside in frosty weather. Store the device protected from frost.
• Monitor the device during operation to detect in adequate time if the pump running dry.

Cleaning, maintenance and storage

• Take heed to all information in the following section: Cleaning, maintenance and storage, p. 24
All other measures, and opening the device in particular, must be car-

ried out by a qualified electrician. Always contact our service centre in the case of repairs.

• Switch the drive off, disconnect the device from the power supply and allow the device to cool off if you want to clean, adjust, store the device or to exchange an accessory part.
• Replace worn or damaged parts in the interests of safety. Use only original spare parts and accessories. Using externally produced parts results in the immediate loss of any warranty claim.
• Store the device in a dry place and out of reach of children.

Preparation

⚠ WARNING! Risk of injury due to unintentional start-up. Do not insert the plug into the outlet until the device is fully prepared for use.

Control elements

Familiarise yourself with the operating elements before using the device for the first time.

On/Off switch (7)

• Switching on: Move the On/Off switch (7) to the position "I" (ON).
• Switching off: Move the On/Off switch (7) to the position "0" (OFF).

Fitting the carrying handle

Procedure (Fig. A)

1. Fasten the carrying handle (6) with the two screws (21).

Setting up the pump

- Place the device on a firm, level surface that is safe from flooding.

- Option for fixed installation: Attach the device to the base using screws (not included) through the holes in the stand. Ensure that the drain plug (14) remains freely accessible.

- If possible, place the device higher than the water surface from which you want to pump.

If this is not possible, remove the suction line from the water after pumping or shut off the suction line with a stopcock.

Connecting the suction line

Notes

• Do not use connection systems with quick couplings on the suction side.
• If possible, use a vacuum-resistant spiral hose or a pipe as the suction line. Minimum diameter: 19 mm ( 34 ).
• The function of the device cannot be guaranteed if there is air in the suction line.
  • Install the suction line so that it slopes upwards and not above the pump.
• Replace damaged seals.

Procedure

1. Remove the sealing plug (1) from the water inlet (19).
2. Fit the backflow stop (20) on the water inlet (19).
3. Fit a suitable hose on the backflow stop (20).

Connecting the pressure line

Notes

• The package contents do not include a connection for a pressure hose.
• Possible connection: Hose nozzle with male thread; G 1"
• For maximum pump capacity: Pressure hose ∅ 19 mm

Procedure

1. Remove the sealing plug (1) from the water outlet (5).

2. If necessary: Fit the double nipple (4) on the water outlet (5).

3. Fit a suitable hose.

Filling the pump

Notes

• Fill the device with water before each use.
• NOTICE! Danger of overheating! Avoid dry running of the pump!
  • CAUTION! Risk of burns! Never touch an overheated pump!

Tools required

- Special key (11)

Procedure

1. Remove the cover (2) using the special key (11).
2. Bleed the air from the connected suction hose.
3. Fill the pump housing with water ( ≈ 1.7 l).
4. Fit the cover (2) using the special key (11).

Setting the pressure switch

The cut-out pressure p is adjustable. At maximum cut-out pressure (5.0 bar), the device achieves the following discharge head: ≤ 50 m.

Difference between cut-out pressure and cut-in pressure p : 1.5–1.8 bar

This setting may only be carried out by a specialist.

Operation

Before use

• Ensure that the mains voltage and mains frequency match the specifications on the rating plate.
• Check that the power outlet is in good working order. Connect the appliance to an outlet with a fuse of at least 10 A.
• Only connect the device to a power outlet with a residual current device (RCD) with a rated residual current no more than 30 mA.
• DANGER! Danger of electric shock! Make sure that moisture or water can never get into the mains connection.

• Check the suction line: The suction end of the suction line is located in the water.

• Check the pressure line: The outlet end of the pressure line is open.

• The device is not suitable for connection to the drinking water supply.

Switching on and off

Notes

• NOTICE! Not suitable for continuous operation! The optimum interval of use is 30 minutes pumping, 5 minutes break.
• Overload protection: In case of overload, a built-in temperature monitor automatically switches the device off. The device automatically switches back on after it has cooled down.
• When switching on the pump, make sure that the pump and the suction hose are completely filled with water to prevent the device from running dry.

Switching on

1. Connect the power cord (13) to the power supply.
2. Move the On/Off switch (7) to the position "I" (ON). After a suction period the pump begins to extract.

Switching off

1. Move the On/Off switch (7) to the position "0" (OFF).
2. Pull the device plug out of the wall outlet if you are leaving the device unattended or if you have finished working.

Operation as a pump

When the connecting hose (17) between the pump and the pressure tank (10) is disconnected, the domestic water system functions as a pump.

Procedure

1. Disconnect the connecting hose (17): Loosen the coupling nut.
2. Close the opening with the sealing cap (18).
   Operation as a domestic water system: Undo the conversion.

Cleaning, maintenance and storage

WARNING! Electric shock! Risk of injury due to unintentional start-up. Protect yourself when performing maintenance or cleaning work. Switch off the device and disconnect the mains plug from the socket. You should have any repair and maintenance work that is not described in these instructions carried out by our Service Centre. Only use original replacement parts.

Cleaning

⚠ WARNING! Electric shock! Never spray down the device with water.

NOTICE! Risk of damage. Chemical substances may attack the plastic parts of the machine. Do not use any cleaning agents or solvents.

- Keep the ventilation slits, motor housing and handles of the machine clean. Use a damp cloth or brush to do this.

