USER MANUAL PHLGB 2000 A1 PARKSIDE

Translation of the original instructions

FR BE

DECAPEUR THERMIQUE

Mode d'emploi

GB/IE User manual Page 17

List of pictograms used

Introduction 19

Intended use. Page 19
Scope of delivery 19
Description of parts . 19
Technical data. 19

Safety instructions 20

Before first use. 23

Unpacking the product. 23

Initial start-up Page 23

Operation. 23

Switching on/off. 23

After use. 24

Cleaning and care. 24

Cleaning 24
Maintenance. 25
Repair. 25
Storage. 25

Spare parts/Accessories 25

Disposal. 25

Warranty.. 25

Warranty claim procedure.. 26

Service 26

List of pictograms used
DANGER! - Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)	Read the user manual.
WARNING! - Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)	Switch off the product and disconnect it from the mains before replacing attachments, cleaning and when not in use.
CAUTION! - Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)	Use the product in dry indoor spaces only.
	Manufacturer
NOTICE! - Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)	~ Alternating current/voltage
	T3.15A	Fuse
Wear protective gloves.	Do not expose the product to rain or moisture.
Wear hearing protection.	Caution! Hot surface. Risk of burns.
Wear eye protection. Protection class I
CE mark indicates conformity with relevant EU directives applicable for this product.	Safety information Instructions for use

HEAT GUN

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

The product is only intended for the following applications:
- Removing paint
- Heating (e.g. heat-shrink tubing)
- Moulding and welding plastics
- Ungluing adhesive joints
- Defrosting water pipes
Use the product in dry indoor spaces only.
The product is exclusively intended for domestic use.
The product is not intended for commercial or industrial use.
Only use the product as described and only for the indicated fields of application.
Any other use or modification of the product is considered to be unauthorised use and entails considerable risk of accidents.
The manufacturer assumes no liability for damages resulting from unauthorised use.
The operator or user of the product is responsible for any accidents or personal injury and/or material damage to third parties or their property.

Scope of delivery

DANGER!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

After unpacking the product, check if the delivery is complete and if all parts are in good condition. Remove all packaging materials before use.

1 Heat Gun
1 Restrictor
1 Surface nozzle
1 Spatula nozzle
1 User manual

Description of parts

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the product.

1Hot air outlet

2Foot

3Air inlet

4On/off switch

5Foot

6Mains cord with mains plug

7Spatula nozzle

8Surface nozzle

9Restrictor

Technical data

Heat Gun PHLGB 200 A1
Model number
VDE plug: HG12955
BS plug: HG12955-BS
CH plug: HG12955-CH
Rated input voltage: 230 V~, 50 Hz
Rated input power: 2,000 W
Protection class:	II/回 (double insulation)
Level I Temperature: 350 °C Air quantity: 300 l/min
Level II Temperature: 550 °C Air quantity: 500 l/min

Safety instructions

BEFORE USING THE PRODUCT, FAMILIARISE YOURSELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, ALSO INCLUDE ALL THE DOCUMENTS!

In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid! No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

Children and persons with limitations

WARNING! DANGER OF DEATH AND ACCIDENTS FOR TODDLERS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers.

This product can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.

Children shall not play with the product. Keep the product and the mains cord out of reach of children.

Cleaning and user maintenance shall not be made by children without supervision.

Intended use

WARNING! Risk of injury! Misuse may lead to injury. Use this product solely in accordance with these instructions. Do not attempt to modify the product in any way.

• Do not use the product as a hair dryer.

Electrical safety

WARNING! Risk of electric shock! Never attempt to repair the product yourself. In case of malfunction, repairs are to be conducted by qualified personnel only.

WARNING! Risk of electric shock! Do not immerse the product's electrical components in water or other liquids. Never hold the product under running water.

WARNING! Risk of electric shock! Never use a damaged product.

Disconnect the product from the mains supply and contact your retailer if it is damaged.

Before connecting the mains plug to the mains supply: Check that the voltage and the current rating correspond with the mains supply details shown on the product's rating label.

Regularly check the mains plug and the mains cord for damages. If the mains cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

• Protect the mains cord against damages. Do not let it hang over sharp edges, do not squeeze or bend it. Keep the mains cord away from hot surfaces and open flames.

The product must only be connected to a socket-outlet via a residual-current circuit breaker (RCD) with a rated leakage current of not more than 30mA .

Operation

A fire may result if the product is not used with care, therefore:

-Be careful when using the product in places where there are combustible materials.
-Do not apply to the same place for a long time.
-Do not use in presence of an explosive atmosphere.
-Be aware that heat may be conducted to combustible materials that are out of sight.
- After use: Place the product on a heat-resistant, stable and secure surface. Position both feet downwards and the hot air outlet upwards.
-Allow the product to cool down before storage.
-Do not leave the product unattended when it is switched on.

Do not point the hot air outlet at people or animals.
- Do not touch the hot air outlet or a hot nozzle.

• Keep a distance between the nozzle and the surface to be heated. Otherwise there is a risk of overheating.
  Disconnect the product from the socket-outlet

• when a malfunction occurs,
  -before attaching/ changing accessories,
  -before cleaning the product,
  -during a thunderstorm and
  -after each use.

• Disconnect the product from the socket-outlet by pulling the mains plug, but not by pulling on the mains cord.
  Only use spare parts and accessories which are supplied and recommended by the manufacturer. Using foreign parts results in the immediate loss of any warranty claim.

• Do not obstruct the ventilation slots during operation. Risk of overheating and damage to the product.

• Do not use the product anymore if it has been dropped.

• Do not use the product if you are tired, lacking in concentration or have consumed alcohol or tablets. Always have a break on time. Use common sense when using the product.

Cleaning and storage

CAUTION! Risk of injury!

Disconnect the product from the mains supply before cleaning work and when not in use.

• Protect the product, its mains cord and mains plug against dust, direct sunlight, dripping and splashing water.
  After each use: Clean the product (see "Cleaning and care").
  Store the product in a cool, dry place, protected from moisture and out of the reach of children.

Before first use

Unpacking the product

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.

2. Check to make sure that all listed parts are included (see "Scope of delivery").

3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter "Warranty".

- Initial start-up

• When you switch on the product for the first time, some smoke may escape. The smoke is caused by binding agents which are released from the insulation film of the heating element due to the heat.
  Ensure that the smoke escapes quickly: Place the product on a heat-resistant, stable and secure surface. Position both feet 2 5 downwards and the hot air outlet 1 upwards.
• Ventilate the work area. If the formation of smoke or the odour is too strong, carry out the initial start-up outdoors in a dry area.

Operation

• Operate the product in one of the following positions: -Hold the product with your hand. or -Place the product on a heat-resistant, stable and secure surface. Position both feet 2 × 5 downwards and the hot air outlet 1 upwards.

- Switching on/off

Connect the mains plug 6 to a suitable socket-outlet.

On/off switch 4	Meaning
Position I Switched	on at level I ■ 350 °C ■ 300 l/min
Position II Switched	on at level II ■ 550 °C ■ 500 l/min
Middle position O Switched off

Attachments

CAUTION! Risk of burns!

Before mounting/changing attachments:

Switch off the product.
-Disconnect the mains plug 6 from the socket-outlet.
- Let the product and any mounted attachment cool down.

NOTICE! Risk of property damage!

When using the surface nozzle: Pay particular attention to the heat development at the areas adjacent to the processing point. Do not point the surface nozzle at one spot for too long to avoid overheating any adjacent parts.
When using the restrictor: Pay particular attention to the heat development at the processing point. Do not point the restrictor at one spot for too long to avoid overheating the workpiece.

NOTE

When using the spatula nozzle Use a regular spatula to scrape off paint and lacquer. The spatula nozzle is not suitable for scraping off paint and lacquer.

Mount the desired attachment to the hot air outlet 1:

Attachment Purpose
Spatula nozzle 7	Targeted hot air supply to paint and lacquer surfaces
Surface nozzle 8	Heat over a wide area
Restrictor 9 Selective heat

After use

1. Switch off the product. Disconnect the mains plug 6 from the socket-outlet.
2. Allow the product to cool down: Place the product on a heat-resistant, stable and secure surface. Position both feet 2 5 downwards and the hot air outlet 1 upwards.
3. Check, clean and store the product (see "Cleaning and care").

Cleaning and care

WARNING!

Switch off the product and disconnect it from the mains before replacing attachments, cleaning and when not in use.

Cleaning

• Do not immerse the product in water or other liquids.
• Do not allow liquids to enter the inside of the product.
• Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.
• Keep the product clean, dust-free, dry and free from oil or grease.

Clean the product with a soft, dry and lint-free cloth. Use a soft brush for areas that are hard to reach.

- Maintenance

Before and after each use: Check the product and its accessories for wear and damage.

Repair

This product does not contain any parts that can be repaired by the user.
- Contact an authorised service centre or a similarly qualified person to have the product checked and repaired.

Storage

Before storage: Allow the product to cool down.
Store the product in a cool, dry place, protected from moisture and out of the reach of children.

- Spare parts/Accessories

Customers can obtain compatible spare parts and accessories via e-mail or our service hotline (see "Service").
Have the item number (IAN 477763_2410) ready for your order.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 477763_2410) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and

information on the details of the defect and when it occurred.

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 477763_2410 takes you to the operating instructions for your item.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]