Cleaning the pre-filter

Replacement filter: Spare parts and accessories, p. 27

1. Remove the cover (2) using the special key (11).
2. Take the pre-filter (22) out of the housing.
3. If it is very dirty, remove the pre-filter (22) from the filter holder (23).
4. Rinse the pre-filter (22) with clear water.
5. Place the cleaned pre-filter (22) in the housing.
6. Fit the cover (2) using the special key (11).

Maintenance

The device is maintenance free.

Checking and adjusting the back pressure

Notes

• Back pressure in the pressure tank when the pressure tank is empty: 1.5–1.8 bar
• Check the pressure at least every 6 months.

Tools required

- Pump or compressor with pressure gauge and connection for car valve.

Procedure

• Open an outlet on the pressure side. Wait until the pressure indicator (15) shows 0.
• Remove the valve cap (8).
• Check the pressure at the air valve (9).
• Replenish with air if necessary.
• Attach the valve cap (8) to the air valve (9).

Storage

Always store the device and accessories:

• clean
• dry
  • protected against dust
  • protected against frost
  • out of the reach of children
• Empty the garden pump (Draining the pump, p. 25) before storing it for a longer period (e.g. Winter storage).
  Otherwise, start-up difficulties may occur due to deposits and residues.

Draining the pump

If there is a danger of frost or longer periods of non-use (e.g. Winter storage) the pump must be completely emptied.

⚠️ CAUTION! Risk of injury! Tank is pressurised. Follow the instructions carefully.

1. Switch off the machine. Pull the plug out of the power outlet.
2. Open an outlet on the pressure side. Wait until the pressure indicator (15) shows 0.
3. Open the drain plug (14). Wait until the water stops flowing.
4. Tilt the device to let the remaining water drain out.

Disposal/environmental protection

The device, accessories and packaging should be properly recycled.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be disposed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured. Depending on the implementation in national law, you may have the following options:

- Return to a shop,

• Hand over to an official collection point,
• Return to the manufacturer/distributor.
  This does not affect accessories enclosed with the old devices or tools without any electrical components.

Service

Guarantee

Dear Customer,

This product is provided with a 3 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred. If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery. The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. Pre-filter,

Sealing ring) or to cover damage to breakable parts.

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

• Please have the receipt and product number (IAN 494357_2504) ready as proof of purchase for all enquiries.
• Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.
• Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

PDF ONLINE parkside-diy.com

You can view and download these and many other manuals on parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 494357_2504.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

• We can only work on devices which are sent in properly packed and with postage paid.
Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.
- The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.
• We will dispose of defective devices you ship to us free of charge.

Service Centre

GB Service Great Britain Tel.: [phone] Contact form on parkside-diy.com IAN 494357_2504

MT Service Malta Tel.: [phone] Contact form on parkside-diy.com IAN 494357_2504

Importer

Please note that the address below is not a service address. Contact the service centre named above first.

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 26

Pos. nr.	1	Name Order No.
	2 2, 3 Cover (Pre-filter)	91105586
	8 66 Valve cap	91105591
	11 1 Special key	91105585
	14 63, 64 Drain plug	91100912
	20 68–72 Backflow stop	91105807
	22 4 Pre-filter	91105587

^1 Exploded view, p. 145

Translation of the original EU declaration of conformity

Product: Domestic Water Pump

Model: PEHWW 1300 B2

Serial number: 000001-006500

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2006/42/EC • 2014/30/EU • 2000/14/EC & 2005/88/EC • 2011/65/EU & (EU) 2015/863

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 60335-1:2012+A11+A13+A1+A14+A2+A15+A16

EN IEC 60335-2-41:2021+A11

EN 62233:2008 • EN ISO 12100:2010

EN IEC 55014-1:2021 • EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A2:2024

EN 61000-3-3:2013/A2:2021 • EN IEC 63000:2018

In accordance with the Directive 2000/14/EC relating to noise emission, the following is confirmed: Sound power level ( L_WA )

- Measured: 81.0 dB;

- Guaranteed: 84 dB

Followed conformity assessment procedure according to 2000/14/EC, Annex V.

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction...... 29

Garantie (France)......40

Service-Center....42

Importateur.... 42

68,0 dB; K_pA=3,16 dB

Service-Center....54

Importeur.... 54

68,0 dB; K_pA=3,16 dB

Geluidsvermogenniveau ( L_WA )

- gemeten ....81,0 dB; K_WA=3,16 dB

Service-Center....67

Importador.... 67

68,0 dB; K_pA=3,16 dB

Service-Center....80

Importatore.... 80

Ricambi e accessori.... 80

68,0 dB; K_pA=3,16 dB

- misurato 81,0 dB; K_WA=3,16 dB

- garantito 84 dB

QR code image containing encoded data, with a central logo or watermark symbol

PDF ONLINE
parkside-diy.com

- misurato: 81,0 dB;

- garantito: 84 dB

Service-Center....91

Dovozce....92

68,0 dB; K_pA=3,16 dB

Service-Center....104

Importér.... 104

68,0 dB; K_pA=3,16 dB

QR code image containing encoded data, with a central logo or watermark symbol

PDF ONLINE
parkside-diy.com

68,0 dB; K_pA=3,16 dB

QR code image containing encoded data, with a central logo or watermark symbol

PDF ONLINE parkside-diy.com

Service-Center....142

Importør.... 143

• Vanding i private haver

• Forsyning med brugsvand
